Rear Heated Seat Temperature Adjustment Inoperative
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Rear Seat Schematics Connector End View Reference: Power Seat Systems Connector End Views DEFINITION: The heated seat cushion or seat back temperature can not be controlled or adjusted. The heated seat system can be turned ON and OFF. | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Verify that the Rear Heated Seat Temperature Adjustment Inoperative complaint is present. Does the rear heated seat system operate as described in the description and operation? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | Test the heated seat element control circuit between the rear heated seat module and the seat cushion heating element for a short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 7 | Go to Step 4 |
| 4 | Test the heated seat element control circuit between the rear heated seat module and the seat back heating element for a short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 7 | Go to Step 5 |
| 5 | Inspect for poor connections at the harness connector of the rear heated seat module. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 7 | Go to Step 6 |
| 6 | Replace the rear heated seat module. Refer to Control Module References in Computer/Integrating Systems for replacement, setup, and programming. Did you complete the replacement? | Go to Step 7 | |
| 7 | Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 2 |
Rear Heated Seat Temperature Adjustment Inoperative
Memory Seat Calibration Procedure
The memory seat module uses position sensor inputs to establish soft stop locations for the adjuster motors several millimeters ahead of the physical limits of the adjuster assembly. After replacing a memory seat module or adjuster components, it may be necessary to reset the adjuster motor soft stop locations. When the repair procedure has been completed, operate the seat adjuster switch in every direction until the seat adjuster reaches its mechanical hard stop by repeatedly pressing and releasing the switch as necessary.
Scheme 16
| Callout | Component Name |
|---|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . | |
| Preliminary Procedure: Remove the rear compartment trim. Refer to Compartment Trim Panel Replacement - Rear . | |
| 1 | Armrest Assembly, Rear Seat |
| 2 | Screw, Rear Seat Armrest Tighten: 2 N.m (18 lb in) |
