Adjustable Pedal System Chevrolet Malibu VI

Accessories Control Systems 5 illustrations ~2402 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Accelerator Pedal Bracket Nuts10 N.m89 lb in
Accelerator Pedal Nuts10 N.m89 lb in
Adjustable Brake Pedal Motor Mounting Screws3 N.m27 lb in
Brake Pedal Assembly to Cowl Mounting Nuts15 N.m11 lb ft
Brake Pedal Bracket Bolts25 N.m18 lb ft

Fastener Tightening Specifications

Scheme 1

Scheme 1: Adjustable Pedals Schematics
Scheme 1: Adjustable Pedals Schematics

Scheme 2

Scheme 2: Adjustable Pedals Component Views
Scheme 2: Adjustable Pedals Component Views
CalloutComponent Name
1Turn Signal/Multifunction Switch
2Steering Wheel Controls - Left
3Instrument Panel Cluster (IPC)
4Steering Wheel Controls - Right
5Windshield Wiper/Washer Switch
6Ignition Switch
7Hazard Switch
8Ambient Light Sensor
9Radio
10HVAC Control Module
11Inflatable Restraint I/P Module
12Traction Control Switch (NW7, NW9), Auxiliary Power Outlet - Front (w/o NW7, NW9)
13Transmission Shifter
14Cigar Lighter
15Horn Buttons/Inflatable Restraint Steering Wheel Module
16Data Link Connector (DLC)
17Fog Lamp Switch (T96)
18Dimmer Switch
19Adjustable Pedals Position Switch (JF4)

Scheme 3

Scheme 3
Scheme 3
CalloutComponent Name
1Power Steering Control Module
2Adjustable Pedals Module
3Brake Pedal Position Sensor

Scheme 4

Scheme 4
Scheme 4
CalloutComponent Name
1Brake Pedal Position Sensor
2Adjustable Pedals Position Sensor

Scheme 5

Scheme 5
Scheme 5
CalloutComponent Name
1Accelerator Pedal Position (APP) Sensor
2Adjustable Pedals Actuator
3Air Temp Sensor - Upper (C68)
4Air Temperature Actuator

Adjustable Pedals Connector End Views

Adjustable Pedals Module Connector End Connector Part Information 12064862 8-Way F Metri-Pack 150 Series (BK) Pin Wire Color Circuit No. Function A L-BU 5499 Adjustable Pedal Enable Signal B PK 5289 Adjustable Pedals Position Sensor Signal C - - Not Used D BN/WH 5288 Adjustable Pedals Position Sensor Low Reference E BK/WH 651 Ground F WH 5287 Adjustable Pedals Position Sensor 5-Volt Reference G L-GN 5980 Adjustable Pedal Inhibit Signal H RD/WH 740 Battery Positive Voltage

Adjustable Pedals Actuator Connector End Connector Part Information 15300027 2-Way F Metri-Pack 280 Series Sealed (BK) Pin Wire Color Circuit No. Function A YE 5129 Adjustable Pedal Actuator Rearward Control B PU 5130 Adjustable Pedal Actuator Forward Control

Adjustable Pedals Position Sensor Connector End Connector Part Information 15326877 3-Way F Global Terminal 280 Series (BK) Pin Wire Color Circuit No. Function A PK 5289 Adjustable Pedals Position Sensor Signal B BN/WH 5288 Adjustable Pedals Position Sensor Low Reference C WH 5287 Adjustable Pedals Position Sensor 5-Volt Reference

Adjustable Pedals Position Switch Connector End Connector Part Information 15332141 6-Way F Global Terminal 150 Series (BK) Pin Wire Color Circuit No. Function A RD/WH 740 Battery Positive Voltage B YE 5129 Adjustable Pedal Actuator Rearward Control C BK 650 Ground D GY 8 Instrument Panel Lamp Supply Voltage E L-BU 5499 Adjustable Pedal Enable Signal F PU 5130 Adjustable Pedal Actuator Forward Control

Diagnostic Starting Point - Adjustable Pedals

Begin the system diagnosis with Diagnostic System Check - Vehicle in Vehicle DTC Information. The Diagnostic System Check - Vehicle will provide the following information

  1. The identification of the control modules which command the system
  2. The ability of the control modules to communicate through the serial data circuit
  3. The identification of any stored diagnostic trouble codes (DTCs) and their status

The use of the Diagnostic System Check - Vehicle will identify the correct procedure for diagnosing the system and where the procedure is located.

Scan Tool Output Controls

Scan Tool Output ControlAdditional Menu SelectionsDescription
Adjustable Pedal InhibitSpecial FunctionsWhile this output is OFF the body control module will allow the adjustable pedal operation. When this output is turned ON the body control module will not allow adjustable pedal operation.

Scan Tool Output Controls

Scan Tool Data List

Scan Tool ParameterData ListUnits DisplayedTypical Data Value
Operating Conditions: Ignition Off/Transmission Selector in Park
Adjustable Pedal Inhibit CommandDataActive/InactiveInactive
Battery Voltage SignalDataVoltsVaries

Body Control Module Scan Tool Data List

Circuit Description

The adjustable pedal system will be disabled by the adjustable pedal module anytime the transmission selector lever is not in the park position while the ignition is on. This feature is controlled by the body control module (BCM) through the adjustable pedal inhibit circuit. While the system is being disabled the BCM supplies battery voltage to the adjustable pedal module through the adjustable pedal inhibit circuit. When the adjustable pedal system is enabled by the body control module the adjustable pedal inhibit circuit will be at 0 volts.

DTC Descriptor

This diagnostic procedure supports the following DTC

DTC B3631 Adjustable Foot Pedal Inhibit Circuit

This vehicle has DTCs which include DTC Symptoms. For more information on DTC Symptoms refer to DTC Symptom Description in Vehicle DTC Information.

DTC SymptomDTC Symptom Descriptor
02Short to Ground
05Short to Battery or Open

DTC B3631

Conditions for Running the DTC

  1. Battery voltage is between 9-18 volts.
  2. The ignition is in the RUN or ACC position.

Conditions for Setting the DTCs

The following conditions will cause the DTC to set

  1. The BCM detects short to ground.
  2. The BCM detects a short to battery voltage.
  3. The BCM detects an open circuit.

B3631 02

The adjustable pedals can be operated while the transmission selector is not in the Park position with the ignition in ACC or RUN.

B3631 05

The adjustable pedals are inoperative with the ignition in ACC or RUN.

Conditions for Clearing the DTC

  1. A current DTC clears when the malfunction is no longer present.
  2. A history DTC clears when the module ignition cycle counter reaches the reset threshold, without a repeat of the malfunction.
StepActionYesNo
Schematic Reference: Adjustable Pedals Schematics Connector End View Reference: Adjustable Pedals Connector End Views
1Did you perform the Diagnostic System Check - Vehicle?Go to Step 2Go to Diagnostic System Check - Vehicle in Vehicle DTC Information
2With the transmission selector in the park position turn the ignition ON. Attempt to operate the adjustable pedals. Do the adjustable pedals operate?Go to Step 3Go to Step 4
3With the ignition ON place the transmission selector in the neutral position. Attempt to operate the adjustable pedals. Do the adjustable pedals operate?Go to Step 5Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems
4Test the adjustable pedal inhibit circuit for a short to voltage. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 8Go to Step 6
5Test the adjustable pedal inhibit circuit for an open or short to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 8Go to Step 6
6Inspect for poor connections at the body control module. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 8Go to Step 7
7Replace the body control module. Refer to Body Control Module Replacement in Computer/Integrating Systems. Is the repair complete?Go to Step 8
8Use the scan tool in order to clear the DTCs . Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset?Go to Step 2System OK

DTC B3631

Symptoms - Adjustable Pedals

IMPORTANTReview the system description in order to familiarize yourself with the system functions. Refer to Adjustable Pedals Description and Operation .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which could affect the operation of the adjustable pedal system. Refer to «Checking Aftermarket Accessories»(/chevrolet/malibu/vi-2003-2006/remont/body-electrical/#wiring-systems-specifications-component-views-and-connector-end-views__checking-aftermarket-accessories) in Wiring Systems.
  2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

Symptom List

Refer to Adjustable Pedals Inoperative in order to diagnose the symptom.

Adjustable Pedals Inoperative

StepActionValuesYesNo
Schematic Reference: Adjustable Pedals Schematics Connector End View Reference: Adjustable Pedals Connector End Views
1Did you review the system description and operation and perform the necessary inspections?Go to Step 2Go to Symptoms - Adjustable Pedals
2Verify the fault is present. Does the system operate normally?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Disconnect the adjustable pedal motor connector. Connect a test lamp between the control circuit terminals in the harness connector. Operate the adjustable pedal switch in both directions. Does the test lamp illuminate when the switch is operated in both directions?Go to Step 18Go to Step 4
4Disconnect the adjustable pedal module connector. Connect a jumper wire from the adjustable pedal enable circuit terminal in the harness connector to ground. Operate the adjustable pedal switch in both directions. Does the test lamp illuminate when the switch is operated in both directions?Go to Step 7Go to Step 5
5Disconnect the adjustable pedal switch connector. Connect a test lamp from the battery voltage supply circuit terminal in the harness connector to a good ground. Does the test lamp illuminate?Go to Step 6Go to Step 15
6Test the adjustable pedal motor control circuits for an open or short to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 28Go to Step 19
7Disconnect the adjustable pedal module connector. Connect a test lamp from the battery voltage supply circuit terminal in the harness connector to a good ground. Does the test lamp illuminate?Go to Step 8Go to Step 16
8Connect a test lamp from the battery voltage supply circuit terminal to the ground circuit terminal in the adjustable pedal module harness connector. Does the test lamp illuminate?Go to Step 9Go to Step 17
9Test the resistance through the brake pedal position sensor from the 5-volt reference circuit terminal to the low reference circuit terminal in the adjustable pedal module harness connector. Is the resistance at or near the specified value?10K ohmsGo to Step 10Go to Step 12
10Connect a jumper wire from the adjustable pedal enable circuit terminal in the adjustable pedal module harness connector to ground. Test the resistance through the brake pedal position sensor from the signal circuit terminal to the low reference circuit terminal in the adjustable pedal module harness connector. Operate the adjustable pedals from stop to stop. Does the resistance remain within the specified values?0-10K ohmsGo to Step 11Go to Step 13
11Connect the adjustable pedal module and adjuster motor connectors. Disconnect the BCM connector C2. Operate the adjustable switch in both directions. Do the adjustable pedals operate while the BCM connector C2 is disconnected?Go to Step 21Go to Step 14
12Test the brake pedal position sensor 5-volt reference and low reference circuits for opens or shorts to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 28Go to Step 22
13Test the brake pedal position sensor signal circuit for an open or short to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 28Go to Step 22
14Test the adjustable pedal inhibit circuit for a short to voltage. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 28Go to Step 20
15Repair the battery voltage supply circuit to the adjustable pedal switch for an open or short to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Is the repair complete?Go to Step 28
16Repair the battery voltage supply circuit to the adjustable pedal module for an open or short to ground. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Is the repair complete?Go to Step 28
17Repair the adjustable pedal module ground circuit for an open or high resistance. Refer to Circuit Testing and to Wiring Repairs in Wiring Systems. Is the repair complete?Go to Step 28
18Inspect for poor connections at the adjustable pedal motor. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 28Go to Step 23
19Inspect for poor connections at the adjustable pedal switch. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 28Go to Step 24
20Inspect for poor connections at the adjustable pedal module. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 28Go to Step 25
21Inspect for poor connections at the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 28Go to Step 26
22Inspect for poor connections at the brake pedal position sensor. Refer to Testing for Intermittent Conditions and Poor Connections and to Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 28Go to Step 27
23Replace the adjustable pedal motor. Refer to Adjustable Accelerator Pedal Motor Replacement . Is the repair complete?Go to Step 28
24Replace the adjustable pedal switch. Refer to Accessory Switch Replacement in Instrument Panel, Gages, and Console. Is the repair complete?Go to Step 28
25Replace the adjustable pedal module. Refer to Adjustable Pedal Module Replacement . Is the repair complete?Go to Step 28
26Replace the BCM. Refer to Body Control Module Replacement in Computer/Integrating Systems. Is the repair complete?Go to Step 28
27Replace the brake pedal position sensor. Refer to Brake Pedal Adjustment Position Sensor Replacement . Is the repair complete?Go to Step 28
28Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 3

Adjustable Pedals Inoperative

Removal Procedure

  1. Remove the knee bolster. Refer to «Knee Bolster Replacement»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  2. Remove the closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  3. Remove the electrical connector from the brake apply sensor.
  4. Remove the electrical connector from the brake pedal adjustment position sensor.
  5. Remove the steering column assembly from the vehicle. Refer to «Steering Column Replacement»(/chevrolet/malibu/vi-2003-2006/remont/steering-column-switches/#steering-wheel-steering-column) in Steering Wheel and Column.
  6. Remove the cable from the adjustable pedal assemblies. Refer to «Adjustable Brake Pedal Cable Replacement»(/chevrolet/malibu/vi-2003-2006/remont/accessories-control-systems/#adjustable-pedal-system) .
  7. Remove the 2 brake pedal assembly to cowl mounting nuts.
  8. Remove the booster pushrod retaining clip (1), the washers (2), and the booster pushrod (3) from the adjustable pedal pivot pin (4).
  9. Remove the 3 brake pedal assembly to instrument panel (I/P) carrier bolts.
  10. Remove the adjustable brake pedal assembly from the vehicle.

Installation Procedure

  1. Insert a #4 square drive tool into the adjustable brake pedal actuator assembly and turn until the adjustable brake pedal assembly moves fully rearward.
  2. Install the adjustable brake pedal assembly to the vehicle.
  3. Install the 3 brake pedal assembly to I/P carrier bolts. Tighten: Tighten the bolts to 25 N.m (18 lb ft).
  4. Install the 2 brake pedal assembly to cowl mounting nuts. Tighten: Tighten the nuts to 15 N.m (11 lb ft).
  5. Install the booster pushrod retaining clip (1), the washers (2), and the booster pushrod (3) to the adjustable pedal pivot pin (4).
  6. Install the steering column assembly to the vehicle. Refer to «Steering Column Replacement»(/chevrolet/malibu/vi-2003-2006/remont/steering-column-switches/#steering-wheel-steering-column) in Steering Wheel and Column.
  7. Install the NEW cable. Refer to «Adjustable Brake Pedal Cable Replacement»(/chevrolet/malibu/vi-2003-2006/remont/accessories-control-systems/#adjustable-pedal-system) .
  8. Install the electrical connector to the brake pedal adjustment position sensor.
  9. Install the electrical connector to the brake apply sensor.
  10. Install the closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  11. Install the knee bolster. Refer to «Knee Bolster Replacement»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  12. Calibrate the brake pedal position sensor. Refer to «Brake Pedal Position Sensor Calibration Description and Operation»(/chevrolet/malibu/vi-2003-2006/remont/exterior-lights/#lighting-systems) in Lighting Systems.
  1. Disconnect the accelerator pedal position sensor electrical connector.
  2. Remove the accelerator mounting nuts from the accelerator bracket.
  3. Remove the accelerator assembly from the vehicle.
  1. Install the accelerator assembly to the vehicle.
  2. Install the accelerator mounting nuts to the accelerator bracket. Tighten: Tighten the nuts to 10 N.m (89 lb in).
  3. Connect the accelerator pedal position sensor electrical connector.
  4. Confirm that the accelerator sensor connector locking clip is fully secured.
  5. Verify the operation of the accelerator pedal.
  1. Remove the accelerator pedal from the vehicle. Refer to «Accelerator Pedal Assembly Replacement»(/chevrolet/malibu/vi-2003-2006/remont/accessories-control-systems/#adjustable-pedal-system) .
  2. Remove the adjustable brake pedal cable. Refer to «Adjustable Brake Pedal Cable Replacement»(/chevrolet/malibu/vi-2003-2006/remont/accessories-control-systems/#adjustable-pedal-system) .
  3. Remove the 3 nuts that attach the adjustable accelerator bracket to the cowl.
  4. Remove the adjustable accelerator bracket from the vehicle.
  1. Install the adjustable accelerator bracket to the vehicle.
  2. Install the 3 adjustable accelerator bracket nuts. Tighten: Tighten the nuts to 10 N.m (89 lb in).
  3. Install the NEW cable. Refer to «Adjustable Brake Pedal Cable Replacement»(/chevrolet/malibu/vi-2003-2006/remont/accessories-control-systems/#adjustable-pedal-system) .
  4. Install the accelerator pedal to the vehicle. Refer to «Accelerator Pedal Assembly Replacement»(/chevrolet/malibu/vi-2003-2006/remont/accessories-control-systems/#adjustable-pedal-system) .
  5. Calibrate the brake pedal position sensor. Refer to «Brake Pedal Position Sensor Calibration Description and Operation»(/chevrolet/malibu/vi-2003-2006/remont/exterior-lights/#lighting-systems) in Lighting Systems.
  1. Remove the adjustable accelerator pedal bracket assembly from the vehicle. Refer to «Adjustable Accelerator Pedal Bracket Assembly Replacement»(/chevrolet/malibu/vi-2003-2006/remont/accessories-control-systems/#adjustable-pedal-system) .
  2. Remove the 3 motor assembly screws and remove the motor assembly from the adjustable accelerator bracket.
  1. Install the motor assembly to the adjustable accelerator bracket assembly.
  2. Install the 3 screws to the adjustable accelerator bracket assembly. Tighten: Tighten the screws to 2 N.m (18 lb in).
  3. Install the adjustable accelerator pedal bracket assembly to the vehicle. Refer to «Adjustable Accelerator Pedal Bracket Assembly Replacement»(/chevrolet/malibu/vi-2003-2006/remont/accessories-control-systems/#adjustable-pedal-system) .
  4. Calibrate the brake pedal position sensor. Refer to «Brake Pedal Position Sensor Calibration Description and Operation»(/chevrolet/malibu/vi-2003-2006/remont/exterior-lights/#lighting-systems) in Lighting Systems.
IMPORTANTA NEW adjustable brake pedal cable is required each time it is disconnected from the adjustable brake pedal assembly or adjustable accelerator pedal assembly.
  1. Remove the knee bolster. Refer to «Knee Bolster Replacement»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  2. Remove the closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  3. Use a flat-bladed screw driver to release the locking tabs from both cable ends.
  4. Remove the cable from the adjustable brake pedal motor assembly.
  5. Remove the cable from the adjustable brake pedal actuator assembly.
  1. Insert a #2 square drive tool into the adjustable brake pedal actuator assembly and turn until the adjustable brake pedal assembly moves fully forward.
  2. Install the NEW cable to the adjustable brake pedal actuator assembly ensure the locking tabs of the cable are seated fully.
  3. Cycle the adjustable pedal position switch until the adjustable accelerator pedal assembly is in a full rearward position. This may take several attempts to ensure the proper position of the adjustable accelerator pedal assembly to the full rearward position.
  4. Install the NEW cable to the adjustable accelerator motor assembly. Ensure the locking tabs of the cable are seated fully.
  5. Cycle the adjustable pedal position switch fully forward and rearward ensuring smooth and consistent operation of the adjustable pedals.
  6. Install the closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  7. Install the knee bolster. Refer to «Knee Bolster Replacement»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  8. Rehone the brake pedal position sensor. Refer to «Brake Pedal Position Sensor Calibration Description and Operation»(/chevrolet/malibu/vi-2003-2006/remont/exterior-lights/#lighting-systems) in Lighting Systems.
  1. Remove the instrument panel (I/P) closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  2. Carefully cut and remove the tie strap securing the adjustable pedal module to the I/P support beam.
  3. Remove the adjustable pedal module (1) from the side of the I/P support beam.
  4. Disconnect the electrical connector from the adjustable pedal module.
  1. Remove the old 2-sided tape from the I/P support beam.
  2. If reinstalling the same adjustable pedal module, install NEW 2-sided tape to the module.
  3. Connect the electrical connector to the adjustable pedal module.
  4. Install the adjustable pedal module (1) to the side of the I/P support beam.
  5. Install a NEW tie strap to secure the adjustable pedal module to the I/P support beam.
  6. Install the closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  1. Remove the closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.
  2. Remove the steering wheel stub shaft bolt and position the steering wheel stub shaft away from the steering column in order to gain access to the brake pedal adjustment position sensor. Refer to «Intermediate Steering Shaft Replacement»(/chevrolet/malibu/vi-2003-2006/remont/steering-column-switches/#steering-wheel-steering-column) in Steering Wheel and Column.
  3. Remove the electrical connector from the brake pedal adjustment position sensor.
  4. Remove the brake pedal adjustment position sensor.
  1. Install the brake pedal adjustment position sensor to the brake pedal bracket. Ensure the brake pedal position sensor tabs (1) lock into the brake pedal bracket and the sensors arm (2) is correctly installed.
  2. Install the electrical connector to the brake pedal adjustment position sensor.
  3. Install the steering wheel stub shaft to the steering column. Refer to «Intermediate Steering Shaft Replacement»(/chevrolet/malibu/vi-2003-2006/remont/steering-column-switches/#steering-wheel-steering-column) in Steering Wheel and Column.
  4. Install the closeout panel. Refer to «Closeout/Insulator Panel Replacement - Left»(/chevrolet/malibu/vi-2003-2006/remont/gauges-instrument-panels/#instrument-panel-system-displays-gauges-and-console) in Instrument Panel, Gages, and Console.

Adjustable Pedals System Operation

The adjustable pedal system is controlled by the adjustable pedal switch and enabled by the adjustable pedal module so that operation can occur only while the transmission selector lever is in the park position. The adjustable pedals are moved forward or backward by a motor which is fixed to the accelerator pedal actuator with a drive cable to the brake pedal actuator. The adjuster motor is controlled by the adjustable pedal switch through 2 motor control circuits. Battery voltage is supplied to the switch form the PEDAL 10-Amp fuse in the I/P BEC. In an inactive state both of the switch contacts are closed to the ground contacts within the switch. When the switch is activated in the forward or rearward direction the appropriate switch contact is closed to the battery voltage supply contact within the switch. The adjuster motor is bidirectional and the direction of the pedal assembly travel is determined by which of the motor control circuits is switched to battery voltage while the other remains grounded.

The adjustable pedal switch is grounded through the adjustable pedal module and system operation is enabled or disabled by the module by opening or closing the switch ground circuit. The adjustable pedal module monitors the movement of the brake pedal assembly while the adjuster motor is in an active state in order to ensure that both pedal assemblies are moving and a step over condition is not being created. If at any time the system is attempted to be operated and no movement of the brake pedal assembly is detected the system will be disabled. Once the system has been disabled by the adjustable pedal module and the necessary repairs have been completed the PEDAL 10-Amp fuse must be removed for several seconds in order to reset the module and allow for normal operation to occur. The adjustable brake pedal position sensor is a potentiometer type position sensor and is supplied with a 5-volt reference and low reference from the module, and the position sensor signal circuit is referenced from 5 volts within the module.

The adjustable pedal system will be disabled by the adjustable pedal module anytime the transmission selector lever is not in the park position while the ignition is on. This feature is controlled by the body control module (BCM) through the adjustable pedal inhibit circuit. While the system is being disabled the BCM supplies battery voltage to the adjustable pedal module through the adjustable pedal inhibit circuit. When the adjustable pedal system is enabled by the body control module the adjustable pedal inhibit circuit will be at 0 volts.

More articles — Accessories & Equipment
