Fastener Tightening Specifications
| Application | Ref No. | Quantity | Size | Specification | |
|---|---|---|---|---|---|
| Metric | English | ||||
| Case Extension Stud to Case Extension | 17 | 2 | M10x1.5 | 15 N.m | 11 lb ft |
| Case Extension to Case Assembly | 16 | 6 | M10x1.5x40 | 55 N.m | 41 lb ft |
| Control Solenoid Valve Assembly and Control Valve Lower Body Assembly to Control Valve Upper Body Assembly | 310 | 6 | M5x0.8x55 | 8 N.m | 71 lb in |
| Control Solenoid Valve Assembly and Control Valve Lower Body Assembly to Control Valve Upper Body Assembly | 309 | 10 | M5x0.8x45 | 8 N.m | 71 lb in |
| Control Solenoid Valve Heat Sink to Valve Body | 312 | 2 | M5x0.8x53 | 8 N.m | 71 lb in |
| Control Valve Upper Body Assembly to Control Valve Lower Body Assembly | 301 | 12 | M5x0.8x36 | 8 N.m | 71 lb in |
| Control (with Body and Valve) Valve Assembly to Case Assembly | 22 | 6 | M5x0.8x73 | 8 N.m | 71 lb in |
| Fluid Pan Assembly to Case Assembly | 30 | 18 | M6x1.0x20 | 9 N.m | 80 lb in |
| Trans Oil Level Check Plug to Fluid Pan Assembly | 31 | 1 | M12x1.75 | 25 N.m | 18 lb ft |
| Fluid Pump Cover Assembly to Torque Converter Housing | 231 | 13 | M6 1.0x40 | 11 N.m | 97 lb in |
| Input and Output Speed Sensor Assembly to Control Valve Upper Body Assembly | 302 | 2 | M6x1.0x20 | 12 N.m | 106 lb in |
| Line Pressure Test Hole Plug to Torque Converter Housing | 202 | 1 | 1/8-27 NPTF | 11 N.m | 97 lb in |
| Manual Shaft Detent Assembly to Valve Body | 23 | 1 | M6x1.0x14.5 | 12 N.m | 106 lb in |
| Torque Converter Housing Assembly to Case Assembly | 3 | 9 | M10x1.5x50 | 72 N.m | 53 lb ft |
| *Reference number refers to the component callout number in Disassembled Views | |||||
Transmission General Specifications
| Name | 6L80 |
|---|---|
| RPO Codes | MYC |
| Production Location | Ypsilanti, Michigan (USA) |
| Transmission Drive | Rear Wheel Drive |
| 1st Gear Ratio | 4.027 |
| 2nd Gear Ratio | 2.364 |
| 3rd Gear Ratio | 1.532 |
| 4th Gear Ratio | 1.152 |
| 5th Gear Ratio | 0.852 |
| 6th Gear Ratio | 0.667 |
| Reverse | 3.064 |
| Torque Converter Size - Diameter of Torque Converter Turbine | 258/300 mm |
| Pressure Taps | Line Pressure |
| Transmission Fluid Type | DEXRON VI® |
| Transmission Type: 6 | Six Forward Gears |
| Transmission Type: L | Longitude Mount |
| Transmission Type: 80 | Product Series |
| Position Quadrant | P, R, N, D, S (some models) |
| Case Material | Die Cast Aluminum |
| Transmission Net Weight | 103.7 kg (228.6 lb) - Corvette |
| Maximum Trailer Towing Capacity | N/A |
Fluid Capacity Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Pan Removal - Approximate Capacity | 6.2 liters | 6.5 quarts |
| Overhaul - Approximate Capacity | 11.8 liters | 12.5 quarts |
| Complete Trans System Fluid Capacity | 12.53 liters | 13.24 quarts |
Fluid Pump Selective Specifications
| Size Classification | Thickness (mm) | Thickness (in) |
|---|---|---|
| NOTE: Rotor and slide must be chosen from the same size classification as the oil pump body. Allowable rotor and slide to fluid pump body end play is as follows: Specification: Slide to Fluid Pump Body End Play - 0.020-0.051 mm (0.0008-0.0020 in) Rotor to Fluid Pump Body End Play - 0.020-0.051 mm (0.0008-0.0020 in) The fluid pump assembly has selective rotor and slide components. These components are chosen based on pump body dimensions. Fluid pump rotor and slide components are available in three size classifications (1, 2, 3) with the following tolerances | ||
| Rotor Selection | ||
| 1 | 17.948-17.961 | 0.7066-0.7071 |
| 2 | 17.961-17.974 | 0.7071-0.7076 |
| 3 | 17.974-17.987 | 0.7076-0.7081 |
| Slide Selection | ||
| 1 | 17.948-17.961 | 0.7066-0.7071 |
| 2 | 17.961-17.974 | 0.7071-0.7076 |
| 3 | 17.974-17.987 | 0.7076-0.7081 |
| Fluid Pump Body Depth | ||
| 1 | 17.98-17.994 | 0.7079-0.7084 |
| 2 | 17.994-18.007 | 0.7084-0.7089 |
| 3 | 18.007-18.033 | 0.7089-0.7100 |
| NOTE |
|---|
| Rotor and slide must be chosen from the same size classification as the oil pump body. Allowable rotor and slide to fluid pump body end play is as follows: Specification: Slide to Fluid Pump Body End Play - 0.020-0.051 mm (0.0008-0.0020 in) Rotor to Fluid Pump Body End Play - 0.020-0.051 mm (0.0008-0.0020 in) |
Fluid Pump Selective Specifications
Clutch Backing Plate Retaining Ring Specifications (6L80)
| Clutch Pack Travel Specification - 1.21-1.79 mm (0.048-0.070 in) | ||
|---|---|---|
| Retaining Ring Thickness | O.D. Color | |
| Metric | English | |
| NOTE: After measuring clutch pack travel, determine if the measurement is within the specification. If the measurement is not within the specification, measure the thickness of the existing retaining ring, and then choose a thicker or thinner retaining ring that will bring the measurement within specification. | ||
| 1.61-1.71 mm | 0.063-0.067 in | Gray |
| 1.88-1.98 mm | 0.074-0.078 in | Light Green |
| 2.15-2.25 mm | 0.085-0.089 in | Yellow |
| 2.42-2.52 mm | 0.095-0.099 in | None |
| 2.69-2.79 mm | 0.106-0.110 in | Purple |
| NOTE |
|---|
| After measuring clutch pack travel, determine if the measurement is within the specification. If the measurement is not within the specification, measure the thickness of the existing retaining ring, and then choose a thicker or thinner retaining ring that will bring the measurement within specification. |
3-5 Reverse Clutch
| Clutch Pack Travel Specification - 1.53-1.99 mm (0.060-0.078 in) | ||
|---|---|---|
| Retaining Ring Thickness | O.D. Color | |
| Metric | English | |
| NOTE: After measuring clutch pack travel, determine if the measurement is within the specification. If the measurement is not within the specification, measure the thickness of the existing retaining ring, and then choose a thicker or thinner retaining ring that will bring the measurement within specification. | ||
| 2.42-2.52 mm | 0.095-0.099 in | None |
| 2.69-2.79 mm | 0.106-0.110 in | Purple |
| 2.96-3.06 mm | 0.117-0.120 in | Light Blue |
| 3.23-3.33 mm | 0.127-0.131 in | Orange |
| 3.50-3.60 mm | 0.138-0.142 in | White |
| NOTE |
|---|
| After measuring clutch pack travel, determine if the measurement is within the specification. If the measurement is not within the specification, measure the thickness of the existing retaining ring, and then choose a thicker or thinner retaining ring that will bring the measurement within specification. |
1-2-3-4 Clutch
| Clutch Pack Travel Specification - 1.28-1.89 mm (0.050-0.074 in) | ||
|---|---|---|
| Retaining Ring Thickness | O.D. Color | |
| Metric | English | |
| NOTE: After measuring clutch pack travel, determine if the measurement is within the specification. If the measurement is not within the specification, measure the thickness of the existing retaining ring, and then choose a thicker or thinner retaining ring that will bring the measurement within specification. | ||
| 1.60-1.70 mm | 0.063-0.067 in | Yellow |
| 2.02-2.12 mm | 0.080-0.083 in | None |
| 2.44-2.54 mm | 0.096-0.100 in | Purple |
| NOTE |
|---|
| After measuring clutch pack travel, determine if the measurement is within the specification. If the measurement is not within the specification, measure the thickness of the existing retaining ring, and then choose a thicker or thinner retaining ring that will bring the measurement within specification. |
4-5-6 Clutch
| Clutch Pack Travel Specification - 1.30-2.07 mm (0.051-0.081 in) | ||
|---|---|---|
| Retaining Ring Thickness | O.D. Color | |
| Metric | English | |
| NOTE: After measuring clutch pack travel, determine if the measurement is within the specification. If the measurement is not within the specification, measure the thickness of the existing retaining ring, and then choose a thicker or thinner retaining ring that will bring the measurement within specification. | ||
| 1.85-1.95 mm | 0.073-0.077 in | Yellow |
| 2.26-2.36 mm | 0.089-0.093 in | None |
| 2.67-2.77 mm | 0.105-0.109 in | Purple |
| NOTE |
|---|
| After measuring clutch pack travel, determine if the measurement is within the specification. If the measurement is not within the specification, measure the thickness of the existing retaining ring, and then choose a thicker or thinner retaining ring that will bring the measurement within specification. |
Low/Reverse Clutch
Range Reference
| Range | Park | Reverse | Neutral | Drive | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 1st Braking | 1st | 2nd | 3rd | 4th | 5th | 6th | ||||
| 1-2-3-4 Clutch | Applied | Applied | Applied | Applied | Applied | |||||
| 3-5 Reverse Clutch | Applied | Applied | Applied | |||||||
| 4-5-6 Clutch | Applied | Applied | Applied | |||||||
| 2-6 Clutch | Applied | Applied | ||||||||
| Low and Reverse Clutch | Applied* | Applied | Applied* | Applied | ||||||
| Low Clutch Sprag | Holding | Holding | ||||||||
| * = Applied with NO load | ||||||||||
Range Reference Table
Shift Solenoid Valve State and Gear Ratio
| Gear | Shift SOL 1 | Shift SOL 2 | 1-2-3-4 CL PC SOL 5 N.L. | 2-6 CL PC SOL 4 N.L. | 3-5 REV CL PC SOL 2 N.H. | LOW REV 4-5-6 CL PC SOL 3 N.H. | Gear Ratio |
|---|---|---|---|---|---|---|---|
| Park | ON | ON | OFF | OFF | OFF | ON | |
| Reverse | ON | OFF | OFF | OFF | ON | ON | 3.064 |
| Neutral | ON | ON | OFF | OFF | OFF | ON | |
| 1st Braking | ON | ON | ON | OFF | OFF | ON | 4.027 |
| 1st | OFF | ON | ON | OFF | OFF | OFF | 4.027 |
| 2nd | OFF | ON | ON | ON | OFF | OFF | 2.364 |
| 3rd | OFF | ON | ON | OFF | ON | OFF | 1.532 |
| 4th | OFF | ON | ON | OFF | OFF | ON | 1.152 |
| 5th | OFF | ON | OFF | OFF | ON | ON | 0.852 |
| 6th | OFF | ON | OFF | ON | OFF | ON | 0.667 |
| For shift solenoids 1 and 2, "ON" = Solenoid Energized (Pressurized) "OFF" = Solenoid De-energized (No Pressure). For pressure control solenoids, "ON" = Pressurized, "OFF" = No Pressure | |||||||
Transmission Fluid Pressure Switch Logic
| Gear | TFP Switch States | |||
|---|---|---|---|---|
| TFP SW1 | *TFP SW3 | TFP SW4 | TFP SW5 | |
| Park | High | Low | Low | Low |
| Reverse | Low | Low | Low | Low |
| Neutral | High | Low | Low | Low |
| Drive 1st - Engine Braking | High | High | Low | Low |
| Drive 1st | High | High | Low | High |
| Drive 2nd | High | Low | Low | High |
| Drive 3rd | Low | High | Low | High |
| Drive 4th | High | High | Low | Low |
| Drive 5th | Low | High | High | Low |
| Drive 6th | High | High | High | Low |
| Drive 6th (Possible additional gear state) | High | Low | High | Low |
| High = 12V (Switch Open or Pressurized) Low = 0V (Switch Closed or No Pressure) Note: All TFP switches are normally closed (NC) *TFP switch 2 does not exist | ||||
Transmission Fluid Pressure (TFP) Switch Logic
Transmission Internal Mode Switch Logic
| Gear Selector Position | Signal A | Signal B | Signal C | Signal P |
|---|---|---|---|---|
| Park | LOW | HI | HI | LOW |
| Park/Reverse | LOW | LOW | HI | LOW |
| Reverse | LOW | LOW | HI | HI |
| Reverse/Neutral | HI | LOW | HI | HI |
| Neutral | HI | LOW | HI | LOW |
| Neutral/Drive 6 | HI | LOW | LOW | LOW |
| Drive 6 | HI | LOW | LOW | HI |
| Drive 6/Drive 4 | LOW | LOW | LOW | HI |
| Drive 4 | LOW | LOW | LOW | LOW |
| Drive 4/Drive 3 | LOW | HI | LOW | LOW |
| Drive 3 | LOW | HI | LOW | HI |
| Drive 3/Drive 2 | HI | HI | LOW | HI |
| Drive 2 | HI | HI | LOW | LOW |
| Open | HI | HI | HI | HI |
| Invalid | HI | HI | HI | LOW |
| Invalid | LOW | HI | HI | HI |
| HI = Ignition voltage LOW = 0 volts | ||||
Scheme 179
Scheme 180
Scheme 181
| Callout | Component Name |
|---|---|
| 1 | Torque Converter Assembly |
| 2 | Torque Converter (with Fluid Pump) Housing Assembly |
| 3 | Bolt/Screw, M10 x 50 mm |
| 4 | Torque Converter Housing Access Hole Cover |
| 5 | A/Trans Fluid Pump Seal |
| 6 | Torque Converter Housing Locator Pin |
| 7 | A/Trans Case Assembly |
| 8 | Transmission Fluid Fill Tube Plug Assembly |
| 9 | A/Trans Connector Seal |
| 10 | A/Trans Connector (O-ring) Seal |
| 11 | A/Trans Electrical Connector Passage Sleeve |
| 12 | A/Trans Case Plug |
| 13 | Output Shaft Bushing |
| 14 | Output Shaft Seal Assembly |
| 15 | A/Trans Case Extension |
| 16 | Bolt/Screw, M10 x 40 mm |
| 17 | A/Trans Case Extension Stud |
| 18 | A/Trans Fluid Pump Seal Assembly |
| 19 | A/Trans Fluid Pump Seal Assembly |
| 20 | Center Support Fluid Passage Seal Assembly |
| 21 | Control (with Body and Valve) Valve Assembly |
| 22 | Bolt/Screw, M5 x 73 mm |
| 23 | Bolt/Screw, M6 x 14.5 mm |
| 24 | Manual Shaft Detent Assembly |
| 25 | A/Trans Fluid Filter Seal Assembly |
| 26 | A/Trans Fluid Filter Assembly |
| 27 | A/Trans Fluid Pan Gasket |
| 28 | A/Trans Fluid Pan Magnet |
| 29 | A/Trans Fluid Pan Assembly |
| 30 | Bolt/Screw, M6 x 20 mm |
| 31 | Trans Oil Level Check Plug |
Scheme 182
| Callout | Component Name |
|---|---|
| 51 | 1-2-3-4 and 3-5 Reverse Clutch Assembly |
| 52 | Input Carrier Assembly |
| 53 | Input Sun Gear |
| 54 | Input Sun Gear Thrust Bearing |
| 55 | Input Sun Gear Thrust Washer |
| 56 | 4-5-6 (w/Turbine Shaft) Clutch Assembly |
| 57 | Turbine Shaft Thrust Bearing Assembly |
| 58 | 4-5-6 Clutch (w/Output Carrier Shaft and Dampener) Hub Assembly |
| 59 | 4-5-6 Clutch Hub Thrust Bearing Assembly |
| 60 | Output Carrier Inner Sun Gear Shaft (Front) Bushing |
| 61 | 1-2-3-4 Clutch (w/Output Carrier Inner Sun Gear Shaft) Hub Assembly |
| 62 | Output Carrier Inner Sun Gear Shaft Bushing |
| 63 | 1-2-3-4 Clutch Hub Thrust Bearing Assembly |
| 64 | 2-6 and 3-5 Reverse Clutch (w/Output Carrier Outer Sun Gear Shaft) Hub Assembly |
| 65 | 2-6 and 3-5 Reverse Clutch Hub Thrust Bearing Assembly |
| 66 | Center Support Retaining Ring |
| 67 | Center (w/2-6 Low and Reverse Clutch) Support Assembly |
| 68 | Output Carrier Assembly |
| 69 | Output Carrier Thrust Bearing Assembly |
| 70 | Output Shaft Assembly |
| 71 | Output Shaft Thrust Bearing Assembly |
Scheme 183
| Callout | Component Name |
|---|---|
| 200 | Torque Converter Fluid Seal Retaining Ring |
| 201 | Torque Converter Fluid Seal Assembly |
| 202 | Line Pressure Test Hole Plug |
| 203 | Torque Converter Housing |
| 204 | A/Trans Vent Pipe (Model Dependent) |
| 205 | Trans Fluid Cooler Pipe Fitting Seal |
| 206 | Torque Converter Bushing |
| 207 | A/Trans Fluid Pump Vane Ring |
| 208 | A/Trans Fluid Pump Rotor Guide |
| 209 | A/Trans Fluid Pump Slide Fluid Seal Ring |
| 210 | A/Trans Fluid Pump Slide (O-ring) Seal |
| 211 | A/Trans Fluid Pump Slide Outer Spring |
| 212 | A/Trans Fluid Pump Slide |
| 213 | A/Trans Fluid Pump Slide Seal |
| 214 | A/Trans Fluid Pump Slide Seal Support |
| 215 | A/Trans Fluid Pump Slide Pivot Pin |
| 216 | A/Trans Fluid Pump Vane |
| 217 | A/Trans Fluid Pump Rotor |
| 218 | Turbine Shaft Front Bushing |
| 219 | A/Trans Fluid Pump Cover Assembly |
| 220 | Converter Feed Limit Valve |
| 221 | Converter Feed Limit Valve Spring |
| 222 | Valve Spring Retainer |
| 223 | Pressure Relief Ball Valve Spring Pin |
| 224 | Pressure Relief Ball Valve Spring |
| 225 | Pressure Relief Ball Valve |
| 226 | TCC Control Valve Spring |
| 227 | TCC Control Valve |
| 228 | Turbine Shaft Rear Bushing |
| 229 | 1-2-3-4 and 3-5 Reverse Clutch Housing Thrust Washer |
| 230 | 1-2-3-4 and 3-5 Reverse Clutch Fluid Seal Ring |
| 231 | Bolt/Screw, M6 x 40 mm |
| 232 | A/Trans Fluid Pump Locator Pin |
| 233 | Pressure Regulator Valve |
| 234 | Pressure Regulator Valve Outer Spring |
| 235 | Pressure Regulator Valve Inner Spring |
| 236 | Isolator Valve |
| 237 | Isolator Valve Sleeve |
| 238 | 1-2-3-4 and 3-5 Reverse Clutch Fluid Seal Ring - Inner O-Ring (Qty: 3) - Model Dependent |
Scheme 184
| Callout | Component Name |
|---|---|
| 301 | Bolt, M5 x 36 mm |
| 302 | Bolt, M6 x 20 mm |
| 303 | A/Trans Input and Output Speed Sensor Assembly |
| 304 | Control Valve Upper Body Assembly |
| 305 | Control Valve Body Spacer (w/Gasket) Plate Assembly |
| 306 | Control Valve Body Ball Check Valve |
| 307 | Control Valve Lower Body Assembly |
| 308 | A/Trans Manual Shift Shaft Position Switch Assembly |
| 309 | Bolt, M5 x 45 mm |
| 310 | Bolt, M5 x 55 mm |
| 311 | Filter Plate Assembly |
| 312 | Bolt, M5 x 53 mm |
| 314 | Control Solenoid (w/Body and TCM) Valve Assembly |
| 315 | A/Trans Manual Shaft Position Switch Wiring Harness Clip |
| 316 | A/Trans Input and Output Speed Sensor Wiring Harness Clip |
Scheme 185
| Callout | Component Name |
|---|---|
| 313 | Control Valve Body Locator Pin |
| 321 | Control Valve Upper Body |
| 322 | Control Valve Body Locator Pin |
| 323 | Retainer |
| 324 | Actuator Feed Limit Valve Spring |
| 325 | Actuator Feed Limit Valve |
| 326 | Clutch Regulator Valve Spring |
| 327 | CBR1/4-5-6 Clutch Regulator Valve |
| 328 | Clutch Regulator Valve Bore Plug |
| 329 | Clutch Boost Valve |
| 330 | Clutch Boost Valve Spring |
| 334 | 2-6 Clutch Regulator Valve |
| 335 | 2-6 Clutch Regulator Valve Gain Valve |
| 336 | 3-5 Reverse Clutch Regulator Valve |
| 337 | 1-2-3-4 Clutch Regulator Valve |
| 338 | Shuttle Valve |
Scheme 186
| Callout | Component Name |
|---|---|
| 323 | Retainer |
| 328 | Clutch Regulator Valve Bore Plug |
| 338 | Shuttle Valve |
| 351 | Control Valve Lower Body |
| 352 | Clutch Select Solenoid Valve 3 |
| 353 | TCC Regulator Apply Valve Spring |
| 354 | Manual Valve |
| 355 | TCC Regulator Apply Valve |
| 356 | Clutch Piston Dam Feed Regulator Valve |
| 357 | Clutch Piston Dam Feed Regulator Valve Spring |
| 358 | Clutch Select Solenoid Valve Spring |
| 359 | Clutch Select Solenoid Valve 2 |
Scheme 187
| Callout | Component Name |
|---|---|
| 400 | 3-5 Reverse Clutch Backing Plate Retaining Ring |
| 401 | 3-5 Reverse Clutch Backing Plate |
| 402 | 3-5 Reverse Clutch Plate Assembly |
| 403 | 3-5 Reverse Clutch Plate |
| 404 | 3-5 Reverse Clutch (Waved) Plate |
| 405 | 3-5 Reverse Clutch Apply Ring |
| 407 | 1-2-3-4 Clutch Backing Plate |
| 408 | 1-2-3-4 Clutch Plate Assembly |
| 409 | 1-2-3-4 Clutch Plate |
| 410 | 1-2-3-4 Clutch (Waved) Plate |
| 411 | 1-2-3-4 Clutch Piston Dam Retaining Ring |
| 412 | 1-2-3-4 Clutch Piston Dam Assembly |
| 413 | 1-2-3-4 Clutch Spring |
| 414 | 1-2-3-4 Clutch Piston |
| 415 | 1-2-3-4 Clutch Piston Housing Retaining Ring |
| 416 | 1-2-3-4 Clutch Piston Seal |
| 417 | 1-2-3-4 Clutch Piston Housing |
| 418 | 3-5 Reverse Clutch Piston Dam (O-ring) Seal |
| 419 | 3-5 Reverse Clutch Piston Inner Seal |
| 420 | 3-5 Reverse Clutch Spring |
| 421 | 3-5 Reverse Clutch Piston |
| 422 | 3-5 Reverse Clutch Piston Outer Seal |
| 423 | 1-2-3-4 Clutch Piston Inner Seal |
| 424 | 1-2-3-4 Clutch Piston Housing Seal |
| 425 | 1-2-3-4 Clutch Piston Housing Seal |
| 426 | 1-2-3-4 and 3-5 Reverse Clutch Housing Rear Bushing |
| 427 | 1-2-3-4 and 3-5 Reverse Clutch Housing Assembly |
| 428 | 1-2-3-4 and 3-5 Reverse Clutch Bearing Assembly |
| 429 | 1-2-3-4 Clutch Backing Plate Retaining Ring |
Scheme 188
| Callout | Component Name |
|---|---|
| 431 | 4-5-6 Clutch Backing Plate Retaining Ring |
| 432 | 4-5-6 Clutch Backing Plate |
| 433 | 4-5-6 Clutch Plate Assembly |
| 434 | 4-5-6 Clutch Plate |
| 435 | 4-5-6 Clutch (Waved) Plate |
| 436 | 4-5-6 Clutch Piston Dam Retaining Ring |
| 437 | 4-5-6 Clutch Piston Dam Assembly |
| 438 | 4-5-6 Clutch Spring |
| 439 | 4-5-6 Clutch Piston Assembly |
| 440 | Output Carrier Shaft Housing Bushing |
| 441 | 4-5-6 (w/Turbine Shaft) Housing Assembly |
| 442 | Turbine Shaft Fluid Seal Ring |
| 443 | Turbine Shaft (O-ring) Seal |
Scheme 189
| Callout | Component Name |
|---|---|
| 450 | 2-6 Clutch Backing Plate Retaining Ring |
| 451 | 2-6 Clutch Backing Plate |
| 452 | 2-6 Clutch Plate Assembly |
| 453 | 2-6 Clutch Plate |
| 454 | 2-6 Clutch (Waved) Plate |
| 455 | 2-6 Clutch Spring Retaining Ring |
| 456 | 2-6 Clutch Spring |
| 457 | 2-6 Clutch Piston Assembly |
| 458 | Output Carrier Outer Sun Gear Shaft (Front) Bushing |
| 459 | Center Support Assembly |
| 460 | Output Carrier Outer Sun Gear Shaft Rear Bushing |
Scheme 190
| Callout | Component Name |
|---|---|
| 459 | Center Support Assembly |
| 461 | Low and Reverse Clutch Backing Plate Retaining Ring |
| 462 | Low and Reverse Clutch Backing Plate |
| 463 | Low and Reverse Clutch Plate Assembly |
| 464 | Low and Reverse Clutch Plate |
| 465 | Low and Reverse Clutch (Waved) Plate |
| 466 | Low and Reverse Clutch Spring Retaining Ring |
| 467 | Low Clutch Sprag Assembly |
| 468 | Low Clutch Sprag Seal |
| 469 | Low and Reverse Clutch Spring |
| 470 | Low and Reverse Clutch Piston Assembly |
Scheme 191
| Callout | Component Name |
|---|---|
| 475 | 4-5-6 Clutch (w/Output Carrier Shaft) Hub Assembly |
| 476 | 4-5-6 Clutch Dampener |
| 477 | 4-5-6 Clutch Dampener Apply Plate |
| 478 | 4-5-6 Clutch Dampener Retaining Ring |
Scheme 192
| Callout | Component Name |
|---|---|
| 485 | Center Support Roller Bearing Assembly |
| 486 | Output Carrier Front Sun Gear Thrust Bearing Assembly |
| 487 | Output Carrier Front Sun Gear |
| 488 | Output Carrier Front Sun Gear Rear Thrust Bearing Assembly |
| 489 | Output Carrier Rear Sun Gear |
| 490 | Output Carrier |
| 491 | Output Carrier Rear Sun Gear Thrust Bearing Assembly - Captured |
Scheme 193
| Callout | Component Name |
|---|---|
| 494 | Output Carrier Internal Gear Retaining Ring |
| 495 | Output Carrier Internal Front Gear |
| 496 | Output Carrier Internal Gear Spacer |
| 497 | Output Carrier Internal Rear Gear |
| 498 | Output Carrier Bushing |
| 499 | Output Shaft Assembly |
Scheme 194
| Callout | Component Name |
|---|---|
| 12 | A/Trans Case Plug |
| 500 | Park Pawl Shaft |
| 501 | Park Pawl Spring |
| 502 | Park Pawl |
| 503 | Park Pawl Actuator Assembly |
| 504 | Manual Shaft Detent Lever Hub Pin |
| 505 | Manual Shaft Detent Lever Assembly |
| 506 | Manual Shift Shaft Pin |
| 507 | Manual Shift Shaft Seal |
| 508 | Manual Shift Shaft |
| 509 | Park Pawl Actuator Guide |
| 510 | Park Pawl Actuator Guide (O-ring) Seal |
| 511 | Park Pawl Actuator Guide Pin |
Scheme 195
| Callout | Component Name |
|---|---|
| 1 | Torque Converter Assembly |
| 2 | Torque Converter (with Fluid Pump) Housing Assembly |
| 21 | Control (with Body and Valve) Valve Assembly |
| 51 | 1-2-3-4 and 3-5 Reverse Clutch Assembly |
| 52 | Input Carrier Assembly |
| 53 | Input Sun Gear |
| 56 | 4-5-6 (w/Turbine Shaft) Clutch Assembly |
| 58 | 4-5-6 Clutch (w/Output Carrier Shaft and Dampener) Hub Assembly |
| 61 | 1-2-3-4 Clutch (w/Output Carrier Inner Sun Gear Shaft) Hub Assembly |
| 64 | 2-6 and 3-5 Reverse Clutch (w/Output Carrier Outer Sun Gear Shaft) Hub Assembly |
| 67 | Center (w/2-6 Low and Reverse Clutch) Support Assembly |
| 68 | Output Carrier Assembly |
| 70 | Output Shaft Assembly |
| 303 | A/Trans Input and Output Speed Sensor Assembly |
| 402 | 3-5 Reverse Clutch Plate Assembly |
| 408 | 1-2-3-4 Clutch Plate Assembly |
| 452 | 2-6 Clutch Plate Assembly |
| 463 | Low and Reverse Clutch Plate Assembly |
| 467 | Low Clutch Sprag Assembly |
| 487 | Output Carrier Front Sun Gear |
| 489 | Output Carrier Rear Sun Gear |
| 495 | Output Carrier Internal Front Gear |
| 497 | Output Carrier Internal Rear Gear |
| 502 | Park Pawl |
| 503 | Park Pawl Actuator Assembly |
| 505 | Manual Shaft Detent Lever Assembly |
| 508 | Manual Shift Shaft |
Scheme 196
| Callout | Component Name |
|---|---|
| 13 | Output Shaft Bushing |
| 54 | Input Sun Gear Thrust Bearing |
| 55 | Input Sun Gear Thrust Washer |
| 57 | Turbine Shaft Thrust Bearing Assembly |
| 59 | 4-5-6 Clutch Hub Thrust Bearing Assembly |
| 60 | Output Carrier Inner Sun Gear Shaft (Front) Bushing |
| 62 | Output Carrier Inner Sun Gear Shaft Bushing |
| 63 | 1-2-3-4 Clutch Hub Thrust Bearing Assembly |
| 65 | 2-6 and 3-5 Reverse Clutch Hub Thrust Bearing Assembly |
| 69 | Output Carrier Thrust Bearing Assembly |
| 71 | Output Shaft Thrust Bearing Assembly |
| 206 | Torque Converter Bushing |
| 218 | Turbine Shaft Front Bushing |
| 228 | Turbine Shaft Rear Bushing |
| 229 | 1-2-3-4 and 3-5 Reverse Clutch Housing Thrust Washer |
| 426 | 1-2-3-4 and 3-5 Reverse Clutch Housing Rear Bushing |
| 428 | 1-2-3-4 and 3-5 Reverse Clutch Bearing Assembly |
| 440 | Output Carrier Shaft Housing Bushing |
| 458 | Output Carrier Outer Sun Gear Shaft (Front) Bushing |
| 460 | Output Carrier Outer Sun Gear Shaft Rear Bushing |
| 485 | Center Support Roller Bearing Assembly |
| 486 | Output Carrier Front Sun Gear Thrust Bearing Assembly |
| 488 | Output Carrier Front Sun Gear Rear Thrust Bearing Assembly |
| 491 | Output Carrier Rear Sun Gear Thrust Bearing - Captured |
| 498 | Output Carrier Bushing |
Scheme 197
| Callout | Component Name |
|---|---|
| 5 | A/Trans Fluid Pump Seal |
| 9 | A/Trans Connector Seal |
| 10 | A/Trans Connector (O-ring) Seal |
| 14 | Output Shaft Seal Assembly |
| 18 | A/Trans Fluid Pump Seal Assembly |
| 19 | A/Trans Fluid Pump Seal Assembly |
| 20 | Center Support Fluid Passage Seal Assembly |
| 25 | A/Trans Fluid Filter Seal Assembly |
| 27 | A/Trans Fluid Pan Gasket |
| 201 | Torque Converter Fluid Seal Assembly |
| 209 | A/Trans Fluid Pump Slide Fluid Seal Ring |
| 210 | A/Trans Fluid Pump Slide (O-ring) Seal |
| 213 | A/Trans Fluid Pump Slide Seal |
| 230 | 1-2-3-4 and 3-5 Reverse Clutch Fluid Seal Ring |
| 238 | 1-2-3-4 and 3-5 Reverse Clutch Fluid Seal Rings - Inner O-rings |
| 412 | 1-2-3-4 Clutch Piston Dam Assembly |
| 416 | 1-2-3-4 Clutch Piston Seal |
| 418 | 3-5 Reverse Clutch Piston Dam (O-ring) Seal |
| 419 | 3-5 Reverse Clutch Piston Inner Seal |
| 422 | 3-5 Reverse Clutch Piston Outer Seal |
| 423 | 1-2-3-4 Clutch Piston Inner Seal |
| 424 | 1-2-3-4 Clutch Piston Housing Seal |
| 425 | 1-2-3-4 Clutch Piston Housing Seal |
| 437 | 4-5-6 Clutch Piston Dam Assembly |
| 439 | 4-5-6 Clutch Piston Assembly |
| 442 | Turbine Shaft Fluid Seal Ring |
| 443 | Turbine Shaft (O-ring) Seal |
| 457 | 2-6 Clutch Piston Assembly |
| 468 | Low Clutch Sprag Seal |
| 470 | Low and Reverse Clutch Piston Assembly |
| 507 | Manual Shift Shaft Seal |
| 510 | Park Pawl Actuator Guide (O-ring) Seal |
Scheme 198
| I.D. | Input Oil | Input Oil | Output Oil |
|---|---|---|---|
| 1 | Drive 1-6 | DRV B | CB26/C1234 FD |
| 2 | Sol 1 | Reverse (Park) | CSV2 Enable |
| 3 | Sol 2 | C456 | CSV3 Enable |
| 4 | PS4 | C456 | CSV2 Latch |
| 5 | Drive 1-6 | C35R Rev FD | C35R Supply |
| 6 | CB26/C1234 FD | C1234 FD | |
| 7 | C35R Supply | C35R FD |
Diagnostic Starting Point - Automatic Transmission
Begin the system diagnosis with the Diagnostic System Check - Vehicle . The Diagnostic System Check - Vehicle will provide the following information
- The identification of the control module or modules which command the system.
- The ability of the control module or modules to communicate through the serial data circuit.
- The identification of any stored diagnostic trouble codes (DTCs) and the status of the codes.
The use of the Diagnostic System Check - Vehicle will identify the correct procedure for diagnosing the system and where the procedure is located.
DIAGNOSTIC CODE INDEX
| DTC | Description |
|---|---|
| DTC P0218 | P0218: Transmission Fluid Overtemperature |
| DTC P0562 or P0563 | P0562: System Voltage Low P0563: System Voltage High |
| DTC P0601-P0604 or P062F | P0601: Transmission Control Module (TCM) Read Only Memory (ROM) P0602: Transmission Control Module (TCM) Not Programmed P0603: Transmission Control Module (TCM) Long Term Memory Reset P0604: Transmission Control Module (TCM) Random Access Memory (RAM) P062F: Transmission Control Module (TCM) Long Term Memory Performance |
| DTC P0634 | P0634: Transmission Control Module (TCM) Overtemperature |
| DTC P0658 or P0659 | P0658: Solenoid High Control Circuit Group 1 Low Voltage P0659: Solenoid High Control Circuit Group 1 High Voltage |
| DTC P0667, P0668, or P0669 | P0667: Transmission Control Module (TCM) Temperature Sensor Performance P0668: Transmission Control Module (TCM) Temperature Sensor Circuit Low Voltage P0669: Transmission Control Module (TCM) Temperature Sensor Circuit High Voltage |
| DTC P06AC, P06AD, or P06AE | P06AC: Transmission Control Module (TCM) Power Up Temperature Sensor Performance P06AD: Transmission Control Module (TCM) Power Up Temperature Sensor Circuit Low Voltage P06AE: Transmission Control Module (TCM) Power Up Temperature Sensor Circuit High Voltage |
| DTC P0711 | P0711: Transmission Fluid Temperature (TFT) Sensor Performance |
| DTC P0712 or P0713 | P0712: Transmission Fluid Temperature (TFT) Sensor Circuit Low Voltage P0713: Transmission Fluid Temperature (TFT) Sensor Circuit High Voltage |
| DTC P0716 or P0717 | P0716: Input Speed Sensor Performance P0717: Input Speed Sensor Circuit Low Voltage |
| DTC P071A | P071A: Transmission Tow Mode Switch Circuit |
| DTC P0722 or P0723 | P0722: Output Speed Sensor (OSS) Circuit Low Voltage P0723: Output Speed Sensor (OSS) Intermittent |
| DTC P0741 or P0742 | P0741: Torque Converter Clutch (TCC) - Stuck Off P0742: Torque Converter Clutch (TCC) - Stuck On |
| DTC P0751 | P0751: Shift Solenoid (SS) 1 Valve Performance - Stuck Off |
| DTC P0752 | P0752: Shift Solenoid (SS) 1 Valve Performance - Stuck On |
| DTC P0756 | P0756: Shift Solenoid (SS) 2 Valve Performance - Stuck Off |
| DTC P0776 or P0777 | P0776: Clutch Pressure Control (PC) Solenoid 2 - Stuck Off P0777: Clutch Pressure Control (PC) Solenoid 2 - Stuck On |
| DTC P0796 or P0797 | P0796: Clutch Pressure Control (PC) Solenoid 3 - Stuck Off P0797: Clutch Pressure Control (PC) Solenoid 3 - Stuck On |
| DTC P0815, P0816, P0826, or P1876 | P0815: Upshift Switch Circuit P0816: Downshift Switch Circuit P0826: Up and Down Shift Switch Circuit P1876: Up and Down Shift Enable Switch Circuit Low Voltage |
| DTC P0842 or P0843 | P0842: Transmission Fluid Pressure (TFP) Switch 1 Circuit Low Voltage P0843: Transmission Fluid Pressure (TFP) Switch 1 Circuit High Voltage |
| DTC P0850-P0852 | P0850: Park/Neutral Position (PNP) Switch Circuit P0851: Park/Neutral Position (PNP) Switch Circuit Low Voltage P0852: Park/Neutral Position (PNP) Switch Circuit High Voltage |
| DTC P0872 or P0873 | P0872: Transmission Fluid Pressure (TFP) Switch 3 Circuit Low Voltage P0873: Transmission Fluid Pressure (TFP) Switch 3 Circuit High Voltage |
| DTC P0877 or P0878 | P0877: Transmission Fluid Pressure (TFP) Switch 4 Circuit Low Voltage P0878: Transmission Fluid Pressure (TFP) Switch 4 Circuit High Voltage |
| DTC P0961-P0963 | P0961: Line Pressure Control (PC) Solenoid System Performance P0962: Line Pressure Control (PC) Solenoid Control Circuit Low Voltage P0963: Line Pressure Control (PC) Solenoid Control Circuit High Voltage |
| DTC P0965-P0967 | P0965: Clutch Pressure Control (PC) Solenoid 2 System Performance P0966: Clutch Pressure Control (PC) Solenoid 2 Control Circuit Low Voltage P0967: Clutch Pressure Control (PC) Solenoid 2 Control Circuit High Voltage |
| DTC P0969-P0971 | P0969: Clutch Pressure Control (PC) Solenoid 3 System Performance P0970: Clutch Pressure Control (PC) Solenoid 3 Control Circuit Low Voltage P0971: Clutch Pressure Control (PC) Solenoid 3 Control Circuit High Voltage |
| DTC P0973 or P0974 | P0973: Shift Solenoid (SS) 1 Control Circuit Low Voltage P0974: Shift Solenoid (SS) 1 Control Circuit High Voltage |
| DTC P0976 or P0977 | P0976: Shift Solenoid (SS) 2 Control Circuit Low Voltage P0977: Shift Solenoid (SS) 2 Control Circuit High Voltage |
| DTC P0989 or P0990 | P0989: Transmission Fluid Pressure (TFP) Switch 5 Circuit Low Voltage P0990: Transmission Fluid Pressure (TFP) Switch 5 Circuit High Voltage |
| DTC P1684-P1686 | P1684: Transmission Control Module (TCM) Power Up Temperature Sensor Performance P1685: Transmission Control Module (TCM) Power Up Temperature Sensor Circuit Low Voltage P1686: Transmission Control Module (TCM) Power Up Temperature Sensor Circuit High Voltage |
| DTC P1751 | P1751: Shift Valve 1 Performance |
| DTC P1761 | P1761: Up and Down Shift Switch Signal Circuit |
| DTC P1825, P182E, or P1915 | P1825: Internal Mode Switch - Invalid Range P182E: Internal Mode Switch - Invalid Range P1915: Internal Mode Switch Does Not Indicate Park/Neutral (P/N) During Start |
| DTC P182A | P182A: Internal Mode Switch - Invalid Range |
| DTC P1831 or P1832 | P1831: Pressure Control (PC)/Shift Lock Solenoid Control Circuit Low Voltage P1832: Pressure Control (PC)/Shift Lock Solenoid Control Circuit High Voltage |
| DTC P2534 | P2534: Ignition 1 Switch Circuit Low Voltage |
| DTC P2714 or P2715 | P2714: Clutch Pressure Control (PC) Solenoid 4 - Stuck Off P2715: Clutch Pressure Control (PC) Solenoid 4 - Stuck On |
| DTC P2719-P2721 | P2719: Clutch Pressure Control (PC) Solenoid 4 System Performance P2720: Clutch Pressure Control (PC) Solenoid 4 Control Circuit Low Voltage P2721: Clutch Pressure Control (PC) Solenoid 4 Control Circuit High Voltage |
| DTC P2723 or P2724 | P2723: Clutch Pressure Control (PC) Solenoid 5 - Stuck Off P2724: Clutch Pressure Control (PC) Solenoid 5 - Stuck On |
| DTC P2728-P2730 | P2728: Clutch Pressure Control (PC) Solenoid 5 System Performance P2729: Clutch Pressure Control (PC) Solenoid 5 Control Circuit Low Voltage P2730: Clutch Pressure Control (PC) Solenoid 5 Control Circuit High Voltage |
| DTC P2762, P2763, or P2764 | P2762: Torque Converter Clutch (TCC) Pressure Control Solenoid System Performance P2763: Torque Converter Clutch (TCC) Pressure Control Solenoid Control Circuit High Voltage P2764: Torque Converter Clutch (TCC) Pressure Control Solenoid Control Circuit Low Voltage |
DIAGNOSTIC CODE INDEX
See also:
• Diagnostic System Check - Vehicle
• DTC P0218
• DTC P0969-P0971
