Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Brake Hose to Caliper Bolt | 50 N.m | 37 lb ft |
| Brake Master Cylinder Mounting Nuts | 25 N.m | 18 lb ft |
| Brake Pedal Assembly to Cowl Mounting Nuts | 25 N.m | 18 lb ft |
| Brake Pedal Assembly to I/P Carrier Mounting Nuts | 25 N.m | 18 lb ft |
| Brake Pipe Fitting-Tube Nut | 18 N.m | 13 lb ft |
| Brake Pipe Fittings at Master Cylinder-Tube Nut | 38 N.m | 28 lb ft |
| Front Brake Hose Mounting Bracket to Steering Knuckle Mounting Bolt | 14 N.m | 10 ft lb |
| Steering Column Support Bracket to Cowl Mounting Nuts | 25 N.m | 18 lb ft |
| Steering Column Support Bracket to I/P Carrier Mounting Nuts | 25 N.m | 18 lb ft |
Fastener Tightening Specifications
Brake Component Specifications
| Application | Specification |
|---|
| Metric | English |
| Brake Caliper Bleeder Valve | 14 N.m | 10 ft lb |
| Brake Caliper Bore Diameter - Front | 45.05 mm | 1.77 in |
| Brake Caliper Bore Diameter - Rear | 48.15 mm | 1.90 in |
Brake Component Specifications
Brake System Specifications
| Application | Specification |
|---|
| Metric | English |
| Brake Pedal Travel Maximum Specification with 445 N (100 lbs) of force applied to the pedal with the ignition OFF and the booster power reserve depleted. Must be Measured with Adjustable Brake Pedal, if equipped, in Full-Forward position. | 67.0 mm | 2.64 in |
Brake System Specifications
Scheme 7
Scheme 7: Brake Warning System Schematics
Scheme 8
Scheme 8: Hydraulic Brakes Component Views
| Callout | Component Name |
|---|
| 1 | Brake Booster |
| 2 | Brake Fluid Level Switch |
Scheme 9
| Callout | Component Name |
|---|
| 1 | Park Brake Switch |
| 2 | Brake Pedal Position Sensor |
| 3 | Accelerator Pedal Position (APP) Sensor |
| 4 | Left Front Floor Panel |
