COMPONENT LOCATIONS
Note. For component locations refer to COMPONENT LOCATIONS table or illustrations. (Scheme 30)- (Scheme 38).
| Component | Location |
|---|---|
| Body Control Module | Below Steering Column |
| Camshaft Position Sensor | Top Center Rear Of Engine |
| Crankshaft Position Sensor | Lower Right Rear Of Engine |
| Data Link Connector | Lower Left Side Of Instrument Panel |
| EGR Valve | Top Right Front Of Engine |
| Engine Coolant Temperature Sensor | Left Front Of Cylinder Head |
| EVAP Canister Purge Solenoid | Top Right Rear Of Engine |
| EVAP Canister Vent Solenoid | Left Front Side Of Fuel Tank |
| Fuel Pump Relay | In Underhood Fuse/Relay Block |
| Fuel Tank Pressure Sensor | In Fuel Tank |
| Heated Oxygen Sensor - Bank 1, Sensor 1 | Left Exhaust Pipe, Ahead Of Catalytic Converter |
| Heated Oxygen Sensor - Bank 1, Sensor 2 | Left Exhaust Pipe, After Catalytic Converter |
| Heated Oxygen Sensor - Bank 2, Sensor 1 | Right Exhaust Pipe, Ahead Of Catalytic Converter |
| Heated Oxygen Sensor - Bank 2, Sensor 2 | Right Exhaust Pipe, After Catalytic Converter |
| Idle Air Control Valve | On Throttle Body |
| Ignition Control Module | Top Right Side Of Engine |
| Knock Sensor | Rear Of Engine Block |
| Manifold Absolute Pressure Sensor | Top Rear Of Engine |
| Mass Airflow Sensor | In Air Intake Duct |
| Secondary Air Injection Reaction Pump | Right Rear Of Engine Compartment |
| Secondary Air Injection Reaction Relay | Right Rear Of Engine Compartment |
| Secondary Air Injection Reaction Solenoid | Right Rear Of Engine Compartment |
| Throttle Position Sensor | On Throttle Body Assembly |
| Vehicle Speed Sensor | Left Rear Of Transmission |
