Engine Mechanical - 6.2l - Component Locator Cadillac CTS II

Mechanical 10 illustrations

Scheme 167

Scheme 167: Disassembled Views
CalloutComponent Name
1Evaporative (EVAP) Emission Canister Purge Tube
2Positive Crankcase Ventilation (PCV) Tube - Fresh Air
3Supercharger Cover Bolts
4Supercharger Cover
5Supercharger Cover Seal
6Supercharger Insulator Seal
7Supercharger Bolts
8Supercharger
9Supercharger Gasket
10Supercharger Gasket Rivet
11Engine Coolant Air Bleed Plug
12Engine Coolant Air Bleed Pipe Bolt
13Engine Coolant Air Bleed Pipe
14Engine Coolant Air Bleed Pipe Seal
15Engine Coolant Air Bleed Pipe
16Valley Cover Bolt
17Engine Oil Pressure Sensor
18Valley Cover
19PCV Hose - Dirty Air
20Valley Cover Seal
21Valley Cover Gasket
22Engine Block

Scheme 168

Scheme 168
CalloutComponent Name
1Oil Cap
2Oil Cap O-ring Seal
3Oil Fill Tube
4Oil Fill Tube O-ring Seal
5Valve Rocker Arm Cover Gasket
6Valve Rocker Arm Cover
7Positive Crankcase Ventilation (PCV) Tube - Fresh Air
8Bolt
9Ignition Coil
10Spark Plug Wire
11Bolt
12Bolt Grommet
13Valve Rocker Arm Cover
14Valve Rocker Arm Cover Gasket
15Valve Stem Key
16Valve Spring Cap
17Valve Spring
18Valve Stem Oil Seal
19Spark Plug
20Cylinder Head Bolt - M11
21Cylinder Head Bolt - M8
22Cylinder Head
23Cylinder Head Gasket
24Cylinder Head Locating Pin
25Cylinder Head Plug
26Coolant Temperature Sensor
27Exhaust Valve
28Intake Valve
29Exhaust Manifold Gasket
30Exhaust Manifold
31Exhaust Manifold Heat Shield
32Exhaust Manifold Heat Shield Bolt
33Exhaust Manifold Bolt
34Bolt
35Valve Rocker Arm
36Valve Rocker Arm Pivot Support
37Valve Pushrod
38Bolt
39Valve Lifter Guide
40Valve Lifter
41Engine Block

Scheme 169

Scheme 169
CalloutComponent Name
1Bolt
2Water Inlet Housing
3Water Inlet Seal
4Engine Coolant Thermostat
5Water Pump
6Water Pump Gasket
7Bolt
8Bolt
9Balancer Weight - Crankshaft Balancer - Manual Transmission
10Crankshaft Balancer
11Crankshaft Front Oil Seal
12Camshaft Position (CMP) Sensor Wire Harness Bolt
13CMP Sensor Wire Harness
14CMP Sensor Bolt
15CMP Sensor Seal
16CMP Sensor
17Bolt
18Engine Front Cover
19Engine Front Cover Gasket
20Bolt
21Timing Chain Tensioner
22Timing Chain
23Crankshaft Balancer Washer
24Crankshaft Sprocket
25Bolt
26Camshaft Sprocket
27Bolt
28Camshaft Retainer
29Camshaft Sprocket Locating Pin
30Camshaft
31Camshaft Bearings
32Engine Block
33Oil Pump Suction Pipe Nut
34Oil Pump Suction Pipe
35Oil Pump Suction Pipe Bolt
36Oil Pump O-ring Seal
37Oil Pressure Relief Valve Bore Plug
38Oil Pressure Relief Valve Spring
39Oil Pressure Relief Valve
40Oil Pump Driven Gear
41Oil Pump Drive Gear
42Oil Pump Cover
43Oil Pump Cover Bolt
44Oil Pump
45Oil Pump Bolt

Scheme 170

Scheme 170
CalloutComponent Name
1Engine Block
2Crankshaft Rear Oil Seal Housing Gasket
3Crankshaft Rear Oil Seal Housing
4Bolt
5Crankshaft Rear Oil Seal
6Flexplate - Automatic Transmission
7Transmission Pilot Bearing - Manual Transmission
8Balance Weight - Flywheel - Manual Transmission
9Flywheel - Manual Transmission
10Bolt
11Clutch Pressure Plate Locating Pin - Manual Transmission
12Clutch Drive Plate - Manual Transmission
13Clutch Pressure Plate - Manual Transmission
14Bolt

Scheme 171

Scheme 171
CalloutComponent Name
1Engine Block
2Bolt
3Connecting Rod Cap
4Connecting Rod Bearing
5Connecting Rod
6Piston Pin Retainer
7Piston Pin
8Piston
9Piston Ring Set
10Crankshaft Bearing
11Crankshaft Bearing - Thrust
12Crankshaft Sprocket Key
13Crankshaft
14Transmission Pilot Bearing - Manual Transmission
15Crankshaft Hole Plug
16Crankshaft Bearing Cap Locating Pin
17Crankshaft Bearing Cap
18Bolt - M8
19Stud - M10
20Bolt - M10
21Crankshaft Oil Deflector
22Crankshaft Oil Deflector Nut
23Oil Pan Gasket
24Oil Pump Suction Pipe Seal
25Oil Pump Suction Pipe
26Bolt
27Engine Cover - Right
28Oil Pump Suction Pipe Bolt
29Oil Pan Baffle Bolt
30Oil Pump Suction Pipe Nut
31Oil Pan Baffle
32Engine Oil Level Sensor
33Engine Oil Level Sensor Seal
34Oil Pan
35Oil Pan Bolt
36Oil Pan Drain Plug
37Oil Pan Bolt
38Oil Filter Fitting
39Oil Filter
40Engine Oil Cooler Coolant Fitting
41Engine Oil Cooler Housing
42Engine Oil Cooler Gasket
43Engine Oil Cooler-to-Oil Pan Bolt - M6
44Engine Oil Cooler Core Seal
45Engine Oil Cooler-to-Oil Pan Bolt - M8
46Engine Oil Cooler Core
47Engine Oil Cooler Core-to-Housing Bolt
48Oil Pan Cover - Left
49Bolt

Scheme 172

Scheme 172
CalloutComponent Name
1Engine Block Oil Gallery Plug - Front
2Engine Block Oil Gallery Plug Seal
3Engine Block Oil Gallery Plug - Side
4Engine Block Coolant Heater Seal
5Engine Block Coolant Heater
6Knock Sensor
7Bolt
8Engine Block Oil Gallery Plug - Side
9Engine Block Oil Gallery Plug Seal
10Engine Block
11Transmission Locating Pin
12Engine Block Oil Gallery Plug Seal
13Engine Block Oil Gallery Plug - Rear
14Piston Oil Nozzle
15Crankshaft Position (CKP) Sensor Seal
16CKP Sensor
17CKP Sensor Bolt
18Engine Block Coolant Drain Hole Plug Seal
19Engine Block Coolant Drain Hole Plug - Side

Scheme 173

Scheme 173
CalloutComponent Name
1Charge Air Cooler Cover
2Charge Air Cooler Cover Bolt
3Barometric Pressure Sensor Bolt
4Barometric Pressure Sensor
5Barometric Pressure Sensor Seal
6Isolator Pad Bolt
7Isolator Pad
8Charge Air Cooler Coolant Pipe Seal
9Charge Air Cooler Coolant Outlet Pipe Assembly Seal
10Charge Air Cooler Coolant Outlet Pipe Assembly
11Charge Air Cooler Coolant Outlet Pipe Assembly Bolt
12Supercharger Air Outlet Pressure Sensor Bolt
13Supercharger Air Outlet Pressure Sensor
14Supercharger Air Outlet Pressure Sensor Seal
15Intake Air Temperature Sensor
16Charge Air Cooler
17Charge Air Cooler Bolt
18Charge Air Cooler Cover Seal

Scheme 174

Scheme 174
CalloutComponent Name
1Fuel Injector Wiring Harness
2Multiport Fuel Injection Fuel Rail
3Fuel Rail Service Port Cap
4Fuel Injector Seal
5Fuel Injector Retainer
6Fuel Injector
7Fuel Injection Fuel Rail Bolt
8Fuel Injector Fuel Rail Stud
9Fuel Injector Wiring Harness
10Charge Air Cooler Insulator
11Fuel Injector Wiring Harness Connector Bracket - Right
12Fuel Injector Wiring Harness Connector Bracket Bolt
13Supercharger Bolt
14Fuel Injector Wiring Harness Connector Bracket - Left
15Supercharger
16Intake Manifold Gasket
17Intake Manifold Gasket Rivet
18Throttle Body Bolt
19Throttle Body
20Throttle Body Seal
21Charge Air Bypass Valve Vacuum Tube
22Supercharger Bypass Actuator
23Charge Air Bypass Valve w/Bracket
24Supercharger Bypass Actuator Bolt
25Charge Air Bypass Valve Bolt
26Charge Air Bypass Valve Tube
27Bypass Valve Actuator Tube
28Evaporative Emission Canister Purge Valve
29Evaporative Emission Canister Purge Valve Seal
30Supercharger Inlet Air Pressure Sensor Bolt
31Supercharger Inlet Air Pressure Sensor
32Supercharger Inlet Air Pressure Sensor Seal

Scheme 175

Scheme 175
CalloutComponent Name
408Bolt
409Oil Pump Housing Cover
410Oil Pump Drive Gear
412Oil Pump Driven Gear
413Oil Pump
414Oil Pump Pressure Relief Valve
415Oil Pump Pressure Relief Valve Spring
416Oil Pump Housing Plug

Scheme 176

Scheme 176: Engine Identification

The vehicle identification number (VIN) is located on the left side rear of the engine block (1) and is typically a 9 digit number stamped or laser-etched onto the engine at the vehicle assembly plant.

  1. The first digit identifies the division.
  2. The second digit identifies the model year.
  3. The third digit identifies the assembly plant.
  4. The fourth through ninth digits are the last 6 digits of the VIN.
