Instrument Panel Trim and Console Trim Cadillac ATS I

Exterior/interior Trim 40 illustrations ~2405 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Driver Knee Bolster Reinforcement Fasteners9 N.m80 lb in
Front Floor Console Armrest Hinge Fasteners9 N.m80 lb in
Front Floor Console Bracket Fasteners9 N.m80 lb in
Front Floor Console Fasteners9 N.m80 lb in
Heater and Air Conditioner Evaporator and Blower Module Fasteners9 N.m80 lb in
Instrument Panel Inflatable Restraint Module Fastener9 N.m80 lb in
Instrument Panel Tie Bar Fasteners22 N.m16 lb ft
Lower Instrument Panel Tie Bar Fasteners22 N.m16 lb ft
Upper Instrument Panel Tie Bar Fastener22 N.m16 lb ft

Fastener Tightening Specifications

Scheme 92

Scheme 92: Instrument Panel Lower Trim Panel Insulator Replacement (Left Side)
Scheme 92: Instrument Panel Lower Trim Panel Insulator Replacement (Left Side)
CalloutComponent Name
Preliminary Procedure Remove the left front floor console extension panel. Refer to Front Floor Console Extension Panel Replacement - Left Side .
1Instrument Panel Insulator Bolt (Qty: 4) CAUTION: Refer to Fastener Caution .
2Instrument Panel Lower Trim Panel Insulator - Left Side Procedure Use a flat-bladed plastic trim tool to release the retainer and tabs securing the insulator to the instrument carrier. Disconnect electrical connection. Unclip the hood release handle from the insulator panel.
CAUTION
Refer to Fastener Caution .

Instrument Panel Lower Trim Panel Insulator Replacement (Left Side)

Scheme 93

Scheme 93: Instrument Panel Lower Trim Panel Insulator Replacement (Right Side)
Scheme 93: Instrument Panel Lower Trim Panel Insulator Replacement (Right Side)
CalloutComponent Name
Preliminary Procedures Remove the instrument panel insulator hole cover. Refer to Instrument Panel Insulator Hole Cover Replacement . Remove the heater and air conditioning remote control. Refer to Heater and Air Conditioning Remote Control Replacement . NOTE: When removing the instrument panel lower trim panel insulator for any reason, it is required that the connector to the HVAC module be disconnected. If the vehicle battery has NOT been disconnected, when reinstalling / reconnecting the module, the BROWN J2 connector must be connected last. Once all the parts are all in place, check and clear all DTCs in the HVAC module.
1Instrument Panel Insulator Bolts (Qty: 3) CAUTION: Refer to Fastener Caution .
2Instrument Panel Lower Trim Panel Insulator - Right Side Procedures Disconnect the electrical connectors. Transfer components as necessary.
NOTE
When removing the instrument panel lower trim panel insulator for any reason, it is required that the connector to the HVAC module be disconnected. If the vehicle battery has NOT been disconnected, when reinstalling / reconnecting the module, the BROWN J2 connector must be connected last. Once all the parts are all in place, check and clear all DTCs in the HVAC module.
CAUTION
Refer to Fastener Caution .

Instrument Panel Lower Trim Panel Insulator Replacement (Right Side)

Scheme 94

Scheme 94: Instrument Panel Insulator Hole Cover Replacement
Scheme 94: Instrument Panel Insulator Hole Cover Replacement
CalloutComponent Name
1Instrument Panel Insulator Hole Cover Fastener CAUTION: Refer to Fastener Caution .
2Instrument Panel Insulator Hole Cover Procedure Disconnect the electrical connector. Transfer parts as necessary.
CAUTION
Refer to Fastener Caution .

Instrument Panel Insulator Hole Cover Replacement

Scheme 95

Scheme 95: Instrument Panel Steering Column Opening Closeout Replacement
Scheme 95: Instrument Panel Steering Column Opening Closeout Replacement
CalloutComponent Name
Preliminary Procedure Remove the steering column upper trim cover. Refer to Steering Column Upper Trim Cover Replacement .
1Instrument Panel Steering Column Opening Closeout Procedure Use a flat-bladed plastic trim tool to remove the steering column opening closeout from the instrument carrier.

Instrument Panel Steering Column Opening Closeout Replacement

Scheme 96

Scheme 96: Instrument Panel Lower Center Trim Plate Applique Replacement
Scheme 96: Instrument Panel Lower Center Trim Plate Applique Replacement
CalloutComponent Name
1Radio Control Assembly Refer to Radio Control Assembly Replacement .
2Instrument Panel Center Molding Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution .
3Instrument Panel Lower Center Trim Plate Applique - Left
4Instrument Panel Lower Center Trim Plate Applique - Right
CAUTION
Refer to Fastener Caution .

Instrument Panel Lower Center Trim Plate Applique Replacement

Scheme 97

Scheme 97: Instrument Panel Instrument Cluster Hood Replacement (Without UV6)
Scheme 97: Instrument Panel Instrument Cluster Hood Replacement (Without UV6)
CalloutComponent Name
1Instrument Panel Instrument Cluster Hood Procedure Grasp the hood firmly and pull rearward to release the hood from the cluster trim plate.

Instrument Panel Instrument Cluster Hood Replacement (Without UV6)

Scheme 98

Scheme 98: Instrument Panel Instrument Cluster Hood Replacement (With UV6)
Scheme 98: Instrument Panel Instrument Cluster Hood Replacement (With UV6)
CalloutComponent Name
1Instrument Panel Instrument Cluster Hood Procedure Grasp the hood firmly and pull rearward to release the hood from the cluster trim plate.

Instrument Panel Instrument Cluster Hood Replacement (With UV6)

Scheme 99

Scheme 99: Instrument Panel Instrument Cluster Hood Replacement (With UEU)
Scheme 99: Instrument Panel Instrument Cluster Hood Replacement (With UEU)
CalloutComponent Name
1Instrument Panel Instrument Cluster Hood Procedure Grasp the hood firmly and pull rearward to release the hood from the cluster trim plate. Disconnect the electrical connection. Transfer all necessary components.

Instrument Panel Instrument Cluster Hood Replacement (With UEU)

Scheme 100

Scheme 100: Instrument Panel Extension Replacement
Scheme 100: Instrument Panel Extension Replacement
CalloutComponent Name
1Instrument Panel Extension Procedure Use a flat-bladed plastic trim tool to remove the extension from the instrument carrier.

Instrument Panel Extension Replacement

Scheme 101

Scheme 101: Driver Knee Bolster Reinforcement Replacement
Scheme 101: Driver Knee Bolster Reinforcement Replacement
CalloutComponent Name
Preliminary Procedure Remove the left front floor air outlet duct. Refer to Floor Front Air Outlet Duct Replacement - Left Side .
1Instrument Panel Driver Knee Bolster Reinforcement Fasteners (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten: 9 (80 lb in)
2Instrument Panel Driver Knee Bolster Reinforcement
CAUTION
Refer to Fastener Caution .

Driver Knee Bolster Reinforcement Replacement

Scheme 102

Scheme 102: Instrument Panel Knee Bolster Replacement
Scheme 102: Instrument Panel Knee Bolster Replacement
CalloutComponent Name
Preliminary Procedure Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the driver side inflatable restraint instrument panel lower module. Refer to Instrument Panel Lower Airbag Replacement - Driver Side . Remove the left instrument panel outer trim cover. Refer to Instrument Panel Outer Trim Cover Replacement . Remove the left instrument panel lower trim panel insulator. Refer to Instrument Panel Lower Trim Panel Insulator Replacement (Left Side) , Instrument Panel Lower Trim Panel Insulator Replacement (Right Side) .
1Instrument Panel Knee Bolster Fasteners (Qty: 3) CAUTION: Refer to Fastener Caution .
2Instrument Panel Knee Bolster Procedures Use a flat bladed plastic trim tool in order to release the retainer clips securing the knee bolster to the instrument carrier. Disconnect electrical connections. Transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Instrument Panel Knee Bolster Replacement

Scheme 103

Scheme 103: Instrument Panel Trim Plate Applique Replacement - Right Side
Scheme 103: Instrument Panel Trim Plate Applique Replacement - Right Side
CalloutComponent Name
Preliminary Procedure Remove the right instrument panel outer trim cover. Refer to Instrument Panel Outer Trim Cover Replacement .
1Instrument Panel Trim Plate Applique Fastener (Qty: 2) CAUTION: Refer to Fastener Caution .
2Instrument Panel Trim Plate Applique - Right Side Procedures Open the instrument panel compartment door to access the lower edge of the trim plate applique. Use a flat-bladed plastic trim tool to remove the trim plate applique from the instrument panel carrier. Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Instrument Panel Trim Plate Applique Replacement - Right Side

Scheme 104

Scheme 104: Instrument Panel Trim Plate Applique Replacement - Left Side
Scheme 104: Instrument Panel Trim Plate Applique Replacement - Left Side
CalloutComponent Name
Preliminary Procedure Remove the instrument panel knee bolster. Refer to Instrument Panel Knee Bolster Replacement .
1Instrument Panel Trim Plate Applique Fastener (Qty: 3) CAUTION: Refer to Fastener Caution .
2Instrument Panel Trim Plate Applique - Left Side Procedure Use a flat-bladed plastic trim tool to remove the trim plate applique from the instrument panel carrier. Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Instrument Panel Trim Plate Applique Replacement - Left Side

Scheme 105

Scheme 105: Instrument Panel Center Trim Plate Applique Replacement
Scheme 105: Instrument Panel Center Trim Plate Applique Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel knee bolster. Refer to Instrument Panel Knee Bolster Replacement .
1Instrument Panel Center Trim Plate Applique Fastener (Qty: 2) CAUTION: Refer to Fastener Caution .
2Instrument Panel Center Trim Plate Applique Procedure Use a flat-bladed plastic trim tool to remove the center trim plate applique from the instrument panel carrier.
CAUTION
Refer to Fastener Caution .

Instrument Panel Center Trim Plate Applique Replacement

Removal Procedure

  1. Remove the windshield garnish molding. Refer to «Windshield Garnish Molding Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  2. Remove the radio control assembly. Refer to «Radio Control Assembly Replacement»(/cadillac/ats/i-2012-2014/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  3. Remove the instrument panel extension. Refer to «Instrument Panel Extension Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  4. Remove the instrument panel compartment. Refer to «Instrument Panel Compartment Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  5. Remove the bolts (1) securing the top of the instrument panel upper trim panel to the instrument panel carrier.
  6. Remove the bolts (1) securing the instrument panel inflatable restraint module bracket to the instrument panel tie bar.
  7. Remove the bolts (1) securing the top of the instrument panel upper trim panel to the instrument panel carrier.
  8. Remove the instrument panel upper trim panel (1) secured by retainers to the instrument panel carrier.
  9. Transfer components as necessary.

Installation Procedure

  1. Install the instrument panel upper trim panel (1) secured by 11 retainers to the instrument panel carrier.
  2. Install the bolts (1) securing the top of the instrument panel upper trim panel to the instrument panel carrier.
  3. Install the bolts (1) securing the instrument panel inflatable restraint module bracket to the instrument panel tie bar and tighten to 9 (80 lb in).
  4. Install the bolts (1) securing the top of the instrument panel upper trim panel to the instrument panel carrier.
  5. Install the instrument panel compartment. Refer to «Instrument Panel Compartment Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  6. Install the instrument panel extension. Refer to «Instrument Panel Extension Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  7. Install the radio control assembly. Refer to «Radio Control Assembly Replacement»(/cadillac/ats/i-2012-2014/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  8. Install the windshield garnish molding. Refer to «Windshield Garnish Molding Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  1. Remove the windshield garnish molding. Refer to «Windshield Garnish Molding Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  2. Remove the instrument cluster. Refer to «Instrument Cluster Replacement»(/cadillac/ats/i-2012-2014/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges) .
  3. Remove the radio control assembly. Refer to «Radio Control Assembly Replacement»(/cadillac/ats/i-2012-2014/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  4. Remove the instrument panel extension. Refer to «Instrument Panel Extension Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  5. Remove the instrument panel knee bolster. Refer to «Instrument Panel Knee Bolster Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  6. Remove the left instrument panel trim plate applique. Refer to «Instrument Panel Trim Plate Applique Replacement - Left Side»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  7. Remove the instrument panel center trim plate applique. Refer to «Instrument Panel Center Trim Plate Applique Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  8. Remove the bolts (1) securing the top of the instrument panel upper trim panel to the instrument panel carrier.
  9. Remove the instrument panel upper trim panel (1) secured by retainers to the instrument panel carrier.
  10. Transfer components as necessary.
  1. Install the instrument panel upper trim panel (1) secured by 6 retainers to the instrument panel carrier.
  2. Install the bolts (1) securing the top of the instrument panel upper trim panel to the instrument panel carrier.
  3. Install the instrument panel center trim plate applique. Refer to «Instrument Panel Center Trim Plate Applique Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  4. Install the left instrument panel trim plate applique. Refer to «Instrument Panel Trim Plate Applique Replacement - Left Side»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  5. Install the instrument panel knee bolster. Refer to «Instrument Panel Knee Bolster Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  6. Install the instrument panel extension. Refer to «Instrument Panel Extension Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  7. Install the radio control assembly. Refer to «Radio Control Assembly Replacement»(/cadillac/ats/i-2012-2014/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  8. Install the instrument cluster. Refer to «Instrument Cluster Replacement»(/cadillac/ats/i-2012-2014/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges) .
  9. Install the windshield garnish molding. Refer to «Windshield Garnish Molding Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .

Scheme 106

Scheme 106: Instrument Panel Cluster Trim Plate Replacement (Without UV6)
Scheme 106: Instrument Panel Cluster Trim Plate Replacement (Without UV6)
CalloutComponent Name
Preliminary Procedure Remove the instrument cluster. Refer to Instrument Cluster Replacement .
1Instrument Panel Cluster Trim Plate Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution .
2Instrument Panel Cluster Trim Plate Procedure Disconnect the electrical connections.
CAUTION
Refer to Fastener Caution .

Instrument Panel Cluster Trim Plate Replacement (Without UV6)

Scheme 107

Scheme 107: Instrument Panel Cluster Trim Plate Replacement (With UV6)
Scheme 107: Instrument Panel Cluster Trim Plate Replacement (With UV6)
CalloutComponent Name
Preliminary Procedure Remove the instrument cluster. Refer to Instrument Cluster Replacement .
1Instrument Panel Cluster Trim Plate Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
2Instrument Panel Cluster Trim Plate Procedure Disconnect the electrical connections.
CAUTION
Refer to Fastener Caution .

Instrument Panel Cluster Trim Plate Replacement (With UV6)

Scheme 108

Scheme 108: Instrument Panel Outer Trim Cover Replacement
Scheme 108: Instrument Panel Outer Trim Cover Replacement
CalloutComponent Name
1Instrument Panel Outer Trim Cover - Left Procedure Use a flat bladed plastic trim tool to aid in the removal of the outer trim cover from the instrument panel assembly.
2Instrument Panel Outer Trim Cover - Right Procedure Use a flat bladed plastic trim tool to aid in the removal of the outer trim cover from the instrument panel assembly.

Instrument Panel Outer Trim Cover Replacement

Scheme 109

Scheme 109: Instrument Panel Lower Trim Panel Replacement
Scheme 109: Instrument Panel Lower Trim Panel Replacement
CalloutComponent Name
Preliminary Procedure Remove the left instrument panel lower trim panel insulator. Refer to Instrument Panel Lower Trim Panel Insulator Replacement (Left Side) , Instrument Panel Lower Trim Panel Insulator Replacement (Right Side) .
1Instrument Panel Insulator Fasteners (Qty: 3) CAUTION: Refer to Fastener Caution .
2Instrument Panel Lower Trim Panel
CAUTION
Refer to Fastener Caution .

Instrument Panel Lower Trim Panel Replacement

Scheme 110

Scheme 110: Instrument Panel Compartment Shelf Replacement
Scheme 110: Instrument Panel Compartment Shelf Replacement
CalloutComponent Name
1Instrument Panel Compartment Shelf Fastener CAUTION: Refer to Fastener Caution .
2Instrument Panel Compartment Shelf Procedures Disconnect electrical connections. Transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Instrument Panel Compartment Shelf Replacement

Scheme 111

Scheme 111: Instrument Panel Center Compartment Replacement
Scheme 111: Instrument Panel Center Compartment Replacement
CalloutComponent Name
1Instrument Panel Center Compartment Procedure Open the instrument panel compartment door to access the instrument panel center compartment.

Instrument Panel Center Compartment Replacement

Scheme 112

Scheme 112: Instrument Panel Compartment Replacement
Scheme 112: Instrument Panel Compartment Replacement
CalloutComponent Name
Preliminary Procedures Remove the right instrument panel trim plate applique. Refer to Instrument Panel Trim Plate Applique Replacement - Right Side . Remove the right front floor console extension panel. Refer to Front Floor Console Extension Panel Replacement - Right Side . Remove the passenger inflatable restraint instrument panel lower module. Refer to Instrument Panel Lower Airbag Replacement - Passenger Side .
1Instrument Panel Compartment Fasteners (Qty: 5) CAUTION: Refer to Fastener Caution .
2Instrument Panel Compartment Procedures Disconnect electrical connections. Transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Instrument Panel Compartment Replacement

  1. Lift up on the instrument panel compartment door latch.
  2. Use a suitable tool and depress the retaining tumbler (1) through the access hole indicated.
  3. With the retaining tumbler (1) depressed, remove the instrument panel compartment door lock cylinder (2) from the instrument panel compartment door latch assembly.
  1. Position the instrument panel compartment door lock cylinder (2) to the opening in the compartment door latch, while depressing the retainer tumbler (1).
  2. Insert the instrument panel door lock cylinder (2) fully into the latch assembly.
  3. An audible click should be heard when the door lock cylinder (2) is fully seated into the latch assembly.
  4. Ensure proper operation of the instrument panel compartment door lock.

Scheme 113

Scheme 113: Instrument Panel Compartment Door Dampener Replacement
Scheme 113: Instrument Panel Compartment Door Dampener Replacement
CalloutComponent Name
Preliminary Procedure Remove the instrument panel outer trim cover. Refer to Instrument Panel Outer Trim Cover Replacement .
1Instrument Panel Compartment Door Dampener Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
2Instrument Panel Compartment Door Dampener Procedure Disconnect the door dampener from the door stop and retainer.
CAUTION
Refer to Fastener Caution .

Instrument Panel Compartment Door Dampener Replacement

  1. Remove the front floor lower console (3). Refer to «Front Floor Lower Console Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  2. Remove the windshield garnish molding (1). Refer to «Windshield Garnish Molding Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  3. Remove the steering column (2). Refer to «Steering Column Replacement»(/cadillac/ats/i-2012-2014/remont/steering-column-switches/#steering-wheel-and-steering-column) .
  4. Remove the radio control assembly (2). Refer to «Radio Control Assembly Replacement»(/cadillac/ats/i-2012-2014/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  5. Remove the instrument panel extension (1). Refer to «Instrument Panel Extension Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  6. Remove the right instrument panel upper trim panel (1). Refer to «Instrument Panel Upper Trim Panel Replacement - Right Side»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  7. Remove the instrument cluster (2). Refer to «Instrument Cluster Replacement»(/cadillac/ats/i-2012-2014/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges) .
  8. Remove the head-up display, if equipped. (2). Refer to «Head-Up Display Replacement»(/cadillac/ats/i-2012-2014/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges) .
  9. Remove the left instrument panel upper trim panel (1). Refer to «Instrument Panel Upper Trim Panel Replacement - Left Side»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  10. Remove the left instrument panel trim plate applique (2). Refer to «Instrument Panel Trim Plate Applique Replacement - Left Side»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  11. Remove the instrument panel center trim plate applique (2). Refer to «Instrument Panel Center Trim Plate Applique Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  12. Remove the front floor console rear air duct (2). Refer to «Front Floor Console Rear Air Duct Replacement»(/cadillac/ats/i-2012-2014/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  13. Remove the radio front center speaker (2). Refer to «Radio Front Center Speaker Replacement»(/cadillac/ats/i-2012-2014/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  14. Remove the instrument panel carrier bolts (1).
  15. Remove the instrument panel carrier bolts (1).
  16. Note the location and routing of the instrument panel electrical harness assembly, to ensure proper reinstallation.
  17. Disconnect the fasteners securing the instrument panel electrical harness assembly to the instrument panel carrier and position out of the way.
  18. With the aid of an assistant lift the instrument panel carrier (1) rearward and upward from the tie bar assembly.
  19. Remove the instrument panel carrier from the vehicle.
  1. With the aid of an assistant, load the instrument panel carrier (1) to the instrument panel tie bar.
  2. Reposition the instrument panel wiring harness into the vehicle position as was noted in the removal and connect the fasteners securing the instrument panel wiring harness to the instrument panel carrier (1).
  3. Install the instrument panel carrier bolts (1).
  4. Install the instrument panel carrier bolts (1).
  5. Install the radio front center speaker (2). Refer to «Radio Front Center Speaker Replacement»(/cadillac/ats/i-2012-2014/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  6. Install the front floor console rear air duct (2). Refer to «Front Floor Console Rear Air Duct Replacement»(/cadillac/ats/i-2012-2014/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  7. Install the instrument panel center trim plate applique (2). Refer to «Instrument Panel Center Trim Plate Applique Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  8. Install the left instrument panel trim plate applique (2). Refer to «Instrument Panel Trim Plate Applique Replacement - Left Side»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  9. Install the left instrument panel upper trim panel (1). Refer to «Instrument Panel Upper Trim Panel Replacement - Left Side»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  10. Install the head-up display, if equipped. (2). Refer to «Head-Up Display Replacement»(/cadillac/ats/i-2012-2014/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges) .
  11. Install the instrument cluster (2). Refer to «Instrument Cluster Replacement»(/cadillac/ats/i-2012-2014/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges) .
  12. Install the right instrument panel upper trim panel (1). Refer to «Instrument Panel Upper Trim Panel Replacement - Right Side»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  13. Install the instrument panel extension (1). Refer to «Instrument Panel Extension Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  14. Install the radio control assembly (2). Refer to «Radio Control Assembly Replacement»(/cadillac/ats/i-2012-2014/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  15. Install the steering column (2). Refer to «Steering Column Replacement»(/cadillac/ats/i-2012-2014/remont/steering-column-switches/#steering-wheel-and-steering-column) .
  16. Install the windshield garnish molding (1). Refer to «Windshield Garnish Molding Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  17. Install the front floor lower console (3). Refer to «Front Floor Lower Console Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  1. Remove the instrument panel carrier. Refer to «Instrument Panel Carrier Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  2. Remove the driver knee bolster reinforcement. Refer to «Driver Knee Bolster Reinforcement Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  3. Reposition the parking brake lever without disconnecting the cables, if equipped. Refer to «Parking Brake Lever Replacement»(/cadillac/ats/i-2012-2014/remont/parking-brake-system/#parking-brake-system__parking-brake-lever-replacement) .
  4. Remove the radio bracket. Refer to «Radio Bracket Replacement»(/cadillac/ats/i-2012-2014/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  5. Remove the windshield wiper transmission. Refer to «Windshield Wiper Transmission Replacement»(/cadillac/ats/i-2012-2014/remont/wiperwasher-systems/#wiper-system-and-washer-system) .
  6. Remove the front side doors. Refer to «Front Side Door Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#bolted-exterior-body-panels-and-closures) .
  7. Remove the left and right side window defogger outlet ducts. Refer to «Side Window Defogger Outlet Duct Replacement - Left Side»(/cadillac/ats/i-2012-2014/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) , and «Side Window Defogger Outlet Duct Replacement - Right Side»(/cadillac/ats/i-2012-2014/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  8. Remove the left and right air distributor ducts. Refer to «Air Distributor Duct Replacement - Left Side»(/cadillac/ats/i-2012-2014/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) , and «Air Distributor Duct Replacement - Right Side»(/cadillac/ats/i-2012-2014/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  9. Remove the instrument panel tie bar brace bolts (1) from the dash and cowl panel.
  10. Remove the instrument panel tie bar bolts (1) from the body side outer frame access holes.
  11. Remove the instrument panel tie bar bolts (1) from the body side outer frame access holes.
  12. Loosen the fasteners of instrument panel fuse block (1) and remove from the instrument panel tie bar assembly and position out of the way.
  13. Remove the lower instrument panel tie bar bolts (1) from the instrument panel tie bar braces.
  14. Remove the bolts (1) securing the instrument panel tie bar assembly to the heater and air conditioning and blower module.
  15. Remove the upper instrument panel tie bar bolt (1) securing the instrument panel tie bar assembly to the instrument panel carrier support.
  16. Note the location and routing of the instrument panel wiring harness and unclip the harness and reposition from the tie bar.
  17. Support the HVAC module in order to prevent damage.
  18. Reposition the front floor carpet as necessary.
  19. With the aid of an assistant remove the instrument panel tie bar assembly (1) from the vehicle.
  1. With the aid of an assistant position the instrument panel tie bar assembly (1) into the vehicle and to the locator pins.
  2. Install the instrument panel wiring harness assembly to its in vehicle position as it was noted in the removal procedure.
  3. Install the upper instrument panel tie bar bolt (1) securing the instrument panel tie bar assembly to the instrument panel carrier support and tighten to 22 (16 lb ft).
  4. Install the bolts (1) securing the instrument panel tie bar assembly to the heater and air conditioning and blower module and tighten to 9 (80 lb in) .
  5. Install the lower instrument panel tie bar bolts (1) to the instrument panel tie bar braces and tighten to 22 (16 lb ft).
  6. Tighten the fasteners of instrument panel fuse block (1) to the instrument panel tie bar assembly.
  7. Install the instrument panel tie bar bolts (1) into the body side outer frame access holes and tighten to 22 (16 lb ft).
  8. Install the instrument panel tie bar bolts (1) into the body side outer frame access holes and tighten to 22 (16 lb ft).
  9. Install the instrument panel tie bar brace bolts (1) to the dash and cowl panel and tighten to 22 (16 lb ft).
  10. Install the left and right air distributor ducts. Refer to «Air Distributor Duct Replacement - Left Side»(/cadillac/ats/i-2012-2014/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) , and «Air Distributor Duct Replacement - Right Side»(/cadillac/ats/i-2012-2014/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  11. Install the left and right side window defogger outlet ducts. Refer to «Side Window Defogger Outlet Duct Replacement - Left Side»(/cadillac/ats/i-2012-2014/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) , and «Side Window Defogger Outlet Duct Replacement - Right Side»(/cadillac/ats/i-2012-2014/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  12. Install the front side doors. Refer to «Front Side Door Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#bolted-exterior-body-panels-and-closures) .
  13. Install the windshield wiper transmission. Refer to «Windshield Wiper Transmission Replacement»(/cadillac/ats/i-2012-2014/remont/wiperwasher-systems/#wiper-system-and-washer-system) .
  14. Install the parking brake lever, if equipped. Refer to «Parking Brake Lever Replacement»(/cadillac/ats/i-2012-2014/remont/parking-brake-system/#parking-brake-system__parking-brake-lever-replacement) .
  15. Install the radio bracket. Refer to «Radio Bracket Replacement»(/cadillac/ats/i-2012-2014/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  16. Install the driver knee bolster reinforcement. Refer to «Driver Knee Bolster Reinforcement Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  17. Install the instrument panel carrier. Do not install the front floor console extension panel at this time. Refer to «Instrument Panel Carrier Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  18. Turn the AC on full cold, on hi blower for 10 minutes with the left side carpet pulled back to visually inspect for water leaks at the air conditioning evaporator and blower case drain bellow connection.
  19. If a leak is found, reposition and reseat the bellow and inspect for water leaks.
  20. Install the front floor console extension panel. Refer to «Front Floor Console Extension Panel Replacement - Right Side»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) , and «Front Floor Console Extension Panel Replacement - Left Side»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .

Scheme 114

Scheme 114: Front Floor Console Front Compartment Replacement
Scheme 114: Front Floor Console Front Compartment Replacement
CalloutComponent Name
1Front Floor Console Trim Plate Refer to Front Floor Console Trim Plate Replacement .
2Front Floor Console Trim Plate Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution .
3Front Floor Console Front Compartment Procedures Disconnect all electrical connectors. When replacing the front compartment, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Front Floor Console Front Compartment Replacement

Scheme 115

Scheme 115: Front Floor Console Compartment Trim Plate Replacement
Scheme 115: Front Floor Console Compartment Trim Plate Replacement
CalloutComponent Name
1Front Floor Console Trim Plate Refer to Front Floor Console Trim Plate Replacement .
2Front Floor Console Trim Plate Fasteners (Qty: 13) CAUTION: Refer to Fastener Caution .
3Front Floor Console Transmission Shift Opening Bezel
4Front Floor Console Compartment Trim Plate Procedures Disconnect and reposition the electrical harness as necessary. Separate the bezel from the trim plate. Remove the remaining fastener to separate the compartment trim plate from the bezel. When replacing the trim plate, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Front Floor Console Compartment Trim Plate Replacement

Scheme 116

Scheme 116: Front Floor Console Compartment Replacement
Scheme 116: Front Floor Console Compartment Replacement
CalloutComponent Name
Preliminary Procedures Remove the front floor console rear trim panel. Refer to Front Floor Console Rear Trim Panel Replacement . Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement .
1Front Floor Console Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
2Front Floor Console Armrest Hinge Fasteners (Qty: 2) Tighten 9 (80 lb in)
3Front Floor Console Armrest Assembly Procedures Use a flat bladed plastic trim tool to aid in the removal of the armrest assembly from the front floor lower console. Disconnect electrical connections.
4Front Floor Console Armrest Hinge Fasteners (Qty: 4)
5Front Floor Console Compartment Procedure Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Front Floor Console Compartment Replacement

Scheme 117

Scheme 117: Front Floor Console Rear Trim Panel Replacement
Scheme 117: Front Floor Console Rear Trim Panel Replacement
CalloutComponent Name
1Front Floor Console Rear Trim Panel Procedures Use a flat-bladed plastic trim tool to remove the cover from the console. Disconnect the electrical connections. When replacing the console cover, transfer all necessary components.

Front Floor Console Rear Trim Panel Replacement

Scheme 118

Scheme 118: Front Floor Console Side Trim Panel Replacement - Right Side
Scheme 118: Front Floor Console Side Trim Panel Replacement - Right Side
CalloutComponent Name
1Front Floor Console Side Trim Panel - Right Side Procedure Use a flat-bladed plastic trim tool to remove the trim panel from the console.

Front Floor Console Side Trim Panel Replacement - Right Side

Scheme 119

Scheme 119: Front Floor Console Side Trim Panel Replacement - Left Side
Scheme 119: Front Floor Console Side Trim Panel Replacement - Left Side
CalloutComponent Name
1Front Floor Console Side Trim Panel - Left Side Procedure Use a flat-bladed plastic trim tool to remove the trim panel from the console.

Front Floor Console Side Trim Panel Replacement - Left Side

Scheme 120

Scheme 120: Front Floor Console Front Ashtray Replacement
Scheme 120: Front Floor Console Front Ashtray Replacement
CalloutComponent Name
1Front Floor Console Front Ashtray

Front Floor Console Front Ashtray Replacement

Scheme 121

Scheme 121: Front Floor Console Transmission Shift Opening Bezel Replacement
Scheme 121: Front Floor Console Transmission Shift Opening Bezel Replacement
CalloutComponent Name
1Front Floor Console Trim Plate Refer to Front Floor Console Trim Plate Replacement .
2Front Floor Console Trim Plate Fasteners (Qty: 13) CAUTION: Refer to Fastener Caution .
3Front Floor Console Compartment Trim Plate
4Front Floor Console Transmission Shift Opening Bezel Procedures Disconnect and reposition the electrical harness as necessary. Separate the applique from the trim plate. Remove the remaining fastener to separate the compartment trim plate from the bezel. When replacing the bezel, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Front Floor Console Transmission Shift Opening Bezel Replacement

Scheme 122

Scheme 122: Front Floor Console Cup Holder Plate Replacement
Scheme 122: Front Floor Console Cup Holder Plate Replacement
CalloutComponent Name
1Front Floor Console Cup Holder Plate Procedure Use a flat-bladed plastic trim tool to remove the cup holder plate from the console.

Front Floor Console Cup Holder Plate Replacement

Scheme 123

Scheme 123: Front Floor Console Extension Panel Replacement - Right Side
Scheme 123: Front Floor Console Extension Panel Replacement - Right Side
CalloutComponent Name
Preliminary Procedure Remove the right front floor console side trim panel. Refer to Front Floor Console Side Trim Panel Replacement - Right Side .
1Front Floor Console Extension Panel Procedure Use a flat-bladed plastic trim tool to remove the extension panel from the console.

Front Floor Console Extension Panel Replacement - Right Side

Scheme 124

Scheme 124: Front Floor Console Extension Panel Replacement - Left Side
Scheme 124: Front Floor Console Extension Panel Replacement - Left Side
CalloutComponent Name
Preliminary Procedure Remove the left front floor console side trim panel. Refer to Front Floor Console Side Trim Panel Replacement - Left Side .
1Front Floor Console Extension Panel Procedure Use a flat-bladed plastic trim tool to remove the extension panel from the console.

Front Floor Console Extension Panel Replacement - Left Side

Scheme 125

Scheme 125: Front Floor Lower Console Replacement
Scheme 125: Front Floor Lower Console Replacement
CalloutComponent Name
Preliminary Procedures Remove the front floor console rear trim panel. Refer to Front Floor Console Rear Trim Panel Replacement . Remove both of the front floor console extension panels. Refer to Front Floor Console Extension Panel Replacement - Right Side , and Front Floor Console Extension Panel Replacement - Left Side . Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement . Remove the front floor console compartment. Refer to Front Floor Console Compartment Replacement .
1Front Floor Console Fastener (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 9 (80 lb in)
2Front Floor Console Bracket Fastener (Qty: 2) Procedure Open the front floor console bolt access hole covers to access the fasteners from the rear of the floor console. Tighten 9 (80 lb in)
3Front Floor Lower Console Procedure Disconnect electrical connections. With the aid of an assistant lift the front floor lower console rearward and upward away from the instrument panel assembly. Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Front Floor Lower Console Replacement

Scheme 126

Scheme 126: Front Floor Console Armrest Replacement
Scheme 126: Front Floor Console Armrest Replacement
CalloutComponent Name
Preliminary Procedures Remove the front floor console rear trim panel. Refer to Front Floor Console Rear Trim Panel Replacement . Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement .
1Front Floor Console Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
2Front Floor Console Armrest Hinge Fasteners (Qty: 2) Tighten 9 (80 lb in)
3Front Floor Console Armrest Assembly Procedures Use a flat bladed plastic trim tool to aid in the removal of the armrest assembly from the front floor lower console. Disconnect electrical connections.
4Front Floor Console Armrest Hinge Fasteners (Qty: 4)
5Front Floor Console Armrest
CAUTION
Refer to Fastener Caution .

Front Floor Console Armrest Replacement

Scheme 127

Scheme 127: Front Floor Console Trim Plate Replacement
Scheme 127: Front Floor Console Trim Plate Replacement
CalloutComponent Name
Preliminary Procedures Remove the transmission control lever knob for automatic transmission, if equipped. Refer to Transmission Control Lever Knob Replacement . Remove the transmission control lever knob for manual transmission, if equipped. Refer to Transmission Control Lever Knob Replacement . Remove the front floor console cup holder plate. Refer to Front Floor Console Cup Holder Plate Replacement . Remove both front floor console side trim panels. Refer to Front Floor Console Side Trim Panel Replacement - Right Side , and Front Floor Console Side Trim Panel Replacement - Left Side .
1Front Floor Console Trim Plate Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
2Front Floor Console Trim Plate Procedures Use a flat-bladed plastic trim tool to remove the trim plate from the console. Disconnect electrical connections.
CAUTION
Refer to Fastener Caution .

Front Floor Console Trim Plate Replacement

Scheme 128

Scheme 128: Front Floor Console Applique Replacement
Scheme 128: Front Floor Console Applique Replacement
CalloutComponent Name
1Front Floor Console Trim Plate Refer to Front Floor Console Trim Plate Replacement .
2Front Floor Console Trim Plate Fasteners (Qty: 12) CAUTION: Refer to Fastener Caution .
3Front Floor Console Applique Procedures Disconnect and reposition the electrical harness as necessary. Separate the applique from the trim plate. When replacing the applique, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Front Floor Console Applique Replacement

Scheme 129

Scheme 129: Roof Console Replacement
Scheme 129: Roof Console Replacement
CalloutComponent Name
1Roof Console Assembly Procedure Use a flat-bladed plastic trim tool to release the 6 retainers securing the roof console to the headliner. Disconnect the electrical connections. When replacing the roof console assembly, transfer all necessary components.

Roof Console Replacement

Scheme 130

Scheme 130: Roof Console Accessory Switch Trim Plate Replacement
Scheme 130: Roof Console Accessory Switch Trim Plate Replacement
CalloutComponent Name
1Roof Console Refer to Roof Console Replacement .
2Roof Console Accessory Switch Trim Plate Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
3Roof Console Accessory Switch Trim Plate Procedure When replacing the roof console accessory switch trim plate, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Roof Console Accessory Switch Trim Plate Replacement

Scheme 131

Scheme 131: Roof Console Opening Trim Plate Replacement
Scheme 131: Roof Console Opening Trim Plate Replacement
CalloutComponent Name
Preliminary Procedure Remove the center reading and courtesy lamp. Refer to Center Reading and Courtesy Lamp Replacement .
1Roof Console
2Roof Console Opening Trim Plate Fasteners (Qty: 3) CAUTION: Refer to Fastener Caution .
3Roof Console Opening Trim Plate Procedure When replacing the roof console opening trim plate, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Roof Console Opening Trim Plate Replacement

More articles — Body & Frame
