Shift Interlock System Chevrolet Corvette C6

Automatic Trans 1 illustration ~1460 words

Scheme 199

Scheme 199: Shift Lock Control Schematics
Scheme 199: Shift Lock Control Schematics

DIAGNOSTIC CODE INDEX

DTCDescription
DTC B2710B2710 02: Gearshift Unlock Circuit Short to Ground

DIAGNOSTIC CODE INDEX

Diagnostic Starting Point - Automatic Transmission Shift Lock Control

Begin the system diagnosis with the Diagnostic System Check - Vehicle . The Diagnostic System Check will provide the following information

  1. The identification of the control modules which command the system
  2. The ability of the control modules to communicate through the serial data circuit
  3. The identification of any stored diagnostic trouble codes (DTCs) and their status

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.

Diagnostic Instructions

  1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/corvette/c6-2004-2014/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/chevrolet/corvette/c6-2004-2014/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/chevrolet/corvette/c6-2004-2014/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.

Diagnostic Fault Information

CircuitShort to GroundOpen/High ResistanceShort to VoltageSignal Performance
Shift Lock Control Solenoid B+B2710 02B2710 02
Shift Lock Control Solenoid ControlB2710 02B2710 02B2710 01

Circuit/System Description

The remote control door lock receiver (RCDLR) controls the automatic transmission shift lock solenoid by providing a ground for the solenoid. The RCDLR utilizes a smart driver to control the ground to the automatic transmission shift lock solenoid. The smart driver monitors the voltage and current flow of the control circuit.

Conditions for Running the DTC

  1. The ignition switch is in the ON position.
  2. The brake pedal is pressed.
  3. The transmission is in the PARK position.

Conditions for Setting the DTC

The RCDLR will set the code if the voltage level at the shift lock control output is greater than 8 volts for more than 0.375 seconds while the output is active.

Action Taken When the DTC Sets

The RCDLR will not attempt to ground the control circuit of the automatic transmission shift lock solenoid until the next key cycle.

Conditions for Clearing the DTC

  1. A current DTC will clear when the malfunction is no longer present and the ignition switch is cycled.
  2. All RCDLR history codes will clear after 100 ignition cycles with no current codes active during the 100 ignition cycles.

Reference Information

Schematic Reference

Connector End View Reference

Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(/chevrolet/corvette/c6-2004-2014/remont/body-electrical/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
  2. «Connector Repairs»(/chevrolet/corvette/c6-2004-2014/remont/body-electrical/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
  3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/corvette/c6-2004-2014/remont/body-electrical/#wiring-systems-and-power-management-service-troubleshooting-diagnosis)
  4. «Wiring Repairs»(/chevrolet/corvette/c6-2004-2014/remont/body-electrical/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

Circuit/System Verification

  1. Ignition ON, Clear the DTC. Observe the scan tool RCDLR Shift Lock Solenoid Command parameter. The parameter should change from UNLOCK to LOCK when the brake pedal is depressed and released. If the parameter does not change, refer to «Stop Lamps Malfunction»(/chevrolet/corvette/c6-2004-2014/remont/exterior-lights/#lighting-systems__stop-lamps-malfunction) .
  2. Press the brake pedal, the vehicle operator should be able to move the shifter lever out of the PARK position.

Circuit/System Testing

  1. Ignition OFF, disconnect the harness connector at the shift lock control solenoid.
  2. Ignition ON, verify a test lamp illuminates between the B+ circuit terminal 5 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or open/high resistance. If the circuit tests normal, test or replace the shift lock control solenoid.
  3. Install a test lamp between the B+ circuit terminal 5 and control circuit terminal 8.
  4. Ignition ON, depress and release the brake pedal several times. The test lamp should turn ON and OFF as commanded. If the test lamp is always ON, test the control circuit for short to ground. If the circuit tests normal, replace the RCDLR. If the test lamp is always OFF, test the control circuit for an open/high resistance or short to voltage. If the circuit test normal, replace the RCDLR.
  5. If all circuits test normal, test or replace the shift lock control solenoid.

Repair Procedures

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Transmission Control Replacement»(/chevrolet/corvette/c6-2004-2014/remont/automatic-trans/#how-to-overhaul-the-automatic-transmission-6l80-removal-installation-service-troubleshooting-diagnosis)
  2. «Control Module References»(/chevrolet/corvette/c6-2004-2014/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for RCDLR replacement, setup, and programming

Symptoms - Automatic Transmission Shift Lock Control

IMPORTANTThe following steps must be completed before using the symptom tables.
  1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/corvette/c6-2004-2014/remont/oem-general-information/#vehicle-diagnostic-information) before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link.
  2. Review the system operation in order to familiarize yourself with the system functions. Refer to «Automatic Transmission Shift Lock Control Description and Operation»(/chevrolet/corvette/c6-2004-2014/remont/automatic-trans/#shift-interlock-system__automatic-transmission-shift-lock-control-description) .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which could affect the operation of the automatic transmission shift lock control. Refer to «Checking Aftermarket Accessories»(/chevrolet/corvette/c6-2004-2014/remont/body-electrical/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__checking-aftermarket-accessories) .
  2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections .

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

  1. Perform the «Diagnostic System Check - Vehicle»(/chevrolet/corvette/c6-2004-2014/remont/oem-general-information/#vehicle-diagnostic-information) prior to using this diagnostic procedure.
  2. Review «Strategy Based Diagnosis»(/chevrolet/corvette/c6-2004-2014/remont/oem-general-information/#vehicle-diagnostic-information__strategy-based-diagnosis) for an overview of the diagnostic approach.
  3. «Diagnostic Procedure Instructions»(/chevrolet/corvette/c6-2004-2014/remont/oem-general-information/#vehicle-diagnostic-information__diagnostic-procedure-instructions) provides an overview of each diagnostic category.
CircuitShort to GroundOpen/High ResistanceShort to VoltageSignal Performance
Shift Lock Control Solenoid B+B2710 02B2710 02
Shift Lock Control Solenoid ControlB2710 02B2710 02B2710 01

The remote control door lock receiver (RCDLR) controls the automatic transmission shift lock solenoid by providing a ground for the solenoid. The RCDLR utilizes a smart driver to control the ground to the automatic transmission shift lock solenoid. The smart driver monitors the voltage and current flow of the control circuit.

Schematic Reference

Connector End View Reference

Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(/chevrolet/corvette/c6-2004-2014/remont/body-electrical/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__circuit-testing)
  2. «Connector Repairs»(/chevrolet/corvette/c6-2004-2014/remont/body-electrical/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__connector-repairs)
  3. «Testing for Intermittent Conditions and Poor Connections»(/chevrolet/corvette/c6-2004-2014/remont/body-electrical/#wiring-systems-and-power-management-service-troubleshooting-diagnosis)
  4. «Wiring Repairs»(/chevrolet/corvette/c6-2004-2014/remont/body-electrical/#wiring-systems-and-power-management-service-troubleshooting-diagnosis__wiring-repairs)

Scan Tool Reference

Control Module References for scan tool information

  1. Ignition ON, Clear the DTC. Observe the scan tool RCDLR Shift Lock Solenoid Command parameter. The parameter should change from UNLOCK to LOCK when the brake pedal is depressed and released. If the parameter did not change, refer to «Stop Lamps Malfunction»(/chevrolet/corvette/c6-2004-2014/remont/exterior-lights/#lighting-systems__stop-lamps-malfunction) .
  2. Press the brake pedal, the vehicle operator should be able to move the shifter lever out of the PARK position.
  1. Ignition OFF, disconnect the harness connector at the shift lock control solenoid.
  2. Ignition ON, verify a test lamp illuminates between the B+ circuit terminal 5 and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or open/high resistance. If the circuit tests normal, test or replace the shift lock control solenoid.
  3. Install a test lamp between the B+ circuit terminal 5 and control circuit terminal 8.
  4. Ignition ON, depress and release the brake pedal several times. The test lamp should turn ON and OFF as commanded. If the test lamp is always ON, test the control circuit for short to ground. If the circuit tests normal, replace the RCDLR. If the test lamp is always OFF, test the control circuit for an open/high resistance or short to voltage. If the circuit test normal, replace the RCDLR.
  5. If all circuits test normal, test or replace the shift lock control solenoid.

Perform the Diagnostic Repair Verification after completing the diagnostic procedure.

  1. «Transmission Control Replacement»(/chevrolet/corvette/c6-2004-2014/remont/automatic-trans/#how-to-overhaul-the-automatic-transmission-6l80-removal-installation-service-troubleshooting-diagnosis)
  2. «Control Module References»(/chevrolet/corvette/c6-2004-2014/remont/communication-devices/#programming-and-setup-all-systems__control-module-references) for RCDLR replacement, setup and programming

Automatic Transmission Shift Lock Control Description and Operation

The automatic transmission shift lock control system is a safety device that prevents an inadvertent shift out of PARK when the engine is running. The driver must press the brake pedal before moving the shift lever out of the PARK position. The system consists of the following components

  1. The automatic transmission shift lock control solenoid
  2. The remote control door lock receiver (RCDLR)
  3. The transmission control module (TCM)

With the ignition in the ON position, battery positive voltage is supplied to the automatic transmission shift lock control solenoid located within the shift lever assembly. The automatic transmission shift lock control solenoid receives a ground from the RCDLR. The RCDLR receives input thought data communications from the TCM indicating transmission gear position and brake pedal position. With the shift lever in the PARK position the internal park switch of the shift lever assembly closes allowing current to flow to the RCDLR. When the RCDLR receives a data communication that the brake pedal is depressed and the transmission is in the PARK position the RCDLR supplies a ground the shift lock control solenoid control circuit. This energizes the solenoid and allows the shift lever to be moved out of the PARK position. With the shift lever out of the PARK position the internal park switch in the shift lever assemble opens, this de-energies the shift lock control solenoid.
