Body Control System: Removal & Installation Chevrolet Silverado 1500 HD

Communication Devices 4 illustrations ~105 words

Removal Procedure

CAUTIONRefer to BATTERY DISCONNECT CAUTION .

Scheme 65

Scheme 65

Scheme 66

Scheme 66
  1. Disconnect the negative battery cable(s).
  2. Remove the knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(ref-189012-S23438223692005091100000) .
  3. Disconnect the brown connector.
  4. Disconnect all other connectors (1).
  5. Remove the BCM from the sliding bracket.

Scheme 67

Scheme 67: Installation Procedure

Scheme 68

Scheme 68
  1. Slide the BCM onto the bracket.
  2. Connect all the connectors (1) except the brown connector.
  3. Connect the brown connector.
  4. Install the knee bolster. Refer to «KNEE BOLSTER REPLACEMENT»(ref-189012-S23438223692005091100000) .
  5. Connect the negative battery cable(s).
  6. Reprogram the BCM. Refer to «Body Control Module (BCM) Programming/RPO Configuration»(ref-189011-S41636714082005091300000) .
  7. Perform the passlock Learn Procedure. Refer to «PROGRAMMING THEFT DETERRENT SYSTEM COMPONENTS»(ref-189016-S23557729342005091100000)
