Engine Mechanical - 6.2l - Component Locator Chevrolet Camaro V

Mechanical 11 illustrations

Scheme 85

Scheme 85: Disassembled Views (6.2L LS3)

Scheme 85: Disassembled Views (6.2L LS3)

Callout	Component Name
1	Evaporative Emission (EVAP) Canister Purge Tube
2	EVAP Canister Purge Solenoid Valve
3	EVAP Tube Clip
4	EVAP Canister Purge Tube
5	EVAP Purge Valve Bracket
6	Bolt
7	Bolt
8	Fuel Rail Ground Strap
9	Fuel Rail with Injectors
10	Bolt
11	Fuel Injection Fuel Rail Stop Bracket
12	Intake Manifold
13	Seal
14	Intake Manifold Gasket
15	Engine Coolant Air Bleed Plug
16	Oil Pressure Sensor
17	Washer
18	Bolt
19	Valley Cover
20	Valley Cover Gasket
21	Engine Block
22	Seal
23	Positive Crankcase Ventilation (PCV) Hose - Dirty Air
24	Seal
25	Engine Coolant Air Bleed Pipe
26	Bolt
27	Bolt
28	Throttle Body
29	Throttle Body Gasket
30	Seal
31	Manifold Absolute Pressure (MAP) Sensor
32	MAP Sensor Bolt

Scheme 86

Scheme 86

Scheme 86

Callout	Component Name
100	Engine Block
209	Valve Lifter
210	Valve Lifter Guide
211	Bolt
212	Pushrod
213	Valve Rocker Arm
214	Bolt
215	Valve Rocker Arm Pivot Support
216	Core Hole Plug
217	Cylinder Head Gasket
218	Cylinder Head
220	Cylinder Head Bolt - M11
221	Cylinder Head Bolt - M8
222	Valve Stem Oil Seal
223	Valve Spring
224	Valve Spring Cap
225	Valve Stem Key
226	Core Hole Plug
227	Intake Valve
228	Exhaust Valve
229	Cylinder Head Plug
230	Cylinder Head Locating Pin
422	O-ring
423	Oil Fill Tube
424	Oil Fill Cap
450	O-ring
504	Valve Rocker Arm Cover Gasket
504	Valve Rocker Arm Cover Gasket
505	Valve Rocker Arm Cover
505	Valve Rocker Arm Cover
515	Bolt Grommet
516	Bolt
558	Plug
600	Exhaust Manifold
601	Exhaust Manifold Gasket
602	Bolt
603	Exhaust Manifold Heat Shield
604	Bolt
605	Stud
700	Positive Crankcase Ventilation (PCV) Hose - Fresh Air
719	Ignition Coil Bracket
720	Stud
721	Ignition Coil Wire Harness Assembly
722	Ignition Coil
723	Bolt
724	Spark Plug Wire
725	Coolant Temperature Sensor (CTS)
726	Spark Plug

Scheme 87

Scheme 87

Scheme 87

Callout	Component Name
1	Bolt
2	Water Inlet Housing
3	O-ring
4	Thermostat
5	Bolt
6	Water Pump
7	Water Pump Gasket
8	Oil Level Indicator
9	O-ring
10	Bolt
11	Oil Level Indicator Tube
12	O-ring
13	Engine Block
14	Camshaft Bearings
15	Camshaft
16	Camshaft Sprocket Locating Pin
17	Crankshaft Sprocket
18	Crankshaft Balancer Washer
19	Camshaft Retainer
20	Bolt
21	Camshaft Sprocket
22	Bolt
23	Timing Chain
24	Timing Chain Tensioner
25	Bolt
26	Engine Front Cover Gasket
27	Engine Front Cover
28	Bolt
29	Crankshaft Front Oil Seal
30	Crankshaft Balancer
31	Bolt
32	Bolt
33	Camshaft Position (CMP) Sensor
34	O-ring
35	Bolt
36	CMP Sensor Wire Harness
37	Bolt
38	Oil Pump
39	Bolt
40	Oil Pump Housing Cover
41	Oil Pump Drive Gear
42	Oil Pump Driven Gear
43	Oil Pump Housing Plug
44	Oil Pump Pressure Relief Valve Spring
45	Oil Pump Pressure Relief Valve

Scheme 88

Scheme 88

Scheme 88

Callout	Component Name
1	Engine Block
2	Crankshaft Rear Oil Seal Housing Gasket
3	Crankshaft Rear Oil Seal Housing
4	Crankshaft Rear Oil Seal Housing Bolt
5	Crankshaft Rear Oil Seal
6	Flex Plate - Automatic Transmission (L99)
7	Flex Plate Bolt - Automatic Transmission (L99)
8	Clutch Pressure Plate Bolt - Manual Transmission (LS3)
9	Clutch Pressure Plate - Manual Transmission (LS3)
10	Clutch Driven Plate - Manual Transmission (LS3)
11	Clutch Pressure Plate Locating Pin - Manual Transmission (LS3)
12	Flywheel - Manual Transmission (LS3)
13	Transmission Pilot Bearing - Manual Transmission (LS3)

Scheme 89

Scheme 89

Scheme 89

Callout	Component Name
1	Engine Block
2	Piston Pin
3	Piston Pin Retainer
4	Piston Rings
5	Piston
6	Connecting Rod
7	Connecting Rod Bearings
8	Connecting Rod Cap
9	Connecting Rod Bolt
10	Crankshaft Main Bearing
10	Crankshaft Main Bearing
11	Crankshaft Thrust Bearing
11	Crankshaft Thrust Bearing
12	Crankshaft Sprocket Key
13	Crankshaft
14	Transmission Pilot Bearing - Manual Transmission
15	Crankshaft Bearing Cap
16	Crankshaft Bearing Cap Bolt - M8
17	Crankshaft Bearing Cap Stud - M10
18	Crankshaft Bearing Cap Bolt - M10
19	Crankshaft Oil Deflector
20	Oil Pan Gasket
21	Crankshaft Oil Deflector Nut
22	Oil Pump Screen
23	Oil Pump Screen Nut
24	Oil Pump Screen O-ring
25	Oil Pump Screen Bolt
26	Engine Closeout Cover Bolt
27	Engine Closeout Cover - Right
28	Oil Pan Baffle Bolt
29	Oil Pan Baffle
30	Oil Level Sensor
31	Oil Level Sensor O-ring
32	Oil Pan
33	Oil Pan Bolt - M8
34	Oil Pan Drain Plug O-ring Seal
35	Oil Pan Drain Plug
36	Oil Filter
37	Oil Filter Fitting
38	Oil Pan Bolt - M6
39	Washer
40	Active Fuel Management Oil Pressure Relief Valve
41	Engine Oil Cooler Coolant Fitting
42	Engine Oil Cooler-to-Oil Pan Bolt - M8
43	Engine Oil Cooler Core
44	Engine Oil Cooler Core-to-Housing Bolt
45	Engine Oil Cooler Housing
46	Engine Oil Cooler Gasket
47	Engine Oil Cooler-to-Oil Pan Bolt - M6
48	Engine Oil Cooler Core Seal
49	Oil Pan Cover - Left
50	Oil Pan Cover Bolt

Scheme 90

Scheme 90

Scheme 90

Callout	Component Name
100	Engine Block
100	Engine Block
101	Oil Gallery Plug - Front
110	O-Ring
111	Oil Gallery Plug - Rear
112	Oil Gallery Plug - Side
113	Washer
114	Engine Coolant Heater
115	Washer
116	Oil Gallery Plug - Side
117	Washer
130	Transmission Housing Locating Pin
145	Washer
146	Engine Block Coolant Drain Hole Plug
701	Crankshaft Position (CKP) Sensor
702	O-Ring
718	Knock Sensor
718	Knock Sensor
739	Bolt
739	Bolt
750	CKP Sensor Bolt

Scheme 91

Scheme 91

Scheme 91

Callout	Component Name
408	Bolt
409	Oil Pump Housing Cover
410	Oil Pump Drive Gear
412	Oil Pump Driven Gear
413	Oil Pump
414	Oil Pump Pressure Relief Valve
415	Oil Pump Pressure Relief Valve Spring
416	Oil Pump Housing Plug

Scheme 92

Scheme 92: Disassembled Views (6.2L L99)

Scheme 92: Disassembled Views (6.2L L99)

Callout	Component Name
1	Positive Crankcase Ventilation (PCV) Tube - Dirty Air
2	Evaporative Emission (EVAP) Canister Purge Tube
3	EVAP Canister Purge Solenoid Valve
4	EVAP Canister Purge Tube
5	EVAP Purge Valve Bracket
6	Bolt
7	Fuel Rail Ground Strap
8	Bolt
9	Fuel Rail with Injectors
10	Manifold Absolute Pressure (MAP) Sensor Bolt
11	Manifold Absolute Pressure (MAP) Sensor
12	Seal
13	Bolt
14	Throttle Body
15	Throttle Body Gasket
16	Intake Manifold
17	Bolt
18	Fuel Injection Fuel Rail Stop Bracket
19	Seal
20	Intake Manifold Gasket
21	Engine Coolant Air Bleed Plug
22	Oil Pressure Sensor
23	Washer
24	Bolt
25	Filter
26	O-ring
27	Valve Lifter Oil Manifold
28	Valve Lifter Oil Manifold Gasket
29	Engine Block
30	Seal
31	Engine Coolant Air Bleed Pipe
32	Bolt

Scheme 93

Scheme 93

Scheme 93

Callout	Component Name
1	Positive Crankcase Ventilation (PCV) Hose - Fresh Air
2	Oil Fill Cap
3	O-ring
4	Oil Fill Tube
5	O-ring
6	Valve Rocker Arm Cover
6	Valve Rocker Arm Cover
7	Valve Rocker Arm Cover Gasket
7	Valve Rocker Arm Cover Gasket
8	Ignition Coil Wire Harness Assembly
9	Bolt
10	Spark Plug Wire
11	Ignition Coil
12	Bolt
13	Ignition Coil Bracket
14	Bolt
15	Bolt Grommet
16	Valve Stem Key
17	Valve Spring Cap
18	Valve Spring
19	Valve Stem Oil Seal
20	Core Hole Plug
21	Spark Plug
22	Cylinder Head Bolt - M11
23	Cylinder Head Bolt - M8
24	Cylinder Head
25	Cylinder Head Gasket
26	Core Hole Plug
27	Cylinder Head Locating Pin
28	Cylinder Head Plug
29	Coolant Temperature Sensor (CTS)
30	Exhaust Valve
31	Intake Valve
32	Exhaust Manifold Gasket
33	Exhaust Manifold
34	Exhaust Manifold Heat Shield
35	Bolt
36	Stud
37	Bolt
38	Engine Block
39	Valve Lifter - Active Fuel Management
40	Valve Lifter - Non-Active Fuel Management
41	Valve Lifter Guide
42	Bolt
43	Pushrod
44	Valve Rocker Arm Pivot Support
45	Valve Rocker Arm
46	Bolt

Scheme 94

Scheme 94

Scheme 94

Callout	Component Name
1	Water Pump Inlet Bolt
2	Water Pump Inlet
3	Engine Coolant Thermostat
4	Water Pump Bolt
5	Water Pump
6	Water Pump Gasket
7	Oil Level Indicator O-ring Seal
8	Oil Level Indicator
9	Oil Level Indicator Tube Bolt
10	Oil Level Indicator Tube
11	O-ring
12	Engine Block
13	Camshaft Bearing
14	Camshaft
15	Camshaft Sprocket Locating Pin
16	Camshaft Retainer
17	Camshaft Retainer Bolt
18	CMP Actuator
19	Camshaft Position (CMP) Actuator Solenoid Valve
20	Crankshaft Sprocket
21	Crankshaft Balancer Washer
22	Timing Chain
23	Timing Chain Tensioner
24	Timing Chain Tensioner Bolt
25	Engine Front Cover Gasket
26	Engine Front Cover
27	Engine Front Cover Bolt
28	CMP Actuator Magnet Gasket
29	CMP Actuator Magnet
30	CMP Actuator Hub Cover Bolt
31	CMP Sensor Bolt
32	CMP Sensor O-ring Seal
33	CMP Sensor
34	CMP Sensor Wire Harness Assembly
35	CMP Sensor Wire Harness Assembly Bolt
36	Crankshaft Front Oil Seal
37	Crankshaft Balancer
38	Crankshaft Balancer Bolt
39	Oil Pump Bolt
40	Oil Pump Cover Bolt
41	Oil Pump Cover
42	Oil Pump Drive Gear
43	Oil Pump Driven Gear
44	Oil Pump
45	Oil Pressure Relief Valve
46	Oil Pressure Relief Valve Spring
47	Oil Pressure Relief Valve Bore Plug

Callout	Component Name
1	Engine Block
2	Crankshaft Rear Oil Seal Housing Gasket
3	Crankshaft Rear Oil Seal Housing
4	Crankshaft Rear Oil Seal Housing Bolt
5	Crankshaft Rear Oil Seal
6	Flex Plate - Automatic Transmission (L99)
7	Flex Plate Bolt - Automatic Transmission (L99)
8	Clutch Pressure Plate Bolt - Manual Transmission (LS3)
9	Clutch Pressure Plate - Manual Transmission (LS3)
10	Clutch Driven Plate - Manual Transmission (LS3)
11	Clutch Pressure Plate Locating Pin - Manual Transmission (LS3)
12	Flywheel - Manual Transmission (LS3)
13	Transmission Pilot Bearing - Manual Transmission (LS3)

Callout	Component Name
1	Engine Block
2	Piston Pin
3	Piston Pin Retainer
4	Piston Rings
5	Piston
6	Connecting Rod
7	Connecting Rod Bearings
8	Connecting Rod Cap
9	Connecting Rod Bolt
10	Crankshaft Main Bearing
10	Crankshaft Main Bearing
11	Crankshaft Thrust Bearing
11	Crankshaft Thrust Bearing
12	Crankshaft Sprocket Key
13	Crankshaft
14	Transmission Pilot Bearing - Manual Transmission
15	Crankshaft Bearing Cap
16	Crankshaft Bearing Cap Bolt - M8
17	Crankshaft Bearing Cap Stud - M10
18	Crankshaft Bearing Cap Bolt - M10
19	Crankshaft Oil Deflector
20	Oil Pan Gasket
21	Crankshaft Oil Deflector Nut
22	Oil Pump Screen
23	Oil Pump Screen Nut
24	Oil Pump Screen O-ring
25	Oil Pump Screen Bolt
26	Engine Closeout Cover Bolt
27	Engine Closeout Cover - Right
28	Oil Pan Baffle Bolt
29	Oil Pan Baffle
30	Oil Level Sensor
31	Oil Level Sensor O-ring
32	Oil Pan
33	Oil Pan Bolt - M8
34	Oil Pan Drain Plug O-ring Seal
35	Oil Pan Drain Plug
36	Oil Filter
37	Oil Filter Fitting
38	Oil Pan Bolt - M6
39	Washer
40	Active Fuel Management Oil Pressure Relief Valve
41	Engine Oil Cooler Coolant Fitting
42	Engine Oil Cooler-to-Oil Pan Bolt - M8
43	Engine Oil Cooler Core
44	Engine Oil Cooler Core-to-Housing Bolt
45	Engine Oil Cooler Housing
46	Engine Oil Cooler Gasket
47	Engine Oil Cooler-to-Oil Pan Bolt - M6
48	Engine Oil Cooler Core Seal
49	Oil Pan Cover - Left
50	Oil Pan Cover Bolt

Callout	Component Name
100	Engine Block
100	Engine Block
101	Oil Gallery Plug - Front
110	O-Ring
111	Oil Gallery Plug - Rear
112	Oil Gallery Plug - Side
113	Washer
114	Engine Coolant Heater
115	Washer
116	Oil Gallery Plug - Side
117	Washer
130	Transmission Housing Locating Pin
145	Washer
146	Engine Block Coolant Drain Hole Plug
701	Crankshaft Position (CKP) Sensor
702	O-Ring
718	Knock Sensor
718	Knock Sensor
739	Bolt
739	Bolt
750	CKP Sensor Bolt

Callout	Component Name
408	Bolt
409	Oil Pump Housing Cover
410	Oil Pump Drive Gear
412	Oil Pump Driven Gear
413	Oil Pump
414	Oil Pump Pressure Relief Valve
415	Oil Pump Pressure Relief Valve Spring
416	Oil Pump Housing Plug

Scheme 95

Scheme 95: Engine Identification

Scheme 95: Engine Identification

The vehicle identification number (VIN) (1) is located on the left side rear of the engine block and is typically a 9 digit number stamped or laser-etched onto the engine at the vehicle assembly plant.

The first digit identifies the division.
The second digit identifies the model year.
The third digit identifies the assembly plant.
The fourth through ninth digits are the last 6 digits of the VIN.
