Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Cargo Tie Down Loop Fastener | 20 | 15 lb ft |
| Center Pillar Upper Garnish Molding Fastener | 3 | 27 lb in |
| Front Side Door Inside Handle Fastener | 2.5 | 22 lb in |
| Front Side Door Pull Handle Fastener | 1.5 | 13 lb in |
| Front Side Door Trim Panel Fastener | 2.5 | 22 lb in |
| Roof Rail Assist Handle Fastener | 6 | 53 lb in |
Fastener Tightening Specifications
Scheme 61
Scheme 61: Front Side Door Armrest Switch Mount Plate Replacement
| Callout | Component Name |
|---|
| 1 | Front Side Door Armrest Switch Mount Plate Assembly Procedure Using a flat-bladed plastic trim tool, start at the rear of the armrest switch plate and gently insert trim tool to lift the front side door armrest switch mount plate from the door trim assembly. Disconnect the electrical connector from the switch assembly. Transfer parts as necessary. |
Front Side Door Armrest Switch Mount Plate Replacement
Scheme 62
Scheme 62: Front Side Door Trim Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front side door armrest switch mount plate driver side. Refer to Front Side Door Armrest Switch Mount Plate Replacement . |
| 1 | Front Side Door Inside Handle Bolt Finish Cap NOTE: Use a suitable tool, place the tool between the notch located at the top of the door handle cap and the door handle. Turn the suitable tool clockwise releasing the door handle cap, exposing the handle fastener. |
| 2 | Front Side Door Inside Handle Fastener CAUTION: Refer to Fastener Caution . |
| 3 | Front Side Door Pull Handle Fastener (Qty: 2) |
| 4 | Front Side Door Trim Assembly Procedure Using the appropriate plastic trim tool loosen the retainers along the bottom of the door trim panel. Remove the door trim panel along with the front side door window inner sealing strip and metal retainer clips by pulling in an upwards direction. Pull upwards on the door lock retainer cable to disengage. Disconnect the electrical connector. Place the door trim panel on a clean flat surface. Remove the front side door window inner sealing strip and metal retainer clips from door trim panel. Refer to Front Side Door Window Inner Sealing Strip Replacement . When installing the door trim panel, reinstall metal clips and front side door window inner sealing strip prior to installing door trim panel. |
| NOTE |
|---|
| Use a suitable tool, place the tool between the notch located at the top of the door handle cap and the door handle. Turn the suitable tool clockwise releasing the door handle cap, exposing the handle fastener. |
Front Side Door Trim Replacement
Scheme 63
Scheme 63: Front Side Door Trim Panel Applique Replacement
| Callout | Component Name |
|---|
| 1 | Front Side Door Trim Panel Applique Assembly Procedure Use a plastic flat-bladed tool to disengage the front side door trim panel applique from the front side door trim. |
Front Side Door Trim Panel Applique Replacement
Scheme 64
Scheme 64: Front Side Door Garnish Molding Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front side door trim. Refer to Front Side Door Trim Replacement . |
| 1 | Front Side Door Garnish Molding Retainer (Qty: 2) |
| 2 | Front Side Door Garnish Molding Assembly Procedure Use a plastic flat-bladed tool to remove the push-in retainers. Ensure that the door weatherstrip is not trapped below the garnish molding once completely installed. Reposition the weatherstrip as necessary. |
Front Side Door Garnish Molding Replacement
Scheme 65
Scheme 65: Rear Side Door Trim Panel Applique Replacement
| Callout | Component Name |
|---|
| 1 | Rear Side Door Trim Panel Applique Assembly Procedure Using a flat-bladed tool, release the rear side door trim panel applique from the rear side door trim. |
Rear Side Door Trim Panel Applique Replacement
Scheme 66
Scheme 66: Rear Side Door Garnish Molding Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the rear side door trim. Refer to Rear Side Door Trim Replacement . |
| 1 | Rear Side Door Garnish Molding Retainer (Qty: 2) Procedure Use a door trim panel removal tool or equivalent to aid in the removal of the retainer. |
| 2 | Rear Side Door Garnish Molding Assembly Procedure Pull outward starting at the front and moving slowly rearward to remove the molding. Reposition the weatherstrip so it rests on top of the garnish molding and is not trapped below the molding. |
Rear Side Door Garnish Molding Replacement
Scheme 67
Scheme 67: Rear Side Door Armrest Switch Mount Plate Replacement
| Callout | Component Name |
|---|
| 1 | Rear Side Door Armrest Switch Mount Plate Assembly Procedure Use a flat-bladed plastic trim tool in order to release the rear side door armrest switch mount plate from the door trim assembly. Disconnect the electrical connector. Transfer parts as necessary. |
Rear Side Door Armrest Switch Mount Plate Replacement
Scheme 68
Scheme 68: Front Side Door Sill Trim Plate Replacement
| Callout | Component Name |
|---|
| 1 | Front Side Door Sill Trim Plate Assembly Procedure Pull toward the rear of the vehicle to disengage integral clips. Reposition the front floor panel carpet as needed. |
Front Side Door Sill Trim Plate Replacement
Scheme 69
Scheme 69: Rear Side Door Sill Garnish Molding Replacement
| Callout | Component Name |
|---|
| 1 | Rear Side Door Sill Garnish Molding Assembly Procedure Use the appropriate plastic trim tool to aid in the removal of the rear side door sill garnish molding. |
Rear Side Door Sill Garnish Molding Replacement
Scheme 70
Scheme 70: Rear Compartment Side Trim Panel Access Hole Cover Replacement
| Callout | Component Name |
|---|
| 1 | Rear Compartment Side Trim Panel Access Hole Cover Assembly Procedure Rotate the knob and pull outward to release the access hole cover from the rear compartment side trim - left side. |
Rear Compartment Side Trim Panel Access Hole Cover Replacement
Scheme 71
Scheme 71: Rear Compartment Side Trim Panel Stowage Compartment Cover Replacement
| Callout | Component Name |
|---|
| 1 | Rear Compartment Side Trim Panel Stowage Compartment Cover Assembly Procedure Rotate the panel lock knob so the widest part of the knob is aligned with the front and rear of the vehicle in the unlock position. Once the panel is unlocked, pull up to remove. |
Rear Compartment Side Trim Panel Stowage Compartment Cover Replacement
Scheme 72
Scheme 72: Roof Rail Assist Handle Replacement
| Callout | Component Name |
|---|
| 1 | Roof Rail Assist Handle Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Fold the assist handle downward and hold. Use a small flat-bladed tool to open the assist handle covers to access the screws. Tighten 6 (53 lb in) |
| 2 | Roof Rail Assist Handle Assembly |
Roof Rail Assist Handle Replacement
Scheme 73
Scheme 73: Sunshade Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Lower the front portion of the headliner to access the sunshade electrical connector and sunshade retainer. Refer to Headlining Trim Panel Replacement (With Sunroof) , Headlining Trim Panel Replacement (Without Sunroof) . |
| 1 | Sunshade Cover |
| 2 | Sunshade Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . |
| 3 | Sunshade Assembly Procedure Squeeze the tabs at the base of the sunshade assembly to detach it from the roof panel and allow the headliner with the sunshade attached to be lowered. Disconnect the electrical connector. Release the retainer attaching the sunshade to the headliner assembly. |
Scheme 74
Scheme 74: Sunshade Support Replacement
| Callout | Component Name |
|---|
| 1 | Sunshade Support Fastener CAUTION: Refer to Fastener Caution . NOTE: Pull the cover downward to access the fastener. |
| 2 | Sunshade Support Assembly Procedure Unclip the sunshade from the support and reposition. |
| NOTE |
|---|
| Pull the cover downward to access the fastener. |
Sunshade Support Replacement
Scheme 75
Scheme 75: Windshield Garnish Molding Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Disable the SIR system. Refer to SIR Disabling and Enabling . |
| 1 | Windshield Garnish Molding Assembly Procedure Disconnect the electrical connector. The tether clip at the upper portion of the garnish molding MUST be replaced every time the windshield side garnish molding is removed. |
Windshield Garnish Molding Replacement
Scheme 76
Scheme 76: Center Pillar Upper Trim Panel Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the center pillar lower trim panel. Refer to Center Pillar Lower Trim Panel Replacement . Remove the seat belt tensioner fastener and feed the seat belt through the center pillar upper trim panel. Refer to Front Seat Belt Anchor Plate Tensioner Replacement . Move the driver or passenger seat to the full forward position. |
| 1 | Center Pillar Upper Trim Panel Assembly Procedure Starting at the bottom, gently pull on the center pillar upper trim panel to disengage the retaining clips. When replacing the center pillar upper trim panel, feed the seat belt through the panel. Verify the upper tabs are fully seated between the headliner and the center pillar inner panel. |
Center Pillar Upper Trim Panel Replacement
Scheme 77
Scheme 77: Center Pillar Lower Trim Panel Replacement
Center Pillar Lower Trim Panel Replacement
Scheme 78
Scheme 78: Quarter Upper Trim Panel Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the rear seat cushion. Refer to Rear Seat Cushion Removal and Installation . Disable the SIR system. Refer to SIR Disabling and Enabling . |
| 1 | Inflatable Restraint Airbag Plate |
| 2 | Quarter Upper Trim Panel Fastener CAUTION: Refer to Fastener Caution . |
| 3 | Quarter Upper Trim Panel Assembly Procedure Remove the seat belt anchor bolt. Disconnect the seat belt through the slot in the escutcheon opening. |
Quarter Upper Trim Panel Replacement
Scheme 79
Scheme 79: Radio Windshield Side Garnish Molding Speaker Grille Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the windshield garnish molding. Refer to Windshield Garnish Molding Replacement . |
| 1 | Radio Windshield Side Garnish Molding Speaker Grille Procedure Release the four retaining tabs to release the radio windshield side garnish molding speaker grille from the windshield garnish molding. |
Radio Windshield Side Garnish Molding Speaker Grille Replacement
Scheme 80
Scheme 80: Rear Window Panel Trim Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the quarter upper trim panel. Refer to Quarter Upper Trim Panel Replacement . If equipped with AM9 (split folding seat), remove the rear seat back cushion bolster. Refer to Rear Seat Back Bolster Replacement . If not equipped with AM9 (non folding seat), remove the rear seat back cushion. Refer to Rear Seat Back Cushion Removal and Installation (40% Seat with AM9) , Rear Seat Back Cushion Removal and Installation (60% Seat with AM9) , Rear Seat Back Cushion Removal and Installation (without AM9) . |
| 1 | Rear Window Trim Panel Retainer (Qty: 3) |
| 2 | Rear Window Trim Panel Assembly Procedure Use a flat bladed tool to open the back cover on the center seat belt anchor buckle and depress the anchor release button. Lift up on the rear window panel to release the retainers under the forward portion of the panel. Route the center seat belt webbing, lower anchor bolt, bracket, buckle, and escutcheon through the trim. With the aid of an assistant, guide the rear window panel forward in the vehicle and upwards to clear the speaker system. When replacing the rear window panel trim assembly, transfer all necessary components. Ensure the rear window trim panel feet are seated into the rear window sheet metal drain shoe. |
Rear Window Panel Trim Replacement
Scheme 81
Scheme 81: Rear End Trim Finish Panel Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the rear compartment floor panel carpet. Refer to Rear Compartment Floor Panel Carpet Replacement . |
| 1 | Cargo Tie Down Loop Cap (Qty: 2) |
| 2 | Cargo Tie Down Loop Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 20 (15 lb ft) |
| 3 | Cargo Tie Down Loop Assembly |
| 4 | Rear End Trim Finish Panel Assembly |
Rear End Trim Finish Panel Replacement
Scheme 82
Scheme 82: Rear Compartment Floor Panel Trim Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the rear compartment floor panel carpet. Refer to Rear Compartment Floor Panel Carpet Replacement . |
| 1 | Rear Compartment Floor Panel Trim Retainer (Qty: 3) Procedure Open the rear compartment lid to access the retainers. Use a trim removal tool to aid in the removal of the retainers. |
| 2 | Rear Compartment Floor Panel Trim |
Rear Compartment Floor Panel Trim Replacement
Scheme 83
Scheme 83: Rear Side Door Trim Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the rear side door armrest switch mount plate. Refer to Rear Side Door Armrest Switch Mount Plate Replacement . |
| 1 | Rear Side Door Inside Handle Bolt Cap NOTE: Use a suitable tool, place the tool between the notch located at the top of the door handle cap and the door handle. Turn the suitable tool clockwise releasing the door handle cap, exposing the handle fastener. |
| 2 | Rear Side Door Inside Handle Fastener CAUTION: Refer to Fastener Caution . |
| 3 | Rear Side Door Armrest Pull Cup Fastener (Qty: 2) |
| 4 | Rear Side Door Trim Assembly Procedure Using the appropriate plastic trim tool loosen the retainers along the bottom of the door trim panel. Remove the door trim panel along with the rear side door window inner sealing strip and metal retainer clips by pulling in an upwards direction. Pull upwards on the door lock retainer cable to disengage. Disconnect the electrical connector. Place the door trim panel on a clean flat surface. Remove the rear side door window inner sealing strip and metal retainer clips from door trim panel. Refer to Rear Side Door Window Inner Sealing Strip Replacement . When installing the door trim panel, reinstall metal clips and rear side door window inner sealing strip prior to installing door trim panel. |
| NOTE |
|---|
| Use a suitable tool, place the tool between the notch located at the top of the door handle cap and the door handle. Turn the suitable tool clockwise releasing the door handle cap, exposing the handle fastener. |
Rear Side Door Trim Replacement
Scheme 84
Scheme 84: Rear Compartment Rear Window Lower Trim Replacement
| Callout | Component Name |
|---|
| 1 | Rear Compartment Rear Window Lower Trim Retainer (Qty: 6) Procedure Open the rear compartment lid to access retainers. Use a trim removal tool to aid in the removal of the retainers. |
| 2 | Rear Compartment Lid Hinge Cover Retainer (Qty: 2) Procedure Use a trim removal tool to aid in the removal of the retainers. |
| 3 | Rear Compartment Rear Window Lower Trim Assembly |
Rear Compartment Rear Window Lower Trim Replacement
Scheme 85
Scheme 85: Rear Compartment Lid Inner Panel Trim Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Remove rear compartment lid latch cover. Refer to Rear Compartment Lid Latch Cover Replacement . Unclip and reposition the upper portions of the rear compartment lid hinge covers. Refer to Rear Compartment Lid Hinge Cover Replacement . |
| 1 | Rear Compartment Lid Inside Handle Fastener CAUTION: Refer to Fastener Caution . Procedure Use a small flat-bladed tool to open integral cover to access fastener. |
| 2 | Rear Compartment Lid Inside Handle |
| 3 | Rear Compartment Lid Inner Panel Trim Assembly Procedure Use the appropriate plastic trim tool to aid in the removal of the rear compartment lid inner panel trim. |
Rear Compartment Lid Inner Panel Trim Replacement
Scheme 86
Scheme 86: Rear Compartment Lid Latch Cover Replacement
| Callout | Component Name |
|---|
| 1 | Rear Compartment Lid Latch Cover Assembly Procedure Use a small flat-bladed tool to pull and release the rear compartment lid latch cover. |
Rear Compartment Lid Latch Cover Replacement
Scheme 87
Scheme 87: Rear Compartment Side Trim Replacement - Left Side (With AM9)
Rear Compartment Side Trim Replacement - Left Side (With AM9)
Rear Compartment Side Trim Replacement - Left Side (Except AM9)
Rear Compartment Side Trim Replacement - Left Side (Except AM9)
Scheme 88
Scheme 88: Rear Compartment Side Trim Replacement - Right Side (With AM9)
Rear Compartment Side Trim Replacement - Right Side (With AM9)
Rear Compartment Side Trim Replacement - Right Side (Except AM9)
Rear Compartment Side Trim Replacement - Right Side (Except AM9)
Scheme 89
Scheme 89: Cargo Tie Down Loop Replacement
| Callout | Component Name |
|---|
| 1 | Cargo Tie Down Loop Bolt Cap (Qty: 2) |
| 2 | Cargo Tie Down Loop Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 20 (15 lb ft) |
| 3 | Cargo Tie Down Hook Assembly (Qty: 2) |
Cargo Tie Down Loop Replacement
Scheme 90
Scheme 90: Quarter Outer Panel Pressure Relief Valve Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the quarter outer panel pressure relief valve water shield. Refer to Quarter Outer Panel Pressure Relief Valve Water Shield Replacement . |
| 1 | Quarter Outer Panel Pressure Relief Valve (QTY: 2) Procedures Use a flat-bladed tool to release the locking tabs on the air pressure relief valve at the two upper, and two lower locations. Press the pressure relief valve into the quarter panel until the locking tabs lock in place at both the upper, and lower locations. |
Quarter Outer Panel Pressure Relief Valve Replacement
Scheme 91
Scheme 91: Quarter Outer Panel Pressure Relief Valve Water Shield Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the rear bumper upper fascia. Refer to Rear Bumper Upper Fascia Replacement . |
| 1 | Quarter Outer Panel Pressure Relief Valve Water Shield Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . |
| 2 | Quarter Outer Panel Pressure Relief Valve Water Shield (QTY: 2) |
Quarter Outer Panel Pressure Relief Valve Water Shield Replacement
