Engine Mount Inspection Cadillac ELR I

Mechanical 2 illustrations ~138 words
  1. Install the engine support fixture. Refer to «Engine Support Fixture»(ref-636500-S28245195062014070700000) .
  2. Observe the engine mount while raising the engine. Raising the engine removes the weight from the engine mount and creates slight tension on the rubber.
  3. Replace the engine mount if the engine mount exhibits any of the following conditions: The hard rubber is covered with heat check cracks. The rubber is separated from the metal plate of the engine mount. The rubber is split through the center of the engine mount.
  4. For engine mount replacement, refer to «Engine Mount Replacement - Right Side»(ref-636500-S41847144872014070700000) .
  5. For rear transmission mount replacement, refer to «Transmission Rear Mount Replacement»(ref-636531-S22651770512014070700000) .
  6. For left transmission mount replacement, refer to «Transmission Mount Replacement - Left Side»(ref-636531-S41246263242014070700000) .

Scheme 10

Scheme 10: Engine Mount Bracket Replacement - Right Side
CalloutComponent Name
Preliminary Procedures Remove the engine mount. Refer to Engine Mount Replacement - Right Side . Remove the front wheelhouse liner. Refer to Front Wheelhouse Liner Replacement . Disconnect and reposition the drive motor battery coolant cooler inlet hose assembly as needed. Refer to Drive Motor Battery Coolant Cooler Inlet Hose Assembly Replacement .
1Engine Mount Bracket Fastener (Qty: 2) CAUTION: This component uses torque-to-yield bolts. When servicing this component do not reuse the bolts, New torque-to-yield bolts must be installed. Reusing used torque-to-yield bolts will not provide proper bolt torque and clamp load. Failure to install NEW torque-to-yield bolts may lead to engine damage. CAUTION: Refer to Fastener Caution . Procedure Raise and lower the engine as needed to access the bolts. Hand start then tighten all three engine mount bracket fasteners in sequence as labeled 1,2,3. Tighten First Pass: 60 (44 lb ft) Final Pass: Tighten the bolt an additional 45-60 degrees.
2Engine Mount Bracket Fastener Tighten First Pass: 60 (44 lb ft) Final Pass: Tighten the bolt an additional 45-60 degrees.
3Engine Mount Bracket
CAUTION
This component uses torque-to-yield bolts. When servicing this component do not reuse the bolts, New torque-to-yield bolts must be installed. Reusing used torque-to-yield bolts will not provide proper bolt torque and clamp load. Failure to install NEW torque-to-yield bolts may lead to engine damage.
CAUTION
Refer to Fastener Caution .

Engine Mount Bracket Replacement - Right Side

Scheme 11

Scheme 11: Engine Support Fixture
CalloutComponent Name
Preliminary Procedure Remove the air cleaner resonator outlet duct. Refer Air Cleaner Resonator Outlet Duct Replacement . Remove the ground wire retaining bolt and wire by heater water auxiliary pump inlet hose. Special Tools EN-43405 Engine Support Fixture Adapter EN-28467-1A Cross Bracket EN-28467-5A Strut Tower Support Assembly EN-28467-8A Hook Assembly EN-28467-2A Radiator Tube Shelf Assembly EN-36857 Engine Lift Bracket For equivalent regional tools, refer to Special Tools .
1Engine Support Fixture Adapter Leg (Qty: 2) Procedure Install the bracket to fender frame. Do not install on top of fender lip.
2Main Support Beam
3Cross Bracket (Qty: 2)
4Strut Tower Support Assembly (Qty: 2) Procedure Adjust the length of the strut tower support assembly.
5Radiator Tube Shelf Assembly (Qty: 2)
6Engine Lift Bracket Procedure Use a grade 10.9 bolt to install the engine lift bracket.
7Hook Assembly (Qty: 2)

Engine Support Fixture
