MODEL IDENTIFICATION
Vehicle model is identified by fourth character of Vehicle Identification Number (VIN). VIN is stamped on metal pad on top of left end of instrument panel, near windshield. See MODEL IDENTIFICATION table.
| Body Code (1) | Model |
|---|
| "C" | Park Avenue |
| "E" | Eldorado |
| "F" | Camaro & Firebird |
| "G" | Aurora |
| "H" | Bonneville & LeSabre |
| "J" | Cavalier, Saturn ("L" Series) & Sunfire |
| "K" | DeVille & Seville |
| "N" | Alero, Grand Am & Malibu |
| "S" | Prizm |
| "W" | Century, Grand Prix, Impala, Intrigue, Monte Carlo & Regal |
| "Y" | Corvette |
| "Z" | Saturn ("S" Series) |
| (1) Vehicle body code is fourth character of VIN. |
| (1) | Vehicle body code is fourth character of VIN. |
INTRODUCTION
Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This is a quick-reference article to use when you are familiar with proper adjustment procedures and only need a specification.
ENGINE OIL CAPACITY
| Application | (2) Quantity Qts. (L) |
|---|
| 1.8L | 3.9 (3.7) |
| 1.9L | 4.0 (3.8) |
| 2.2L |
| "J" Body |
| Cavalier & Sunfire | (3) |
| Saturn ("L" Series) | 5.0 (4.7) |
| "N" Body |
| Alero & Grand Am | 5.0 (4.7) |
| 2.4L | 4.0 (3.8) |
| 3.0L | 5.0 (4.7) |
| 3.1L |
| Except Grand Prix | 4.5 (4.3) |
| Grand Prix | 4.3 (4.1) |
| 3.4L | 4.5 (4.3) |
| 3.5L |
| "G" Body | 6.0 (5.7) |
| "W" Body | 6.5 (6.2) |
| 3.8L |
| "W" Body | 4.3 (4.1) |
| All Others | 4.5 (4.3) |
| 4.0L | 7.0 (6.6) |
| 4.6L | 7.5 (7.1) |
| 5.7L |
| "F" Body | 5.5 (5.2) |
| "Y" Body | 6.5 (6.2) |
| (1) Fluid capacities listed are approximate. Always fill to FULL mark. (2) Includes oil filter capacity. (3) Vehicles identified with 8th VIN character "F", use 5.8 Qts. (5.5L). Vehicles identified with 8th VIN character "4", use 4.0 Qts. (3.8L). |
| (1) | Fluid capacities listed are approximate. Always fill to FULL mark. |
| (2) | Includes oil filter capacity. |
| (3) | Vehicles identified with 8th VIN character "F", use 5.8 Qts. (5.5L). Vehicles identified with 8th VIN character "4", use 4.0 Qts. (3.8L). |
FLUID CAPACITY (CRANKCASE) (1)
COOLING SYSTEM FLUID CAPACITY
| Application | (2) Quantity Qts. (L) |
|---|
| 1.8L |
| Automatic Transmission | 6.4 (6.1) |
| Manual Transmission | 6.6 (6.2) |
| 1.9L | 7.0 (6.6) |
| 2.2L |
| "J" Body |
| Cavalier & Sunfire | (3) |
| Saturn ("L" Series) |
| Automatic Transmission | 7.3 (6.9) |
| Manual Transmission | 7.4 (7.0) |
| "N" Body | 11.3 (10.7) |
| 2.4L | 10.2 (9.6) |
| 3.0L | 7.8 (7.4) |
| 3.1L |
| "N" Body | 13.6 (12.9) |
| "W" Body |
| Except Grand Prix | 11.6 (11.0) |
| Grand Prix | 11.0 (10.4) |
| 3.4L |
| "N" Body | 13.6 (12.9) |
| "W" Body | 11.3 (10.7) |
| 3.5L | 10.0 (9.5) |
| 3.8L |
| "C" Body | 13.0 (12.3) |
| "F" Body |
| Automatic Transmission | 11.4 (10.8) |
| Manual Transmission | 11.6 (11.0) |
| "H" Body | 10.0 (9.5) |
| "W" Body |
| Except Impala, Monte Carlo & Regal | 11.2 (10.6) |
| Impala & Monte Carlo | 11.7 (11.0) |
| Regal | 12.3 (11.6) |
| 4.0L | 13.0 (12.3) |
| 4.6L | 12.5 (11.8) |
| 5.7L |
| "F" Body |
| Automatic Transmission | 11.8 (11.2) |
| Manual Transmission | 11.9 (11.3) |
| "Y" Body | 12.6 (11.9) |
| (1) Fluid capacities listed are approximate. Always fill to FULL mark. (2) Includes heater. (3) Vehicles identified with 8th VIN character "F", use 8.6 Qts. (8.2L). Vehicles identified with 8th VIN character "4", use 10.2 Qts. (9.6L). |
| (1) | Fluid capacities listed are approximate. Always fill to FULL mark. |
| (3) | Vehicles identified with 8th VIN character "F", use 8.6 Qts. (8.2L). Vehicles identified with 8th VIN character "4", use 10.2 Qts. (9.6L). |
FLUID CAPACITY (COOLING SYSTEM) (1)
AUTOMATIC TRANSAXLE/TRANSMISSION FLUID CAPACITY
| Application | (3) Quantity Qts. (L) |
|---|
| "C" Body | 6.0 (5.7) |
| "E" & "K" Bodies | 11.0 (10.4) |
| "F" & "Y" Bodies | 5.0 (4.7) |
| "G" Body |
| 4T65-E | 7.4 (7.0) |
| 4T80-E | 11.0 (10.4) |
| "H" Body | 7.4 (7.0) |
| "J" Body |
| Cavalier & Sunfire |
| 3-Speed | 4.0 (3.8) |
| 4-Speed | 6.9 (6.5) |
| Saturn ("L" Series) | 6.9 (6.5) |
| "M" Body |
| 3-Speed | 2.6 (2.5) |
| 4-Speed | 1.6 (1.5) |
| "N" Body | 6.9 (6.5) |
| "S" Body |
| 3-Speed | 2.6 (2.5) |
| 4-Speed | 3.3 (3.1) |
| "W" Body | 7.4 (7.0) |
| "Z" Body | (4) 4.2 (4.0) |
| (1) Fluid capacities listed are approximate. Always fill to FULL mark. (2) Drain and refill capacity only. Does not include torque converter. (3) Unless otherwise specified, use Dexron-III transmission fluid. (4) Use Saturn transaxle fluid or Dexron-III. If Dexron-III is used, service transmission fluid and filter every 30,000 miles rather than 100,000 miles. |
| (1) | Fluid capacities listed are approximate. Always fill to FULL mark. |
| (2) | Drain and refill capacity only. Does not include torque converter. |
| (3) | Unless otherwise specified, use Dexron-III transmission fluid. |
| (4) | Use Saturn transaxle fluid or Dexron-III. If Dexron-III is used, service transmission fluid and filter every 30,000 miles rather than 100,000 miles. |
FLUID CAPACITY (AUTOMATIC TRANSAXLE/TRANSMISSION) (1) (2)
MANUAL TRANSAXLE/TRANSMISSION FLUID CAPACITY
| Application | Quantity Qts. (L) |
|---|
| "F" Body (2) |
| 5-Speed | 3.4 (3.2) |
| 6-Speed | 4.0 (3.8) |
| "J" Body (2) |
| Cavalier & Sunfire | 1.8 (1.7) |
| Saturn ("L" Series) | 2.0 (1.9) |
| "M" Body (3) | 2.5 (2.4) |
| "N" Body (2) | 2.6 (2.5) |
| "S" Body (3) | 2.0 (1.9) |
| "Y" Body (2) | 4.1 (3.9) |
| "Z" Body (4) | 2.6 (2.5) |
| (1) Fluid capacities listed are approximate. Always fill to FULL mark. (2) Dexron III. (3) SAE 75W-90 GL-4 gear oil. (4) Use Saturn transaxle fluid or Dexron-III. |
| (1) | Fluid capacities listed are approximate. Always fill to FULL mark. |
| (3) | SAE 75W-90 GL-4 gear oil. |
| (4) | Use Saturn transaxle fluid or Dexron-III. |
FLUID CAPACITY (MANUAL TRANSAXLE/TRANSMISSION) (1)
DIFFERENTIAL FLUID CAPACITY
| Application | Quantity Pts. (L) |
|---|
| "F" & "Y" Bodies |
| Locking | (1) 3.5 (1.7) |
| Non-Locking | (2) 3.5 (1.7) |
| (1) Use Synthetic 75W-90 GL-5 gear lubricant with 4 oz. (118 ml) of limited slip differential additive (GM Part No. 1052358). (2) Use Synthetic 75W-90 GL-5 gear lubricant. |
| (1) | Use Synthetic 75W-90 GL-5 gear lubricant with 4 oz. (118 ml) of limited slip differential additive (GM Part No. 1052358). |
| (2) | Use Synthetic 75W-90 GL-5 gear lubricant. |
FLUID CAPACITY (DIFFERENTIAL)
SERVICE INTERVALS & SPECIFICATIONS
| Component | Miles |
|---|
| Air Filter | 30,000 |
| Accessory Drive Belt (1) |
| "J" Body |
| Cavalier & Sunfire | 60,000 |
| Saturn ("L" Series) | 18,000 |
| "M" Body | 30,000 |
| "Z" Body | 18,000 |
| All Others | 60,000 |
| Automatic Transaxle Fluid |
| "F" Body | (2) |
| "J" Body | (3) |
| "K" Body | (4) |
| "N" Body |
| Alero & Grand Am | (5) |
| Malibu | (6) |
| "S" Body | (6) |
| "W" Body |
| Except Grand Prix, Impala, Intrigue, Monte Carlo & Regal | (5) |
| Grand Prix, Impala, Intrigue, Monte Carlo & Regal | (3) |
| All Others | (5) |
| Engine Coolant (7) |
| "J" Body |
| Cavalier & Sunfire | 150,000 |
| Saturn ("L" Series) | 100,000 |
| "M" Body | 30,000 |
| "N" Body |
| Alero & Grand Am | 100,000 |
| Malibu | 150,000 |
| "S" Body | (8) |
| "W" Body | (9) |
| "Z" Body | 100,000 |
| All Others | 150,000 |
| Fuel Filter |
| "J" Body |
| Cavalier & Sunfire | (10) |
| Saturn ("L" Series) | 100,000 |
| "M" & "Z" Bodies | 100,000 |
| "N" Body |
| Alero & Grand Am | (11) |
| Malibu | (10) |
| All Others | (10) |
| Manual Transmission/Transaxle Fluid |
| "F", "J", "S", "Y" & "Z" Bodies | (11) |
| Oil & Filter |
| "C" Body | (12) |
| "H" Body |
| Bonneville | (12) |
| Le Sabre | (13) |
| "J" Body | 7500 |
| "N" Body |
| Alero & Grand Am | (14) 3000 |
| Malibu | (12) |
| "S" Body | (14) 3000-7500 |
| "Z" Body | 6000 |
| All Others | (13) |
| Spark Plugs |
| "J" Body |
| Cavalier & Sunfire | 100,000 |
| Saturn ("L" Series) |
| 2.2L | (10) |
| 3.0L | 100,000 |
| "M" & "Z" Bodies | 30,000 |
| "S" Body | 120,000 |
| All Others | 100,000 |
| Timing Belt |
| "J" Body (3.0L) |
| Saturn "L" Series | 100,000 |
| "M" Body | 100,000 |
| (1) Check and replace as necessary. (2) Under normal service conditions, replace at 50,000 miles. If used under severe service conditions, replace every 15,000 miles. (3) Under normal service conditions, periodic replacement is not required. If used under severe service conditions, replace every 50,000 miles. (4) Under normal service conditions, replace when CHANGE TRANS FLUID message is displayed on driver's information center. If used under severe service conditions, replace every 50,000 miles. (5) Under normal service conditions, replace at 100,000 miles. If used under severe service conditions, replace every 50,000 miles. (6) Under normal service conditions, periodic replacement is not required. If used under severe service conditions, replace every 30,000 miles. (7) Use only DEX-COOL® coolant or equivalent silicate-free coolant. (8) Replace at 24 months or 30,000 miles, whichever occurs first. (9) Replace at 60 months or 150,000 miles, whichever occurs first. (10) Information is not available from manufacturer. (11) Periodic replacement is not required. (12) Replace at 12 months or 7500 miles, whichever occurs first. (13) Replace as indicated by oil life monitor or every 12 months, whichever occurs first. (14) If not equipped with oil life monitor, check and replace as necessary. |
| (1) | Check and replace as necessary. |
| (2) | Under normal service conditions, replace at 50,000 miles. If used under severe service conditions, replace every 15,000 miles. |
| (3) | Under normal service conditions, periodic replacement is not required. If used under severe service conditions, replace every 50,000 miles. |
| (4) | Under normal service conditions, replace when CHANGE TRANS FLUID message is displayed on driver's information center. If used under severe service conditions, replace every 50,000 miles. |
| (5) | Under normal service conditions, replace at 100,000 miles. If used under severe service conditions, replace every 50,000 miles. |
| (6) | Under normal service conditions, periodic replacement is not required. If used under severe service conditions, replace every 30,000 miles. |
| (7) | Use only DEX-COOL® coolant or equivalent silicate-free coolant. |
| (8) | Replace at 24 months or 30,000 miles, whichever occurs first. |
| (9) | Replace at 60 months or 150,000 miles, whichever occurs first. |
| (10) | Information is not available from manufacturer. |
| (11) | Periodic replacement is not required. |
| (12) | Replace at 12 months or 7500 miles, whichever occurs first. |
| (13) | Replace as indicated by oil life monitor or every 12 months, whichever occurs first. |
| (14) | If not equipped with oil life monitor, check and replace as necessary. |
| Application | Belt Deflection |
|---|
| All Models | (1) |
| (1) Adjustment of serpentine belt is not necessary. Belt tension is maintained by spring-tensioned idler pulley (some equipped with belt wear indicator). |
| (1) | Adjustment of serpentine belt is not necessary. Belt tension is maintained by spring-tensioned idler pulley (some equipped with belt wear indicator). |
ENGINE COMPRESSION
Check engine compression with engine at normal operating temperature, all spark plugs removed and throttle wide open.
| Application | Specification |
|---|
| Normal Compression Pressure | Psi (kPa) |
| 1.8L | (1) 218 (1500) |
| 1.9L | 185-205 (1276-1414) |
| 3.5L |
| Aurora | 140-170 (965-1172) |
| Intrigue | (2) |
| 4.0L & 4.6L | 140-170 (965-1172) |
| All Others | (3) |
| Minimum Compression Pressure |
| 1.8L | (1) 145 (1000) |
| 1.9L | 180 psi (1241 kPa) |
| 3.5L |
| Aurora | (4) |
| Intrigue | (2) |
| 4.0L & 4.6L | (2) |
| All Others | (3) |
| (1) No cylinder compression reading should be less than 15 psi (100 kPa) of highest compression reading. (2) Lowest compression reading should not be less than 70 percent of highest compression reading. No cylinder compression reading should be less than 140 psi (965 kPa). (3) Lowest compression reading should not be less than 70 percent of highest compression reading. No cylinder compression reading should be less than 100 psi (690 kPa). (4) Information is not available from manufacturer. |
| (1) | No cylinder compression reading should be less than 15 psi (100 kPa) of highest compression reading. |
| (2) | Lowest compression reading should not be less than 70 percent of highest compression reading. No cylinder compression reading should be less than 140 psi (965 kPa). |
| (3) | Lowest compression reading should not be less than 70 percent of highest compression reading. No cylinder compression reading should be less than 100 psi (690 kPa). |
| (4) | Information is not available from manufacturer. |
ENGINE COMPRESSION SPECIFICATIONS
VALVE CLEARANCE
| Application | In. (mm) |
|---|
| "S" Body |
| Intake | (1) .006-.010 (.15-.25) |
| Exhaust | (1) .010-.014 (.25-.35) |
| All Others | (2) |
| (1) Adjustments are made with engine cold 77°F (25°C). (2) Equipped with hydraulic lifters. Adjustment is not required. |
| (1) | Adjustments are made with engine cold 77°F (25°C). |
| (2) | Equipped with hydraulic lifters. Adjustment is not required. |
VALVE CLEARANCE SPECIFICATIONS
HIGH TENSION WIRE RESISTANCE
| Application | Ohms |
|---|
| 1.9L | 1500-15,000 Per Ft. |
| 2.2L |
| "J" Body |
| Cavalier & Sunfire | (1) |
| Saturn ("L" Series) | (2) |
| "N" Body | (2) |
| 3.1L | 3000 Per Ft. |
| 3.4L |
| Except Impala & Monte Carlo | 3000 Per Ft. |
| Impala & Monte Carlo | 600 Per Ft. |
| 3.8L |
| Except Police | 3000 Per Ft. |
| Police | 600 Per Ft. |
| 5.7L | 700 Per Ft. |
| All Others | (2) |
| (1) Vehicles identified with 8th VIN character "F", are not equipped with high tension wires. Ignition coils are connected directly to spark plugs by boots. On vehicles identified with 8th VIN character "4", resistance is 12,000 ohms per foot. (2) Not equipped with high tension wires. Ignition coils are connected directly to spark plugs by boots. |
| (1) | Vehicles identified with 8th VIN character "F", are not equipped with high tension wires. Ignition coils are connected directly to spark plugs by boots. On vehicles identified with 8th VIN character "4", resistance is 12,000 ohms per foot. |
| (2) | Not equipped with high tension wires. Ignition coils are connected directly to spark plugs by boots. |
HIGH TENSION WIRE RESISTANCE
SPARK PLUGS
| Application | Spark Plug Type | Spark Plug No. |
|---|
| 1.8L | Denso | SR16R-11 |
| NGK | IFR5A-11 |
| 1.9L |
| DOHC | NGK | BKR5ESA-11 |
| SOHC | NGK | BKR4ESA-11 |
| 2.2L |
| Alero & Grand Am | AC | 41-981 |
| Cavalier & Sunfire | AC | (1) |
| Saturn ("L" Series) | AC | 41-628 |
| 2.4L | AC | 41-963 |
| 3.0L | Bosch | FLR9LTE |
| 3.1L & 3.4L | AC | 41-940 |
| 3.5L |
| Aurora | AC | 41-950 |
| Intrigue | AC | PTR5C-13 |
| 3.8L | AC | 41-921 |
| 4.0L | AC | 41-950 |
| 4.6L | AC | PT16EPR-C13 |
| 5.7L |
| Camaro & Firebird | AC | 41-952 |
| Corvette | AC | 41-974 |
| (1) Vehicles identified with 8th VIN character "F", use spark plug No. 41-981. Vehicles identified with 8th VIN character "4", use spark plug No. 41-928. |
| (1) | Vehicles identified with 8th VIN character "F", use spark plug No. 41-981. Vehicles identified with 8th VIN character "4", use spark plug No. 41-928. |
| Application | Gap - In. (mm) | Torque - Ft. Lbs. (N.m) |
|---|
| 1.8L | .040-.043 (1.02-1.09) | 13 (18) |
| 1.9L | .040 (1.02) | 20 (27) |
| 2.2L |
| "J" Body |
| Cavalier & Sunfire | (1) | (2) |
| Saturn ("L" Series) | .045 (1.14) | 15 (20) |
| "N" Body |
| Alero & Grand Am | .042 (1.07) | 15 (20) |
| Malibu | .60 (1.52) | 11 (15) |
| 2.4L | .050 (1.27) | 13 (18) |
| 3.0L | .040 (1.02) | 18 (25) |
| 3.1L & 3.8L | .060 (1.52) | 11 (15) |
| 3.4L |
| Except Impala & Monte Carlo | .060 (1.52) | 11 (15) |
| Impala & Monte Carlo | .060 (1.52) | 20 (27) |
| 3.5L |
| Aurora | .050 (1.27) | 15 (20) |
| Intrigue | .060 (1.52) | 15 (20) |
| 4.0L | .050 (1.27) | 13-16 (18-22) |
| 4.6L |
| Deville & Seville | .050 (1.27) | 13-17 (18-23) |
| Eldorado | .050 (1.27) | 11 (15) |
| 5.7L |
| Camaro & Firebird | .060 (1.52) | 11 (15) |
| Corvette | .060 (1.52) | (3) |
| (1) On vehicles identified with 8th VIN character "F", gap is .042" (1.07 mm). On vehicles identified with 8th VIN character "4", gap is .040" (1.02 mm). (2) On vehicles identified with 8th VIN character "F", torque is 15 ft. lbs. (20 N.m). On vehicles identified with 8th VIN character "4", torque is 13 ft. lbs. (18 N.m). (3) Torque spark plugs on new heads to 20 ft. lbs. (27 N.m). Torque spark plugs on used heads to 11 ft. lbs. (15 N.m). |
| (1) | On vehicles identified with 8th VIN character "F", gap is .042" (1.07 mm). On vehicles identified with 8th VIN character "4", gap is .040" (1.02 mm). |
| (2) | On vehicles identified with 8th VIN character "F", torque is 15 ft. lbs. (20 N.m). On vehicles identified with 8th VIN character "4", torque is 13 ft. lbs. (18 N.m). |
| (3) | Torque spark plugs on new heads to 20 ft. lbs. (27 N.m). Torque spark plugs on used heads to 11 ft. lbs. (15 N.m). |
SPARK PLUG SPECIFICATIONS
FIRING ORDER
Scheme 1
Scheme 1: Firing Order (1.8L, 1.9L, 2.2L & 2.4L)
Scheme 2
Scheme 2: Firing Order (3.0L & 3.5L)
Scheme 3
Scheme 3: Firing Order (3.1L & 3.4L)
Scheme 4
Scheme 4: Firing Order (3.8L - Except "F" Body)
Scheme 5
Scheme 5: Firing Order (3.8L - "F" Body)
Scheme 6
Scheme 6: Firing Order (4.0L & 4.6L)
Scheme 7
Scheme 7: Firing Order (5.7L)
IGNITION TIMING
Note. All models are equipped with an electronic computer-controlled ignition system. Timing is not adjustable.
FUEL PUMP
| Application | (1) KOEO psi (kPa) |
|---|
| 1.8L | 44-50 (303-345) |
| 1.9L | 40-55 (276-379) |
| 2.2L |
| "J" Body |
| Cavalier & Sunfire |
| VIN "F" (2) | 50-60 (345-414) |
| VIN "4" (2) | 53-59 (365-407) |
| Saturn ("L" Series) | 50-60 (345-414) |
| "N" Body | 50-60 (345-414) |
| 2.4L | 53-59 (365-407) |
| 3.0L | 40-50 (276-345) |
| 3.1L & 3.4L | 52-59 (359-407) |
| 3.5L, 4.0L & 4.6L | 41-47 (283-324) |
| 3.8L |
| VIN "K" (2) | (3) 53-59 (365-407) |
| VIN "1" (2) | 48-54 (331-372) |
| 5.7L | 55-62 (379-428) |
| (1) KOEO is ignition key ON and engine OFF. (2) Eighth VIN character. (3) 48-55 psi (331-379 kPa) on Camaro and Firebird. |
| (1) | KOEO is ignition key ON and engine OFF. |
| (3) | 48-55 psi (331-379 kPa) on Camaro and Firebird. |
INJECTOR RESISTANCE
| Application | (1) Ohms |
|---|
| 1.8L | (2) 13.4-14.4 |
| 1.9L | (3) 11.8-12.6 |
| 2.2L |
| "J" Body |
| Cavalier & Sunfire | 11.0-14.0 |
| Saturn ("L" Series) | (3) 12.0-13.0 |
| "N" Body | 11.0-14.0 |
| 3.0L | 14.0-23.0 |
| 3.4L |
| Except Impala & Monte Carlo | 11.0-14.0 |
| Impala & Monte Carlo | 11.4-12.6 |
| All Others | 11.0-14.0 |
| (1) Unless otherwise specified, injector resistance specification is at 50-95°F (10-35°C). (2) Injector voltage is also measured. Voltage reading should be 6.7-7.7 volts. (3) Injector resistance specification is at 74°F (23.3°C). |
| (1) | Unless otherwise specified, injector resistance specification is at 50-95°F (10-35°C). |
| (2) | Injector voltage is also measured. Voltage reading should be 6.7-7.7 volts. |
| (3) | Injector resistance specification is at 74°F (23.3°C). |
INJECTOR RESISTANCE SPECIFICATIONS
IDLE SPEED & MIXTURE
Note. Idle mixture is controlled by Powertrain Control Module (PCM). Idle speed is preset by manufacturer and is not adjustable.
THROTTLE POSITION (TP) SENSOR
Note. TP sensor is not adjustable unless specified otherwise. For further testing procedures, refer to appropriate SELF-DIAGNOSTICS or SYSTEM & COMPONENT TESTING article.
Note. On some models, throttle control is electronic with NO mechanical link from engine to accelerator pedal. The PCM and Throttle Actuator Control (TAC) module monitors the position of accelerator pedal based on signals from a nonadjustable Accelerator Pedal Position (APP) sensor. The APP sensor is mounted above accelerator pedal.
| Application | (1) Volts |
|---|
| 1.8L | 0.1 To 4.9 |
| 1.9L | (2) |
| 2.2L |
| "J" Body |
| Cavalier & Sunfire | (3) |
| Saturn ("L" Series) | (4) |
| "N" Body | (3) |
| 3.0L | (5) |
| 3.8L | (6) |
| 5.7L |
| Camaro & Firebird | (3) |
| Corvette | (7) |
| 2.4L, 3.1L, 3.4L, 3.5L, 4.0L & 4.6L | (3) |
| (1) Voltage range is from idle to wide open throttle. (2) Voltage ranges from 0.2-0.6 volt with throttle closed to 4.7 volts at wide open throttle. (3) Voltage range is from less than one volt at closed throttle to greater than 4 volts at wide open throttle. (4) Voltage ranges from 0.15-0.55 volt with throttle closed to 4.65 volts at wide open throttle. (5) Voltage ranges from 0.50 volt with throttle closed to 4.15-4.35 volts at wide open throttle. (6) On Camaro and Firebird, voltage range is from 0.25 volt with throttle closed to 4.49 volts at wide open throttle. On all other vehicles, voltage range is from less than one volt at closed throttle to greater than 4 volts at wide open throttle. (7) TP sensor is 2 individual units within one housing. TP sensor 1 signal voltage ranges from one volt with throttle closed to more than 3.5 volts at wide open throttle. TP sensor 2 signal voltage ranges from about 3.8 volts with throttle closed to less than one volt at wide open throttle. |
| (1) | Voltage range is from idle to wide open throttle. |
| (2) | Voltage ranges from 0.2-0.6 volt with throttle closed to 4.7 volts at wide open throttle. |
| (3) | Voltage range is from less than one volt at closed throttle to greater than 4 volts at wide open throttle. |
| (4) | Voltage ranges from 0.15-0.55 volt with throttle closed to 4.65 volts at wide open throttle. |
| (5) | Voltage ranges from 0.50 volt with throttle closed to 4.15-4.35 volts at wide open throttle. |
| (6) | On Camaro and Firebird, voltage range is from 0.25 volt with throttle closed to 4.49 volts at wide open throttle. On all other vehicles, voltage range is from less than one volt at closed throttle to greater than 4 volts at wide open throttle. |
| (7) | TP sensor is 2 individual units within one housing. TP sensor 1 signal voltage ranges from one volt with throttle closed to more than 3.5 volts at wide open throttle. TP sensor 2 signal voltage ranges from about 3.8 volts with throttle closed to less than one volt at wide open throttle. |
TP SENSOR ADJUSTMENT VOLTAGE
