Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Belt Assembly Anchor Bolt | 70 N.m | 52 lb ft |
| Body Lock Pillar Garnish Molding Screws | 2 N.m | 18 lb in |
| Body Rear Corner Upper Garnish Molding Screws | 2 N.m | 18 lb in |
| Center Pillar Upper Assist Handle Screws | 1.2 N.m | 10 lb in |
| Center Pillar Upper Garnish Molding Screws | 2 N.m | 18 lb in |
| Coat Hook Screws | 9 N.m | 80 lb in |
| Floor Console Bolts | 6 N.m | 53 lb in |
| Front Floor Console Rear Cupholder Screw | 2 N.m | 18 lb in |
| Jack and Tool Stowage Container Retaining Nut | 5 N.m | 44 lb in |
| Liftgate Trim Finish Panel Screw | 2 N.m | 18 lb in |
| Overhead Console Screws | 2 N.m | 18 lb in |
| Quarter Panel Trim Armrest Screws | 2 N.m | 18 lb in |
| Quarter Panel Trim Screws | 2 N.m | 18 lb in |
| Rear Assist Handle Screws | 6 N.m | 53 lb in |
| Side Door Armrest Bolt | 2 N.m | 18 lb in |
| Side Door Trim Panel Bolt | 2 N.m | 18 lb in |
| Sunshade Screws | 6 N.m | 53 lb in |
| Tool Storage Compartment Bracket Nuts | 50 N.m | 36 lb ft |
| Tool Storage Compartment Nuts | 10 N.m | 88 lb in |
| Windshield Side Garnish Molding Screws | 2 N.m | 18 lb in |
| Windshield Side Pillar Assist Handle Screws | 6 N.m | 53 lb in |
Scheme 68
Scheme 68: Heated/Cooled Cup Holder Schematics
Diagnostic Instructions
- Perform the «Diagnostic System Check - Vehicle»(/cadillac/escalade/gmt900-2006-2014/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures) prior to using this diagnostic procedure.
- Review «Strategy Based Diagnosis»(/cadillac/escalade/gmt900-2006-2014/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__strategy-based-diagnosis) for an overview of the diagnostic approach.
- «Diagnostic Procedure Instructions»(/cadillac/escalade/gmt900-2006-2014/remont/oem-general-information/#vehicle-diagnostic-information-diagnostic-information-and-procedures__diagnostic-procedure-instructions) provides an overview of each diagnostic category.
Diagnostic Fault Information
| Circuit | Short to Ground | Open/High Resistance | Short to Voltage |
|---|
| B+ | 1 | 1 | |
| Ground | | 1 | 1 |
| 1. Heated/Cooled cup holder Malfunction |
Circuit/System Description
The Heated/Cooled cup holder system uses a positive temperature coefficient (PTC) ceramic element. The PTC is attached to the side of an aluminum cylinder that forms the cup holder to provide the temperature change. B+ will either heat or cool the PTC element in the cup holder. Voltage applied in one direction heats the element and cools it when the polarity is reversed. A momentary switch on the console surface operates the unit. It offers off, heat and cool settings. The cup holders have a temperature range that heats to 140°F or cools to 35°F. A light in the switch glows red to indicate heating and blue to indicate cooling.
Reference Information
Connector End View Reference
Description and Operation
Electrical Information Reference
- «Circuit Testing»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__circuit-testing)
- «Connector Repairs»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__connector-repairs)
- «Testing for Intermittent Conditions and Poor Connections»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__testing-for-intermittent-conditions-and-poor)
- «Wiring Repairs»(/cadillac/escalade/gmt900-2006-2014/remont/ignition-switchsteering-lock/#wiring-systems-and-power-management-diagnostic-information-and-procedures__wiring-repairs)
Diagnostic Aids
If heating or cooling is insufficient make sure the air vents on either side of the console are not blocked in any way.
Circuit/System Verification
Ignition ON, turn the Heated/Cooled cup holder ON. Feel the inside of the Heated/Cooled cup holder it should feel warm or cool to the touch within a few minutes depending on the switch position.
Circuit/System Testing
- Ignition OFF, disconnect the harness connector at the Heated/Cooled cup holder.
- Test for less than 10 ohms between the ground circuit terminal A and ground. If greater than the specified range, test the ground circuit for an open/high resistance.
- 2. Ignition ON, verify that a test lamp illuminates between the B+ circuit terminal D and ground. If the test lamp does not illuminate, test the B+ circuit for a short to ground or an open/high resistance. If the circuit tests normal and the B+ circuit fuse is open, test or replace the Heated/Cooled cup holder.
- If all circuits test normal, test or replace the Heated/Cooled cup holder.
Repair Procedures
Scheme 69
Scheme 69: Upper Extension Trim Panel Replacement (Escalade)
| Callout | Component Name |
|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . |
| 1 | Front Side Door Upper Trim Panel Assembly Tip: Tab must be installed prior to retainer. Tab to be fully seated in front side door trim panel. |
| 2 | Front Side Door Upper Trim Panel Retainer (Qty: 1) |
| 3 | Front Side Door Upper Trim Panel Tab (Qty: 1) |
Scheme 70
Scheme 70: Upper Extension Trim Panel Replacement (Except Escalade)
| Callout | Component Name |
|---|
| Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . |
| 1 | Front Side Door Upper Trim Panel Assembly |
| 2 | Front Side Door Upper Trim Panel Retainer (Qty: 3) |
Scheme 71
Scheme 71: Front Side Door Trim Panel Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the door upper trim panel. Refer to Upper Extension Trim Panel Replacement (Escalade) or Upper Extension Trim Panel Replacement (Except Escalade) . Remove the door window control switch. Refer to Door Lock and Side Window Switch Replacement - Driver Side and Door Lock and Side Window Switch Replacement - Passenger Side . |
| 1 | Front Side Door Locking Rod Knob Assembly Procedure Lower the window. Ensure the locking rod is in the unlocked position. Use a flat-bladed tool to disengage the detent tab and then remove the knob by pulling upward. When re-installing, push the knob down until the detent tab touches the locking rod opening cover. Push the detent tab in to lock the knob to the locking rod. |
| 2 | Front Side Door Trim Panel Cover |
| 3 | Front Side Door Trim Panel Cover Retainer (Qty: 3) |
| 4 | Front Side Door Inside Handle Bezel Cover |
| 5 | Front Side Door Trim Panel Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (18 lb in) |
| 6 | Front Side Door Trim Panel Assembly Procedure Disconnect the electrical connectors. There are 2 hooks located on the lower portion of the door trim panel that are being used for service and manufacturing installation. If these hooks are damaged during either removal or installation of the door trim panel, replacement of the panel is not required. When installing the trim panel start at the lock knob, pushing down and outward moving toward the upper front. |
| 7 | Front Side Door Cable Retainer Procedure Depress both tabs to remove cable and pull cable rearward out of handle assembly. When reinstalling cable make sure that it is fully seated past the guide tab. |
| 8 | Front Side Door Trim Panel Retainer (Qty: 12) |
Scheme 72
Scheme 72: Rear Side Door Trim Panel Replacement (Standard Wheelbase)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the rear door window control switch. Refer to Rear Side Door Window Switch Replacement . |
| 1 | Rear Side Door Locking Rod Knob Assembly Procedure Lower the window. Ensure locking rod is in the unlocked position. Use a flat-bladed tool to disengage detent tab, then remove knob by pulling upward. When re-installing, push knob down, until detent tab touches locking rod opening cover. Push detent tab in to lock knob to locking rod. |
| 2 | Rear Side Door Trim Panel Cover |
| 3 | Rear Side Door Trim Panel Cover Retainer (Qty: 4) |
| 4 | Rear Side Door Inside Handle Bezel Cover |
| 5 | Rear Side Door Trim Panel Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (18 lb in) |
| 6 | Rear Side Door Trim Panel Assembly Procedure Disconnect the electrical connectors. There are 2 hooks located on the lower portion of the door trim panel that are being used for service and manufacturing installation. If these hooks are damaged during either removal or installation of the door trim panel, replacement of the panel is not required. |
| 7 | Rear Side Door Cable Retainer Procedure Depress both tabs to remove cable and pull cable rearward out of handle assembly. When reinstalling cable make sure that it is fully seated past the guide tab. |
| 8 | Rear Side Door Trim Panel Retainer (Qty: 10) |
Scheme 73
Scheme 73: Rear Side Door Trim Panel Replacement (Extended Wheelbase)
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the rear door window control switch. Refer to Rear Side Door Window Switch Replacement . |
| 1 | Rear Side Door Locking Rod Knob Assembly Procedure Lower the window. Ensure locking rod is in the unlocked position. Use a flat-bladed tool to disengage detent tab, then remove knob by pulling upward. When re-installing, push knob down, until detent tab touches locking rod opening cover. Push detent tab in to lock knob to locking rod. |
| 2 | Rear Side Door Trim Panel Cover |
| 3 | Rear Side Door Trim Panel Cover Retainer (Qty: 4) |
| 4 | Rear Side Door Inside Handle Bezel Cover |
| 5 | Rear Side Door Trim Panel Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (18 lb in) |
| 6 | Rear Side Door Trim Panel Assembly Procedure Disconnect the electrical connectors. There are 2 hooks located on the lower portion of the door trim panel that are being used for service and manufacturing installation. If these hooks are damaged during either removal or installation of the door trim panel, replacement of the panel is not required. |
| 7 | Rear Side Door Cable Retainer Procedure Depress both tabs to remove cable and pull cable rearward out of handle assembly. When reinstalling cable make sure that it is fully seated past the guide tab. |
| 8 | Rear Side Door Trim Panel Retainer (Qty: 10) |
Scheme 74
Scheme 74: Front Side Door Water Deflector Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the door trim panel. Refer to Front Side Door Trim Panel Replacement . |
| 1 | Front Side Door Water Deflector Tip: Use a flat-bladed tool to separate the bond between the sealer and the door. Use waterproof tape, or 3M 777 or equivalent, if the water deflector is damaged. It will be necessary to replace trim panel retaining clips, if broken. Before replacing the water deflector clean the door adhesive area, using a 50/50 mix of isopropyl alcohol or equivalent. |
Scheme 75
Scheme 75: Rear Side Door Water Deflector Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove the door trim panel. Refer to Rear Side Door Trim Panel Replacement (Standard Wheelbase) or Rear Side Door Trim Panel Replacement (Extended Wheelbase) . |
| 1 | Rear Side Door Water Deflector Tip: Use a flat-bladed tool to separate the bond between the sealer and the door. Use waterproof tape or equivalent, if the water deflector is damaged. It will be necessary to replace trim panel retaining clips, if broken. Before replacing the water deflector, clean the door adhesive area using a 50/50 mix of isopropyl alcohol or equivalent. |
Scheme 76
Scheme 76: Front Side Door Opening Frame Garnish Molding Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures: Remove the front door trim panel. Refer to Front Side Door Trim Panel Replacement . |
| 1 | Front Side Door Window Garnish Molding Retainer (Qty: 6) |
| 2 | Front Side Door Window Garnish Molding Tip: Install the 3 clips in the corners over the flange. Install the tab at each end of the garnish molding between the flange and reveal molding. Install the remaining 3 clips around the window flange. |
Scheme 77
Scheme 77: Rear Door Opening Frame Garnish Molding Replacement
Scheme 78
Scheme 78: Armrest Replacement
Scheme 79
Scheme 79: Front Side Door Sill Trim Plate Replacement
| Callout | Component Name |
|---|
| 1 | Front Side Door Sill Trim Plate Assembly Tip: Reposition the door opening weatherstrip out of the way. Pull upward to disengage retainers. |
| 2 | Front Side Door Trim Plate Retainer (Qty: 6) |
Scheme 80
Scheme 80: Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase)
| Callout | Component Name |
|---|
| 1 | Rear Side Door Sill Trim Plate Assembly Tip: Reposition the door opening weatherstrip out of the way. Pull upward to disengage retainers. |
| 2 | Rear Side Door Trim Plate Retainer (Qty: 5) |
Scheme 81
Scheme 81: Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase)
| Callout | Component Name |
|---|
| 1 | Rear Side Door Sill Trim Plate Assembly Tip: Reposition the door opening weatherstrip out of the way. Pull upward to disengage retainers. |
| 2 | Rear Side Door Trim Plate Retainers (Qty: 4) |
Scheme 82
Scheme 82: Liftgate Door Sill Plate Replacement
| Callout | Component Name |
|---|
| 1 | Rear Floor Rear Trim Plate Assembly Tip: Reposition the liftgate opening weatherstrip out of the way. Pull upward to disengage retainers. |
| 2 | Rear Floor Rear Trim Plate Retainer (Qty: 10) |
Scheme 83
Scheme 83: Front Assist Handle Replacement
| Callout | Component Name |
|---|
| 1 | Windshield Pillar Assist Handle Cover (Qty: 2) |
| 2 | Windshield Pillar Assist Handle Cover Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 6 N.m (53 lb in) |
| 3 | Windshield Pillar Assist Handle Cover Assembly |
Scheme 84
Scheme 84: Roof Rail Rear Assist Handle Replacement
| Callout | Component Name |
|---|
| 1 | Roof Rail Rear Assist Handle Cover (Qty: 2) |
| 2 | Roof Rail Rear Assist Handle Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 6 N.m (53 lb in) |
| 3 | Roof Rail Rear Assist Handle Assembly Tip: Pull assist handle downward to access covers and fasteners. |
Scheme 85
Scheme 85: Coat Hook Replacement
| Callout | Component Name |
|---|
| 1 | Coat Hook Assembly Cover |
| 2 | Coat Hook Screw (Qty: 1) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in) |
| 3 | Coat Hook Assembly Tip: Pull hook downward to access cover and fastener. |
Scheme 86
Scheme 86: Sunshade Replacement
| Callout | Component Name |
|---|
| 1 | Sunshade Bracket Cover |
| 2 | Windshield Side Garnish Molding Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 6 N.m (53 lb in) |
| 3 | Sunshade Assembly Tip: Disconnect electrical connectors. |
| 4 | Sunshade Bracket |
Scheme 87
Scheme 87: Sunshade Anchor Replacement
| Callout | Component Name |
|---|
| 1 | Sunshade Anchor Screw CAUTION: Refer to Fastener Caution . Tighten: 3 N.m (25 lb in) |
| 2 | Sunshade Anchor Assembly Tip: Pull the cover downward to access the fastener. |
Scheme 88
Scheme 88: Windshield Pillar Garnish Molding Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle, passenger side only. Refer to Front Assist Handle Replacement . |
| 1 | Windshield Side Garnish Molding Cover |
| 2 | Windshield Side Garnish Molding Screw CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in) |
| 3 | Windshield Side Garnish Molding Assembly Procedure Tabs must be installed prior to retainers. Tabs to be fully seated in I/P trim panel retainer and valance panel. Disconnect electrical connectors. |
| 4 | Windshield Side Garnish Molding Retainer (Qty: 2) |
Scheme 89
Scheme 89: Center Pillar Upper Garnish Molding Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Disable roof rail SIR system. Refer to SIR Disabling and Enabling . Remove center pillar lower garnish molding. Refer to Center Pillar Lower Garnish Molding Replacement . |
| 1 | Center Pillar Upper Garnish Molding Cover |
| 2 | Center Pillar Upper Garnish Molding Screw CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in) |
| 3 | Center Pillar Upper Garnish Molding Assembly Tip: Remove seat belt D-ring from the adjuster assembly. Pull garnish molding toward inside of the vehicle to disengage the retainers. Align 4-way locator to center pillar before engaging retainers. Tighten: 35 N.m (25 lb ft) |
| 4 | Center Pillar Upper Garnish Molding Retainer (Qty: 4) |
Scheme 90
Scheme 90: Center Pillar Lower Garnish Molding Replacement
Scheme 91
Scheme 91: Rear Upper Garnish Molding Replacement (Avalanche/Escalade EXT)
Scheme 92
Scheme 92: Body Rear Corner Garnish Molding Replacement - Right Side
| Callout | Component Name |
|---|
| Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the rear opening garnish molding. Refer to Rear Door Upper Garnish Molding Replacement . |
| 1 | Body Rear Corner Upper Garnish Molding Cover Tip: Disconnect the 2 electrical connectors. |
| 2 | Body Rear Corner Upper Garnish Molding Screw CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in) |
| 3 | Body Rear Corner Upper Garnish Molding Assembly |
| 4 | Body Rear Corner Upper Garnish Molding Clip (Qty: 3) |
| 5 | Body Rear Corner Upper Garnish Molding Retainer (Qty: 3) |
Scheme 93
Scheme 93: Body Rear Corner Garnish Molding Replacement - Left Side (w/E61)
Scheme 94
Scheme 94: Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61)
Scheme 95
Scheme 95: Rear Door Upper Garnish Molding Replacement
| Callout | Component Name |
|---|
| 1 | Back Body Opening Garnish Molding Assembly Tip: Pull down to disengage retainer clips. |
| 2 | Back Body Opening Garnish Molding Assembly Clip (Qty: 7) |
Scheme 96
Scheme 96: Body Hinge Pillar Trim Panel Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures: Remove front door sill trim panel. Refer to Front Side Door Sill Trim Plate Replacement . |
| 1 | Front Hinge Pillar Trim Panel Assembly Tip: The hood release handle must be in the open position for installation of the LH hinge pillar panel. |
| 2 | Front Hinge Pillar Trim Panel Assembly Retainer (Qty: 2) |
Scheme 97
Scheme 97: Rear Quarter Trim Panel Replacement - Left Side (Extended Wheelbase w/o E61)
Scheme 98
Scheme 98: Rear Quarter Trim Panel Replacement - Left Side (Extended Wheelbase w/E61)
Scheme 99
Scheme 99: Rear Quarter Trim Panel Replacement - Left Side (Standard Wheelbase w/o E61)
Scheme 100
Scheme 100: Rear Quarter Trim Panel Replacement - Left Side (Standard Wheelbase w/E61)
Scheme 101
Scheme 101: Rear Quarter Trim Panel Replacement - Right Side (Standard Wheelbase)
Scheme 102
Scheme 102: Rear Quarter Trim Panel Replacement - Right Side (Extended Wheelbase)
Scheme 103
Scheme 103: Liftgate Pull Strap Replacement
| Callout | Component Name |
|---|
| 1 | Liftgate Pull Strap Fastener CAUTION: Refer to Fastener Caution . |
| 2 | Liftgate Pull Strap Assembly |
Scheme 104
Scheme 104: Liftgate Garnish Molding Replacement
| WARNING |
|---|
| When a hood hold open device is being removed or installed, provide alternate support to avoid the possibility of damage to the vehicle or personal injury. |
Scheme 105
Scheme 105: Endgate Trim Panel Replacement
| Callout | Component Name |
|---|
| 1 | Endgate Trim Panel Screw (Qty: 10) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in) |
| 2 | Endgate Trim Panel |
Scheme 106
Scheme 106: Liftgate Trim Panel Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure: Remove liftgate window upper garnish molding. Refer to Liftgate Garnish Molding Replacement . |
| 1 | Liftgate Trim Finish Panel Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in) |
| 2 | Liftgate Trim Finish Panel Assembly Tip: Pull outward to disengage retainers and clips. Disconnect electrical connector. |
| 3 | Liftgate Trim Finish Panel Retainer (Qty: 12) |
| 4 | Liftgate Trim Finish Panel Clip (Qty: 5) |
Scheme 107
Scheme 107: Rear Floor Trim Plate Replacement (Avalanche/Escalade EXT)
Scheme 108
Scheme 108: Removable Midgate Hinge Finish Cover Replacement (SUT)
| Callout | Component Name |
|---|
| 1 | Midgate Hinge Finish Cover Tip: Tilt rear seat backs forward in order to gain access to hinge cover. Pull upward on hinge cover to disengage clips. |
| 2 | Midgate Hinge Finish Cover Clip (Qty: 2) |
Scheme 109
Scheme 109: Front Floor Console Front Cup Holder Replacement (Except Cadillac)
| Callout | Component Name |
|---|
| 1 | Front Floor Console Cupholder Assembly |
Scheme 110
Scheme 110: Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase)
Scheme 111
Scheme 111: Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT)
Scheme 112
Scheme 112: Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase)
Scheme 113
Scheme 113: Pressure Relief Valve Replacement
Heated/Cooled Cup Holder Description and Operation
The Heated/Cooled cup holder system uses a positive temperature coefficient (PTC) ceramic element. The PTC is attached to the side of an aluminum cylinder that forms the cup holder to provide the temperature change. B+ will either heat or cool the PTC element in the cup holder. Voltage applied in one direction heats the element and cools it when the polarity is reversed. A momentary switch on the console surface operates the unit. It offers off, heat and cool settings. The cup holders have a temperature range that heats to 140°F or cools to 35°F. A light in the switch glows red to indicate heating and blue to indicate cooling.
