Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Air Cleaner Outlet Duct Clamp Screw | 7 N.m | 62 lb in |
| Coolant Air Bleed Pipe Stud/Bolt | 12 N.m | 106 lb in |
| Coolant Heater Cord Bolt | 8 N.m | 71 lb in |
| Coolant Heater | 50 N.m | 37 lb ft |
| Engine Block Coolant Drain Plug | 60 N.m | 44 lb ft |
| Fan Clutch Bolt | 23 N.m | 17 lb ft |
| Fan Clutch Nut | 56 N.m | 41 lb ft |
| Fan Shroud Bolt | 9 N.m | 80 lb in |
| Radiator Bolt | 25 N.m | 18 lb ft |
| Surge Tank Bolt/Nut | 9 N.m | 80 lb in |
| Thermostat Housing Bolt | 15 N.m | 11 lb ft |
| Transmission Control Module (TCM) Cover Bolt | 9 N.m | 80 lb in |
| Transmission Control Module (TCM) Electrical Connector Bolt | 8 N.m | 71 lb in |
| Water Pump Bolt (First Pass) | 15 N.m | 11 lb ft |
| Water Pump Bolt (Final Pass) | 30 N.m | 22 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Engine Cooling Schematics
Scheme 2
Scheme 2: Cooling System Component Views
| Callout | Component Name |
|---|
| 1 | Cooling Fan |
| 2 | Cooling Fan Connector |
| 3 | Cooling Fan 1 Relay |
| 4 | Cooling Fan 2 Relay |
