Engine Controls and Fuel - 3.6l - Repair Instructions Chevrolet Camaro V

Scheme 1

Description

The engine control module (ECM) learns the idle position of the throttle body to ensure the correct idle operation. Anytime the ECM or the throttle body is replaced, the ECM must learn the idle position. The engine idle may be unstable or a DTC may set if the idle position is not learned.

Conditions for Running the Idle Learn Procedure

1. DTCs P0121, P0122, P0123, P0221, P0222, P0223, P0638, P2100, P2101, P2105, and P2119 are not set.
2. The engine speed is less than 40 RPM.
3. The vehicle speed is 0 km/h (0 mph).
4. The accelerator pedal position is less than 14.9 percent.
5. The ignition 1 voltage is more than 10 volts.
6. The engine coolant temperature is between 5-85°C (41-185°F).
7. The intake air temperature is between 5-60°C (41-140°F).

Idle Learn Procedure

1. Turn OFF the ignition for 30 seconds.
2. Turn ON the ignition, with the engine OFF for 60 seconds.
3. Turn OFF the ignition.
4. Turn ON the ignition, with the engine OFF.
5. Clear the DTCs with a scan tool.

Scheme 2

Scheme 3

Removal Procedure

1. Turn the ignition OFF.
2. Remove the intake manifold cover, if necessary. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
3. Disconnect the heated oxygen sensor (HO2S) electrical connector.
4. Remove the HO2S electrical connector from the wiring harness bracket.
5. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/camaro/v-2009-2013/remont/ignition-switchsteering-lock/#general-information) .
6. Remove the HO2S from the catalytic converter.

Installation Procedure

1. Install the HO2S to the catalytic converter and tighten to 40 N.m (30 lb ft).
2. Lower the vehicle.
3. Install the HO2S electrical connector to the wiring harness bracket.
4. Connect the HO2S electrical connector.
5. Install the intake manifold cover, if necessary. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .

1. Turn the ignition OFF.
2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/camaro/v-2009-2013/remont/ignition-switchsteering-lock/#general-information) .
3. Disconnect the heated oxygen sensor (HO2S) electrical connector.
4. Remove the HO2S wiring harness from the transmission case.
5. Remove the HO2S.

1. Install the HO2S and tighten to 40 N.m (30 lb ft).
2. Connect the HO2S electrical connector.
3. Install the HO2S wiring harness to the transmission case.
4. Lower the vehicle.

1. Turn the ignition OFF.
2. Remove the intake manifold cover, if necessary. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
3. Disconnect the heated oxygen sensor (HO2S) electrical connector.
4. Remove the HO2S electrical connector from the wiring harness bracket.
5. Remove the HO2S.

1. Install the HO2S and tighten to 40 N.m (30 lb ft).
2. Install the HO2S electrical connector to the wiring harness bracket.
3. Connect the HO2S electrical connector.
4. Install the intake manifold cover, if necessary. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .

1. Turn the ignition OFF.
2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/camaro/v-2009-2013/remont/ignition-switchsteering-lock/#general-information) .
3. Disconnect the heated oxygen sensor (HO2S) electrical connector.
4. Remove the HO2S wiring harness from the transmission case.
5. Remove the HO2S.

1. Install the HO2S and tighten to 40 N.m (30 lb ft).
2. Connect the HO2S electrical connector.
3. Install the HO2S wiring harness to the transmission case.
4. Lower the vehicle.

1. Remove the closeout/insulator panel from under the dashboard on the drivers side.
2. Disconnect the accelerator pedal position (APP) sensor electrical connector from the accelerator pedal module.
3. Remove the nuts from the APP sensor and remove the APP sensor from the front of dash.

1. Install the APP sensor to the front of dash.
2. Install the APP sensor mounting nuts and tighten to 9 N.m (80 lb in).
3. Connect the APP sensor electrical connector.
4. Operate the accelerator pedal and observe the APP angles using a scan tool. The accelerator pedal should operate freely, without binding between closed throttle and wide open throttle.
5. Install the closeout/insulator panel.

1. Turn the ignition OFF.
2. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Remove the throttle body electrical connector.
4. Unlock and reposition the wiring harness conduit.
5. Remove the throttle body bolts.
6. Remove the throttle body and gasket.

1. Carefully clean the throttle body mounting surfaces of any gasket and/or seal material.
2. Install the throttle body and NEW gasket.
3. Install the throttle body bolts and tighten to 10 N.m (89 lb in).
4. Install the wiring harness conduit.
5. Install the throttle body electrical connector.
6. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
7. Perform the throttle learn procedure. Refer to «Throttle/Idle Learn (Without LF1, LFW)»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
8. Use the scan tool to clear all DTCs.

Throttle Body Inspection and Cleaning

1. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
2. Fully open the throttle valve in order to Inspect the throttle body bore and the throttle valve plate for any deposits.
3. Use a clean shop towel and Top Engine Cleaner GM P/N 1052626 or equivalent product in order to clean the throttle body bore and the throttle valve plate. If necessary, use a parts cleaning brush in order to remove heavy deposits.
4. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
5. Perform the throttle learn procedure. Refer to «Throttle/Idle Learn (Without LF1, LFW)»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .

Fuel Pressure Relief

1. Install a scan tool to the vehicle and command the fuel pump relay OFF, allowing the low pressure fuel pump to shut off.
2. Start the vehicle and allow the engine to idle until the engine stops. The engine will stop in approximately 20-30 seconds.
3. Turn the ignition OFF.
4. Using the scan tool, verify that there is little to no fuel pressure, if there still is fuel pressure repeat step 2.

Special Tools

CH-48027 Digital Pressure Gauge. See Special Tools .

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
2. Connect the CH-48027-1 (1) to the CH-48027-2 (2).
3. Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
4. Perform any tests and/or diagnostics as needed. For the proper usage of the CH-48027 , refer to the manufacture's directions. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .

1. Relieve the fuel system pressure, if required. Perform the following steps: WARNING: Wrap a shop towel around the fuel pressure connection in order to reduce the risk of fire and personal injury. The towel will absorb any fuel leakage that occurs during the connection of the fuel pressure gauge. Place the towel in an approved container when the connection of the fuel pressure gauge is complete. Wrap a shop towel around the fuel rail service port. Place the hose on the CH-48027-2 (2) into an approved gasoline container. Open the valve on the CH-48027-2 (2) in order to bleed any fuel from the fuel rail. Close the valve on the CH-48027-2 (2). Remove the hose on the CH-48027-2 (2) from the approved gasoline container. Remove the shop towel from around the fuel rail service port, and place in an approved gasoline container.
2. Disconnect the CH-48027-1 (1) from the CH-48027-2 (2).
3. Disconnect the CH-48027-2 (2) from the CH-48027-3 (4).
4. Disconnect the CH-48027-3 (4) from the fuel rail service port.
5. Install the fuel rail service port cap.
6. Tighten the fuel fill cap.

1. J 37088-A Fuel Line Disconnect Tool Set
2. J 44581 Fuel Line Disconnect Tool. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
2. Remove the retainer from the quick-connect fitting.
3. Blow dirt out of the fitting using compressed air.
4. Depending on the fuel line size and ability to access the fitting, choose the appropriate tool: J 37088-A or J 44581 . Insert the J 37088-A or J 44581 into the female connector, then push inward to release the locking tabs. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .
5. Pull the connection apart.
6. Using a clean shop towel, wipe off the male pipe end.
7. Inspect both ends of the fitting for dirt and burrs.
8. Clean or replace the components as required.

1. Apply a few drops of clean engine oil to the male pipe end.
2. Push both sides of the quick-connect fitting together to cause the retaining tabs to snap into place.
3. Pull on both sides of the quick-connect fitting to make sure the connection is secure.
4. Install the retainer to the quick-connect fitting.
5. Inspect for leaks using the following procedure: Turn the ignition ON, with the engine OFF for 2 seconds. Turn the ignition OFF, for 10 seconds. Turn the ignition ON, with the engine OFF for 2 seconds. Turn the ignition OFF. Inspect for leaks.

Disconnect Procedure

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
2. Using compressed air, blow any dirt or debris from around the connection.
3. This step applies to Bartholomew style connector ONLY. Squeeze the plastic quick connect fitting release tabs.
4. This step applies to Release Tab style connector ONLY. Release the fitting by pushing the tab toward the other side of the slot in the fitting.
5. This step applies to the Squeeze to Release style connector ONLY. Squeeze where indicated by the arrows shown above on both sides of the plastic ring surrounding the quick connect fitting.
6. This step applies to the Sliding Retainer style connector ONLY. Release the fitting by pressing on one side of the release tab causing it to push in slightly. If the tab does not move try pressing the tab in from the opposite side. The tab will only move in one direction.
7. This step applies to the Push Down TI style connector ONLY. Release the fitting by pressing on the tab indicated by the arrow.
8. Pull the connection apart.

Connect Procedure

1. Apply a few drops of clean engine oil to the male connection end.
2. Push both sides of the quick-connect fitting together in order to cause the retaining feature to snap into place.
3. Once installed, pull on both sides of the connection in order to make sure the connection is secure.

Fuel Tank Draining

Special Tools

1. J 36850 Transjel Lubricant. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .
2. J 45004 Fuel Drain Hose. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .

1. Remove the fuel filler cap.
2. Insert the J 45004 into the fuel tank until the hose reaches the bottom of the fuel tank. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .
3. Use an air operated pump device in order to drain the fuel into an approved gasoline container. Up to 26 liters (7 gallons) of residual fuel may remain in the secondary side of the fuel tank.
4. Simultaneously twist and pull in order to remove the J 45004 from the fuel tank. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .

1. Relieve the system fuel pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
2. Drain the fuel tank. Refer to «Fuel Tank Draining»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-tank-draining) .
3. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/camaro/v-2009-2013/remont/ignition-switchsteering-lock/#general-information)
4. Remove the right rear wheel. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/camaro/v-2009-2013/remont/wheel-tire-system/#tires-and-wheels)
5. Remove the exhaust system for access. Refer to «Exhaust Muffler with Resonator, Exhaust, and Tail Pipe Replacement (Vehicle Service)»(/chevrolet/camaro/v-2009-2013/remont/exhaust/#engine-exhaust-system) .
6. Remove the propeller shaft. Refer to «Two-Piece Propeller Shaft Replacement»(/chevrolet/camaro/v-2009-2013/remont/driveshaft-universal-joints/#propeller-shaft) .
7. Remove the park brake cables. Refer to «Parking Brake Rear Cable Replacement»(/chevrolet/camaro/v-2009-2013/remont/parking-brake-system/#parking-brake-system) . Support the rear suspension with a jack stand. Remove the front support bolts. Loosen the rear support bolts in order to slide the fuel tank out. For tightening specifications, refer to «Rear Suspension Support Replacement»(/chevrolet/camaro/v-2009-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
8. Disconnect the evaporative emission lines (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
9. Disconnect the vent solenoid electrical connector (2).
10. Loosen the hose clamp (1) and remove the filler tube (2).
11. Disconnect the evaporative emission line (3). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
12. Disconnect the fuel tank electrical connector (1).
13. Disconnect the fuel feed line (3) and evaporative emission line (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) and «Metal Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
14. Support the fuel tank with a suitable jack.
15. Remove the fuel tank strap bolts (1).
16. Remove the fuel tank.
17. Remove the following components if replacing just the fuel tank. Fuel pump module. Refer to «Fuel Tank Fuel Pump Module Replacement - Right Side»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) . Fuel level sensor. Refer to «Fuel Level Sensor Replacement - Left Side»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) . Transfer components as necessary.

1. Install the following components if fuel tank replacement was necessary: Fuel pump module. Refer to «Fuel Tank Fuel Pump Module Replacement - Right Side»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) . Fuel level sensor. Refer to «Fuel Level Sensor Replacement - Left Side»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
2. Use a suitable jack and install the fuel tank.
3. Install the fuel tank strap bolts (1) and tighten to 50 N.m (37 lb ft).
4. Connect the fuel tank electrical connector (1).
5. Connect the fuel feed line (2) and evaporative emission line (3). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) and «Metal Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
6. Install the filler tube (2) and tighten the hose clamp (1) to 4 N.m (35 lb in) and remove the filler tube (2).
7. Connect the evaporative emission line (3). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
8. Connect the evaporative emission lines (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
9. Connect the vent solenoid electrical connector (2).
10. Connect the parking brake cables at the calipers. Refer to «Parking Brake Rear Cable Replacement»(/chevrolet/camaro/v-2009-2013/remont/parking-brake-system/#parking-brake-system) .
11. Install the rear suspension support and tighten to specifications. Refer to «Rear Suspension Support Replacement»(/chevrolet/camaro/v-2009-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
12. Install the park brake cables. Refer to «Parking Brake Rear Cable Replacement»(/chevrolet/camaro/v-2009-2013/remont/parking-brake-system/#parking-brake-system) .
13. Install the propeller shaft. Refer to «Two-Piece Propeller Shaft Replacement»(/chevrolet/camaro/v-2009-2013/remont/driveshaft-universal-joints/#propeller-shaft) .
14. Install the exhaust system for access. Refer to «Exhaust Muffler with Resonator, Exhaust, and Tail Pipe Replacement (Vehicle Service)»(/chevrolet/camaro/v-2009-2013/remont/exhaust/#engine-exhaust-system) .
15. Install the right rear wheel. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/camaro/v-2009-2013/remont/wheel-tire-system/#tires-and-wheels)
16. Refill the fuel tank.
17. Inspect for fuel leaks.

J 45722 Fuel Sender Lock Ring Wrench. See Special Tools .

1. Remove the fuel tank. Refer to «Fuel Tank Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
2. Disconnect the fuel pump electrical connector (1) and the fuel feed line (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Use the J 45722: wrench by turning counter clockwise and remove the lock ring (1).
4. Partially remove the primary fuel tank module in order to disconnect the fuel transfer hose quick connect fitting (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
5. Remove the primary fuel tank module (1) and seal (2) from the fuel tank.

1. Install a NEW seal (2) and partially install the primary fuel tank module (1).
2. Connect the fuel transfer hose quick connect fitting (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Use the J 45722: wrench by turning clockwise and install the lock ring (1).
4. Connect the fuel pump electrical connector (1) and the fuel feed line (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
5. Install the fuel tank. Refer to «Fuel Tank Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .

Scheme 4

Scheme 5

1. Remove the fuel filler cap.
2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/camaro/v-2009-2013/remont/ignition-switchsteering-lock/#general-information) .
3. Drain the fuel tank below the level of the fuel filler hose. Refer to «Fuel Tank Draining»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-tank-draining) .
4. Remove the right rear wheel. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/camaro/v-2009-2013/remont/wheel-tire-system/#tires-and-wheels) .
5. Remove the right rear wheelhouse Liner. Refer to «Rear Wheelhouse Panel Liner Replacement»(/chevrolet/camaro/v-2009-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
6. Remove the filler tube to chassis retaining bolts (6).
7. Disconnect the evaporative emission (EVAP) line (2) from the quick connect fitting (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
8. Remove the retaining hose clamp (4).
9. Disconnect the fuel filler tube (3) from the fuel filler hose (5).
10. Maneuver the fuel filler tube (7) and remove from the vehicle.

1. Install the fuel filler tube (7) to the vehicle.
2. Connect the fuel filler tube (3) to the fuel filler hose (5).
3. Install the retaining hose clamp (4) and tighten the fuel filler tube hose clamp (3) to 3.5 N.m (31 lb in).
4. Connect the evaporative emission (EVAP) line (2) to the quick connect fitting (1).
5. Install the filler tube to chassis retaining bolts (6) and tighten to 9 N.m (80 lb in).
6. Install the right rear wheelhouse Liner. Refer to «Rear Wheelhouse Panel Liner Replacement»(/chevrolet/camaro/v-2009-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
7. Install the right rear wheel. Refer to «Tire and Wheel Removal and Installation»(/chevrolet/camaro/v-2009-2013/remont/wheel-tire-system/#tires-and-wheels) .

CH 48482: Fuel Sender Lock Wrench

1. Remove the fuel tank. Refer to «Fuel Tank Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
2. Disconnect the secondary fuel tank module electrical connector (1).
3. Rotate the lock ring (1) counterclockwise using the CH-48482: wrench and remove the lock ring.
4. Partially remove the primary fuel tank module in order to disconnect the fuel transfer hose quick connect fitting (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
5. Remove the secondary fuel tank module (1) and the seal (2).

1. Install a NEW seal (2).
2. Partially install the secondary fuel pump module in order to connect the fuel transfer hose quick connect fitting (1). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Rotate the lock ring (1) clockwise using the CH-48482: wrench and install the lock ring.
4. Connect the secondary fuel tank module electrical connector (1).
5. Install the fuel tank. Refer to «Fuel Tank Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .

Scheme 6

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
2. Disconnect the fuel feed connector (1) and the evaporative emission connector (2). Refer to «Metal Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) and «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/camaro/v-2009-2013/remont/ignition-switchsteering-lock/#general-information) .
4. Remove the exhaust heat shield fasteners (3) and the exhaust heat shield (4).
5. Remove the exhaust heat shield fastener (1) and the exhaust heat shield (2).
6. Remove the brake pipe heat shield fastener (1) and the heat shield (2).
7. Remove the plastic retainer (1) and the retaining nut (2).
8. Separate the fuel feed line and the evaporative emission line from the clips (1).
9. Remove the protector bracket fasteners (1) and remove the bracket (2).
10. Disconnect the fuel feed line (1) and the evaporative emission line (2). Refer to «Metal Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) and «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
11. Remove the pipes (3) from the vehicle.

1. Install the pipes (3) to the vehicle and connect the evaporative emission line (2) and the fuel fed line (1) Refer to «Metal Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) and «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
2. Install the protector bracket (2) and the bracket fasteners (1) then tighten to 3 N.m(27 lb in).
3. Install the fuel feed line and the evaporative emission line to the clips (1).
4. Install the plastic retainer (1) and the retaining nut (2), then tighten to 3 N.m (27 lb in).
5. Install the heat shield (2) and the brake pipe heat shield fastener (1), then tighten to 22 N.m (16 lb ft).
6. Install the exhaust heat shield (2) and the exhaust heat shield fastener (1), then tighten to 3 N.m (27 lb in).
7. Install the exhaust heat shield (4) and the exhaust heat shield fasteners (3), then tighten to 6 N.m (53 lb in).
8. Connect the fuel feed connector (1) and the evaporative emission connector (2). Refer to «Metal Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) and «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
9. Inspect for leaks using the following procedure: Turn ON the ignition, with the engine OFF for 2 seconds. Turn OFF the ignition, for 10 seconds. Turn ON the ignition, with the engine OFF. Inspect for fuel leaks.

Scheme 7

1. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Rear»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
2. Remove the high pressure pump shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Relieve the low side fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
4. Disconnect the fuel feed line quick connect fitting from the fuel feed pipe (2). Refer to «Metal Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
5. Loosen the fuel feed pipe fitting to the high pressure fuel pump.
6. Remove the fuel feed pipe bolts (4) from the cylinder heads.
7. Remove the fuel feed pipe from the engine and high pressure fuel pump. Discard the pipe.

1. Ensure that the fuel feed pipe and fuel pump fittings are clean and dry prior to assembly.
2. Position the NEW fuel feed pipe (2) to the cylinder head and high pressure fuel pump.
3. Install the fuel feed pipe fitting to the high pressure fuel pump hand tight.
4. Install the fuel feed pipe bolts (4). Tighten the bolts to 50 N.m (37 lb ft). Tighten the fitting to 28 N.m (20 lb ft).
5. Connect the fuel feed line quick connect fitting to the fuel feed pipe (2). Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
6. Inspect for leaks using the following procedure: Turn ON the ignition, with the engine OFF for 2 seconds. Turn OFF the ignition, for 10 seconds. Turn ON the ignition, with the engine OFF. Inspect for fuel leaks.
7. Install the low side fuel pressure service port cap.
8. Install the fuel tank cap.
9. Install the high pressure pump shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
10. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Rear»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .

Fuel System Cleaning

The following procedure covers the disassembly and the inspection of the complete fuel supply system. If the fuel system is contaminated, the fuel system can be cleaned. You can usually determine the extent of the fuel system contamination during the disassembly.

1. Remove the fuel module assemblies. Refer to «Fuel Tank Fuel Pump Module Replacement - Right Side»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) and «Fuel Level Sensor Replacement - Left Side»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
2. Locate the tank in a suitable work area away from any heat, any flame, or any other source of ignition.
3. Perform the following procedures: Inspect the fuel sender strainer. Replace the primary fuel tank module if the strainer is contaminated. Inspect the secondary fuel tank module for debris. Clean the secondary fuel tank module if debris is found. WARNING: Wear safety glasses when using compressed air, as flying dirt particles may cause eye injury. Use compressed air in order to apply air pressure to the transfer tube.
4. Flush the fuel tank with running hot water for at least five minutes. Pour the water out of the fuel sender assembly opening. Rock the tank in order to ensure that the removal of the water from the tank is complete.
5. Refer to «Metal Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) in order to disconnect the following quick connect fittings from the fuel rail: The feed hose/pipe The return hose/pipe
6. Use compressed air in order to apply air pressure to the fuel lines in the opposite direction from the normal fuel flow.
7. Remove the fuel injectors and fuel rail.
8. Clean and inspect the fuel injectors and fuel rail.

Assemble the fuel system as follows

1. Install the fuel injectors and fuel rail.
2. Install the fuel module assemblies. Refer to «Fuel Tank Fuel Pump Module Replacement - Right Side»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) and «Fuel Level Sensor Replacement - Left Side»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Refer to «Metal Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) in order to connect the following quick connect fittings to the fuel rail: The feed hose/pipe The return hose/pipe

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
2. Remove the cross vehicle brace.
3. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
4. Remove the foam insulator from the fuel rails.
5. Using a 27 mm socket, remove the fuel pressure sensor (1) from the fuel injection fuel rail (2). Discard the fuel pressure sensor.
6. Allow any fuel to drain from the fuel rail and pressure sensor location.
7. Dry the sealing cone in the fuel rail and the area around the sensor joint with a lint free cloth.
8. Inspect the sealing cone in the fuel rail. The surface should be free of fuel, debris, and burrs.

Note. Applying force to the plastic housing of the sensor will destroy the sensor. To tighten or loosen, only apply force to the attached hexagon.

Note. Ensure that the fuel rail threads have been cleaned of any excess fuel, or the NEW fuel injection fuel rail fuel pressure sensor will NOT seal properly.

1. Lubricate the threads and the sealing cone in the fuel rail with silicon free engine oil GM P/N 12345610 (Canadian P/N 993193) or equivalent.
2. Lubricate the threads and sealing cone on the NEW fuel injection fuel rail fuel pressure sensor with silicon free engine oil GM P/N 12345610 (Canadian P/N 993193) or equivalent.
3. Install the NEW fuel pressure sensor (1) to the fuel injection fuel rail (2) hand tight.
4. Remove the NEW fuel injection fuel rail fuel pressure sensor, re-lubricate following steps 1 and 2 above.
5. Install the NEW fuel pressure sensor (1) to the fuel injection fuel rail (2) and tighten the sensor to 33 N.m (25 lb ft).
6. Install the foam insulator from the fuel rails.
7. Install the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
8. Inspect for fuel leaks using the following procedure: Turn ON the ignition, with the engine OFF for 2 seconds. Turn OFF the ignition, for 10 seconds. Turn ON the ignition, with the engine OFF. Inspect for fuel leaks.
9. Install the cross vehicle brace.

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
2. Remove the cross vehicle brace.
3. Remove the fuel pipe shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
4. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
5. Remove the high pressure fuel pipe. Discard the pipe. Refer to «Fuel Feed Intermediate Pipe Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
6. Remove the fuel rail crossover pipe. Refer to «Fuel Injection Fuel Rail Crossover Tube Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) . Discard the pipe.
7. Remove the foam insulator from the fuel rails.
8. Disconnect the fuel pressure sensor electrical connector and cut the wire harness tie straps.
9. Remove the fuel rail (2) bolts (1).
10. Remove the fuel pressure sensor. Refer to «Fuel Pressure Sensor Replacement - Fuel Injection Fuel Rail»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
11. Remove and discard the direct fuel injector hold down clamps.
12. Once the fuel rail is removed, remove the fuel injectors and rebuild them. Refer to «Fuel Injector Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .

1. Install the rebuilt direct fuel injectors (1) to the cylinder heads. Refer to «Fuel Injector Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
2. Install NEW direct injector hold down clamps to the injector.
3. On a new fuel rail, lubricate the fuel injector cups with silicon free engine oil GM P/N 12345610 (Canadian P/N 9931930) or equivalent.
4. Carefully place the fuel rail (2) into position, placing the front into the fuel rail over the front injector and rotating the rear downward.
5. Install the 2 outer fuel rail bolts first, then the 2 inner bolts, and hand tighten.
6. Tighten the fuel rail bolts in the sequence shown: Tighten the Bank 1 fuel rail bolts first pass to 12 N.m (106 lb in). Tighten the Bank 1 fuel rail bolts final pass to 23 N.m (17 lb ft).
7. Install a NEW fuel rail crossover pipe. Refer to «Fuel Injection Fuel Rail Crossover Tube Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
8. Install a NEW high pressure fuel pipe. Refer to «Fuel Feed Intermediate Pipe Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
9. Install the high pressure fuel sensor. Refer to «Fuel Pressure Sensor Replacement - Fuel Injection Fuel Rail»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
10. Connect the fuel injector wiring harness electrical connector to the fuel injectors, fuel rail and fuel pressure sensor.
11. Inspect for fuel leaks using the following procedure: Turn ON the ignition, with the engine OFF for 2 seconds. Turn OFF the ignition, for 10 seconds. Turn ON the ignition, with the engine OFF. Inspect for fuel leaks.
12. Install the foam insulator from the fuel rails.
13. Install the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
14. Install the fuel pipe shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
15. Install the low side fuel pressure service port cap.
16. Install the fuel tank cap.
17. Install the cross vehicle brace.

1. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
2. Remove the fuel pipe shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Remove the high pressure fuel sensor. Refer to «Fuel Pressure Sensor Replacement - Fuel Injection Fuel Rail»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
4. Remove the fuel rail crossover pipe. Refer to «Fuel Injection Fuel Rail Crossover Tube Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) . Discard this pipe.
5. Remove the fuel rail bolts (1).
6. Carefully remove the Bank 2 fuel rail (2) from the engine. Lift the rear of the rail to ease removal.
7. Remove and discard the direct fuel injector hold down clamps.
8. Once the fuel rail is removed, remove the fuel injectors and rebuild them. Refer to «Fuel Injector Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .

1. Install the rebuilt direct fuel injectors (1) to the cylinder heads. Refer to «Fuel Injector Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
2. Install new direct injector hold down clamps to the injectors.
3. On the new fuel rail, lubricate the fuel injector cups with silicon free engine oil GM P/N 12345610 (Canadian P/N 9931930) or equivalent.
4. Carefully place the fuel rail (2) into position, placing the front into the fuel rail over the front injector and rotating the rear downward.
5. Install the 2 outer fuel rail bolts first, then the 2 inner bolts and hand tighten.
6. Tighten the fuel rail bolts in the sequence shown: Tighten the Bank 1 fuel rail bolts first pass to 12 N.m (106 lb in). Tighten the Bank 1 fuel rail bolts a final pass to 23 N.m (17 lb ft).
7. Install a NEW fuel rail crossover pipe. Refer to «Fuel Injection Fuel Rail Crossover Tube Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
8. Install the high pressure fuel sensor. Refer to «Fuel Pressure Sensor Replacement - Fuel Injection Fuel Rail»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
9. Connect the fuel injector wiring harness electrical connector (1) from the fuel injectors, fuel rail and fuel pressure sensor.
10. Inspect for fuel leaks using the following procedure: Turn ON the ignition, with the engine OFF for 2 seconds. Turn OFF the ignition, for 10 seconds. Turn ON the ignition, with the engine OFF. Inspect for fuel leaks.
11. Install the fuel pipe shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
12. Install the low side fuel pressure service port cap.
13. Install the fuel tank cap.

1. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
2. Remove the high pressure pump shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
4. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
5. Loosen the fuel rail crossover pipe (1) fitting to the right fuel rail (2).
6. Loosen the fuel rail crossover pipe (1) fitting to the right fuel rail (3).
7. Remove the fuel rail crossover pipe (1) from the vehicle. Discard the pipe.

1. Ensure that the fuel rail crossover pipe, right fuel rails fittings and left fuel rail fittings are clean and dry prior to assembly.
2. Position the fuel rail crossover pipe (1) to the right fuel rails fitting (2) and left fuel rail fitting (3).
3. Tighten the fuel rail crossover pipe fittings. Tighten the fittings first pass to 16 N.m (12 lb ft). Tighten the fittings final pass to 32 N.m (24 lb ft).
4. Inspect for leaks using the following procedure: Turn ON the ignition, with the engine OFF for 2 seconds. Turn OFF the ignition, for 10 seconds. Turn ON the ignition, with the engine OFF. Inspect for fuel leaks.
5. Install the low side fuel pressure service port cap.
6. Install the fuel tank cap.
7. Install the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
8. Install the high pressure pump shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
9. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .

1. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
2. Remove the high pressure pump shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Relieve fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
4. Remove the foam insulator from the pipes.
5. Loosen the high pressure pipe fitting to the high pressure fuel pump (1).
6. Loosen the high pressure pipe fitting to the left fuel rail (3).
7. Remove the high pressure fuel pipe (2) from the vehicle. Discard the pipe.

1. Ensure that the high pressure fuel pipe, fuel rail fitting and fuel pump fitting are clean and dry prior to assembly.
2. Position the NEW high pressure fuel pipe (2) to the high pressure fuel pump fitting (1) and left fuel rail (3). hand tighten the fitting.
3. Tighten the high pressure fuel pipe fitting. Tighten the fitting a first pass to 16 N.m (12 lb ft). Tighten the fitting a final pass to 32 N.m (24 lb ft).
4. Inspect for leaks using the following procedure: Turn ON the ignition, with the engine OFF for 2 seconds. Turn OFF the ignition, for 10 seconds. Turn ON the ignition, with the engine OFF. Inspect for fuel leaks.
5. Install the low side fuel pressure service port cap.
6. Install the fuel tank cap.
7. Install the high pressure pump shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
8. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .

1. Remove the cross vehicle brace.
2. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
3. Remove the intake manifold insulator.
4. Remove the fuel pipe shield to intake manifold bolts (1).
5. Remove the fuel pipe shield to cylinder bolt (1).
6. Carefully remove the fuel pipe shield from the vehicle. Take care not to damage the insulation behind the shield.

1. Position the fuel pipe shield behind the high pressure fuel pump. Take care not to damage the insulation behind the shield.
2. Install the fuel pipe shield to cylinder bolt (1). Hand tighten at this time.
3. Install the fuel pipe shield to intake manifold bolts (1). Tighten the fuel pipe shield to manifold bolts to 23 N.m (17 lb ft). Tighten the fuel pipe shield to head bolt to 10 N.m (89 lb in).
4. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
5. Install the cross vehicle brace.

EN-48896 HP Fuel Pump Installation Alignment Gauge. See Special Tools .

1. Relieve the low and high side fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
2. Remove the cross vehicle brace.
3. Remove the high pressure fuel pump shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
4. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
5. Remove the wiper module. Refer to «Windshield Wiper Motor Replacement»(/chevrolet/camaro/v-2009-2013/remont/wiperwasher-systems/#wiper-system-and-washer-system) .
6. Disconnect the engine wiring harness electrical connector from the high pressure fuel pump.
7. Remove the radiator surge tank outlet pipe.
8. Remove the low pressure feed pipe.
9. Remove the high pressure pipe. Refer to «Fuel Feed Intermediate Pipe Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) . Discard this pipe.
10. Remove and discard the high pressure fuel pump bolts (4).
11. Remove the high pressure fuel pump (3).
12. Remove and discard the high pressure fuel pump gasket (2).
13. Remove and discard the high pressure fuel pump O-ring.
14. Remove the high pressure fuel pump roller lifter.

1. Use the EN-48896 to ensure that the camshaft lobe is in the base circle position. At base circle the tool will be flush with the head. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .
2. Lubricate the high pressure fuel pump cylinder head bore and roller lifter with camshaft prelube GM P/N 12345501 (Canadian P/N 992704) or equivalent.
3. Install high pressure fuel pump roller lifter.
4. Install a NEW high pressure fuel pump O-ring.
5. Position the NEW high pressure fuel pump gasket (2) and bolts (4) to the fuel pump.
6. Install the high pressure fuel pump (3) to the cylinder head (1). Force will be required while hand tightening the bolts.
7. Tighten the high pressure fuel pump retaining bolts to 15 N.m (11 lb ft).
8. Ensure the high pressure fuel pump and fuel rail fittings are clean prior to assembly.
9. Install a NEW high pressure fuel pipe. Refer to «Fuel Feed Intermediate Pipe Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
10. Install the fuel feed pipe to the high pressure fuel pump.
11. Connect the high pressure fuel pump wiring harness.
12. Install the radiator surge tank outlet pipe.
13. Install the fuel tank cap.
14. Inspect for leaks using the following procedure: Turn ON the ignition, with the engine OFF for 2 seconds. Turn OFF the ignition, for 10 seconds. Turn ON the ignition, with the engine OFF. Inspect for fuel leaks.
15. Install the pressure relief cap to the fuel feed pipe.
16. Install the wiper module. Refer to «Windshield Wiper Motor Replacement»(/chevrolet/camaro/v-2009-2013/remont/wiperwasher-systems/#wiper-system-and-washer-system) .
17. Install the intake manifold. Refer to «Intake Manifold Replacement»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
18. Install the high pressure fuel pump shield. Refer to «Fuel Pipe Shield Replacement»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
19. Install the cross vehicle brace.

1. EN-47909 Injector Bore and Sleeve Cleaning Kit
2. EN-48266 Injector Seal Installer and Sizer. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .
3. J 2619-01 Slide Hammer. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .
4. J-37281-A Injector Remover. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .
5. J 39313 Spark Plug Port Adapter. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .

1. Relieve the high side fuel system pressure. Refer to «Fuel Pressure Relief»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions__fuel-pressure-relief) .
2. Remove the fuel injection fuel rail assembly. Refer to «Fuel Injection Fuel Rail Assembly Replacement - Bank 1»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) or «Fuel Injection Fuel Rail Assembly Replacement - Bank 2»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Remove and discard the three fuel injector retaining rings (1).
4. Remove the direct fuel injectors and harness (1) as an assembly, and disconnect the electrical connector (2). If necessary, use the J 2619-01 with the J-37281-A in order to remove the direct fuel injectors evenly. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .
5. Remove and discard the following components from the fuel injectors (4). Upper O-ring Seal (1) Plastic Spacer (2) Retaining Ring (3) Isolator Cup (5) Teflon Seal (6)
6. Inspect the fuel rail injector bores and clean with J 39313 , and EN-47909 , if required. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .

1. Install the following NEW components to the fuel injectors. Use steps 2 through 8 to install these components. Upper O-ring Seal (1) Plastic Spacer (2) Retaining Ring (3) Isolator Cup (5) Teflon Seal (6)
2. From the EN-48266 , position the EN 48266-1 to the injector tip. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .
3. Install a NEW teflon seal onto the EN 48266-1.
4. Pull the NEW teflon seal by hand over the EN 48266-1 and into the groove in the injector.
5. Remove the EN 48266-1 from the injector tip.
6. From the EN-48266 , install the EN 48266-2 to the injector tip. See «Special Tools»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-special-tools-and-equipment) .
7. Using the EN 48266-2, resize the teflon seal. Install the EN 48266-2, until it bottoms out against the injector body, and rotate the EN 48266-2 while applying only moderate force 180 degrees in one direction and then 180 degrees back in the other direction.
8. Remove the EN 48266-2.
9. Install the direct fuel injectors and harness (1) as an assembly and connect the electrical connector (2).
10. Install the fuel injection fuel rail assembly. Refer to «Fuel Injection Fuel Rail Assembly Replacement - Bank 1»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) or «Fuel Injection Fuel Rail Assembly Replacement - Bank 2»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .

1. Turn the ignition OFF.
2. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Rear»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
3. Disconnect the purge line (3) from the purge valve solenoid.
4. Disconnect the purge valve solenoid electrical connector.
5. Disconnect the purge line from the manifold side of the purge valve solenoid.
6. Remove the purge valve solenoid from the bracket.

1. Install the purge valve solenoid to the bracket.
2. Disconnect the purge line from the manifold side of the purge valve solenoid.
3. Disconnect the purge valve solenoid electrical connector.
4. Connect the purge line (3) to the purge valve solenoid.
5. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Rear»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .

Scheme 8

Scheme 9

Scheme 10

1. Remove the rear suspension support. Refer to «Rear Suspension Support Replacement»(/chevrolet/camaro/v-2009-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .
2. Disconnect the vent solenoid electrical connector (1).
3. Disconnect the evaporative emission hoses (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
4. Remove the evaporative emission canister fasteners (1) and the evaporative emission canister (2).
5. Remove the evaporative vent solenoid valve (1) from the carbon canister.

1. Install the evaporative vent solenoid valve (1) to the carbon canister.
2. Install the evaporative emission canister (2) and tighten the fasteners (1) to 9 N.m (80 lb in).
3. Connect the evaporative emission hoses (2). Refer to «Plastic Collar Quick Connect Fitting Service»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
4. Connect the vent solenoid electrical connector (1).
5. Install the rear suspension support. Refer to «Rear Suspension Support Replacement»(/chevrolet/camaro/v-2009-2013/remont/frames-subframes-crossmembers/#frame-and-underbody) .

1. Turn the ignition OFF.
2. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
3. Remove the ignition coil electrical connector(s).
4. Remove the ignition coil bolt(s).
5. Remove the ignition coil(s).

1. Install the ignition coil(s).
2. Install the ignition coil bolt(s) and tighten to 10 N.m (89 lb in).
3. Install the ignition coil electrical connector(s).
4. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .

Scheme 11

1. Turn the ignition OFF.
2. Remove the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .
3. If you are replacing the ignition coil for cylinder 2, remove and reposition the intake manifold. Perform the following steps: Disconnect the air cleaner duct from the throttle body. Disconnect the positive crankcase ventilation (PCV) hose from the right bank camshaft cover. NOTE: Do NOT separate the upper intake manifold from the lower intake manifold. Remove the intake manifold bolts. Remove the intake manifold brace bolts (1 and 2) and the brace. Remove and reposition the upper intake manifold with the lower intake manifold in order to gain sufficient clearance for ignition coil removal.
4. Remove the ignition coil electrical connector(s).
5. Remove the ignition coil bolt(s).
6. Remove the ignition coil(s).

1. Install the ignition coil(s).
2. Install the ignition coil bolt(s) and tighten to 10 N.m (89 lb in).
3. Install the ignition coil electrical connector(s).
4. If necessary, install the upper intake manifold.
5. Install the intake manifold cover. Refer to «Intake Manifold Cover Replacement - Front»(/chevrolet/camaro/v-2009-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle-1-of-2) .

Spark Plug Operation

Worn or dirty spark plugs may operate well at idle speeds, but frequently fail at higher load. Bad spark plugs are often responsible for the following conditions

1. Power loss
2. Poor fuel economy
3. Loss of speed
4. Hard starting
5. Poor engine performance

Normal spark plug operation results in brown to grayish tan deposits on the area of the spark plug that enters the cylinder. A small amount of reddish brown, yellow, and white powdery residue may also be present on the insulator tip around the center electrode. These deposits are normal combustion by-products of fuels and lubricating oils which contain additives.

Misfiring is a general term that applies to a poor running engine. With misfiring, the ignition spark is not igniting the air/fuel mixture at the proper time. While other possible causes must be investigated, the spark plugs should be inspected first. Spark voltage should not reach ground before jumping across the gap at the tip of the spark plug. This leaves the air/fuel mixture unburned, causing misfiring. Pre-ignition misfiring occurs when the spark plug tip overheats, igniting the mixture before the spark jumps.

Carbon fouling of the spark plug is indicated by dry carbon deposits on the portion of the spark plug inside of the cylinder. Excess idling and driving at slower speeds under light engine loads can keep the spark plug temperatures so low that these deposits are not burned off. Rich fuels or poor ignition system output may also cause carbon fouling.

Oil fouling of the spark plug appears as wet oily deposits on the portion of the spark plug inside of the cylinder. This may be caused by the following conditions

1. Oil getting past worn piston rings
2. Breaking in a new or recently overhauled engine

Deposit fouling of the spark plug occurs when the normal reddish brown, yellow, or white deposits of combustion by-products become sufficient enough to cause misfiring. In some cases, these deposits melt and form a shiny glaze on the insulator around the center electrode. If the fouling is found only in one or two of the cylinders, valve stem clearances or the intake valve seals may be allowing excess lubricating oil to enter the cylinder, particularly if the deposits are heavier on the intake valve side of the spark plug.

Excess gap means that the air space between the center and side electrodes at the bottom of the spark plug is too wide for consistent firing. This may be due to improper gap adjustment or to excess wear of the electrodes during use. A gap that is too small may cause idling instability. Excess gap wear might indicate vehicle operation at continual high speeds or with high engine loads. This causes the spark plugs to run too hot. Excessively lean fuel may also cause the wear.

Improper torque or seating can cause a spark plug to run hot, eventually leading to excess gap wear. In extreme cases, an overtightened or under-tightened spark plug can cause exhaust blow-by. The cylinder head seats must make good contact for sufficient heat transfer and spark plug cooling. Dirty or damaged threads in the head or on the spark plug can keep the spark plug from seating even though the proper torque is applied. Once the spark plugs are properly seated, tighten the spark plugs properly.

Cracked or broken insulators and insulator tips may be the result of improper installation or heat shock. Heat shock is a rapid increase in the insulator tip temperature which causes the insulator material to crack. The upper insulators can be broken when a poorly-fitting tool is used during servicing, or when the spark plug is hit from the outside. Cracks in the upper insulator may be inside the shell or invisible. The breakage may not cause problems until oil or water penetrates the crack later. Heat shock breakage in the lower insulator tip generally occurs during severe engine operating conditions such as higher RPM or heavy loading. Over advanced timing or low grade fuels may also cause heat shock breakage. Always replace spark plugs with broken or cracked insulators.

Damage during gapping can occur when the tool is pushed against the center electrode or the surrounding insulator, causing the insulator to crack. When gapping a spark plug, bend only the outside electrode. Keep tools free of any other parts.

Spark plugs with less than the recommended amount of service can sometimes be cleaned and re-gapped, then returned to service. If there is any doubt about the serviceability of a spark plug, replace the spark plug.

1. Turn the ignition OFF.
2. Remove the ignition coil. Refer to «Ignition Coil Replacement - Bank 1»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) and/or «Ignition Coil Replacement - Bank 2»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .
3. Use compressed air in order to remove debris from the spark plug cavity.
4. Remove the spark plug.

1. Ensure that the spark plug gap is equivalent to the spark plug gap specification. Refer to «Ignition System Specifications»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-specifications__ignition-system-specifications) .
2. Install the spark plug and tighten to 20 N.m (15 lb ft).
3. Install the ignition coil. Refer to «Ignition Coil Replacement - Bank 1»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) and/or «Ignition Coil Replacement - Bank 2»(/chevrolet/camaro/v-2009-2013/remont/testing-diagnostics/#engine-controls-and-fuel-36l-repair-instructions) .

1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/camaro/v-2009-2013/remont/ignition-switchsteering-lock/#general-information) .
2. Disconnect the crankshaft position (CKP) electrical connector (3).
3. Remove the crankshaft sensor bolt.
4. Remove the crankshaft sensor.

1. Install the crankshaft position sensor.
2. Install the crankshaft position sensor bolt and tighten to 10 N.m (89 lb in).
3. Connect the CKP electrical connector (3).
4. Lower the vehicle.

1. Turn the ignition OFF.
2. Remove the power steering fluid reservoir bolts and reposition the power steering fluid reservoir in order to provide access. Refer to «Power Steering Fluid Reservoir Replacement (V6)»(/chevrolet/camaro/v-2009-2013/remont/manual-power-steering/#power-steering-system) .
3. Remove the camshaft position (CMP) sensor electrical connector.
4. Remove the CMP sensor bolt.
5. Remove the CMP sensor.

1. Install the CMP sensor.
2. Install the CMP sensor bolt and tighten to 10 N.m (89 lb in).
3. Install the CMP sensor electrical connector.
4. Install the power steering fluid reservoir. Refer to «Power Steering Fluid Reservoir Replacement (V6)»(/chevrolet/camaro/v-2009-2013/remont/manual-power-steering/#power-steering-system) .

1. Turn the ignition OFF.
2. Remove the power steering fluid reservoir bolts and reposition the power steering fluid reservoir in order to provide access. Refer to «Power Steering Fluid Reservoir Replacement (V6)»(/chevrolet/camaro/v-2009-2013/remont/manual-power-steering/#power-steering-system) .
3. Remove the camshaft position (CMP) sensor electrical connector.
4. Remove the CMP sensor bolt.
5. Remove the CMP sensor.

1. Install the CMP sensor.
2. Install the CMP sensor bolt and tighten to 10 N.m (89 lb in).
3. Install the CMP sensor electrical connector.
4. Install the power steering fluid reservoir. Refer to «Power Steering Fluid Reservoir Replacement (V6)»(/chevrolet/camaro/v-2009-2013/remont/manual-power-steering/#power-steering-system) .

1. Turn the ignition OFF.
2. Remove the front compartment sight shields as necessary.
3. Disconnect the camshaft position (CMP) sensor electrical connector.
4. Remove the CMP sensor bolt.
5. Remove the CMP sensor.

1. Install the CMP sensor.
2. Install the CMP sensor bolt and tighten to 10 N.m (89 lb in).
3. Connect the CMP sensor electrical connector.
4. Install the front compartment sight shields as necessary.

1. Turn the ignition OFF.
2. Remove the front compartment sight shields as necessary.
3. Disconnect the camshaft position (CMP) sensor electrical connector.
4. Remove the CMP sensor bolt.
5. Remove the CMP sensor.

1. Install the CMP sensor.
2. Install the CMP sensor bolt and tighten to 10 N.m (89 lb in).
3. Connect the CMP sensor electrical connector.
4. Install the front compartment sight shields as necessary.

1. Turn the ignition OFF.
2. Remove the front compartment sight shields as necessary.
3. Disconnect the camshaft position (CMP) actuator valve electrical connector.
4. Remove the CMP actuator valve bolt.
5. Remove the CMP actuator valve.
6. Inspect the CMP actuator valve seal for damage. Replace the seal if necessary.

1. Inspect the CMP actuator valve seal for damage. Replace the seal if necessary.
2. Install the CMP actuator valve.
3. Install the CMP actuator valve bolt and tighten to 10 N.m (89 lb in).
4. Connect the CMP actuator valve electrical connector.
5. Install the front compartment sight shields as necessary.

1. Turn the ignition OFF.
2. Remove the front compartment sight shields as necessary.
3. Disconnect the camshaft position (CMP) actuator valve electrical connector.
4. Remove the CMP actuator valve bolt.
5. Remove the CMP actuator valve.
6. Inspect the CMP actuator valve seal for damage. Replace the seal if necessary.

1. Inspect the CMP actuator valve seal for damage. Replace the seal if necessary.
2. Install the CMP actuator valve.
3. Install the CMP actuator valve bolt and tighten to 10 N.m (89 lb in).
4. Connect the CMP valve electrical connector.
5. Install the front compartment sight shields as necessary.

1. Turn the ignition OFF.
2. Remove the power steering fluid reservoir bolts and reposition the power steering fluid reservoir in order to provide access. Refer to «Power Steering Fluid Reservoir Replacement (V6)»(/chevrolet/camaro/v-2009-2013/remont/manual-power-steering/#power-steering-system) .
3. Remove the camshaft position (CMP) actuator valve electrical connector.
4. Remove the CMP actuator valve bolt.
5. Remove the CMP actuator valve.
6. Inspect the CMP actuator valve seal for damage and replace as necessary.

1. Inspect the CMP actuator valve seal for damage. Replace the seal if necessary.
2. Install the CMP actuator valve.
3. Install the CMP actuator valve bolt and tighten to 10 N.m (89 lb in).
4. Install the CMP actuator valve electrical connector.
5. Install the power steering fluid reservoir. Refer to «Power Steering Fluid Reservoir Replacement (V6)»(/chevrolet/camaro/v-2009-2013/remont/manual-power-steering/#power-steering-system) .

1. Turn the ignition OFF.
2. Remove the power steering fluid reservoir bolts and reposition the power steering fluid reservoir in order to provide access. Refer to «Power Steering Fluid Reservoir Replacement (V6)»(/chevrolet/camaro/v-2009-2013/remont/manual-power-steering/#power-steering-system) .
3. Remove the camshaft position (CMP) actuator valve electrical connector.
4. Remove the CMP actuator valve bolt.
5. Remove the CMP actuator valve.
6. Inspect the CMP actuator valve seal for damage and replace as necessary.

1. Inspect the CMP actuator valve seal for damage. Replace the seal if necessary.
2. Install the CMP actuator valve.
3. Install the CMP actuator valve bolt and tighten to 10 N.m (89 lb in).
4. Install the CMP actuator valve electrical connector.
5. Install the power steering fluid reservoir. Refer to «Power Steering Fluid Reservoir Replacement (V6)»(/chevrolet/camaro/v-2009-2013/remont/manual-power-steering/#power-steering-system) .

1. Turn the ignition OFF.
2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/camaro/v-2009-2013/remont/ignition-switchsteering-lock/#general-information) .
3. Reposition the wiring harness heat shield to obtain access.
4. Remove the knock sensor (KS) electrical connector.
5. Remove the KS bolt.
6. Remove the KS.

1. Install the KS.
2. Install the KS bolt and tighten to 23 N.m (17 lb ft).
3. Install the KS electrical connector.
4. Install the wiring harness heat shield to the original position.
5. Lower the vehicle.

1. Turn the ignition OFF.
2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/chevrolet/camaro/v-2009-2013/remont/ignition-switchsteering-lock/#general-information) .
3. Remove the wiring harness heat shield from the oil level indicator tube to gain access.
4. Remove the knock sensor (KS) electrical connector.
5. Remove the KS bolt.
6. Remove the KS.

1. Install the KS.
2. Install the KS bolt and tighten to 23 N.m (17 lb ft).
3. Install the KS electrical connector.
4. Install the wiring harness heat shield to the oil level indicator tube.
5. Lower the vehicle.

Scheme 12

Scheme 13

Scheme 14

Scheme 15

See also:
• Battery Negative Cable Disconnection and Connection
• Safety Glasses Warning
• Control Module References
• Cooling System Draining and Filling (LS3, L99 Static Fill)
• Fastener Caution
• Intake Manifold Cover Replacement - Front
• Lifting and Jacking the Vehicle
• Oxygen Sensor Caution
• Component Fastener Tightening Caution
• Disengaging Connectors Caution
• Special Tools
• Gasoline/Gasoline Vapors Warning
• Fuel and Evaporative Emission Hose/Pipe Connection Cleaning Caution
• Relieving Fuel Pressure Warning
• Fuel Pipe Fitting Warning
• Tire and Wheel Removal and Installation
• Exhaust Muffler with Resonator, Exhaust, and Tail Pipe Replacement (Vehicle Service)
• Two-Piece Propeller Shaft Replacement
• Parking Brake Rear Cable Replacement
• Rear Suspension Support Replacement
• Quarter Trim Panel Replacement
• Windshield Wiper Motor Replacement
• Safety Glasses and Compressed Air Warning
• Ignition System Specifications
• Power Steering Fluid Reservoir Replacement (V6)
• Mass Airflow Sensor with Intake Air Temperature Sensor Replacement
• Air Cleaner Outlet Duct Replacement
• Fuel Pressure Relief
• Fuel Tank Draining
