No Torque in Reverse & 3rd
Broken forward clutch hub, housing or snap ring.
No Torque in 2nd
Worn or damaged intermediate sprag.
TORQUE CONVERTER INSPECTION
Torque converter must be replaced for any of the following reasons.
- Damage To Pump Assembly
- Metal Particles Present in Oil
- Leaks in Hub Weld Area
- Crankshaft Pilot Broken Or Damaged
- Hub Scored Or Damaged
- Stator Failure
- Torque Converter Imbalance
- Engine Coolant Contamination
- Excessive End Play
TORQUE CONVERTER END PLAY CHECK
Mount Torque Converter End Play Fixture (J-35138) and Dial Gauge (J-8001) on stand to check end play. End play should be 0-.024" (0-0.60 mm). (Scheme 33)
Scheme 33
TRANSMISSION SPECIFICATIONS
| Application | In. (mm) | ||
|---|---|---|---|
| Clutch Clearances | |||
| Direct Clutch | .121-.186 (3.07-4.72) | ||
| Forward Clutch | |||
| Except Model ZBP | .121-.186 (3.07-4.72) | ||
| Model ZBP | .087-.110 (2.21-2.81) | ||
| Intermediate Clutch | .040-.107 (1.02-2.72) | ||
| Overrun Clutch | .033-.094 (.838-2.39) | ||
| 4th Clutch | .040-.100 (1.01-2.54) | ||
| End Play | |||
| Front Unit | .004-.022 (.10-.56) | ||
| Output/Reaction Carrier Pinion Gear | .009-.024 (.023-.61) | ||
| Rear Unit | .005-.025 (.13-.63) | ||
| Torque Converter | 0-.024 (0-.60) | ||
| Oil Pump Gears-To-Body Clearance | .007-.0028 (.017-.071) | ||
TRANSMISSION SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Center Support Bolt | 29 (39) |
| Connector Cooler Fitting Bolt | 29 (39) |
| Converter-To-Flexplate Bolt | 32 (43) |
| Extension Housing-To-Case Bolt | 25 (34) |
| Manual Shaft-To-Detent Lever Nut | 18 (24) |
| Oil Pan Bolt | 18 (24) |
| Parking Pawl Bracket-To-Case Bolt | 18 (24) |
| Pump Body-To-Case Bolt | 18 (24) |
| Pump Cover-To-Pump Body Bolt | 18 (24) |
| Rear Servo Cover-To-Case Bolt | 18 (24) |
| Rear Transmission Mount Bolt | 32 (43) |
| Rear Transmission Support Bracket Nut | 32 (43) |
| Transmission-To-Engine Bolt | 32 (43) |
| 4th Clutch Bolt | 12 (16) |
| INCH Lbs. (N.m) | |
| Accumulator Cover-To-Case Bolt | 98 (11) |
| Force Motor Bracket Bolt | 71 (8) |
| Lube Pipe Clamp Bolt | 98 (11) |
| Pipe Plug | 98 (11) |
| Speed Sensor Bolt | 98 (11) |
| Solenoid-To-Valve Body Bolt | 71 (8) |
| Temperature Sensor | 35 (4) |
| Valve Body-To-Case Bolt | 98 (11) |
TORQUE SPECIFICATIONS
