Secondary and Configurable Customer Controls: Specifications Chevrolet Silverado 2500 HD

Memory Modules 4 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Steering Wheel Switch Screws2 N.m18 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Steering Wheel Secondary/Configurable Control Schematics
Scheme 1: Steering Wheel Secondary/Configurable Control Schematics

Scheme 2

Scheme 2: Secondary/Configurable Control Component Views
Scheme 2: Secondary/Configurable Control Component Views
CalloutComponent Name
1Heated Steering Wheel Control Module (KA9)
2Horn Switch
3Steering Wheel Control Switch Assembly - Right (UK3)
4Horn Switch
5Steering Wheel Control Switch Assembly - Left (K34/KA9)

Scheme 3

Scheme 3: Steering Wheel Control Switch Assembly - Left (K34/KA9)
Scheme 3: Steering Wheel Control Switch Assembly - Left (K34/KA9)
Connector Part Information Pins: 1-4, 6, 8-9 OEM: 15405522 Service: See Catalog Description: 10-Way F Receptacle 0.64 Series (GY) Terminal/Tray: 1393364-2/7 Core/Insulation Crimp: K/K Release Tool/Test Probe: 15315247/J-35616-64B (L-BU)

Steering Wheel Control Switch Assembly - Left (K34/KA9) Connector Parts Information

PinWire ColorCircuit No.Function
10.35 PK/BK144412-Volt Reference
20.35 PK5883Heated Steering Wheel Switch Signal (KA9)
30.35 GY1884Cruise Control Switch Signal
40.35 OG5884Heated Steering Wheel Switch LED Control (KA9)
5Not Used
60.35 BN6136LED Dimming Supply
7Not Used
80.35 BK1050Ground
90.35 D-GN/WH7158Cruise Control Indicator Dimming Control
10Not Used

Steering Wheel Control Switch Assembly - Left (K34/KA9) Connector Terminal Identification

Scheme 4

Scheme 4: Steering Wheel Control Switch Assembly - Right (UK3)
Scheme 4: Steering Wheel Control Switch Assembly - Right (UK3)
Connector Part Information OEM: 31068-1010 Service: See Catalog Description: 4-Way F 0.64 Series (BK)

Steering Wheel Control Switch Assembly - Right (UK3) Connector Parts Information

PinWire ColorCircuit No.Function
10.35 BK1050Ground
20.35 BN6136Supply Voltage
30.35 PK/BK144412-Volt Reference
40.35 L-GN6818Steering Wheel Resistor Ladder Signal #1
5-6Not Used

Steering Wheel Control Switch Assembly - Right (UK3) Connector Terminal Identification
