Data Communication System: Removal & Installation Chevrolet HHR I

Communication Devices 1 illustration

Removal Procedure

  1. Lower the instrument panel (I/P) closeout panel. Refer to «Instrument Panel Insulator Replacement»(ref-299568-S39873684372008092400000) .
  2. Remove the screws securing the data link connector (DLC) to the I/P carrier.

Installation Procedure

  1. Install the screws securing the DLC to the I/P carrier. Tighten: Tighten the screws to 2 N.m (18 lb in).
  2. Install the I/P closeout panel. Refer to «Instrument Panel Insulator Replacement»(ref-299568-S39873684372008092400000) .

Scheme 8

Scheme 8: Body Control Module Replacement
Scheme 8: Body Control Module Replacement
CalloutComponent Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures: Remove the right console extension panel. Refer to Front Floor Console Extension Replacement - Side .
1Screw, Body Control Module Assembly Tighten: 2 N.m (18 lb in)
2Module Assembly, Body Control Tip: Reprogram the body control module (BCM) after replacement. Refer to Control Module References .
NOTE
Refer to Fastener Notice .
