Eliminating Unwanted Odors in Vehicles

GM Vehicle Care Odor Eliminator, GM P/N 88861431 (Canadian P/N 88861436), may control or eliminate odors in the interior and luggage compartment areas of GM vehicles. This non-toxic, biodegradable, odorless product has been shown to greatly reduce or remove the following types of odor

  1. Objectionable smells of mold and mildew resulting from vehicle water leaks
  2. Customer created odors, such as smoke

You may safely use GM Vehicle Care Odor Eliminator on fabrics, vinyl, leather, carpet, and sound deadening materials. You may also induce this product into HVAC modules and instrument panel ducts for the control of non-bacterial related odors.

IMPORTANTThis product leaves no residual scent and should not be used as an air freshener.

This product may result in the permanent elimination of an odor and may be preferable to customers whose allergies make them sensitive to perfumes. This product may effectively remove odors when directly contacting the odor source. In cases such as water leaks, use this product with diagnostic procedures to first eliminate the primary cause of the odor. Then use further applications on the residual odor to permanently correct the vehicle condition.

How to Use this Product

  1. Spray GM Vehicle Care Odor Eliminator directly or as an additive with carpet shampoo in steam cleaners.
  2. Do not use on any interior surface that plain water would deteriorate, because this product will have the same effect. Also avoid letting this product come into contact with vinegar or any acidic substance. Acid-based products will hamper the effectiveness of GM Vehicle Care Odor Eliminator.
  3. Complete eight page treatment sheets are enclosed within each case of GM Vehicle Care Odor Eliminator. These treatment instructions range from simple vehicle odor elimination to full step by step procedures for odor removal from water leaks. If lost, contact 800-977-4145 to get a replacement set faxed or e-mailed to your dealership.
  4. Instructions and cautions are printed on the bottle, but additional help is available. If you encounter a persistent or recurring odor, you may call to obtain additional information and usage suggestions. In the USA, call 1-800-955-8591. In Canada, call 1-800-977-4145.

Floor Carpet Drying

If the carpet or the pad or insulator is wet, use the following criteria for drying or for replacing the components

  1. For a 1-piece carpet assembly bonded to a cotton or a fiber padding, replace the entire assembly.
  2. For a 2-piece carpet assembly with a cotton or a fiber padding, replace the padding only. While the carpet is out of the vehicle, dry the carpet using the method described below.
  3. For a 1-piece carpet assembly bonded to a foam padding or attached to a synthetic padding, dry the carpet using the method described below.
  4. For a 2-piece carpet assembly with a synthetic padding, dry the assembly using the method described below.
  5. For a 1-piece carpet assembly with a separate cotton or a fiber padding, replace the cotton or fiber padding. While the carpet is out of the vehicle, dry the carpet using the method described below.

Drying Method

  1. If you observe puddles of liquid on the carpet face, use a wet vacuum to remove the excess moisture.
  2. Blot the face of the carpet with a towel in order to absorb as much moisture as possible.
  3. Point a fan at the affected area and air dry the carpet.

Scheme 114

Scheme 114: Front Floor Panel Carpet Replacement (Extended Wheelbase)
Scheme 114: Front Floor Panel Carpet Replacement (Extended Wheelbase)
CalloutComponent Name
Preliminary Procedures Remove front seats. Refer to Front Seat Replacement - Bucket (with HP2) or Front Seat Replacement - Bucket (without HP2) . Remove rear seats. Refer to Rear Seat Replacement (Tahoe/Yukon/Escalade with Split Bench) or Rear Seat Replacement (Avalanche/Escalade EXT) or Rear Seat Replacement (Tahoe/Yukon/Escalade with Bucket Seat) and Rear Number 2 Seat Replacement (Suburban/Yukon XL) or Rear Number 2 Seat Replacement (Tahoe/Yukon/Escalade) . Remove floor console. Refer to Front Floor Console Replacement (Cadillac) or Front Floor Console Replacement (Except Cadillac) . Remove front center seat. Refer to Front Center Seat Replacement . Remove front seat belt buckles. Refer to Driver or Passenger Seat Belt Buckle Replacement (with HP2) or Driver or Passenger Seat Belt Buckle Replacement (without HP2) . Remove rear seat belt buckles. Refer to Rear Seat Buckle Side Belt Replacement (Bucket) or Rear Seat Buckle Side Belt Replacement (Split Bench) . Remove front door sill plates. Refer to Front Side Door Sill Trim Plate Replacement . Remove rear door sill plates. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove front hinge pillar trim panels. Refer to Body Hinge Pillar Trim Panel Replacement . Remove center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement .
1Front Floor Panel Carpet Assembly Tip: Route carpet openings on left and right over floor duct openings.

Scheme 115

Scheme 115: Front Floor Panel Carpet Replacement (Standard Wheelbase)
Scheme 115: Front Floor Panel Carpet Replacement (Standard Wheelbase)
CalloutComponent Name
Preliminary Procedures Remove front seats. Refer to Front Seat Replacement - Bucket (with HP2) or Front Seat Replacement - Bucket (without HP2) . Remove rear seats. Refer to Rear Seat Replacement (Tahoe/Yukon/Escalade with Split Bench) or Rear Seat Replacement (Avalanche/Escalade EXT) or Rear Seat Replacement (Tahoe/Yukon/Escalade with Bucket Seat) and Rear Number 2 Seat Replacement (Suburban/Yukon XL) or Rear Number 2 Seat Replacement (Tahoe/Yukon/Escalade) . Remove floor console. Refer to Front Floor Console Replacement (Cadillac) or Front Floor Console Replacement (Except Cadillac) . Remove front center seat. Refer to Front Center Seat Replacement . Remove front seat belt buckles. Refer to Driver or Passenger Seat Belt Buckle Replacement (with HP2) or Driver or Passenger Seat Belt Buckle Replacement (without HP2) . Remove rear seat belt buckles. Refer to Rear Seat Buckle Side Belt Replacement (Bucket) or Rear Seat Buckle Side Belt Replacement (Split Bench) . Remove front door sill plates. Refer to Front Side Door Sill Trim Plate Replacement . Remove rear door sill plates. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove front hinge pillar trim panels. Refer to Body Hinge Pillar Trim Panel Replacement . Remove center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement .
1Front Floor Panel Carpet Assembly Tip: Route carpet openings on left and right over floor duct openings.

Scheme 116

Scheme 116: Rear Floor Panel Carpet Replacement (Standard Wheelbase with AS3 and AW2)
Scheme 116: Rear Floor Panel Carpet Replacement (Standard Wheelbase with AS3 and AW2)
CalloutComponent Name
Preliminary Procedures Remove the rear seats. Refer to Rear Seat Replacement (Tahoe/Yukon/Escalade with Split Bench) or Rear Seat Replacement (Avalanche/Escalade EXT) or Rear Seat Replacement (Tahoe/Yukon/Escalade with Bucket Seat) and Rear Number 2 Seat Replacement (Suburban/Yukon XL) or Rear Number 2 Seat Replacement (Tahoe/Yukon/Escalade) . Remove the rear seat belt buckles. Refer to Rear Seat Buckle Side Belt Replacement (Bucket) or Rear Seat Buckle Side Belt Replacement (Split Bench) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the back rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the body side trim panel. Refer to Rear Quarter Trim Panel Replacement - Left Side (Extended Wheelbase w/o E61) or Rear Quarter Trim Panel Replacement - Left Side (Extended Wheelbase w/E61) or Rear Quarter Trim Panel Replacement - Left Side (Standard Wheelbase w/o E61) or Rear Quarter Trim Panel Replacement - Left Side (Standard Wheelbase w/E61) and Rear Quarter Trim Panel Replacement - Right Side (Standard Wheelbase) or Rear Quarter Trim Panel Replacement - Right Side (Extended Wheelbase) .
1Rear Floor Panel Carpet Assembly
2Rear Floor Panel Carpet Escutcheon Tip: Escutcheon to be installed prior to locating carpet to floor studs.

Scheme 117

Scheme 117: Rear Floor Panel Carpet Replacement (Extended Wheelbase)
Scheme 117: Rear Floor Panel Carpet Replacement (Extended Wheelbase)
CalloutComponent Name
Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the rear seats. Refer to Rear Seat Replacement (Tahoe/Yukon/Escalade with Split Bench) or Rear Seat Replacement (Avalanche/Escalade EXT) or Rear Seat Replacement (Tahoe/Yukon/Escalade with Bucket Seat) and Rear Number 2 Seat Replacement (Suburban/Yukon XL) or Rear Number 2 Seat Replacement (Tahoe/Yukon/Escalade) . Remove the rear seat belt buckles. Refer to Rear Seat Buckle Side Belt Replacement (Bucket) or Rear Seat Buckle Side Belt Replacement (Split Bench) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the back rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the body side trim panel. Refer to Rear Quarter Trim Panel Replacement - Left Side (Extended Wheelbase w/o E61) or Rear Quarter Trim Panel Replacement - Left Side (Extended Wheelbase w/E61) or Rear Quarter Trim Panel Replacement - Left Side (Standard Wheelbase w/o E61) or Rear Quarter Trim Panel Replacement - Left Side (Standard Wheelbase w/E61) and Rear Quarter Trim Panel Replacement - Right Side (Standard Wheelbase) or Rear Quarter Trim Panel Replacement - Right Side (Extended Wheelbase) .
1Rear Floor Panel Carpet Assembly
2Rear Floor Panel Carpet Escutcheon Tip: Escutcheon to be installed prior to locating carpet to floor studs.

Scheme 118

Scheme 118: Rear Floor Panel Carpet Replacement (Standard Wheelbase w/o AS3 and AW2)
Scheme 118: Rear Floor Panel Carpet Replacement (Standard Wheelbase w/o AS3 and AW2)
CalloutComponent Name
Preliminary Procedures Remove the rear seats. Refer to Rear Seat Replacement (Tahoe/Yukon/Escalade with Split Bench) or Rear Seat Replacement (Avalanche/Escalade EXT) or Rear Seat Replacement (Tahoe/Yukon/Escalade with Bucket Seat) and Rear Number 2 Seat Replacement (Suburban/Yukon XL) or Rear Number 2 Seat Replacement (Tahoe/Yukon/Escalade) . Remove the rear seat belt buckles. Refer to Rear Seat Buckle Side Belt Replacement (Bucket) or Rear Seat Buckle Side Belt Replacement (Split Bench) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the back rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the body side trim panel. Refer to Rear Quarter Trim Panel Replacement - Left Side (Extended Wheelbase w/o E61) or Rear Quarter Trim Panel Replacement - Left Side (Extended Wheelbase w/E61) or Rear Quarter Trim Panel Replacement - Left Side (Standard Wheelbase w/o E61) or Rear Quarter Trim Panel Replacement - Left Side (Standard Wheelbase w/E61) and Rear Quarter Trim Panel Replacement - Right Side (Standard Wheelbase) or Rear Quarter Trim Panel Replacement - Right Side (Extended Wheelbase) .
1Cargo Tie Down Loop Bolt CAUTION: Refer to Fastener Caution . Tighten: 35 N.m (25 lb ft)
2Cargo Tie Down Loop Assembly
3Rear Floor Panel Carpet Assembly
CAUTION
Refer to Fastener Caution .

Scheme 119

Scheme 119: Headlining Trim Panel Replacement (LWB w/CJ3)
Scheme 119: Headlining Trim Panel Replacement (LWB w/CJ3)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the body rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the rear overhead console. Refer to Roof Rear Console Replacement (w/o DVD) or Roof Rear Console Replacement (with DVD) . Remove the rear headliner trim panel assembly. Refer to Headlining Rear Trim Panel Replacement (Extended Wheelbase) . Place the rear seats in the stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer (Qty: 4)
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 120

Scheme 120: Headlining Trim Panel Replacement (LWB w/CJ2)
Scheme 120: Headlining Trim Panel Replacement (LWB w/CJ2)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the body rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the map/dome lamp. Refer to Dome Lamp Replacement . Remove the rear headliner trim panel assembly. Refer to Headlining Rear Trim Panel Replacement (Extended Wheelbase) . Place the rear seats in the stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer (Qty: 4)
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 121

Scheme 121: Headlining Trim Panel Replacement (Avalanche/Escalade EXT w/CF5 and U42)
Scheme 121: Headlining Trim Panel Replacement (Avalanche/Escalade EXT w/CF5 and U42)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the headliner trim panel molding. Refer to Rear Upper Garnish Molding Replacement (Avalanche/Escalade EXT) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the sunroof panel window molding. Refer to Sunroof Panel/Window Garnish Molding Replacement (Crew Cab) . Remove the rear overhead console. Refer to Video Display Replacement (Second Row) or Video Display Replacement (Third Row) . Place the rear seats in stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer (Qty: 2)
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 122

Scheme 122: Headlining Trim Panel Replacement (Avalanche/Escalade EXT w/CF5 w/o U42)
Scheme 122: Headlining Trim Panel Replacement (Avalanche/Escalade EXT w/CF5 w/o U42)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the headliner trim panel molding. Refer to Rear Upper Garnish Molding Replacement (Avalanche/Escalade EXT) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the sunroof panel window molding. Refer to Sunroof Panel/Window Garnish Molding Replacement (Crew Cab) . Remove the map/dome lamp. Refer to Dome Lamp Replacement . Place the rear seats in stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer (Qty: 2)
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 123

Scheme 123: Headlining Trim Panel Replacement (Avalanche w/CJ2 w/o CF5 and U42)
Scheme 123: Headlining Trim Panel Replacement (Avalanche w/CJ2 w/o CF5 and U42)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the headliner trim panel molding. Refer to Rear Upper Garnish Molding Replacement (Avalanche/Escalade EXT) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the map/dome lamp. Refer to Dome Lamp Replacement . Place the rear seats in stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer (Qty: 2)
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 124

Scheme 124: Headlining Trim Panel Replacement (Avalanche/Escalade EXT w/CJ3)
Scheme 124: Headlining Trim Panel Replacement (Avalanche/Escalade EXT w/CJ3)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the headliner trim panel molding. Refer to Rear Upper Garnish Molding Replacement (Avalanche/Escalade EXT) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the map/dome lamp. Refer to Dome Lamp Replacement . Place the rear seats in stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer (Qty: 2)
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 125

Scheme 125: Headlining Trim Panel Replacement (Avalanche/Escalade EXT w/U24 w/o CF5)
Scheme 125: Headlining Trim Panel Replacement (Avalanche/Escalade EXT w/U24 w/o CF5)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the headliner trim panel molding. Refer to Rear Upper Garnish Molding Replacement (Avalanche/Escalade EXT) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the rear overhead console. Refer to Video Display Replacement (Second Row) or Video Display Replacement (Third Row) . Place the rear seats in stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer (Qty: 2)
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 126

Scheme 126: Headlining Trim Panel Replacement (LWB w/CF5 and U42)
Scheme 126: Headlining Trim Panel Replacement (LWB w/CF5 and U42)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the body rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the sunroof panel window molding. Refer to Sunroof Panel/Window Garnish Molding Replacement (Crew Cab) . Remove the rear overhead console. Refer to Video Display Replacement (Second Row) or Video Display Replacement (Third Row) . Place the rear seats in the stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer (Qty: 4)
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 127

Scheme 127: Headlining Trim Panel Replacement (SWB w/U42 w/o CF5)
Scheme 127: Headlining Trim Panel Replacement (SWB w/U42 w/o CF5)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the body rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the rear overhead console. Refer to Video Display Replacement (Second Row) or Video Display Replacement (Third Row) . Place the rear seats in the stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 128

Scheme 128: Headlining Trim Panel Replacement (SWB w/o CF5 and U42)
Scheme 128: Headlining Trim Panel Replacement (SWB w/o CF5 and U42)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the body rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the map/dome lamp. Refer to Dome Lamp Replacement . Place the rear seats in the stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 129

Scheme 129: Headlining Trim Panel Replacement (SWB w/CJ3)
Scheme 129: Headlining Trim Panel Replacement (SWB w/CJ3)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the body rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the rear overhead console. Refer to Roof Rear Console Replacement (w/o DVD) or Roof Rear Console Replacement (with DVD) . Place the rear seats in the stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 130

Scheme 130: Headlining Trim Panel Replacement (SWB w/CF5 w/o U42)
Scheme 130: Headlining Trim Panel Replacement (SWB w/CF5 w/o U42)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the body rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the sunroof panel window molding. Refer to Sunroof Panel/Window Garnish Molding Replacement (Crew Cab) . Remove the map/dome lamp. Refer to Dome Lamp Replacement . Place the rear seats in the stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Headlining Trim Panel Replacement (SWB w/CF5 and U42)

WARNINGDo not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTIONUse care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTIONIf a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Removal Procedure

  1. Disable the roof rail SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/escalade/gmt900-2006-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
  2. Remove the front assist handle. Refer to «Front Assist Handle Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  3. Remove the windshield garnish molding. Refer to «Windshield Pillar Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  4. Remove the sunshade assembly and the sunshade retainers. Refer to «Sunshade Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  5. Remove the roof console assembly. Refer to «Roof Console Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  6. Remove the front door sill plate. Refer to «Front Side Door Sill Trim Plate Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  7. Remove the rear door sill plate. Refer to «Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) or «Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  8. Remove the center pillar lower molding. Refer to «Center Pillar Lower Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  9. Remove the center pillar upper molding. Refer to «Center Pillar Upper Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  10. Remove the lock pillar molding. Refer to «Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) or «Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) or «Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  11. Remove the back body opening molding. Refer to «Rear Door Upper Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  12. Remove the body rear corner upper molding. Refer to «Body Rear Corner Garnish Molding Replacement - Right Side»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) and «Body Rear Corner Garnish Molding Replacement - Left Side (w/E61)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) or «Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  13. Remove the coat hooks. Refer to «Coat Hook Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  14. Remove the sunroof panel window molding. Refer to «Sunroof Panel/Window Garnish Molding Replacement (Crew Cab)»(/cadillac/escalade/gmt900-2006-2014/remont/sun-rooft-topconvertible-top/#sunroof-system) .
  15. Remove the rear overhead console. Refer to «Video Display Replacement (Second Row)»(/cadillac/escalade/gmt900-2006-2014/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems) or «Video Display Replacement (Third Row)»(/cadillac/escalade/gmt900-2006-2014/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems) .
  16. Place the rear seats in the stowed position.
  17. Remove the front seat headrest.
  18. Remove the instrument panel (I/P) upper trim pad. Refer to «Instrument Panel Upper Trim Panel Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) or «Instrument Panel Upper Trim Panel Replacement (Except Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  19. Remove the roof assist handles. Refer to «Front Assist Handle Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) and «Roof Rail Rear Assist Handle Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  20. Remove the front seat. Refer to «Front Seat Replacement - Bucket (with HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Front Seat Replacement - Bucket (without HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  21. Remove the second row right seat. Refer to «Rear Seat Replacement (Tahoe/Yukon/Escalade with Split Bench)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Rear Seat Replacement (Avalanche/Escalade EXT)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Rear Seat Replacement (Tahoe/Yukon/Escalade with Bucket Seat)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  22. Remove the third row right seat. Refer to «Rear Number 2 Seat Replacement (Suburban/Yukon XL)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Rear Number 2 Seat Replacement (Tahoe/Yukon/Escalade)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  23. Disconnect the electrical harness retainers from the windshield pillars.
  24. Disconnect the electrical harness from the BEC under the steering column. Route the wires out.
  25. Remove the right side rear quarter trim. Refer to «Rear Quarter Trim Panel Replacement - Right Side (Standard Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) or «Rear Quarter Trim Panel Replacement - Right Side (Extended Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  26. Remove the rearview mirror trim and disconnect the electrical connectors. Refer to «Inside Rearview Mirror Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/mirrors/#mirror-system) .
  27. Remove the sunshade anchor. Refer to «Sunshade Anchor Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  28. Note routing of the wire harness and remove the headliner trim panel assembly (3).

Installation Procedure

  1. Install the headliner trim panel assembly (3).
  2. Install the sunshade anchor. Refer to «Sunshade Anchor Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  3. Install the rearview mirror trim and connect the electrical connectors. Refer to «Inside Rearview Mirror Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/mirrors/#mirror-system) .
  4. Install the right side rear quarter trim. Refer to «Rear Quarter Trim Panel Replacement - Right Side (Standard Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) or «Rear Quarter Trim Panel Replacement - Right Side (Extended Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  5. Connect the electrical harness to the BEC under the steering column.
  6. Connect the electrical harness retainers to the windshield pillars.
  7. Install the third row right seat. Refer to «Rear Number 2 Seat Replacement (Suburban/Yukon XL)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Rear Number 2 Seat Replacement (Tahoe/Yukon/Escalade)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  8. Install the second row right seat. Refer to «Rear Seat Replacement (Tahoe/Yukon/Escalade with Split Bench)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Rear Seat Replacement (Avalanche/Escalade EXT)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Rear Seat Replacement (Tahoe/Yukon/Escalade with Bucket Seat)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  9. Install the front seat. Refer to «Front Seat Replacement - Bucket (with HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) or «Front Seat Replacement - Bucket (without HP2)»(/cadillac/escalade/gmt900-2006-2014/remont/seats/#seat-hardware-seat-trim-and-upholstery) .
  10. Install the roof assist handles. Refer to «Front Assist Handle Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) and «Roof Rail Rear Assist Handle Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  11. Install the I/P upper trim pad. Refer to «Instrument Panel Upper Trim Panel Replacement (Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) or «Instrument Panel Upper Trim Panel Replacement (Except Cadillac)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  12. Install the front seat headrest.
  13. Install the rear overhead console. Refer to «Video Display Replacement (Second Row)»(/cadillac/escalade/gmt900-2006-2014/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems) or «Video Display Replacement (Third Row)»(/cadillac/escalade/gmt900-2006-2014/remont/entertainment-systems/#cellular-systems-entertainment-systems-navigation-systems) .
  14. Install the sunroof panel window molding. Refer to «Sunroof Panel/Window Garnish Molding Replacement (Crew Cab)»(/cadillac/escalade/gmt900-2006-2014/remont/sun-rooft-topconvertible-top/#sunroof-system) .
  15. Install the coat hooks. Refer to «Coat Hook Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  16. Install the body rear corner upper molding. Refer to «Body Rear Corner Garnish Molding Replacement - Right Side»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) and «Body Rear Corner Garnish Molding Replacement - Left Side (w/E61)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) or «Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  17. Install the back body opening molding. Refer to «Rear Door Upper Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  18. Install the lock pillar molding. Refer to «Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) or «Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) or «Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  19. Install the center pillar upper molding. Refer to «Center Pillar Upper Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  20. Install the center pillar lower molding. Refer to «Center Pillar Lower Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  21. Install the rear door sill plate. Refer to «Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) or «Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase)»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  22. Install the front door sill plate. Refer to «Front Side Door Sill Trim Plate Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  23. Install the roof console assembly. Refer to «Roof Console Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  24. Install the sunshade assembly and the sunshade retainers. Refer to «Sunshade Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  25. Install the windshield garnish molding. Refer to «Windshield Pillar Garnish Molding Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  26. Install the front assist handle. Refer to «Front Assist Handle Replacement»(/cadillac/escalade/gmt900-2006-2014/remont/exteriorinterior-trim/#interior-trim-system-and-paneling) .
  27. Enable the roof rail SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/escalade/gmt900-2006-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Scheme 131

Scheme 131: Headlining Trim Panel Replacement (LWB w/U42 w/o CF5)
Scheme 131: Headlining Trim Panel Replacement (LWB w/U42 w/o CF5)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the body rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the rear overhead console. Refer to Video Display Replacement (Second Row) or Video Display Replacement (Third Row) . Remove the rear headliner trim panel assembly. Refer to Headlining Rear Trim Panel Replacement (Extended Wheelbase) . Place the rear seats in the stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer (Qty: 4)
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Headlining Trim Panel Replacement (LWB w/CF5 w/o U42)

CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the front assist handle. Refer to Front Assist Handle Replacement . Remove the windshield garnish molding. Refer to Windshield Pillar Garnish Molding Replacement . Remove the sunshade assembly and the sunshade retainers. Refer to Sunshade Replacement . Remove the roof console assembly. Refer to Roof Console Replacement . Remove the front door sill plate. Refer to Front Side Door Sill Trim Plate Replacement . Remove the rear door sill plate. Refer to Rear Side Door Sill Trim Plate Replacement (Extended Wheelbase) or Rear Side Door Sill Trim Plate Replacement (Standard Wheelbase) . Remove the center pillar lower molding. Refer to Center Pillar Lower Garnish Molding Replacement . Remove the center pillar upper molding. Refer to Center Pillar Upper Garnish Molding Replacement . Remove the lock pillar molding. Refer to Body Lock Pillar Garnish Molding Replacement (Standard Wheelbase) or Body Lock Pillar Garnish Molding Replacement (Avalanche/Escalade EXT) or Body Lock Pillar Garnish Molding Replacement (Extended Wheelbase) . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the body rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the coat hooks. Refer to Coat Hook Replacement . Remove the sunroof panel window molding. Refer to Sunroof Panel/Window Garnish Molding Replacement (Crew Cab) . Remove the map/dome lamp. Refer to Dome Lamp Replacement . Place the rear seats in the stowed position. Remove the front seat headrest.
1Headliner Trim Panel Retainer (Qty: 4)
2Sunshade Anchor (Qty: 2) Refer to Sunshade Anchor Replacement .
3Headliner Trim Panel Assembly Procedure Prior to removal, note the routing of the wire harness to aid in reassembly and to ensure proper installation. Disconnect the electrical connectors. Tip: When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

Scheme 132

Scheme 132: Headlining Rear Trim Panel Replacement (Extended Wheelbase)
Scheme 132: Headlining Rear Trim Panel Replacement (Extended Wheelbase)
CalloutComponent Name
WARNING: Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury. CAUTION: Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced. CAUTION: If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced. Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the back body opening molding. Refer to Rear Door Upper Garnish Molding Replacement . Remove the body rear corner upper molding. Refer to Body Rear Corner Garnish Molding Replacement - Right Side and Body Rear Corner Garnish Molding Replacement - Left Side (w/E61) or Body Rear Corner Garnish Molding Replacement - Left Side (w/o E61) . Remove the coat hooks. Refer to Coat Hook Replacement . Place the rear seats in the stowed position.
1Rear Headliner Trim Panel Retainer (Qty: 2) Procedure Install push pin retainer to back body opening frame. Install push pin retainer to roof bow. Tip: Retainers are one time use only. When installing a new headliner, tape any unused connector to the headliner with a high adhesive tape.
2Rear Headliner Trim Panel Assembly
WARNING
Do not attempt to repair or alter the head impact energy-absorbing material glued to the headliner or to the garnish trims. If the material is damaged, replace the headliner and/or the garnish trim. Failure to do so could result in personal injury.
CAUTION
Use care when working around the head curtain inflator module. Sharp tools may puncture the curtain airbag. If the head curtain inflator module is damaged in any way, it must be replaced.
CAUTION
If a vehicle is equipped with a head curtain inflator module ensure that the inflator module and tether are undamaged. If tether or curtain airbag are damaged in any way, they must be replaced.

More articles — Body & Frame
