Power Outlets: Other Buick LaCrosse II facelift

Body Electrical 2 illustrations ~469 words

Intermittent

Electrical connections or wiring may be the cause of intermittent conditions. Refer to Testing for Intermittent Conditions and Poor Connections

Reference Information

Schematic Reference

Cigar Lighter/Power Outlet Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Power Outlets Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-621979-S25489769122014061000000)
  2. «Connector Repairs»(ref-621979-S38632404432014061000000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-621979-S12070404672014061000000)
  4. «Wiring Repairs»(ref-621979-S02064091202014061000000)

Circuit/System Verification

  1. Ignition ON.
  2. Connect an AC powered device to the X81 Accessory Power Receptacle - 110V AC.
  3. Verify the T1 Accessory DC/AC Power Inverter Module is turned ON and the device works as expected. If the device is not powered Refer to Circuit/System Testing (below). If the device is powered
  4. All OK.

Repair Instructions

Perform the Diagnostic Repair Verification after completing the repair.

Accessory AC and DC Power Control Module Replacement

Schematic Reference

Cigar Lighter/Power Outlet Schematics

Connector End View Reference

COMPONENT CONNECTOR END VIEWS - INDEX

Description and Operation

Power Outlets Description and Operation

Electrical Information Reference

  1. «Circuit Testing»(ref-621979-S25489769122014061000000)
  2. «Connector Repairs»(ref-621979-S38632404432014061000000)
  3. «Testing for Intermittent Conditions and Poor Connections»(ref-621979-S12070404672014061000000)
  4. «Wiring Repairs»(ref-621979-S02064091202014061000000)
  1. Ignition ON, connect an appropriate device to the X80 Accessory Power Receptacle.
  2. Verify the device is powered by the X80 Accessory Power Receptacle. If the device is not powered Refer to Circuit/System Testing (below). If the device is powered
  3. All OK.

Perform the Diagnostic Repair Verification after completing the repair.

Accessory Power Receptacle Replacement .

Scheme 245

Scheme 245: Accessory AC and DC Power Control Module Replacement
CalloutComponent Name
Preliminary Procedures Disconnect the battery negative cable. Refer to Battery Negative Cable Disconnection and Connection . Remove the front floor console. Refer to Front Floor Console Assembly Replacement .
1Accessory AC and DC Power Control Module Fastener (Qty: 3)
2Accessory AC and DC Power Control Module Procedure Disconnect the electrical connector. Transfer components as necessary. Program the accessory AC and DC power control module. Refer to Control Module References for programming and set up.

Accessory AC and DC Power Control Module Replacement

Scheme 246

Scheme 246: 120-Volt Accessory Power Receptacle Replacement
CalloutComponent Name
Preliminary Procedure Remove the front floor console side rear cover. Refer to Front Floor Console Side Rear Cover Replacement .
1Accessory Power Receptacle Assembly Procedure Push in the 4 tabs to release the accessory power receptacle from the rear console trim cover.

120-Volt Accessory Power Receptacle Replacement

110 Volt Power Outlet Receptacle Isolation Fault Protection

The accessory DC/AC power inverter module contains a ground fault circuit interrupter (GFCI). GFCI monitors the 110 V circuit for a short to vehicle chassis ground. If a 110 V AC short to ground is detected, the accessory DC/AC power inverter module will turn OFF. The module remains OFF, until the AC powered device is unplugged from the outlet, and then plugged into the outlet after a 3 s delay.

110 Volt Power Outlet Receptacle Overload Shutdown

The accessory DC/AC power inverter module will turn OFF if the current in the 110 V circuit is greater than 3.8 A for 1 s , or 2.5 A for 10 s . The module will turn ON again, when the AC powered device is unplugged from the outlet, and then plugged into the outlet after a 3 s delay.

110 Volt Power Outlet Receptacle Internal Shutdown

The accessory DC/AC power inverter module will turn OFF if the B+ supply voltage is greater than 16.5 V or less than 11 V. The module will also turn OFF if the device temperature is greater than 85°C (185°F). The module will turn ON again, after the shutdown condition is corrected, and the AC powered device is unplugged from the outlet, and then plugged into the outlet.
