Ignition Switch
Ignition Switch Connector End Connector Part Information 19900853490 7-Way F Kostal (BLK) Pin Wire Color Circuit No. Function A BRN 4 Accessory Voltage B ORN 1040 Battery Positive Voltage C PNK 3 Ignition 1 Voltage D YEL 5 Crank Voltage E DK GRN 500 Ignition 0 Voltage F ORN 2340 Battery Positive Voltage G ORN 300 Ignition 3 Voltage
C101
C101 Connector End Connector Part Information 15326864 16-Way F 150 Series Sealed (BLK) Connector Part Information 15326868 16-Way M 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A WHT 17 Stop Lamp Switch Signal A WHT 17 Stop Lamp Switch Signal B YEL 2470 Class 2 Serial Data (LY7) B YEL 2470 Class 2 Serial Data (LY7) C PNK 39 Ignition 1 Voltage (LY7) C PNK 39 Ignition 1 Voltage (LY7) D BRN 882 Right Rear Wheel Speed Sensor Signal D BRN 882 Right Rear Wheel Speed Sensor Signal E WHT 883 Right Rear Wheel Speed Sensor Low Reference E WHT 883 Right Rear Wheel Speed Sensor Low Reference F LT BLU 1122 ABS/TCS Class 2 Serial Data F LT BLU 1122 ABS/TCS Class 2 Serial Data G BRN 1271 Low Reference (LY7) G BRN 1271 Low Reference (LY7) H WHT/BLK 1164 5-Volt Reference (LY7) H WHT/BLK 1164 5-Volt Reference (LY7) J DK BLU 1161 APP Sensor 1 Signal J DK BLU 1161 APP Sensor 1 Signal K BLK 884 Left Rear Wheel Speed Sensor Signal K BLK 884 Left Rear Wheel Speed Sensor Signal L RED 885 Left Rear Wheel Speed Sensor Low Reference L RED 885 Left Rear Wheel Speed Sensor Low Reference M TAN 1274 5-Volt Reference (LY7) M TAN 1274 5-Volt Reference (LY7) N PPL 1272 Low Reference (LY7) N PPL 1272 Low Reference (LY7) P LT BLU 1162 APP Sensor 2 Signal (LY7) P LT BLU 1162 APP Sensor 2 Signal (LY7) R TAN/WHT 2500 High Speed GMLAN Serial Data Bus+ (LY7) R TAN/WHT 2500 High Speed GMLAN Serial Data Bus+ (LY7) S TAN 2501 High Speed GMLAN Serial Data Bus- (LY7) S TAN 2501 High Speed GMLAN Serial Data Bus- (LY7)
C102 (LA1)
C102 (LA1) Connector End Connector Part Information 15326084 16-Way F GT 150, 280 Series Sealed 4.0 5.8 (BLK) Connector Part Information 15326085 16-Way M GT 150, 280 Series Sealed 4.0 5.8 (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PNK 639 Ignition 1 Voltage A PNK 639 Ignition 1 Voltage B YEL 410 ECT Sensor Signal B YEL 410 ECT Sensor Signal C BLK 1744 Fuel Injector 1 Control C BLK 1744 Fuel Injector 1 Control D LT GRN/BLK 1745 Fuel Injector 2 Control D LT GRN/BLK 1745 Fuel Injector 2 Control E PNK/BLK 1746 Fuel Injector 3 Control E PNK/BLK 1746 Fuel Injector 3 Control F LT BLU/BLK 844 Fuel Injector 4 Control F LT BLU/BLK 844 Fuel Injector 4 Control G BLK/WHT 845 Fuel Injector 5 Control G BLK/WHT 845 Fuel Injector 5 Control H YEL/BLK 846 Fuel Injector 6 Control H YEL/BLK 846 Fuel Injector 6 Control J - - Not Used J - - Not Used K GRY 2704 5-Volt Reference K GRY 2704 5-Volt Reference L ORN/BLK 469 Low Reference L ORN/BLK 469 Low Reference M LT GRN 432 MAP Sensor Signal M LT GRN 432 MAP Sensor Signal N RED/WHT 812 12-Volt Reference N RED/WHT 812 12-Volt Reference P BLK 407 Low Reference P BLK 407 Low Reference R BRN/WHT 633 CMP Sensor Signal R BRN/WHT 633 CMP Sensor Signal S - - Not Used S - - Not Used
Scheme 102
C103
C103 Connector End Connector Part Information 15326864 16-Way F 150 Series Sealed (BLK) Connector Part Information 15326868 16-Way M 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A DK GRN 1049 PCM Class 2 Serial Data A DK GRN 1049 PCM Class 2 Serial Data B BLK 2759 Low Reference B BLK 2759 Low Reference C PPL 420 TCC Brake Switch/Cruise Control Release Signal (LA1) C PPL 420 TCC Brake Switch/Cruise Control Release Signal (LA1) WHT 17 Stop Lamp Switch Signal (LY7) WHT 17 Stop Lamp Switch Signal (LY7) D BRN/WHT 419 MIL Control D BRN/WHT 419 MIL Control E DK GRN 890 Fuel Tank Pressure Sensor Signal E DK GRN 890 Fuel Tank Pressure Sensor Signal F WHT 1310 EVAP Canister Vent Solenoid Control F WHT 1310 EVAP Canister Vent Solenoid Control G DK GRN 389 Vehicle Speed Signal G DK GRN 389 Vehicle Speed Signal H BLK/WHT 451 Ground (LA1) H BLK/WHT 451 Ground (LA1) PPL 420 TCC Brake Switch/Cruise Control Release Signal (LY7) PPL 420 TCC Brake Switch/Cruise Control Release Signal (LY7) J YEL 5 Crank Voltage J YEL 5 Crank Voltage K WHT 85 Cruise Control Engaged Signal (LA1) K WHT 85 Cruise Control Engaged Signal (LA1) DK BLU 84 Cruise Control Set/Coast Switch Signal (LY7) DK BLU 84 Cruise Control Set/Coast Switch Signal (LY7) L DK GRN 500 Ignition 0 Voltage L DK GRN 500 Ignition 0 Voltage M GRY 397 Cruise Control On Switch Signal (LY7) M GRY 397 Cruise Control On Switch Signal (LY7) N PPL 1589 Fuel Level Sensor Signal N PPL/WHT 1589 Fuel Level Sensor Signal P GRY 2709 5-Volt Reference P GRY 2709 5-Volt Reference R DK GRN 83 Cruise Control Inhibit Signal (LA1) R DK GRN 83 Cruise Control Inhibit Signal (LA1) GRY/BLK 87 Cruise Control Resume/Accel Switch Signal (LY7) GRY/BLK 87 Cruise Control Resume/Accel Switch Signal (LY7) S LT BLU 1296 Axle Actuator - Control (AWD) S LT BLU 1296 Axle Actuator - Control
C105
C105 Connector End Connector Part Information 12129565 4-Way F Metri-Pack 280 Series Sealed (GRY) Connector Part Information 12129600 4-Way M Metri-Pack 280 Sealed (GRY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BLK 1250 Ground A BLK 1250 Ground B LT BLU 409 Cooling Fan Motor Supply Voltage B RED 409 Cooling Fan Motor Supply Voltage C GRY 532 Cooling Fan Motor Supply Voltage C RED 532 Cooling Fan Motor Supply Voltage D WHT 504 Cooling Fan Motor Ground D BLK 504 Cooling Fan Motor Ground
C106 (LY7)
C106 (LY7) Connector End Connector Part Information 1-963214-1 10-Way F Amp (BLK) Connector Part Information 6-1355688-1 10-Way M Amp (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 WHT 5291 Ignition 1 Voltage 1 WHT 5291 Ignition 1 Voltage 2 WHT 5292 Ignition 1 Voltage 2 WHT 5292 Ignition 1 Voltage 3 TAN 1744 Fuel Injector 1 Control 3 TAN 1744 Fuel Injector 1 Control 4 PNK/BLK 1746 Fuel Injector 3 Control 4 PNK/BLK 1746 Fuel Injector 3 Control 5 TAN/WHT 845 Fuel Injector 5 Control 5 TAN/WHT 845 Fuel Injector 5 Control 6 LT GRN/BLK 1745 Fuel Injector 2 Control 6 LT GRN/BLK 1745 Fuel Injector 2 Control 7 DK BLU/BLK 844 Fuel Injector 4 Control 7 DK BLU/BLK 844 Fuel Injector 4 Control 8 YEL/BLK 846 Fuel Injector 6 Control 8 YEL/BLK 846 Fuel Injector 6 Control 9-10 - - Not Used 9-10 - - Not Used
Scheme 103
C108 (LY7)
C108 (LY7) Connector End Connector Part Information 12059471 7-Way F Metri-Pack 150, 480 Series (BLK) Connector Part Information 12052200 7-Way M Metri-Pack 150, 480 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PNK/BLK 5291 Ignition 1 Voltage A WHT 5291 Ignition 1 Voltage B - - Not Used B - - Not Used C DK GRN 59 A/C Compressor Clutch Supply Voltage C DK GRN 59 A/C Compressor Clutch Supply Voltage D PNK/LBK 5292 Ignition 1 Voltage D WHT 5292 Ignition 1 Voltage E PPL 6 Starter Solenoid Crank Voltage E PPL 6 Starter Solenoid Crank Voltage F PNK/BLK 5293 Ignition 1 Voltage F WHT 5293 Ignition 1 Voltage G BLK/WHT 451 Ground G BLK/WHT 451 Ground
Scheme 104
C120 - Pontiac/UH9
C120 Connector End - Pontiac/UH9 Connector Part Information 15326802 2-Way F 150 Series Sealed (BLK) Connector Part Information 15326806 2-Way M 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A LT GRN/BLK 735 Ambient Air Temperature Sensor Signal A LT GRN/BLK 735 Ambient Air Temperature Sensor Signal B YEL 61 Low Reference B YEL 61 Low Reference
Scheme 105
C121 - Buick
C121 Connector End - Buick Connector Part Information 15326829 6-Way F 150 Series Sealed (BLK) Connector Part Information 15326833 6-Way M 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A LT GRN/BLK 735 Ambient Air Temperature Sensor Signal (UH9/CJ2) A LT GRN/BLK 735 Ambient Air Temperature Sensor Signal (UH9/CJ2) B YEL 61 Low Reference (UH9/CJ2) B YEL 61 Low Reference (UH9/CJ2) C YEL 9901 Inflatable Restraint Front End Discriminating Sensor - Left - Signal C RED 9901 Inflatable Restraint Front End Discriminating Sensor - Left - Signal D GRY 9904 Inflatable Restraint Front End Discriminating Sensor - Left - Voltage D BRN 9904 Inflatable Restraint Front End Discriminating Sensor - Left - Voltage E BLU 9906 Inflatable Restraint Front End Discriminating Sensor - Right - Signal E PPL 9906 Inflatable Restraint Front End Discriminating Sensor - Right - Signal F ORN 9902 Inflatable Restraint Front End Discriminating Sensor - Right - Voltage F RED 9902 Inflatable Restraint Front End Discriminating Sensor - Right - Voltage
C151 - Pontiac
C151 Connector End - Pontiac Connector Part Information 15326816 4-Way F 150 Series Sealed (BLK) Connector Part Information 15369319 4-Way M GT 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A YEL 712 Left Headlamp Low Beam Supply Voltage A YEL 712 Left Headlamp Low Beam Supply Voltage B DK GRN/WHT 711 Left Headlamp High Beam Supply Voltage B DK GRN/WHT 711 Left Headlamp High Beam Supply Voltage C BLK 1350 Ground C BLK 1350 Ground D - - Not Used D - - Not Used
C152 - Pontiac
C152 Connector End - Pontiac Connector Part Information 15326816 4-Way F GT 150 Series Sealed (BLK) Connector Part Information 15369319 4-Way M GT 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A TAN/WHT 312 Right Headlamp Low Beam Supply Voltage A TAN/WHT 312 Right Headlamp Low Beam Supply Voltage B LT GRN/BLK 311 Right Headlamp High Beam Supply Voltage B LT GRN/BLK 311 Right Headlamp High Beam Supply Voltage C BLK 1250 Ground C BLK 1250 Ground D DK BLU 593 DRL Headlamp High Beam Supply Voltage D DK BLU 593 DRL Headlamp High Beam Supply Voltage
C153 - Pontiac
C153 Connector End - Pontiac Connector Part Information 15326809 3-Way F 150 Series Sealed (BLK) Connector Part Information 15326813 3-Way M 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A LT BLU 14 Left Turn Signal Lamps Supply Voltage A LT BLU 14 Left Turn Signal Lamps Supply Voltage B BRN 9 Park Lamp Supply Voltage B BRN 9 Park Lamp Supply Voltage C BLK 1350 Ground C BLK 1350 Ground
C154 - Pontiac
C154 Connector End - Pontiac Connector Part Information 15326809 3-Way F 150 Series Sealed (BLK) Connector Part Information 15326813 3-Way M 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A LT BLU 15 Right Turn Signal Lamps Supply Voltage A DK BLU 15 Right Turn Signal Lamps Supply Voltage B BRN 9 Park Lamp Supply Voltage B BRN 9 Park Lamp Supply Voltage C BLK 1250 Ground C BLK 1250 Ground
C155 - Buick
C155 Connector End - Buick Connector Part Information 15326829 6-Way F 150 Series Sealed (BLK) Connector Part Information 15326833 6-Way M 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A YEL 712 Left Headlamp Low Beam Supply Voltage A YEL 712 Left Headlamp Low Beam Supply Voltage B DK GRN/WHT 711 Left Headlamp High Beam Supply Voltage B DK GRN/WHT 711 Left Headlamp High Beam Supply Voltage C BLK 1350 Ground C BLK 1350 Ground D - - Not Used D - - Not Used E BRN 9 Park Lamp Supply Voltage E BRN 9 Park Lamp Supply Voltage F LT BLU 14 Left Turn Signal Supply Voltage F LT BLU 14 Left Turn Signal Lamps Supply Voltage
C156 - Buick
C156 Connector End - Buick Connector Part Information 15326829 6-Way F 150 Series Sealed (BLK) Connector Part Information 15326833 6-Way M 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A TAN/WHT 312 Right Headlamp Low Beam Supply Voltage A TAN/WHT 312 Right Headlamp Low Beam Supply Voltage B LT GRN/BLK 311 Right Headlamp High Beam Supply Voltage B LT GRN/BLK 311 Right Headlamp High Beam Supply Voltage C BLK 1250 Ground C BLK 1250 Ground D DK BLU 593 DRL Headlamp High Beam Supply Voltage D DK BLU 593 DRL Headlamp High Beam Supply Voltage E BRN 9 Park Lamp Supply Voltage E BRN 9 Park Lamp Supply Voltage F DK BLU 15 Right Turn Signal Supply Voltage F DK BLU 15 Right Turn Signal Supply Voltage
C200
C200 Connector End Connector Part Information 15304908 30-Way F GT 150, 280 Series (BLK) Connector Part Information 15326762 30-Way M GT 150, 280 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 LT BLU/BLK 315 Right Subwoofer Speaker Output (-) (UQ3) A1 LT BLU/BLK 315 Right Subwoofer Speaker Output (-) (UQ3) A2 DK GRN 1795 Right Subwoofer Speaker Output (+) (UQ3) A2 DK GRN 1795 Right Subwoofer Speaker Output (+) (UQ3) A3 BRN/WHT 2517 Keypad Red LED Signal (UE1) A3 BRN/WHT 2517 Keypad Red LED Signal (UE1) A4 YEL/BLK 2516 Keypad Green LED Signal (UE1) A4 YEL/BLK 2516 Keypad Green LED Signal (UE1) A5 DK GRN/WHT 2514 Keypad Signal (UE1) A5 DK GRN/WHT 2514 Keypad Signal (UE1) A6 ORN/BLK 2518 Keypad Low Reference (UE1) A6 ORN/BLK 2518 Keypad Low Reference (UE1) A7 PNK 1439 Ignition 1 Voltage A7 PNK 1439 Ignition 1 Voltage (AWD) PNK 1439 Ignition 1 Voltage (UD7) A8 GRY 391 Rear Window Wiper Switch Signal (Buick) A8 GRY 391 Rear Window Wiper Switch Signal (Buick) A9 GRY 120 Fuel Pump Supply Voltage A9 GRY 120 Fuel Pump Supply Voltage A10 LT GRN/BLK 2515 Keypad Supply Voltage (UE1) A10 LT GRN/BLK 2515 Keypad Supply Voltage (UE1) A11 GRY 655 Cellular Microphone Signal (UE1) A11 GRY 655 Cellular Microphone Signal (UE1) A12 BARE 1705 Drain Wire (UE1) A12 BARE 1705 Drain Wire (UE1) A13 DK GRN 392 Rear Window Washer Pump Control (Buick) A13 DK GRN 392 Rear Window Washer Pump Control (Buick) A14-A15 - - Not Used A14-A15 - - Not Used B1 RED 1955 Right Rear Midrange Speaker Output (-) (Pontiac/UQ3) B1 RED 1955 Right Rear Midrange Speaker Output (-) (Pontiac/UQ3) DK GRN 117 Right Front Speaker Output (-) (Buick) PPL 117 Right Front Tweeter Speaker Output (-) (Buick w/o UQ3) PPL 1952 Right Front Tweeter Speaker Output (-) (Buick/UQ3) B2 TAN 1855 Right Rear Midrange Speaker Output (+) (Pontiac/UQ3) B2 TAN 1855 Right Rear Midrange Speaker Output (+) (Pontiac/UQ3) LT GRN 200 Right Front Speaker Output (+) (Buick) LT GRN 200 Right Front Tweeter Speaker Output (+) (Buick w/o UQ3) LT GRN 1852 Right Front Tweeter Speaker Output (+) (Buick/UQ3) B3-B4 - - Not Used B3-B4 - - Not Used B5 LT BLU/BLK 1505 Passenger Heated Seat Switch Signal (KA1) B5 LT BLU/BLK 1505 Passenger Heated Seat Switch Signal (KA1) B6 - - Not Used B6 - - Not Used B7 DK GRN 117 Right Front Speaker Output (-) B7 DK GRN 117 Right Front Speaker Output (-) DK GRN 117 Right Front Speaker Output (-) (Pontiac) DK GRN 117 Right Front Speaker Output (-) (Buick w/o UQ3) B8 LT GRN 200 Right Front Speaker Output (+) B8 LT GRN 200 Right Front Speaker Output (+) LT GRN 200 Right Front Speaker Output (+) (Pontiac) LT GRN 200 Right Front Speaker Output (+) (Buick w/o UQ3) B9 DK BLU 1796 Steering Wheel Controls Signal (Pontiac/UQ3) B9 DK BLU 1796 Steering Wheel Controls Signal (Pontiac/UQ3) DK BLU 1796 Steering Wheel Controls Signal (Pontiac/UQ3) B10 RED 9901 Inflatable Restraint Front End Discriminating Sensor - Left - Signal (Buick) B10 RED 9901 Inflatable Restraint Front End Discriminating Sensor - Left - Signal (Buick) B11 BRN 9904 Inflatable Restraint Front End Discriminating Sensor - Left - Voltage (Buick) B11 BRN 9904 Inflatable Restraint Front End Discriminating Sensor - Left - Voltage (Buick) B12 RED 9906 Inflatable Restraint Front End Discriminating Sensor - Right - Signal (Buick) B12 RED 9906 Inflatable Restraint Front End Discriminating Sensor - Right - Signal (Buick) B13 PPL 9902 Inflatable Restraint Front End Discriminating Sensor - Right - Voltage (Buick) B13 PPL 9902 Inflatable Restraint Front End Discriminating Sensor - Right - Voltage (Buick) B14 ORN 4540 Battery Positive Voltage B14 ORN 4540 Battery Positive Voltage B15 - - Not Used B15 - - Not Used
Scheme 106
Scheme 107
C201
C201 Connector End Connector Part Information 15304837 40-Way F GT 150, 280 Series (BLK) Connector Part Information 15336417 40-Way M GT 150, 280 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 ORN 300 Ignition 3 Voltage A1 ORN 300 Ignition 3 Voltage A2 YEL 5 Crank Voltage A2 YEL 5 Crank Voltage A3 PNK 3 Ignition 1 Voltage A3 PNK 3 Ignition 1 Voltage A4 BRN 4 Accessory Voltage A4 BRN 4 Accessory Voltage A5 ORN 1040 Battery Positive Voltage A5 ORN 1040 Battery Positive Voltage A6 YEL 243 Accessory Voltage A6 YEL 243 Accessory Voltage A7 DK GRN 500 Ignition 0 Voltage A7 DK GRN 500 Ignition 0 Voltage A8 ORN 2340 Battery Positive Voltage A8 ORN 2340 Battery Positive Voltage B1 BLK 1550 Ground B1 BLK 1550 Ground B2 LT GRN 80 Key In Ignition Switch Signal B2 LT GRN 80 Key In Ignition Switch Signal B3 PPL 1807 Class 2 Serial Data (Primary) B3 PPL 1807 Class 2 Serial Data (Primary) B4 LT BLU 1134 Park Position Switch Signal (Pontiac) B4 LT BLU 1134 Park Position Switch Signal (Pontiac) DK GRN/WHT 1135 A/T Shift Lock Control Solenoid Supply Voltage (Buick) DK GRN/WHT 1135 A/T Shift Lock Control Solenoid Supply Voltage (Buick) B5 BLK 1450 Ground B5 BLK 1450 Ground B6 ORN 2340 Battery Positive Voltage B6 ORN 2340 Battery Positive Voltage B7 PPL 1500 Ignition 0 Voltage B7 PPL 1500 Ignition 0 Voltage B8 PNK 39 Ignition 1 Voltage B8 PNK 39 Ignition 1 Voltage B9 GRY 397 Cruise Control On Switch Signal B9 GRY 397 Cruise Control On Switch Signal B10 DK BLU 84 Cruise Control Set/Coast Switch Signal B10 DK BLU 84 Cruise Control Set/Coast Switch Signal B11 GRY/BLK 87 Cruise Control Resume/Accel Switch Signal B11 GRY/BLK 87 Cruise Control Resume/Accel Switch Signal B12 PPL 1375 Remote Radio Control Supply Voltage B12 PPL 1375 Remote Radio Control Supply Voltage C1 PNK 539 Ignition 1 Voltage C1 PNK 539 Ignition 1 Voltage C2 LT BLU/WHT 1414 Turn Signal Switch Left Signal C2 LT BLU/WHT 1414 Turn Signal Switch Left Signal C3 DK BLU/WHT 1415 Turn Signal Switch Right Signal C3 DK BLU/WHT 1415 Turn Signal Switch Right Signal C4 TAN 2144 Hazard Switch Signal C4 TAN 2144 Hazard Switch Signal C5 BLK 28 Horn Relay Control C5 BLK 28 Horn Relay Control C6-C11 - - Not Used C6-C11 - - Not Used C12 BLK 910 Headlamp Low/High Beam Relay Control C12 LT BLU 910 Headlamp Low/High Beam Relay Control D1 BLK/WHT 1969 Headlamp High Beam Relay Control D1 BLK/WHT 1969 Headlamp High Beam Relay Control D2 PNK/WHT 1970 Headlamp Low Beam Relay Control D2 PNK/WHT 1970 Headlamp Low Beam Relay Control D3 GRY 112 Windshield Wiper Switch Signal 1 D3 GRY 112 Windshield Wiper Switch Signal 1 D4 DK GRN 113 Windshield Wiper Switch Signal 2 D4 DK GRN 113 Windshield Wiper Switch Signal 2 D5 PPL 92 Windshield Wiper Motor High Speed D5 PPL 92 Windshield Wiper Motor High Speed D6 RED 228 Washer Pump Control D6 RED 228 Windshield Washer Pump Control D7 DK BLU 1796 Steering Wheel Controls Signal D7 DK BLU 1796 Steering Wheel Controls Signal D8 GRY/BLK 1458 Instrument Panel Lamp Supply Voltage 4 D8 GRY/BLK 1458 Instrument Panel Lamp Supply Voltage 4
Scheme 108
Scheme 109
C203
C203 Connector End Connector Part Information 15305217 40-Way F GT 150, 280 Series (LT GRY) Connector Part Information 15305216 40-Way M GT 150, 280 Series (LT GRY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 BLK 884 Left Rear Wheel Speed Sensor Signal A1 BLK 884 Left Rear Wheel Speed Sensor Signal A2 RED 885 Left Rear Wheel Speed Sensor Low Reference A2 RED 885 Left Rear Wheel Speed Sensor Low Reference A3 TAN 201 Left Front Speaker Output (+) A3 TAN 201 Left Front Speaker Output (+) TAN 201 Left Front Speaker Output (+) (Pontiac) TAN 201 Left Front Speaker Output (+) (Buick w/o UQ3) A4 GRY 118 Left Front Speaker Output (-) A4 GRY 118 Left Front Speaker Output (-) GRY 118 Left Front Speaker Output (-) (Pontiac) GRY 118 Left Front Speaker Output (-) (Buick w/o UQ3) A5 BRN 1999 Left Rear Low Level Audio Signal (-) (Pontiac/UK6) A5 BRN 1999 Left Rear Low Level Audio Signal (-) (Pontiac w/o UQ3) BRN 1999 Left Rear Low Level Audio Signal (-) (Pontiac w/o UQ3) A6 BRN/WHT 599 Left Rear Low Level Audio Signal (+) (Pontiac/UK6) A6 BRN/WHT 599 Left Rear Low Level Audio Signal (+) (Pontiac w/o UQ3) BRN/WHT 599 Left Rear Low Level Audio Signal (+) (Pontiac w/o UQ3) A7 BRN 199 Left Rear Speaker Output (+) A7 BRN 199 Left Rear Speaker Output (+) A8 WHT 883 Right Rear Wheel Speed Sensor Low Reference A8 WHT 883 Right Rear Wheel Speed Sensor Low Reference B1 PPL 1589 Fuel Level Sensor Signal - Primary B1 PPL/WHT 1589 Fuel Level Sensor Signal B2 LT BLU 1296 Axle Actuator - Control (M76) B2 LT BLU 1296 Axle Actuator - Control (M76) B3 BRN 9380 Rear Parking Assist Disable Switch Input (UD7) B3 LT GRN 9380 Rear Parking Assist Disable Switch Input (UD7) B4 GRY 2709 5-Volt Reference B4 GRY 2709 5-Volt Reference B5 YEL 116 Left Rear Speaker Output (-) B5 YEL 116 Left Rear Speaker Output (-) B6 BARE 814 Rear Seat Audio Enable Signal (U32) B6 BARE 814 Rear Seat Audio Enable Signal (U32) B7 ORN 4240 Battery Positive Voltage (U32) B7 ORN 4240 Battery Positive Voltage (U32) B8 DK GRN 890 Fuel Tank Pressure Sensor Signal B8 DK GRN 890 Fuel Tank Pressure Sensor Signal B9 BLK 2759 Low Reference B9 BLK 2759 Low Reference B10 - - Not Used B10 - - Not Used B11 BRN 882 Right Rear Wheel Speed Sensor Signal (JM4/JL9) B11 BRN 882 Right Rear Wheel Speed Sensor Signal (JM4/JL9) B12 LT BLU 1462 Driver Heated Seat Switch Signal (KA1) B12 LT BLU 1462 Driver Heated Seat Switch Signal (KA1) C1 BLK/WHT 351 Ground (U32) C1 BLK/WHT 351 Ground (U32) C2 PNK 1045 RFA Class 2 Serial Data (U32) C2 PNK 1045 RFA Class 2 Serial Data (U32) C3 BRN/WHT 367 Remote Radio Left Audio Signal C3 BRN/WHT 367 Remote Radio Left Audio Signal C4 BRN 9 Park Lamp Supply Voltage C4 BRN 9 Park Lamp Supply Voltage C5 WHT 1310 EVAP Canister Vent Solenoid Control C5 WHT 1310 EVAP Canister Vent Solenoid Control C6 DK GRN 389 Vehicle Speed Signal C6 DK GRN 389 Vehicle Speed Signal C7 BRN/WHT 1048 SCM (Seat) Class 2 Serial Data (A43) C7 BRN/WHT 1048 SCM (Seat) Class 2 Serial Data (A43) C8 GRN/WHT 368 Remote Radio Right Audio Signal (U32) C8 GRN/WHT 368 Remote Radio Right Audio Signal (U32) C9 BLK/WHT 372 Remote Radio Audio Output (-) (U32) C9 BLK/WHT 372 Remote Radio Audio Output (-) (U32) C10 LT BLU 115 Right Rear Speaker Output (-) C10 LT BLU 115 Right Rear Speaker Output (-) C11 DK BLU 46 Right Rear Speaker Output (+) C11 DK BLU 46 Right Rear Speaker Output (+) C12 - - Not Used C12 - - Not Used D1 LT GRN/BLK 1794 Left Rear Subwoofer Speaker Output (-) (Pontiac w/UQ3 or Buick) D1 LT GRN/BLK 1794 Left Rear Subwoofer Speaker Output (-) (UQ3) D2 DK BLU/WHT 346 Left Rear Subwoofer Speaker Output (+) (Pontiac w/UQ3 or Buick) D2 DK BLU/WHT 346 Left Rear Subwoofer Speaker Output (+) (UQ3) D3 DK BLU 1128 SDM Class 2 Serial Data D3 DK BLU 1128 SDM Class 2 Serial Data D4 WHT/BLK 1221 Liftgate Release Switch Signal D4 WHT/BLK 1221 Liftgate Release Switch Signal D5-D6 - - Not Used D5-D6 - - Not Used D7 WHT 1959 Left Rear Midrange Speaker Output (-) (Pontiac/UQ3) D7 WHT 1959 Left Rear Midrange Speaker Output (-) (Pontiac w/UQ3) GRY 118 Left Front Tweeter Speaker Output (-) (Buick) YEL 1956 Left Front Tweeter Speaker Output (-) (Buick w/UQ3) GRY 118 LF Speaker Output (-) (Buick w/o UQ3) D8 TAN 1859 Left Rear Midrange Speaker Output (+) (Pontiac/UQ3) D8 TAN 1859 Left Rear Midrange Speaker Output (+) (Pontiac w/UQ3) TAN 201 Left Front Tweeter Speaker Output (+) (Buick) BLK 1856 Left Front Tweeter Speaker Output (+) (Buick w/UQ3) TAN 201 LF Speaker Output (+) (Buick w/o UQ3)
C204
C204 Connector End (Pontiac) Connector Part Information 12066387 2-Way F Metri-Pack 480 Series (BLK) Connector Part Information 12064750 2-Way M Metri-Pack 480 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A ORN 2740 Battery Positive Voltage A ORN 2740 Battery Positive Voltage B BLK 150 Ground B BLK 150 Ground
C206 (Buick)
C206 Connector End (Buick) Connector Part Information 15304692 18-Way F GT 150, 280 Series (BLK) Connector Part Information 15317538 18-Way M GT 150, 280 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 ORN 2740 Battery Positive Voltage A1 ORN 2740 Battery Positive Voltage A2 BRN 9 Park Lamp Supply Voltage A2 BRN 9 Park Lamp Supply Voltage A3 ORN 1732 Courtesy Lamp Supply Voltage A3 ORN 1732 Courtesy Lamp Supply Voltage A4 YEL 116 Left Rear Speaker Output (-) (w/o UQ3) A4 YEL 116 Left Rear Speaker Output (-) (w/o UQ3) BRN 1999 Left Rear Low Level Audio Signal (-) (UQ3) BRN 1999 Left Rear Low Level Audio Signal (-) (UQ3) BRN 1999 Left Rear Low Level Audio Signal (-) (UQ3) A5 LT BLU 115 Right Rear Speaker Output (-) (w/o UQ3) A5 LT BLU 115 Right Rear Speaker Output (-) (w/o UQ3) BLK/WHT 1946 Right Rear Low Level Audio Signal (-) (UQ3) BLK 1946 Right Rear Low Level Audio Signal (-) (UQ3) BLK/WHT 1946 Right Rear Low Level Audio Signal (-) (UQ3) A6 PPL 1375 Remote Radio Control Supply Voltage A6 PPL 1375 Remote Radio Control Supply Voltage (UK6) PPL 1375 Remote Radio Control Supply Voltage A7 BRN 199 Left Rear Speaker Output (+) (w/o UQ3) A7 BRN 199 Left Rear Speaker Output (+) A8 YEL 116 Left Rear Speaker Output (-) (w/o UQ3) A8 YEL 116 Left Rear Speaker Output (-) A9 - - Not Used A9 - - Not Used B1 BLK 150 Ground B1 BLK 150 Ground B2 - - Not Used B2 - - Not Used B3 GRY 8 Instrument Panel Lamp Supply Voltage B3 GRY 8 Instrument Panel Lamp Supply Voltage B4 PPL 493 Rear Seat Audio Enable Signal B4 PPL 493 Rear Seat Audio Enable Signal (UK6) PPL 493 Rear Seat Audio Enable Signal (UK6) B5 BRN 199 Left Rear Speaker Output (+) (w/o UQ3) B5 BRN 199 Left Rear Speaker Output (+) (w/o UQ3) BRN/WHT 599 Left Rear Low Level Audio Signal (+) (UQ3) BRN 599 Left Rear Low Level Audio Signal (+) (UQ3) BRN/WHT 599 Left Rear Low Level Audio Signal (+) (UQ3) B6 DK BLU 46 Right Rear Speaker Output (+) (w/o UQ3) B6 DK BLU 46 Right Rear Speaker Output (+) (w/o UQ3) DK BLU 546 Right Rear Low Level Audio Signal (+) (UQ3) DK BLU 546 Right Rear Low Level Audio Signal (+) (UQ3) DK BLU 546 Right Rear Low Level Audio Signal (+) (UQ3) B7 DK BLU 46 Right Rear Speaker Output (+) (w/o UQ3) B7 DK BLU 46 Right Rear Speaker Output (+) B8 LT GRN 1011 Remote Radio Control Signal B8 LT GRN 1011 Remote Radio Control Signal (UK6) B9 LT BLU 115 Right Rear Speaker Output (-) (w/o UQ3) B9 LT BLU 115 Right Rear Speaker Output (-)
Scheme 110
Scheme 111
C207
C207 Connector End Connector Part Information 15336479 4-Way F Metri-Pack 280 Series (YEL) Connector Part Information 15336476 4-Way F Metri-Pack 280 Series (YEL) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 TAN 3021 Steering Wheel Module - Stage1 - High Control A1 TAN 3021 Steering Wheel Module - Stage 1 - High Control A2 BRN 3020 Steering Wheel Module - Stage 1 - Low Control A2 BRN 3020 Steering Wheel Module - Stage 1 - Low Control B1 WHT 3023 Steering Wheel Module - Stage 2 - High Control B1 WHT 3023 Steering Wheel Module - Stage 2 - High Control B2 PNK 3022 Steering Wheel Module - Stage 2 - Low Control B2 PNK 3022 Steering Wheel Module - Stage2 - Low Control
Scheme 112
C210
C210 Connector End Connector Part Information 15336888 12-Way F GT 150, 280 Series (BLK) Connector Part Information 15336891 12-Way M GT 150, 280 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A LT BLU 1235 Audio Low Reference A BLK/WHT 1235 Audio Low Reference B BRN 2506 Audio Return Signal B BRN/WHT 2506 Audio Return Signal C DK GRN 2507 Audio Transmit Signal C DK GRN/WHT 2507 Audio Transmit Signal D BARE 1792 Drain Wire D BARE 1792 Drain Wire E GRY/BLK 2508 Microphone Signal E GRY/BLK 2508 Microphone Signal F ORN 2240 Battery Positive Voltage F ORN 2240 Battery Positive Voltage G TAN 2510 OnStar Serial Data Return G TAN/BLK 2510 OnStar Serial Data Return H DK BLU 2511 OnStar Serial Data (-) H DK BLU/WHT 2511 OnStar Serial Data (-) J LT BLU 2512 OnStar Serial Data (+) J LT BLU/BLK 2512 OnStar Serial Data (+) K GRY 2520 Transceiver Low Reference K GRY 2520 Transceiver Low Reference L PPL 2513 Ignition ON Signal L PPL/WHT 2513 Ignition ON Signal M - - Not Used M - - Not Used
Scheme 113
C301
C301 Connector End Connector Part Information 15304837 40-Way F GT 150, 280 Series (BLK) Connector Part Information 15336417 40-Way M GT 150, 280 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 LT GRN 1514 Driver Mirror Switch Down Signal (A43) A1 LT GRN 1514 Driver Mirror Switch Down Signal (A43) A2-A3 - - Not Used A2-A3 - - Not Used A4 DK BLU 1307 Power Window Master Switch Lockout Signal A4 DK BLU 1307 Power Window Master Switch Lockout Signal A5 PPL 169 Power Window Master Switch Left Rear Down Signal A5 PPL 169 Power Window Master Switch Left Rear Down Signal A6 DK GRN 168 Power Window Master Switch Left Rear Up Signal A6 DK GRN 168 Power Window Master Switch Left Rear Up Signal A7 PPL/WHT 1515 Passenger Mirror Switch Down Signal (A43) A7 PPL/WHT 1515 Passenger Mirror Switch Down Signal (A43) A8 YEL 1496 Mirror Motor Left/Up Control (A43) A8 YEL 1496 Mirror Motor Left/up Control (A43) B1 WHT 1512 Driver Mirror Switch Right Signal (A43) B1 WHT 1512 Driver Mirror Switch Right Signal (A43) B2 GRY 118 Left Front Speaker Output (-) B2 GRY 118 Left Front Speaker Output (-) B3 GRY 118 Left Front Speaker Output (-) B3 GRY 118 Left Front Speaker Output (-) B4 DK BLU/WHT 727 Right Front Door Open Switch Signal B4 DK BLU/WHT 727 Right Front Door Open Switch Signal B5 RED/WHT 1513 Passenger Mirror Switch Right Signal (A43) B5 RED/WHT 1513 Passenger Mirror Switch Right Signal (A43) B6 GRY 915 Mirror Switch Supply Voltage (A43) B6 GRY 915 Mirror Switch Supply Voltage (A43) B7 WHT 615 Memory 1 Switch Signal (A43) B7 WHT 615 Memory 1 Switch Signal (A43) B8 ORN 840 Battery Positive Voltage (w/o A43) B8 ORN 840 Battery Positive Voltage (w/o A43) B9 RED/WHT 881 Passenger Mirror Motor Right Control (w/o A43) B9 RED/WHT 881 Passenger Mirror Motor Right Control (w/o A43) WHT 81 Driver Mirror Motor Right Control (A43) WHT 81 Driver Mirror Motor Right Control (A43) B10 GRY 8 Instrument Panel Lamp Supply Voltage B10 GRY 8 Instrument Panel Lamp Supply Voltage - 1 B11 TAN 694 Driver Door Lock Actuator Unlock Control B11 TAN 694 Driver Door Lock Actuator Unlock Control B12 PPL 616 Memory 2 Switch Signal (A43) B12 PPL 616 Memory 2 Switch Signal (A43) C1 TAN 201 Left Front Speaker Output (+) C1 TAN 201 Left Front Speaker Output (+) C2 TAN 201 Left Front Speaker Output (+) C2 TAN 201 Left Front Speaker Output (+) C3 RED/BLK 780 Driver Door Lock Switch Lock Signal C3 RED/BLK 780 Driver Door Lock Switch Lock Signal C4 DK BLU 49 Driver Door Ajar Switch Signal Door Open Switch Signal C4 DK BLU 49 Driver Door Ajar Switch Signal Door Open Switch Signal C5 GRY 786 Driver Mirror Horizontal Position Sensor Signal (A43) C5 GRY 786 Driver Mirror Horizontal Position Sensor Signal (A43) C6 BRN 673 Low Reference (A43) C6 BRN 673 Low Reference (A43) C7 DK GRN 784 Driver Mirror Vertical Position Sensor Signal (A43) C7 DK GRN 784 Driver Mirror Vertical Position Sensor Signal (A43) C8 PPL 1124 Door Lock Key Switch Unlock Signal C8 PPL 1124 Door Lock Key Switch Unlock Signal C9 LT BLU/WHT 1497 Passenger Mirror Motor Left/Down Control (w/o A43) C9 LT BLU/WHT 1497 Passenger Mirror Motor Left/Down Control (w/o A43) LT BLU 82 Driver Mirror Motor Left Control (A43) LT BLU 82 Driver Mirror Motor Left Control (A43) C10 BRN/WHT 1498 Passenger Mirror Motor Up Control (w/o A43) C10 BRN/WHT 1498 Passenger Mirror Motor Up Control (w/o A43) LT GRN 89 Driver Mirror Motor Down Control (A43) LT GRN 89 Driver Mirror Motor Down Control (A43) C11 GRY 295 Door Lock Actuator Lock Control C11 GRY 295 Door Lock Actuator Lock Control C12 DK BLU 672 5-Volt Reference (A43) C12 DK BLU 672 5-Volt Reference (A43) D1 ORN 267 Heated Mirror Element Supply Voltage (DE5) D1 ORN 267 Heated Mirror Element Supply Voltage (DE5) D2 - - Not Used D2 - - Not Used D3 LT GRN 170 Power Window Master Switch Right Rear Up Signal D3 LT GRN 170 Power Window Master Switch Right Rear Up Signal D4 PPL 171 Power Window Master Switch Right Rear Down Signal D4 PPL 171 Power Window Master Switch Right Rear Down Signal D5 LT BLU 166 Power Window Master Switch Right Front Up Signal D5 LT BLU 166 Power Window Master Switch Right Front Up Signal D6 TAN 167 Power Window Master Switch Right Front Down Signal D6 TAN 167 Power Window Master Switch Right Front Down Signal D7-D8 - - Not Used D7-D8 - - Not Used
C302
C302 Connector End Connector Part Information 15304837 40-Way F GT 150, 280 Series (BLK) Connector Part Information 15336417 40-Way M GT 150, 280 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 - - Not Used A1 - - Not Used A2 BLK 750 Ground A2 BLK 750 Ground A3 - - Not Used A3 - - Not Used A4 YEL 143 Accessory Voltage A4 YEL 143 Accessory Voltage A5-A8 - - Not Used A5-A8 - - Not Used B1 - - Not Used B1 - - Not Used B2 DK GRN 117 Right Front Speaker Output (-) B2 DK GRN 117 Right Front Speaker Output (-) B3 DK GRN 117 Right Front Speaker Output (-) B3 DK GRN 117 Right Front Speaker Output (-) B4 DK BLU/WHT 727 Right Front Door Open Switch Signal B4 DK BLU/WHT 727 Right Front Door Open Switch Signal B5-B8 - - Not Used B5-B8 - - Not Used B9 RED/WHT 881 Passenger Mirror Motor Right Control B9 RED/WHT 881 Passenger Mirror Motor Right Control B10 GRY 8 Instrument Panel Lamp Supply Voltage B10 GRY 8 Instrument Panel Lamp Supply Voltage B11 TAN 294 Door Lock Actuator Unlock Control B11 TAN 294 Door Lock Actuator Unlock Control B12 - - Not Used B12 - - Not Used C1 LT GRN 200 Right Front Speaker Output (+) C1 LT GRN 200 Right Front Speaker Output (+) C2 LT GRN 200 Right Front Speaker Output (+) C2 LT GRN 200 Right Front Speaker Output (+) C3 - - Not Used C3 - - Not Used C4 ORN 54 Passenger Door Jamb Switch Signal C4 ORN 54 Passenger Door Jamb Switch Signal C5 LT BLU/BLK 785 Passenger Mirror Horizontal Position Sensor Signal (A43) C5 LT BLU/WHT 785 Passenger Mirror Horizontal Position Sensor Signal (A43) C6 LT GRN 675 Low Reference (A43) C6 LT GRN 675 Low Reference (A43) C7 BRN 787 Passenger Mirror Vertical Position Sensor Signal (A43) C7 BRN 787 Passenger Mirror Vertical Position Sensor Signal (A43) C8 - - Not Used C8 - - Not Used C9 LT BLU/WHT 1497 Passenger Mirror Motor Left/Down Control (w/o A43) C9 LT BLU/WHT 1497 Passenger Mirror Motor Left/Down Control (w/o A43) GRY 90 Passenger Mirror Motor Left Control (A43) GRY 90 Passenger Mirror Motor Left Control (A43) C10 BRN/WHT 1498 Passenger Mirror Motor Up Control (w/o A43) C10 BRN/WHT 1498 Passenger Mirror Motor Up Control (w/o A43) PPL/WHT 889 Passenger Mirror Motor Down Control (A43) PPL/WHT 889 Passenger Mirror Motor Down Control (A43) C11 GRY 295 Door Lock Actuator Lock Control C11 GRY 295 Door Lock Actuator Lock Control C12 YEL 674 5-Volt Reference (A43) C12 YEL 674 5-Volt Reference (A43) D1 ORN 267 Heated Mirror Element Supply Voltage (DE5) D1 ORN 267 Heated Mirror Element Supply Voltage (DE5) D2 - - Not Used D2 - - Not Used D3 RED/BLK 780 Driver Door Lock Switch Lock Signal D3 RED/BLK 780 Driver Door Lock Switch Lock Signal RED/BLK 780 Driver Door Lock Switch Lock Signal D4 PPL 1124 Door Lock Key Switch Unlock Signal D4 - - Not Used PPL 1124 Door Lock Key Switch Unlock Signal D5 LT BLU 166 Power Window Master Switch Right Front Up Signal D5 LT BLU 166 Power Window Master Switch Right Front Up Signal D6 TAN 167 Power Window Master Switch Right Front Down Signal D6 TAN 167 Power Window Master Switch Right Front Down Signal D7-D8 - - Not Used D7-D8 - - Not Used
C303
C303 Connector End Connector Part Information 15326870 2-Way F GT 280 Series (BLK) Connector Part Information 15326874 2-Way M 280 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BLK 550 Ground A BLK 550 Ground B YEL 143 Accessory Voltage B YEL 143 Accessory Voltage
Scheme 114
C304 (G67)
C304 (G67) Connector End Connector Part Information 15326654 8-Way F GT 280 Series (BLK) Connector Part Information 15326655 8-Way M GT 280 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A ORN 840 Battery Positive Voltage A - - Battery Positive Voltage B ORN 840 Battery Positive Voltage B - - Battery Positive Voltage C WHT 320 Ground C - - Ground D YEL 321 ALC Compressor Relay Control D - - ALC Compressor Relay Control E ORN 1240 Battery Positive Voltage E - - Battery Positive Voltage F ORN 840 Battery Positive Voltage F - - Battery Positive Voltage G BLK 450 Ground G - - Ground H WHT 837 ALC Inflator Relay Coil Control H - - ALC Inflator Relay Coil Control
C305
C305 Connector End Connector Part Information 12146439 4-Way F 150 Series (LT GRY) 12162144 4-Way F Metri-Pack 150 Series Sealed (BLK) 12176334 8-Way F Metri-Pack 280 Series Flexlock Sealed (WHT) Connector Part Information 15326715 16-Way M Metri-Pack (LT GRY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BRN 882 Right Rear Wheel Speed Sensor Signal (JM4/JL9) 1A BRN 882 Right Rear Wheel Speed Sensor Signal (JM4/JL9) B WHT 883 Right Rear Wheel Speed Sensor Low Reference (JM4/JL9) 1B WHT 883 Right Rear Wheel Speed Sensor Low Reference (JM4/JL9) C BLK 884 Left Rear Wheel Speed Sensor Signal (JM4/JL9) 1C BLK 884 Left Rear Wheel Speed Sensor Signal (JM4/JL9) D RED 885 Left Rear Wheel Speed Sensor Low Reference (JM4/JL9) 1D RED 885 Left Rear Wheel Speed Sensor Low Reference (JM4/JL9) A LT BLU 1296 Axle Actuator - Control (AWD&JM4/JL9) 2A LT BLU 1296 Axle Actuator - Control (AWD&JM4/JL9) B PNK 1439 Ignition 1 Voltage 2B PNK 1439 Ignition 1 Voltage C BLK 550 Ground (JM4/JL9) 2C BLK 550 Ground (JM4/JL9) D - - Not Used (JM4/JL9) 2D - - Not Used (JM4/JL9) A BLK 250 Ground 3A BLK 250 Ground B BLK/WHT 2759 Low Reference 3B BLK 2759 Low Reference C GRY 120 Fuel Pump Supply Voltage 3C GRY 120 Fuel Pump Supply Voltage D PPL 1589 Fuel Level Sensor Signal 3D PPL/WHT 1589 Fuel Level Sensor Signal E DK GRN 890 Fuel Tank Pressure Sensor Signal 3E DK GRN 890 Fuel Tank Pressure Sensor Signal F WHT 1310 EVAP Canister Vent Solenoid Control 3F WHT 1310 EVAP Canister Vent Solenoid Control G ORN 4540 Battery Positive Voltage 3G ORN 4540 Battery Positive Voltage H GRY/BLK 2709 5-Volt Reference 3H GRY 2709 5-Volt Reference
Scheme 115
Scheme 116
C306 (JM4/JL9)
C306 (JM4/JL9) Connector End Connector Part Information 12052644 2-Way F Metri-Pack 150 Series Sealed (BLK) Connector Part Information 12162000 2-Way M Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A WHT 883 Right Rear Wheel Speed Sensor Low Reference A WHT 883 Right Rear Wheel Speed Sensor Low Reference B BLK 882 Right Rear Wheel Speed Sensor Signal B BRN 882 Right Rear Wheel Speed Sensor Signal
C308
C308 (Pontiac) Connector Part Information 15304908 30-Way F GT 150, 280 Series (BLK) Connector Part Information 15326762 30-Way M GT 150, 280 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1-A2 - - Not Used A1-A2 - - Not Used A3 BARE 814 Drain Wire (U32) A3 BARE 814 Drain Wire (U32) A4 ORN 4240 Battery Positive Voltage (U32) A4 ORN 4240 Battery Positive Voltage (U32) A5 BLK/WHT 351 Ground (U32) A5 BLK/WHT 351 Ground (U32) A6 PNK 1045 Ignition 3 Voltage (U32) A6 PNK 1045 Ignition 3 Voltage (U32) A7 BLK/WHT 367 Remote Radio Left Audio Signal (U32) A7 BLK/WHT 367 Remote Radio Left Audio Signal (U32) A8 DK GRN/WHT 368 Remote Radio Right Audio Signal (U32) A8 DK GRN/WHT 368 Remote Radio Right Audio Signal (U32) A9 DK GRN 1927 Rear Defog Element Supply Voltage A9 DK GRN 1927 Rear Defog Element Supply Voltage A10 - - Not Used A10 - - Not Used A11 WHT 17 Stop Lamp Switch Signal A11 WHT 17 Stop Lamp Switch Signal A12 BARE 1705 Drain Wire (UE1) A12 BARE 1705 Drain Wire (UE1) A13 GRY 655 Cellular Microphone Signal (UE1) A13 GRY 655 Cellular Microphone Signal (UE1) A14 DK GRN/WHT 2514 Keypad Signal (UE1) A14 DK GRN/WHT 2514 Keypad Signal (UE1) A15 LT GRN/BLK 2515 Keypad Supply Voltage (UE1) A15 LT GRN/BLK 2515 Keypad Supply Voltage (UE1) B1-B2 - - Not Used B1-B2 - - Not Used B3 BLK/WHT 372 Remote Radio Audio Output (-) (U32) B3 BLK/WHT 372 Remote Radio Audio Output (-) (U32) B4 ORN 1732 Courtesy Lamps Supply Voltage B4 ORN 1732 Courtesy Lamps Supply Voltage B5 - - Not Used B5 - - Not Used B6 GRY/BLK 690 Courtesy Lamp Low Control B6 GRY/BLK 690 Courtesy Lamp Low Control B7 LT BLU 115 Right Rear Speaker Output (-) (w/o UQ3) B7-B8 - - Not Used B8 - - Not Used B9 YEL 643 Accessory Voltage (CF5) B9 YEL 643 Accessory Voltage (CF5) B10 YEL 116 Left Rear Speaker Output (-) (w/o UQ3) B10 YEL 116 Left Rear Speaker Output (-) (w/o UQ3) B11 BRN 199 Left Rear Speaker Output (+) (w/o UQ3) B11 BRN 199 Left Rear Speaker Output (+) (w/o UQ3) B12 YEL/BLK 2516 Keypad Green LED Signal (UE1) B12 YEL/BLK 2516 Keypad Green LED Signal (UE1) B13 ORN/BLK 2518 Keypad Low Reference (UE1) B13 ORN/BLK 2518 Keypad Low Reference (UE1) B14 BRN/WHT 2517 Keypad Red LED Signal (UE1) B14 BRN/WHT 2517 Keypad Red LED Signal (UE1) B15 - - Not Used B15 - - Not Used
C309 (JM4/JL9)
C309 (JM4/JL9) Connector End Connector Part Information 12052644 2-Way F Metri-Pack 150 Series Sealed (BLK) Connector Part Information 12162000 2-Way M Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A WHT 883 Left Rear Wheel Speed Sensor Low Reference A RED 885 Left Rear Wheel Speed Sensor Low Reference B BLK 882 Left Rear Wheel Speed Sensor Signal B BLK 884 Left Rear Wheel Speed Sensor Signal
C310 (U32)
C310 (U32) Connector End Connector Part Information 15317325 30-Way F GT 150, 280 Series (LT GRY) Connector Part Information 15317322 30-Way M GT 150, 280 Series (LT GRY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 WHT 2370 Telltale Assembly Supply Voltage A1 WHT 2370 Telltale Assembly Supply Voltage A2 ORN 2371 Left Amber Indicator Control A2 ORN 2371 Left Amber Indicator Control A3 ORN 640 Battery Positive Voltage A3 ORN 640 Battery Positive Voltage A4-A6 - - Not Used A4-A6 - - Not Used A8 YEL 640 Battery Positive Voltage A8 - - Not Used A9 BLK 650 Ground A9 BLK 650 Ground A10 GRY 8 Instrument Panel Lamp Supply Voltage A10 GRY 8 Instrument Panel Lamp Supply Voltage A11 BARE 1705 Drain Wire A11 BARE 1705 Drain Wire A12 GRY 655 Cellular Microphone Signal A12 GRY 655 Cellular Microphone Signal A13 DK BLU 2372 Center Amber Indicator Control A13 DK BLU 2372 Center Amber Indicator Control A14 GRY 2373 Red Indicator Control A14 GRY 2373 Red Indicator Control A15 BARE 814 Drain Wire A15 BARE 814 Drain Wire B1 ORN 4240 Battery Positive Voltage B1 ORN 4240 Battery Positive Voltage B2 BLK/WHT 351 Ground B2 BLK/WHT 351 Ground B3 PNK 1045 RFA Class 2 Serial Data B3 PNK 1045 RFA Class 2 Serial Data B4 BRN/WHT 367 Remote Radio Left Audio Signal B4 BRN/WHT 367 Remote Radio Left Audio Signal B5 GRN/WHT 368 Remote Radio Right Audio Signal B5 GRN/WHT 368 Remote Radio Right Audio Signal B6 BLK/WHT 372 Remote Radio Audio Output (-) B6 BLK/WHT 372 Remote Radio Audio Output (-) B7 ORN 1732 Courtesy Lamps Supply Voltage B7 ORN 1732 Courtesy Lamps Supply Voltage B8 - - Not Used B8 - - Not Used B9 GRY/BLK 690 Courtesy Lamp Supply Voltage B9 GRY/BLK 690 Courtesy Lamp Supply Voltage B10 DK GRN/WHT 2514 Keypad Signal B10 DK GRN/WHT 2514 Keypad Signal B11 LT GRN/BLK 2515 Key Pad Supply Voltage B11 LT GRN/BLK 2515 Key Pad Supply Voltage B12 YEL/BLK 2516 Key Pad Green LED Signal B12 YEL/BLK 2516 Key Pad Green LED Signal B13 ORN/BLK 2518 Key Pad Low Reference B13 ORN/BLK 2518 Key Pad Low Reference B14 BRN/WHT 2517 Key Pad Red LED Signal B14 BRN/WHT 2517 Key Pad Red LED Signal B15 - - Not Used B15 - - Not Used
C310 (w/o U32)
C310 (w/o U32) Connector End Connector Part Information 15317325 22-Way F GT 150, 280 Series (LT GRY) Connector Part Information 15317322 22-Way M GT 150, 280 Series (LT GRY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 WHT 2370 Telltale Assembly Supply Voltage A1 WHT 2370 Telltale Assembly Supply Voltage A2 ORN 2371 Left Amber Indicator Control A2 ORN 2371 Left Amber Indicator Control A3 - - Not Used A3 - - Not Used A4 LT GRN 24 Backup Lamp Supply Voltage A4 LT GRN 24 Backup Lamp Supply Voltage LT GRN 24 Backup Lamp Supply Voltage A5 YEL 643 Accessory Voltage A5 YEL 643 Accessory Voltage YEL 643 Accessory Voltage A6 BLK 650 Ground A6 BLK 650 Ground A7 - - Not Used A7 - - Not Used A8 ORN 640 Battery Positive Voltage A8 ORN 640 Battery Positive Voltage A9 GRY 8 Instrument Panel Lamp Supply Voltage A9 GRY 8 Instrument Panel Lamp Supply Voltage A10 BARE 1705 Drain Wire A10 BARE 1705 Drain Wire A11 GRY 655 Cellular Microphone Signal A11 GRY 655 Cellular Microphone Signal B1 DK BLU 2372 Center Amber Indicator Control B1 DK BLU 2372 Center Amber Indicator Control B2 GRY 2373 Red Indicator Control B2 GRY 2373 Red Indicator Control B3 - - Not Used B3 - - Not Used B4 ORN 1732 Courtesy Lamps Supply Voltage B4 ORN 1732 Courtesy Lamps Supply Voltage B5 - - Not Used B5 - - Not Used B6 GRY/BLK 690 Courtesy Lamp Low Control B6 GRY/BLK 690 Courtesy Lamp Low Control B7 LT BLU 2514 Key Pad Signal B7 LT BLU 2514 Key Pad Signal B8 DK BLU 2515 Key Pad Supply Voltage B8 DK BLU 2515 Key Pad Supply Voltage B9 PPL 2516 Key Pad Green LED Signal B9 PPL 2516 Key Pad Green LED Signal B10 RED 2518 Key Pad Low Reference B10 RED 2518 Key Pad Low Reference B11 PNK 2517 Key Pad Red LED Signal B11 PNK 2517 Key Pad Red LED Signal
Scheme 117
C313 (w/AG1 or KA1)
C313 (w/AG1 or KA1) Connector End Connector Part Information 15326924 8-Way F GT 280 Series (BLK) Connector Part Information 15326928 8-Way M 280 Series GT (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BLK 550 Ground A BLK 550 Ground B LT BLU 1462 Driver Heated Seat Switch Signal B LT BLU 1462 Driver Heated Seat Switch Signal (KA1) C WHT 615 Memory 1 Switch Signal (A43) C WHT 615 Memory 1 Switch Signal (A43) D PPL 616 Memory 2 Switch Signal (A43) D PPL 616 Memory 2 Switch Signal (A43) E BLK/WHT 238 Seat Belt Switch - Left E BLK/WHT 238 Seat Belt Switch - Left F ORN 1140 Battery Positive Voltage F ORN 1140 Battery Positive Voltage (KA1) G BLK/WHT 9238 Driver Seat Position Switch Signal (Buick) G - - Not Used H BLK 9363 Low Reference (Buick) H - - Not Used
C314 (w/AG1 or KA1)
C314 (w/AG1 or KA1) Connector End Connector Part Information 15326924 8-Way F GT 280 Series (BLK) Connector Part Information 15326928 8-Way M 280 Series GT (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BLK 750 Ground A BLK 750 Ground B LT BLU/BLK 1505 Passenger Heated Seat Switch Signal B LT BLU 1505 Passenger Heated Seat Switch Signal C-E - - Not Used C-D - - Not Used E BLK/WHT 238 Seat Belt Switch - Right F ORN 1140 Battery Positive Voltage F ORN 1140 Battery Positive Voltage G-H - - Not Used G-H - - Not Used
C315 (KA1)
C315 (KA1) Connector End Connector Part Information 12047785 4-Way F Metri-Pack 150 Series (BLK) Connector Part Information 12047786 4-Way M Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A WHT - Heated Seat Switch Signal A LT BLU 1462 Heated Seat Switch Signal B RED - Battery Positive Voltage B ORN 1140 Battery Positive Voltage C BLK - Ground C BLK 550 Ground D - - Not Used D - - Not Used
C316 (KA1)
C316 (KA1) Connector End Connector Part Information 12047785 4-Way F Metri-Pack 150 Series (BLK) Connector Part Information 12047786 4-Way M Metri-Pack 150 Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A WHT - Passenger Heated Seat Switch Signal A LT BLU 1505 Passenger Heated Seat Switch Signal B RED - Battery Positive Voltage B ORN 1140 Battery Positive Voltage C BLK - Ground C BLK 750 Ground D - - Not Used D - - Not Used
C317 (A43)
C317 (A43) Connector End Connector Part Information 15317325 22-Way F GT 150, 280 Series (LT GRY) Connector Part Information 15317322 22-Way M GT 150, 280 Series (LT GRY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 GRY 786 Driver Mirror Horizontal Position Sensor Signal A1 GRY 786 Driver Mirror Horizontal Position Sensor Signal A2 DK GRN 784 Driver Mirror Vertical Position Sensor Signal A2 DK GRN 784 Driver Mirror Vertical Position Sensor Signal A3 BRN/WHT 1048 SCM (Seat) Class 2 Serial Data A3 BRN/WHT 1048 SCM (Seat) Class 2 Serial Data A4 BRN 673 Low Reference A4 BRN 673 Low Reference LT GRN 675 Low Reference A5 - - Not Used A5 - - Not Used A6 RED/WHT 1513 Passenger Mirror Switch Right Signal A6 RED/WHT 1513 Passenger Mirror Switch Right Signal A7 WHT 1512 Driver Mirror Switch Right Signal A7 WHT 1512 Driver Mirror Switch Right Signal A8 GRY 915 Mirror Switch Supply Voltage A8 TAN 915 Mirror Switch Supply Voltage A9 LT GRN 89 Driver Mirror Motor Down Control A9 DK GRN 89 Driver Mirror Motor Down Control A10 LT BLU 82 Driver Mirror Motor Left Control A10 LT BLU 82 Driver Mirror Motor Left Control A11 WHT 81 Driver Mirror Motor Right Control A11 WHT 81 Driver Mirror Motor Right Control B1 LT BLU/BLK 785 Passenger Mirror Horizontal Position Sensor Signal B1 LT BLU/BLK 785 Passenger Mirror Horizontal Position Sensor Signal B2 BRN 787 Passenger Mirror Vertical Position Sensor Signal B2 BRN 787 Passenger Mirror Vertical Position Sensor Signal B3 PPL/WHT 889 Passenger Mirror Motor Down Control B3 PPL/WHT 889 Passenger Mirror Motor Down Control B4 - - Not Used B4 - - Not Used B5 PPL/WHT 1515 Passenger Mirror Switch Down Signal B5 PPL/WHT 1515 Passenger Mirror Switch Down Signal B6 YEL 1496 Mirror Motor Left/Up Control B6 YEL 1496 Mirror Motor Left/Up Control B7 - - Not Used B7 - - Not Used B8 DK BLU 672 5-Volt Reference B8 DK BLU 672 5-Volt Reference YEL 674 5-Volt Reference B9 GRY 90 Passenger Mirror Motor Left Control B9 GRY 90 Passenger Mirror Motor Left Control B10 RED/WHT 881 Passenger Mirror Motor Right Control B10 RED/WHT 881 Passenger Mirror Motor Right Control B11 LT GRN 1514 Driver Mirror Switch Down Control B11 DK GRN 1514 Driver Mirror Switch Down Control
C319 (KA1)
C319 (KA1) Connector End Connector Part Information 12059253 2-Way F Metri-Pack 150 Series (GRN) Connector Part Information 12059254 2-Way M Metri-Pack 150 Series (GRN) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BRN Heated Seat Element (Back) - Driver Ground A BLK Heated Seat Element (Back) - Driver Ground B BRN Heated Seat Element (Back) - Driver Supply Voltage B YEL Heated Seat Element (Back) - Driver Supply Voltage
C320 (KA1)
C320 (KA1) Connector End Connector Part Information 12059253 2-Way F Metri-Pack 150 Series (GRN) Connector Part Information 12059254 2-Way M Metri-Pack 150 Series (GRN) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BRN Heated Seat Element (Back) - Front Passenger Ground A BLK Heated Seat Element (Back) - Front Passenger Ground B BRN Heated Seat Element (Back) - Front Passenger Supply Voltage B YEL Heated Seat Element (Back) - Front Passenger Supply Voltage
C351
C351 Connector End Connector Part Information 12191371 6-Way F Metri-Pack 280 Series Flexlock (BLK) 12191370 4-Way F Metri-Pack 150 Series (BLK) Connector Part Information 12191369 10-Way M Metri-Pack (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PPL 169 Power Window Master Switch Left Rear Down Signal A PPL 169 Power Window Master Switch Left Rear Down Signal B GRY 295 Door Lock Actuator Lock Control B GRY 295 Door Lock Actuator Lock Control C PNK 775 Side Door Jamb Switch Signal C PNK 775 Side Door Jamb Switch Signal D DK BLU 1307 Power Window Master Switch Lockout Signal D DK BLU 1307 Power Window Master Switch Lockout Signal E TAN 294 Door Lock Actuator Unlock Control E TAN 294 Door Lock Actuator Unlock Control F DK GRN 168 Power Window Master Switch Left Rear Up Signal F DK GRN 168 Power Window Master Switch Left Rear Up Signal G YEL 116 Left Rear Speaker Output (-) G YEL 116 Left Rear Speaker Output (-) H BLK 550 Ground H BLK 550 Ground J DK BLU/WHT 727 Door Ajar Switch Signal J DK BLU/WHT 727 Door Ajar Switch Signal K BRN 199 Left Rear Speaker Output (+) K BRN 199 Left Rear Speaker Output (+)
Scheme 118
Scheme 119
C352
C352 Connector End Connector Part Information 12191371 6-Way F Metri-Pack 280 Series Flexlock (BLK) 12191370 4-Way F Metri-Pack 150 Series (BLK) Connector Part Information 12191369 10-Way M Metri-Pack (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PPL 171 Power Window Master Switch Right Rear Down Signal A PPL 171 Power Window Master Switch Right Rear Down Signal B GRY 295 Door Lock Actuator Lock Control B GRY 295 Door Lock Actuator Lock Control C PNK 775 Side Door Jamb Switch Signal C PNK 775 Side Door Jamb Switch Signal D DK BLU 1307 Power Window Master Switch Lockout Signal D DK BLU 1307 Power Window Master Switch Lockout Signal E TAN 294 Door Lock Actuator Unlock Control E TAN 294 Door Lock Actuator Unlock Control F LT GRN 170 Power Window Master Switch Right Rear Up Signal F LT GRN 170 Power Window Master Switch Right Rear Up Signal G LT BLU 115 Right Rear Speaker Output (-) G LT BLU 115 Right Rear Speaker Output (-) H BLK 750 Ground H BLK 750 Ground J DK BLU/WHT 727 Door Ajar Switch Signal J DK BLU/WHT 727 Door Ajar Switch Signal K DK BLU 46 Right Rear Speaker Output (+) K DK BLU 46 Right Rear Speaker Output (+)
C397 (CF5)
C397 (CF5) Connector End Connector Part Information 15326900 6-Way F 280 GT Series Sealed (BLK) Connector Part Information 15326833 6-Way M 150 GT Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A YEL 643 Accessory Voltage A YEL 643 Accessory Voltage B BLK 650 Ground B BLK 650 Ground (CF5) C BRN 100 Sunroof Switch Open Signal C BRN 100 Sunroof Switch Open Signal D DK BLU 128 Sunroof Switch Low Reference D DK BLU 128 Sunroof Switch Low Reference E ORN 110 Sunroof Switch Close Signal E ORN 110 Sunroof Switch Close Signal F - - Not Used F - - Not Used
C403
C403 Connector End Connector Part Information 15326842 10-Way F 150 Series Sealed (BLK) Connector Part Information 15326847 10-Way M 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BRN 9 Park Lamp Supply Voltage A BRN 9 Park Lamp Supply Voltage B ORN 9294 Endgate Lock Motor Unlock Control B ORN 9294 Endgate Lock Motor Unlock Control C RED 9295 Endgate Lock Motor Lock Control C RED 9295 Endgate Lock Motor Lock Control D PNK/BLK 1303 Liftgate Ajar Switch Signal D PNK/BLK 1303 Liftgate Ajar Switch Signal E PPL 9124 Liftgate Release Switch Signal E PPL 9124 Liftgate Release Switch Signal F RED/BLK 744 Trunk Ajar Switch Signal F RED/BLK 744 Trunk Ajar Switch Signal G LT BLU 383 Trunk Release Control G LT BLU 383 Trunk Release Control H PPL 2279 Lift Glass Ajar Switch Signal H PPL 2279 Lift Glass Ajar Switch Signal J BLK 450 Ground J BLK 450 Ground K YEL 656 Endgate Courtesy Lamp Control K YEL 656 Endgate Courtesy Lamp Control
Scheme 120
C405 (G67)
C405 (G67) Connector End Connector Part Information 15326829 6-Way F GT 150 Series Sealed (BLK) Connector Part Information 15326833 6-Way M GT 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A ORN 840 Battery Positive Voltage A ORN 840 Battery Positive Voltage B WHT 320 Automatic Level Control Exhaust Solenoid Control B WHT 320 Automatic Level Control Exhaust Solenoid Control C YEL 321 Automatic Level Control Relay Control C YEL 321 Automatic Level Control Relay Control D ORN 1240 Battery Positive Voltage D ORN 1240 Battery Positive Voltage E WHT 837 Automatic Level Control Inflator Relay Coil Control E WHT 837 Automatic Level Control Inflator Relay Coil Control F BLK 450 Ground F BLK 450 Ground
C407
C407 Connector End Connector Part Information 12146045 5-Way F 150 Series Sealed (WHT) Connector Part Information 12103974 5-Way M 150 Series Sealed (WHT) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BRN 9 Park Lamp Supply Voltage A BRN 9 Park Lamp Supply Voltage B LT GRN 24 Backup Lamp Supply Voltage (Pontiac) B LT GRN 24 Backup Lamp Supply Voltage (Pontiac) BRN 9 Park Lamp Supply Voltage (Buick) BRN 9 Park Lamp Supply Voltage (Buick) C YEL 18 Left Rear Stop/Turn Lamp Supply Voltage C DK GRN/YEL 18 Left Rear Stop/Turn Lamp Supply Voltage D BLK 850 Ground D BLK 850 Ground E BLK 850 Ground E BLK 850 Ground
C408
C408 Connector End Connector Part Information 12146045 5-Way F Metri-Pack 150 Series Sealed (WHT) Connector Part Information 12103974 5-Way M Metri-Pack 150 Series Sealed (WHT) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BRN 9 Park Lamp Supply Voltage A BRN 9 Park Lamp Supply Voltage B LT GRN 24 Backup Lamp Supply Voltage (Pontiac) B LT GRN 24 Backup Lamp Supply Voltage (Pontiac) BRN 9 Park Lamp Supply Voltage (Buick) BRN 9 Park Lamp Supply Voltage (Buick) C DK GRN 19 Right Rear Stop/Turn Lamp Supply Voltage C DK GRN/YEL 19 Right Rear Stop/Turn Lamp Supply Voltage D BLK 1850 Ground D BLK 1850 Ground E BLK 1850 Ground E BLK 1850 Ground
C411 (UD7)
C411 (UD7) Connector End Connector Part Information 15326829 6-Way F GT 150 Series Sealed (BLK) Connector Part Information 15326833 6-Way M GT 150 Series Sealed (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A DK BLU 2374 Object Sensor Supply Voltage A DK BLU 2374 Object Sensor Supply Voltage B YEL 2375 LR Corner Object Sensor Signal B YEL 2375 LR Corner Object Sensor Signal C GRY 2379 Object Sensor Low Reference C GRY 2379 Object Sensor Low Reference D ORN 2376 LR Middle Object Sensor Signal D ORN 2376 LR Middle Object Sensor Signal E DK GRN 2377 RR Middle Object Sensor Signal E DK GRN 2377 RR Middle Object Sensor Signal F RED 2378 RR Corner Object Sensor Signal F RED 2378 RR Corner Object Sensor Signal
C413
C413 Connector End Connector Part Information 15326956 16-Way F 280 GT Series (BLK) Connector Part Information 15326952 16-Way M 280 GT Series (BLK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A DK GRN 1927 Rear Defog Element Supply Voltage A DK GRN 1927 Rear Defog Element Supply Voltage B YEL 656 Liftgate Courtesy Lamp Control B YEL 656 Liftgate Courtesy Lamp Control C PNK/BLK 1303 Liftgate Ajar Switch Signal C PNK/BLK 1303 Liftgate Ajar Switch Signal D WHT/BLK 1221 Lift Gate Release Switch Signal D WHT/BLK 1221 Lift Gate Release Switch Signal E WHT 17 Stop Lamp Switch Signal E WHT 17 Stop Lamp Switch Signal F PPL 1305 Liftgate Lock Motor Unlock Signal F PPL 1305 Liftgate Lock Motor Unlock Signal G BRN 9 Park Lamp Supply Voltage G BRN 9 Park Lamp Supply Voltage H LT GRN 24 Backup Lamp Supply Voltage H LT GRN 24 Backup Lamp Supply Voltage LT GRN 24 Backup Lamp Supply Voltage J WHT 1304 Liftgate Lock Motor Lock Control J WHT 1304 Liftgate Lock Motor Lock Control K - - Not Used K - - Not Used L YEL 343 Accessory Voltage L YEL 343 Accessory Voltage M GRY 391 Rear Window Wiper Switch Signal M GRY 391 Rear Window Wiper Switch Signal N DK GRN 392 Rear Window Washer Pump Control N DK GRN 392 Rear Window Washer Pump Control P BLK 1150 Ground P BLK 1150 Ground R-S - - Not Used R-S - - Not Used
C420 (V92)
C420 (V92) Connector End Connector Part Information 12146045 5-Way F Metri-Pack 150 Series Sealed (WHT) Connector Part Information 12103974 5-Way M Metri-Pack 150 Series Sealed (WHT) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BLK 450 Ground A - - Ground B BRN 9 Park Lamp Supply Voltage B - - Park Lamp Supply Voltage C ORN 2540 Battery Positive Voltage C - - Battery Positive Voltage D YEL 18 Left Rear Stop/Turn Lamp Supply Voltage D - - Left Rear Stop/Turn Lamp Supply Voltage E DK GRN 19 Right Rear Stop/Turn Lamp Supply Voltage E - - Right Rear Stop/Turn Lamp Supply Voltage
C900
C900 (Buick) Connector Part Information 12146046 5-Way F Metri-Pack 150 Series (GRY) Connector Part Information 12092840 5-Way M Metri-Pack 150 Series (GRY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BRN 9 Park Lamp Supply Voltage A BRN - Park Lamp Supply Voltage B LT GRN 24 Backup Lamp Supply Voltage B LT GRN - Backup Lamp Supply Voltage C LT GRN 24 Backup Lamp Supply Voltage C LT GRN - Backup Lamp Supply Voltage D - - Not Used D - - Not Used E BLK 1150 Ground E BLK - Ground
Splice Pack SP205
Splice Pack SP205 Connector End Connector Part Information 12191216 12-Way F Metri-Pack 150 Series (GRY) Pin Wire Color Circuit No. Function A PPL 1132 DLC Class 2 Serial Data B DK GRN 1049 PCM Class 2 Serial Data C BRN/WHT 1048 SCM (Seat) Class 2 Serial Data (A43) D ORN 1044 Radio Class 2 Serial Data E LT BLU 1122 ABS/TCS Class 2 Serial Data F DK BLU 1128 SDM Class 2 Serial Data G GRY 1036 IPC Class 2 Serial Data H PPL 1807 Class 2 Serial Data (Primary) J LT GRN 2271 Class 2 Serial Data K BLK 9936 HUD Class 2 Serial Data L WHT 1038 HVAC Class 2 Serial Data (CJ2) M LT GRN 1037 BCM Class 2 Serial Data
Splice Pack SP206
Splice Pack SP206 Connector End Connector Part Information 12191216 12-Way F Metri-Pack 150 Series (GRY) Pin Wire Color Circuit No. Function A - - Not Used B DK BLU 1128 SDM Class 2 Serial Data C - - Not Used D ORN 1044 Radio Class 2 Serial Data E PNK 1045 DVD Class 2 Serial Data (U32) F TAN 9807 Class 2 Serial Data (U2K) G GRY 2289 Rear HVAC/Audio Class 2 Serial Data (UK6) H-M - - Not Used
SP215 - UK3
SP215 - UK3 Connector End Connector Part Information 12176473 12-Way F Metri-Pack 280 Series Splice Saver (BLK) Pin Wire Color Circuit No. Function A BRN/WHT 367 Remote Radio Left Audio Signal B BRN/WHT 367 Remote Radio Left Audio Signal C BRN/WHT 367 Remote Radio Left Audio Signal D DK GRN/WHT 368 Remote Radio Right Audio Signal E DK GRN/WHT 368 Remote Radio Right Audio Signal F DK GRN/WHT 368 Remote Radio Right Audio Signal G BLK/WHT 372 Remote Radio Audio Output (-) H BLK/WHT 372 Remote Radio Audio Output (-) J BLK/WHT 372 Remote Radio Audio Output (-) K BARE 814 Drain Wire (UE1) L - - Not Used M BARE 814 Drain Wire (UE1)
SP250
SP250 Connector End Connector Part Information 12176473 12-Way F Metri-Pack 280 Series Splice Saver (BLK) Pin Wire Color Circuit No. Function A BLK 1650 Ground (Buick) B BLK 1650 Ground C BLK 1650 Ground D BRN 9 Park Lamp Supply Voltage E BRN 9 Park Lamp Supply Voltage F BRN 9 Park Lamp Supply Voltage G ORN 2740 Battery Positive Voltage H ORN 2740 Battery Positive Voltage J ORN 2740 Battery Positive Voltage K BRN 241 Ignition 3 Voltage L BRN 241 Ignition 3 Voltage M BRN 241 Ignition 3 Voltage
SP315
SP315 Connector End Connector Part Information 12176473 12-Way F Metri-Pack 280 Series Splice Saver (BLK) Pin Wire Color Circuit No. Function A DK BLU/WHT 727 Secondary Door Latch Switch Signal B DK BLU/WHT 727 Secondary Door Latch Switch Signal C DK BLU/WHT 727 Secondary Door Latch Switch Signal D-J - - Not Used K PNK 775 Door Jamb Switch Signal - Driver L PNK 775 Door Jamb Switch Signal - Driver M PNK 775 Door Jamb Switch Signal - Driver
SP409
SP409 Connector End Connector Part Information 12176473 12-Way F Metri-Pack 280 Series Splice Saver (BLK) Pin Wire Color Circuit No. Function A BRN 9 Park Lamp Supply Voltage BRN 9 Park Lamp Supply Voltage (Buick) B BRN 9 Park Lamp Supply Voltage BRN 9 Park Lamp Supply Voltage C BRN 9 Park Lamp Supply Voltage BRN 9 Park Lamp Supply Voltage D BLK 850 Ground BLK 850 Ground (Buick) E BLK 850 Ground BLK 850 Ground F BLK 850 Ground G YEL 18 Left Rear Stop/Turn Lamp Supply Voltage H YEL 18 Left Rear Stop/Turn Lamp Supply Voltage J YEL 18 Left Rear Stop/Turn Lamp Supply Voltage K BRN 9 Park Lamp Supply Voltage (Buick) L BRN 9 Park Lamp Supply Voltage (Buick) BRN 9 Park Lamp Supply Voltage (Buick) M BRN 9 Park Lamp Supply Voltage (Buick)
