Collision Repair Cadillac ATS I

Point-To-Point Measurements

Point-to-point measurements are for reference only. All measurements are given in millimeters. Use these measurements for diagnosing and estimating. Point-to-point measurements are duplicated with tram bar pointers set at equal lengths. All the marks, holes, slots, and fasteners are measured to the center. All dimensions are symmetrical unless otherwise specified.

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Structure Identification

Removal Procedure

Note. The front wheelhouse panel is cast aluminum and it is rivet bonded to the front lower frame rail (Ultra High Strength Steel) and hinge pillar upper extensions (Dual Phase Steel). The front wheelhouse is serviced as a complete assembly that includes the hinge pillar upper extension, which is rivet bonded to the front wheelhouse panel.

Note. This procedure describes how to replace the complete front wheelhouse assembly, using recommended adhesive and rivets to attach the assembly to the front lower frame rail. The assembly requires welding at the cowl on the upper hinge pillar extension.

Note. Partial replacement of the front wheelhouse assembly can be done by replacing only the front wheelhouse panel (cast aluminum). The front wheelhouse panel will need to be separated from the complete wheelhouse service assembly and replaced using adhesive and rivets.

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damage as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the Sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Remove all necessary factory welds and then remove the front upper outer rail (1) and the front tie bar attachment bracket (2), to access rivets and hinge pillar upper extension welds.
6. Remove all necessary factory welds for the upper outer rail reinforcement bracket and then remove the upper outer rail reinforcement bracket (1), then remove the welds from the hinge pillar upper extensions from the cowl area.
7. Locate, mark and remove the factory rivets that attach the front wheelhouse assembly to the structure (1).
8. To complete the removal of the front wheelhouse panel, apply heat to the adhesive material to cause the adhesive to release and then remove the wheelhouse assembly from the vehicle (1).

Installation Procedure

1. Prior to applying adhesive, or welding, fit the wheelhouse assembly to the structure and check for proper alignment (1).
2. With the part properly located and aligned, mark the locations for the rivets and welds recorded from the original part and drill the holes for the rivets (1).
3. Remove the part from the vehicle to clean and prepare the surfaces for bonding and welding.
4. Scuff sand the bonding surfaces on the service part to remove the gloss of the Elpo-coating.
5. Using a grinding disk, or equivalent, prepare a bare steel surface on the bonding areas of the vehicle structure.
6. Clean and prepare all welding surfaces.
7. Apply a bead of adhesive to all bonding surfaces on the vehicle structure and service part, per the adhesive manufacturer's recommendations. Refer to «Aluminum Panel Bonding»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair__aluminum-panel-bonding) .
8. Using a small brush, spread a coat of the adhesive to cover the entire adhesive bonding surface, to ensure proper corrosion protection.
9. Apply a bead of adhesive to the mating surface of the service part, per the adhesive manufacturer's recommendations.
10. Install the service part to the vehicle structure and check for proper alignment (1).
11. Install the rivets along the bonding joint, at the original locations. Refer to the electronic parts catalog for the recommended rivets.
12. Weld the service part at the original weld locations, as necessary.
13. Install front tie bar attachment bracket, front outer upper rail and upper outer rail reinforcement bracket.
14. Clean all welded surfaces.
15. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
16. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
17. Install all related panels and components.
18. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. The front wheelhouse panel is cast aluminum and it is rivet bonded to the front lower frame rail (Ultra High Strength Steel) and hinge pillar upper extensions (Dual Phase Steel). The front wheelhouse is serviced as a complete assembly that includes the hinge pillar upper extension, which is rivet bonded to the front wheelhouse panel.

Note. This procedure describes how to perform a partial replacement of the front wheelhouse assembly, using recommended adhesive and rivets to attach the assembly to the front lower frame rail and upper hinge pillar extension. This procedure can be used to replace the front wheelhouse panel (cast aluminum), when the upper hinge pillar extension is not damaged, or can be repaired. The hinge pillar upper extension can left attached to cowl area.

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damage as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Remove all necessary factory welds and then remove the front upper outer rail (1) and the front tie bar attachment bracket (2), to access rivets and hinge pillar upper extension welds.
6. Remove all necessary factory welds for the upper outer rail reinforcement bracket and then remove the upper outer rail reinforcement bracket (1).
7. Locate, mark and remove the factory rivets that attach the front wheelhouse assembly to the structure (1).
8. To complete the removal of the front wheelhouse panel, apply heat to the adhesive material to cause the adhesive to release and then remove the wheelhouse assembly from the vehicle (1).

1. Prior to applying adhesive, or welding, fit the wheelhouse assembly to the structure and check for proper alignment (1).
2. With the part properly located and aligned, mark the locations for the rivets and welds recorded from the original part and drill the holes for the rivets (1).
3. Remove the part from the vehicle to clean and prepare the surfaces for bonding and welding.
4. Scuff sand the bonding surfaces on the service part to remove the gloss of the Elpo-coating.
5. Using a grinding disk, or equivalent, prepare a bare steel surface on the bonding areas of the vehicle structure.
6. Clean and prepare all welding surfaces.
7. Apply a bead of adhesive to all bonding surfaces on the vehicle structure and service part, per the adhesive manufacturer's recommendations. Refer to «Aluminum Panel Bonding»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair__aluminum-panel-bonding) .
8. Using a small brush, spread a coat of the adhesive to cover the entire adhesive bonding surface, to ensure proper corrosion protection.
9. Apply a bead of adhesive to the mating surface of the service part, per the adhesive manufacturer's recommendations.
10. Install the service part to the vehicle structure and check for proper alignment (1).
11. Install the rivets along the bonding joint, at the original locations. Refer to the electronic parts catalog for the recommended rivets.
12. Install front tie bar attachment bracket, front outer upper rail and upper outer rail reinforcement bracket.
13. Clean all welded surfaces.
14. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
15. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
16. Install all related panels and components.
17. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damage as possible to factory specifications. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair)
4. Remove the sealers and anti-corrosion materials from the repair area. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
5. Remove factory welds as required. Note the number and location of the welds for installation of the front upper rail (1).
6. Remove the damaged front upper rail (1).

1. Prepare all mating surfaces as necessary.
2. Position the front upper rail on the vehicle. Clamp the rail in place and verify that it is in the correct location (1).
3. Weld accordingly at the original factory weld locations (1).
4. Clean and prepare all welded surfaces.
5. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. Paint the repair area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
7. Install all related panels ad components.
8. Enable the SIR system and connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling)

Note. The front compartment lower rail assembly is made of Ultra High Strength Steel. Sectioning or repair of Ultra High Strength Steel is not recommended. It should be replaced as a complete assembly at factory locations. Refer to Ultra High Strength Steel

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damage as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Locate, mark and remove the factory rivets that attach the front wheelhouse assembly to the front lower frame rail (1).
6. Remove welds from the inner side rail gussets, outer side rail gussets, and rear side rail extension from the front lower frame rail assembly, and then remove the parts.
7. Remove the factory welds from the front lower frame rail, as necessary.
8. To complete the removal of the front wheelhouse panel, apply heat to the adhesive material to cause the adhesive to release, and then remove the part.

1. Remove the inner side rail gussets, outer side rail gussets and rear side rail extension from the service part, prior to installing the service part.
2. Prior to applying adhesive, or welding, fit the front lower frame rail to the structure and check for proper alignment.
3. With the part properly located and aligned, mark the locations for the rivets and welds recorded from the original part and drill the holes for the rivets (1).
4. Remove the part from the vehicle to clean and prepare the surfaces for bonding and welding.
5. Clean and prepare all bonding and welding surfaces.
6. Apply a bead of adhesive to all bonding surfaces on the vehicle structure and service part, per the adhesive manufacturer's recommendations. Refer to «Aluminum Panel Bonding»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair__aluminum-panel-bonding) .
7. Using a small brush, spread a coat of the adhesive to cover the entire adhesive bonding surface, to ensure proper corrosion protection.
8. Apply a bead of adhesive to the mating surface of the service part, per the adhesive manufacturer's recommendations.
9. Install the service part to the vehicle structure and check for proper alignment.
10. Install the rivets along the bonding joint, at the original locations. Refer to the electronic parts catalog for the recommended rivets.
11. Weld the service part at the original weld locations, as necessary.
12. Install inner side rail gussets, outer side rail gussets and rear side rail extension removed from the service part.
13. Clean and prepare all of the welded surfaces.
14. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
15. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
16. Install all related panels and components.
17. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. There are sectioning procedures available for various locations of the body side outer panel. The sectioning procedure and location should be chosen based on the extent of damage to the vehicle and other inner reinforcements that need to be replaced. Sectioning should be performed only in the recommended areas. Failure to do so may compromise the structural integrity of the vehicle. Refer to other service procedures for additional sectioning locations.

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
3. Remove all related panels and components.
4. Repair as much of the damage as possible . Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
6. Measure down 100 mm from the door wiring conduit hole lower edge (1) and mark the cut location (2) on the body side outer front hinge pillar. Mark another cut location in the straight area on the body side outer rocker panel 330 mm rearward from front edge of the body side panel at the rocker (3).
7. Perform additional sectioning procedures as needed, depending on damage to vehicle. Refer to «Quarter Outer Panel Sectioning»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) , «Rocker Outer Panel Sectioning»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) , or «Center Pillar Sectioning - Outer»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
8. Cut the outer body side panel where sectioning is to be performed (1).
9. Remove the damaged front hinge pillar body.

1. From the service part, cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 in) at each joint location (1).
2. Prepare all matting surfaces as necessary.
3. Apply Weld-Thru Coating to all matting surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
4. Position the outer front pillar to the vehicle using 3-dimensional measuring equipment (1). Clamp the pillar in place.
5. Weld the perimeter of the part at the original spot weld locations (1). To create a solid weld with minimum heat distortion, make stitch welds along the 25 mm overlap joints, with equal gaps between the welds. Then go back and complete the welds, to create a solid weld joint (2).
6. Clean and prepare all of the welded surfaces.
7. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
8. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
9. Install all of the related panels and components.
10. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
11. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. This procedure was developed to allow access for the complete replacement of the front body hinge pillar reinforcement. There are sectioning procedures available for various locations of the body side outer panel. The sectioning procedure and location should be chosen based on the extent of damage to the vehicle and other inner reinforcements that need to be replaced. Sectioning should be performed only in the recommended areas. Failure to do so may compromise the structural integrity of the vehicle. Refer to other service procedures for additional sectioning locations.

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
3. Remove all related panels and components.
4. Repair as much of the damage as possible . Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
6. On the "A" pillar, measure up 400 mm from front edge of body side panel at the bottom of the "A" pillar (1). Mark this cut location on the front hinge pillar (2). Mark a cut location in the straight area of the rocker panel 330 mm rearward from front edge of the body side panel at the rocker (3).
7. Perform additional sectioning procedures as needed depending on damage to vehicle. Refer to «Quarter Outer Panel Sectioning»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) , «Rocker Outer Panel Sectioning»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) , or «Center Pillar Sectioning - Outer»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
8. Remove the front compartment upper side rail for access to welds and to remove the front hinge pillar outer panel. Refer to «Front Compartment Upper Side Rail Replacement»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
9. Cut the front hinge pillar body where sectioning is to be performed (1).
10. Remove the damaged front hinge pillar body (1).

1. From the service part, cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 in) at each joint location (1).
2. Prepare all mating surfaces as necessary.
3. Apply GM-approved weld-thru coating or equivalent to all mating surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
4. Position the outer front pillar to the vehicle using 3-dimensional measuring equipment (1). Clamp the pillar in place.
5. Weld the perimeter of the part at the original spot weld locations. To create a solid weld with minimum heat distortion, make stitch welds along the 25 mm overlap joints, with equal gaps between the welds. Then go back and complete the welds, to create a solid weld joint (1).
6. Install the front compartment upper side rail for access to welds and to remove the front hinge pillar outer panel. Refer to «Front Compartment Upper Side Rail Replacement»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
7. Clean and prepare all of the welded surfaces.
8. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
9. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
10. Install all of the related panels and components.
11. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
12. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Visually inspect the damage. Repair as much of the damage as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Remove factory welds as required.
6. Remove the damaged body hinge pillar lower reinforcement (1).

1. Prepare all mating surfaces as necessary.
2. Clean and prepare the attaching surfaces for welding (1).
3. Position the body hinge pillar lower reinforcement (1) on the vehicle.
4. Verify the fit of the body hinge pillar lower reinforcement.
5. Weld the body hinge pillar lower reinforcement (1) accordingly at original weld locations.
6. Clean all of the welded surfaces.
7. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
8. Install the body side outer panel. Refer to the appropriate service procedures as required based on the specific amount of vehicle damage.
9. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
10. Install all of the related panels and components.
11. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damaged area as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Remove welds at the front and rear window opening of the roof panel (1).
6. On the side rail area of the roof use a cut off wheel or equivalent to cut the panel 30 mm inboard of the roof edge (1).
7. Remove the center portion of the panel.
8. To separate the remaining portion of the panel use a cut off wheel or equivalent to grind out the MIG braze joint (1).
9. Remove the remaining portion of the original panel.

1. Test fit the service panel to the vehicle, to create locating holes for accurate location of the panel.
2. Clamp the panel into position in the rear window opening (1). Adjust the bow of the roof front to rear. Clamp in place in the windshield opening area (2).
3. With the service panel clamped in position drill a 3.2 m (1/8 in) hole in each corner of the panel in the front and rear window openings (1).
4. Remove the service panel from the vehicle.
5. Prepare the roof rail area of the vehicle with an abrasive wheel or equivalent (1).
6. Clean and prepare the front and rear window attaching surfaces for welding. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
7. Prepare the roof side rail bond areas. Refer to adhesive manufacturers preparation instructions.
8. Apply flexible anti-flutter foam, or equivalent, to the roof bows (1) in the locations noted from the original panel.
9. Apply a 12 mm (1/2 in) bead of metal panel bonding adhesive «Metal Panel Bonding (Steel)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair__metal-panel-bonding-steel) to the left and right roof rails (1).
10. With the help of a second person lower the service panel straight down onto the vehicle.
11. Insert an awl or equivalent tool into the four holes drilled in the window openings in step 3 (1).
12. Clamp the roof in place in the front and rear window openings.
13. Clean up the excess urethane from the surface.
14. Install 25 mm (1 in) wide ratchet strap or equivalent across the roof inboard of the bond area (1). Apply light even pressure to the bond area.
15. Allow adhesive to completely cure per manufacturers instructions. Remove the ratchet straps.
16. Weld along window openings (1) accordingly.
17. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
18. Use a high quality seam sealer to fill the gap between the outer roof panel and the body side roof rail. Follow the manufacturers instructions.
19. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
20. Install all of the related panels and components.
21. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damaged area as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. The body side outer panel, center pillar reinforcement, rocker panel outer reinforcement and front hinge pillar reinforcement will need to be removed to gain access to the rocker inner panel reinforcement (1). Refer to the appropriate service procedures as required based on the specific amount of vehicle damage.
6. Remove all the necessary factory welds (1).
7. Remove the damaged rocker inner panel reinforcement.

1. Prepare the mating surfaces as necessary.
2. Apply Weld-Thru Coating to all mating surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
3. Position the rocker reinforcement in place, use 3-dimensional measuring equipment, clamp in place.
4. Weld accordingly at the original weld locations (1).
5. Install the body side outer panel, center pillar reinforcement, rocker panel outer reinforcement and front hinge pillar reinforcement. Refer to the appropriate service procedures as required based on the specific amount of vehicle damage.
6. Clean all of the welded surfaces.
7. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
8. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
9. Install all of the related panels and components.
10. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damaged area as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. The body side outer panel, center pillar reinforcement and front hinge pillar reinforcement will need to be removed to gain access to the rocker outer panel reinforcement. Refer to the appropriate service procedures as required based on the specific amount of vehicle damage.
6. Remove all necessary welds of the body side outer panel reinforcement (1).
7. Remove the damaged body side outer panel reinforcement (1).

1. Clean and prepare the attaching surfaces for welding.
2. Position the body side outer panel reinforcement (1) on the vehicle.
3. Verify the fit of the body side outer panel reinforcement.
4. Clamp the body side outer panel reinforcement into position.
5. Weld the body side outer panel reinforcement (1) accordingly.
6. Clean all of the welded surfaces.
7. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
8. Install the body side outer panel, center pillar reinforcement and front hinge pillar reinforcement. Refer to the appropriate service procedures as required based on the specific amount of vehicle damage.
9. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
10. Install all of the related panels and components.
11. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
3. Remove all related panels and components.
4. Repair as much of the damaged area as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
6. Create cut lines on the rocker outer panel (1). To avoid cutting into hidden reinforcements within the center pillar panel, measure 100 mm down from bottom of electrical conduit hole (2), mark a cut line (3). To avoid a cutting into a sound deadener baffle within the lock pillar panel, measure 350 mm up from the bottom of the rocker panel (4), mark a cut line (5).
7. Perform additional sectioning procedures as needed, depending on damage to vehicle. Refer to «Quarter Outer Panel Sectioning»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) , «Front Hinge Pillar Body Sectioning (Lower)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) , «Front Hinge Pillar Body Sectioning (Upper)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) , or «Center Pillar Sectioning - Outer»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
8. Cut the rocker outer panel (1) where sectioning is to be performed.
9. Remove all the necessary factory welds of the rocker outer panel (1).
10. Remove the damaged rocker outer panel (1).

1. From the service part (1), cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 inch) at each joint location.
2. Prepare all mating surfaces, as necessary.
3. Clean and prepare the attaching surfaces for welding.
4. Apply Weld-Thru Coating to all mating surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Position the rocker outer panel section (1) to the vehicle using 3-dimensional measuring equipment. Clamp the pillar in place.
6. Weld the perimeter of the part at the original weld locations (1).
7. To create a solid weld with minimum heat distortion, make stitch welds along the 25 mm overlap joints, with equal gaps between the welds. Then go back and complete the welds, to create a solid weld joint (1).
8. Clean and prepare all of the welded surfaces.
9. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
10. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
11. Install all of the related panels and components.
12. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
13. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. The upper flanges of the rear compartment floor panel are trapped between the rear lower frame rail and rear frame rail upper reinforcement, on both sides of the panel. This procedure describes how to perform a partial replacement of the rear compartment floor panel, by creating a 25 mm (1 in) flange on both sides of the original panel and should be used when the rear frame rail and frame rail reinforcement do not require replacement. Complete panel replacement can be done when the rear frame rails, or frame rail reinforcements have been removed.

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damage as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Remove the body rear end panel (1). Refer to «Body Rear End Panel Replacement»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
6. Apply a 25 mm (1 in) wide piece of masking tape to the rear compartment panel along the top side of the panel, below the rear frame rail upper extension, on both sides (1).
7. Create a 25 mm (1 in) weld flange on both sides of the floor panel, to attach the replacement panel. Cut along the bottom of the tape, below the rear frame rail upper reinforcement (1).
8. Cut the rear compartment panel, vertically at the forward corners, leaving two 25 mm (1 in) flanges to attach the replacement floor.
9. Locate, mark, and remove the factory weld along the forward edge of the rear floor panel.
10. Remove the damaged rear compartment panel from the vehicle.

1. Cut the top flange off of the rear compartment panel replacement part, along the sides only (1). This will create a 25 mm (1 in) overlap joint to fit over the flange that was left from the original panel.
2. Clean and prepare all welding surfaces (1). Place 8 mm (5/16 in) holes 40 mm (1 1/2 in) apart along the sides of the panel that will overlap the flanges left from the original panel, to MIG plug weld the replacement part.
3. Install and align the service part as necessary.
4. Weld the service part along the front edge, at the original weld locations (1).
5. MIG plug weld on the sides of the replacement part, along the 25 mm (1 in) overlap joint (1).
6. Replace the body rear end panel. Refer to «Body Rear End Panel Replacement»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
7. Clean and prepare all welded surfaces.
8. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
9. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
10. Install all related panels and components.
11. Enable the SIR system and then connect the battery negative cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damaged area as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Remove all the necessary factory welds (1).
6. Remove the rear inner wheelhouse (1).

1. Prepare all mating surfaces for welding as necessary (1).
2. Apply Weld-Thru Coating to all mating surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
3. Position the rear inner wheelhouse to the vehicle (1).
4. Weld accordingly at the original weld locations.
5. Clean all of the welded surfaces.
6. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
7. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
8. Install all of the related panels and components.
9. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Repair as much of the damaged area as possible.
3. Visually inspect the damage. Repair as much of the damage as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Section the sail panel and the rocker panel. At the sail panel, measure from the top outer corner of the back glass opening down 100 mm. Scribe a line. This is the cut location (1). Scribe a line 350 mm forward of the rear edge of the rocker. This is the cut location (2).
6. Remove all factory welds (1).
7. Cut the panel at the marked locations (1).
8. Remove the lower quarter panel (1).

1. From the service part, cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 in) at each joint location (1,2).
2. Drill 8 mm (5/16 in) plug weld holes as necessary in locations noted from the original quarter panel (1).
3. Prepare all mating surfaces for welding, as necessary.
4. Apply GM approved Weld-Thru coating or equivalent to all mating surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Position the new service panel and clamp in place (1).
6. Perform the sectioning procedure.
7. Weld accordingly at the original weld locations (1).
8. To create a solid weld with the minimum heat distortion, make a 25 mm (1 in) stitch weld along the seam with gaps of 25 mm (1 in) gaps between them. Go back and complete the stitch weld.
9. Clean and prepare all welded surfaces.
10. Pre-flange wheel housing. Using a flat faced body hammer, bend over the flanged edge 45 degrees (1) and at the same time holding a hard rubber block against it. Use the structural adhesive in the area (2).
11. Bend the wheel arch (3).
12. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
13. Paint the repair area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
14. Install all related panels and components.
15. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damage as possible.
4. Remove the sealers and anti-corrosion materials from the repair area as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. The body side outer panel will need to be removed to perform the quarter inner panel lower sectioning procedure. Refer to the appropriate service procedures to remove the body side outer panel, based on the specific amount of vehicle damage.
6. Remove factory welds for the quarter inner panel upper reinforcement, as required (1).
7. Remove the quarter inner panel reinforcement (1).
8. Cut the inner panel along inner edge of outer wheelhouse.
9. Remove the damaged section of the wheelhouse.

1. Trim the service part to leave approximately 25 mm (1 in) vertical flange (1).
2. Prepare all mating surfaces for welding as necessary.
3. Position the rear wheelhouse portion of the inner panel on the vehicle.
4. Clamp the part in place and verify that it is the correct location.
5. Weld the part accordingly (1) using MIG plug welds approximately 40 mm apart.
6. Install the quarter inner panel reinforcement (1).
7. Clean and prepare all welded surfaces.
8. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
9. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
10. Install all related panels and components.
11. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damage as possible.
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair)
5. The body side outer panel will need to be removed to perform the quarter inner panel lower sectioning procedure. Refer to the appropriate service procedures to remove the body side outer panel, based on the specific amount of vehicle damage.
6. Remove factory welds for the quarter inner panel upper reinforcement, as required (1).
7. Remove body lock pillar upper reinforcement (1).
8. Cut body side inner panel where sectioning is to be performed (1).
9. Remove factory welds, as required (1).
10. Remove the damaged body side inner panel.

1. From the service part, cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 in) at each joint location (1).
2. Prepare all mating surfaces for welding, as necessary.
3. Position the body side inner panel to the vehicle.
4. Clamp the part in place and verify that it is the correct location.
5. Weld the perimeter of the part at the original weld locations (1).
6. To create a solid weld with minimum heat distortion, make stitch welds along the 25 mm (1 in) overlap joints, with equal gaps between the welds. Then go back and complete the welds to create a solid weld joint (1).
7. Install the quarter inner panel upper reinforcement (1).
8. Clean and prepare all welded surfaces.
9. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
10. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
11. Install all related panels and components.
12. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
3. Remove all related panels and components (1).
4. Repair as much of the damaged area as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair)
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
6. Remove the shock reinforcement wheel house extension (1).
7. Remove the rear rail (1).

1. Prepare all mating surfaces as necessary.
2. Apply GM-approved weld-thru coating or equivalent to all mating surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
3. Position the rear rail to the vehicle using 3-dimensional measuring equipment. Clamp the rail in place (1).
4. Weld the perimeter of the part at the original weld locations (1).
5. Install the 5 bar (1).
6. Clean and prepare all of the welded surfaces.
7. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
8. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
9. Install all related panels and components.
10. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
11. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
3. Remove all related panels and components.
4. Repair as much of the damaged area as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
6. Create cut lines on the rear side rail (1).
7. Cut the panel (1) where sectioning is to be performed.
8. Note the number and location of the factory welds for installation of the rail service part (1).
9. Remove the damaged rear side rail (1).

1. Cut the rear side rail (1) in corresponding locations to fit the remaining original panel. The sectioning joint should be trimmed to allow a gap of one-and-one-half-times the metal thickness at the sectioning joint.
2. Prepare all mating surfaces as necessary.
3. Apply GM-approved weld-thru coating or equivalent to all mating surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair)
4. Position the sectioned rail to the vehicle using 3-dimensional measuring equipment. Clamp the rail in place.
5. Position the backing plate inside the rail (1). Weld accordingly.
6. To create a solid weld with minimum heat distortion, make 25 mm (1 in) stitch welds along the seam with 25 mm (1 in) gaps between them. Then go back and complete the stitch weld.
7. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
8. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
9. Install all related panels and components.
10. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
11. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damaged area as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Remove all the necessary factory welds (1).
6. Remove the rear end panel (1).

1. Clean and prepare all matting surfaces as necessary (2).
2. Apply Weld-Thru Coating to all mating surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
3. Position the rear end panel on the vehicle. Use 3-dimensional measuring equipment to inspect the panel (1).
4. Weld accordingly at the original weld locations (1).
5. Clean all of the welded surfaces.
6. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
7. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
8. Install all of the related panels and components.
9. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damaged area as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Remove all the necessary factory welds (1).
6. Remove the damaged center pillar inner panel (1).

1. Clean and prepare the attaching surfaces for welding.
2. Position the center pillar inner panel (1) on the vehicle.
3. Verify the fit of the panel.
4. Clamp the center pillar inner panel into position.
5. Weld accordingly at original weld locations (1).
6. Clean all of the welded surfaces.
7. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
8. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
9. Install all related panels and components.
10. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR System and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove all related panels and components.
3. Repair as much of the damaged area as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
4. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Remove body side center pillar section. Refer to «Center Pillar Sectioning - Outer»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
6. Remove all necessary factory welds (1).
7. Remove the damaged center pillar reinforcement (1).

1. Prepare all mating surfaces, as necessary.
2. Align the center pillar reinforcement.
3. Drill 8 mm (5/16 in) for plug welding along the edges of the center pillar reinforcement (1) as noted from the original panel.
4. Clean and prepare the attaching surfaces for welding.
5. Position the center pillar reinforcement (1) on the vehicle using 3-dimensional measuring equipment.
6. Verify the fit of the center pillar reinforcement.
7. Clamp the center pillar reinforcement into position.
8. Weld accordingly at the original weld locations (1).
9. Complete body side center pillar sectioning. Refer to «Center Pillar Sectioning - Outer»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
10. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
11. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
12. Install all related panels and components.
13. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
3. Remove all related panels and components.
4. Repair as much of the damaged area as possible. Refer to «Dimensions - Body (Sedan)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
5. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
6. Remove the weather-strip and measure rearward from the front edge of the roof panel 430 mm and mark a vertical line on the bodyside (1).
7. Measure rearward from the front edge of the roof panel 800 mm and mark a second vertical line on the bodyside (1).
8. Measure down 25 mm (1 in) from the upper edge of the body side outer panel and mark a horizontal line (1). This is the cut line.
9. Cut access window (1) in the center pillar outer.
10. Perform additional sectioning procedures as needed depending on damage to vehicle. Refer to «Quarter Outer Panel Sectioning»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) , «Rocker Outer Panel Sectioning»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) , or «Front Hinge Pillar Body Sectioning (Lower)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) , «Front Hinge Pillar Body Sectioning (Upper)»(/cadillac/ats/i-2012-2014/remont/exterior-body-panels/#collision-repair) .
11. Remove the damaged center pillar outer panel section (1).

1. From the service part, cut the panel in corresponding locations to overlap the remaining original panel by 25 mm (1 in) at each joint location (1).
2. Prepare all mating surfaces for welding, as necessary (1).
3. Apply GM approved Weld -Thru Coating or equivalent to all mating surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
4. Position the outer center pillar (1) to the vehicle using 3-dimensional measuring equipment. Clamp the pillar in place.
5. Weld the perimeter of the part at the original spot weld locations. To create a solid weld with minimum heat distortion, make stitch welds along the 25 mm overlap joints with equal gaps between the welds. Then go back and complete the welds to create a solid weld joint (1).
6. Clean and prepare all of the welded surfaces.
7. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
8. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
9. Install all of the related panels and components.
10. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system)
11. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove the door from the vehicle. Refer to «Front Side Door Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#bolted-exterior-body-panels-and-closures) .
3. Remove all related panels and components.
4. Remove factory welds as necessary (1).
5. Grind the edges of the door outer panel to separate the outer door panel from the door shell .
6. Remove the outer door panel (1).
7. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
8. Straighten the edges of the door shell (1).

1. Using a grinding disk, or equivalent, grind the surface of the door shell mating flanges to bare steel (1).
2. Scuff the opposing mating surfaces of the door outer panel to remove the gloss of the E-Coat (1).
3. Clean and prepare the mating surfaces.
4. Apply a 3-6 mm (1/8-1/4 in) bead of metal panel bonding adhesive to both of the mating surfaces (1).
5. Using a small brush, spread a coat of adhesive to cover all of the bare metal surfaces to ensure proper corrosion protection.
6. Apply a 9-13 mm (3/8-1/2 in) bead of metal panel bonding adhesive to the mating surface of the service panel.
7. Install the door outer panel to the door shell (1).
8. Clamp the door outer panel into position as required.
9. Using a hammer re-hem the hem flanges around the door shell. Continue to hammer in stages along the hem flanges (1).
10. Remove the excess adhesive from the door panel area.
11. Install the door to the vehicle. Inspect the door outer panel for proper alignment. Adjust the alignment as required. Refer to «Front Side Door Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#bolted-exterior-body-panels-and-closures) .
12. Weld the door outer panel to the door frame in the locations noted at the upper door frame (1).
13. Clean all welded surfaces.
14. Apply flexible anti-flutter foam, or equivalent, in 4-5 evenly spaced locations between the door outer panel and the inner safety beam and the upper belt reinforcement.
15. Apply sealers and anti-corrosion materials to the repair area as necessary. Refer to Paint the repaired area. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
16. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
17. Install the door to the vehicle. Refer to «Front Side Door Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#bolted-exterior-body-panels-and-closures) .
18. Install all related panels and components.
19. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

1. Disable the SIR system and then disconnect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Remove the door from the vehicle. Refer to «Front Side Door Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#bolted-exterior-body-panels-and-closures) , or «Rear Side Door Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#bolted-exterior-body-panels-and-closures) .
3. Remove all related panels and components.
4. Remove factory welds as necessary (1).
5. Grind the edges of the door outer panel to separate the outer door panel from the door shell (1).
6. Remove the outer door panel (1).
7. Remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
8. Straighten the edges of the door shell (1).

1. Using a grinding disk, or equivalent, grind the surface of the door shell mating flanges to bare steel (1).
2. Scuff the opposing mating surfaces of the door outer panel to remove the gloss of the E-Coat (1).
3. Clean the mating surfaces.
4. Apply a 3-6 mm (1/8-1/4 in) bead of metal panel bonding adhesive to both of the mating surfaces (1).
5. Using a small brush, spread a coat of adhesive to cover all of the bare metal surfaces to ensure proper corrosion protection.
6. Apply a 9-13 mm (3/8-1/2 in) bead of metal panel bonding adhesive to the mating surface of the service panel.
7. Install the door outer panel to the door shell (1).
8. Clamp the door outer panel into position as required.
9. Using a hammer re-hem the hem flanges around the door shell . Continue to hammer in stages along the hem flanges (1).
10. Remove the excess adhesive from the door panel area.
11. Install the door to the vehicle check the door outer panel for proper alignment, adjust the alignment as required.
12. Weld the door outer panel to the door frame in the locations noted at the upper door frame (1).
13. Clean all welded surfaces.
14. Apply flexible anti-flutter foam, or equivalent, in 4-5 evenly spaced locations between the door outer panel and the inner safety beam and the upper belt reinforcement (1).
15. Apply sealers and anti-corrosion materials to the repair area as necessary. Refer to Paint the repaired area. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
16. Paint the repaired area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems)
17. Install the door to the vehicle. Refer to «Front Side Door Replacement»(/cadillac/ats/i-2012-2014/remont/exteriorinterior-trim/#bolted-exterior-body-panels-and-closures) .
18. Install all related panels and components.
19. Enable the SIR system and then connect the negative battery cable. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Resistance Spot Welded Full Panel Replacement

Note. Use this procedure for all panels that are replaced at the factory seams, unless a specific procedure exists in the Collision Repair section of this vehicle's service information.

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
3. Remove all related panels and components.
4. Repair as much of the damage as possible to factory specifications.
5. Note the location and remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
6. Locate and drill out all factory welds (1). Note the number and location of the welds for installation of the service part.
7. Remove the damaged part (1).

1. Prepare all mating surfaces as necessary.
2. Apply GM-approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
3. Position the service part. Clamp in place.
4. Apply welds accordingly (1).
5. Clean and prepare all welded surfaces.
6. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
7. Paint the repair area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
8. Install all related panels and components.
9. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
10. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Note. Use this procedure for all panels that are replaced at the factory seams, unless a specific procedure exists in the Collision Repair section of this vehicle's service information.

1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
2. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
3. Remove all related panels and components.
4. Repair as much of the damage as possible to factory specifications.
5. Note the location and remove the sealers and anti-corrosion materials from the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
6. Locate and drill out all factory welds (1). Note the number and location of the welds for installation of the service part.
7. Remove the damaged part (1).

1. Drill 8 mm (5/16 in) plug weld holes in the service part as necessary in the locations noted from the original panel (1).
2. Prepare all attachment surfaces as necessary.
3. Prepare all mating surfaces as necessary.
4. Apply GM-approved Weld-Thru Coating or equivalent to all mating surfaces. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
5. Position the service part. Clamp in place.
6. Plug weld accordingly (1).
7. Clean and prepare all welded surfaces.
8. Apply the sealers and anti-corrosion materials to the repair area, as necessary. Refer to «Anti-Corrosion Treatment and Repair»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__anti-corrosion-treatment-and-repair) .
9. Paint the repair area. Refer to «Basecoat/Clearcoat Paint Systems»(/cadillac/ats/i-2012-2014/remont/paintcoatings/#paint-and-coatings__basecoatclearcoat-paint-systems) .
10. Install all related panels and components.
11. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnection and Connection»(/cadillac/ats/i-2012-2014/remont/body-electrical/#battery-charging-system-and-starting-system) .
12. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/cadillac/ats/i-2012-2014/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .

Aluminum Panel Bonding

This information is intended to provide general guidelines for adhesive bonding of aluminum panels. Panel bonding of aluminum is only recommended when the panel is originally bonded to the vehicle.

The adhesives listed in this document are known to meet the General Motors specifications and requirements for bonding of aluminum body panels.

Bonding procedures in general are applicable only at factory joints.

The use of adhesive to section aluminum panels is not recommended by General Motors.

Rivets, or other mechanical fasteners, may be used in combination with adhesive bonding of aluminum panels. The specified rivets, or fasteners, should be used with adhesive, when replacing the original panel.

Two types of adhesives are listed here. Impact Resistant Adhesive is used in joints in frame rail assemblies and strut tower assemblies and other body structure joints that have critical strength requirements. The factory applied Impact Resistant Adhesive is purple in color when cured. The only adhesive available for servicing these joints is Dow Betamate 2098. The other bonding adhesives are non-impact resistant, offer a lower strength rating and can be used in all other joints that are not originally made with Impact Resistant Adhesive

Note. Always follow the adhesive manufacturer's instructions for application, handling, and curing for the specific product.

Adhesives currently meeting the performance requirements include the adhesive products listed below meet these guidelines

Aluminum Panel Bonding Impact Resistant

Aluminum Panel Bonding Non Impact Resistant

Dual Phase Steel

This information provides repair recommendations and general guidelines for steel classified as Dual Phase Steel, also known as DP. This type of steel normally has a tensile strength below 780 MPa.

General Motors recommends the following when repairing or replacing this type of steel during collision repair.

Note. The use of heat to repair damage is not recommended for this classification of steel.

Recommended Repairs

1. Cold repairs can be performed on this type of steel, unless the damage includes kinks. If the damage includes kinks, the part should be replaced.
2. Sectioning or partial replacement of this type of steel is recommended only at approved locations, in a specific sectioning procedure.
3. This type of steel can be used as a sleeve, or backer plate, when recommended in a specific sectioning procedure.
4. Squeeze Resistance Spot Welding can be used to replace factory spot welds, where applicable.
5. MIG plug welding and MIG stitch welding can be used on this type of steel.
6. MIG Brazing can be used on this type of steel.

High Strength Low Alloy Steel

This information provides repair recommendations and general guidelines for steel classified as High Strength Low Alloy Steel, also known as HSLA. This type of steel normally has a tensile strength range from 300-700 MPa.

General Motors recommends the following when repairing or replacing this type of steel during collision repair.

Recommended Repairs

1. Cold repairs can be performed on this type of steel, unless the damage includes kinks. If the damage includes kinks, the part should be replaced.
2. Controlled use of heat can be used to repair damage, if the heat does not exceed 650°C (1200°F). The heat should be applied a maximum of 2 times, for up to 90 seconds.
3. Sectioning or partial replacement of this type of steel is recommended only at approved locations, in a specific sectioning procedure.
4. This type of steel can be used as a sleeve, or backer plate, during sectioning procedures.
5. Squeeze Resistance Spot Welding can be used to replace factory spot welds, where applicable.
6. MIG plug welding and MIG stitch welding can be used on this type of steel.
7. MIG Brazing can be used on this type of steel.

Metal Panel Bonding (Steel)

This is intended to provide general guidelines for adhesive bonding of exterior panels as an alternative to Metal-Inert Gas (MIG) welding. Panel bonding may be seen as an alternative to MIG welding to provide full panel replacement in regards to collision repair procedures. The benefits of panel bonding is

1. No heat or burn damage when additional welding is not required
2. Corrosion protection
3. Can act as a sealant
4. Improved process for complicated shapes (wheelhouse area)

The General Motors specification for metal bonding adhesives is GM 6449G. The scope of this specification is intended to provide the performance guidelines of structural adhesive systems used to repair (metallic) automotive bodies in the aftermarket. These types of adhesives are intended for use when bonding replacement body panels as an option to welding as the attachment means. GM information outlines the use of room temperature cure acrylic adhesives that contain glass bead technology.

Bonding procedures in general are applicable only to a factory seams type approach.

Sectioning or partial paneling of full panels is not supported by General Motors unless specifically documented in a Service Bulletin or Manual.

Applicable components for this technology are EXTERIOR PANELS ONLY, including door skins, tail panels, roof outer panels and quarter panels.

Adhesives currently meeting the performance requirements include General Motors materials and products manufactured by Lord Adhesives. At this time, ONLY the adhesive products listed below meet this guideline

Metal Panel Bonding (Steel)

Mild Steel

This information provides repair recommendations and general guidelines for steel classified as Mild Steel. This type of steel normally has a tensile strength less than 270 MPa. This includes the common steel names of

1. Mild Steel
2. Bake Hardenable Steel (BH)
3. Solid Solution Strengthened Steel

General Motors recommends the following when repairing or replacing this type of steel during collision repair.

Recommended Repairs

1. Cold repairs can be performed on this type of steel, unless the damage includes kinks. If the damage includes kinks, the part should be replaced.
2. Controlled use of heat can be used to repair damage, if the heat does not exceed 650°C (1200°F). The heat should be applied a maximum of 2 times, for up to 90 seconds.
3. Sectioning or partial replacement of this type of steel is recommended only at approved locations, in a specific sectioning procedure.
4. This type of steel can be used as a sleeve, or backer plate, when recommended in a specific sectioning procedure.
5. Squeeze Resistance Spot Welding can be used to replace factory spot welds, where applicable
6. MIG plug welding and MIG stitch welding can be used on this type of steel.
7. MIG Brazing can be used on this type of steel.

Ultra High Strength Dual Phase Steel

This information provides repair recommendations and general guidelines for steel classified as Ultra High Strength Dual Phase Steel , also known as DPX. This type of steel normally has a tensile strength of 780 MPa, or greater.

General Motors recommends the following when repairing or replacing this type of steel during collision repair.

Note. Repair of this type of steel is not recommended. This type of steel should be replaced at factory joints only. Sectioning or partial replacement is not recommended. The use of heat to repair damage is not recommended for this type of steel. Stitch Welding is not recommended for this type of steel (unless replacing a factory installed stitch weld). This type of steel should not be used as a backing reinforcement or a sleeve for a sectioning joint.

Recommended Repairs

1. Squeeze Resistance Spot Welding can be used to replace factory spot welds, where applicable.
2. MIG plug welding can be used to replace factory spot welds.
3. MIG Brazing can be used to replace factory spot welds.

Ultra High Strength Steel

This information provides repair recommendations and general guidelines for steel classified as Ultra High Strength Steel, also known as UHSS. This type of steel normally has a tensile strength of 780 MPa, or greater.

This includes the common steel names of

1. Ultra High Strength Dual Phase Steel (DPX)
2. Martensitic Steel (M)
3. Boron/Press Hardened Steel (B)
4. Multi-Phase Steel (MP)
5. TRIP Steel (TR)

General Motors recommends the following when repairing or replacing this type of steel during collision repair.

Note. Repair of this type of steel is not recommended. This type of steel should be replaced only, at factory joints. Sectioning or partial replacement is not recommended. The use of heat to repair damage is not recommended for this type of steel. Stitch Welding is not recommended for this type of steel (unless replacing a factory installed stitch weld). This type of steel should not be used as a backing reinforcement or a sleeve for a sectioning joint.

Recommended Repairs

1. Squeeze Resistance Spot Welding can be used to replace factory spot welds, where applicable.
2. MIG plug welding can be used to replace factory spot welds.
3. MIG Brazing can be used to replace factory spot welds.

See also:
• Front Compartment Front Panel Replacement
• Approved Equipment for Collision Repair Warning
• Foam Sound Deadeners Warning
• Battery Disconnect Warning
• SIR Disabling and Enabling
• Anti-Corrosion Treatment and Repair
• Basecoat/Clearcoat Paint Systems
• Battery Negative Cable Disconnection and Connection
• Glass and Sheet Metal Handling Warning
• Collision Sectioning Warning
• Mild Steel
• Front Compartment Upper Side Rail Replacement
• Aluminum Panel Bonding
• High Strength Low Alloy Steel
• Dual Phase Steel
• Ultra High Strength Steel
• Ultra High Strength Dual Phase Steel
• Metal Panel Bonding (Steel)
