Hybrid/ev Cooling System: Specifications Buick LaCrosse II facelift

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Accessory DC Power Control Module Cooling Air Duct Fasteners	1.5 N.m	13 lb in
Air Conditioning and Drive Motor Cooling Compressor Bolt	22 N.m	16 lb ft
Air Conditioning and Drive Motor Cooling Compressor Nut	22 N.m	16 lb ft
Air Conditioning Compressor and Condenser Hose Bolt	22 N.m	16 lb ft
Air Conditioning Compressor and Condenser Hose Nut	17 N.m	12 lb ft
Air Conditioning Compressor Front Hose Bracket Bolt	17 N.m	12 lb ft
Air Conditioning Compressor Front Hose Bolt	22 N.m	16 lb ft
Air Conditioning Compressor Front Hose Nut	22 N.m	16 lb ft
Air Conditioning Compressor and Evaporator Hose Nut	17 N.m	12 lb ft
Air Conditioning Refrigerant Pressure Sensor	6 N.m	53 lb in
Air Conditioning Thermal Expansion Valve Bolt	7 N.m	62 lb in
Air Distribution Case Screw	3 N.m	27 lb in
Air Inlet Fastener	2.5 N.m	23 lb in
Air Inlet Housing Fastener	2.5 N.m	23 lb in
Air Inlet Valve Actuator Gear Screw	1.5 N.m	13 lb in
Blower Motor Control Module Screw	2 N.m	17 lb in
Bracket Heater Core Inlet Tube Bolt	2.5 N.m	23 lb in
Bracket Heater Core Outlet Tube Bolt	2.5 N.m	23 lb in
Drive Motor Battery Cooling Blower Motor Bracket Fastener	9 N.m	80 lb in
Heater Inlet and Outlet Pipe Bolt	17 N.m	12 lb ft
Heater Coolant Heater	9 N.m	80 lb in
Heater Water Shutoff Valve Nuts	9 N.m	80 lb in
HVAC Module Assembly Fastener	10 N.m	89 lb in
Instrument Panel Center Air Outlet Duct Fasteners	1.5 N.m	13 lb in
Mode Actuator Screw	1.5 N.m	13 lb in
Side Window Defogger Outlet Duct Fasteners	1.5 N.m	13 lb in

Fastener Tightening Specifications

Scheme 218: Starter/Generator (LUK)

Scheme 219: Battery Pack (LUK)
