COMPONENT LOCATIONS
Note. For component locations refer to COMPONENT LOCATIONS table or illustrations. (Scheme 103)- (Scheme 112).
| Component | Location |
|---|---|
| Acceleration Pedal Position Sensor | Behind Accelerator Pedal |
| Body Control Module | Below Steering Column |
| Camshaft Position Sensor | Top Center Rear Of Engine |
| Crankshaft Position Sensor | Lower Right Rear Of Engine |
| Data Link Connector | Below Steering Column |
| EGR Valve | Top Right Front Of Engine |
| Engine Coolant Temperature Sensor | Left Front Of Cylinder Head |
| Engine Oil Level Switch | Right Side Of Oil Pan |
| EVAP Canister Purge Solenoid | Top Right Rear Of Engine |
| EVAP Canister Vent Solenoid | Left Front Side Of Fuel Tank |
| Fuel Pump Relay | In Underhood Junction Block |
| Fuel Tank Pressure Sensor | In Fuel Tank |
| Heated Oxygen Sensor - Bank 1, Sensor 1 | Left Exhaust Pipe, Ahead Of Catalytic Converter |
| Heated Oxygen Sensor - Bank 1, Sensor 2 | Left Exhaust Pipe, After Catalytic Converter |
| Heated Oxygen Sensor - Bank 2, Sensor 1 | Right Exhaust Pipe, Ahead Of Catalytic Converter |
| Heated Oxygen Sensor - Bank 2, Sensor 2 | Right Exhaust Pipe, After Catalytic Converter |
| Knock Sensor 1 & 2 | Under Intake Manifold |
| Manifold Absolute Pressure Sensor | Top Rear Of Engine |
| Mass Airflow Sensor | In Air Intake Duct |
| PCM | Left Front Of Engine Compartment |
| Primary Fuel Pump/Level Sensor | In Fuel Tank |
| Secondary Fuel Pump/Level Sensor | In Fuel Tank |
| Throttle Actuator Control Module | Near Front Of Engine Compartment |
| Throttle Actuator Control Motor | Near Front Of Engine Compartment |
| Throttle Position Sensor (Dual Track) | Near Front Of Engine Compartment |
| Vehicle Speed Sensor (2WD) | Left Rear Of Transmission |
| Vehicle Speed Sensor Adapter (4WD) | Left Side Of Transmission |
