Automatic Transmission - 4L80-E - Service & Replacement: Overview Chevrolet Silverado 1500 HD

Scheme 972

Test Description

The numbers below refer to the step numbers on the diagnostic table.

1. This step determines if the scan tool is receiving power through the DLC connector.
2. The MIL should illuminate whenever the ignition is ON and the engine is not running.
3. This step determines if the PCM is transmitting Class 2 serial data to the DLC and that the Class 2 data circuit is not open or shorted.
4. This step determines if a DTC is current or stored in history.

Scheme 973

Scheme 974

Scheme 975

Scheme 976

Scheme 977

The numbers below refer to the step numbers on the diagnostic table.

1. 2. The normal state is the state of the input before activation.
2. 4. The normal state is the state of the input before activation.
3. 8. After replacement of the BCM you must calibrate the new module for proper operation.

Scheme 978

Scheme 979

Scheme 980

The number below refers to the step number on the diagnostic table.

1. 4. This step inspects for air restrictions and loss of transmission fluid flow, causing an extremely high TFT.

Scheme 981

Scheme 982

Scheme 983

The numbers below refer to the step numbers on the diagnostic table.

1. 4. This step tests the AT OSS circuit.
2. 7. This step tests the integrity of the AT OSS sensor.

Scheme 984

Scheme 985

Scheme 986

Scheme 987

The numbers below refer to the step numbers on the diagnostic table.

1. 3. This step tests the AT OSS assembly circuit.
2. 4. This step tests the integrity of the AT OSS sensor.

Scheme 988

Scheme 989

Scheme 990

The numbers below refer to the step numbers on the diagnostic table.

1. 5. By disconnecting the transmission range switch, the ground path of all TR switch circuits would be removed and the PCM would recognize all circuits as open. The scan tool will display HI for all range signals.
2. 6. This step tests TR switch wiring for an open or the lack of the signal voltage from the PCM.
3. 7. This step tests TR switch wiring and the PCM by providing a ground path through a fused jumper wire. When grounded, the scan tool range signal A should change to LOW.
4. 8. This step tests TR switch wiring and the PCM by providing a ground path through a fused jumper wire. When grounded, the scan tool range signal B should change to LOW.
5. 9. This step tests TR switch wiring and the PCM by providing a ground path through a fused jumper wire. When grounded, the scan tool range signal C should change to LOW.

Scheme 991

Scheme 992

Scheme 993

Scheme 994

The numbers below refer to the step numbers on the diagnostic table.

1. 2. This step tests for proper AT fluid level and condition.
2. 3. This step verifies which condition has set DTC P0711.
3. 5. The 12 volt test lamp is used as a fixed resistance.
4. 6. This step ensures that the PCM monitors the TFT sensor Signal circuit (CKT 1227).

Scheme 995

Scheme 996

Scheme 997

The numbers below refer to the step numbers on the diagnostic table.

1. 3. This step tests for a short to ground or a skewed sensor by verifying the fault exists.
2. 4. This step tests for an internal fault within the transmission by creating an open.
3. 6. This step inspects the TFT sensor signal circuit (CKT 1227) of the AT wiring harness assembly for being shorted to ground.

Scheme 998

Scheme 999

Scheme 1000

The numbers below refer to the step numbers on the diagnostic table.

1. 3. This step verifies a condition in the TFT sensor circuit inside the transmission.
2. 6. This step tests for higher than normal circuit voltage which may also damage the TFT sensor.

Scheme 1001

Scheme 1002

Scheme 1003

The numbers below refer to the step numbers on the diagnostic table.

1. 2. This step tests for proper operation to the AT ISS sensor.
2. 10. This step tests for proper AT ISS circuit operation up to the PCM connections. Remove the fuel pump relay in order to eliminate a flooding condition during this step.

Scheme 1004

Scheme 1005

Scheme 1006

The numbers below refer to the step numbers on the diagnostic table.

1. 3. This step tests for proper circuit operation up to the PCM connections.
2. 6. This step tests for proper operation of the AT ISS sensor.

Scheme 1007

Scheme 1008

Scheme 1009

The numbers below refer to the step numbers on the diagnostic table.

1. 4. This step tests for TCC/Stop lamp switch voltage to the PCM connector.
2. 7. This step isolates the TCC/Stop lamp switch as a source for setting the DTC.
3. 10. This step tests for a short to ground in the brake fuse circuit (CKT 441).
4. 12. This step tests for a short to ground in the TCC brake switch signal circuit (CKT 420), from the TCC/Stop lamp switch to the PCM.
5. 13. This step isolates the PCM as a source for causing the fuse to open.

Scheme 1010

Scheme 1011

Scheme 1012

Scheme 1013

The number below refers to the step numbers on the diagnostic table.

1. 3. This step isolates the TCC/Stop lamp switch as a source for setting the DTC.

Scheme 1014

Scheme 1015

The numbers below refer to the step numbers on the diagnostic table.

1. 3. This step tests the indicated range signal to the actual selected range. A faulty TFP manual valve position switch could set DTC P1810.
2. 4. This step tests for proper ratios in each commanded gear state.

Scheme 1016

Scheme 1017

Scheme 1018

The numbers below refer to the step numbers on the diagnostic table.

1. 2. This step tests for excessive TCC slip when TCC is commanded on.
2. 3. This step inspects for possible causes of no TCC apply.

Scheme 1019

Scheme 1020

Scheme 1021

The number below refers to the step number on the diagnostic table.

1. 3. This step tests the mechanical state of the TCC. When the PCM commands the TCC solenoid OFF, the slip speed should increase.

Scheme 1022

Scheme 1023

Scheme 1024

The numbers below refer to the step numbers on the diagnostic table.

1. 2. This step tests the ability of the PCM to command the PC solenoid valve.
2. 3. This step tests the PC solenoid valve and the AT wiring harness assembly for incorrect resistance.
3. 6. This step tests the PC solenoid valve and the internal wiring harness for a short to ground.
4. 9. This step tests the entire PC solenoid valve circuit up to the PCM for continuity.
5. 10. This step tests for a short to ground in the PC solenoid valve high control circuit (CKT 1228) and the PC solenoid valve low control circuit (CKT 1229) of the engine harness.

Scheme 1025

Scheme 1026

Scheme 1027

Scheme 1028

The numbers below refer to the step numbers on the diagnostic table.

1. 2. This step tests the function of the TFP manual valve position switch.
2. 3. This step tests whether the scan tool commanded all the shifts, or whether all the shift solenoids responded correctly, but all of the correct shifts did not occur.

Scheme 1029

Scheme 1030

Scheme 1031

The numbers below refer to the step numbers on the diagnostic table.

1. 2. This step tests the function of the TFP manual valve position switch.
2. 3. This step tests whether the shift solenoids responded correctly as commanded by the scan tool.

Scheme 1032

Scheme 1033

Scheme 1034

The numbers below refer to the step numbers on the diagnostic table.

1. 4. This step tests the function of the 1-2 SS valve and the internal wiring harness.
2. 5. This step tests the power to the 1-2 SS valve from the ignition through the fuse.
3. 7. This step tests the ability of the PCM and the wiring to control the ground circuit.
4. 12. This step measures the resistance of the automatic transmission wiring harness assembly and the 1-2 SS valve.

Scheme 1035

Scheme 1036

Scheme 1037

Scheme 1038

The numbers below refer to the step numbers on the diagnostic table.

1. 2. This step tests the function of the TFP manual valve position switch.
2. 3. This step tests for a selected gear ratio versus a ratio not obtainable under normal operating conditions.

Scheme 1039

Scheme 1040

Scheme 1041

The numbers below refer to the step numbers on the diagnostic table.

1. 2. This step tests the function of the TFP manual valve position switch.
2. 3. This step tests for a selected gear ratio versus a ratio not obtainable under normal operating conditions.

Scheme 1042

Scheme 1043

Scheme 1044

The numbers below refer to the step numbers on the diagnostic table.

1. 4. This step tests the function of the 2-3 SS valve and the internal wiring harness.
2. 5. This step tests the power to the 2-3 SS valve from the ignition through the fuse.
3. 7. This step tests the ability of the PCM and the wiring to control the ground circuit.
4. 12. This step measures the resistance of the automatic transmission (AT) wiring harness assembly and the 2-3 SS valve.

Scheme 1045

Scheme 1046

Scheme 1047

Scheme 1048

The numbers below refer to the step numbers on the diagnostic table.

1. 3. This step tests the indicated range signal to the actual selected range. A faulty TFP manual valve position switch can set a DTC P0894.
2. 4. This step tests for excessive TCC slip speed while in a commanded TCC lock-up state and in fourth gear; and confirms that the fault is present.
3. 5. This step tests for excessive TCC slip speed while in a commanded TCC lock-up state and in third gear.
4. 6. This step tests for a sticking TCC shift valve.
5. 7. This step tests for proper transmission line pressure.

Scheme 1049

Scheme 1050

Scheme 1051

The numbers below refer to the step numbers on the diagnostic table.

1. 3. This step tests the indicated range signal to the manual valve that is actually selected.
2. 5. This step tests the voltage from the PCM to the transmission 20-way connector.

Scheme 1052

Scheme 1053

Scheme 1054

Scheme 1055

The numbers below refer to the step numbers on the diagnostic table.

1. 4. This step tests for voltage to the TCC PWM solenoid valve circuit at the 20-way connector.
2. 6. This step tests the ability of the PCM and wiring to control the ground circuit.
3. 10. This step tests the resistance of the TCC PWM solenoid valve and the internal wiring harness.

Scheme 1056

Scheme 1057

Scheme 1058

Scheme 1059

The numbers below refer to the step numbers on the diagnostic table.

1. 3. This step tests for a short to ground in the 4WD Low signal circuit (CKT 1694).
2. 4. This step tests for an open in the 4WD Low signal circuit (CKT 1694), a faulty transfer case control module, active transfer case vehicles, or transfer case switch, non-active transfer case vehicles.

Scheme 1060

Scheme 1061

Scheme 1062

Scheme 1063

Scheme 1064

Scheme 1065

The numbers below refer to the step numbers on the diagnostic table.

1. 4. By disconnecting the TR switch, the ground path of all TR switch circuits is removed and the PCM should recognize all circuits as open. The scan tool should display HI for all range signal states.
2. 6. This step tests the TR switch wiring for an open or the lack of the signal voltage from the PCM.
3. 7. This step tests the TR switch wiring and the PCM by providing a ground path through a fused jumper wire. When grounded, the scan tool range signal states should change to LOW.
4. 8. This step tests the TR switch wiring and the PCM by providing a ground path through a fused jumper wire. When grounded, the scan tool range signal states should change to LOW.
5. 9. This step tests the TR switch wiring and the PCM by providing a ground path through a fused jumper wire. When grounded, the scan tool range signal states should change to LOW.
6. 10. This step tests the TR switch wiring and the PCM by providing a ground path through a fused jumper wire. When grounded, the scan tool range signal states should change to LOW.

Scheme 1066

Scheme 1067

Scheme 1068

The numbers below refer to the step numbers on the diagnostic table.

1. 2. This step tests for a faulty tow/haul switch.
2. 3. This step tests for voltage input from the BCM to the tow/haul switch.
3. 6. This step tests for ground integrity.

Scheme 1069

Transmission Abbreviations

A/C: Air Conditioning

AC: Alternating Current

AT: Automatic Transmission

CCDIC: Climate Control Driver Information Center

DC: Direct Current

DIC: Driver Information Center

DLC: Diagnostic Link Connector

DMM: Digital Multimeter

DTC: Diagnostic Trouble Code

EBTCM: Electronic Brake/Traction Control Module

ECCC: Electronically-Controlled Capacity Clutch

ECT: Engine Coolant Temperature

EMI: Electromagnetic Interference

IAT: Intake Air Temperature

IGN: Ignition

IMS: Internal Mode Switch

ISS: Input Speed Sensor

MAP: Manifold Absolute Pressure

MIL: Malfunction Indicator Lamp

NC: Normally Closed

NO: Normally Open

OBD: On Board Diagnostic

OSS: Output Speed Sensor

PC: Pressure Control

PCM: Powertrain Control Module

PWM: Pulse Width Modulation

RPM: Revolutions Per Minute

SS: Shift Solenoid

STL: Service Transmission Lamp

TAP: Transmission Adaptive Pressure

TCC: Torque Converter Clutch

TCM: Transmission Control Module

TFP: Transmission Fluid Pressure

TFT: Transmission Fluid Temperature

TP: Throttle Position

TV: Throttle Valve

VCM: Vehicle Control Module

VSS: Vehicle Speed Sensor

WOT: Wide Open Throttle

Transmission General Description

The 4L80-E is a fully automatic rear wheel drive electronically controlled transmission. The 4L80-E provides four forward ranges including overdrive and reverse. A gear type of oil pump controls shift points. The PCM and the pressure control (PC) solenoid (force motor) regulate these shift points. The PCM also controls shift schedules and TCC apply rates. Transmission temperature also influences shift schedules and TCC apply rates.

You can operate the transmission in any one of the following seven modes

1. P-PARK position prevents the vehicle from rolling either forward or backward on vehicles less than 15,000 G.V.W. For safety reasons, use the parking brake in addition to the park position.
2. R-REVERSE allows the vehicle to be operated in a rearward direction.
3. N-NEUTRAL allows the engine to be started and operated while driving the vehicle. If necessary, you may select this position in order to restart the engine with the vehicle moving.
4. OD-OVERDRIVE is used for all normal driving conditions. Overdrive provides four gear ratios plus a converter clutch operation. Depress the accelerator in order to downshift for safe passing.
5. D-DRIVE position is used for city traffic, and hilly terrain. Drive provides three gear ranges. Depress the accelerator in order to downshift.
6. 2 - Manual SECOND provides acceleration and engine braking or greater traction from a stop. When you choose manual SECOND, the vehicle will start out in first gear and upshift to second gear. You may select this gear at a vehicle speed of up to 22 km/h (35 mph).
7. 1 - Manual LOW provides maximum engine braking. You may select this gear at a vehicle speed of up to 13 km/h (20 mph).

Transmission Component and System Description

The mechanical components of this unit are as follows

1. A torque converter with a torque converter clutch (TCC)
2. A gear type oil pump
3. Five multiple disk clutches
4. Two band assemblies
5. Three planetary gear sets
6. One sprag clutch
7. Two roller clutches
8. A control valve body assembly The electrical components of this unit are as follows

1. Two shift solenoid valves, 1-2 and 2-3
2. A torque converter clutch (TCC) solenoid valve
3. A transmission pressure control (PC) solenoid valve
4. An automatic transmission fluid temperature (TFT) sensor
5. An automatic transmission fluid pressure (TFP) manual valve position switch assembly
6. An output speed sensor (OSS)
7. An input speed sensor (ISS) For more information refer to «Electronic Component Description»(ref-188999-S37070188952005091400000) .
