Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Brake and Clutch Pedal Release Bracket to Pedal Mounting Bracket Bolt | 22 N.m | 16 lb ft |
| Brake and Clutch Pedal Release Bracket to Steering Column Reinforcement Bracket Bolt | 22 N.m | 16 lb ft |
| Brake Hose Fitting Bolt | 40 N.m | 30 lb ft |
| Brake Pedal Bracket Bolt | 9 N.m | 80 lb in |
| Brake Pedal Bracket Nut | 19 N.m | 14 lb ft |
| Brake Pipe Fitting | 18 N.m | 13 lb ft |
| Master Cylinder Nut | 50 N.m | 37 lb ft |
| Power Brake Booster Pump Bracket Bolt | 22 N.m | 16 lb ft |
| Power Brake Booster Pump Bracket Bolt and Nut | 22 N.m | 16 lb ft |
| Power Vacuum Brake Booster Bolt | 19 N.m | 14 lb ft |
Fastener Tightening Specifications
Brake Component Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Brake Caliper Bleeder Valve | 17 N.m | 13 lb ft |
| Rear Brake Cylinder Bleeder Valve | 9 N.m | 80 lb in |
Brake Component Specifications
Brake System Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Brake Pedal Travel Maximum specification with 450 N (101 lbs) of force applied to the pedal with the ignition OFF and the booster power reserve depleted. | 48-58 mm | 1.9-2.3 in |
Brake System Specifications
Scheme 1
