Scheme 89
Scheme 90
Scheme 91
| Callout | Component Name |
|---|---|
| 1 | Instrument Cluster |
| 2 | Driver's Information/HUD Switches |
| 3 | A/C Sunload Sensor (CJ2)/Ambient Light Sensor (CJ3/C60) |
| 4 | Security Indicator Lamp |
| 5 | Inflatable Restraint I/P Module |
| 6 | HVAC Control Module |
| 7 | Fuse Block-Center Console |
| 8 | Cigar Lighter |
| 9 | Auxiliary Power Outlet-Center Console Lower (2002 and earlier) |
| 10 | Auxiliary Power Outlet-Center Console Upper |
| 11 | Radio |
| 12 | Ignition Switch |
| 13 | Turn Signal, Wiper, Washer, Cruise and High Beam Switch |
Scheme 92
| Callout | Component Name |
|---|---|
| 1 | Tailgate Audio Controls |
| 2 | Subwoofer |
| 3 | Aux Outlet-Rear |
| 4 | Auto Level Control (ALC) Inflator Air Switch |
Power Outlet Connector End Views
Auxiliary Drop Connector End Connector Part Information 12193928 6-Way F Metri-Pack 280 Series Flexlock (GRY) Pin Wire Color Circuit No. Function A ORN 2740 Battery Positive Voltage B - - Not Used C YEL 743 Accessory Voltage D LT GRN 2271 ADG Class 2 Serial Data E - - Not Used F BLK 150 Ground
Auxiliary Power Outlet Connector End - Console Connector Part Information 12176836 3-Way F Metri-Pack 280 Series (GRY) Pin Wire Color Circuit No. Function A ORN 2740 Battery Positive Voltage B - - Not Used C BLK 150 Ground
Auxiliary Power Outlet Connector End - Rear Connector Part Information 12176836 3-Way F Metri-Pack 280 Series (GRY) Pin Wire Color Circuit No. Function A ORN 2540 Battery Positive Voltage B - - Not Used C BLK 850 Ground
Cigar Lighter Connector End Connector Part Information 12176836 3-Way F Metri-Pack 280 Series (GRY) Pin Wire Color Circuit No. Function A ORN 2740 Battery Positive Voltage B - - Not Used C BLK 150 Ground
Tools Required
J 42059: Cigar Lighter Housing Remover. See Special Tools and Equipment .
Scheme 93
Scheme 94
Scheme 95
- Remove the cigar lighter fuse.
- Place one side of the T-portion of J 42059 into the tab window. Angle the other portion into the opposite tab window. Pull the cigar lighter housing straight out.
- Remove J 42059 from the cigar lighter housing.
- Disconnect the electrical connector from the housing.
- Remove the housing retainer by using your index finger and pulling out.
Installation Procedure
- Position the cigar lighter housing retainer, placing the key to the slot into the cigar lighter housing hole.
- Install the housing retainer by pressing into place until fully seated.
- Connect the electrical connector to the housing.
- Position the housing to the retainer.
- Install the housing into the front console. Press into place until fully seated.
- Install the cigar lighter fuse.
- Inspect the cigar lighter for proper operation.
J 42059: Cigar Lighter Socket Remover. See Special Tools and Equipment .
Scheme 96
Scheme 97
- Remove the 12-volt power supply fuse.
- Remove the 12-volt power supply receptacle by placing one side of the "T" portion of J 42059 into the tab window. Angle the other side into the opposite tab window. Pull the 12-volt power supply receptacle straight out.
- Remove J 42059 from the power supply receptacle.
- Disconnect the electrical connector from the power supply receptacle.
- Using your index finger, pull out the power supply retainer.
Scheme 98
Scheme 99
Scheme 100
Scheme 101
- Position the 12-volt power supply retainer with the key to the slot into the power supply hole.
- Install the power supply retainer pressing into place until fully seated.
- Connect the electrical connector to the I/P power supply receptacle.
- Position the power supply receptacle to the retainer.
- Install the power supply receptacle into the I/P, pressing into place until fully seated.
- Install the power supply fuse.
- Inspect the power supply for proper operation.
Special Tools
Special Tools Illustration Tool Number/Description J 42059 Cigar Lighter Socket Remover
