Data Link Communication System: Overview Chevrolet Silverado 1500 HD

Test Description

The numbers below refer to the step numbers on the diagnostic table.

1. 1. A DTC U1001-U1254 Lost Communications with XXX with a history status may indicate the cause of U1000 or U1255.
2. 2. The modules not communicating are the likely cause of U1000 or U1255. The modules that are available on the class 2 serial data circuit are listed in the Circuit Description.
3. 6. The module which was not communicating due to a poor connection to the class 2 serial data circuit may have set DTC U1001-U1254 Lost Communications with XXX for those modules that it was monitoring.
4. 9. The modules which can communicate indicate the module which cannot communicate. You must clear the serial data communication DTCs from these modules to avoid future misdiagnosis.
5. 12. If all modules are communicating, the module which set U1000 or U1255 may have done so due to some other condition.
6. 14. The module which set U1000 or U1255 is the likely cause of the malfunction.

Scheme 14

Scheme 15

Scheme 16

The number below refers to the step number on the diagnostic table.

1. 6. The module which was not communicating on the class 2 serial data circuit may have set Loss of Communication DTCs for those modules that it was monitoring.

Scheme 17

Scheme 18

The number below refers to the step number on the diagnostic table.

1. 4. If the battery positive voltage and ground circuits of the DLC are functioning properly. The malfunction must be due to the scan tool.

Scheme 19

The numbers below refer to the step numbers on the diagnostic table.

2. A partial loss of communication in the class 2 serial data circuit uses a different procedure than a total loss of communication of the class 2 serial data circuit.

4. The following DTCs may be retrieved with a history status. These DTCs are not the cause of the present condition.

1. U1300
2. U1301
3. U1305

6. A State of Health DTC with a history status may be present along with a U1000 or U1255 with a current status. This indicates that the malfunction occurred when the ignition was on.

10. Normal class 2 serial data communication cannot take place until the body control module (BCM) module sends the appropriate power mode message. If the BCM does not send a wake-up message, other modules on the class 2 serial data circuit may not communicate.

12. Normal class 2 serial data communication cannot take place until the body control module (BCM) module sends the appropriate power mode message. If the BCM does not send a wake-up message, other modules on the class 2 serial data circuit may not communicate.

13. Normal class 2 serial data communication cannot take place until the body control module (BCM) module sends the appropriate power mode message. If the BCM does not send a wake-up message, other modules on the class 2 serial data circuit may not communicate.

19. If there are no current DTCs that begin with the letter "U", the communication concern has been repaired.

20. The communication concern may have prevented diagnosis of the customer complaint.

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Remove the bolt from the data link connector.
2. Remove the data link connector from the instrument panel.

Scheme 24

1. Install the data link connector to the instrument panel. NOTE: Refer to «FASTENER NOTICE»(ref-175132-S17785009232005041500000) .
2. Install the data link connector bolt. Tighten Tighten the bolt to 6 N.m (53 lb in).
