Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Backup Lamp Retaining Screws | 2 N.m | 18 lb in |
| Headlamp Door Access Cover Fastener | 7-11 N.m | 62-98 lb in |
| License Lamp Assembly Retaining Screws | 2 N.m | 18 lb in |
| Rear License Assembly Retaining Screws | 2 N.m | 18 lb in |
| Tail Lamp Fasteners | 6 N.m | 53 lb in |
Fastener Tightening Specifications
Lighting Systems Schematic Icons Icon Icon Definition CAUTION: When performing service on or near the SIR components or the SIR wiring, the SIR system must be disabled. Refer to SIR Disabling and Enabling Zones. Failure to observe the correct procedure could cause deployment of the SIR components, personal injury, or unnecessary SIR system repairs
Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
| Callout | Component Name |
|---|---|
| 1 | Turn Signal/Multifunction Switch |
| 2 | Hazard Switch |
| 3 | Horn Switch |
| 4 | Mode/AM/FM Switch |
| 5 | Volume Up/Down Switch |
| 6 | Select/Personalization Switch |
| 7 | Fuel/Trip Switch |
| 8 | Data Link Connector (DLC) |
| 9 | Headlamp Switch |
Scheme 15
| Callout | Component Name |
|---|---|
| 1 | Head Lamp High Beam - Right |
| 2 | Head Lamp Low Beam - Right |
| 3 | Marker Lamp - RF |
| 4 | Park/Turn Signal Lamp - LF |
| 5 | Marker Lamp - LF |
| 6 | Head Lamp Low Beam - Left |
| 7 | Head Lamp High Beam - Left |
| 8 | Fog Lamp - LF |
| 9 | Park/Turn Signal Lamp - RF |
| 10 | Fog Lamp - RF |
Scheme 16
| Callout | Component Name |
|---|---|
| 1 | Marker Lamp - RR |
| 2 | Center High Mounted Stop Lamp (CHMSL) |
| 3 | Tail/Stop and Turn Signal Lamp - Right |
| 4 | License Lamps |
| 5 | Backup Lamp - Right |
| 6 | Backup Lamp - Left |
| 7 | Tail/Stop and Turn Signal Lamp - Left |
| 8 | Marker Lamp - LR |
| 9 | I/P Harness |
| 10 | Ambient Light Sensor |
| 11 | Radio |
Scheme 17
| Callout | Component Name |
|---|---|
| 1 | Inside Rear View Mirror (ISRVM) (w/o DJ2) |
| 2 | Reading Lamp Switch (w/o DJ2) |
| 3 | Reading Lamp Switch (w/o DJ2) |
| 4 | Reading Lamp Switch (DJ2) |
| 5 | Electrochromic On/Off Switch (DJ2) |
| 6 | Garage Door Opener (DJ2) |
| 7 | Inflatable Restraint I/P Module Disable Switch |
| 8 | I/P Compartment Lamp |
| 9 | Rear Compartment Lid Release Switch - Interior |
Scheme 18
| Callout | Component Name |
|---|---|
| 1 | Vanity Mirror Lamp - Left Connector |
| 2 | Left Sunshade |
| 3 | Right Sunshade |
| 4 | Vanity Mirror Lamp - Right Connector |
| 5 | Vanity Mirror Lamp - Right |
| 6 | Inside Rearview Mirror |
| 7 | Reading Lamp Switch |
| 8 | Electrochromic Mirror On/Off Switch |
| 9 | Garage Door Opener |
| 10 | Vanity Mirror Lamp - Left |
Ambient Light Sensor Connector End Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A WH 278 Ambient Light Sensor Signal B BK 279 Ambient Light Sensor Low Reference
Backup Lamp - Left Connector End Connector Part Information 12160392 3-Way F Lamp Socket Components, Bulb Bases, Type C-2, Right Angle (GY) Pin Wire Color Circuit No. Function A L-GN 24 Backup Lamp Supply Voltage B - - Not Used G BK 1550 Ground
Backup Lamp - Right Connector End Connector Part Information 12160392 3-Way F Lamp Socket Components, Bulb Bases, Type C-2, Right Angle (GY) Pin Wire Color Circuit No. Function A L-GN 24 Backup Lamp Supply Voltage B - - Not Used G BK 1550 Ground
Center High Mounted Stop Lamp (CHMSL) Connector End Connector Part Information 15358845 2-Way F GT 150 Series, Sealed 4.0 (BK) Pin Wire Color Circuit No. Function A YE 820 CHMSL Supply Voltage B BK 1550 Ground
Daytime Running Lamp (DRL) Diode Connector End Connector Part Information 12064749 2-Way F Metri-Pack 480 Series (BK) Pin Wire Color Circuit No. Function A OG 840 Battery Positive Voltage OG 840 Battery Positive Voltage B YE 634 DRL Relay Coil Supply Voltage
Fog Lamp - LF Connector End Connector Part Information 12124819 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A PU 34 Fog Lamp Supply Voltage B BK 350 Ground
Fog Lamp - RF Connector End Connector Part Information 12124819 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A PU 34 Fog Lamp Supply Voltage B BK 350 Ground
Headlamp - Left High Beam Connector End Connector Part Information 15336116 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function 1 D-GN/WH 711 Left Headlamp High Beam Supply Voltage 2 BK 350 Ground
Headlamp - Left Low Beam Connector End Connector Part Information 12124819 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A YE 712 Left Headlamp Low Beam Supply Voltage B BK 350 Ground
Headlamp - Right High Beam Connector End Connector Part Information 15336116 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function 1 L-GN/BK 311 Right Headlamp High Beam Supply Voltage 2 BK 250 Ground
Headlamp - Right Low Beam Connector End Connector Part Information 12124819 2-Way F Metri-Pack 280 Series, Sealed (BK) Pin Wire Color Circuit No. Function A TN/WH 312 Right Headlamp Low Beam Supply Voltage B BK 250 Ground
Headlamp Switch Connector End Connector Part Information IL-AG5-18S-D3C1 18-Way F (GN) Pin Wire Color Circuit No. Function 1 GY 705 5 Volt Reference 2-3 - - Not Used 4 BK 2250 Ground 5-6 - - Not Used 7 OG 192 Fog Lamps Enable 8 GY/BK 308 Park Lamp Switch On Signal 9 OG/BK 2090 Instrument Panel Lamp Dimming Control 10 GY/BK 2226 Instrument Panel Lamp Dimming Switch Low Reference 11 - - Not Used 12 BN/WH 230 Instrument Panel Lamp Dimming Control 13 PU 34 Front Fog Lamp Supply Voltage 14-15 - - Not Used 16 BK 2250 Ground 17 WH 103 Headlamp Switch Headlamps On Signal 18 - - Not Used
I/P Compartment Lamp Connector End Connector Part Information 12047662 2-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A OG 1732 Inadvertent Courtesy Lamp Supply Voltage B BK 2250 Ground
Inside Rear Mirror (ISRVM) - DJ2 Connector End Connector Part Information 936163-2 10-Way F 2x5, 0.64 mm Unsealed (BK) Pin Wire Color Circuit No. Function 1-2 - - Not Used 3 BK 1450 Ground 4 GY 1690 Automatic Day/Night Mirror Signal 5 OG 3140 Battery Positive Voltage 6 PK 639 Ignition 1 Voltage 7 L-GN 24 Backup Lamp Supply Voltage 8 GY/BK 690 Courtesy Lamp Supply Voltage 9 PK 1691 Automatic Day/Night Mirror Low Reference 10 - - Not Used
Inside Rear Mirror (ISRVM) - w/o DJ2 Connector End Connector Part Information VHR-7N-BK 7-Way F (BK) Pin Wire Color Circuit No. Function 1 - - Not Used 2 OG 1732 Inadvertent Power Courtesy Lamps Supply Voltage 3-5 - - Not Used 6 GY/BK 690 Courtesy Lamp Supply Voltage 7 BK 1450 Ground
License Lamp - Left Connector End Connector Part Information 12110053 2-Way F Lamp Socket Wedge Base W2 (L-GY) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park and License Lamps Supply Voltage B BK 1550 Ground
License Lamp - Right Connector End Connector Part Information 12110053 2-Way F Lamp Socket Wedge Base W2 (L-GY) Pin Wire Color Circuit No. Function A BN 2509 Left Rear Park and License Lamps Supply Voltage B BK 1550 Ground
Marker Lamp - LF Connector End Connector Part Information E3550-000 2-Way F (BK) Pin Wire Color Circuit No. Function 1 BN 2309 Front Park Lamps Supply Voltage 2 L-BU 2114 Left Turn Signal Lamps Supply Voltage
Marker Lamp - LR Connector End Connector Part Information E3550-000 2-Way F (BK) Pin Wire Color Circuit No. Function 1 BN 2509 Left Rear Park Lamps Supply Voltage 2 BK 1550 Ground
Marker Lamp - RF Connector End Connector Part Information E3550-000 2-Way F (BK) Pin Wire Color Circuit No. Function 1 BN 2309 Front Park Lamps Supply Voltage 2 D-BU 2115 Right Turn Signal Lamps Supply Voltage
Marker Lamp - RR Connector End Connector Part Information E3550-000 2-Way F (BK) Pin Wire Color Circuit No. Function 1 BN/WH 2609 Right Rear Park Lamps Supply Voltage 2 BK 1550 Ground
Park/Turn Signal Lamp - LF Connector End Connector Part Information Unknown 3-Way F Lamp Socket (TN) Pin Wire Color Circuit No. Function A GN - Left Turn Signal Lamps Supply Voltage B RD/OG - Front Park Lamps Supply Voltage C BK - Ground
Scheme 19
Park/Turn Signal Lamp - RF Connector End Connector Part Information Unknown 3-Way F Lamp Socket (TN) Pin Wire Color Circuit No. Function A GN - Right Turn Signal Lamps Supply Voltage B RG/OG - Front Park Lamps Supply Voltage C BK - Ground
Rear Compartment Lid Lamp - (ERK) Connector End Connector Part Information 12047781 3-Way F Metri-Pack 150 Series, (BK) Pin Wire Color Circuit No. Function A WH - Inadvertent Courtesy Lamps Supply Voltage B BK - Ground C - - Not Used
Rear Compartment Lid Lamp Relay - (ERK) Connector End Connector Part Information 206434-1 8-Way F Plug, Series 2, (BK) Pin Wire Color Circuit No. Function 1 L-GN 1732 Inadvertent Courtesy Lamps Supply Voltage 2 BK 1550 Ground 3 OG 744 Rear Compartment Lid Ajar Switch Signal 4-8 - - Not Used
Scheme 20
Stop Lamp Switch Connector End Connector Part Information 12040551 6-Way F Metri-Pack 480 Series (BK) Pin Wire Color Circuit No. Function A WH 17 Stop Lamp Switch Signal WH 17 Stop Lamp Switch Signal B OG 1540 Battery Positive Voltage C PU 420 TCC Brake Switch/Cruise Control Release Signal D PK 639 Run/Crank Ignition 1 Voltage E D-GN/WH 1135 A/T Shift Lock Control Solenoid Supply Voltage D-GN/WH 1135 A/T Shift Lock Control Solenoid Supply Voltage F L-GN/BK 584 A/T Shift Lock Control Switch Supply Voltage
Tail/Stop and Turn Signal Lamp - Left Connector End Connector Part Information ZFI-00701-UA 3-Way F (BK) Pin Wire Color Circuit No. Function 1 BK 1550 Ground 2 BN 2509 Left Rear Park Lamps Supply Voltage 3 YE/BK 1618 Trailer Left Rear Turn/Stop Lamp Supply Voltage
Tail/Stop and Turn Signal Lamp - Right Connector End Connector Part Information ZFI-00701-UA 3-Way F (BK) Pin Wire Color Circuit No. Function 1 BK 1550 Ground 2 BN/WH 2609 Right Rear Park Lamps Supply Voltage 3 D-GN 1619 Trailer Right Rear Turn/Stop Lamp Supply Voltage
Turn Signal/Hazard Flasher Module Connector End Connector Part Information 15359360 10-Way F Metri-Pack Mixed Series (GY) Pin Wire Color Circuit No. Function A L-GN 1427 Right Turn Signal Switch Signal B WH 17 Stop Lamp Switch Signal C YE 18 Left Rear Stop/Turn Lamp Supply Voltage D D-GN 19 Right Rear Stop/Turn Lamp Supply Voltage E BK 2250 Ground F D-GN 1428 Left Turn Signal Switch Signal G WH 111 Hazard Switch Signal H YE 685 Left Turn Lamp Supply Voltage J TN 686 Right Turn Lamp Supply Voltage K OG 140 Battery Positive Voltage
Turn Signal/Multifunction Switch C1 Connector End Connector Part Information 12064862 8-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A L-GN 1427 Right Turn Signal Switch Signal B PK 639 Ignition 1 Voltage C D-GN 1428 Left Turn Signal Switch Signal D OG 57 Left Cornering Lamp Supply Voltage E BN 2309 Front Park Lamps Supply Voltage F BK 58 Right Cornering Lamp Supply Voltage G BK/YE 28 Horn Relay Control H WH 111 Hazard Switch Signal
Turn Signal/Multifunction Switch C2 Connector End Connector Part Information 12059800 5-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A TN 751 Ground B YE/BK 307 Headlamp Switch Flash to Pass Signal C L-GN 11 Headlamp Dimmer Switch Signal D-E - - Not Used
Turn Signal/Multifunction Switch C3 Connector End Connector Part Information 15339058 7-Way F Metri-Pack 150 Series (GY) Pin Wire Color Circuit No. Function G - - Not Used H PK 94 Windshield Wiper Switch Signal J GY 478 Windshield Wiper Switch Supply Voltage K D-BU/WH 477 Windshield Wiper Switch High Signal L-N - - Not Used
Turn Signal/Multifunction Switch C4 (w/K34) Connector End Connector Part Information 12047786 4-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BN 341 Ignition 3 Voltage B GY/WH 397 Cruise Control On Switch Signal C GY/BK 87 Cruise Control Resume/Accel Switch Signal D D-BU 84 Cruise Control Set/Coast Switch Signal
Vanity Mirror Lamp - Left Connector End Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BK 1450 Ground B OG 1732 Inadvertent Courtesy Lamps Supply Voltage C - - Not Used
Vanity Mirror Lamp - Right Connector End Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A BK 1450 Ground B OG 1732 Inadvertent Courtesy Lamps Supply Voltage C - - Not Used
Begin the system diagnosis with the Diagnostic System Check - Lighting Systems . The Diagnostic System Check will provide the following information
- The identification of the control modules which command the system.
- The ability of the control modules to communicate through the serial data circuit.
- The identification of any stored diagnostic trouble codes (DTCs) and their status.
The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.
