Body Rear End Buick Rendezvous I

Exterior Body Panels 62 illustrations ~6326 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Endgate Bellcrank Bolt10 N.m89 lb in
Endgate Bolt33 N.m28 lb ft
Endgate Handle Bolt10 N.m89 lb in
Endgate Latch Bolt10 N.m89 lb in
Endgate Nut33 N.m28 lb ft
Endgate Strikers25 N.m18 lb ft
Endgate Support Cable Bolt3 N.m27 lb in
Endgate Torque Rod Bolt10 N.m89 lb in
Fuel Filler Pocket Screw2 N.m18 lb in
Liftgate Hinge Bolt33 N.m28 lb ft
Liftgate Hinge Nut33 N.m28 lb ft
Liftgate Latch Bolt10 N.m89 lb in
Liftgate Spoiler Nuts6 N.m53 lb in
Liftgate Striker Bolt10 N.m89 lb in
Torque Rod Bracket Bolt25 N.m18 lb ft

Fastener Tightening Specifications

Scheme 1

Scheme 1: Body Rear End Schematics
Scheme 1: Body Rear End Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Body Rear End Component Views
Scheme 3: Body Rear End Component Views
CalloutComponent Name
1Endgate Harness
2Lock Cylinder - Endgate
3Lock Cylinder Switch - Endgate

Scheme 4

Scheme 4
Scheme 4
CalloutComponent Name
1C403
2Endgate Harness
3Endgate Latch - Right C1
4Endgate Latch- Right C2
5Lift Window Release Actuator - Right C1
6Lift Window Release Actuator - Right C2
7Lock Cylinder Switch - Endgate
8Lift Window Release Actuator - Left C2
9Lift Window Release Actuator - Left C1
10Endgate Latch - Left C2
11Endgate Latch - Left C1

Scheme 5

Scheme 5
Scheme 5
CalloutComponent Name
1Lift Window Release Actuator and Ajar Switch - Left
2Lift Window Release Actuator and Ajar Switch - Right
3Endgate Lock Actuator and Ajar Switch - Right
4Endgate Lock Actuator and Ajar Switch - Left

Scheme 6

Scheme 6
Scheme 6
CalloutComponent Name
1Liftgate Latch
2Liftgate

Endgate Latch Connector End - Left - C1 (Pontiac) Connector Part Information 12162190 4-Way F Metri-Pack 150.2 Series Sealed P2S (BLK) Pin Wire Color Circuit No. Function A BLK 450 Ground B YEL 656 Endgate Open Switch Signal C PNK/BLK 1303 Endgate Ajar Switch Signal D - - Not Used

Endgate Latch Connector End - Right - C1 (Pontiac) Connector Part Information 12162190 4-Way F Metri-Pack 150.2 Series Sealed P2S (BLK) Pin Wire Color Circuit No. Function A - - Not Used B PNK/BLK 1303 Endgate Ajar Switch Signal C YEL 656 Endgate Open Switch Signal D BLK 450 Ground

Endgate Latch Connector End - Left - C2 (Pontiac) Connector Part Information 15300027 2-Way F Metri-Pack 280 Series (BLK) Pin Wire Color Circuit No. Function A ORN 9294 Liftgate Motor Unlock B RED 9295 Liftgate Motor Lock

Endgate Latch Connector End - Right - C2 (Pontiac) Connector Part Information 15300027 2-Way F Metri-Pack 280 (BLK) Pin Wire Color Circuit No. Function A ORN 9294 Liftgate Motor Unlock B RED 9295 Liftgate Motor Lock

I/P Switch Assembly C1 Connector End (Pontiac) Connector Part Information 12162455 8-Way F 280 Series (NAT) Pin Wire Color Circuit No. Function A GRY 8 Instrument Panel Lamp Supply Voltage B BLK 150 Ground C WHT/BLK 1221 Liftgate Release Switch Signal D BRN/WHT 1571 Traction Control Switch Signal E-H - - Not Used

I/P Switch Assembly Connector End C1 (Buick) Connector Part Information 12041301 8-Way F Metri-Pack 280 (BLK) Pin Wire Color Circuit No. Function A GRY 8 Instrument Panel Lamp Supply Voltage B BLK 1450 Ground C-D - - Not Used E WHT/BLK 1221 Liftgate Release Switch Signal F GRY 391 Rear Window Wiper Switch Signal G YEL 343 Accessory Voltage H DK GRN 392 Rear Window Washer Pump Control

I/P Switch Assembly C2 Connector End Connector Part Information 12047976 8-Way F Metri-Pack 280 Series (BLU) Pin Wire Color Circuit No. Function A GRY 8 Instrument Panel Lamp Supply Voltage 1 B BLK 150 Ground C LT GRN 911 Rear Defog Relay Coil Supply Voltage D LT BLU 1462 Driver Heated Seat Switch Signal E LT BLU/BLK 1505 Front Passenger Heated Seat Switch Signal F-H - - Not Used

I/P Switch Assembly C3 Connector End (Buick) Connector Part Information 12162455 8-Way F 280 Series (NAT) Pin Wire Color Circuit No. Function A GRY 8 Instrument Panel Lamp Supply Voltage B BLK 150 Ground C-F - - Not Used G LT GRN 9380 Rear Parking Assist Disable Switch Signal H BRN 241 Ignition 3 Voltage

I/P Switch Assembly C4 - JM4 Connector End (Buick) Connector Part Information 12162455 8-Way F 280 Series (NAT) Pin Wire Color Circuit No. Function A GRY 8 Instrument Panel Lamp Supply Voltage B BLK 150 Ground C BRN/WHT 1571 Traction Control Switch Signal (NW9) D-H - - Not Used

Liftgate Latch - C1 Connector End (Buick) Connector Part Information 15354716 4-Way F MGT 150 Sealed (BLK) Pin Wire Color Circuit No. Function A - - Not Used B PNK/BLK 1303 Endgate Ajar Switch Signal C YEL 656 Endgate Open Switch Signal D BLK 1150 Ground

Liftgate Latch - C2 Connector End (Buick) Connector Part Information 15300027 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A WHT 1304 Liftgate Motor Lock Control B PPL 1305 Liftgate Lock Motor Unlock Control

Lift Window Latch Connector End - Left (Pontiac) Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A BLK 450 Ground B PPL 2279 Lift Glass Ajar Switch Signal C - - Not Used

Lift Window Lock Actuator Connector End - Left (Pontiac) Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT BLU 383 Lift Glass Release Control B BLK 450 Ground

Lift Window Latch Connector End - Right (Pontiac) Connector Part Information 12047781 3-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A BLK 450 Ground B RED/BLK 744 Lift Glass Ajar Switch Signal C - - Not Used

Lift Window Lock Actuator Connector End - Right (Pontiac) Connector Part Information 12052832 2-Way F Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function A LT BLU 383 Lift Glass Release Control B BLK 450 Ground

Lock Cylinder Switch Connector End - Endgate (Pontiac) Connector Part Information 15354699 2-Way M Metri-Pack 150 Series (WHT) Pin Wire Color Circuit No. Function A PPL 9124 Liftgate Release Switch Signal B BLK 450 Ground

Begin the system diagnosis with the Diagnostic System Check - Body Rear End . The Diagnostic System Check will provide the following information

  1. The identification of the control modules which command the system
  2. The ability of the control modules to communicate through the serial data circuit
  3. The identification of any stored diagnostic trouble codes (DTCs) and their status

The use of the Diagnostic System Check will identify the correct procedure for diagnosing the system and where the procedure is located.

Test Description

The number(s) below refer to the step number(s) on the diagnostic table.

  1. 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.
  2. 4: The presence of DTCs which begin with U indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.
StepActionYesNo
1Install a scan tool. Does the scan tool power up?Go to Step 2Go to Scan Tool Does Not Power Up in Data Link Communications
2Turn ON the ignition, with the engine OFF. Attempt to establish communication with the body control module (BCM) and the instrument panel cluster (IPC). Does the scan tool communicate with the BCM and the IPC?Go to Step 3Go to Scan Tool Does Not Communicate with Class 2 Device in Data Link Communications
3Select the BCM display DTCs function on the scan tool. Does the scan tool display any DTCs?Go to Step 4Go to Symptoms - Body Rear End
4Does the scan tool display any DTCs which begin with a U?Go to Scan Tool Does Not Communicate with Class 2 Device in Data Link CommunicationsGo to Step 5
5Does the scan tool display DTC B1000 or B1009?Go to Diagnostic Trouble Code (DTC) List in Body Control SystemGo to Step 6
6Does the scan tool display DTC B1327?Go to Diagnostic Trouble Code (DTC) List in Engine ElectricalGo to Diagnostic Trouble Code (DTC) List

Diagnostic System Check - Body Rear End

Scan Tool Output Controls

Scan Tool Output ControlAdditional Menu Selection(s)Description
Lift Glass RelayLift Glass ReleaseThe BCM pulses the lift glass actuators when you select On. The lift glass should open.
Liftgate Lock MotorLiftgate LockThe BCM pulses the liftgate lock actuator when you select Unlock. The liftgate should open.

Scan Tool Output Controls

Scan Tool Data List

Scan Tool ParameterData ListUnits DisplayedTypical Data Value
Ignition ON/Engine OFF/Vehicle in PARK
LH Lift Glass Ajar SwitchInputActive/InactiveInactive
Lift Glass RelayOutputOn/OffOff
Liftgate Ajar SwitchInputActive/InactiveInactive
Liftgate Key Cyl. Unlk. Sw.InputActive/InactiveInactive
Liftgate Lock MotorOutputOn/OffOff
Liftgate Open SwitchInputActive/InactiveInactive
Liftgate Unlock MotorOutputOn/OffOff
RH Lift Glass Ajar SwitchInputActive/InactiveInactive
Rear Release SwitchInputActive/InactiveInactive

Scan Tool Data List

Diagnostic Trouble Code (DTC) List

DTCDiagnostic ProcedureModule
B2732DTC B2732BCM
B3826DTC B3826BCM

Diagnostic Trouble Code (DTC) List

Circuit Description

The liftgate release switch provides a ground input to the BCM when the switch is closed. This input allows the BCM to detect when a key release switch request is received.

Conditions for Running the DTC

The BCM detects a fault on the circuit for more than 60 seconds.

Action Taken When the DTC Sets

The BCM stores DTC B2732 in memory.

Conditions for Clearing the DTC

  1. The BCM no longer detects a fault on the signal circuit for the liftgate release switch.
  2. A history DTC will clear after 100 consecutive ignition cycles if the malfunction no longer exists.
  3. A scan tool can be used to clear history and current DTCs.

Diagnostic Aids

The cause of the malfunction could be intermittent. Refer to Testing for Intermittent Conditions and Poor Connections .

StepActionYesNo
Schematic Reference: Body Rear End Schematics Connector End View Reference: Body Rear End Connector End Views and Body Control System Connector End Views
1Did you perform the Body Rear End Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Body Rear End
2Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, observe the rear release switch parameter in the BCM data list. Does the scan tool display Inactive?Go to Diagnostic AidsGo to Step 3
3Turn OFF the ignition. Disconnect the liftgate release switch. Turn ON the ignition, with the engine OFF. With a scan tool, observe the rear release switch parameter. Does the scan tool display inactive?Go to Step 6Go to Step 4
4Test the signal circuit of the rear release switch for a short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 5
5Inspect for poor connections at the harness connector of the BCM. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 7
6Inspect for poor connections at the harness connector of the liftgate release switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 8
7IMPORTANT: Perform the set up procedure for the BCM. Replace the Body Control Module (BCM). Refer to Body Control Module Replacement in Body Control Systems.Did you complete the replacement?Go to Step 9
8Replace the liftgate release switch. Did you complete the replacement?Go to Step 9
9Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset?Go to Step 2System OK
IMPORTANT
Perform the set up procedure for the BCM.

DTC B2732

The liftgate key cylinder switch provides a ground input to the BCM when the switch is closed. This input allows the BCM to detect when a key unlock request is received.

The BCM detects a fault on the circuit for more than 60 seconds.

The BCM stores DTC B3826 in memory.

  1. The BCM no longer detects a fault on the signal circuit for the liftgate key unlock switch.
  2. A history DTC will clear after 100 consecutive ignition cycles if the malfunction no longer exists.
  3. A scan tool can be used to clear history and current DTCs.

The cause of the malfunction could be intermittent. Refer to Testing for Intermittent Conditions and Poor Connections .

StepActionYesNo
Schematic Reference: Body Rear End Schematics Connector End View Reference: Body Rear End Connector End Views and Body Control System Connector End Views
1Did you perform the Body Rear End Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Body Rear End
2Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, observe the liftgate key cylinder unlock parameter in the BCM data list. Does the scan tool display inactive?Go to Diagnostic AidsGo to Step 3
3Turn OFF the ignition. Disconnect the liftgate key cylinder switch. Turn ON the ignition, with the engine OFF. With a scan tool, observe the liftgate key cylinder unlock parameter. Does the scan tool display inactive?Go to Step 6Go to Step 4
4Test the signal circuit of the liftgate key cylinder unlock switch for a short to ground or an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 5
5Inspect for poor connections at the harness connector of the BCM. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 7
6Inspect for poor connections at the harness connector of the liftgate key cylinder switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 9Go to Step 8
7IMPORTANT: Perform the set up procedure for the BCM. Replace the Body Control Module (BCM). Refer to Body Control Module Replacement in Body Control Systems.Did you complete the replacement?Go to Step 9
8Replace the liftgate key cylinder switch. Refer to Lock Cylinder Replacement - Endgate in Body Rear End. Did you complete the replacement?Go to Step 9
9Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset?Go to Step 2System OK
IMPORTANT
Perform the set up procedure for the BCM.

DTC B3826

IMPORTANTThe following steps must be completed before using the symptom tables.
  1. Perform the before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control module(s) can communicate via the serial data link.
  2. Review the system operation in order to familiarize yourself with the system functions: Refer to «Rear Hatch/Gate Description and Operation (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end__rear-hatchgate-description-and-operation-aztek) or «Rear Hatch/Gate Description and Operation (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end__rear-hatchgate-description-and-operation-rendezvous) . Refer to «Rear Hatch/Gate Ajar Indicator Description and Operation (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Rear Hatch/Gate Ajar Indicator Description and Operation (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .

Visual/Physical Inspection

  1. Inspect for aftermarket devices which could affect the operation of the system. Refer to «Checking Aftermarket Accessories»(/buick/rendezvous/i-2001-2007/remont/body-electrical/#wiring-systems-diagnostic-information-and-procedures__checking-aftermarket-accessories) in Wiring Systems.
  2. Inspect the easily accessible or visible system components for obvious damage or conditions which could cause the symptom.

Intermittent

Faulty electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections in Wiring Systems.

Symptom List

Refer to a symptom diagnostic procedure from the following list in order to diagnose the symptom

  1. «Hatch Release Inoperative (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end__hatch-release-inoperative-rendezvous)
  2. «Rear Window Release Inoperative (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end__rear-window-release-inoperative-aztek)
  3. «Rear Hatch/Gate Ajar Indicator Malfunction (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end__rear-hatchgate-ajar-indicator-malfunction-aztek) or «Rear Hatch/Gate Ajar Indicator Malfunction (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end__rear-hatchgate-ajar-indicator-malfunction-rendezvous)

Hatch Release Inoperative (Rendezvous)

StepActionYesNo
Schematic Reference: Body Rear End Schematics Connector End View Reference: Body Rear End Connector End Views , Body Control System Connector End Views and Electrical Center Identification Views
1Did you perform the Body Rear End Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Body Rear End
2Verify that the hatch release is inoperative. Does the hatch release operate normally?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool command the liftgate lock motor to Unlock. Does the liftgate open?Go to Step 5Go to Step 4
4Probe the liftgate/endgate lock motor unlock control circuit of the BCM C1 harness connector with a test lamp that is connected to a good ground. With a scan tool command the liftgate lock motor to Unlock. Does the test lamp illuminate?Go to Step 7Go to Step 8
5Disconnect the liftgate release switch. Probe the liftgate release switch signal circuit of the liftgate release switch harness connector with a test lamp that is connected to a good ground. Does the test lamp illuminate?Go to Step 6Go to Step 9
6Connect a test lamp between the liftgate release switch signal circuit of the liftgate release switch harness connector and the ground circuit of the liftgate release switch harness connector. Does the test lamp illuminate?Go to Step 10Go to Step 13
7Test the liftgate/endgate lock motor lock control circuit for an open. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 11
8Test the liftgate/endgate lock motor unlock control circuit for a short to ground or an open. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 12
9Test the liftgate release switch signal circuit for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 12
10Inspect for poor connections at the harness connector of the liftgate release switch. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 14
11Inspect for poor connections at the harness connector of the liftgate lock actuator. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 15
12Inspect for poor connections at the harness connector of the body control module. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17Go to Step 16
13Repair the open in the liftgate release switch ground circuit. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 17
14Replace the liftgate release switch. Did you complete the replacement?Go to Step 17
15Replace the liftgate lock actuator. Did you complete the replacement?Go to Step 17
16IMPORTANT: When replacing the BCM refer to Body Control Module (BCM) Programming/RPO Configuration in Body Control Systems. Replace the BCM. Refer to Body Control Module Replacement in Body Control Systems.Did you complete the replacement?Go to Step 17
17Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 2
IMPORTANT
When replacing the BCM refer to Body Control Module (BCM) Programming/RPO Configuration in Body Control Systems.

Hatch Release Inoperative (Rendezvous)

Rear Window Release Inoperative (Aztek)

StepActionYesNo
Schematic Reference: Body Rear End Schematics Connector End View Reference: Body Rear End Connector End Views , Body Control System Connector End Views and Electrical Center Identification Views
1Did you perform the Body Rear End Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Body Rear End
2Verify that the rear window release is inoperative. Does the rear window release operate normally?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool command the lift glass relay ON. Does the lift glass open?Go to Step 5Go to Step 4
4Probe the lift glass release control circuit of the BCM C1 harness connector with a test lamp that is connected to a good ground. With a scan tool command the lift glass relay ON. Does the test lamp illuminate?Go to Step 10Go to Step 11
5Is the lift glass inoperative from the lift window release switch?Go to Step 6Go to Step 8
6Disconnect the lift window release switch. Probe the lift window release switch signal circuit of the lift window release switch harness connector with a test lamp that is connected to a good ground. Does the test lamp illuminate?Go to Step 7Go to Step 12
7Connect a test lamp between the lift window release switch signal circuit of the lift window release switch harness connector and the ground circuit of the lift window release switch harness connector. Does the test lamp illuminate?Go to Step 14Go to Step 18
8Disconnect the endgate lock cylinder switch. Probe the liftgate release switch signal circuit of the endgate lock cylinder switch harness connector with a test lamp that is connected to a good ground. Does the test lamp illuminate?Go to Step 9Go to Step 13
9Connect a test lamp between the liftgate release switch signal circuit of the endgate lock cylinder switch harness connector and the ground circuit of the endgate lock cylinder switch harness connector. Does the test lamp illuminate?Go to Step 15Go to Step 19
10Test the lift window lock actuator ground circuit for an open. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 24Go to Step 16
11Test the lift glass release control circuit for a short to ground or an open. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 24Go to Step 17
12Test the lift window release switch signal circuit for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 24Go to Step 17
13Test the liftgate release switch signal circuit for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 24Go to Step 17
14Inspect for poor connections at the harness connector of the lift window release switch. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 24Go to Step 20
15Inspect for poor connections at the harness connector of the endgate lock cylinder switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs . Did you find and correct the condition?Go to Step 24Go to Step 21
16Inspect for poor connections at the harness connector of the appropriate lift window lock actuator. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 24Go to Step 22
17Inspect for poor connections at the harness connector of the body control module. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 24Go to Step 23
18Repair the open in the lift window release switch ground circuit. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 24
19Repair the open in the endgate lock cylinder switch ground circuit. Refer to Testing for Intermittent Conditions and Poor Connections and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 24
20Replace the lift window release switch. Did you complete the replacement?Go to Step 24
21Replace the endgate lock cylinder switch. Refer to Lock Cylinder Replacement - Endgate . Did you complete the replacement?Go to Step 24
22Replace the lift window lock actuator. Did you complete the replacement?Go to Step 24
23IMPORTANT: When replacing the BCM refer to Body Control Module (BCM) Programming/RPO Configuration in Body Control Systems. Replace the BCM. Refer to Body Control Module Replacement in Body Control Systems.Did you complete the replacement?Go to Step 24
24Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 2
IMPORTANT
When replacing the BCM refer to Body Control Module (BCM) Programming/RPO Configuration in Body Control Systems.

Rear Window Release Inoperative (Aztek)

Rear Hatch/Gate Ajar Indicator Malfunction (Aztek)

StepActionYesNo
Schematic Reference: Body Rear End Schematics Connector End View Reference: Body Rear End Connector End Views and Body Control System Connector End Views
1Did you perform the Body Rear End Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Body Rear End
2Verify that the rear hatch/gate ajar indicator malfunction is present. Does the rear hatch/gate ajar indicator operate normally?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Is the rear hatch/gate ajar indicator inoperative?Go to Step 4Go to Step 5
4Install a scan tool. Turn ON the ignition with the engine OFF. Open the liftgate. With a scan tool, observe the LH lift glass ajar switch and RH lift glass ajar switch parameters in the Body Control Module data list. Does the scan tool display inactive?Go to Step 6Go to Step 11
5Install a scan tool. Turn ON the ignition with the engine OFF. Close the liftgate. With a scan tool, observe the LH lift glass ajar switch and RH lift glass ajar switch parameters in the Body Control Module data list. Does the scan tool display inactive?Go to Step 11Go to Step 7
6Turn OFF the ignition. Disconnect the left and right lift window latch harness connectors. Turn ON the ignition with the engine OFF. Connect a 3-amp fused jumper wire between the lift glass ajar switch signal circuit of the left lift window latch harness connector and a good ground. Connect a 3-amp fused jumper wire between the lift glass ajar switch signal circuit of the right lift window latch harness connector and a good ground. Does the rear hatch/gate ajar indicator illuminate?Go to Step 8Go to Step 9
7Turn OFF the ignition. Disconnect the left and right lift window latch harness connectors. Turn ON the ignition with the engine OFF. With a scan tool, observe the LH lift glass ajar switch and RH lift glass ajar switch parameters in the Body Control Module data list. Does the scan tool display inactive?Go to Step 12Go to Step 10
8Connect a 3-amp fused jumper wire between the lift glass ajar switch signal circuit of the left lift window latch harness connector and a the lift glass ajar switch ground circuit of the left lift window latch harness connector. Connect a 3-amp fused jumper wire between the lift glass ajar switch signal circuit of the right lift window latch harness connector and a the lift glass ajar switch ground circuit of the right lift window latch harness connector. Does the rear hatch/gate ajar indicator illuminate?Go to Step 12Go to Step 14
9Test the lift glass ajar switch signal circuits for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 18Go to Step 13
10Test the lift glass ajar switch signal circuits for a short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 18Go to Step 13
11Inspect for poor connections at the harness connector of the instrument panel cluster (IPC). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 18Go to Step 15
12Inspect for poor connections at the harness connector of the appropriate lift window latch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 18Go to Step 16
13Inspect for poor connections at the harness connector of the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 18Go to Step 17
14Repair the open in the lift glass ajar switch ground circuit. Refer to Wiring Repairs and Connector Repairs in Wiring Systems. Did you complete the repair?Go to Step 18
15Replace the IPC. Refer to Instrument Panel Cluster (IPC) Replacement in Instrument Panel, Gages, and Console. Did you complete the repair?Go to Step 18
16Replace the appropriate lift window latch. Did you complete the replacement?Go to Step 18
17IMPORTANT: When replacing the BCM, refer to Body Control Module (BCM) Programming/RPO Configuration in Body Control System. Replace the BCM. Refer to Body Control Module Replacement in Body Control System.Did you complete the replacement?Go to Step 18
18Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 2
IMPORTANT
When replacing the BCM, refer to Body Control Module (BCM) Programming/RPO Configuration in Body Control System.

Rear Hatch/Gate Ajar Indicator Malfunction (Aztek)

Rear Hatch/Gate Ajar Indicator Malfunction (Rendezvous)

StepActionYesNo
Schematic Reference: Body Rear End Schematics Connector End View Reference: Body Rear End Connector End Views and Body Control System Connector End Views
1Did you perform the Body Rear End Diagnostic System Check?Go to Step 2Go to Diagnostic System Check - Body Rear End
2Verify that the rear hatch/gate ajar indicator malfunction is present. Does the rear hatch/gate ajar indicator operate normally?Go to Testing for Intermittent Conditions and Poor Connections in Wiring SystemsGo to Step 3
3Is the rear hatch/gate ajar indicator inoperative?Go to Step 4Go to Step 5
4Install a scan tool. Turn ON the ignition with the engine OFF. Open the liftgate. With a scan tool, observe the liftgate ajar switch parameter in the Body Control Module data list. Does the scan tool display inactive?Go to Step 6Go to Step 11
5Install a scan tool. Turn ON the ignition with the engine OFF. Close the liftgate. With a scan tool, observe the liftgate ajar switch parameter in the Body Control Module data list. Does the scan tool display inactive?Go to Step 11Go to Step 7
6Turn OFF the ignition. Disconnect the liftgate latch harness connector. Turn ON the ignition with the engine OFF. Connect a 3-amp fused jumper wire between the endgate/liftgate ajar switch signal circuit of the liftgate latch harness connector and a good ground. Does the rear hatch/gate ajar indicator illuminate?Go to Step 8Go to Step 9
7Turn OFF the ignition. Disconnect the liftgate latch harness connector. Turn ON the ignition with the engine OFF. With a scan tool, observe the liftgate ajar switch parameter in the Body Control Module data list. Does the scan tool display inactive?Go to Step 12Go to Step 10
8Connect a 3-amp fused jumper wire between the endgate/liftgate ajar switch signal circuit of the liftgate latch harness connector and the endgate/liftgate ajar switch ground circuit of the liftgate latch harness connector. Does the rear hatch/gate ajar indicator illuminate?Go to Step 12Go to Step 14
9Test the endgate/liftgate ajar switch signal circuit for an open. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 18Go to Step 13
10Test the endgate/liftgate ajar switch signal circuit for a short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 18Go to Step 13
11Inspect for poor connections at the harness connector of the instrument panel cluster. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 18Go to Step 15
12Inspect for poor connections at the harness connector of the liftgate latch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 18Go to Step 16
13Inspect for poor connections at the harness connector of the body control module. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition?Go to Step 18Go to Step 17
14Repair the open in the endgate/liftgate ajar switch ground circuit. Refer to Wiring Repairs and Connector Repairs in Wiring Systems. Did you complete the repair?Go to Step 18
15Replace the instrument panel cluster (IPC). Refer to Instrument Panel Cluster (IPC) Replacement in Instrument Panel, Gages, and Console. Did you complete the repair?Go to Step 18
16Replace the liftgate latch. Did you complete the replacement?Go to Step 18
17IMPORTANT: When replacing the body control module (BCM), refer to Body Control Module (BCM) Programming/RPO Configuration in Body Control System. Replace the BCM. Refer to Body Control Module Replacement in Body Control System.Did you complete the replacement?Go to Step 18
18Operate the system in order to verify the repair. Did you correct the condition?System OKGo to Step 2
IMPORTANT
When replacing the body control module (BCM), refer to Body Control Module (BCM) Programming/RPO Configuration in Body Control System.

Rear Hatch/Gate Ajar Indicator Malfunction (Rendezvous)

Scheme 7

Scheme 7: Opening the Liftgate When There Is an Electrical Failure (Aztek)
Scheme 7: Opening the Liftgate When There Is an Electrical Failure (Aztek)

Scheme 8

Scheme 8
Scheme 8
  1. Open the rear door.
  2. Mark the location on each side of the endgate trim panel for the holes to be drilled using the following dimensions: Dimension (a) is 63 mm (2.5 in.) from the feature line on the endgate trim panel. Dimension (b) is 114 mm (4.5 in.) from the edge of the endgate trim panel.
  3. Using a 22 mm (.875 in) drill bit, drill a hole in the endgate trim panel at the marked locations.
  4. Insert a flat bladed tool in to the access hole and rotate the endgate latch clockwise to release.
  5. Open the liftgate.
  6. Open the endgate.
  7. Plug the access holes using GM P/N 88954014.
  8. If necessary, paint to match. Refer to «Plastic Identification and Refinishing Systems»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#plastic-panel-information-and-repair__plastic-identification-and-refinishing-systems) in Plastic Panel Information and Repair.

Opening the Liftgate When There Is an Electrical Failure (Rendezvous)

  1. Use a small flat-bladed tool to remove the plug from the liftgate trim panel.
  2. Inset a flat-bladed tool in to the access hole and rotate the liftgate latch clockwise to release.
  3. Open the liftgate.

Scheme 9

Scheme 9: Removal Procedure
Scheme 9: Removal Procedure

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11
  1. Open the endgate.
  2. Remove the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  3. Disconnect the electrical connectors from the liftgate latches.
  4. Remove the bolts from the liftgate latches.
  5. Remove the liftgate latches from the endgate.

Installation Procedure

IMPORTANTMake sure the child safety lock feature is not engaged before installing the liftgate latches.
  1. Install the liftgate latches to the endgate. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the bolts to the liftgate latches. Tighten: Tighten the liftgate latch bolts to 10 N.m (89 lb in).
  3. Connect the electrical connectors to the liftgate latches.
  4. Install the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  5. Close the endgate.

Tools Required

J 38778: Door Trim Pad and Garnish Clip Remover. See Special Tools and Equipment .

Scheme 12

Scheme 12: Removal Procedure
Scheme 12: Removal Procedure
  1. Open the endgate.
  2. Remove the endgate inside handle from the endgate. Refer to «Handle Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  3. Remove the endgate trim panel from the endgate inner panel using J 38778 .
IMPORTANTBefore installing the endgate trim panel to the endgate inner panel, the old trim panel retainers MUST be discarded and replaced with NEW trim panel retainers.
  1. Install the new trim panel retainers to the endgate trim panel.
  2. Align the endgate trim panel to the endgate inner panel.
  3. Install the endgate trim panel by firmly pressing in the area of the retainer clips until the clips are fully seated around the perimeter of the endgate trim panel.
  4. Install the endgate inside handle to the endgate. Refer to «Handle Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  5. Close the endgate.

Scheme 13

Scheme 13: Removal Procedure
Scheme 13: Removal Procedure

Scheme 14

Scheme 14
Scheme 14
  1. Open the liftgate.
  2. Remove the lower liftgate trim panel sides by pulling the left and right sides from the liftgate frame.
  3. Remove the lower liftgate trim panel from the pinch-weld flange by pulling up from the pinch-weld flange.
  4. Remove the lower liftgate trim panel from the vehicle.
  5. Remove the upper liftgate trim panel sides by pulling the left and right sides from the liftgate frame.
  6. Remove the upper liftgate trim panel from the pinch-weld flange by pulling up from the pinch-weld flange.
  7. Remove the upper liftgate trim panel from the vehicle.
  1. Install the upper liftgate trim panel to the liftgate by pressing down until fully seated.
  2. Position the defogger harness to the cutout in the upper trim panel.
  3. Install the right and the left side upper trim panel by pressing in until seated.
  4. Install the lower trim panels. Press down on the panels until fully seated.
  5. Install the right and left sides of the lower trim panels, pressing in until fully seated.
  6. Close the liftgate.

J 38778: Door Trim Pad and Garnish Clip Remover. See Special Tools and Equipment .

Scheme 15

Scheme 15: Removal Procedure
Scheme 15: Removal Procedure
  1. Raise the lift gate.
  2. Remove the access trim panel from the lift gate.
  3. Remove 2 screws from the bottom of the trim panel.
  4. Use J 38778 to disengage the fasteners from the trim panel.
  5. Remove the trim panel.
  1. Install the trim panel to the lift gate. IMPORTANT: Discard the old trim panel fasteners. Install new fasteners.
  2. Install new fasteners to the trim panel. NOTE: Refer to Fastener Notice in Cautions and Notices.
  3. Install the screws to the bottom of the trim panel. Tighten: Tighten the screws to 2 N.m (18 lb in).
  4. Install the access trim panel to the lift gate.
  5. Close the lift gate.

Scheme 16

Scheme 16: Removal Procedure
Scheme 16: Removal Procedure
  1. Remove the liftgate trim panel. Refer to «Trim Panel Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Trim Panel Replacement - Liftgate (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  2. Remove the liftgate water deflector.
  3. Clean liftgate surface using GM P/N 3984 adhesive remover or equivalent.
  1. Align the liftgate door water deflector to the liftgate inner panel.
  2. Secure the water deflector at the corners.
  3. Install the liftgate water deflector, start pressing the adhesive pattern at the bottom center and working outward and upward in order to prevent puckering.
  4. Install the liftgate trim panel. Refer to «Trim Panel Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Trim Panel Replacement - Liftgate (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .

Scheme 17

Scheme 17: Removal Procedure
Scheme 17: Removal Procedure
  1. Remove the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  2. Remove the endgate water deflector.
  3. Clean endgate surface using GM P/N 3984 adhesive remover or equivalent.
  1. Align the endgate door water deflector to the endgate inner panel.
  2. Secure the water deflector at the corners.
  3. Starting at the bottom center, press the adhesive outward and upward to prevent puckering.
  4. Install the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .

Scheme 18

Scheme 18: Removal Procedure
Scheme 18: Removal Procedure
  1. Open the lift gate.
  2. Remove the screw from the pullstrap.
  3. Remove the pullstrap
  1. Install the pullstrap to the lift gate. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the screws to the pullstrap. Tighten: Tighten the pullstrap screws to 1.9 N.m (17 lb in).
  3. Close the lift gate.

Scheme 19

Scheme 19: Removal Procedure
Scheme 19: Removal Procedure

Scheme 20

Scheme 20
Scheme 20
  1. Release the locking tabs on the lift gate trim panel access panel and remove the access panel.
  2. Remove the wing nuts from the studs on the lift gate applique.
  3. Remove the lift gate applique nuts.
  4. Partially remove the lift gate applique to access the electrical connector.
  5. Disconnect the lift gate applique electrical connector.
  6. Remove the lift gate applique.
  7. Remove the license plate lamp sockets from the lift gate applique.
  8. Remove the lift gate applique lamp sockets from the lift gate applique.
  9. Remove the backup lamp sockets and harness from the lift gate applique.
  1. Install the backup lamp sockets and harness to the lift gate applique.
  2. Install the lift gate applique lamp sockets to the lift gate applique.
  3. Install the license plate lamp sockets to the lift gate applique.
  4. Connect the lift gate applique electrical connector.
  5. Install the lift gate applique to the lift gate. NOTE: Refer to Fastener Notice in Cautions and Notices.
  6. Install the lift gate applique nuts. Tighten: Tighten the lift gate applique nuts to 10 N.m (89 lb in).
  7. Install the wing nuts to the studs on the lift gate applique.
  8. Hand tighten the wing nuts.
  9. Install the lift gate trim panel access panel and engage the locking tabs. Refer to «Trim Panel Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Trim Panel Replacement - Liftgate (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .

Scheme 21

Scheme 21: Removal Procedure
Scheme 21: Removal Procedure

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23
  1. Remove the liftgate trim. Refer to «Trim Panel Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Trim Panel Replacement - Liftgate (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  2. Remove the rear liftgate spoiler water channel.
  3. Remove the rear liftgate spoiler nuts.
  4. Using a thin-bladed tool, cut the adhesive tape along the upper edge of the rear spoiler.
  5. Using a thin-bladed tool, cut the adhesive tape along the lower edge of the rear spoiler.
  6. Remove the rear spoiler from the liftgate.
  7. Clean the vehicle mounting surface and the rear spoiler using Varnish Makers and Painters (VMP) naphtha.
IMPORTANTDo not touch the adhesive backing.
  1. Remove the backing tape from the underside of the spoiler.
  2. Install the rear spoiler to the liftgate, pressing into place until the adhesive is fully seated. NOTE: Refer to Fastener Notice in Cautions and Notices.
  3. Install the nuts to the rear liftgate spoiler. Tighten: Tighten the rear liftgate spoiler nuts to 6 N.m (53 lb in).
  4. Install the rear liftgate spoiler water channel.
  5. Install the liftgate trim. Refer to «Trim Panel Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Trim Panel Replacement - Liftgate (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .

Scheme 24

Scheme 24: Removal Procedure
Scheme 24: Removal Procedure

Scheme 25

Scheme 25
Scheme 25
  1. Open the fuel filler door.
  2. Remove the fuel filler cap.
  3. Remove the fuel filler pocket. Refer to «Fuel Filler Pocket Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Fuel Filler Pocket Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  4. Remove the screws from the fuel filler door.
  5. Remove the fuel filler door from the vehicle.
  6. Remove the fuel filler cap from the fuel filler door.
  1. Install the fuel filler cap to the fuel filler door. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Position the fuel filler door to the vehicle.
  3. Install the fuel filler door screws. Tighten: Tighten the fuel filler door screws to 10 N.m (89 lb in).
  4. Install the fuel filler pocket. Refer to «Fuel Filler Pocket Replacement (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Fuel Filler Pocket Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  5. Install the fuel filler cap.
  6. Close the fuel filler door.

Scheme 26

Scheme 26: Removal Procedure
Scheme 26: Removal Procedure

Scheme 27

Scheme 27
Scheme 27
  1. Remove the screw from the fuel filler pocket.
  2. Remove the fuel filler cap from the fuel filler neck.
  3. Remove the fuel filler pocket from the fuel filler neck.
  4. Remove the fuel filler cap from the fuel filler pocket by compressing the retainer on the fuel filler cap tether and pulling through the fuel filler pocket drain hole.
  1. Install the fuel filler cap to the fuel filler pocket by compressing the retainer on the fuel filler cap tether and pushing the tether through the fuel filler pocket drain hole.
  2. Install the fuel filler pocket to the fuel filler neck, pressing into place until fully seated. NOTE: Refer to Fastener Notice in Cautions and Notices.
  3. Install the screw to the fuel filler pocket. Tighten: Tighten the fuel filler pocket screw to 2 N.m (18 lb in).
  4. Install the fuel filler cap to the fuel filler neck.

Scheme 28

Scheme 28: Removal Procedure
Scheme 28: Removal Procedure
  1. Remove the fuel filler cap from the fuel filler neck.
  2. Remove the fuel filler neck seal from the fuel filler neck.
  3. Remove the screws from the fuel filler pocket.
  4. Remove the fuel filler pocket from the fuel filler neck.
  1. Install the fuel filler pocket to the fuel filler neck, pressing into place until fully seated. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the screws to the fuel filler pocket. Tighten: Tighten the fuel filler pocket screw to 2 N.m (18 lb in).
  3. Install the fuel filler neck seal to the fuel filler neck.
  4. Install the fuel filler cap to the fuel filler neck.

Scheme 29

Scheme 29: Removal Procedure
Scheme 29: Removal Procedure

Scheme 30

Scheme 30
Scheme 30
  1. Remove liftgate trim panel. Refer to «Trim Panel Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Trim Panel Replacement - Liftgate (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  2. Remove the liftgate window. Refer to «Window Replacement - Liftgate (Pontiac)»(/buick/rendezvous/i-2001-2007/remont/heated-glassdefoggers/#stationary-window-system__window-replacement-liftgate-pontiac) or «Window Replacement - Liftgate (Buick)»(/buick/rendezvous/i-2001-2007/remont/heated-glassdefoggers/#stationary-window-system__window-replacement-liftgate-buick) in Stationary Windows.
  3. Remove the liftgate latch strikers. Refer to «Latch Striker Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Latch Striker Replacement - Liftgate (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  4. Remove the liftgate bumper mounting brackets.
  5. Disconnect the liftgate electrical connector.
  6. Remove the liftgate struts. Refer to «Strut Replacement - Liftgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  7. Mark the location of the liftgate hinges to the liftgate with a grease pencil.
  8. Remove the bolts from the liftgate hinges, with an assistant.
  9. Remove the liftgate from the vehicle, with an assistant and place outside face down on a clean padded surface.
  1. Position the liftgate hinges to the marked location points on the liftgate, with an assistant. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the bolts to the liftgate hinges, with an assistant. Tighten: Tighten the liftgate hinge bolts to 33 N.m (28 lb ft).
  3. Install the liftgate struts. Refer to «Strut Replacement - Liftgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  4. Connect the liftgate electrical connector.
  5. Install the liftgate latch strikers. Refer to «Latch Striker Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Latch Striker Replacement - Liftgate (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  6. Install the liftgate bumper mounting brackets.
  7. Install the liftgate window. Refer to «Window Replacement - Liftgate (Pontiac)»(/buick/rendezvous/i-2001-2007/remont/heated-glassdefoggers/#stationary-window-system__window-replacement-liftgate-pontiac) or «Window Replacement - Liftgate (Buick)»(/buick/rendezvous/i-2001-2007/remont/heated-glassdefoggers/#stationary-window-system__window-replacement-liftgate-buick) in Stationary Windows.
  8. Install the upper and lower liftgate trim panels. Refer to «Trim Panel Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Trim Panel Replacement - Liftgate (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  9. Adjust the liftgate as required. Refer to «Hinge Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end)

Scheme 31

Scheme 31: Removal Procedure
Scheme 31: Removal Procedure

Scheme 32

Scheme 32
Scheme 32
  1. Remove the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  2. Remove the endgate water deflector. Refer to «Water Deflector Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  3. Remove the endgate handle. Refer to «Handle Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  4. Remove the endgate bellcrank. Refer to «Bellcrank Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  5. Remove the endgate latches. Refer to «Latch Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  6. Remove the liftgate latches. Refer to «Latch Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  7. Remove the endgate lock cylinder. Refer to «Lock Cylinder Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  8. Remove the endgate weatherstrip. Refer to «Weatherstrip Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  9. Remove the endgate hinge bolts.
  10. Remove the endgate from the vehicle, with an assistant.
  11. Remove the endgate wiring harness.
  12. Remove the endgate rear panel molding. Refer to «Molding Replacement - Rear Panel»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#exterior-trim) .
  1. Align the endgate to the vehicle, with an assistant. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the endgate hinge bolts. Tighten: Tighten the endgate hinge bolts to 33 N.m (28 lb ft).
  3. Install the endgate rear panel molding. Refer to «Molding Replacement - Rear Panel»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#exterior-trim) .
  4. Install the endgate wiring harness.
  5. Install the endgate weatherstrip. Refer to «Weatherstrip Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  6. Install the endgate lock cylinder. Refer to «Lock Cylinder Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  7. Install the liftgate latches. Refer to «Latch Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  8. Install the endgate latches. Refer to «Latch Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end)
  9. Install the endgate bellcrank. Refer to «Bellcrank Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  10. Install the endgate handle. Refer to «Handle Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  11. Install the endgate water deflector. Refer to «Water Deflector Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  12. Install the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .

Removal Procedure

  1. Open the liftgate.
  2. Open the endgate.
  3. Disconnect the electrical harness from the endgate.
  4. Remove the bolts from the endgate hinge to endgate.
  5. Remove the endgate, with an assistant.
  6. Remove the endgate nuts from the endgate hinge.
  7. Remove the endgate hinge from the rear body panel.
  1. Align the endgate hinge to the body rear end panel. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the endgate nuts to the endgate hinge. Tighten: Tighten the endgate nuts to 33 N.m (28 lb ft).
  3. Align the endgate to the endgate hinges, with an assistant.
  4. Install the endgate hinge to endgate bolts. Tighten: Tighten the endgate bolts to 33 N.m (28 lb ft).
  5. Connect the electrical harness to the endgate.
  6. Close the endgate.
  7. Close the liftgate.

Scheme 33

Scheme 33: Removal Procedure
Scheme 33: Removal Procedure
  1. Remove the liftgate. Refer to «Liftgate Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  2. Mark the location of the liftgate hinges with a grease pencil.
  3. Remove the nuts from the liftgate hinges. IMPORTANT: Mark the location of the shims right and/or left for reinstallation.
  4. Remove the liftgate hinges with the shims and seals from the vehicle.
  1. Position the liftgate hinges with the shims and seals to the location marks on vehicle. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the nuts to the liftgate hinges. Tighten: Tighten the liftgate hinge nuts to 33 N.m (28 lb ft).
  3. Install the liftgate. Refer to «Liftgate Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  1. Remove the liftgate. Refer to «Liftgate Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  2. Mark the location of the liftgate hinges with a grease pencil.
  3. Remove the nuts from the liftgate hinges. IMPORTANT: Mark the location of the shims right and/or left for reinstallation.
  4. Remove the liftgate hinges with the shims and seals from the vehicle.
  1. Position the liftgate hinges with the shims and seals to the location marks on vehicle. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the nuts to the liftgate hinges. Tighten: Tighten the liftgate hinge nuts to 33 N.m (28 lb ft).
  3. Install the liftgate. Refer to «Liftgate Replacement (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .

Scheme 34

Scheme 34: Removal Procedure
Scheme 34: Removal Procedure

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39
  1. Open the endgate.
  2. Remove the endgate torque rod bolt from the torque rod bracket.
  3. Remove the bolts from the endgate torque rod to the endgate.
  4. Remove the endgate torque rod from the endgate.
  5. Remove the bolts from the endgate torque rod bracket to the rear body panel.
  6. Remove the torque rod bracket from the rear body panel.
  7. Remove the torque rod insulator from the endgate using a small flat-bladed tool.

Scheme 40

Scheme 40
Scheme 40
  1. Install the torque rod insulator to the endgate, pressing into place until fully seated.
  2. Position the torque rod bracket to the rear body panel. NOTE: Refer to Fastener Notice in Cautions and Notices.
  3. Install the bolts to the torque rod bracket. Tighten: Tighten the torque rod bracket bolts to 25 N.m (18 lb ft).
  4. Position the torque rod to the torque rod bracket.
  5. Install the endgate torque rod bolt to the torque rod bracket. Tighten: Tighten the endgate torque rod bolt to 10 N.m (89 lb in).
  6. Position the endgate torque rod to the endgate.
  7. Install the bolts to the endgate torque rod to the endgate. Tighten: Tighten the torque rod to endgate bolts to 33 N.m (28 lb ft).
  8. Close the endgate.
CAUTIONWhen a hood hold open device is being removed or installed, provide alternate support to avoid the possibility of damage to the vehicle or personal injury.

Note. Refer to Liftgate/Hood Assist Rod Notice in Cautions and Notices.

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42
  1. Open and support the liftgate.
  2. Lift up the retainer clips on the assist rods using a small flat-bladed tool.
  3. Remove the upper end of the assist rods from the ball joint.
  4. Remove the lower end of the assist rods from the ball joint.
  5. Remove the assist rods from the liftgate.
  1. Position the assist rods to the liftgate.
  2. Install the upper end of the assist rods to the ball joint. Press in to place until fully seated.
  3. Install the lower end of the assist rods to the ball joint. Press in to place until fully seated.
  4. Remove the support from the liftgate.
  5. Close the liftgate.
CAUTIONWhen a hood hold open device is being removed or installed, provide alternate support to avoid the possibility of damage to the vehicle or personal injury.

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. Open the endgate. NOTE: Refer to Liftgate/Hood Assist Rod Notice in Cautions and Notices.
  2. Lift up the retainer clips on the endgate assist rods using a small flat-bladed tool.
  3. Remove the upper end of the assist rods from the ball joint.
  4. Remove the lower end of the assist rods from the ball joint.
  5. Remove the assist rods from the endgate.
  1. Position the assist rods to the endgate.
  2. Install the upper end of the assist rods to the ball joint. Press in to place until fully seated.
  3. Install the lower end of the assist rods to the ball joint. Press in to until fully seated.
  4. Close the endgate.

Scheme 47

Scheme 47: Removal Procedure
Scheme 47: Removal Procedure

Scheme 48

Scheme 48
Scheme 48
  1. Open the endgate.
  2. Remove the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  3. Remove the endgate water deflector. Refer to «Water Deflector Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  4. Disconnect the electrical connector from the endgate lock cylinder.
  5. Disconnect the endgate lock cylinder wiring harness from the endgate inner panel.
  6. Remove the endgate lock cylinder retainer from the lock cylinder.
  7. Remove the endgate lock cylinder from the endgate.
  1. Install the endgate lock cylinder to the endgate.
  2. Install the endgate lock cylinder retainer to the lock cylinder, pressing into place until fully seated.
  3. Connect the electrical connector to the endgate lock cylinder.
  4. Connect the endgate lock cylinder wiring harness to the endgate inner panel.
  5. Install the endgate water deflector. Refer to «Water Deflector Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  6. Install the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  7. Close the endgate.
  1. Open the endgate.
  2. Support the endgate in the open position.
  3. Remove the bolts from the endgate support cable.
  4. Remove the endgate support cable from the endgate.

Scheme 49

Scheme 49: Installation Procedure
Scheme 49: Installation Procedure
  1. Position the endgate support cable to the endgate.
  2. Install the bolts to the endgate support cable. Tighten: Tighten the endgate support cable bolts to 3 N.m (27 lb in).
  3. Remove the support from the endgate.
  4. Close the endgate.

Scheme 50

Scheme 50: Removal Procedure
Scheme 50: Removal Procedure
  1. Open the endgate.
  2. Remove the bolts from the endgate handle.
  3. Remove the endgate handle from the endgate handle assembly.
  1. Install the endgate handle to the endgate handle assembly. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the bolts to the endgate handle. Tighten: Tighten the endgate handle bolts to 10 N.m (89 lb in).
  3. Close the endgate.

Scheme 51

Scheme 51: Removal Procedure
Scheme 51: Removal Procedure
  1. Open the liftgate.
  2. Open the endgate.
  3. Remove the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  4. Remove the water deflector. Refer to «Water Deflector Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  5. Disconnect the endgate latch rod from the bellcrank. Refer to «Bellcrank Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  6. Remove the endgate latch bolts from the endgate latch.
  7. Slide the endgate latch forward and disconnect the end gate latch rod from the endgate.
  8. Disconnect the electrical connectors from the endgate latch.
  9. Remove the endgate latch from the vehicle.

Note. Do not engage the child safety switch on the endgate latch. If the endgate is closed with the child safety switch engaged, the endgate will not open unless you remove the endgate trim panel. Removal will damage the endgate trim panel.

  1. Align the endgate latch to the end gate.
  2. Connect the electrical connectors to the endgate latch.
  3. Connect the endgate latch rod to the endgate latch.
  4. Slide the endgate latch into the end gate. NOTE: Refer to Fastener Notice in Cautions and Notices.
  5. Install the endgate latch bolts. Tighten: Tighten the endgate latch bolts to 10 N.m (89 lb in).
  6. Install the endgate latch rod to the bellcrank. Refer to «Bellcrank Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  7. Install the water deflector. Refer to «Water Deflector Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  8. Install the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  9. Close the endgate.
  10. Close the liftgate.

Scheme 52

Scheme 52: Removal Procedure
Scheme 52: Removal Procedure
  1. Open the endgate.
  2. Mark the location of the endgate strikers with a grease pencil.
  3. Remove the screws from the endgate strikers. IMPORTANT: Mark the endgate strikers and shims (RT or LT) for reinstallation.
  4. Remove the endgate strikers and shims from the vehicle.
  1. Position the endgate strikers and shims to the locations marks. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the screws to the endgate strikers. Tighten: Tighten the endgate strikers to 25 N.m (18 lb ft).
  3. Close the endgate and inspect for proper fit and operation.
  4. Adjust the endgate, if required. Refer to «Hinge Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .

Scheme 53

Scheme 53: Removal Procedure
Scheme 53: Removal Procedure
  1. Open the liftgate.
  2. Remove the lower liftgate trim panel. Refer to «Trim Panel Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Trim Panel Replacement - Liftgate (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  3. Remove the bolts from the liftgate strikers.
  4. Remove the liftgate strikers from the liftgate.

Scheme 54

Scheme 54: Installation Procedure
Scheme 54: Installation Procedure
  1. Install the liftgate strikers to the liftgate. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the bolts to the liftgate strikers. Tighten: Tighten the liftgate striker bolts to 10 N.m (89 lb in)
  3. Install the lower liftgate trim panel. Refer to «Trim Panel Replacement - Liftgate (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) or «Trim Panel Replacement - Liftgate (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  4. Close the liftgate.

Scheme 55

Scheme 55: Removal Procedure
Scheme 55: Removal Procedure
  1. Open the liftgate.
  2. Remove screws from liftgate striker.
  3. Remove liftgate striker and spacer from vehicle.
  1. Align spacer and liftgate striker to holes in body. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the liftgate striker bolts. Tighten: Tighten the liftgate striker retaining bolts to 25 N.m (18 lb ft).
  3. Close the liftgate.

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57
  1. Remove the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  2. Remove the endgate water deflector. Refer to «Water Deflector Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  3. Remove the endgate handle rod from the endgate bellcrank.
  4. Remove the endgate latch rods from the endgate bellcrank.
  5. Remove the bolts from the bellcrank to the endgate.
  6. Remove the endgate bellcrank from the endgate.
  1. Install the bellcrank to the endgate. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the bolts to the bellcrank to the endgate. Tighten: Tighten the endgate bellcrank bolts to 10 N.m (89 lb in).
  3. Install the endgate latch rods to the bellcrank.
  4. Install the endgate latch handle rod to the bellcrank.
  5. Install the endgate water deflector. Refer to «Water Deflector Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .
  6. Install the endgate trim panel. Refer to «Trim Panel Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#body-rear-end) .

Scheme 58

Scheme 58: Removal Procedure
Scheme 58: Removal Procedure
  1. Remove the rear bumper fascia. Refer to «Fascia Replacement - Rear Bumper (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) or «Fascia Replacement - Rear Bumper (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) in Bumpers.
  2. Using a small flat-bladed tool, apply pressure at two upper locations and two lower locations to release the retainers on the pressure relief valve.
  3. Remove the pressure relief valve from the lower quarter panel.
  1. Install the pressure relief valve to the lower quarter panel.
  2. Press the pressure relief valve into the quarter lower panel until the retainers lock into place at the upper and lower locations.
  3. Install the rear bumper fascia. Refer to «Fascia Replacement - Rear Bumper (Aztek)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) or «Fascia Replacement - Rear Bumper (Rendezvous)»(/buick/rendezvous/i-2001-2007/remont/exterior-body-panels/#bumper-system) in Bumpers.

J 38778: Door Trim Pad and Garnish Clip Remover. See Special Tools and Equipment .

Scheme 59

Scheme 59: Removal Procedure
Scheme 59: Removal Procedure
  1. Open the endgate.
  2. Remove the push-in retainers from each end of the endgate weatherstrip, using J 38778 .
  3. Remove the endgate weatherstrip from the endgate starting at the corner of the endgate and pull the weatherstrip from the endgate pinch-weld flange.
  1. Position the ends of the weatherstrip to the endgate pinch-weld flange corners.
  2. Install the push-in retainers to the holes in the pinch-weld flange.
  3. Install the endgate weatherstrip to the pinch-weld flange working from each end toward the center.

Scheme 60

Scheme 60: Removal Procedure
Scheme 60: Removal Procedure
  1. Open the liftgate.
  2. Remove the endgate sill plate. Refer to «Door Sill Plate Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  3. Pull the liftgate weatherstrip from the liftgate opening pinch-weld flange.
  4. Clean all the adhesive from the liftgate opening pinch-weld flange using GM P/N 8984 adhesive remover or equivalent.
IMPORTANTA mastic/sealer/glue is inside of new liftgate weatherstrips. If a new weatherstrip in being installed, weatherstrip adhesive should not be used. If the liftgate weatherstrip is reused, weatherstrip adhesive should be used.
  1. Install the liftgate weatherstrip, starting at the top center of the liftgate opening position the liftgate weatherstrip to the pinch-weld flange and working down the right and left sides towards the bottom center, being careful not to stretch the liftgate weatherstrip while installing it.
  2. Install the butt joint seam at the center of the bottom pinch-weld flange.
  3. Use a rubber mallet to ensure full engagement of the liftgate weatherstrip to the pinch-weld flange.
  4. Spooning of the liftgate weatherstrip may be required to complete the installation of the liftgate weatherstrip.
  5. Install the endgate sill plate. Refer to «Door Sill Plate Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  6. Close the liftgate.

Scheme 61

Scheme 61: Removal Procedure
Scheme 61: Removal Procedure
  1. Open the liftgate.
  2. Remove the endgate sill plate. Refer to «Door Sill Plate Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  3. Pull the liftgate weatherstrip from the liftgate opening pinch-weld flange.
  4. Clean all the adhesive from the liftgate opening pinch-weld flange using GM P/N 8984 adhesive remover or equivalent.
IMPORTANTA mastic/sealer/glue is inside of the new liftgate weatherstrips. If a new weatherstrip is being installed, weatherstrip adhesive should not be used. If the liftgate weatherstrip is reused, weatherstrip adhesive should be used.
  1. Install the liftgate weatherstrip starting at the top center of the liftgate opening. Position the liftgate weatherstrip to the pinch-weld flange, and working down the right and left sides towards the bottom center, being careful not to stretch the liftgate weatherstrip while installing it.
  2. Install the butt joint seam at the center of the bottom pinch-weld flange.
  3. Use a rubber mallet to ensure full engagement of the liftgate weatherstrip to the pinch-weld flange.
  4. Spooning of the liftgate weatherstrip may be required to complete the installation of the liftgate weatherstrip.
  5. Install the endgate sill plate. Refer to «Door Sill Plate Replacement - Endgate»(/buick/rendezvous/i-2001-2007/remont/exteriorinterior-trim/#interior-trim) in Interior Trim.
  6. Close the liftgate.

Rear Hatch/Gate Description and Operation (Aztek)

The lift glass can be opened by operating the switch on the instrument panel or rotating the key cylinder in the endgate. Battery voltage is supplied to the lift glass actuators through the body control module (BCM). The BCM will pulse the LH and RH lift glass actuators when a release input is received through the key fob, endgate key switch, or the instrument panel switch.

Rear Hatch/Gate Description and Operation (Rendezvous)

The liftgate can be opened by operating the switch on the instrument panel. Battery voltage is supplied to the liftgate actuator through the body control module (BCM). The BCM will pulse the liftgate actuator when a release input is received through the key fob, or the instrument panel switch.

Rear Hatch Ajar Indicator

The instrument panel cluster (IPC) illuminates the rear hatch ajar indicator in the message center when the body control module (BCM) detects that either of the lift window latches are open. The IPC receives a class 2 message from the BCM requesting illumination. The IPC sends a class 2 message to the radio in order to activate an audible warning.

The instrument panel cluster (IPC) illuminates the rear hatch ajar indicator in the message center when the body control module (BCM) detects that the liftgate latch is open. The IPC receives a class 2 message from the BCM requesting illumination. The IPC sends a class 2 message to the radio in order to activate an audible warning.

Special Tools

Special Tools Illustration Tool Number/Description J 38778 Door Trim Pad and Garnish Clip Remover

Scheme 62

Scheme 62: Special Tools
Scheme 62: Special Tools

See also:
• Scan Tool Does Not Power Up
• Diagnostic Trouble Code (DTC) List
• Diagnostic Trouble Code (DTC) List
• Testing for Intermittent Conditions and Poor Connections
• Body Control System Connector End Views
• Circuit Testing
• Wiring Repairs
• Connector Repairs
• Checking Aftermarket Accessories
• Electrical Center Identification Views
• Instrument Panel Cluster (IPC) Replacement
• Plastic Identification and Refinishing Systems
• Window Replacement - Liftgate (Pontiac)
• Window Replacement - Liftgate (Buick)
• Molding Replacement - Rear Panel
• Fascia Replacement - Rear Bumper (Aztek)
• Door Sill Plate Replacement - Endgate
• Diagnostic System Check - Body Rear End
• Diagnostic Trouble Code (DTC) List
• Rear Hatch/Gate Description and Operation (Aztek)
• Rear Hatch/Gate Description and Operation (Rendezvous)
• Hatch Release Inoperative (Rendezvous)
• Rear Window Release Inoperative (Aztek)
• Rear Hatch/Gate Ajar Indicator Malfunction (Aztek)
• Rear Hatch/Gate Ajar Indicator Malfunction (Rendezvous)

More articles — Body & Frame
