Instrument Panel Trim and Console Trim Cadillac Escalade GMT900

Exterior/interior Trim 59 illustrations ~2387 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Front Floor Console Bolts (Cadillac)2 N.m18 lb in
Front Floor Console Compartment Bezel Screws (Cadillac)2 N.m18 lb in
Front Floor Console Compartment Panel Screws (Except Cadillac)2 N.m18 lb in
Front Floor Console Cover (Lid) Screws2 N.m18 lb in
Front Floor Console End Panel Screws (Except Cadillac)2 N.m18 lb in
Front Floor Console Inner Cover Screws2 N.m18 lb in
Front Floor Console Latch Inner Screws2 N.m18 lb in
Front Floor Console Latch Outer Screws2 N.m18 lb in
Front Floor Console Side Trim Panel Screws (Cadillac)2 N.m18 lb in
Front Overhead Console Screws2 N.m18 lb in
Instrument Panel Carrier Screws/Bolts (Except Cadillac)2 N.m18 lb in
Instrument Panel Carrier Support Bolts22 N.m16 lb ft
Instrument Panel Carrier Support Screw2 N.m18 lb in
Instrument Panel Cluster Trim Plate Cover Screws2 N.m18 lb in
Instrument Panel Compartment Door Assembly Screws (Except Cadillac)2 N.m18 lb in
Instrument Panel Compartment Door Screws2 N.m18 lb in
Instrument Panel Compartment Latch Screws2 N.m18 lb in
Instrument Panel Compartment Striker Screws2 N.m18 lb in
Instrument Panel Insulator Screws2 N.m18 lb in
Instrument Panel Knee Bolster Deflector Nuts9 N.m80 lb in
Instrument Panel Knee Bolster Screws2 N.m18 lb in
Instrument Panel Lower Trim Panel Nuts (Cadillac)9 N.m80 lb in
Instrument Panel Lower Trim Panel Screws (Cadillac)2 N.m18 lb in
Instrument Panel Upper Trim Panel Bolts (Except Cadillac)9 N.m80 lb in
Instrument Panel Upper Trim Panel Bolts/Screws (Cadillac)9 N.m80 lb in
Instrument Panel Upper Trim Panel Screws (Except Cadillac)2 N.m18 lb in

Scheme 133

Scheme 133: Instrument Panel Insulator Replacement (Cadillac)
Scheme 133: Instrument Panel Insulator Replacement (Cadillac)
CalloutComponent Name
Preliminary Procedures: Remove the right console trim panel. Refer to Front Floor Console Side Trim Panel Replacement - Right Side (Cadillac) .
1Instrument Panel Lower Trim Panel Insulator Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Lower Trim Panel Insulator
CAUTION
Refer to Fastener Caution .

Scheme 134

Scheme 134: Instrument Panel Insulator Replacement (Except Cadillac)
Scheme 134: Instrument Panel Insulator Replacement (Except Cadillac)
CalloutComponent Name
1Instrument Panel Lower Trim Panel Insulator Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Lower Trim Panel Insulator
CAUTION
Refer to Fastener Caution .

Scheme 135

Scheme 135: Knee Bolster Replacement (Cadillac)
Scheme 135: Knee Bolster Replacement (Cadillac)
CalloutComponent Name
1Left Outer Trim Cover Tip: Refer to Instrument Panel Outer Trim Cover Replacement (Cadillac) .
2Knee Bolster Assembly Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
3Knee Bolster Assembly Procedure Disconnect the electrical connections, if applicable. If replacing the knee bolster assembly, transfer all necessary components.
4Retainer Clip (Qty: 4)
CAUTION
Refer to Fastener Caution .

Scheme 136

Scheme 136: Knee Bolster Replacement (Except Cadillac)
Scheme 136: Knee Bolster Replacement (Except Cadillac)
CalloutComponent Name
Preliminary Procedures: Remove the left instrument panel outer trim cover. Refer to Instrument Panel Outer Trim Cover Replacement (Except Cadillac) .
1Knee Bolster Assembly Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Knee Bolster Assembly Procedure Disconnect the electrical connections, if applicable. If replacing the knee bolster assembly, transfer all necessary components.
3Retainer Clip (Qty: 4)
CAUTION
Refer to Fastener Caution .

Scheme 137

Scheme 137: Instrument Panel Driver Knee Bolster Deflector Replacement
Scheme 137: Instrument Panel Driver Knee Bolster Deflector Replacement
CalloutComponent Name
Preliminary Procedure: Remove the knee bolster. Refer to Knee Bolster Replacement (Cadillac) or Knee Bolster Replacement (Except Cadillac) .
1Knee Bolster Deflector Nut (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in)
2Knee Bolster Deflector
CAUTION
Refer to Fastener Caution .

Scheme 138

Scheme 138: Instrument Panel Accessory Trim Plate Replacement (Cadillac)
Scheme 138: Instrument Panel Accessory Trim Plate Replacement (Cadillac)
CalloutComponent Name
Preliminary Procedures Remove the instrument panel center trim plate. Refer to Instrument Panel Center Trim Panel Replacement (Cadillac) . Remove the front floor console bezel. Refer to Floor Console Bezel Replacement (Cadillac) .
1Instrument Panel Accessory Trim Panel Tip: Disconnect the electrical connections. If replacing the accessory trim plate transfer all necessary components.
2Retainer Clips (Qty: 6)

Scheme 139

Scheme 139: Instrument Panel Accessory Trim Plate Replacement (Except Cadillac)
Scheme 139: Instrument Panel Accessory Trim Plate Replacement (Except Cadillac)
CalloutComponent Name
1Instrument Panel Accessory Trim Plate Tip: Use a flat-bladed plastic trim tool in order to release the retainer clips securing the trim plate to the instrument panel.
2Retainer Clips (Qty: 9)

Scheme 140

Scheme 140: Instrument Panel Center Trim Panel Replacement (Cadillac)
Scheme 140: Instrument Panel Center Trim Panel Replacement (Cadillac)
CalloutComponent Name
1Instrument Panel Center Trim Plate Tip: Use a flat-bladed plastic trim tool in order to release the retainer clips securing the trim plate to the instrument panel.
2Retainer Clips (Qty: 6)

Scheme 141

Scheme 141: Instrument Panel Center Trim Panel Replacement (Except Cadillac)
Scheme 141: Instrument Panel Center Trim Panel Replacement (Except Cadillac)
CalloutComponent Name
1Instrument Panel Center Trim Plate Tip: Use a flat-bladed plastic trim tool in order to release the retainer clips securing the trim plate to the instrument panel. Disconnect the electrical connections.
2Retainer Clips (Qty: 8)

Scheme 142

Scheme 142: Instrument Panel Upper Trim Panel Replacement (Cadillac)
Scheme 142: Instrument Panel Upper Trim Panel Replacement (Cadillac)
CalloutComponent Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the windshield pillar garnish moldings. Refer to Windshield Pillar Garnish Molding Replacement . Remove the instrument panel upper trim panel with defroster nozzle. Refer to Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Cadillac) . Remove the instrument panel outer trim covers. Refer to Instrument Panel Outer Trim Cover Replacement (Cadillac) . Remove the left instrument panel deflector. Refer to Instrument Panel Outer Air Outlet Deflector Replacement - Left Side (Cadillac) . Remove the instrument panel cluster assembly. Refer to Instrument Cluster Replacement (Cadillac) . Remove the instrument panel center trim panel. Refer to Instrument Panel Center Trim Panel Replacement (Cadillac) . Remove the instrument panel accessory trim panel assembly. Refer to Instrument Panel Accessory Trim Plate Replacement (Cadillac) . Remove the instrument panel inflatable restraint. Refer to Instrument Panel Inflatable Restraint Module Replacement .
1Instrument Panel Upper Trim Panel Bolt/Screw (Qty: 8) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in)
2Instrument Panel Upper Trim Panel to HVAC Duct Screw (Qty: 8) Tighten: 2 N.m (18 lb in)
3Instrument Panel Upper Trim Panel Assembly Procedure Disconnect electrical connections. With the aid of an assistant, remove the trim panel from the vehicle.
4Retainer Clip (Qty: 6)
CAUTION
Refer to Fastener Caution .

Scheme 143

Scheme 143: Instrument Panel Upper Trim Panel Replacement (Except Cadillac)
Scheme 143: Instrument Panel Upper Trim Panel Replacement (Except Cadillac)
CalloutComponent Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the windshield pillar garnish moldings. Refer to Windshield Pillar Garnish Molding Replacement . Remove the instrument panel upper trim panel with defroster nozzle. Refer to Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Except Cadillac) . Remove the Radio Front Speaker, if Equipped. Refer to Radio Front Speaker Replacement . Remove the instrument panel outer trim covers. Refer to Instrument Panel Outer Trim Cover Replacement (Except Cadillac) . Remove the left instrument panel deflector. Refer to Instrument Panel Outer Air Outlet Deflector Replacement - Left Side (Except Cadillac) . Remove the headlamp switch bezel assembly. Refer to Headlamp Switch Bezel Replacement (Except Cadillac) . Remove the instrument panel cluster assembly. Refer to Instrument Cluster Replacement (Except Cadillac) . Remove the knee bolster assembly. Refer to Knee Bolster Replacement (Except Cadillac) . Remove the instrument panel center trim panel. Refer to Instrument Panel Center Trim Panel Replacement (Except Cadillac) . Remove the instrument panel accessory switch assembly. Refer to Accessory Switch Replacement (Except Cadillac) . Remove the HVAC control module. Refer to HVAC Control Module Replacement . Remove the radio. Refer to Radio Replacement (Except Cadillac) . Remove the instrument panel inflatable restraint. Refer to Instrument Panel Inflatable Restraint Module Replacement . Remove the right instrument panel deflector. Refer to Instrument Panel Center Air Outlet Deflector Replacement (Except Cadillac) . Remove the instrument panel compartment door. Refer to Instrument Panel Compartment Door Replacement (Except Cadillac) . Remove the instrument panel access hole cover panel. Refer to Instrument Panel Compartment Access Hole Cover Replacement (Except Cadillac) .
1Instrument Panel Upper Trim Panel Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in)
2Instrument Panel Upper Trim Panel Screw (Qty: 18) Tighten: 2 N.m (18 lb in)
3Instrument Panel Upper Trim Panel Assembly Tip: Prior to removal of the trim panel from the carrier assembly, note the routing of the wiring to aid in reassembly. Disconnect electrical connections. With the aid of an assistant, remove the trim panel from the vehicle.
CAUTION
Refer to Fastener Caution .

Scheme 144

Scheme 144: Headlamp Switch Bezel Replacement (Except Cadillac)
Scheme 144: Headlamp Switch Bezel Replacement (Except Cadillac)
CalloutComponent Name
1Headlamp Switch Plate Assembly Procedure Use a flat bladed plastic trim tool in order to remove the trim plate from the instrument panel. Disconnect the electrical connections. When replacing the headlamp switch plate assembly, transfer all necessary components.

Scheme 145

Scheme 145: Headlamp Switch Bezel Replacement (Cadillac)
Scheme 145: Headlamp Switch Bezel Replacement (Cadillac)
CalloutComponent Name
1Headlamp Switch Trim Plate Assembly Tip: Disconnect the electrical connectors. If replacing the trim plate, transfer the switches as needed.
2Headlamp Switch Plate Retainer (Qty: 4)

Scheme 146

Scheme 146: Instrument Panel Cluster Trim Plate Cover Replacement (Except Cadillac)
Scheme 146: Instrument Panel Cluster Trim Plate Cover Replacement (Except Cadillac)
CalloutComponent Name
Preliminary Procedures Tilt the steering wheel to its lowest position. Remove the instrument panel left air deflector. Refer to Instrument Panel Outer Air Outlet Deflector Replacement - Left Side (Except Cadillac) . Remove the instrument panel center trim panel. Refer to Instrument Panel Center Trim Panel Replacement (Except Cadillac) .
1Instrument Panel Cluster Trim Plate Cover Assembly Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Cluster Trim Plate Cover Assembly
CAUTION
Refer to Fastener Caution .

Scheme 147

Scheme 147: Instrument Cluster Trim Panel Replacement (Except Cadillac)
Scheme 147: Instrument Cluster Trim Panel Replacement (Except Cadillac)
CalloutComponent Name
Preliminary Procedure: Remove the instrument panel cluster trim plate cover. Refer to Instrument Panel Cluster Trim Plate Cover Replacement (Except Cadillac) .
1Instrument Panel Cluster Trim Plate
2Retainer Clips (Qty: 4)

Scheme 148

Scheme 148: Instrument Cluster Trim Panel Replacement (Cadillac)
Scheme 148: Instrument Cluster Trim Panel Replacement (Cadillac)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel accessory trim plate. Refer to Instrument Panel Accessory Trim Plate Replacement (Cadillac) . Remove the left instrrument panel outer air outlet deflector. Refer to Instrument Panel Outer Air Outlet Deflector Replacement - Left Side (Cadillac) .
1Instrument Panel Cluster Trim Plate Bezel Procedure Position the steering wheel to its lowest possible position. Use a flat-bladed plastic trim tool in order to release the retainer clips securing the lower edge of the trim plate to the instrument panel. Pull the trim bezel downward, releasing the tabs at the upper edge of the bezel from the instrument panel upper trim panel.
2Retainer Clips (Qty: 4)

Scheme 149

Scheme 149: Instrument Panel Outer Trim Cover Replacement (Cadillac)
Scheme 149: Instrument Panel Outer Trim Cover Replacement (Cadillac)
CalloutComponent Name
1Instrument Panel Outer Trim Cover - Right or Left
2Retainer Clips (Qty: 3)

Scheme 150

Scheme 150: Instrument Panel Outer Trim Cover Replacement (Except Cadillac)
Scheme 150: Instrument Panel Outer Trim Cover Replacement (Except Cadillac)
CalloutComponent Name
1Instrument Panel Outer Trim Cover - Right or Left
2Retainer Clips (Qty: 3)

Scheme 151

Scheme 151: Instrument Panel Compartment Door Lock Striker Replacement (Except Cadillac)
Scheme 151: Instrument Panel Compartment Door Lock Striker Replacement (Except Cadillac)
CalloutComponent Name
1Instrument Panel Compartment Striker Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Compartment Striker
CAUTION
Refer to Fastener Caution .

Scheme 152

Scheme 152: Instrument Panel Compartment Door Lock Striker Replacement (Cadillac)
Scheme 152: Instrument Panel Compartment Door Lock Striker Replacement (Cadillac)
CalloutComponent Name
1Instrument Panel Compartment Striker Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Compartment Striker
CAUTION
Refer to Fastener Caution .

Scheme 153

Scheme 153: Instrument Panel Compartment Door Replacement (Cadillac)
Scheme 153: Instrument Panel Compartment Door Replacement (Cadillac)
CalloutComponent Name
Preliminary Procedures Open the instrument panel compartment. Release the instrument panel compartment stop, allowing the compartment to fully open.
1Instrument Panel Compartment Screw (Qty: 5) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Compartment Assembly
CAUTION
Refer to Fastener Caution .

Scheme 154

Scheme 154: Instrument Panel Compartment Door Replacement (Except Cadillac)
Scheme 154: Instrument Panel Compartment Door Replacement (Except Cadillac)
CalloutComponent Name
1Instrument Panel Compartment Door Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in) Tip: Open the instrument panel compartment door. Release the instrument panel compartment door stop. Allow the instrument panel compartment door to open completely to access the screws.
2Instrument Panel Compartment Door Assembly
CAUTION
Refer to Fastener Caution .

Scheme 155

Scheme 155: Instrument Panel Compartment Door Assembly Replacement (Except Cadillac)
Scheme 155: Instrument Panel Compartment Door Assembly Replacement (Except Cadillac)
CalloutComponent Name
Preliminary Procedure: Remove the front floor console. Refer to Front Floor Console Replacement (Except Cadillac) .
1Instrument Panel Upper Trim Panel Assembly Refer to Instrument Panel Upper Trim Panel Replacement (Except Cadillac) .
2Instrument Panel Compartment Assembly Screw (Qty: 18) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
3Instrument Panel Compartment Assembly (Lower Trim Panel)
CAUTION
Refer to Fastener Caution .

Scheme 156

Scheme 156: Instrument Panel Compartment Access Hole Cover Replacement (Cadillac)
Scheme 156: Instrument Panel Compartment Access Hole Cover Replacement (Cadillac)
CalloutComponent Name
1Instrument Panel Access Hole Cover
2Retainer Clips (Qty: 3)

Scheme 157

Scheme 157: Instrument Panel Compartment Access Hole Cover Replacement (Except Cadillac)
Scheme 157: Instrument Panel Compartment Access Hole Cover Replacement (Except Cadillac)
CalloutComponent Name
1Instrument Panel Access Hole Cover
2Retainer Clips (Qty: 3)

Scheme 158

Scheme 158: Instrument Panel Compartment Door Opening Frame Replacement (Cadillac)
Scheme 158: Instrument Panel Compartment Door Opening Frame Replacement (Cadillac)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel compartment door. Refer to Instrument Panel Compartment Door Replacement (Cadillac) . Remove the right instrument panel outer trim cover. Refer to Instrument Panel Outer Trim Cover Replacement (Cadillac) .
1Instrument Panel Compartment Opening Frame Screw (Qty: 5) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
2Instrument Panel Compartment Opening Frame Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel compartment opening frame assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 159

Scheme 159: Instrument Panel Compartment Door Latch Replacement (Cadillac)
Scheme 159: Instrument Panel Compartment Door Latch Replacement (Cadillac)
CalloutComponent Name
1Instrument Panel Compartment Latch Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Compartment Latch Assembly
CAUTION
Refer to Fastener Caution .

Scheme 160

Scheme 160: Instrument Panel Compartment Door Latch Replacement (Except Cadillac)
Scheme 160: Instrument Panel Compartment Door Latch Replacement (Except Cadillac)
CalloutComponent Name
1Instrument Panel Compartment Latch Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Compartment Latch Assembly
CAUTION
Refer to Fastener Caution .

Removal Procedure

  1. Remove the instrument panel compartment latch. Refer to «Instrument Panel Compartment Door Latch Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) or «Instrument Panel Compartment Door Latch Replacement (Except Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  2. Position the instrument panel compartment latch fork bolt in the up position.
  3. Insert the key into the instrument panel compartment lock cylinder.
  4. Rotate the instrument panel compartment lock cylinder clockwise to the 3 o'clock position with the key.
  5. With the key in position, apply a light load and depress the retainer tumbler through the poke hole at the right hand side of the instrument panel compartment latch.
  6. Rotate the key until the instrument panel compartment lock cylinder rotates to about the 5 o'clock position. This will line up the notch at the rear of the instrument panel compartment lock cylinder with the tab in the instrument panel compartment latch housing.
  7. Remove the instrument panel compartment lock cylinder from the instrument panel compartment latch by pulling on the key.

Installation Procedure

  1. Position the instrument panel compartment latch fork bolt in the up position.
  2. Grasp the instrument panel compartment lock cylinder. Depress the rear-most, light-colored tumbler that is flush with the instrument panel compartment lock cylinder surface.
  3. Insert the key. All the tumblers will now stay depressed.
  4. Insert the instrument panel compartment lock cylinder, with the key inserted, into the instrument panel compartment latch housing. Ensure that the front projection pin is at the appropriate 8 o'clock position. The instrument panel compartment lock cylinder will drop into place.
  5. Rotate the key counterclockwise until the key stops.
  6. Remove the key, the tumblers will now release. The instrument panel compartment lock cylinder is now locked into the instrument panel compartment latch housing.
  7. Install the instrument panel compartment latch. Refer to «Instrument Panel Compartment Door Latch Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) or «Instrument Panel Compartment Door Latch Replacement (Except Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .

Scheme 161

Scheme 161: Instrument Panel Compartment Door Dampener Replacement (Cadillac)
Scheme 161: Instrument Panel Compartment Door Dampener Replacement (Cadillac)
CalloutComponent Name
1Instrument Panel Compartment Opening Frame Refer to Instrument Panel Compartment Door Opening Frame Replacement (Cadillac) .
2Instrument Panel Compartment Dampener Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
3Instrument Panel Compartment Dampener
CAUTION
Refer to Fastener Caution .

Scheme 162

Scheme 162: Instrument Panel Compartment Door Dampener Replacement (Except Cadillac)
Scheme 162: Instrument Panel Compartment Door Dampener Replacement (Except Cadillac)
CalloutComponent Name
1Instrument Panel Compartment Door Assembly Refer to Instrument Panel Compartment Door Assembly Replacement (Except Cadillac) .
2Instrument Panel Compartment Dampener Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2.5 N.m (22 lb in)
3Instrument Panel Compartment Dampener
CAUTION
Refer to Fastener Caution .

Scheme 163

Scheme 163: Instrument Panel Lower Trim Panel Replacement (Cadillac)
Scheme 163: Instrument Panel Lower Trim Panel Replacement (Cadillac)
CalloutComponent Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the front floor console assembly. Refer to Front Floor Console Replacement (Cadillac) . Remove the windshield pillar garnish moldings. Refer to Windshield Pillar Garnish Molding Replacement . Remove the instrument panel upper trim panel with defroster nozzle. Refer to Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Cadillac) . Remove the instrument panel upper trim panel. Refer to Instrument Panel Upper Trim Panel Replacement (Cadillac) . Remove the instrument panel outer trim covers. Refer to Instrument Panel Outer Trim Cover Replacement (Cadillac) . Remove the left instrument panel deflector. Refer to Instrument Panel Outer Air Outlet Deflector Replacement - Left Side (Cadillac) . Remove the headlamp switch bezel assembly. Refer to Headlamp Switch Bezel Replacement (Cadillac) . Remove the instrument panel cluster assembly. Refer to Instrument Cluster Replacement (Cadillac) . Remove the knee bolster assembly. Refer to Knee Bolster Replacement (Cadillac) . Remove the steering column. Refer to Steering Column Replacement (Without HP2) or Steering Column Replacement (HP2) or Steering Column Replacement (Without HP2 With Electric Tilt Column) . Remove the instrument panel center trim panel. Refer to Instrument Panel Center Trim Panel Replacement (Cadillac) . Remove the instrument panel accessory trim panel. Refer to Instrument Panel Accessory Trim Plate Replacement (Cadillac) . Remove the instrument panel clock assembly. Refer to Clock Replacement . Remove the instrument panel accessory switch assembly. Refer to Accessory Switch Replacement (Cadillac) . Remove the HVAC control module. Refer to HVAC Control Module Replacement . Remove the radio. Refer to Radio Replacement (Cadillac) . Remove the instrument panel compartment door. Refer to Instrument Panel Compartment Door Replacement (Cadillac) . Remove the instrument panel access hole cover panel. Refer to Instrument Panel Compartment Access Hole Cover Replacement (Cadillac) .
1Instrument Panel Lower Trim Panel Nut (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in)
2Instrument Panel Lower Trim Panel Bolt/Screw (Qty: 10) Tighten: 2 N.m (18 lb in)
3Instrument Panel Lower Trim Panel Assembly Tip: Prior to removing the trim panel from the carrier support assembly, note the routing of the wiring to aid in the reassembly. Disconnect all electrical connections. With the aid of an assistant, remove the trim panel from the vehicle.
CAUTION
Refer to Fastener Caution .

Scheme 164

Scheme 164: Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Except Cadill
Scheme 164: Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Except Cadill
CalloutComponent Name
Preliminary Procedure: Remove the windshield garnish moldings. Refer to Windshield Pillar Garnish Molding Replacement .
1Instrument Panel Upper Trim Panel Tip: Disconnect the electrical connections.
2Retainer Clips (Qty: 7)

Scheme 165

Scheme 165: Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Cadillac)
Scheme 165: Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Cadillac)
CalloutComponent Name
Preliminary Procedure: Remove the windshield garnish moldings. Refer to Windshield Pillar Garnish Molding Replacement .
1Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Tip: Disconnect the electrical connections.
2Retainer Clips (Qty: 7)

Special Tools

J-42640: Steering Column Anti-Rotation Pin

  1. Lock the steering column through the access hole in the steering column shroud using J-42640: Steering Column Anti-Rotation Pin.
  2. Remove the steering shaft coupling nut (1) and bolt (2) at the steering column.
  3. Remove the front seats. Refer to «Front Seat Replacement - Bucket (with HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Front Seat Replacement - Bucket (without HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  4. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/escalade/gmt900-2006-2014/remont/charging-system/#battery-charging-system-and-starting-system) .
  5. Remove the front floor console. Refer to «Front Floor Console Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) or «Front Floor Console Replacement (Except Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  6. Remove the instrument panel outer trim covers. Refer to «Instrument Panel Outer Trim Cover Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) or «Instrument Panel Outer Trim Cover Replacement (Except Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  7. Remove the windshield pillar garnish moldings. Refer to «Windshield Pillar Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  8. Remove the instrument panel upper trim panel with windshield defroster nozzle grille. Refer to «Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Except Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) or «Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  9. Tape the ambient light sensor to the instrument panel upper trim panel to ensure it does not fall behind the instrument panel assembly during reinstallation.
  10. Remove the right and left body hinge pillar trim panel. Refer to «Body Hinge Pillar Trim Panel Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  11. Remove the instrument panel center support bracket.
  12. Note location and routing of the instrument panel wiring harness prior to removal in order to ensure proper installation.
  13. On the right side of the instrument panel perform the following procedures: Disconnect the electrical connections to the instrument panel right electrical center. Disconnect the electrical connection for the instrument panel inflatable restraint module. Disconnect the radio antennas. Release the wire looms securing the wiring harnesses to the right side of the instrument panel.
  14. On the left side of the instrument panel perform the following procedures: Disconnect the electrical connections to the instrument panel left electrical center. Disconnect the ground wires from the upper left cowl panel. Remove the body wiring harness junction block from its bracket to allow movement in the body harness. Release the wire looms securing the wiring harnesses to the left side of the instrument panel.
  15. Remove the 4 bolts (1) securing the instrument panel upper trim panel to the cowl.
  16. Remove the 2 bolts (1) securing the instrument carrier support to the cowl. These bolts are located down inside the instrument panel and can be seen through the windshield.
  17. Remove the 4 bolts (1) releasing the instrument panel assembly from the vehicle.
  18. With the aid of an assistant pull the instrument panel assembly (1) rearward in the vehicle until the locator pin on each side clears the opening.
  19. The person on the right side of the instrument panel should pivot the instrument panel inward toward the center of the vehicle until enough clearance is gained to access the HVAC module.
  20. Set the instrument panel assembly down and adequately support it in order to prevent any damage.
  1. With the aid of an assistant perform the following procedures: Lift the instrument panel assembly (1) up and align the locator pins to the openings in the hinge pillars. Push the instrument panel forward until the instrument panel is in vehicle position.
  2. Loosely install the 4 bolts (1) on the outer ends of the instrument panel.
  3. Loosely install the 2 bolts (1) securing the instrument panel carrier support to the cowl.
  4. Tighten the 6 bolts securing the instrument panel to the vehicle to 22 N.m (16 lb ft).
  5. Install the 4 bolts (1) securing the instrument panel upper trim panel to the cowl and tighten to 9 N.m (80 lb in).
  6. On the left side of the instrument panel perform the following procedures: Connect the wire looms securing the wiring harnesses to the left side of the instrument panel. Install the body wiring harness junction block into its bracket. Connect the ground wires to the upper left cowl panel. Tighten the nut to 9 N.m (80 lb in). Connect the electrical connections to the instrument panel left electrical center.
  7. On the right side of the instrument panel perform the following procedures: Connect the wire looms securing the wiring harnesses to the right side of the instrument panel. Connect the radio antennas. Connect the electrical connection for the instrument panel inflatable restraint module. Connect the electrical connections to the instrument panel right electrical center.
  8. Install the instrument panel center support bracket.
  9. Install the right and left body hinge pillar trim panel. Refer to «Body Hinge Pillar Trim Panel Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  10. Remove the instrument panel upper trim panel with windshield defroster nozzle grille. Refer to «Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Except Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) or «Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  11. Install the windshield pillar garnish moldings. Refer to «Windshield Pillar Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  12. Install the instrument panel outer trim covers. Refer to «Instrument Panel Outer Trim Cover Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) or «Instrument Panel Outer Trim Cover Replacement (Except Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  13. Install the front floor console. Refer to «Front Floor Console Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) or «Front Floor Console Replacement (Except Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  14. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/escalade/gmt900-2006-2014/remont/charging-system/#battery-charging-system-and-starting-system) .
  15. Install the front seats. Refer to «Front Seat Replacement - Bucket (with HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Front Seat Replacement - Bucket (without HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  16. Install the steering shaft coupling nut (1) and bolt (2) at the steering column. Tighten the nut and bolt to 50 N.m (37 lb ft).
  17. Remove the J-42640: Pin from the steering column.

J-42640: Steering Column Anti-Rotation Pin

  1. Remove the steering shaft coupling nut (1) and bolt (2) at the steering column.
  2. Remove the front seats. Refer to «Front Seat Replacement - Bucket (with HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Front Seat Replacement - Bucket (without HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  3. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/escalade/gmt900-2006-2014/remont/charging-system/#battery-charging-system-and-starting-system) .
  4. Remove the front floor console. Refer to «Front Floor Console Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  5. Remove the instrument panel outer trim covers. Refer to «Instrument Panel Outer Trim Cover Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  6. Remove the windshield pillar garnish moldings. Refer to «Windshield Pillar Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  7. Remove the instrument panel upper trim panel with windshield defroster nozzle grille. Refer to «Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  8. Tape the ambient light sensor to the instrument panel upper trim panel to ensure it does not fall behind the instrument panel assembly during reinstallation.
  9. Remove the right and left body hinge pillar trim panel. Refer to «Body Hinge Pillar Trim Panel Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  10. Remove the instrument panel center support bracket.
  11. Note location and routing of the instrument panel wiring harness prior to removal in order to ensure proper installation.
  12. On the right side of the instrument panel perform the following procedures: Disconnect the electrical connections to the instrument panel right electrical center. Disconnect the electrical connectors on the right lower hinge pillar. Disconnect the electrical connection for the instrument panel inflatable restraint module. Disconnect the radio antennas. Release the wire looms securing the wiring harnesses to the right side of the instrument panel.
  13. On the left side of the instrument panel perform the following procedures: Disconnect the electrical connections to the instrument panel left electrical center. Disconnect the ground wires from the upper left cowl panel. Remove the body wiring harness junction block from its bracket to allow movement in the body harness. Release the wire looms securing the wiring harnesses to the left side of the instrument panel.
  14. Remove the 4 bolts (1) securing the instrument panel upper trim panel to the cowl.
  15. Remove the 2 bolts (1) securing the instrument carrier support to the cowl. These bolts are located down inside the instrument panel and can be seen through the windshield.
  16. Remove the 4 bolts (1) releasing the instrument panel assembly from the vehicle.
  17. With the aid of an assistant pull the instrument panel assembly (1) rearward in the vehicle until the locator pin on each side clears the opening.
  18. The person on the right side of the instrument panel should pivot the instrument panel inward toward the center of the vehicle until enough clearance is gained to access the HVAC module.
  19. Set the instrument panel assembly down and adequately support it in order to prevent any damage.
  1. With the aid of an assistant perform the following procedures: Lift the instrument panel assembly (1) up and align the locator pins to the openings in the hinge pillars. Push the instrument panel forward until the instrument panel is in vehicle position.
  2. Loosely install the 4 bolts (1) on the outer ends of the instrument panel.
  3. Loosely install the 2 bolts (1) securing the instrument panel carrier support to the cowl.
  4. Tighten the 6 bolts securing the instrument panel to the vehicle to 22 N.m (16 lb ft).
  5. Install the 4 bolts (1) securing the instrument panel upper trim panel to the cowl and tighten to 9 N.m (80 lb in).
  6. On the left side of the instrument panel perform the following procedures: Connect the wire looms securing the wiring harnesses to the left side of the instrument panel. Install the body wiring harness junction block into its bracket. Connect the ground wires to the upper left cowl panel. Tighten the nut to 9 N.m (80 lb in). Connect the electrical connections to the instrument panel left electrical center.
  7. On the right side of the instrument panel perform the following procedures: Connect the wire looms securing the wiring harnesses to the right side of the instrument panel. Connect the radio antennas. Connect the electrical connection for the instrument panel inflatable restraint module. Connect the electrical connectors on the right lower hinge pillar. Connect the electrical connections to the instrument panel right electrical center.
  8. Install the instrument panel center support bracket.
  9. Install the right and left body hinge pillar trim panel. Refer to «Body Hinge Pillar Trim Panel Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  10. Remove the instrument panel upper trim panel with windshield defroster nozzle grille. Refer to «Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  11. Install the windshield pillar garnish moldings. Refer to «Windshield Pillar Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  12. Install the instrument panel outer trim covers. Refer to «Instrument Panel Outer Trim Cover Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  13. Install the front floor console. Refer to «Front Floor Console Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  14. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/escalade/gmt900-2006-2014/remont/charging-system/#battery-charging-system-and-starting-system) .
  15. Install the front seats. Refer to «Front Seat Replacement - Bucket (with HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Front Seat Replacement - Bucket (without HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  16. Install the steering shaft coupling nut (1) and bolt (2) at the steering column. Tighten the nut and bolt to 50 N.m (37 lb ft).
  17. Remove the J-42640: Pin from the steering column.

Scheme 166

Scheme 166: Instrument Panel Carrier Replacement (Except Cadillac)
Scheme 166: Instrument Panel Carrier Replacement (Except Cadillac)
CalloutComponent Name
Preliminary Procedure: Remove the instrument panel compartment assembly (I/P lower trim panel). Refer to Instrument Panel Compartment Door Assembly Replacement (Except Cadillac) .
1Instrument Panel Carrier Assembly Bolt (Qty: 8) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in)
2Instrument Panel Carrier Assembly
CAUTION
Refer to Fastener Caution .

Scheme 167

Scheme 167: Instrument Panel Carrier Support Replacement (Except Cadillac)
Scheme 167: Instrument Panel Carrier Support Replacement (Except Cadillac)
CalloutComponent Name
Preliminary Procedure: Remove the instrument panel carrier assembly. Refer to Instrument Panel Carrier Replacement (Except Cadillac) .
1Instrument Panel Carrier Assembly Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 9 N.m (80 lb in)
2Instrument Panel Carrier Assembly Bolt (Qty: 6) Tighten: 22 N.m (16 lb ft)
3Instrument Panel Carrier Assembly Lower Bolt Tighten: 22 N.m (16 lb ft)
4Instrument Panel Carrier Support Assembly
CAUTION
Refer to Fastener Caution .

Instrument Panel Carrier Support Replacement (Cadillac)

CalloutComponent Name
Preliminary Procedure: Remove the instrument panel lower trim panel assembly. Refer to Instrument Panel Lower Trim Panel Replacement (Cadillac) .
1Instrument Panel Carrier Support Assembly Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Instrument Panel Carrier Support Assembly Bolt (Qty: 6) Tighten: 22 N.m (16 lb ft)
3Instrument Panel Carrier Assembly Lower Bolt Tighten: 22 N.m (16 lb ft)
4Instrument Panel Carrier Support Assembly
CAUTION
Refer to Fastener Caution .

Scheme 168

Scheme 168: Front Floor Console Compartment Bezel Replacement (Except Cadillac)
Scheme 168: Front Floor Console Compartment Bezel Replacement (Except Cadillac)
CalloutComponent Name
1Front Floor Console Compartment Bezel Assembly Tip: Disconnect the electrical connections.
2Retainer Clips (Qty: 4)

Scheme 169

Scheme 169: Front Floor Console Compartment Bezel Replacement (Cadillac)
Scheme 169: Front Floor Console Compartment Bezel Replacement (Cadillac)
CalloutComponent Name
1Heater and A/C Controller Opening Cover Assembly Screw CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Heater and A/C Controller Opening Cover Assembly Tip: Release the retainer clips at the top edge. Lift the heater and A/C controller opening cover upward removing the lower tab from behind the console trim. Disconnect the electrical connections. If replacing the trim cover, transfer all necessary components.
3Retainer Clip (Qty: 4)
CAUTION
Refer to Fastener Caution .

Scheme 170

Scheme 170: Front Floor Console Compartment Door Panel Replacement (Cadillac)
Scheme 170: Front Floor Console Compartment Door Panel Replacement (Cadillac)
CalloutComponent Name
1Front Floor Console Compartment Door Latch Retainer Procedure: Use a flat bladed plastic trim tool and separate the door latch retainer from the folding top stowage compartment lid assembly.
2Front Floor Console Compartment Door Panel Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution .
3Front Floor Console Compartment Door Panel Assembly
CAUTION
Refer to Fastener Caution .

Scheme 171

Scheme 171: Folding Top Stowage Compartment Lid Replacement (Cadillac)
Scheme 171: Folding Top Stowage Compartment Lid Replacement (Cadillac)
CalloutComponent Name
Preliminary Procedure: Remove the front floor console armrest assembly. Refer to Front Floor Console Armrest Removal and Installation (Cadillac) .
1Front Floor Console Compartment Door Latch Retainer Procedure: Use a flat bladed plastic trim tool and separate the door latch retainer from the folding top stowage compartment lid assembly.
2Front Floor Console Compartment Door Panel Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution .
3Front Floor Console Compartment Door Panel Assembly
4Folding Top Stowage Compartment Lid Outer Panel Assembly
CAUTION
Refer to Fastener Caution .

Scheme 172

Scheme 172: Front Floor Console Compartment Door Latch Replacement (Except Cadillac)
Scheme 172: Front Floor Console Compartment Door Latch Replacement (Except Cadillac)
CalloutComponent Name
1Front Floor Console Inner Cover Panel Screw (Qty: 8) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Front Floor Console Inner Panel
3Front Floor Console Latch Inner Screw (Qty: 2) Tighten: 2 N.m (18 lb in)
4Front Floor Console Latch Outer Screw (Qty: 2) Tighten: 2 N.m (18 lb in)
5Front Floor Console Cover Latch Assembly
CAUTION
Refer to Fastener Caution .

Scheme 173

Scheme 173: Front Floor Console Cup Holder Replacement (Except Cadillac)
Scheme 173: Front Floor Console Cup Holder Replacement (Except Cadillac)
CalloutComponent Name
1Front Floor Console Rear Cupholder Assembly Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Front Floor Console Rear Cupholder Assembly
CAUTION
Refer to Fastener Caution .
  1. Open the cupholder assembly.
  2. Remove the screws securing the door to the cupholder.
  3. Remove the door from the cupholder assembly.
  4. Insert a flat bladed tool between the console assembly and the cupholder and release the retaining tab.
  5. Remove the cupholder from the console assembly.
  1. Install the cupholder into the console assembly.
  2. Position the door to the cupholder assembly.
  3. Install the screws securing the cupholder door to the cupholder assembly. Tighten the screws to 2 N.m (18 lb in).

Scheme 174

Scheme 174: Console Rear Trim Plate Replacement
Scheme 174: Console Rear Trim Plate Replacement
CalloutComponent Name
Preliminary Procedures Remove the front floor console compartment bezel. Refer to Front Floor Console Compartment Bezel Replacement (Except Cadillac) or Front Floor Console Compartment Bezel Replacement (Cadillac) . Remove the front floor console rear cupholder. Refer to Front Floor Console Cup Holder Replacement (Except Cadillac) or Front Floor Console Cup Holder Replacement (Cadillac) .
1Front Floor Console Rear Trim Plate Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Front Floor Console Rear Trim Plate Assembly Procedure: Disconnect the electrical connectors.
CAUTION
Refer to Fastener Caution .

Scheme 175

Scheme 175: Front Floor Console Side Trim Panel Replacement - Right Side (Cadillac)
Scheme 175: Front Floor Console Side Trim Panel Replacement - Right Side (Cadillac)
CalloutComponent Name
Preliminary Procedure: Remove the front floor console bezel. Refer to Floor Console Bezel Replacement (Cadillac) .
1Front Floor Console Side Trim Panel Screw CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Front Floor Console Side Trim Panel
3Retainer Clip (Qty: 5)
CAUTION
Refer to Fastener Caution .

Scheme 176

Scheme 176: Front Floor Console Side Trim Panel Replacement - Right Side (Except Cadillac)
Scheme 176: Front Floor Console Side Trim Panel Replacement - Right Side (Except Cadillac)
CalloutComponent Name
1Console Side Trim Panel
2Retainer Clips (Qty: 2)

Scheme 177

Scheme 177: Front Floor Console Side Trim Panel Replacement - Left Side (Except Cadillac)
Scheme 177: Front Floor Console Side Trim Panel Replacement - Left Side (Except Cadillac)
CalloutComponent Name
1Console Side Trim Panel
2Retainer Clips (Qty: 2)

Scheme 178

Scheme 178: Front Floor Console Side Trim Panel Replacement - Left Side (Cadillac)
Scheme 178: Front Floor Console Side Trim Panel Replacement - Left Side (Cadillac)
CalloutComponent Name
Preliminary Procedure: Remove the front floor console bezel. Refer to Floor Console Bezel Replacement (Cadillac) .
1Front Floor Console Side Trim Panel Screw CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Front Floor Console Side Trim Panel
3Retainer Clip (Qty: 5)
CAUTION
Refer to Fastener Caution .

Scheme 179

Scheme 179: Front Floor Console Side Trim Front Panel Replacement - Left Side (Cadillac)
Scheme 179: Front Floor Console Side Trim Front Panel Replacement - Left Side (Cadillac)
CalloutComponent Name
Preliminary Procedure: Remove the knee bolster assembly. Refer to Knee Bolster Replacement (Cadillac) .
1Front Floor Console Side Trim Front Panel Procedure: Use a flat bladed plastic trim tool in order to release the retainer clips securing the trim panel to the front floor console assembly.
2Retainer Clips (Qty: 4)

Scheme 180

Scheme 180: Front Floor Console Side Trim Front Panel Replacement - Right Side (Cadillac)
Scheme 180: Front Floor Console Side Trim Front Panel Replacement - Right Side (Cadillac)
CalloutComponent Name
Preliminary Procedure: Open the instrument panel compartment door.
1Front Floor Console Side Trim Front Panel Procedure: Use a flat bladed plastic trim tool in order to release the retainer clips securing the trim panel to the front floor console assembly.
2Retainer Clips (Qty: 4)

Scheme 181

Scheme 181: Floor Console Bezel Replacement (Cadillac)
Scheme 181: Floor Console Bezel Replacement (Cadillac)
CalloutComponent Name
CAUTION: To prevent component damage, DO NOT use metal tools to remove the trim.
1Front Floor Console Bezel Assembly Tip: Use a flat-bladed plastic trim tool to carefully release the retainer clips along the rear edge of the bezel. Disconnect the electrical connections. Lift the bezel out of the console assembly.
2Retainer Clip (Qty: 4)
CAUTION
To prevent component damage, DO NOT use metal tools to remove the trim.

Scheme 182

Scheme 182: Floor Console Bezel Replacement (Except Cadillac)
Scheme 182: Floor Console Bezel Replacement (Except Cadillac)
CalloutComponent Name
1Front Floor Console Bezel Assembly Tip: Use a flat-bladed plastic trim tool to release the retainer clips along the rear edge of the bezel. Lift the bezel out of the console assembly.
2Retainer Clips (Qty: 4)

Scheme 183

Scheme 183: Front Floor Console Compartment Replacement (Except Cadillac)
Scheme 183: Front Floor Console Compartment Replacement (Except Cadillac)
CalloutComponent Name
Preliminary Procedures Remove the front floor console. Refer to Front Floor Console Replacement (Except Cadillac) . Remove the front floor console armrest assembly. Refer to Front Floor Console Armrest Replacement . Remove the front floor console rear trim panel. Refer to Console Rear Trim Plate Replacement .
1Front Floor Console Compartment Screw (Qty: 14) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Front Floor Console Compartment Assembly
CAUTION
Refer to Fastener Caution .

Scheme 184

Scheme 184: Front Floor Console Replacement (Cadillac)
Scheme 184: Front Floor Console Replacement (Cadillac)
CalloutComponent Name
Preliminary Procedures Remove the 2 front seats. Refer to Front Seat Replacement - Bucket (with HP2) or Front Seat Replacement - Bucket (without HP2) . Remove the right and left front floor consoleside trim front panels. Refer to Front Floor Console Side Trim Front Panel Replacement - Left Side (Cadillac) and Front Floor Console Side Trim Front Panel Replacement - Right Side (Cadillac) . Remove the front floor console bezel. Refer to Floor Console Bezel Replacement (Cadillac) .
1Front Floor Console Assembly Bolt/Screw CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Front Floor Console Assembly Tip: Disconnect the electrical connectors to the console assembly. With the aid of an assistant, remove the console from the vehicle. If replacing the console assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Scheme 185

Scheme 185: Front Floor Console Replacement (Except Cadillac)
Scheme 185: Front Floor Console Replacement (Except Cadillac)
CalloutComponent Name
Preliminary Procedures Remove the 2 front seats. Refer to Front Seat Replacement - Bucket (with HP2) or Front Seat Replacement - Bucket (without HP2) . Remove the right and left front floor console trim panels. Refer to Front Floor Console Side Trim Panel Replacement - Right Side (Except Cadillac) and Front Floor Console Side Trim Panel Replacement - Left Side (Except Cadillac) . Remove the front floor console bezel. Refer to Floor Console Bezel Replacement (Except Cadillac) . Disconnect the electrical connectors to the console assembly.
1Front Floor Console Assembly Tip: With the aid of an assistant, remove the console from the vehicle. When replacing the console assembly, transfer all the necessary components.

Scheme 186

Scheme 186: Front Floor Console Armrest Replacement
Scheme 186: Front Floor Console Armrest Replacement
CalloutComponent Name
1Front Floor Console Compartment Cover Assembly
2Front Floor Console Armrest Assembly Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
3Front Floor Console Armrest Assembly Tip: When replacing the front floor console armrest, inspect the old front floor console armrest hinge assembly for proper operation. If the old hinge assembly is operational and functioning properly, remove and discard the hinge assembly from the new part and use remaining parts of the armrest for replacement, leaving the old hinge in place.
CAUTION
Refer to Fastener Caution .

Scheme 187

Scheme 187: Front Floor Console Armrest Removal and Installation (Cadillac)
Scheme 187: Front Floor Console Armrest Removal and Installation (Cadillac)
CalloutComponent Name
Preliminary Procedure: Remove the front floor console compartment bezel. Refer to Front Floor Console Compartment Bezel Replacement (Cadillac) .
1Front Top Storage Compartment Armrest Screw (Qty: 5) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Front Top Storage Compartment Armrest Assembly
CAUTION
Refer to Fastener Caution .

Scheme 188

Scheme 188: Front Floor Console Armrest Hinge Replacement
Scheme 188: Front Floor Console Armrest Hinge Replacement
CalloutComponent Name
Preliminary Procedure: Remove the Console Assembly. Refer to Front Floor Console Replacement (Cadillac) or Front Floor Console Replacement (Except Cadillac) .
1Front Floor Console Armrest Inner Panel Screw (Qty: 8) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
2Front Floor Console Armrest Inner Panel
3Front Floor Console Armrest to Hinge Screw (Qty: 4) Tighten: 2 N.m (18 lb in)
4Front Floor Console Armrest Assembly
5Front Floor Console Compartment Assembly Refer to Front Floor Console Compartment Replacement (Except Cadillac) .
6Front Floor Console Armrest Hinge to Console Retainer Screw (Qty: 4) Tighten: 2 N.m (18 lb in)
7Front Floor Console Armrest Hinge Assembly
CAUTION
Refer to Fastener Caution .

Scheme 189

Scheme 189: Roof Console Replacement
Scheme 189: Roof Console Replacement
CalloutComponent Name
1Roof Console Dome and Reading Lamp Lens
2Roof Console Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten: 2 N.m (18 lb in)
3Roof Console Assembly CAUTION: Do not exert downward force at the forward or rearward edge of the roof console assembly as irreversible damage will occur. Procedures Grasp the right and left sides of the roof console assembly where indicated with arrows and pull downward using equal force on each side in order to release the retainer clips securing the overhead console assembly to the headlining assembly. Disconnect the electrical connectors. If replacing roof console assembly, transfer all necessary components.
4Roof Console Retainers (Qty: 2)
CAUTION
Refer to Fastener Caution .
CAUTION
Do not exert downward force at the forward or rearward edge of the roof console assembly as irreversible damage will occur.

Scheme 190

Scheme 190: Roof Rear Console Replacement (w/o DVD)
Scheme 190: Roof Rear Console Replacement (w/o DVD)
CalloutComponent Name
1Rear Overhead Console Assembly Tip: Pull down to disengage clips. Disconnect electrical connectors. If replacing rear overhead console, transfer all necessary components.
2Rear Overhead Console Retainer (Qty: 4)

Scheme 191

Scheme 191: Roof Rear Console Replacement (with DVD)
Scheme 191: Roof Rear Console Replacement (with DVD)
CalloutComponent Name
Preliminary Procedure: Remove the video display assembly. Refer to Video Display Replacement (Second Row) or Video Display Replacement (Third Row) .
1Roof Console Assembly Tip: Pull down to disengage the retainer clips. Disconnect the electrical connectors. If replacing the rear roof console, transfer all necessary components.
2Roof Console Retainer (Qty: 4)

More articles — Body & Frame
