Computer/integrating Systems: Removal & Installation Chevrolet Silverado 1500

Communication Devices 1 illustration ~112 words

Installation Procedure

  1. Slide the BCM onto the bracket.
  2. Connect all the connectors (1) except the brown connector.
  3. Connect the brown connector.
  4. Install the knee bolster. Refer to «Knee Bolster Replacement»(ref-238186-S18945448682006072400000) in Instrument Panel, Gages, and Console.
  5. Connect the negative battery cables.
  6. Reprogram the BCM. Refer to «Body Control Module (BCM) Programming/RPO Configuration»(ref-238179-S23929970412006072400000) .
  7. Perform the Passlock Learn Procedure. Refer to «Programming Theft Deterrent System Components»(ref-238205-S06865753932006072400000) in Theft Deterrent.

Scheme 13

Scheme 13: Removal Procedure
  1. Remove the bolt from the data link connector (DLC).
  2. Remove the DLC from the instrument panel (I/P).
  1. Install the DLC to the I/P.
  2. Install the DLC bolt. Tighten: Tighten the bolt to 6 N.m (53 lb in).
