Interior Trim and Interior Paneling Buick Encore I

Exterior/interior Trim 48 illustrations ~489 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Cargo Tie Down Hook Fastener980 lb in
Roof Rail Assist Handle653 lb in
Roof Rail Front Stowage Compartment653 lb in
Roof Rail Rear Assist Handle653 lb in

Fastener Tightening Specifications

Scheme 47

Scheme 47: Rear Side Door Accessory Switch Mount Plate Replacement (Encore)
Scheme 47: Rear Side Door Accessory Switch Mount Plate Replacement (Encore)
CalloutComponent Name
1Rear Side Door Accessory Switch Mount Plate Fastener CAUTION: Refer to Fastener Caution . Procedure Use a flat-bladed tool to open the rear side door trim integral cap to access the fastener.
2Rear Side Door Accessory Switch Mount Plate Assembly Procedure Use a flat-bladed plastic trim tool in order to release the rear side door accessory switch mount plate from the door trim assembly. Disconnect the electrical connector, if equipped.
CAUTION
Refer to Fastener Caution .

Rear Side Door Accessory Switch Mount Plate Replacement (Encore)

Scheme 48

Scheme 48: Rear Side Door Accessory Switch Mount Plate Replacement (Trax)
Scheme 48: Rear Side Door Accessory Switch Mount Plate Replacement (Trax)
CalloutComponent Name
1Rear Side Door Accessory Switch Mount Plate Fastener CAUTION: Refer to Fastener Caution . Procedure Use a flat-bladed tool to open the rear side door trim integral cap to access the fastener.
2Rear Side Door Accessory Switch Mount Plate Assembly Procedure Starting from the front portion of the switch mount plate, use a flat-bladed plastic trim tool in order to release the rear side door accessory switch mount plate from the door trim assembly. Disconnect the electrical connector, if equipped. Transfer parts as necessary.
CAUTION
Refer to Fastener Caution .

Rear Side Door Accessory Switch Mount Plate Replacement (Trax)

Scheme 49

Scheme 49: Front Side Door Armrest Switch Mount Plate Replacement (Driver Side Door, Encore)
Scheme 49: Front Side Door Armrest Switch Mount Plate Replacement (Driver Side Door, Encore)
CalloutComponent Name
1Front Side Door Armrest Switch Mount Plate Fastener CAUTION: Refer to Fastener Caution . Procedure Use a small flat-bladed tool to open the front side door trim integral cap to access the fastener.
2Front Side Door Armrest Switch Mount Plate Assembly - Driver Side Door Procedure Use a flat-bladed plastic trim tool in order to release the front side door accessory switch mount plate from the door trim assembly. Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Front Side Door Armrest Switch Mount Plate Replacement (Driver Side Door, Encore)

Scheme 50

Scheme 50: Front Side Door Armrest Switch Mount Plate Replacement (Passenger Side Door, Encore)
Scheme 50: Front Side Door Armrest Switch Mount Plate Replacement (Passenger Side Door, Encore)
CalloutComponent Name
1Front Side Door Trim Fastener CAUTION: Refer to Fastener Caution . Procedure Use a small flat-bladed tool to open the front side door trim integral cap to access the fastener.
2Front Side Door Armrest Switch Mount Plate Assembly - Passenger Side Door Procedure Use the appropriate plastic trim tool to release the front side door armrest switch mount plate spring clips from the door trim panel. Disconnect the electrical connector from the switch assembly. Transfer parts as necessary.
CAUTION
Refer to Fastener Caution .

Front Side Door Armrest Switch Mount Plate Replacement (Passenger Side Door, Encore)

Scheme 51

Scheme 51: Front Side Door Armrest Switch Mount Plate Replacement (Driver Side Door, Trax)
Scheme 51: Front Side Door Armrest Switch Mount Plate Replacement (Driver Side Door, Trax)
CalloutComponent Name
1Front Side Door Armrest Switch Mount Plate Assembly - Driver Side Door Procedure Starting from the bottom of the switch mount plate, use the appropriate plastic trim tool to release the front side door armrest switch mount plate spring clips from the door trim panel. Once the integral retainers are released, pull downward to disengage the integral plastic hook feature retaining the switch mount plate to the door trim panel. Disconnect the electrical connectors from the switch assemblies. Transfer parts as necessary.

Front Side Door Armrest Switch Mount Plate Replacement (Driver Side Door, Trax)

Scheme 52

Scheme 52: Front Side Door Armrest Switch Mount Plate Replacement (Passenger Side Door, Trax)
Scheme 52: Front Side Door Armrest Switch Mount Plate Replacement (Passenger Side Door, Trax)
CalloutComponent Name
1Front Side Door Armrest Switch Mount Plate Assembly - Passenger Side Door Procedure Starting from the bottom of the switch mount plate, use the appropriate plastic trim tool to release the front side door armrest switch mount plate spring clips from the door trim panel. Once the integral retainers are released, pull downward to disengage the integral plastic hook feature retaining the switch mount plate to the door trim panel. Disconnect the electrical connector from the switch assembly. Transfer parts as necessary.

Front Side Door Armrest Switch Mount Plate Replacement (Passenger Side Door, Trax)

Scheme 53

Scheme 53: Front Side Door Trim Replacement (Encore)
Scheme 53: Front Side Door Trim Replacement (Encore)
CalloutComponent Name
1Front Side Door Inside Handle Bolt Finish Cap Procedure Pull the handle back to remove the cap. Use a suitable tool to unsnap.
2Front Side Door Inside Handle Fastener CAUTION: Refer to Fastener Caution .
3Front Side Door Trim Fastener Procedure Use a small flat-bladed tool to open the front side door trim integral cap to access the fastener.
4Front Side Door Trim Assembly Procedure Use the appropriate plastic trim tool to aid in the removal of the door trim. Pull upwards on the door lock retainer cable to disengage. Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Front Side Door Trim Replacement (Encore)

Scheme 54

Scheme 54: Front Side Door Trim Replacement (Trax)
Scheme 54: Front Side Door Trim Replacement (Trax)
CalloutComponent Name
1Front Side Door Inside Handle Bolt Finish Cap Procedure Pull the handle back to remove the cap. Use a suitable tool to unsnap.
2Front Side Door Inside Handle Fastener CAUTION: Refer to Fastener Caution .
3Front Side Door Trim Fastener Procedure Use a small flat-bladed tool to open the front side door trim integral cap to access the fastener.
4Front Side Door Trim Assembly Procedure Use the appropriate plastic trim tool to aid in the removal of the door trim. Pull upwards on the door lock retainer cable to disengage. Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Front Side Door Trim Replacement (Trax)

Scheme 55

Scheme 55: Rear Side Door Window Garnish Molding Replacement (Encore)
Scheme 55: Rear Side Door Window Garnish Molding Replacement (Encore)
CalloutComponent Name
Preliminary Procedure Remove the rear side door trim. Refer to Rear Side Door Trim Replacement .
1Rear Side Door Window Garnish Molding Retainer Procedure Use a door trim panel removal tool or equivalent to aid in the removal of the retainer.
2Rear Side Door Window Garnish Molding Assembly Procedure Pull outward starting at the front and moving slowly rearward to release the integral tabs from the rear side door inner panel.

Rear Side Door Window Garnish Molding Replacement (Encore)

Scheme 56

Scheme 56: Rear Side Door Window Garnish Molding Replacement (Trax)
Scheme 56: Rear Side Door Window Garnish Molding Replacement (Trax)
CalloutComponent Name
Preliminary Procedure Remove the rear side door trim. Refer to Rear Side Door Trim Replacement .
1Rear Side Door Window Garnish Molding Retainer Procedure Use a door trim panel removal tool or equivalent to aid in the removal of the retainer.
2Rear Side Door Window Garnish Molding Assembly Procedure Pull outward starting at the front and moving slowly rearward to release the integral tabs from the rear side door inner panel.

Rear Side Door Window Garnish Molding Replacement (Trax)

Scheme 57

Scheme 57: Front Side Door Window Garnish Molding Replacement
Scheme 57: Front Side Door Window Garnish Molding Replacement
CalloutComponent Name
Preliminary Procedure Remove the front side door trim. Refer to Front Side Door Trim Replacement (Encore) , Front Side Door Trim Replacement (Trax) .
1Front Side Door Window Garnish Molding Assembly Procedure Pull outward starting at the front and moving slowly rearward to release the integral tabs from the front side door inner panel.

Front Side Door Window Garnish Molding Replacement

Scheme 58

Scheme 58: Roof Rail Front Stowage Compartment Replacement (Encore)
Scheme 58: Roof Rail Front Stowage Compartment Replacement (Encore)
CalloutComponent Name
1Roof Rail Front Stowage Compartment Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Fold the assist handle downward and hold. Use a small flat-bladed tool to release the cover to access the fastener. Tighten: 6 (53 lb in)
2Roof Rail Front Stowage Compartment Assembly
CAUTION
Refer to Fastener Caution .

Roof Rail Front Stowage Compartment Replacement (Encore)

Scheme 59

Scheme 59: Roof Rail Front Stowage Compartment Replacement (Trax)
Scheme 59: Roof Rail Front Stowage Compartment Replacement (Trax)
CalloutComponent Name
1Roof Rail Front Stowage Compartment Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Fold the assist handle downward and hold. Use a small flat-bladed tool to release the cover to access the fastener. Tighten: 6 (53 lb in)
2Roof Rail Front Stowage Compartment Assembly
CAUTION
Refer to Fastener Caution .

Roof Rail Front Stowage Compartment Replacement (Trax)

Scheme 60

Scheme 60: Roof Rail Assist Handle Replacement (Encore)
Scheme 60: Roof Rail Assist Handle Replacement (Encore)
CalloutComponent Name
1Roof Rail Assist Handle Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Fold the assist handle downward and hold. Use a small flat-bladed tool to open the assist handle covers to access the screws. Tighten 6 (53 lb in)
2Roof Rail Assist Handle Assembly
CAUTION
Refer to Fastener Caution .

Roof Rail Assist Handle Replacement (Encore)

Scheme 61

Scheme 61: Roof Rail Assist Handle Replacement (Trax)
Scheme 61: Roof Rail Assist Handle Replacement (Trax)
CalloutComponent Name
1Roof Rail Assist Handle Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Fold the assist handle downward and hold. Use a small flat-bladed tool to open the assist handle covers to access the screws. Tighten 6 (53 lb in)
2Roof Rail Assist Handle Assembly
CAUTION
Refer to Fastener Caution .

Roof Rail Assist Handle Replacement (Trax)

Scheme 62

Scheme 62: Roof Rail Rear Assist Handle Replacement (Encore)
Scheme 62: Roof Rail Rear Assist Handle Replacement (Encore)
CalloutComponent Name
1Roof Rail Rear Assist Handle Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Fold the assist handle downward and hold. Use a small flat-bladed tool to open the assist handle covers to access the screws. Tighten 6 (53 lb in)
2Roof Rail Rear Assist Handle Assembly
CAUTION
Refer to Fastener Caution .

Roof Rail Rear Assist Handle Replacement (Encore)

Scheme 63

Scheme 63: Roof Rail Rear Assist Handle Replacement (Trax)
Scheme 63: Roof Rail Rear Assist Handle Replacement (Trax)
CalloutComponent Name
1Roof Rail Rear Assist Handle Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Fold the assist handle downward and hold. Use a small flat-bladed tool to open the assist handle covers to access the screws. Tighten 6 (53 lb in)
2Roof Rail Rear Assist Handle Assembly
CAUTION
Refer to Fastener Caution .

Roof Rail Rear Assist Handle Replacement (Trax)

Scheme 64

Scheme 64: Sunshade Replacement (Encore)
Scheme 64: Sunshade Replacement (Encore)
CalloutComponent Name
Preliminary Procedure Lower the front of the headliner to access the sunshade electrical connector, if necessary. Refer to Headlining Trim Panel Replacement (Without Sunroof, Encore) , Headlining Trim Panel Replacement (With Sunroof, Encore) .
1Sunshade Cover
2Sunshade Fastener (Qty: 3) CAUTION: Refer to Fastener Caution .
3Sunshade Assembly Procedure Squeeze the tabs at the base of the sunshade assembly to remove from the headliner. Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Sunshade Replacement (Encore)

Scheme 65

Scheme 65: Sunshade Replacement (Trax)
Scheme 65: Sunshade Replacement (Trax)
CalloutComponent Name
Preliminary Procedure Lower the front portion of the headliner to access the sunshade electrical connector and sunshade retainer. Refer to Headlining Trim Panel Replacement (With Sunroof, Trax) , Headlining Trim Panel Replacement (Without Sunroof, Trax) .
1Sunshade Cover
2Sunshade Fastener (Qty: 3) CAUTION: Refer to Fastener Caution .
3Sunshade Assembly Procedure Squeeze the tabs at the base of the sunshade assembly to detach it from the roof panel and allow the headliner with the sunshade attached to be lowered. Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Sunshade Replacement (Trax)

Scheme 66

Scheme 66: Sunshade Support Replacement (Encore)
Scheme 66: Sunshade Support Replacement (Encore)
CalloutComponent Name
1Sunshade Support Fastener CAUTION: Refer to Fastener Caution . NOTE: Pull the cover downward to access the fastener.
2Sunshade Support Assembly Procedure Unclip the sunshade from the support and reposition.
CAUTION
Refer to Fastener Caution .
NOTE
Pull the cover downward to access the fastener.

Sunshade Support Replacement (Encore)

Scheme 67

Scheme 67: Sunshade Support Replacement (Trax)
Scheme 67: Sunshade Support Replacement (Trax)
CalloutComponent Name
1Sunshade Support Fastener CAUTION: Refer to Fastener Caution . NOTE: Open the cover at the bottom and push upward to access the fastener.
2Sunshade Support Assembly Procedure Unclip the sunshade from the support and reposition.
CAUTION
Refer to Fastener Caution .
NOTE
Open the cover at the bottom and push upward to access the fastener.

Sunshade Support Replacement (Trax)

Scheme 68

Scheme 68: Windshield Garnish Molding Replacement (Encore)
Scheme 68: Windshield Garnish Molding Replacement (Encore)
CalloutComponent Name
1Windshield Garnish Molding Assembly Procedure Tabs must be installed prior to retainers. Tabs to be fully seated in the instrument panel (I/P) trim panel retainer and valance panel. Disconnect the electrical connector. The tether clip at the upper portion of the garnish molding MUST be replaced every time the windshield side garnish molding is removed.

Windshield Garnish Molding Replacement (Encore)

Scheme 69

Scheme 69: Windshield Garnish Molding Replacement (Trax)
Scheme 69: Windshield Garnish Molding Replacement (Trax)
CalloutComponent Name
1Windshield Garnish Molding Assembly Procedure Tabs must be installed prior to retainers. Tabs to be fully seated in the instrument panel (I/P) trim panel retainer and valance panel. Disconnect the electrical connector. The tether clip at the upper portion of the garnish molding MUST be replaced every time the windshield side garnish molding is removed.

Windshield Garnish Molding Replacement (Trax)

Scheme 70

Scheme 70: Center Pillar Upper Trim Panel Replacement (Encore)
Scheme 70: Center Pillar Upper Trim Panel Replacement (Encore)
CalloutComponent Name
Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the seat belt tensioner fastener and feed seat belt through center pillar upper trim panel. Refer to Front Seat Belt Anchor Plate Tensioner Replacement . Remove the center pillar lower trim panel. Refer to Center Pillar Lower Trim Panel Replacement (Encore) . Move the driver or passenger seat to the full forward position.
1Center Pillar Upper Trim Panel Bolt Cap
2Center Pillar Upper Trim Panel Fastener CAUTION: Refer to Fastener Caution .
3Center Pillar Upper Trim Panel Assembly Procedure Pull the trim panel toward the inside of the vehicle to disengage the retainers. When replacing the center pillar upper trim panel, feed the seat belt through the panel.
CAUTION
Refer to Fastener Caution .

Center Pillar Upper Trim Panel Replacement (Encore)

Scheme 71

Scheme 71: Center Pillar Upper Trim Panel Replacement (Trax)
Scheme 71: Center Pillar Upper Trim Panel Replacement (Trax)
CalloutComponent Name
Preliminary Procedures Disable the roof rail SIR system. Refer to SIR Disabling and Enabling . Remove the seat belt tensioner fastener and feed seat belt through center pillar upper trim panel. Refer to Front Seat Belt Anchor Plate Tensioner Replacement . Remove the center pillar lower trim panel. Refer to Center Pillar Lower Trim Panel Replacement (Trax) . Move the driver or passenger seat to the full forward position.
1Center Pillar Upper Trim Panel Bolt Cap
2Center Pillar Upper Trim Panel Fastener CAUTION: Refer to Fastener Caution .
3Center Pillar Upper Trim Panel Assembly Procedure Pull the trim panel toward the inside of the vehicle to disengage the retainers. When replacing the center pillar upper trim panel, feed the seat belt through the panel.
CAUTION
Refer to Fastener Caution .

Center Pillar Upper Trim Panel Replacement (Trax)

Scheme 72

Scheme 72: Center Pillar Lower Trim Panel Replacement (Encore)
Scheme 72: Center Pillar Lower Trim Panel Replacement (Encore)
CalloutComponent Name
Preliminary Procedures Remove the floor auxiliary mat lower retainer. Refer to Floor Auxiliary Mat Lower Retainer Replacement (Encore) . Remove the rear side door step mat retainer. Refer to Rear Side Door Step Mat Retainer Replacement . Move seat to full forward position.
1Center Pillar Lower Trim Panel Assembly Procedure Ensure the seat belt webbing does not become trapped during installation.

Center Pillar Lower Trim Panel Replacement (Encore)

Scheme 73

Scheme 73: Center Pillar Lower Trim Panel Replacement (Trax)
Scheme 73: Center Pillar Lower Trim Panel Replacement (Trax)
CalloutComponent Name
Preliminary Procedures Remove the floor auxiliary mat lower retainer. Refer to Floor Auxiliary Mat Lower Retainer Replacement (Trax) . Remove the rear side door step mat retainer. Refer to Rear Side Door Step Mat Retainer Replacement . Move seat to full forward position.
1Center Pillar Lower Trim Panel Assembly Procedure Ensure the seat belt webbing does not become trapped during installation.

Center Pillar Lower Trim Panel Replacement (Trax)

Scheme 74

Scheme 74: Body Lock Pillar Upper Trim Panel Replacement
Scheme 74: Body Lock Pillar Upper Trim Panel Replacement
CalloutComponent Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the rear seat lower anchor plate bolt on the side of the trim panel being replaced. . Refer to Rear Seat Belt Retractor Replacement .
1Body Lock Pillar Upper Trim Panel Bolt Cap
2Body Lock Pillar Upper Trim Panel Fastener CAUTION: Refer to Fastener Caution .
3Body Lock Pillar Upper Trim Panel Assembly Procedure Grasp the top of the upper trim panel and gently pull the panel away from the body to release the retainers. Route the rear seat retractor side belt through the opening in the body lock pillar upper trim panel.
CAUTION
Refer to Fastener Caution .

Body Lock Pillar Upper Trim Panel Replacement

Scheme 75

Scheme 75: Quarter Lower Rear Trim Panel Replacement
Scheme 75: Quarter Lower Rear Trim Panel Replacement
CalloutComponent Name
Preliminary Procedures Remove the load floor front trim panel support. Refer to Load Floor Front Trim Panel Support Replacement (Encore) , Load Floor Front Trim Panel Support Replacement (Trax) . Remove the body lock pillar upper trim panel. Refer to Body Lock Pillar Upper Trim Panel Replacement . Remove the load floor panel rear extension panel. Refer to Load Floor Panel Rear Extension Panel Replacement (Encore) , Load Floor Panel Rear Extension Panel Replacement (Trax) . Remove the luggage shade. Refer to Luggage Shade Replacement (Encore) , Luggage Shade Replacement (Trax) . Remove the rear side door step mat retainer. Refer to Rear Side Door Step Mat Retainer Replacement . Remove the rear seat back cushion. Refer to Rear Seat Back Cushion Removal and Installation (60%) , Rear Seat Back Cushion Removal and Installation (40%) .
1Cargo Tie Down Hook Fastener CAUTION: Refer to Fastener Caution . Tighten 9 (80 lb in)
2Cargo Tie Down Hook Assembly
3Quarter Lower Rear Trim Panel Assembly Procedure Release the rear seat belt anchor bracket from the rear seat. Use a flat-bladed plastic trim tool to release the quarter lower rear trim panel from the quarter inner panel. Disconnect the electrical connectors.
CAUTION
Refer to Fastener Caution .

Quarter Lower Rear Trim Panel Replacement

Scheme 76

Scheme 76: Quarter Stowage Pocket Door Replacement (Left Side)
Scheme 76: Quarter Stowage Pocket Door Replacement (Left Side)
CalloutComponent Name
1Quarter Stowage Pocket Door Cap (Qty: 2)
2Quarter Stowage Pocket Door Fastener (Qty: 2) CAUTION: Refer to Fastener Caution .
3Quarter Stowage Pocket Door Assembly Left Side Outer Procedure Use a flat-bladed trim tool to aid in the removal of the quarter stowage pocket door left side from the quarter inner trim finish panel.
CAUTION
Refer to Fastener Caution .

Quarter Stowage Pocket Door Replacement (Left Side)

Scheme 77

Scheme 77: Quarter Stowage Pocket Door Replacement (Right Side)
Scheme 77: Quarter Stowage Pocket Door Replacement (Right Side)
CalloutComponent Name
1Quarter Stowage Pocket Door Assembly Right Side Procedure Use a flat-bladed trim tool to aid in the removal of the quarter stowage pocket door from the quarter inner trim finish panel right side.

Quarter Stowage Pocket Door Replacement (Right Side)

Scheme 78

Scheme 78: Load Floor Front Trim Panel Support Replacement (Encore)
Scheme 78: Load Floor Front Trim Panel Support Replacement (Encore)
CalloutComponent Name
Preliminary Procedure Remove the load floor stowage compartment cover. Refer to Load Floor Stowage Compartment Cover Replacement (Encore) .
1Rear Compartment Floor Stowage Compartment Divider Retainer
2Load Floor Front Trim Panel Support NOTE: Load floor front trim panel support on left side must be removed prior to removal of right side load floor front trim panel support, due to overlap.
NOTE
Load floor front trim panel support on left side must be removed prior to removal of right side load floor front trim panel support, due to overlap.

Load Floor Front Trim Panel Support Replacement (Encore)

Scheme 79

Scheme 79: Load Floor Front Trim Panel Support Replacement (Trax)
Scheme 79: Load Floor Front Trim Panel Support Replacement (Trax)
CalloutComponent Name
Preliminary Procedure Remove the load floor stowage compartment cover. Refer to Load Floor Stowage Compartment Cover Replacement (Trax) .
1Rear Compartment Floor Stowage Compartment Divider Retainer
2Load Floor Front Trim Panel Support NOTE: Load floor front trim panel support on left side must be removed prior to removal of right side load floor front trim panel support, due to overlap.
NOTE
Load floor front trim panel support on left side must be removed prior to removal of right side load floor front trim panel support, due to overlap.

Load Floor Front Trim Panel Support Replacement (Trax)

Scheme 80

Scheme 80: Load Floor Panel Center Support Replacement (Encore)
Scheme 80: Load Floor Panel Center Support Replacement (Encore)
CalloutComponent Name
Procedure Remove the load floor front trim panel support. Refer to Load Floor Front Trim Panel Support Replacement (Encore) .
1Load Floor Panel Center Support Assembly

Load Floor Panel Center Support Replacement (Encore)

Scheme 81

Scheme 81: Load Floor Panel Rear Extension Panel Replacement (Encore)
Scheme 81: Load Floor Panel Rear Extension Panel Replacement (Encore)
CalloutComponent Name
Preliminary Procedure Remove the cargo tie down hooks. Refer to Cargo Tie Down Loop Replacement (Encore) .
1Load Floor Panel Rear Extension Panel Assembly Procedure Grasp and gently pull up on the load floor panel rear extension panel in order to release the integral retaining clips.

Load Floor Panel Rear Extension Panel Replacement (Encore)

Scheme 82

Scheme 82: Load Floor Panel Rear Extension Panel Replacement (Trax)
Scheme 82: Load Floor Panel Rear Extension Panel Replacement (Trax)
CalloutComponent Name
Preliminary Procedure Remove the load floor stowage compartment cover. Refer to Load Floor Stowage Compartment Cover Replacement (Trax) . Remove the cargo tie down hooks. Refer to Cargo Tie Down Loop Replacement (Trax) .
1Load Floor Panel Rear Extension Panel Assembly Procedure Grasp and gently pull up on the load floor panel rear extension panel in order to release the integral retaining clips.

Load Floor Panel Rear Extension Panel Replacement (Trax)

Scheme 83

Scheme 83: Rear Side Door Trim Replacement
Scheme 83: Rear Side Door Trim Replacement
CalloutComponent Name
1Rear Side Door Inside Handle Bolt Finish Cap Procedure Pull handle back to remove cap. Use suitable tool to unsnap.
2Rear Side Door Inside Handle Fastener CAUTION: Refer to Fastener Caution . Tighten 2.5 (22 lb in)
3Rear Side Door Pull Handle Fastener Procedure Use a small flat-bladed tool to open the rear side door trim integral cap to access the fastener. Tighten 2.5 (22 lb in)
4Rear Side Door Trim Assembly Procedure Use the appropriate plastic trim tool to aid in the removal of the door trim. Pull upwards on the door lock retainer cable to disengage. Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Rear Side Door Trim Replacement

Scheme 84

Scheme 84: Luggage Shade Replacement (Encore)
Scheme 84: Luggage Shade Replacement (Encore)
CalloutComponent Name
1Luggage Shade Assembly Procedure Release the luggage shade straps from the liftgate. Pull gently upon the luggage shade to disengage from the body lock pillar upper trim panel. Release the luggage shade from the pivot supports.

Luggage Shade Replacement (Encore)

Scheme 85

Scheme 85: Luggage Shade Replacement (Trax)
Scheme 85: Luggage Shade Replacement (Trax)
CalloutComponent Name
1Luggage Shade Assembly Procedure Release the luggage shade straps from the liftgate. Pull gently upon the luggage shade to disengage from the body lock pillar upper trim panel. Release the luggage shade from the pivot supports.

Luggage Shade Replacement (Trax)

Scheme 86

Scheme 86: Luggage Shade Pivot Replacement (Body Side)
Scheme 86: Luggage Shade Pivot Replacement (Body Side)
CalloutComponent Name
Preliminary Procedure Remove the body lock pillar upper trim panel. Refer to Body Lock Pillar Upper Trim Panel Replacement .
1Luggage Shade Pivot Procedure Use a flat bladed tool to release the luggage shade pivot from the backside of the body lock pillar upper trim panel.

Luggage Shade Pivot Replacement (Body Side)

Scheme 87

Scheme 87: Luggage Shade Pivot Replacement (Luggage Shade)
Scheme 87: Luggage Shade Pivot Replacement (Luggage Shade)
CalloutComponent Name
1Luggage Shade Pivot Retainer (Qty: 2) Procedure Use a flat-bladed tool to release the luggage shade pivot locking retainer from the luggage shade.
2Luggage Shade Pivot Procedure Pull gently the luggage shade pivot to disengage from the luggage shade.

Luggage Shade Pivot Replacement (Luggage Shade)

Scheme 88

Scheme 88: Luggage Shade Pivot Replacement (Liftgate)
Scheme 88: Luggage Shade Pivot Replacement (Liftgate)
CalloutComponent Name
1Luggage Shade Pivot Procedure Release the luggage shade strap. NOTE: The luggage shade pivots are a one-time use component and will break upon removal.
NOTE
The luggage shade pivots are a one-time use component and will break upon removal.

Luggage Shade Pivot Replacement (Liftgate)

Scheme 89

Scheme 89: Liftgate Upper Center Trim Finish Panel Replacement
Scheme 89: Liftgate Upper Center Trim Finish Panel Replacement
CalloutComponent Name
1Liftgate Upper Center Trim Finish Panel Assembly Procedure The left and right outboard lower ends of the trim finish panel snap into the liftgate upper side trim finish panels.

Liftgate Upper Center Trim Finish Panel Replacement

Scheme 90

Scheme 90: Liftgate Upper Side Trim Finish Panel Replacement
Scheme 90: Liftgate Upper Side Trim Finish Panel Replacement
CalloutComponent Name
Preliminary Procedure Remove the liftgate upper center trim finish panel. Refer to Liftgate Upper Center Trim Finish Panel Replacement . Remove the luggage shade pivot. Refer to Luggage Shade Pivot Replacement (Body Side) , Luggage Shade Pivot Replacement (Luggage Shade) , Luggage Shade Pivot Replacement (Liftgate) .
1Liftgate Upper Side Trim Finish Panel Assembly (Qty: 2) Procedure The outboard lower end of the liftgate upper side trim finish panel snaps into the liftgate lower trim finish panel.

Liftgate Upper Side Trim Finish Panel Replacement

Scheme 91

Scheme 91: Liftgate Lower Trim Finish Panel Replacement
Scheme 91: Liftgate Lower Trim Finish Panel Replacement
CalloutComponent Name
Preliminary Procedure Remove the liftgate upper side trim finish panel. Refer to Liftgate Upper Side Trim Finish Panel Replacement .
1Liftgate Inside Pull Handle Procedure Squeeze and pull the inside handle to disengage from liftgate trim finish panel.
2Liftgate Lower Trim Finish Panel Assembly Procedure Use a trim panel removal tool to aid in the removal of the trim panel from the liftgate assembly. Start at the top clip on the right-hand side of liftgate lower trim finish panel. Disconnect the electrical connector, if equipped.

Liftgate Lower Trim Finish Panel Replacement

Scheme 92

Scheme 92: Cargo Tie Down Loop Replacement (Encore)
Scheme 92: Cargo Tie Down Loop Replacement (Encore)
CalloutComponent Name
1Cargo Tie Down Hook Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 9 (80 lb in)
2Cargo Tie Down Hook Assembly (Qty: 2)
CAUTION
Refer to Fastener Caution .

Cargo Tie Down Loop Replacement (Encore)

Scheme 93

Scheme 93: Cargo Tie Down Loop Replacement (Trax)
Scheme 93: Cargo Tie Down Loop Replacement (Trax)
CalloutComponent Name
1Cargo Tie Down Hook Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 9 (80 lb in)
2Cargo Tie Down Hook Assembly (Qty: 2)
CAUTION
Refer to Fastener Caution .

Cargo Tie Down Loop Replacement (Trax)

Scheme 94

Scheme 94: Body Rear Outer Panel Pressure Relief Valve Replacement
Scheme 94: Body Rear Outer Panel Pressure Relief Valve Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear bumper lower fascia. Refer to Rear Bumper Lower Fascia Replacement .
1Body Rear Outer Panel Pressure Relief Valve (Qty: 2) Procedure Release the tabs attaching the valves to the inner rear quarter panel to remove the body rear outer panel pressure relief valve.

Body Rear Outer Panel Pressure Relief Valve Replacement

More articles — Body & Frame
