Engine Mechanical - 3.6l (ly7) (Repair Instructions - 1 of 5) Buick LaCrosse I

Mechanical 1 illustration ~9647 words

Removal Procedure

  1. Raise the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/lacrosse/i-2004-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
  2. Remove the right engine splash shield. Refer to «Splash Shield Replacement - Engine»(/buick/lacrosse/i-2004-2009/remont/exterior-body-panels/#body-front-end) in Body Front End.
  3. Rotate the drive belt tensioner clockwise to release the drive belt tension.
  4. Remove the drive belt from the generator.
  5. Slowly release the drive belt tensioner.
  6. Remove the drive belt from the accessory drive pulleys.

Installation Procedure

  1. Install the right engine splash shield. Refer to «Splash Shield Replacement - Engine»(/buick/lacrosse/i-2004-2009/remont/exterior-body-panels/#body-front-end) in Body Front End.
  2. Lower the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/lacrosse/i-2004-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
  3. Install the drive belt to the accessory drive pulley.
  4. Rotate the drive belt tensioner clockwise.
  5. Install the drive belt to the generator.
  6. Slowly release the drive belt tensioner.
  1. Remove the drive belt. Refer to «Drive Belt Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the idler pulley. Refer to «Drive Belt Idler Pulley Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the drive belt tensioner bolts.
  4. Remove the drive belt tensioner from the engine.
  1. Position the drive belt tensioner to the engine.
  2. Install the drive belt tensioner bolts. Tighten: Tighten the drive belt tensioner center bolts to 50 N.m (37 lb ft). Tighten the drive belt tensioner outer bolts to 23 N.m (17 lb ft).
  3. Install the idler pulley. Refer to «Drive Belt Idler Pulley Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  4. Install the drive belt. Refer to «Drive Belt Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the drive belt from the generator. Refer to «Drive Belt Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the drive belt idler pulley bolt.
  3. Remove the drive belt idler pulley.
  1. Install the drive belt idler pulley.
  2. Install the drive belt idler pulley bolt. Tighten: Tighten the drive belt idler pulley bolt to 50 N.m (37 lb ft).
  3. Install the drive belt. Refer to «Drive Belt Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .

Tools Required

  1. J 28467-34 Lift Hook Wing Nut and Washer (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  2. J 28467-6A Bracket Assembly (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  3. J 28467-7A Bolt Hook (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  4. J 28467-500 Engine Support Fixture Adapters. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  5. J 28467-501 Engine Support Fixture Adapters. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  6. J 28467-B Universal Engine Support Fixture. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  7. J 28467-2A Radiator Tube Shelf Assembly
  8. J 28467-3 Tube Assembly
  9. J 28467-4A Front Support Assembly
  10. J 28467-9 Quick Release Pin
  11. J 28467-1A Cross Bracket
  12. J 28467-34 Handle
  13. J 45057-2 Lower Support Bar. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  1. Remove the fuel injector sight shield.
  2. Remove the engine mount struts. Refer to «Engine Mount Strut Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) and «Engine Mount Strut Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. One engine mount strut and nut can be reinstalled to the engine mount strut bracket on engine to be used as an attachment point for front engine attachment.
  4. Disconnect the electrical harness clip at the UHJB and at coolant housing.
  5. Disconnect the electrical connector at the engine control module (ECM).
  6. Remove the coolant recovery reservoir. Refer to «Coolant Recovery Reservoir Replacement»(/buick/lacrosse/i-2004-2009/remont/cooling-system-mechanical/#engine-cooling-system) in Engine Cooling.
  7. Remove the power steering reservoir and bracket.
  8. Remove the attachment screw from the power steering pump reservoir to bracket.
  9. Install the power steering reservoir bracket to powertrain. NOTE: Refer to «Fastener Notice»(/buick/lacrosse/i-2004-2009/remont/oem-general-information/#cautions-and-notices__fastener-notice) . Tighten: Tighten the power steering reservoir bracket bolts: M6 bolt to 9 N.m (7 lb ft) and M8 bolt to M8 Bolt to 25 N.m (18 lb ft)
  10. Install a J 28467-B and retention pin to each end of the J 28467-500 beam (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  11. Position the J 28467-B to the left and right side inner fender rails in order to install the J 28467-500 . See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  12. Install the radiator shelf tube J 28467-2A (2) on top of the strut tower tube J 28467-3 (1) above the engine front (right bank) lift bracket.
  13. Install the round tube of the front support assembly J 28467-4A through the large hole in the radiator shelf tube J 28467-2A.
  14. Locate the J 28467-4A front support assembly to the upper tie bar.
  15. Install the J 28467-9 7/16 in x 2.0 in quick-release pin through the top hole in the J 28467-4A front support assembly.
  16. Install the J 28467-1A cross bracket assembly.
  17. Assemble the following to create 2 lift hook assemblies as shown: J 28467-34 . See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) . J 28467-6A . See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) . J 28467-7A . See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  18. Install the 2 lift hook assemblies (1) to the J 45057-2 (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  19. Install the LH engine mount strut nuts and bolts to the strut brackets.
  20. Install the RH engine lift hook through the power steering reservoir bracket.
  21. Gently tighten the J 28467-34 lift hook wing nuts to support powertrain. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  1. Remove the complete engine support fixture assembly.
  2. Remove the power steering reservoir bracket.
  3. Attach the power steering reservoir to bracket and install the screws. Tighten: Tighten the power steering reservoir screws to bracket to 6 N.m (53 lb in).
  4. Install the power steering reservoir and bracket assembly. Tighten: Tighten the power steering reservoir bracket bolts: M6 bolt to 9 N.m (7 lb ft) and M8 bolt to M8 Bolt to 25 N.m (18 lb ft)
  5. Install the engine mount struts. Refer to «Engine Mount Strut Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) and «Engine Mount Strut Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .

Engine Mount Inspection

Note. In order to avoid oil pan damage and possible engine failure, insert a block of wood that spans the width of the oil pan bottom between the oil pan and the jack support.

  1. Raise the engine in order to remove the weight from the engine mount and create slight tension in the rubber.
  2. Observe the engine mount while raising the engine. Replace the engine mount if the engine mount exhibits any of the following conditions: The hard rubber surface is covered with heat check cracks. The rubber is separated from the metal plate of the engine mount. The rubber is split through the center of the engine mount.
  3. If there is movement between the metal plate of the engine mount and its attaching points, lower the engine on the engine mount. Tighten the bolts or nuts attaching the engine mount to the frame or engine mount bracket. Refer to «Engine Mount Bracket Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  4. For information on the transaxle mount, refer to «Transmission Mount Inspection»(/buick/lacrosse/i-2004-2009/remont/automatic-trans/#automatic-transaxle-4t65-e-introduction-2-of-2__transmission-mount-inspection) in Automatic Transaxle - 4T65-E.
  1. Disconnect the battery ground (negative) cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  2. Remove the throttle body air inlet duct. Refer to «Air Cleaner Intake Duct Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L.
  3. Remove the engine mount struts. Refer to «Engine Mount Strut Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) or «Engine Mount Strut Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  4. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/lacrosse/i-2004-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) in General Information.
  5. Remove the three-way catalytic converter pipe from the engine right side exhaust manifold. Refer to «Catalytic Converter Replacement»(/buick/lacrosse/i-2004-2009/remont/exhaust/#engine-exhaust-system) in Engine Exhaust.
  6. Remove the right front wheel and tire. Refer to «Tire and Wheel Removal and Installation»(/buick/lacrosse/i-2004-2009/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
  7. Remove the right engine splash shield. Refer to «Splash Shield Replacement - Engine»(/buick/lacrosse/i-2004-2009/remont/exterior-body-panels/#body-front-end) in Body Front End.
  8. Remove the engine mount lower nuts.
  9. Use a utility stand and a block of wood in order to raise the engine.
  10. Remove the engine mount bracket-to-oil pan bolts (2).
  11. Remove the engine mount bracket-to engine bolts (1).
  12. Remove the engine mount and the engine mount bracket.
  13. Remove the engine mount upper nuts.
  14. Remove the engine mount from the engine mount bracket.
  1. Install the engine mount to the engine mount bracket.
  2. Install the engine mount upper nuts. Tighten: Tighten the engine mount upper nuts to 53 N.m (39 lb ft).
  3. Install the engine mount bracket with the engine mount to the oil pan.
  4. Install all the engine mount bracket bolts. Hand tighten only.
  5. Install the engine mount bracket bolt. Tighten: Tighten the bolts to 58 N.m (43 lb ft).
  6. Use the utility stand in order to lower the engine.
  7. Install the engine mount lower nuts. Tighten: Tighten the engine mount lower nuts to 47 N.m (35 lb ft).
  8. Install the right engine splash shield. Refer to «Splash Shield Replacement - Engine»(/buick/lacrosse/i-2004-2009/remont/exterior-body-panels/#body-front-end) in Body Front End.
  9. Install the right front wheel and tire. Refer to «Tire and Wheel Removal and Installation»(/buick/lacrosse/i-2004-2009/remont/wheel-tire-system/#tires-and-wheels) in Tires and Wheels.
  10. Connect the three-way catalytic converter pipe to the engine right side exhaust manifold. Refer to «Catalytic Converter Replacement»(/buick/lacrosse/i-2004-2009/remont/exhaust/#engine-exhaust-system) in Engine Exhaust.
  11. Lower the vehicle.
  12. Install the engine mount struts. Refer to «Engine Mount Strut Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) and «Engine Mount Strut Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  13. Install the throttle body air inlet duct. Refer to «Air Cleaner Intake Duct Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L.
  14. Connect the battery ground (negative) cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  1. Remove the engine mount. Refer to «Engine Mount Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the engine mount upper nuts.
  3. Remove the engine mount bracket from the engine mount.
  1. Install the engine mount bracket to the engine mount.
  2. Install the engine mount upper nuts. Tighten: Tighten the engine mount upper nuts to 53 N.m (39 lb ft).
  3. Install the engine mount. Refer to «Engine Mount Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the bolt and the nut from the engine mount strut at the left engine mount strut bracket on the engine.
  2. Remove the bolt and the nut from the engine mount strut at the engine mount strut bracket on the upper radiator support.
  3. Remove the engine mount strut.
  4. Inspect the rubber in the engine mount strut for the following conditions: Hardness Splitting Cracking
  1. Install the engine mount strut.
  2. Install the bolt and the nut to the engine mount strut at the engine mount strut bracket on the upper radiator support. HAND TIGHTEN ONLY.
  3. Install the bolt and the nut to the engine mount strut at the left engine mount strut bracket on the engine. Tighten: Tighten bolt engine mount strut nuts to 48 N.m (35 lb ft).
  1. Remove the bolt and the nut from the engine mount strut at the right engine mount strut bracket on the engine.
  2. Remove the bolt and the nut from the engine mount strut at the engine mount strut bracket on the upper radiator support.
  3. Remove the engine mount strut.
  4. Inspect the rubber in the engine mount strut for the following conditions: Hardness Splitting Cracking
  1. Install the engine mount strut.
  2. Install the bolt and the nut to the engine mount strut at the engine mount strut bracket on the upper radiator support. HAND TIGHTEN ONLY.
  3. Install the bolt and the nut to the engine mount strut at the right engine mount strut bracket on the engine. Tighten: Tighten both engine mount strut nuts to 48 N.m (35 lb ft).
  1. Remove the left engine mount strut from the left engine mount strut bracket. Refer to «Engine Mount Strut Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Disconnect the positive crankcase ventilation (PCV) tube from the air intake duct.
  3. Remove the exhaust crossover pipe nuts (5) and studs (1).
  4. Disconnect the engine mount strut bracket bolts from the cylinder head.
  5. Remove the left engine mount strut bracket and bolts from the vehicle.
  1. Install the left engine mount strut bracket and bolts to the vehicle.
  2. Connect the engine mount strut bracket bolts to the cylinder head. Tighten: Tighten the engine mount strut bracket bolts to 50 N.m (37 lb ft).
  3. Install the exhaust crossover pipe nuts (5) and studs (1). Tighten: Tighten the exhaust crossover pipe nuts (5) to 34 N.m (25 lb ft).
  4. Connect the PCV tube to the air intake duct.
  5. Install the left engine mount strut to the left engine mount strut bracket. Refer to «Engine Mount Strut Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  2. Disconnect the pulley from the generator.
  3. Remove the right engine mount strut and radiator support bracket from the right engine mount strut bracket. Refer to «Engine Mount Strut Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  4. Remove the generator bolts from the generator.
  5. Move the generator off to the side to provide access to the engine mount strut bracket bolts.
  6. Remove the engine mount strut bracket bolts from the cylinder head.
  7. Remove the right engine mount strut bracket from the vehicle.
  1. Install the right engine mount strut bracket to the vehicle.
  2. Connect the engine mount strut bracket bolts to the cylinder head. Tighten: Tighten the engine mount strut bracket bolts to 50 N.m (37 lb ft).
  3. Install the generator into the proper position.
  4. Install the generator bolts. Tighten: Tighten the generator bolts to 50 N.m (37 lb ft).
  5. Install the right engine mount strut and radiator support bracket to the right engine mount strut bracket. Refer to «Engine Mount Strut Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  6. Connect the pulley to the generator.
  7. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.

Scheme 34

Scheme 34: Fuel Injector Sight Shield Replacement
Scheme 34: Fuel Injector Sight Shield Replacement
CalloutComponent Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .
1Cap, Oil Filler Tip: Clean the area around the oil fill cap before removing.
2Shield, Fuel Injection Sight

Fuel Injector Sight Shield Replacement

  1. Remove the positive crankcase ventilation (PCV) fresh air tube from the left camshaft cover.
  2. Remove the PCV fresh air tube from the air inlet duct.
  3. Remove the PCV dirty air tube from the right camshaft cover.
  4. Remove the PCV dirty air tube from the intake manifold.
  1. Install the PCV dirty air tube to the intake manifold.
  2. Install the PCV dirty air tube to the right camshaft cover.
  3. Install the PCV fresh air tube to the air inlet duct.
  4. Install the PCV fresh air tube to the left camshaft cover.
  1. Turn the ignition OFF.
  2. Remove the air inlet duct. Refer to «Air Cleaner Intake Duct Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  3. Relieve the fuel system pressure. Refer to «Fuel Pressure Relief Procedure»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  4. Remove the fuel pressure and evaporative emission (EVAP) hoses from the engine. Refer to «Quick Connect Fitting(s) Service (Metal Collar)»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) and «Quick Connect Fitting(s) Service (Plastic Collar)»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  5. Remove the purge line from the purge line retainer.
  6. Remove the fuel feed hose bracket bolt and reposition the fuel feed hose.
  7. Remove the ECM bracket with the ECM and reposition aside. Refer to «Engine Control Module (ECM) Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  8. Disconnect the purge solenoid electrical connector.
  9. Remove the wiring harness from the right side of the intake manifold.
  10. Disconnect the fuel injector electrical connector.
  11. Remove the fuel injector electrical connector from the fuel injector electrical connector bracket.
  12. Remove the throttle body electrical connector.
  13. Remove the brake booster vacuum hose and check valve from the brake booster.
  14. Remove the electrical connector for the baro sensor.
  15. Remove the positive crankcase ventilation (PCV) hose from the intake manifold.
  16. Remove the intake manifold bolts (1-6).
  17. Remove the upper intake manifold.
  18. Remove and discard the upper intake manifold gasket.
  19. Disassemble the intake manifold if necessary. Refer to «Intake Manifold Disassemble»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  20. Clean and inspect the intake manifold and the sealing surfaces. Refer to «Intake Manifold Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  1. Assemble the intake manifold if necessary. Refer to «Intake Manifold Assemble»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  2. Install the intake manifold.
  3. Install the intake manifold bolts (1-6). Tighten: Tighten the intake manifold bolts in the order shown to 23 N.m (17 lb ft).
  4. Install the PCV hose to the intake manifold.
  5. Install the brake booster vacuum hose and check valve to the brake booster.
  6. Install the throttle body electrical connector.
  7. Reconnect the electrical connector for the baro sensor.
  8. Install the fuel injector electrical connector to the fuel injector electrical connector bracket.
  9. Connect the fuel injector electrical connector.
  10. Install the wiring harness and bracket to the right side of the intake manifold. Tighten: Tighten the wiring harness bracket bolts to 10 N.m (89 lb in).
  11. Connect the purge solenoid electrical connector.
  12. Install the ECM bracket with the ECM. Refer to «Engine Control Module (ECM) Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  13. Install the fuel feed hose bracket and the fuel feed hose bracket bolt. Tighten: Tighten the fuel feed hose bracket bolt to 10 N.m (89 lb in).
  14. Install the purge line to the purge line retainer.
  15. Install the fuel pressure and EVAP hoses to the engine. Refer to «Quick Connect Fitting(s) Service (Metal Collar)»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) and «Quick Connect Fitting(s) Service (Plastic Collar)»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  16. Install the air inlet duct. Refer to «Air Cleaner Intake Duct Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  1. Turn the ignition OFF.
  2. Remove the air inlet duct. Refer to «Air Cleaner Intake Duct Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  3. Remove the fuel pressure and evaporative emission (EVAP) hoses from the engine. Refer to «Quick Connect Fitting(s) Service (Metal Collar)»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) and «Quick Connect Fitting(s) Service (Plastic Collar)»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  4. Disconnect the BARO sensor electrical connector.
  5. Remove the ECM bracket with the ECM and reposition aside. Refer to «Engine Control Module (ECM) Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  6. Disconnect the purge solenoid electrical connector.
  7. Disconnect the purge solenoid electrical connector.
  8. Remove the wiring harness from the right side of the intake manifold.
  9. Disconnect the fuel injector electrical connector.
  10. Remove the throttle body electrical connector.
  11. Remove the brake booster vacuum hose and check valve from the brake booster.
  12. Remove the positive crankcase ventilation (PCV) hose from the intake manifold.
  13. Remove the intake manifold bolts (1-6).
  14. Remove the intake manifold.
  15. Disassemble the intake manifold as necessary. Refer to «Intake Manifold Disassemble»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  16. Clean and inspect the intake manifold and the sealing surfaces. Refer to «Intake Manifold Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  1. Assemble the intake manifold as necessary. Refer to «Intake Manifold Assemble»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  2. Install the intake manifold. Refer to «INTAKE MANIFOLD INSTALLATION»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__intake-manifold-installation) .
  3. Install the PCV hose to the intake manifold.
  4. Install the brake booster vacuum hose and check valve to the brake booster.
  5. Install the throttle body electrical connector.
  6. Connect the fuel injector electrical connector.
  7. Install the wiring harness to the right side of the intake manifold. Tighten: Tighten the wiring harness bracket bolts to 10 N.m (89 lb in).
  8. Connect the purge solenoid electrical connector.
  9. Install the ECM bracket with the ECM. Refer to «Engine Control Module (ECM) Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  10. Connect the BARO sensor electrical connector.
  11. Install the fuel pressure and EVAP hoses to the engine. Refer to «Quick Connect Fitting(s) Service (Metal Collar)»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) and «Quick Connect Fitting(s) Service (Plastic Collar)»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  12. Install the air inlet duct. Refer to «Air Cleaner Intake Duct Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  1. Turn the ignition OFF.
  2. Remove the oil level indicator from the oil level indicator tube.
  3. Remove the oil level indicator tube bolt.
  4. Remove the oil level indicator tube up through the exhaust manifold.
  5. If you are replacing only the oil level indicator tube seal, remove and discard the old seal.
  1. Install the oil level indicator and tube. Refer to «OIL LEVEL INDICATOR AND TUBE INSTALLATION»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__oil-level-indicator-and-tube-installation) .
  2. Lower the vehicle.
  1. Turn the ignition OFF.
  2. Remove the generator. Refer to «Generator Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  3. Remove the oil filter. Refer to «Engine Oil and Oil Filter Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  4. Remove the oil filter adapter. Refer to «Oil Filter Adapter Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__oil-filter-adapter-removal) .
  5. Disassemble the oil filter adapter as necessary. Refer to «Oil Filter Adapter Disassemble»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5__oil-filter-adapter-disassemble) .
  6. Clean and inspect the oil filter adapter and sealing surfaces as necessary. Refer to «Oil Filter Adapter Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  1. Install the oil filter adapter. Refer to «OIL FILTER ADAPTER INSTALLATION»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__oil-filter-adapter-installation) .
  2. Install the oil filter. Refer to «Engine Oil and Oil Filter Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  3. Install the generator. Refer to «Generator Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.

J 41816-A Harmonic Balancer Puller. See Special Tools .

  1. Remove the accessory drive belt. Refer to «Drive Belt Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/lacrosse/i-2004-2009/remont/hoistjack/#general-information__lifting-and-jacking-the-vehicle) .
  3. Use the J 41816-A in order to remove the crankshaft balancer. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) . Refer to «Crankshaft Balancer Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  1. Install the crankshaft balancer. Refer to «CRANKSHAFT BALANCER INSTALLATION»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  2. Install the accessory drive belt. Refer to «Drive Belt Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Lower the vehicle.
  1. J 29184 Oil Seal Installer. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  2. J 45000 Seal Remover. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  1. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Use J 45000 in order to remove the crankshaft oil seal. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  1. Use the J 29184 or equivalent to install the crankshaft front oil seal. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  2. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the upper intake manifold with the lower intake manifold. Refer to «Intake Manifold Replacement - Lower»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Disconnect the ignition coil electrical connectors.
  3. Remove the wiring harness from the side of the camshaft cover by sliding the conduit down and outboard.
  4. Remove the wiring conduit retainers from the camshaft cover by rotating the wiring harness conduit retainers counterclockwise.
  5. Remove the wiring harness from the front of the camshaft cover.
  6. Reposition and secure the wiring harnesses away from the camshaft cover in order to provide clearance.
  7. Remove the ignition coils.
  8. Loosen the left engine strut bracket.
  9. Loosen the left engine strut bracket-to-cylinder head bolts.
  10. Remove the camshaft cover bolts and camshaft cover.
  11. Remove and discard the camshaft cover seal and grommets. DO NOT reuse.
  1. Install a NEW camshaft cover seal and NEW grommets.
  2. Install the camshaft cover. Refer to «CAMSHAFT COVER INSTALLATION - LEFT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  3. Tighten the left engine strut bracket-to-cylinder head bolts. Tighten: Tighten the left engine strut bracket-to-cylinder head bolts to 50 N.m (37 lb ft).
  4. Install the ignition coils.
  5. Install the wiring harness to the front of the camshaft cover.
  6. Install the wiring harness conduit retainers to the wiring harness conduit.
  7. Install the wiring harness to the side of the camshaft cover.
  8. Connect the ignition coil electrical connectors.
  9. Install the upper intake manifold with the lower intake manifold. Refer to «Intake Manifold Replacement - Lower»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the upper intake manifold with the lower intake manifold. Refer to «Intake Manifold Replacement - Lower»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Disconnect the ignition coil electrical connectors.
  3. Remove the wiring harness from the side of the camshaft cover by sliding the conduit down and outboard.
  4. Remove the wiring conduit retainers from the camshaft cover by rotating the wiring harness conduit retainers counterclockwise.
  5. Remove the wiring harness from the front of the camshaft cover.
  6. Reposition and secure the wiring harnesses away from the camshaft cover in order to provide clearance.
  7. Remove the ignition coils.
  8. Remove the camshaft cover.
  9. Remove and discard the camshaft cover seal and grommets.
  1. Install a NEW camshaft cover seal and NEW grommets.
  2. Install the camshaft cover. Refer to «CAMSHAFT COVER INSTALLATION - RIGHT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  3. Install the ignition coils.
  4. Install the wiring harness to the front of the camshaft cover.
  5. Install the wiring harness conduit retainers to the wiring harness conduit.
  6. Install the wiring harness to the side of the camshaft cover.
  7. Connect the ignition coil electrical connectors.
  8. Install the upper intake manifold with the lower intake manifold. Refer to «Intake Manifold Replacement - Lower»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Disconnect the negative battery cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) .
  2. Remove the ECU module. Refer to «Engine Control Module (ECM) Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) .
  3. Remove the generator assembly. Refer to «Generator Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) .
  4. Remove the coolant overflow reservoir. Refer to «Coolant Recovery Reservoir Replacement»(/buick/lacrosse/i-2004-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
  5. Remove the power steering reservoir. Refer to «Remote Power Steering Fluid Reservoir Replacement»(/buick/lacrosse/i-2004-2009/remont/manual-power-steering/#power-steering-system) .
  6. Remove the camshaft covers. For the left camshaft cover, refer to «Valve Rocker Arm Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) . For the right camshaft cover, refer to «Valve Rocker Arm Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  7. Remove the upper radiator hose. Refer to «Radiator Hose Replacement - Inlet (3.6L)»(/buick/lacrosse/i-2004-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
  8. Remove the water pump. Refer to «Water Pump Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
  9. Remove the engine splash shield. Refer to «Splash Shield Replacement - Engine»(/buick/lacrosse/i-2004-2009/remont/exterior-body-panels/#body-front-end) .
  10. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  11. Remove the drive belt tensioner. Refer to «Drive Belt Tensioner Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  12. Remove the engine front cover from the engine block. Refer to «Engine Front Cover Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  1. Install the engine front cover. Refer to «Engine Front Cover Assemble»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  2. Install the water pump. Refer to «Water Pump Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
  3. Install the camshaft covers. For the left camshaft cover, refer to «Valve Rocker Arm Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) . For the right camshaft cover, refer to «Valve Rocker Arm Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  4. Install the drive belt tensioner. Refer to «Drive Belt Tensioner Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  5. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  6. Install the coolant overflow reservoir. Refer to «Coolant Recovery Reservoir Replacement»(/buick/lacrosse/i-2004-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
  7. Install the power steering reservoir. Refer to «Remote Power Steering Fluid Reservoir Replacement»(/buick/lacrosse/i-2004-2009/remont/manual-power-steering/#power-steering-system) .
  8. Install the upper radiator hose. Refer to «Radiator Hose Replacement - Inlet (3.6L)»(/buick/lacrosse/i-2004-2009/remont/cooling-system-mechanical/#engine-cooling-system) .
  9. Install the generator assembly. Refer to «Generator Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) .
  10. Install engine splash shield. Refer to «Splash Shield Replacement - Engine»(/buick/lacrosse/i-2004-2009/remont/exterior-body-panels/#body-front-end) .
  11. Install the ECU module. Refer to «Engine Control Module (ECM) Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) .
  12. Connect the negative battery cable. Refer to «Battery Negative Cable Disconnect/Connect Procedure (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) .
  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) .
  4. Remove the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-shoe-removal) .
  5. Remove the right bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-guide-removal) .
  6. Remove the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Drive Chain Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  7. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioners Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__primary-camshaft-drive-chain-tensioner-removal) .
  8. Remove the primary upper camshaft drive chain guide. Refer to «Primary Camshaft Drive Chain Guide Removal - Upper»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__primary-camshaft-drive-chain-guide-removal) .
  9. Remove the primary camshaft drive chain. Refer to «Primary Camshaft Drive Chain Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  10. Remove the right bank camshaft intermediate drive chain idler. Refer to «Camshaft Intermediate Drive Chain Idler Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__camshaft-intermediate-drive-chain-idler-removal) .
  11. Remove the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) .
  12. Remove the left bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-shoe-removal) .
  13. Remove the left bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-guide-removal) .
  14. Remove the left bank camshaft intermediate drive chain idler. Refer to «Camshaft Intermediate Drive Chain Idler Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__camshaft-intermediate-drive-chain-idler-removal) .
  15. Remove the left bank secondary camshaft drive chain. Refer to «Secondary Camshaft Drive Chain Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  16. Clean and inspect all of the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) . Replace components as necessary.
  1. Install the left bank secondary camshaft drive chain. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN TENSIONER INSTALLATION - LEFT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  2. Install the left bank camshaft intermediate drive chain idler. Refer to «CAMSHAFT INTERMEDIATE DRIVE CHAIN IDLER INSTALLATION - LEFT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__camshaft-intermediate-drive-chain-idler-installation) .
  3. Install the left bank secondary camshaft drive chain guide. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN GUIDE INSTALLATION - LEFT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-guide-installation) .
  4. Install the left bank secondary camshaft drive chain shoe. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN SHOE INSTALLATION - LEFT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-shoe-installation) .
  5. Install the left bank secondary camshaft drive chain tensioner. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN TENSIONER INSTION - LEFT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  6. Install the right bank camshaft intermediate drive chain idler. Refer to «Camshaft Intermediate Drive Chain Idler Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__camshaft-intermediate-drive-chain-idler-installation) .
  7. Install the primary camshaft drive chain. Refer to «Primary Camshaft Drive Chain Installation»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__primary-camshaft-drive-chain-installation) .
  8. Install the primary upper camshaft drive chain guide. Refer to «Primary Camshaft Drive Chain Guide Installation - Upper»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__primary-camshaft-drive-chain-guide-installation) .
  9. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioners Installation»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  10. Install the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Drive Chain Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-installation) .
  11. Install the right bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-guide-installation) .
  12. Install the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-shoe-installation) .
  13. Install the right bank secondary camshaft drive chain tensioner. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN TENSIONER INSTALLATION - RIGHT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5)
  14. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  15. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) .
  4. Remove the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-shoe-removal) .
  5. Remove the right bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-guide-removal) .
  6. Remove the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Drive Chain Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  1. Install the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Drive Chain Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-installation) .
  2. Install the right bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-guide-installation) .
  3. Install the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-shoe-installation) .
  4. Install the right bank secondary camshaft drive chain tensioner. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN TENSIONER INSTALLATION - RIGHT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  5. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  6. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) .
  1. Install the left bank secondary camshaft drive chain tensioner. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN TENSIONER INSTALLATION - LEFT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  2. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  3. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) .
  1. Install the right bank secondary camshaft drive chain tensioner. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN TENSIONER INSTALLATION - RIGHT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  2. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  3. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) .
  1. Install the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  2. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  3. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) .
  4. Remove the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-shoe-removal) .
  1. Install the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-shoe-installation) .
  2. Install the right bank secondary camshaft drive chain tensioner. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN TENSIONER INSTALLATION - RIGHT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  3. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  4. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) .
  4. Remove the left bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-guide-removal) .
  1. Install the left bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-guide-installation) .
  2. Install the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  3. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  4. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) .
  4. Remove the right bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-guide-removal) .
  1. Install the right bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-guide-installation) .
  2. Install the right bank secondary camshaft drive chain tensioner. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN TENSIONER INSTALLATION - RIGHT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5)
  3. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  4. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) .
  4. Remove the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-shoe-removal) .
  5. Remove the right bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-guide-removal) .
  6. Remove the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Drive Chain Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  7. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioners Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__primary-camshaft-drive-chain-tensioner-removal) .
  8. Remove the primary camshaft drive chain upper guide. «Primary Camshaft Drive Chain Guide Removal - Upper»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__primary-camshaft-drive-chain-guide-removal) .
  9. Remove the primary camshaft timing chain. Refer to «Secondary Camshaft Drive Chain Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  1. Install the primary camshaft timing chain. Refer to «Primary Camshaft Drive Chain Installation»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__primary-camshaft-drive-chain-installation) .
  2. Install the primary upper camshaft drive chain guide. Refer to «Primary Camshaft Drive Chain Guide Installation - Upper»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__primary-camshaft-drive-chain-guide-installation) .
  3. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioners Installation»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  4. Install the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Drive Chain Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-installation) .
  5. Install the right bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-guide-installation) .
  6. Install the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-shoe-installation) .
  7. Install the right bank secondary camshaft drive chain tensioner. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN TENSIONER INSTALLATION - RIGHT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  8. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  9. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) .
  4. Remove the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-shoe-removal) .
  5. Remove the right bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-guide-removal) .
  6. Remove the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Drive Chain Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  7. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioners Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__primary-camshaft-drive-chain-tensioner-removal) .
  8. Remove the primary upper camshaft drive chain guide. Refer to «Primary Camshaft Drive Chain Guide Removal - Upper»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__primary-camshaft-drive-chain-guide-removal) .
  9. Remove the primary camshaft drive chain. Refer to «Primary Camshaft Drive Chain Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  10. Remove the right bank camshaft intermediate drive chain idler. Refer to «Camshaft Intermediate Drive Chain Idler Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__camshaft-intermediate-drive-chain-idler-removal) .
  11. If you are servicing the left bank camshaft intermediate drive chain idler, perform the following steps: Remove the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-tensioner-removal) . Remove the left bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-shoe-removal) . Remove the left bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__secondary-camshaft-drive-chain-guide-removal) . Remove the left bank secondary camshaft drive chain. Refer to «Secondary Camshaft Drive Chain Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) . Remove the left bank camshaft intermediate drive chain idler. Refer to «Camshaft Intermediate Drive Chain Idler Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__camshaft-intermediate-drive-chain-idler-removal) .
  1. If you are servicing the left bank idler sprocket, perform the following steps: Install the left bank camshaft intermediate drive chain idler. Refer to «Camshaft Intermediate Drive Chain Idler Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__camshaft-intermediate-drive-chain-idler-installation) . Install the left bank secondary camshaft drive chain. Refer to «Secondary Camshaft Drive Chain Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) . Install the left bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-guide-installation) . Install the left bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-shoe-installation) . Install the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Camshaft Drive Chain Tensioner Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  2. Install the right bank camshaft intermediate drive chain idler. Refer to «Camshaft Intermediate Drive Chain Idler Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__camshaft-intermediate-drive-chain-idler-installation) .
  3. Install the primary camshaft drive chain. Refer to «Primary Camshaft Drive Chain Installation»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__primary-camshaft-drive-chain-installation) .
  4. Install the primary upper camshaft drive chain guide. Refer to «Primary Camshaft Drive Chain Guide Installation - Upper»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__primary-camshaft-drive-chain-guide-installation) .
  5. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioners Installation»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  6. Install the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Drive Chain Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-installation) .
  7. Install the right bank secondary camshaft drive chain guide. Refer to «Secondary Camshaft Drive Chain Guide Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-guide-installation) .
  8. Install the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__secondary-camshaft-drive-chain-shoe-installation) .
  9. Install the right bank secondary camshaft drive chain tensioner. Refer to «SECONDARY CAMSHAFT DRIVE CHAIN TENSIONER INSTALLATION - RIGHT»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  10. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  11. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioner Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__primary-camshaft-drive-chain-tensioner-removal) .
  1. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioner Installation»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  2. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  3. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .

Primary Camshaft Drive Chain Guide Replacement - Lower

The primary camshaft drive chain guide is not serviceable separately. If the guide is worn or damaged, the guide must be replaced with the oil pump.

  1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioner Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__primary-camshaft-drive-chain-tensioner-removal) .
  4. Remove the primary upper camshaft drive chain guide. Refer to «Primary Camshaft Drive Chain Guide Removal - Upper»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5__primary-camshaft-drive-chain-guide-removal) .
  1. Install the primary upper camshaft drive chain guide. Refer to «Primary Camshaft Drive Chain Guide Installation - Upper»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__primary-camshaft-drive-chain-guide-installation) .
  2. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Drive Chain Tensioner Installation»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  3. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  4. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the camshaft. Refer to «Camshaft Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the camshaft position actuator from the timing chain.
  1. Install the camshaft position actuator to the timing chain.
  2. Install the applicable camshaft. Refer to «Camshaft Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the camshaft. Refer to «Camshaft Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the camshaft position actuator from the timing chain.
  1. Install the camshaft position actuator to the timing chain.
  2. Install the camshaft. Refer to «Camshaft Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the camshaft position actuator from the timing chain.
  2. Remove the camshaft. Refer to «Camshaft Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Install the camshaft position actuator to the timing chain.
  2. Install the camshaft. Refer to «Camshaft Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the camshaft. Refer to «Camshaft Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the camshaft position actuator from the timing chain.
  1. Install the camshaft position actuator to the timing chain.
  2. Install the camshaft. Refer to «Camshaft Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .

Setting Camshaft Timing

IMPORTANTSetting the camshaft timing is necessary whenever the camshaft drive system has been disturbed such that the relationship between any chain and sprocket has been lost. Even when only one sprocket is involved, multiple crankshaft rotations will not produce conditions where correct timing can be confirmed.

If necessary, follow the left bank secondary camshaft drive chain replacement procedures to reset the camshaft timing. Refer to Secondary Camshaft Drive Chain Replacement - Left .

  1. EN 46108 Timing Chain Retention Tool. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  2. EN 46111 Crankshaft Rotation Socket. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  1. Remove the upper intake manifold with the lower intake manifold. Refer to «Intake Manifold Replacement - Lower»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the left bank camshaft cover. Refer to «Camshaft Cover Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the camshaft sensors. Refer to «Camshaft Position (CMP) Sensor Replacement - Bank 2 (Left) Exhaust»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) and «Camshaft Position (CMP) Sensor Replacement - Bank 2 (Left) Intake»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  4. Remove the camshaft position actuator solenoid. Refer to «Camshaft Position (CMP) Actuator Solenoid Replacement - Bank 2 (Left) Intake»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  5. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  6. Rotate the crankshaft with the EN 46111 until the camshafts are in a neutral (low tension) position. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) . The camshaft flats will be parallel with the camshaft cover rail (1).
  7. Loosen the camshaft position actuator bolt.
  8. Install the EN 46108 (1 and 2) in order to retain the timing chain. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) . Firmly tighten the EN 46108 nuts. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  9. Mark the timing chain and the respective locations on the camshaft position actuators (1-4).
  10. Remove the camshaft position actuator bolt.
  11. Remove the camshafts. Refer to «Camshaft Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  1. Locate the camshafts to the cylinder head and assemble the camshaft actuators to the camshafts.
  2. Install the camshafts and the camshaft bearing caps. Refer to «Camshaft Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  3. Remove the EN 46108 . See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  4. Install and tighten the camshaft position actuators. Refer to «Camshaft Position (CMP) Actuator Installation - Left Intake»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__camshaft-position-cmp-actuator-installation) and «Camshaft Position (CMP) Actuator Installation - Left Exhaust»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__camshaft-position-cmp-actuator-installation) .
  5. Install the intake camshaft position actuator solenoid. Refer to «Camshaft Position (CMP) Actuator Solenoid Replacement - Bank 2 (Left) Intake»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  6. Install the camshaft sensors. Refer to «Camshaft Position (CMP) Sensor Replacement - Bank 2 (Left) Exhaust»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) and «Camshaft Position (CMP) Sensor Replacement - Bank 2 (Left) Intake»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  7. Install the crankshaft balancer. Refer to «Crankshaft Balancer Installation»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  8. Install the camshaft cover. Refer to «Camshaft Cover Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  9. Install the upper intake manifold with the lower intake manifold. Refer to «Intake Manifold Replacement - Lower»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. EN 46108 Timing Chain Retention Tool. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  2. EN 46111 Crankshaft Rotation Socket. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  1. Remove the upper intake manifold with the lower intake manifold. Refer to «Intake Manifold Replacement - Lower»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the camshaft cover. Refer to «Camshaft Cover Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the camshaft sensors. Refer to «Camshaft Position (CMP) Sensor Replacement - Bank 1 (Right) Exhaust»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) and «Camshaft Position (CMP) Sensor Replacement - Bank 1 (Right) Intake»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  4. Remove the intake camshaft position actuator solenoid. Refer to «Camshaft Position (CMP) Actuator Solenoid Replacement - Bank 1 (Right) Intake»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  5. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Removal»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-2-of-5) .
  6. Rotate the crankshaft with the EN 46111 until the camshafts are in a neutral (low tension) position. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) . The camshaft flats will be parallel with the camshaft cover rail (1).
  7. Loosen the camshaft position actuator bolt.
  8. Install the EN 46108 (1 and 2) in order to retain the timing chain. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) . Firmly tighten the EN 46108 nuts. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  9. Mark the timing chain and the respective locations on camshaft position actuators (15-18).
  10. Remove the camshaft position actuator bolt.
  11. Remove the camshaft bearing caps and the camshaft. Refer to «Camshaft Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  1. Locate the camshafts to the cylinder head and assemble the camshaft actuators to the camshafts.
  2. Install the camshafts and the camshaft bearing caps. Refer to «Camshaft Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  3. Remove the EN 46108 . See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  4. Install the crankshaft balancer. Refer to «Crankshaft Balancer Installation»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5) .
  5. Install and tighten the camshaft position actuators. Refer to «Camshaft Position (CMP) Actuator Installation - Right Intake»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__camshaft-position-cmp-actuator-installation) and «Camshaft Position (CMP) Actuator Installation - Right Exhaust»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__camshaft-position-cmp-actuator-installation) .
  6. Install the intake camshaft position actuator solenoid. Refer to «Camshaft Position (CMP) Actuator Solenoid Replacement - Bank 1 (Right) Intake»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  7. Install the camshaft sensors. Refer to «Camshaft Position (CMP) Sensor Replacement - Bank 1 (Right) Exhaust»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) and «Camshaft Position (CMP) Sensor Replacement - Bank 1 (Right) Intake»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  8. Install the camshaft cover. Refer to «Camshaft Cover Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  9. Install the upper intake manifold with the lower intake manifold. Refer to «Intake Manifold Replacement - Lower»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the applicable camshaft(s). Refer to «Camshaft Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the rocker arms. Refer to «Valve Rocker Arm Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  3. Clean and inspect the camshaft(s) and the rocker arm(s). Repair or replace as necessary. Refer to «Camshaft Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) and «Valve Lifters Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5__valve-lifters-cleaning-and-inspection) .
  1. Install the rocker arms. Refer to «Valve Rocker Arm Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__valve-rocker-arm-installation-left) .
  2. Install the applicable camshaft(s). Refer to «Camshaft Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the applicable camshaft(s). Refer to «Camshaft Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the rocker arms. Refer to «Valve Rocker Arm Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  3. Clean and inspect the camshaft(s) and the rocker arm(s). Repair or replace as necessary. Refer to «Camshaft Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) and «Valve Lifters Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5__valve-lifters-cleaning-and-inspection) .
  1. Install the rocker arms.
  2. Install the applicable camshaft(s). Refer to «Valve Rocker Arm Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__valve-rocker-arm-installation-right) .
  1. Remove the applicable camshaft(s). Refer to «Camshaft Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the rocker arms. Refer to «Valve Rocker Arm Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  3. Remove the lifters. Refer to «Valve Lifter Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  4. Clean and inspect the camshaft(s), rocker arm(s) and lifter(s). Repair or replace as necessary. Refer to «Camshaft Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) , «Valve Lifters Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5__valve-lifters-cleaning-and-inspection) and «Valve Lifters Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5__valve-lifters-cleaning-and-inspection) .
  1. Install the lifters. Refer to «Valve Lifter Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__valve-lifter-installation-left) .
  2. Install the rocker arms. Refer to «Valve Rocker Arm Installation - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__valve-rocker-arm-installation-left) .
  3. Install the applicable camshaft(s). Refer to «Camshaft Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the applicable camshaft(s). Refer to «Camshaft Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the rocker arms. Refer to «Valve Rocker Arm Removal - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  3. Remove the lifters. Refer to «Valve Lifter Removal - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) .
  4. Clean and inspect the camshaft(s) and the rocker arm(s). Repair or replace as necessary. Refer to «Camshaft Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5) and «Valve Lifters Cleaning and Inspection»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-3-of-5__valve-lifters-cleaning-and-inspection) .
  1. Install the lifters. Refer to «Valve Lifter Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__valve-lifter-installation-right) .
  2. Install the rocker arms. Refer to «Valve Rocker Arm Installation - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-4-of-5__valve-rocker-arm-installation-right) .
  3. Install the applicable camshaft(s). Refer to «Camshaft Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. EN 46106 Flywheel Holding Tool. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  2. EN 46110 On-Vehicle Valve Spring Compressor. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  3. EN 46116 Valve Stem Seal Remover/Installer. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  4. J 39313 Spark Plug Port Adapter. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  1. Remove the starter motor. Refer to «Starter Motor Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  2. Install the EN 46106 in order to prevent crankshaft rotation. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  3. Remove the camshafts and rocker arms. Refer to «Camshaft Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  4. Remove the spark plug from the applicable cylinder. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  5. Install the J 39313 to the applicable cylinder. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  6. Connect the J 39313 to a compressed air source. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  7. Install the EN 46110 above the applicable cylinder as shown. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  8. Tighten the EN 46110 valve spring compressor nut (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  9. Remove the valve keepers.
  10. Loosen the EN 46110 valve spring compressor nut. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  11. Remove the valve spring retainer.
  12. Remove the valve spring.
  13. Use the EN 46116 (1) in order to remove the valve stem seal (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  1. Use the EN 46116 (1) in order to install the valve stem seal (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  2. Install the valve spring.
  3. Install the valve spring retainer.
  4. Install the EN 46110 above the applicable valve spring as shown. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) . Tighten the EN 46110 valve spring compressor nut (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  5. Install the valve spring keepers.
  6. Remove the EN 46110 . See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  7. Disconnect the J 39313 from the compressed air source. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  8. Remove the J 39313 . See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  9. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  10. Install the rocker arms and camshafts. Refer to «Camshaft Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  11. Remove the EN 46106 in order to prevent crankshaft rotation. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  12. Install the starter motor. Refer to «Starter Motor Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  1. EN 46106 Flywheel Holding Tool. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  2. EN 46110 On-Vehicle Valve Spring Compressor. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  3. EN 46116 Valve Stem Seal Remover/Installer. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  4. J 39313 Spark Plug Port Adapter. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  1. Remove the starter motor. Refer to «Starter Motor Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  2. Install the EN 46106 in order to prevent crankshaft rotation. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  3. Remove the camshafts and rocker arms. Refer to «Camshaft Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  4. Remove the spark plug from the applicable cylinder. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  5. Install the J 39313 to the applicable cylinder. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  6. Connect the J 39313 to a compressed air source. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  7. Install the EN 46110 above the applicable cylinder as shown. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  8. Tighten the EN 46110 valve spring compressor nut (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  9. Remove the valve keepers.
  10. Loosen the EN 46110 valve spring compressor nut. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  11. Remove the valve spring retainer.
  12. Remove the valve springs.
  13. Use the EN 46116 (1) in order to remove the valve stem seal (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  1. Use the EN 46116 (1) in order to install the valve stem seals (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  2. Install the valve spring.
  3. Install the valve spring retainer.
  4. Install the EN 46110 above the applicable valve spring as shown. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) . Tighten the EN 46110 valve spring compressor nut (2). See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  5. Install the valve spring keepers.
  6. Remove the EN 46110 . See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  7. Disconnect the J 39313 from the compressed air source. See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  8. Remove the J 39313 . See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  9. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/lacrosse/i-2004-2009/remont/testing-diagnostics/#engine-control-system-36l-ly7-introduction-2-of-2) in Engine Controls - 3.6L (LY7).
  10. Install the rocker arms and camshafts. Refer to «Camshaft Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  11. Remove the EN 46106 . See «Special Tools»(/buick/lacrosse/i-2004-2009/remont/mechanical/#how-to-diagnosis-troubleshooting-the-engine-mechanical-36l-ly7-introduction__special-tools) .
  12. Install the starter motor. Refer to «Starter Motor Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  1. Remove the left bank secondary timing chain. Refer to «Secondary Camshaft Drive Chain Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the oil level indicator. Refer to «Oil Level Indicator and Tube Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  3. Remove the heat shield from the coolant temperature sensor and disconnect the coolant temperature sensor electrical connector.
  4. Remove the wiring harness ground from the cylinder head.
  5. Disconnect the wiring harness electrical connector located at the side of the cylinder head.
  6. Remove the wiring harness connector bracket from the side of the cylinder head.
  7. Remove the power steering pump bolts.
  8. Remove the surge tank hose from the bracket at the rear of the cylinder head.
  9. Remove the wiring harness bracket from the rear of the cylinder head.
  10. Remove the catalytic converter.
  11. Remove the oil level indicator. Refer to «Oil Level Indicator and Tube Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  12. Remove the oil filter adapter upper bolt.
  13. Remove the cylinder head with the exhaust manifold.
  14. Remove and discard the cylinder head gasket.
  15. Clean and inspect the cylinder head and the engine block sealing surfaces.
  16. If necessary, perform the following steps: Remove the exhaust manifold from the cylinder head. Disassemble the cylinder head.
  1. If necessary, perform the following steps: Assemble the cylinder head. Install the exhaust manifold to the cylinder head.
  2. Install a NEW cylinder head gasket.
  3. Carefully install the cylinder head with the exhaust manifold to the engine.
  4. Install the oil filter adapter upper bolt.
  5. Install the oil level indicator. Refer to «Oil Level Indicator and Tube Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  6. Install the catalytic converter to the exhaust manifold.
  7. Install the wiring harness bracket to the rear of the cylinder head.
  8. Install the surge tank hose to the bracket at the rear of the cylinder head.
  9. Install the power steering pump bolts.
  10. Install the wiring harness connector bracket from the side of the cylinder head.
  11. Disconnect the wiring harness electrical connector located at the side of the cylinder head.
  12. Install the wiring harness ground to the cylinder head. Tighten: Tighten the wiring harness ground bolt to 10 N.m (89 lb in).
  13. Install the coolant temperature sensor electrical connector heat shield.
  14. Install the oil level indicator. Refer to «Oil Level Indicator and Tube Replacement»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  15. Install the left bank secondary timing chain. Refer to «Secondary Camshaft Drive Chain Replacement - Left»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  1. Remove the right bank secondary timing chain. Refer to «Secondary Camshaft Drive Chain Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .
  2. Remove the coolant inlet pipe bolts and reposition the coolant inlet pipe to provide access.
  3. Remove the catalytic converter.
  4. Remove the wiring harness ground from the side of the cylinder head.
  5. Remove the wiring harness conduit upper bolt from the cylinder head and reposition the conduit to provide access.
  6. Remove the battery cable from the cylinder head. Refer to «Battery Negative Cable Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  7. Remove the cylinder head with the exhaust manifold.
  8. Remove and discard the cylinder head gasket.
  9. Clean and inspect the cylinder head and the engine block sealing surfaces.
  10. If necessary, perform the following steps: Remove the exhaust manifold from the cylinder head. Disassemble the cylinder head.
  1. If necessary, perform the following steps: Assemble the cylinder head. Install the exhaust manifold to the cylinder head.
  2. Install a NEW cylinder head gasket.
  3. Carefully install the cylinder head with the exhaust manifold to the engine.
  4. Connect the catalytic converter to the exhaust manifold.
  5. Install the battery negative cable to the cylinder head. Refer to «Battery Negative Cable Replacement (LY7)»(/buick/lacrosse/i-2004-2009/remont/charging-system/#battery-charging-system-and-starting-system) in Engine Electrical.
  6. Install the wiring harness conduit to the cylinder head. Tighten: Tighten the wiring harness upper bolt to 10 N.m (89 lb in).
  7. Install the wiring harness ground to the side of the cylinder head. Tighten: Tighten the wiring harness ground bolt to 10 N.m (89 lb in).
  8. Install the catalytic converter.
  9. Install the coolant inlet pipe.
  10. Install the right bank secondary timing chain. Refer to «Secondary Camshaft Drive Chain Replacement - Right»(/buick/lacrosse/i-2004-2009/remont/mechanical/#engine-mechanical-36l-ly7-repair-instructions-1-of-5) .

See also:
• Lifting and Jacking the Vehicle
• Splash Shield Replacement - Engine
• Fastener Notice
• Special Tools
• Coolant Recovery Reservoir Replacement
• Transmission Mount Inspection
• Battery Negative Cable Disconnect/Connect Procedure (LY7)
• Air Cleaner Intake Duct Replacement
• Catalytic Converter Replacement
• Tire and Wheel Removal and Installation
• Fastener Tightening Specifications
• Intake Manifold Disassemble
• INTAKE MANIFOLD INSTALLATION
• OIL LEVEL INDICATOR AND TUBE INSTALLATION
• Engine Oil and Oil Filter Replacement
• Oil Filter Adapter Removal
• Oil Filter Adapter Disassemble
• OIL FILTER ADAPTER INSTALLATION
• CRANKSHAFT BALANCER INSTALLATION
• Remote Power Steering Fluid Reservoir Replacement
• Secondary Camshaft Drive Chain Tensioner Removal - Right
• Secondary Camshaft Drive Chain Shoe Removal - Right
• Secondary Camshaft Drive Chain Guide Removal - Right
• Primary Camshaft Drive Chain Tensioners Removal
• Primary Camshaft Drive Chain Guide Removal - Upper
• Camshaft Intermediate Drive Chain Idler Removal - Right
• CAMSHAFT INTERMEDIATE DRIVE CHAIN IDLER INSTALLATION - LEFT
• SECONDARY CAMSHAFT DRIVE CHAIN GUIDE INSTALLATION - LEFT
• SECONDARY CAMSHAFT DRIVE CHAIN SHOE INSTALLATION - LEFT
• Primary Camshaft Drive Chain Installation
• Primary Camshaft Drive Chain Guide Installation - Upper
• Secondary Camshaft Drive Chain Installation - Right
• Camshaft Timing Drive Chain Alignment Diagram (W/Primary Inverted Tooth (IT) Chain)
• Torque Reaction Against Timing Drive Chain Notice
• Camshaft Position (CMP) Actuator Installation - Left Intake
• Valve Lifters Cleaning and Inspection
• Valve Rocker Arm Installation - Left
• Valve Rocker Arm Installation - Right
• Valve Lifter Installation - Left
• Valve Lifter Installation - Right
• Drive Belt Replacement

More articles — Engine
