Scheme 66
Scheme 66: Disassembled Views
| Callout | Component Name |
|---|
| 1 | Right Exhaust Manifold Heat Shield Bolt |
| 2 | Right Exhaust Manifold Heat Shield |
| 3 | Right Camshaft Cover Assembly |
| 4 | Ignition Coil Bolt |
| 5 | Ignition Coil |
| 6 | Spark Plug |
| 7 | Fuel Injector Sight Shield Cover |
| 8 | Upper Intake Manifold Cover |
| 9 | Intake Manifold Assembly |
| 10 | Left Camshaft Cover Assembly |
| 11 | Engine Flywheel Bolt |
| 12 | Engine Flywheel |
| 13 | Left Exhaust Manifold Upper Heat Shield |
| 14 | Left Exhaust Manifold Lower Heat Shield |
| 15 | Engine Assembly |
| 16 | Left Exhaust Manifold Heat Shield Bolt |
| 17 | Left Exhaust Manifold Heat Shield |
| 18 | Cylinder Head Exhaust Manifold Bolt |
| 19 | Left Exhaust Manifold |
| 20 | Left Exhaust Manifold Gasket |
| 21 | Oil Pan Assembly |
| 22 | Crankshaft Balancer Bolt |
| 23 | Crankshaft Balancer |
| 24 | Engine Front Cover Assembly |
| 25 | Exhaust Manifold Lower Heat Shield |
| 26 | Exhaust Manifold Lower Heat Shield Bolt |
| 27 | Right Exhaust Manifold Lower Heat Shield |
| 28 | Right Exhaust Manifold Lower Heat Shield Retainers |
| 29 | Right Exhaust Manifold |
| 30 | Right Exhaust Manifold Gasket |
Scheme 67
| Callout | Component Name |
|---|
| 1 | Right Cylinder Head Gasket |
| 2 | Right Cylinder Head Assembly |
| 3 | Coolant Pipe Bracket Bolt - Small |
| 4 | Coolant Pipe Clamp |
| 5 | Coolant Pipe |
| 6 | Water Inlet/Outlet Pipe Bolts |
| 7 | Water Inlet/Outlet Pipe |
| 8 | Water Inlet/Outlet Pipe Gaskets |
| 9 | Water Inlet/Outlet Pipe O-ring |
| 10 | Coolant Pipe Bracket Bolt - Large |
| 11 | Coolant Pipe O-ring |
| 12 | Engine Cooling Thermostat Housing Bolt |
| 13 | Engine Cooling Thermostat Housing |
| 14 | Engine Cooling Thermostat |
| 15 | Engine Cooling Thermostat Seal |
| 16 | Engine Cooling Thermostat Lower Housing Bolt |
| 17 | Engine Cooling Thermostat Lower Housing |
| 18 | Engine Cooling Thermostat Lower Housing Seal |
| 19 | Engine Cooling Thermostat Gasket |
| 20 | Left Cylinder Head Assembly |
| 21 | Left Cylinder Head Gasket |
| 22 | Oil Level Indicator Tube Bolt |
| 23 | Oil Level Indicator |
| 24 | Oil Level Indicator Handle O-ring |
| 25 | Oil Level Indicator Tube O-ring |
| 26 | Oil Level Indicator Tube |
| 27 | Knock Sensor Bolt |
| 28 | Knock Sensor |
| 29 | Oil Filter Adapter Assembly |
| 30 | Engine Short Block Assembly |
| 31 | Oil Pump Assembly |
| 32 | Timing Drive Assembly |
| 33 | Water Outlet Bolt |
| 34 | Water Outlet |
| 35 | Water Outlet O-ring |
| 36 | Water Outlet Seal |
| 37 | Crankshaft Position Sensor Bolt |
| 38 | Crankshaft Position Sensor |
| 39 | Crankshaft Position Sensor O-ring |
Scheme 68
| Callout | Component Name |
|---|
| 250 | Left Camshaft Cover |
| 251 | Left Camshaft Cover Gasket |
| 252 | Right Camshaft Cover |
| 253 | Right Camshaft Cover Gasket |
| 254 | Camshaft Cover Spark Plug Port Seal |
| 254 | Camshaft Cover Spark Plug Port Seal |
| 255 | Camshaft Cover Bolt |
| 255 | Camshaft Cover Bolt |
| 256 | Camshaft Cover Bolt Insulator |
| 256 | Camshaft Cover Bolt Insulator |
| 257 | Ignition Coil Bolt Thread Insert |
| 258 | Oil Fill Cap |
| 259 | Oil Fill O-ring |
| 259 | Oil Fill O-ring |
| 260 | Left Camshaft Cover PCV Fitting |
| 261 | Right Camshaft Cover PCV Fitting Orifice |
| 262 | Oil Fill Tube |
| 263 | Left Camshaft Cover PCV Fitting O-ring |
| 265 | Left Camshaft Housing Cover Insulator |
| 266 | Right Camshaft Housing Cover Insulator |
| 704 | Ignition Coil |
| 704 | Ignition Coil |
| 705 | Ignition Coil Bolt |
| 705 | Ignition Coil Bolt |
| 719 | Spark Plug |
| 719 | Spark Plug |
Scheme 69
| Callout | Component Name |
|---|
| 1 | Primary Timing Chain Tensioner Bolt |
| 2 | Left Secondary Timing Chain Shoe Bolt |
| 3 | Right Secondary Timing Chain Tensioner |
| 4 | Right Secondary Timing Chain Tensioner Gasket |
| 5 | Right Secondary Timing Chain Shoe |
| 6 | Secondary Timing Chain |
| 7 | Camshaft Position Actuator Bolt |
| 8 | Exhaust Camshaft Position Actuator |
| 9 | Camshaft Position Actuator Thrust Washer |
| 10 | Intake Camshaft Position Actuator |
| 11 | Right Secondary Timing Chain Guide |
| 12 | Left Camshaft Intermediate Drive Shaft Sprocket |
| 13 | Camshaft Intermediate Drive Shaft Sprocket Bolt |
| 14 | Left Secondary Timing Chain Shoe |
| 15 | Left Secondary Timing Chain Tensioner Gasket |
| 16 | Left Secondary Timing Chain Tensioner |
| 17 | Left Secondary Timing Chain Guide |
| 18 | Lower Primary Timing Chain Guide |
| 19 | Lower Primary Timing Chain Guide Bolt |
| 20 | Crankshaft Sprocket |
| 21 | Primary Timing Chain |
| 22 | Right Camshaft Intermediate Drive Shaft Sprocket |
| 23 | Upper Primary Timing Chain Guide |
| 24 | Primary Timing Chain Tensioner Gasket |
| 25 | Primary Timing Chain Tensioner |
Scheme 70
| Callout | Component Name |
|---|
| 282 | PCV Hose Bolt |
| 282 | PCV Hose Bolt |
| 283 | Dirty PCV Hose |
| 285 | PCV Hose O-ring Outer/Larger |
| 286 | PCV Hose O-ring Inner/Smaller |
| 290 | PCV Hose Right Bracket |
| 291 | PCV Hose Left Bracket |
| 292 | PCV Hose Clip |
| 503 | Upper Intake Manifold |
| 509 | Upper Intake Manifold Bolt - Long |
| 510 | Upper Intake Manifold Bolt - Short |
| 514 | Intake Manifold Brace |
| 515 | Intake Manifold Brace Small Bolt |
| 516 | Intake Manifold Brace Large Bolt |
| 524 | Intake Manifold Cover |
| 525 | Intake Manifold Cover Gasket |
| 526 | Intake Manifold Cover Lower Gasket |
| 527 | Intake Manifold Cover Bolt |
| 532 | Fuel Rail Bolt |
| 560 | Fuel Rail |
| 561 | Fuel Injector |
| 562 | Fuel Injector Retainer |
| 563 | Fuel Injector O-ring Seal |
| 564 | Fuel Injector Teflon Seal |
| 565 | Fuel Pressure Sensor |
| 566 | Fuel Injector Spacer |
| 567 | Fuel Injector Isolator Cup |
| 568 | Fuel Injector Isolator Cup Retaining Ring |
| 594 | Fuel Injector Sight Shield Cover Ball Stud |
| 700 | Fuel Injector Wiring Harness |
| 701 | Throttle Body |
| 702 | Throttle Body Bolt |
| 703 | Throttle Body Gasket |
| 744 | EVAP Purge Solenoid |
| 746 | EVAP Purge Solenoid Bolt |
| 747 | EVAP Purge Solenoid Tube |
| 752 | EVAP Purge Solenoid Bracket |
| 755 | Intake Manifold Tuning Valve |
| 756 | Intake Manifold Tuning Valve O-ring |
| 757 | Intake Manifold Tuning Valve Bolt |
| 765 | Fuel Injector Wiring Harness Bracket |
| 766 | Fuel Injector Wiring Harness Bracket Bolt |
| 776 | BARO Sensor Bolt |
| 777 | BARO Sensor |
| 778 | BARO Sensor O-ring |
Scheme 71
| Callout | Component Name |
|---|
| 1 | Fuel Pressure Sensor |
| 2 | Fuel Rail Bolt |
| 3 | Fuel Injector Retainer |
| 4 | Fuel Injector O-ring Seal |
| 5 | Fuel Injector Spacer |
| 6 | Fuel Injector |
| 7 | Fuel Injector Teflon Seal |
| 8 | Fuel Injector Isolator Cup |
| 9 | Fuel Injector Isolator Cup Retaining Ring |
| 10 | Fuel Rail |
Scheme 72
| Callout | Component Name |
|---|
| 300 | Left Cylinder Head |
| 301 | Right Cylinder Head |
| 302 | Left Cylinder Head Gasket |
| 303 | Right Cylinder Head Gasket |
| 310 | Cylinder Head Bolt |
| 311 | Cylinder Head Front Bolt |
| 313 | Cylinder Head Coolant Hole Threaded Plug |
| 318 | Spark Plug Sleeve |
| 319 | Cylinder Head Oil Gallery Expansion Plug - 14 mm |
| 319 | Cylinder Head Oil Gallery Expansion Plug - 14 mm |
| 320 | Exhaust Valve |
| 321 | Intake Valve |
| 322 | Valve Rocker Arm Assembly |
| 323 | Hydraulic Valve Lash Adjuster Assembly |
| 324 | Valve Stem Oil Seal |
| 325 | Valve Spring |
| 326 | Valve Spring Cap |
| 327 | Valve Stem Key |
| 328 | Cylinder Head Camshaft Front Thrust Bearing Cap |
| 328 | Cylinder Head Camshaft Front Thrust Bearing Cap |
| 329 | Camshaft Oil Seal Ring |
| 330 | Left Exhaust Camshaft |
| 331 | Left Intake Camshaft |
| 332 | Right Intake Camshaft |
| 333 | Right Exhaust Camshaft |
| 336 | Cylinder Head Camshaft Cap - Intermediate |
| 337 | Cylinder Head Camshaft Cap Bolt |
| 339 | Cylinder Head Oil Gallery Check Valve |
| 711 | Engine Coolant Temperature Sensor |
Scheme 73
| Callout | Component Name |
|---|
| 1 | Water Pump Pulley Bolt |
| 2 | Water Pump Pulley |
| 3 | Water Pump Assembly |
| 4 | Water Pump Pulley Gasket |
| 5 | Camshaft Position Actuator Solenoid Valve Seal |
| 6 | Camshaft Position Sensor Bolt |
| 7 | Camshaft Position Sensor |
| 8 | Camshaft Position Sensor O-ring Seal |
| 9 | Camshaft Position Actuator Solenoid Valve Bolt |
| 10 | Camshaft Position Actuator Solenoid Valve |
| 11 | Engine Front Cover Gasket |
| 12 | Engine Front Cover Locating Pin |
| 13 | Engine Front Cover |
| 14 | Engine Front Cover Bolt |
| 15 | Engine Front Cover Seal |
| 16 | Crankshaft Balancer |
| 17 | Crankshaft Balancer Bolt |
| 18 | Engine Front Cover Bolt |
| 19 | Water Pump Bolt |
Scheme 74
| Callout | Component Name |
|---|
| 151 | Lower Primary Timing Chain Guide |
| 154 | Lower Primary Timing Chain Guide Bolt |
| 463 | Oil Pump Housing |
| 464 | Oil Pump Cover |
| 465 | Oil Pump Driven Gear |
| 466 | Oil Pump Drive Gear |
| 468 | Oil Pump Cover Bolt |
| 470 | Oil Pressure Relief Valve Bore Plug |
| 471 | Oil Pressure Relief Valve Spring |
| 472 | Oil Pressure Relief Valve |
| 474 | Oil Pressure Relief Valve Bore Plug Retainer Clip |
| 475 | Oil Pump Bolt |
Scheme 75
| Callout | Component Name |
|---|
| 1 | Crankshaft |
| 2 | Crankshaft Key |
| 3 | Crankshaft Lower Bearing |
| 4 | Crankshaft Bearing Cap |
| 5 | Crankshaft Bearing Cap Outboard Bolt |
| 6 | Crankshaft Bearing Cap Inboard Bolt |
| 7 | Crankshaft Bearing Thrust Cap |
| 8 | Piston Oil Nozzle Bolt |
| 9 | Piston Oil Nozzle |
| 10 | Oil Pan Locating Pin |
| 11 | Crankshaft Bearing Cap Side Bolt - Long |
| 12 | Engine Block Oil Gallery Threaded Plug - 14 mm |
| 13 | Crankshaft Rear Oil Seal Housing Assembly |
| 14 | Crankshaft Rear Oil Seal Housing Assembly Bolt |
| 15 | Transaxle Locating Pin |
| 16 | Piston and Connecting Rod Assembly |
| 17 | Engine Block Coolant Drain Threaded Plug - 14 mm |
| 18 | Engine Block Core Coolant Expansion Plug - 34.3 mm |
| 19 | Cylinder Head Locating Pin |
| 20 | Engine Block |
| 21 | Engine Block Oil Gallery Expansion Plug - 14 |
| 22 | Engine Front Cover Stud |
| 23 | Engine Block Oil Gallery Threaded Plug - 20 mm |
| 24 | Engine Block Oil Gallery Expansion Plug - 10 mm |
| 25 | Crankshaft Bearing Cap Side Bolt - Short |
| 26 | Crankshaft Upper Thrust Bearing #3 |
| 27 | Crankshaft Upper Bearing |
Scheme 76
| Callout | Component Name |
|---|
| 200 | Connecting Rod |
| 201 | Connecting Rod Bolt |
| 202 | Connecting Rod Bushing |
| 203 | Connecting Rod Bearing |
| 210 | Piston |
| 211 | Piston Pin |
| 212 | Piston Pin Retainer |
| 212 | Piston Pin Retainer |
| 213 | Piston Upper Compression Ring |
| 214 | Piston Lower Compression Ring |
| 215 | Piston Oil Control Rail Ring |
| 216 | Piston Oil Control Ring Spacer |
Scheme 77
| Callout | Component Name |
|---|
| 1 | Oil Pan Baffle Scraper Bolt |
| 2 | Oil Pan Baffle Scraper |
| 3 | Oil Pump Suction Pipe Bolt |
| 4 | Oil Pump Suction Pipe Seal |
| 5 | Oil Pump Suction Pipe |
| 6 | Oil Pan |
| 7 | Oil Pan Bolt - Long |
| 8 | Oil Pan Bolt - Medium |
| 9 | Oil Pan Bolt - Short |
| 10 | Oil Pan Drain Plug Seal |
| 11 | Oil Pan Drain Plug |
Scheme 78
| Callout | Component Name |
|---|
| 440 | Oil Filter Adapter |
| 441 | Oil Filter Adapter Gasket |
| 442 | Oil Filter Adapter Bolt |
| 443 | Oil Filter Adapter Bolt - Long |
| 446 | Oil Filter Bypass Valve |
| 447 | Oil Filter Adapter Bolt - Large |
| 448 | Oil Filter Adapter Bolt Sleeve |
| 449 | Oil Filter |
| 450 | Oil Filter Cap |
| 451 | Oil Filter Cap O-ring |
| 456 | Oil Filter Bypass Valve Body |
| 458 | Drain Valve Assembly |
| 459 | Drain Valve Assembly Seal |
| 728 | Engine Oil Pressure Sensor |
| 729 | Engine Oil Pressure Sensor O-ring |
Vehicle Identification Number
The Vehicle Identification Number (VIN) Derivative is located in two places on the engine and is a nine digit number stamped or laser etched onto the block at the vehicle assembly plant. If reading the identification number the following information can be obtained
- The first digit identifies the vehicle division.
- The second digit is the model year.
- The third digit identifies the assembly plant.
- The fourth through ninth digits are the last six digits of the Vehicle Identification Number (VIN).
Scheme 79
The engine block is marked with the VIN on a pad area on the left rear side (1).
Scheme 80
The engine block is marked with the VIN on a pad area on the center lower right side (1).
Engine Traceability Label
The engine traceability label is located in two places on the engine and consists of the broadcast code, bar code and sequence number.
Scheme 81
Scheme 81: Engine Traceability Label
One engine traceability label (1) is located on the left rear side of the engine block.
Scheme 82
Another engine traceability label (1) is located on the rear of the left cylinder head.
Engine Verification Label
The engine verification label is located in two places on the engine and consists of the broadcast code and bar code.
Scheme 83
Scheme 83: Engine Verification Label
One engine verification label (1) is located on the left side of the engine front cover below the exhaust camshaft position sensor.
Scheme 84
Another engine verification label (1) is located on the rear of the right cylinder head.
