Engine Control Module (ECM) Connector End Views
Engine Control Module (ECM) - C1 Connector End Connector Part Information 15357147 56-Way F Micro 64 (BLU) Pin Wire Color Circuit No. Function 1 YEL 2361 SAE J1939 Serial Data Bus + 2 DK GRN 2362 SAE J1939 Serial Data Bus - 3-4 - - Not Used 5 ORN 440 Battery Positive Voltage 6 - - Not Used 7 ORN/BLK 1057 Low Reference 8 PNK/BLK 632 Low Reference 9 BLK/WHT 451 Ground 10 PNK 439 Ignition 1 Voltage 11-12 - - Not Used 13 YEL 492 MAF Sensor Signal 14 BRN/WHT 5763 EGR Valve Position Signal 15 DK GRN 1049 Class 2 Serial Data 16 YEL 710 Class 2 Serial Data 17 TAN 1274 5-Volt Reference 18 PNK 1020 Ignition 0 Voltage (M74) 19 PNK 439 Ignition 1 Voltage 20 ORN 440 Battery Positive Voltage 21 GRY 2700 5-Volt Reference 22 - - Not Used 23 ORN/BLK 5929 5-Volt Reference 24-25 - - Not Used 26 DK BLU 507 Wait to Start Indicator Control 27 - - Not Used 28 LT BLU 1162 APP Sensor 2 Signal 29 - - Not Used 30 PPL/WHT 1589 Fuel Level Sensor Signal - Primary 31 WHT/BLK 2932 5-Volt Reference 32 WHT/BLK 1164 5-Volt Reference 33 TAN 2917 5-Volt Reference 34 GRY 2705 5-Volt Reference 35 - - Not Used 36 YEL/BLK 1275 5-Volt Reference 37 YEL 2834 Fuel Pressure Regulator Solenoid Control 38 - - Not Used 39 GRY 597 5-Volt Reference 40 PPL/WHT 2530 Fuel Pressure Regulator Solenoid Supply Voltage 41 GRY 23 Generator Field Duty Cycle Signal 42 PNK 1039 Ignition 1 Voltage 43 DK BLU 1936 Fuel Level Sensor Signal - Secondary 44 DK GRN/WHT 465 Fuel Pump Relay Control 45 - - Not Used 46 YEL/BLK 1827 Vehicle Speed Sensors 47 GRY 2703 5-Volt Reference 48-49 - - Not Used 50 RED 631 5-Volt Reference 51 YEL 2834 Fuel Pressure Regulator Solenoid Control 52 GRY/BLK 2219 FICM Relay Control 53 DK GRN/WHT 817 Vehicle Speed Signal 54 PPL/WHT 2530 Fuel Pressure Regulator Solenoid Supply Voltage 55 - - Not Used 56 PNK 1039 Ignition 1 Voltage
Engine Control Module (ECM) - C2 Connector End Connector Part Information 15357131 73-Way F Micro 64 (BLK) Pin Wire Color Circuit No. Function 1 - - Not Used 2 ORN/BLK 2919 Low Reference 3 - - Not Used 4 BRN 25 Charge Indicator Control 5-6 - - Not Used 7 GRY/BLK 1694 4WD Low Signal 8 BLK 2754 Low Reference 9-12 - - Not Used 13 BLK 2751 Low Reference 14 GRY 720 Low Reference 15-16 - - Not Used 17 YEL/BLK 508 Water in Fuel Indicator Control 18 - - Not Used 19 DK BLU 1161 APP Sensor 1 Signal 20 - - Not Used 21 DK BLU 2466 Trans MIL Request 22 - - Not Used 23 LT GRN 432 Turbocharger Boost Sensor Signal 24 DK GRN 1163 APP Sensor 3 Signal 25 TAN/WHT 332 Oil Pressure Sensor Signal 26 BRN 1174 Oil Level Switch Signal 27 YEL 1578 Fuel Temperature Signal 28 LT GRN 1867 12-Volt Reference 29 GRY/BLK 2931 Low Reference 30 ORN/BLK 469 Low Reference 31 YEL 5775 Turbocharger Vane Position Sensor Signal 32 - - Not Used 33 ORN/BLK 5764 EGR Motor High Control 34 - - Not Used 35 LT GRN/ BLK 5746 EGR Motor Low Control 36 BLK/WHT 451 Ground 37 - - Not Used 38 LT GRN 1478 Coolant Level Switch Signal 39 BLK 2755 Low Reference 40 BRN 1271 Low Reference 41 - - Not Used 42 YEL 2918 FRP Sensor Signal 43 - - Not Used 44 TAN 5928 Low Reference 45 - - Not Used 46 GRY/BLK 433 Baro Sensor Signal 47-48 - - Not Used 49 DK BLU 5930 Turbocharger Vane Position Control Solenoid Valve High Control 50 WHT 5931 Low Reference 51 - - Not Used 52 PNK/BLK 1746 Fuel Injector 3 Control 53 ORN/BLK 5764 EGR Motor High Control 54 PPL 1272 Low Reference 55 LT GRN/ BLK 5746 EGR Motor Low Control 56 GRY 1273 Low Reference 57 BRN 2524 Generator 2 Turn on Signal (K65 or 8X5) 58 BLK 552 Low Reference 59 - - Not Used 60 LT BLU 1320 CHMSL Supply Voltage 61 PPL 420 TCC Brake Switch/Cruise Control Release Signal 62 - - Not Used 63 LT BLU 2832 Engine Speed Signal 64 BLK 470 Low Reference 65 LT GRN/BLK 1745 Fuel Injector 2 Control 66 RED/BLK 877 Fuel Injector 7 Control 67 YEL 410 ECT Sensor Signal 68 DK BLU/WHT 878 Fuel Injector 8 Control 69 LT BLU/BLK 844 Fuel Injector 4 Control 70 BLK/WHT 845 Fuel Injector 5 Control 71 YEL/BLK 846 Fuel Injector 6 Control 72 BLK 1744 Fuel Injector 1 Control 73 BLK/WHT 451 Ground
Scheme 359
Engine Control Module (ECM) - C3 Connector End Connector Part Information 15357148 56-Way F Micro 64 (GRY) Pin Wire Color Circuit No. Function 1 LT BLU 494 PTO Engine Kill Signal (PTO) 2-4 - - Not Used 5 GRY/BLK 5765 Fuel Filter Pressure Switch Signal 6 LT GRN 488 PTO on Switch Signal (PTO) 7 - - Not Used 8 BLK/WHT 1695 Front Axle Switch Signal 9 - - Not Used 10 PNK 1039 Ignition 1 Voltage 11 - - Not Used 12 PPL/WHT 821 VSS High Signal (ML6) YEL 400 VSS High Signal (M74) 13 - - Not Used 14 PNK 1039 Ignition 1 Voltage 15-16 - - Not Used 17 YEL 2522 PTO Engage Signal (PTO) 18 PPL 806 Crank Voltage 19 DK BLU 84 Cruise Control Set/Coast Switch Signal (K34) 20-21 - - Not Used 22 GRY/BLK 87 Cruise Control Resume/Accel Switch Signal (K34) 23 LT GRN/BLK 822 VSS Low Signal (ML6) 24 TAN 472 IAT Sensor Signal 25-29 - - Not Used 30 GRY 397 Cruise Control on Switch Signal (K34) 31 ORN/BLK 1786 Park/Neutral Signal 32 - - Not Used 33 RED/BLK 380 A/C Refrigerant Pressure Sensor Signal 34 - - Not Used 35 YEL/BLK 625 Starter Enable Relay Control 36 - - Not Used 37 WHT 121 Engine Speed Signal 38 - - Not Used 39 PPL 2562 PTO Control (PTO) 40 BRN/WHT 419 MIL Control 41 DK GRN/WHT 459 A/C Compressor Clutch Relay Control 42 - - Not Used 43 YEL/BLK 1868 Low Reference 44 BLK/WHT 451 Ground 45 GRY 1524 Backup Lamp Supply Voltage 46 - - Not Used 47 GRY 48 CPP Switch Signal (ML6) 48 BRN 718 Low Reference 49-50 - - Not Used 51 BRN/WHT 633 CMP Sensor Signal 52 DK BLU/WHT 1869 CKP Sensor Signal 53 YEL 505 Glow Plug Control 54-56 - - Not Used
Engine Controls Connector End Views
Accelerator Pedal Position (APP) Sensor Connector End Connector Part Information 15318071 10-Way F Metri-Pack 150 Series (GRY) Pin Wire Color Circuit No. Function A GRY 1273 Low Reference B PPL 1272 Low Reference C LT BLU 1162 APP Sensor 2 Signal D TAN 1274 5-Volt Reference E BRN 1271 Low Reference F DK BLU 1161 APP Sensor 1 Signal G WHT/BLK 1164 5-Volt Reference H - - Not Used J YEL/BLK 1275 5-Volt Reference K DK GRN 1163 APP Sensor 3 Signal
BARO Sensor Connector Part Information 12129946 3-Way F M/P 150 Series Sealed (GRY) Pin Wire Color Circuit No. Function A ORN/BLK 1057 Low Reference B GRY/BLK 433 BARO Sensor Signal C WHT/BLK 2932 5-Volt Reference
Boost Pressure Sensor Connector End Connector Part Information 12129946 3-Way F Sealed (GRY) Pin Wire Color Circuit No. Function A ORN/BLK 469 Low Reference B LT GRN 432 Turbocharger Boost Sensor Signal C GRY 597 5-Volt Reference
Camshaft Position (CMP) Sensor Connector End Connector Part Information 6248-5317 3-Way F Sealed (GRY) Pin Wire Color Circuit No. Function 1 BRN/WHT 633 CMP Sensor Signal 2 PNK/BLK 632 Low Reference 3 RED 631 5-Volt Reference
Crankshaft Position (CKP) Sensor Connector End Connector Part Information 6248-5317 3-Way F Sealed (GRY) Pin Wire Color Circuit No. Function 1 DK BLU/WHT 1869 CKP Sensor Signal 2 YEL/BLK 1868 Low Reference 3 LT GRN 1867 12-Volt Reference
Engine Coolant Temperature (ECT) Sensor Connector End Connector Part Information 12162192 2-Way Metri-Pack 150.2 Series, Sealed, Pull To Seat (BLK) Pin Wire Color Circuit No. Function A GRY 720 Low Reference B YEL 410 ECT Sensor Signal
Exhaust Gas Recirculation (EGR) Valve Connector End Connector Part Information 6195-0021 6-Way F DL Series Sealed (GRY) Pin Wire Color Circuit No. Function A PPL 2703 5-Volt Reference B YEL/BLK 2754 Low Reference C DK BLU/WHT 5763 EGR Valve Position Signal D PNK 5764 EGR Motor High Control E - - Not Used F WHT 5746 EGR Motor Low Control
Fuel Heater Connector End Connector Part Information 7118-3320-30 2-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 PNK 239 Ignition 1 Voltage 2 BLK 50 Ground
Fuel Injection Control Module (FICM) Connector End - C1 Connector Part Information 1928403454 81-Way F Bosch Series (BLK) Pin Wire Color Circuit No. Function 1 WHT/LT GRN IC18 Fuel Injector 4 Command 2 YEL/BLK IZ17 Ground 3 ORN IC13 Injector Supply Voltage 4 RED/LT GRN IC15 Fuel Injector 1 Command 5 PNK 339 Ignition 1 Voltage 6-43 - - Not Used 44 LT BLU/BLK 844 Fuel Injector 4 Control 45 BLK/WHT 845 Fuel Injector 5 Control 46 - - Not Used 47 PNK/BLK 1746 Fuel Injector 3 Control 48 RED/BLK 877 Fuel Injector 7 Control 49-58 - - Not Used 59 DK BLU/WHT IC20 Fuel Injector 6 Command 60 DK BLU/WHT IC520 Fuel Injector 6 Command 61 WHT/RED IC21 Fuel Injector 7 Command 62 WHT/RED IC521 Fuel Injector 7 Command 63 DK BLU/WHT 878 Fuel Injector 8 Control 64 YEL/BLK 846 Fuel Injector 6 Control 65 - - Not Used 66 BLK 1744 Fuel Injector 1 Control 67 LT GRN/BLK 1745 Fuel Injector 2 Control 68-81 - - Not Used
Fuel Injection Control Module (FICM) Connector End - C2 Connector Part Information 1928403462 40-Way F Bosch Series (BLK) Pin Wire Color Circuit No. Function 82-89 - - Not Used 90 DK GRN 2362 SAE J1939 Serial Data Bus - 91 YEL 2361 SAE J1939 Serial Data Bus + 92-93 - - Not Used 94 LT BLU 2832 Engine Speed Signal 95-113 - - Not Used 114 BLK/GRN IZ18 Ground 115 WHT/LT BLU IC17 Fuel Injector 3 Command 116 RED/LT GRN IC19 Fuel Injector 5 Command 117 - - Not Used 118 RED/WHT IC60 Injector Supply Voltage 119 PNK 339 Ignition 1 Voltage 120 WHT/GRN IC22 Fuel Injector 8 Command 121 WHT/YEL IC16 Fuel Injector 2 Command
Scheme 360
Fuel Injector 1 Connector End Connector Part Information 1928403874 2-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 RED/LT GRN IC15 Fuel Injector 1 Command 2 ORN IC13 Injector Supply Voltage
Fuel Injector 2 Connector End Connector Part Information 1928403874 2-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 WHT/YEL IC16 Fuel Injector 2 Command 2 RED/WHT IC14 Injector Supply Voltage
Fuel Injector 3 Connector End Connector Part Information 1928403874 2-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 WHT/BLU IC17 Fuel Injector 3 Command 2 RED/WHT IC60 Injector Supply Voltage
Fuel Injector 4 Connector End Connector Part Information 1928403874 2-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 WHT/LT GRN IC18 Fuel Injector 4 Command 2 ORN IC62 Injector Supply Voltage
Fuel Injector 5 Connector End Connector Part Information 1928403874 2-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 RED/LT GRN IC19 Fuel Injector 5 Command 2 RED/WHT IC61 Injector Supply Voltage
Fuel Injector 6 Connector End Connector Part Information 1928403874 2-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 DK BLU/WHT IC20 Fuel Injector 6 Command 2 ORN IC64 Injector Supply Voltage
Fuel Injector 7 Connector End Connector Part Information 1928403874 2-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 WHT/RED IC21 Fuel Injector 7 Command 2 ORN IC63 Injector Supply Voltage
Fuel Injector 8 Connector End Connector Part Information 1928403874 2-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 WHT/GRN IC22 Fuel Injector 8 Command 2 RED/WHT IC65 Injector Supply Voltage
Fuel Level Sensor Connector End - Primary Connector Part Information 12160563 2-Way F Metri-Pack 150 Series Sealed (NAT) Pin Wire Color Circuit No. Function A PPL 1589 Fuel Level Sensor Signal - Primary B - C - - Unavailable D ORN/BLK 510 Low Reference
Fuel Level Sensor Connector End - Secondary w/Dual Tanks Connector Part Information 12160563 2-Way F Metri-Pack 150 Series Sealed (NAT) Pin Wire Color Circuit No. Function A DK BLU 1936 Fuel Level Sensor Signal - Secondary B - C - - Unavailable D ORN/BLK 510 Low Reference
Fuel Pressure Regulator Connector End Connector Part Information 12059450 3-Way M Sealed (BLK) Pin Wire Color Circuit No. Function 1 PPL/WHT 2530 Fuel Pressure Regulator Solenoid Supply Voltage 2 YEL 2834 Fuel Pressure Solenoid Control 3 BLK - Shield
Fuel Pressure Sensor Connector End Connector Part Information 1928403968 3-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 ORN/BLK 2919 Low Reference 2 YEL 2918 FRP Sensor Signal 3 TAN 2917 5-Volt Reference
Fuel Pump w/Dual Tanks Connector End Connector Part Information 12059450 2-Way M Metri-Pack 280 Series Sealed (BLK) Pin Wire Color Circuit No. Function A GRY 120 Fuel Pump Supply Voltage B BLK 1650 Ground (20 Series) BLK 2150 Ground (30 Series)
Fuel Temperature Sensor Connector End Connector Part Information 178392-6 2-Way F Sealed (GRY) Pin Wire Color Circuit No. Function 1 YEL 1578 Fuel Temperature Signal 2 BRN 718 Low Reference
Glow Plug Controller Connector End - C1 Connector Part Information 15443870 1-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 BLK 1042 Battery Positive Voltage
Glow Plug Controller Connector End - C2 Connector Part Information 60412601 E 12-Way F Sealed (BLK) Pin Wire Color Circuit No. Function 1 RED/GRN HB11 Glow Plug 1 Supply Voltage 2 WHT/GRN HB12 Glow Plug 2 Supply Voltage 3 RED/WHT HB13 Glow Plug 3 Supply Voltage 4 WHT/YEL HB14 Glow Plug 4 Supply Voltage 5 PNK 239 Ignition 1 Voltage 6 DK GRN 2362 SAE J1939 Serial Data Bus 7 RED/LT GRN HB15 Glow Plug 5 Supply Voltage 8 WHT/LT GRN HB16 Glow Plug 6 Supply Voltage 9 RED/BLU HB17 Glow Plug 7 Supply Voltage 10 WHT/BLU HB18 Glow Plug 8 Supply Voltage 11 PNK/YEL HB03 Ground 12 YEL 2361 SAE J1939 Serial Data Bus +
Intake Air Temperature (IAT)/Mass Air Flow (MAF) Sensor Connector End Connector Part Information 15324447 5-Way F 090II SLD (BLK) Pin Wire Color Circuit No. Function 1 BLK 552 Low Reference 2 TAN 472 IAT Sensor Signal 3 PNK 439 Ignition 1 Voltage 4 GRY/BLK 2931 Low Reference 5 YEL 492 MAF Sensor Signal
Turbocharger Vane Position Control Solenoid Valve Connector End Connector Part Information PR-IA066070097 2-Way F Sealed (BLK) Pin Wire Color Circuit No. Function A DK BLU 5930 Turbocharger Vane Position Control Solenoid Valve B WHT 5931 Low Reference
Turbocharger Vane Position Sensor Connector End Connector Part Information 282088-1 4-Way F Superseal 1.5 Series Sealed (BLK) Pin Wire Color Circuit No. Function A TAN 5929 5-Volt Reference B ORN/BLK 5928 Low Reference C YEL 5775 Turbocharger Vane Position Sensor Signal D - - Not Used
Scheme 361
Wiring Harness Service
The control module harness electrically connects the control module to the various solenoids, switches, and sensors in the vehicle engine compartment and passenger compartment.
Replace the wire harnesses with the proper part number replacement. When splicing signal wires into a harness, use the wiring that has high temperature insulation.
Consider the low amperage and voltage levels utilized in the powertrain control systems. Make the best possible bond at all splices. Use rosin-core solder in these areas.
Molded-on connectors require complete replacement of the connector. Splice a new connector into the harness. Replacement connectors and terminals are listed in Group 8.965 in the Standard Parts Catalog.
For wiring repair, refer to Wiring Repairs in Wiring Systems.
