Accessory Power Socket Cadillac SRX I

Body Electrical 4 illustrations ~665 words

Scheme 87

Scheme 87: Cigar Lighter/Auxiliary Outlets Schematics
Scheme 87: Cigar Lighter/Auxiliary Outlets Schematics

Scheme 88

Scheme 88: Power Outlet Component Views
Scheme 88: Power Outlet Component Views
CalloutComponent Name
1Turn Signal/Multifunction Switch
2Steering Wheel Controls - Left
3Instrument Panel Cluster
4Windshield Wiper/Washer Switch
5Inside Air Temperature Sensor
6Sunload/Ambient Light Sensor
7Speaker - Front Midrange (U57)
8Hazard Switch
9Radio
10CD Player
11HVAC Control Module - Climate Control - Right
12Heated Seat Switch - Passenger (KA1)
13Cigar Lighter
14Heated Seat Switch - Driver (KA1)
15HVAC Control Module - Climate Control - Left
16Steering Wheel Controls - Left
17Hood Release Lever

Scheme 89

Scheme 89
Scheme 89
CalloutComponent Name
1Video Display (U42)
2DVD Player (U42)
3Auxiliary Power Outlet - Center Console 2 (U42)
4Auxiliary Power Outlet - Center Console 1

Scheme 90

Scheme 90
Scheme 90
CalloutComponent Name
1Auxiliary Power Outlet - Rear

Power Outlet Connector End Views

Auxiliary Power Outlet - Center Console 1 Connector Part Information 12176446 3-Way F Metri-Pack 280 Series, Flexlock (BK) Pin Wire Color Circuit No. Function A RD/WH 2040 Battery Positive Voltage B - - Not Used C BK 450 Ground

Auxiliary Power Outlet - Center Console 2 (U42) Connector Part Information 12176446 3-Way F Metri-Pack 280 Series, Flexlock (BK) Pin Wire Color Circuit No. Function A RD/WH 2040 Battery Positive Voltage B - - Not Used C BK 450 Ground

Auxiliary Power Outlet - Front (w/o DT4) Connector Part Information 12047699 2-Way M Miscellaneous Connectors Series (GY) Pin Wire Color Circuit No. Function A RD/WH 3540 Battery Positive Voltage B BK 450 Ground

Auxiliary Power Outlet - Rear Connector Part Information 12176446 3-Way F Metri-Pack 280 Series, Flexlock (BK) Pin Wire Color Circuit No. Function A RD/WH 3540 Battery Positive Voltage B - - Not Used C BK 450 Ground

Cigar Lighter (DT4) Connector Part Information 12047699 2-Way M Miscellaneous Connectors Series (GY) Pin Wire Color Circuit No. Function A RD/WH 3540 Battery Positive Voltage B BK 450 Ground

Tools Required

J 42059 Cigar Lighter Socket Remover. See Special Tools .

Removal Procedure

  1. Remove the cigar lighter fuse.
  2. Remove the cigar lighter element.
  3. Remove the cigar lighter housing by placing one side of the T portion of J 42059 into the tab window and the other side into the opposite tab window. See «Special Tools»(/cadillac/srx/i-2003-2009/remont/body-electrical/#accessory-power-socket__special-tools) . Pull the lighter housing straight out.
  4. Remove the tool from the lighter housing.
  5. Pull the housing (3) and the retainer (2) out of the ash tray.
  6. Disconnect the electrical connector (1) from the housing.
  7. Remove the retainer from the housing.

Installation Procedure

  1. Install the cigar lighter retainer (1) to the ash tray, by pressing the retainer into place until fully seated.
  2. Connect the electrical connector (2) to the retainer.
  3. Align the housing (2) key way, to the key slot in the retainer ring (1).
  4. Press the housing into place until the housing is fully seated.
  5. Install the cigar lighter fuse.
  6. Install the cigar lighter element.

J 42059 Cigar Lighter Socket Remover. See Special Tools .

  1. Remove the power outlet fuse.
  2. Remove the power outlet housing by placing one side of the T portion of J 42059 into the tab window and the other side into the opposite tab window. See «Special Tools»(/cadillac/srx/i-2003-2009/remont/body-electrical/#accessory-power-socket__special-tools) . Pull the lighter housing straight out.
  3. Remove the tool from the power outlet housing.
  4. Pull the housing (3) and the retainer (2) out of the console.
  5. Disconnect the electrical connector (1) from the housing.
  6. Remove the retainer from the housing.
  1. Install the power outlet retainer (1) to the console, by pressing the retainer into place until fully seated.
  2. Connect the electrical connector (2) to the retainer.
  3. Align the housing (2) key way, to the key slot in the retainer ring (1).
  4. Press the housing into place until the housing is fully seated.
  5. Install the power outlet fuse.

J 42059 Cigar Lighter Socket Remover. See Special Tools .

  1. Remove the power outlet fuse.
  2. Remove the power outlet housing by placing one side of the T portion of J 42059 into the tab window and the other side into the opposite tab window. See «Special Tools»(/cadillac/srx/i-2003-2009/remont/body-electrical/#accessory-power-socket__special-tools) . Pull the lighter housing straight out.
  3. Remove the tool from the power outlet housing.
  4. Pull the housing (3) and the retainer (2) out of the console.
  5. Disconnect the electrical connector (1) from the housing.
  6. Remove the retainer from the housing.
  1. Install the power outlet retainer (1) to the console, by pressing the retainer into place until fully seated.
  2. Connect the electrical connector (2) to the retainer.
  3. Align the housing (2) key way, to the key slot in the retainer ring (1).
  4. Press the housing into place until the housing is fully seated.
  5. Install the power outlet fuse.

Special Tools

Special Tools Illustration Tool Number/ Description J 42059 Cigar Lighter Socket Remover
