Engine Mechanical - 3.6l - Special Tools and Equipment Chevrolet Camaro V

Illustration Tool Number/Description EN 46101 Spark Plug Tube Seal Guide EN 46103 Camshaft Actuator Valve Seal Installer EN 46104 Water Pump Pulley Holding Tool EN 46105 Camshaft Locking Tool EN 46106 Flywheel Holding Tool EN 46108 Timing Chain Retention Tool EN 46109 Guide Pins EN 46110 On-Vehicle Valve Spring Compressor EN 46111 Crankshaft Rotation Socket EN 46112 Tensioner Retraction Pins EN 46114 Engine Lift Brackets EN 46116 Valve Stem Seal Remover/Installer EN 46117 Valve Stem Key Remover/Installer EN 46119 Off-Vehicle Valve Spring Compressor Adapter EN 46121 Connecting Rod Guide Pin Set EN 46122 Camshaft Position Actuator Check-Ball Valve Remover/Installer EN 46745 Piston Pin Clip Remover/Installer EN 47839 Crankshaft Rear Oil Seal Installation Tool EN 47971 Oil Pressure Gauge Adapter EN 48018 Flywheel Holding Tool EN 48313 Timing Chain Retention Tool EN 48383 Camshaft Retaining Tool EN 48589 Crankshaft Rotation Socket EN 48896 HP Fuel Pump Installation Alignment Gauge EN 49882 Timing Chain Retainer J 5590 Bearing and Seal Driver J 6125-1B Slide Hammer Adapter J 7872 Magnetic Base Dial Indicator J 8001 Dial Indicator Set J 8037 Ring Compressor J 8062 Valve Spring Compressor - Head Off J 8087 Cylinder Bore Gauge J 8358 Carbon Removal Brush J 21867 Pressure Gauge J 21867-6 Oil Pressure Adapter Fitting J 22738-B Valve Spring Tester J 24254 Oil Seal Installer J 24420-C Harmonic Balancer Puller J 25033-C Pulley Installer J 25034-C Pulley Remover J 28410 Gasket Remover J 28428-E High Intensity Black Light Kit J 28467-B Universal Engine Support Fixture J 28467-501 Engine Support Fixture Adapters J 29184 Oil Seal Installer J 35667-A Cylinder Head Leakdown Tester J 36857 Engine Lift Bracket J 38416-2 Crankshaft Button J 39313 Spark Plug Port Adapter J 41818 Crankshaft Bearing Cap Remover J 41998-B Crankshaft Balancer Installer J 42096 Valve Guide Reamer J 42183 Handle J 42385-700 High Feature Thread Repair Kit J 42385-2000 Thread Insert Kit J 42640 Steering Column Anti-Rotation Pin J 43690 Rod Bearing Clearance Checking Tool J 43690-100 Rod Bearing Clearance Checking Tool - Adapter Kit J 43965 Thread Repair Extension Kit J 45000 Seal Remover J 45027 Tensioner Tool J 45059 Angle Meter J 45299 Engine Preluber

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142
