Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Radiator Inlet Hose Bracket Fastener | 9 N.m | 80 lb in |
| Spring Tensioner Stop Fastener | 9 N.m | 80 lb in |
| Starter Generator Mounting Fasteners | 58 N.m | 41 lb ft |
| Starter Generator High Voltage Cable Fasteners | 9 N.m | 80 lb in |
| Starter Generator High Voltage Cable Cover Fasteners | 9 N.m | 80 lb in |
Fastener Tightening Specifications
Scheme 212
Scheme 213
Scheme 214
| Callout | Component Name |
|---|---|
| 1 | Drive Belt Tensioner Assembly |
| 2 | Drive Belt Tensioner Bolt |
| 3 | Drive Belt Tensioner Stop Bolt |
| 4 | Tensioner Stop |
| 5 | Generator and A/C Compressor Bracket |
| 6 | Starter Generator Nut - Production |
| 7 | Starter Generator Bolt - Service |
| 8 | Starter Generator Stud - Production |
| 9 | Drive Motor Generator Battery Cable Cover Nuts |
| 10 | Drive Motor Generator Battery Cable Cover |
| 11 | Drive Motor Generator Battery Cable |
| 12 | Starter Generator Stud - Long |
| 13 | Starter Generator Stud - Short |
| 14 | Starter Generator |
| 15 | Starter Generator Bolt |
| 16 | A/C Compressor Bolts |
| 17 | A/C Compressor Bolt - Service |
| 18 | A/C Compressor Stud - Production |
| 19 | A/C Compressor Nut - Production |
| 20 | A/C Compressor |
| 21 | Generator and A/C Compressor Belt |
Torque Smoothing
While not unique to the eAssist hybrid vehicle, expanded operational range is possible because the drive motor can react quickly to smooth driveline disturbances that would otherwise be objectionable.
