Instrument Panel Trim and Console Trim Buick Encore I

Exterior/interior Trim 40 illustrations ~3206 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Brake Pedal Bracket Bolt9 N.m80 lb in
HVAC Module Bolt9 N.m80 lb in
Instrument Panel Compartment Door Latch Striker Bolt9 N.m80 lb in
Instrument Panel Driver Knee Bolster Inner Bracket Bolt9 N.m80 lb in
Instrument Panel Inflatable Restraint Module Bracket Bolt9 N.m80 lb in
Instrument Panel Knee Bolster Outer Bracket Bolt9 N.m80 lb in
Instrument Panel Knee Bolster Outer Bracket Nut9 N.m80 lb in
Instrument Panel Tie Bar Bolt22 N.m16 lb ft
Instrument Panel Tie Bar Lower Support Bracket Bolt22 N.m16 lb ft
Instrument Panel Tie Bar Nut22 N.m16 lb ft

Fastener Tightening Specifications

Scheme 95

Scheme 95: Instrument Panel Lower Trim Panel Insulator Replacement
Scheme 95: Instrument Panel Lower Trim Panel Insulator Replacement
CalloutComponent Name
1Instrument Panel Lower Trim Panel Insulator Bolt (Qty: 3) CAUTION: Refer to Fastener Caution .
2Instrument Panel Lower Trim Panel Insulator
CAUTION
Refer to Fastener Caution .

Instrument Panel Lower Trim Panel Insulator Replacement

Scheme 96

Scheme 96: Instrument Panel Lower Center Trim Plate Applique Replacement (Trax)
Scheme 96: Instrument Panel Lower Center Trim Plate Applique Replacement (Trax)
CalloutComponent Name
Preliminary Procedure Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement (Trax) .
1Instrument Panel Lower Center Trim Plate Applique Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
2Instrument Panel Lower Center Trim Plate Applique Procedures Use a flat bladed plastic trim tool to aid in the removal of the trim plate applique from the instrument panel assembly. Disconnect the electrical connections. Transfer parts as necessary.
CAUTION
Refer to Fastener Caution .

Instrument Panel Lower Center Trim Plate Applique Replacement (Trax)

Scheme 97

Scheme 97: Instrument Panel Lower Center Trim Plate Applique Replacement (Encore)
Scheme 97: Instrument Panel Lower Center Trim Plate Applique Replacement (Encore)
CalloutComponent Name
Preliminary Procedures Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement (Encore) . Remove the instrument panel trim plate. Refer to Instrument Panel Trim Plate Replacement (Encore) .
1Instrument Panel Lower Center Trim Plate Applique Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
2Instrument Panel Lower Center Trim Plate Applique Procedures Use a flat bladed plastic trim tool to aid in the removal of the trim plate from the instrument panel assembly. Disconnect the electrical connection. Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Instrument Panel Lower Center Trim Plate Applique Replacement (Encore)

Scheme 98

Scheme 98: Instrument Panel Instrument Cluster Hood Replacement (Encore)
Scheme 98: Instrument Panel Instrument Cluster Hood Replacement (Encore)
CalloutComponent Name
1Instrument Panel Instrument Cluster Hood Procedure Use a flat bladed plastic trim tool in order to release the retainers securing the hood to the instrument panel assembly.

Instrument Panel Instrument Cluster Hood Replacement (Encore)

Scheme 99

Scheme 99: Instrument Panel Instrument Cluster Hood Replacement (Trax)
Scheme 99: Instrument Panel Instrument Cluster Hood Replacement (Trax)
CalloutComponent Name
1Instrument Panel Instrument Cluster Hood Procedure Use a flat bladed plastic trim tool in order to release the retainers securing the hood to the instrument panel assembly.

Instrument Panel Instrument Cluster Hood Replacement (Trax)

Scheme 100

Scheme 100: Instrument Panel Knee Bolster Inner Bracket Replacement
Scheme 100: Instrument Panel Knee Bolster Inner Bracket Replacement
CalloutComponent Name
Preliminary Procedures Remove the instrument panel knee bolster. Refer to Instrument Panel Knee Bolster Replacement (Encore) , Instrument Panel Knee Bolster Replacement (Trax) .
1Instrument Panel Driver Knee Bolster Inner Bracket Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 9 (80 lb in)
2Instrument Panel Knee Bolster Inner Bracket
CAUTION
Refer to Fastener Caution .

Instrument Panel Knee Bolster Inner Bracket Replacement

Scheme 101

Scheme 101: Instrument Panel Knee Bolster Outer Bracket Replacement
Scheme 101: Instrument Panel Knee Bolster Outer Bracket Replacement
CalloutComponent Name
Preliminary Procedures Remove the instrument panel knee bolster inner bracket. Refer to Instrument Panel Knee Bolster Inner Bracket Replacement .
1Instrument Panel Knee Bolster Outer Bracket Bolt CAUTION: Refer to Fastener Caution . Tighten 9 (80 lb in)
2Instrument Panel Knee Bolster Outer Bracket Nut Tighten 9 (80 lb in)
3Instrument Panel Knee Bolster Outer Bracket
CAUTION
Refer to Fastener Caution .

Instrument Panel Knee Bolster Outer Bracket Replacement

Scheme 102

Scheme 102: Instrument Panel Knee Bolster Replacement (Encore)
Scheme 102: Instrument Panel Knee Bolster Replacement (Encore)
CalloutComponent Name
1Instrument Panel Knee Bolster Fastener (Qty: 3) CAUTION: Refer to Fastener Caution .
2Instrument Panel Knee Bolster Procedure Use a flat bladed plastic trim tool in order to release the retainers securing the knee bolster to the instrument panel assembly. Disconnect the data link connector.
CAUTION
Refer to Fastener Caution .

Instrument Panel Knee Bolster Replacement (Encore)

Scheme 103

Scheme 103: Instrument Panel Knee Bolster Replacement (Trax)
Scheme 103: Instrument Panel Knee Bolster Replacement (Trax)
CalloutComponent Name
1Instrument Panel Knee Bolster Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 2.5 (22 lb in)
2Instrument Panel Knee Bolster Procedure Use a flat bladed plastic trim tool in order to release the retainers securing the knee bolster to the instrument panel assembly. Disconnect the data link connector.
CAUTION
Refer to Fastener Caution .

Instrument Panel Knee Bolster Replacement (Trax)

Scheme 104

Scheme 104: Instrument Panel Trim Plate Replacement (Trax)
Scheme 104: Instrument Panel Trim Plate Replacement (Trax)
CalloutComponent Name
1Instrument Panel Trim Plate Procedure Use a flat bladed plastic trim tool to aid in the removal of the trim plate from the instrument panel assembly.

Instrument Panel Trim Plate Replacement (Trax)

Scheme 105

Scheme 105: Instrument Panel Trim Plate Replacement (Encore)
Scheme 105: Instrument Panel Trim Plate Replacement (Encore)
CalloutComponent Name
1Instrument Panel Trim Plate Procedures Use a flat bladed plastic trim tool to aid in the removal of the trim plate from the instrument panel assembly. Disconnect the electrical connection.

Instrument Panel Trim Plate Replacement (Encore)

Removal Procedure

  1. Remove the instrument panel assembly. Refer to «Instrument Panel Assembly Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  2. Remove the windshield defroster outlet duct. Refer to «Windshield Defroster Outlet Duct Replacement»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  3. Remove the instrument panel bolts (1).
  4. Remove the instrument panel bolts (1).
  5. Use a flat bladed plastic trim tool to aid in the removal of the upper trim panel from the instrument panel assembly.
  6. Transfer the airbag instrument panel module. Refer to «Airbag Instrument Panel Module Replacement»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system) .

Installation Procedure

  1. Install the instrument panel bolts (1).
  2. Install the instrument panel bolts (1).
  3. Install the windshield defroster outlet duct. Refer to «Windshield Defroster Outlet Duct Replacement»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  4. Install the instrument panel. Refer to «Instrument Panel Assembly Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  1. Remove the instrument panel assembly. Refer to «Instrument Panel Assembly Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  2. Remove the windshield defroster outlet duct. Refer to «Windshield Defroster Outlet Duct Replacement»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  3. Remove the airbag instrument panel module. Refer to «Airbag Instrument Panel Module Replacement»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system) .
  4. Remove the instrument panel bolts (1).
  5. Remove the instrument panel bolts (1).
  6. Use a flat bladed plastic trim tool to aid in the removal of the upper trim panel from the instrument panel assembly.
  1. Install the instrument panel bolts (1).
  2. Install the instrument panel bolts (1).
  3. Install the airbag instrument panel module. Refer to «Airbag Instrument Panel Module Replacement»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system) .
  4. Install the windshield defroster outlet duct. Refer to «Windshield Defroster Outlet Duct Replacement»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  5. Install the instrument panel. Refer to «Instrument Panel Assembly Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .

Scheme 106

Scheme 106: Instrument Panel Upper Trim Panel Cover Replacement (UAG)
Scheme 106: Instrument Panel Upper Trim Panel Cover Replacement (UAG)
CalloutComponent Name
1Instrument Panel Upper Trim Panel Cover Procedure Use a flat bladed plastic trim tool to aid in the removal of the cover from the instrument panel assembly.

Instrument Panel Upper Trim Panel Cover Replacement (UAG)

Scheme 107

Scheme 107: Instrument Panel Upper Trim Panel Cover Replacement (UDN)
Scheme 107: Instrument Panel Upper Trim Panel Cover Replacement (UDN)
CalloutComponent Name
1Instrument Panel Upper Trim Panel Cover Procedure Use a flat bladed plastic trim tool to aid in the removal of the cover from the instrument panel assembly.

Instrument Panel Upper Trim Panel Cover Replacement (UDN)

Scheme 108

Scheme 108: Instrument Panel Upper Trim Panel Bracket Replacement (UAG)
Scheme 108: Instrument Panel Upper Trim Panel Bracket Replacement (UAG)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel upper trim panel cover. Refer to Instrument Panel Upper Trim Panel Cover Replacement (UAG) .
1Driver Information Display Bezel Fasteners (Qty: 5) CAUTION: Refer to Fastener Caution . Procedures Use a flat bladed plastic trim tool to aid in the removal of the instrument panel upper trim panel bracket from the instrument panel assembly. Disconnect the electrical connections.
2Instrument Panel Upper Trim Panel Bracket
CAUTION
Refer to Fastener Caution .

Instrument Panel Upper Trim Panel Bracket Replacement (UAG)

Scheme 109

Scheme 109: Instrument Panel Upper Trim Panel Bracket Replacement (UDN)
Scheme 109: Instrument Panel Upper Trim Panel Bracket Replacement (UDN)
CalloutComponent Name
Preliminary Procedure Remove the instrument panel upper trim panel cover. Refer to Instrument Panel Upper Trim Panel Cover Replacement (UDN) .
1Driver Information Display Bezel Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution . Procedures Use a flat bladed plastic trim tool to aid in the removal of the instrument panel upper trim panel bracket from the instrument panel assembly. Disconnect the electrical connections.
2Instrument Panel Upper Trim Panel Bracket
CAUTION
Refer to Fastener Caution .

Instrument Panel Upper Trim Panel Bracket Replacement (UDN)

Scheme 110

Scheme 110: Instrument Panel Outer Trim Cover Replacement (Trax)
Scheme 110: Instrument Panel Outer Trim Cover Replacement (Trax)
CalloutComponent Name
1Instrument Panel Outer Trim Cover - Left Procedure Use a flat bladed plastic trim tool, start releasing the panel from the bottom working toward the top. Once at the top, carefully release the hook retaining feature.
2Instrument Panel Outer Trim Cover - Right Procedure Use a flat bladed plastic trim tool, start releasing the panel from the bottom working toward the top. Once at the top, carefully release the hook retaining feature.

Instrument Panel Outer Trim Cover Replacement (Trax)

Scheme 111

Scheme 111: Instrument Panel Outer Trim Cover Replacement (Encore)
Scheme 111: Instrument Panel Outer Trim Cover Replacement (Encore)
CalloutComponent Name
1Instrument Panel Outer Trim Cover - Left Procedure Use a flat bladed plastic trim tool, start releasing the panel from the bottom working toward the top. Once at the top, carefully release the hook retaining feature.
2Instrument Panel Outer Trim Cover - Right Procedure Use a flat bladed plastic trim tool, start releasing the panel from the bottom working toward the top. Once at the top, carefully release the hook retaining feature.

Instrument Panel Outer Trim Cover Replacement (Encore)

Scheme 112

Scheme 112: Instrument Panel Upper Compartment Replacement (Encore)
Scheme 112: Instrument Panel Upper Compartment Replacement (Encore)
CalloutComponent Name
1Instrument Panel Upper Compartment Mat Procedure Remove the mat to access the fasteners.
2Instrument Panel Upper Compartment Fasteners (Qty: 3) CAUTION: Refer to Fastener Caution .
3Instrument Panel Upper Compartment Procedure Use a flat bladed plastic trim tool to aid in the removal of the compartment from the instrument panel assembly.
CAUTION
Refer to Fastener Caution .

Instrument Panel Upper Compartment Replacement (Encore)

Scheme 113

Scheme 113: Instrument Panel Upper Compartment Replacement (Trax)
Scheme 113: Instrument Panel Upper Compartment Replacement (Trax)
CalloutComponent Name
Preliminary Procedure Remove the audio disc player and USB receptacle. Refer to Audio Disc Player and USB Receptacle Replacement (Trax) .
1Instrument Panel Upper Compartment Mat Procedure Remove the mat to access the fasteners.
2Instrument Panel Upper Compartment Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
3Instrument Panel Upper Compartment Procedure Use a flat bladed plastic trim tool to aid in the removal of the compartment from the instrument panel assembly.
CAUTION
Refer to Fastener Caution .

Instrument Panel Upper Compartment Replacement (Trax)

Scheme 114

Scheme 114: Instrument Panel Upper Center Compartment Replacement
Scheme 114: Instrument Panel Upper Center Compartment Replacement
CalloutComponent Name
Preliminary Procedure Remove the Instrument Panel Trim Plate. Refer to Instrument Panel Trim Plate Replacement (Trax) , Instrument Panel Trim Plate Replacement (Encore) .
1Instrument Panel Upper Center Compartment Liner
2Instrument Panel Upper Center Compartment Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
3Instrument Panel Upper Center Compartment
CAUTION
Refer to Fastener Caution .

Instrument Panel Upper Center Compartment Replacement

Scheme 115

Scheme 115: Instrument Panel Compartment Replacement
Scheme 115: Instrument Panel Compartment Replacement
CalloutComponent Name
Preliminary Procedure Open the instrument panel compartment to the full open position. Disconnect the instrument panel compartment dampener from the compartment assembly by depressing the tabs on the compartment and sliding the dampener rod off.
1Instrument Panel Compartment Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 (22 lb in) Procedure To access the fasteners, squeeze the sides of the compartment assembly and allow the compartment to lower past the compartment stops.
2Instrument Panel Compartment Procedure When replacing the instrument panel compartment, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Instrument Panel Compartment Replacement

  1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
  2. Remove both of the windshield garnish moldings (1). Refer to «Windshield Garnish Molding Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  3. Remove the front floor console (2). Refer to «Front Floor Console Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  4. Remove the front floor console stowage tray (2). Refer to «Front Floor Console Stowage Tray Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  5. Remove the instrument panel outer trim covers (1) left side and (2) right side. Refer to «Instrument Panel Outer Trim Cover Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  6. Remove the instrument panel upper center compartment (3). Refer to «Instrument Panel Upper Center Compartment Replacement»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  7. Remove the radio (2). Refer to «Radio Replacement (Encore)»(/buick/encore/i-2012-2016/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) , «Radio Replacement (Trax)»(/buick/encore/i-2012-2016/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  8. Remove the instrument panel lower center trim plate applique (2). Refer to «Instrument Panel Lower Center Trim Plate Applique Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  9. Remove the instrument panel upper compartment (3). Refer to «Instrument Panel Upper Compartment Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  10. Remove the instrument panel compartment (2). Refer to «Instrument Panel Compartment Replacement»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  11. Remove the instrument panel outer air outlets (1) left side and (2) right side. Refer to «Instrument Panel Outer Air Outlet Replacement (Trax)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  12. Remove the steering column. Refer to «Steering Column Replacement (Mexico, N40)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) , «Steering Column Replacement (Canada, NJ1)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) , «Steering Column Replacement (United States, NJ1)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  13. Remove the instrument cluster (2). Refer to «Instrument Cluster Replacement (Trax)»(/buick/encore/i-2012-2016/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges) .
  14. Remove the headlamp switch (1). Refer to «Headlamp Switch Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exterior-lights/#lighting-system-repair-instructions) .
  15. Remove the sun load temperature sensor bezel (1). Refer to «Sun Load Temperature Sensor Bezel Replacement (Trax)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#hvac-system-automatic) .
  16. Remove the instrument panel bolts (1).
  17. Remove the instrument panel inflatable restraint module bracket bolts (1).
  18. Remove the instrument panel compartment door latch striker bolt (2).
  19. Disconnect the inflatable restraint module connector from the instrument panel harness.
  20. Note the location and routing of the instrument panel electrical harness assembly, to ensure proper reinstallation.
  21. Disconnect the fasteners securing the instrument panel electrical harness assembly to the instrument panel and position out of the way.
  22. Reposition the body side front side door weatherstrip on both side in the area that the instrument panel assembly is the widest to allow clearance.
  23. With the aid of an assistant lift the instrument panel (1) rearward and upward from the tie bar assembly.
  24. Remove the instrument panel from the vehicle.
  25. Transfer all necessary components.
  1. With the aid of an assistant, load the instrument panel (1) to the instrument panel tie bar to the locator pins.
  2. Reposition the instrument panel wiring harness into the vehicle position as was noted in the removal and connect the fasteners securing the instrument panel wiring harness to the instrument carrier (1).
  3. Install the instrument panel bolts (1).
  4. Install the instrument panel inflatable restraint module bracket bolts (1) and tighten to 9 N.m (80 lb in).
  5. Install the instrument panel compartment door latch striker bolt (2) and tighten to 9 N.m (80 lb in).
  6. Install the sun load temperature sensor bezel (1). Refer to «Sun Load Temperature Sensor Bezel Replacement (Trax)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#hvac-system-automatic) .
  7. Install the headlamp switch (1). Refer to «Headlamp Switch Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exterior-lights/#lighting-system-repair-instructions) .
  8. Install the instrument cluster (2). Refer to «Instrument Cluster Replacement (Trax)»(/buick/encore/i-2012-2016/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges) .
  9. Install the steering column. Refer to «Steering Column Replacement (Mexico, N40)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) , «Steering Column Replacement (Canada, NJ1)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) , «Steering Column Replacement (United States, NJ1)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  10. Install the instrument panel outer air outlets (1) left side and (2) right side. Refer to «Instrument Panel Outer Air Outlet Replacement (Trax)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  11. Install the instrument panel compartment (2). Refer to «Instrument Panel Compartment Replacement»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  12. Install the instrument panel upper compartment (3). Refer to «Instrument Panel Upper Compartment Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  13. Install the instrument panel lower center trim plate applique (2). Refer to «Instrument Panel Lower Center Trim Plate Applique Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  14. Install the radio (2). Refer to «Radio Replacement (Trax)»(/buick/encore/i-2012-2016/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  15. Install the instrument panel upper center compartment (3). Refer to «Instrument Panel Upper Center Compartment Replacement»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  16. Install the instrument panel outer trim covers (1) left side and (2) right side. Refer to «Instrument Panel Outer Trim Cover Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  17. Install the front floor console stowage tray (2). Refer to «Front Floor Console Stowage Tray Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  18. Install the front floor console (2). Refer to «Front Floor Console Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  19. Install both of the windshield garnish moldings (1). Refer to «Windshield Garnish Molding Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  20. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
  1. Disable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
  2. Remove both of the windshield garnish moldings (1). Refer to «Windshield Garnish Molding Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  3. Remove the front floor console (3). Refer to «Front Floor Console Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  4. Remove the front floor console stowage tray (2). Refer to «Front Floor Console Stowage Tray Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  5. Remove the instrument panel outer trim covers (1) left side and (2) right side. Refer to «Instrument Panel Outer Trim Cover Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  6. Remove the radio (2). Refer to «Radio Replacement (Encore)»(/buick/encore/i-2012-2016/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  7. Remove the instrument panel lower center trim plate applique (2). Refer to «Instrument Panel Lower Center Trim Plate Applique Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  8. Remove the UAG instrument panel upper trim panel bracket (2), if equipped. Refer to «Instrument Panel Upper Trim Panel Bracket Replacement (UAG)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim)
  9. Remove the UDN instrument panel upper trim panel bracket (2), if equipped. Refer to «Instrument Panel Upper Trim Panel Bracket Replacement (UDN)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim)
  10. Remove the instrument panel upper compartment (3). Refer to «Instrument Panel Upper Compartment Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  11. Remove the instrument panel compartment (2). Refer to «Instrument Panel Compartment Replacement»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  12. Remove the instrument panel center air outlet (1). Refer to «Instrument Panel Center Air Outlet Replacement (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  13. Remove the instrument panel outer air outlets (1) left side and (2) right side. Refer to «Instrument Panel Outer Air Outlet Replacement (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  14. Remove the steering column. Refer to «Steering Column Replacement (Mexico, N40)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) , «Steering Column Replacement (Canada, NJ1)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) , «Steering Column Replacement (United States, NJ1)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  15. Remove the instrument cluster (2). Refer to «Instrument Cluster Replacement (Encore)»(/buick/encore/i-2012-2016/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges) .
  16. Remove the headlamp switch (1). Refer to «Headlamp Switch Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exterior-lights/#lighting-system-repair-instructions) .
  17. Remove the instrument panel bolts (1).
  18. Remove the instrument panel inflatable restraint module bracket bolts (1).
  19. Remove the instrument panel compartment door latch striker bolt (2).
  20. Note the location and routing of the instrument panel electrical harness assembly, to ensure proper reinstallation.
  21. Disconnect the fasteners securing the instrument panel electrical harness assembly to the instrument panel and position out of the way.
  22. With the aid of an assistant lift the instrument panel (1) rearward and upward from the tie bar assembly.
  23. Remove the instrument panel from the vehicle.
  24. Transfer all necessary components.
  1. With the aid of an assistant, load the instrument panel (1) to the instrument panel tie bar to the locator pins.
  2. Reposition the instrument panel wiring harness into the vehicle position as was noted in the removal and connect the fasteners securing the instrument panel wiring harness to the instrument carrier.
  3. Install the instrument panel bolts (1).
  4. Install the instrument panel inflatable restraint module bracket bolts (1) and tighten to 9 N.m (80 lb in).
  5. Install the instrument panel compartment door latch striker bolt (2) and tighten to 9 N.m (80 lb in).
  6. Install the headlamp switch (1). Refer to «Headlamp Switch Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exterior-lights/#lighting-system-repair-instructions) .
  7. Install the instrument cluster (2). Refer to «Instrument Cluster Replacement (Encore)»(/buick/encore/i-2012-2016/remont/gauges-instrument-panels/#instrument-panel-system-displays-and-gauges) .
  8. Install the steering column. Refer to «Steering Column Replacement (Mexico, N40)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) , «Steering Column Replacement (Canada, NJ1)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) , «Steering Column Replacement (United States, NJ1)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  9. Install the instrument panel center air outlet (1). Refer to «Instrument Panel Center Air Outlet Replacement (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  10. Install the instrument panel outer air outlets (1) left side and (2) right side. Refer to «Instrument Panel Outer Air Outlet Replacement (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  11. Install the instrument panel compartment (2). Refer to «Instrument Panel Compartment Replacement»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  12. Install the instrument panel upper compartment (3). Refer to «Instrument Panel Upper Compartment Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  13. Install the UDN instrument panel upper trim panel bracket (2), if equipped. Refer to «Instrument Panel Upper Trim Panel Bracket Replacement (UDN)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim)
  14. Install the UAG instrument panel upper trim panel bracket (2), if equipped. Refer to «Instrument Panel Upper Trim Panel Bracket Replacement (UAG)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim)
  15. Install the instrument panel lower center trim plate applique (2). Refer to «Instrument Panel Lower Center Trim Plate Applique Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  16. Install the radio (2). Refer to «Radio Replacement (Encore)»(/buick/encore/i-2012-2016/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  17. Install the instrument panel outer trim covers (1) left side and (2) right side. Refer to «Instrument Panel Outer Trim Cover Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  18. Install the front floor console stowage tray (2). Refer to «Front Floor Console Stowage Tray Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  19. Install the front floor console (3). Refer to «Front Floor Console Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  20. Install both of the windshield garnish moldings (1). Refer to «Windshield Garnish Molding Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  21. Enable the SIR system. Refer to «SIR Disabling and Enabling»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system__sir-disabling-and-enabling) .
  1. Remove the left instrument panel outer air outlet. Refer to «Instrument Panel Outer Air Outlet Replacement (Trax)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) , «Instrument Panel Outer Air Outlet Replacement (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  2. Remove the left instrument panel outer trim cover. Refer to «Instrument Panel Outer Trim Cover Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  3. Remove the steering column upper trim cover. Refer to «Steering Column Upper Trim Cover Replacement (Encore)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  4. Remove the bolts (1) to loosen the instrument panel upper trim panel.
  5. Use a flat bladed plastic trim tool to aid in the removal of the left instrument panel retainer (1) from the instrument panel assembly.
  6. Disconnect the electrical connection.
  7. Remove the instrument panel retainer (1) after getting the space by pulling out the instrument upper trim panel.
  1. Install the instrument panel retainer (1) to the instrument panel assembly.
  2. Connect the electrical connection.
  3. Install the bolts (1) to the instrument panel upper trim panel.
  4. Install the steering column upper trim cover. Refer to «Steering Column Upper Trim Cover Replacement (Encore)»(/buick/encore/i-2012-2016/remont/ignition-switchsteering-lock/#steering-wheel-and-steering-column) .
  5. Install the left instrument panel outer trim cover. Refer to «Instrument Panel Outer Trim Cover Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  6. Install the left instrument panel outer air outlet. Refer to «Instrument Panel Outer Air Outlet Replacement (Trax)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) , «Instrument Panel Outer Air Outlet Replacement (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  1. Remove the right instrument panel outer air outlet. Refer to «Instrument Panel Outer Air Outlet Replacement (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  2. Remove the right instrument panel outer trim cover. Refer to «Instrument Panel Outer Trim Cover Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  3. Remove the instrument panel upper compartment. Refer to «Instrument Panel Upper Compartment Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  4. Remove the radio control. Refer to «Radio Control Assembly Replacement»(/buick/encore/i-2012-2016/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  5. Remove the instrument panel center air outlet. Refer to «Instrument Panel Center Air Outlet Replacement (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  6. Remove the bolts (1) to loosen the instrument panel upper trim panel.
  7. Use a flat bladed plastic trim tool to aid in the removal of the right instrument panel retainer (1) from the instrument panel assembly.
  8. Disconnect the electrical connection.
  9. Carefully lift up the instrument panel upper trim panel enough to remove the instrument panel retainer (1).
  1. Install the instrument panel retainer (1) to the instrument panel assembly.
  2. Connect the electrical connection.
  3. Install the bolts (1) to the instrument panel upper trim panel and radio control assembly.
  4. Install the instrument panel center air outlet. Refer to «Instrument Panel Center Air Outlet Replacement (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  5. Install the radio control. Refer to «Radio Control Assembly Replacement»(/buick/encore/i-2012-2016/remont/entertainment-systems/#cellular-system-entertainment-system-and-navigation-system) .
  6. Install the instrument panel upper compartment. Refer to «Instrument Panel Upper Compartment Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  7. Install the left instrument panel outer trim cover. Refer to «Instrument Panel Outer Trim Cover Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  8. Install the left instrument panel outer air outlet. Refer to «Instrument Panel Outer Air Outlet Replacement (Encore)»(/buick/encore/i-2012-2016/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
  1. Remove the Instrument panel assembly. Refer to «Instrument Panel Assembly Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) , «Instrument Panel Assembly Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  2. Remove the instrument panel lower trim panel insulator. Refer to «Instrument Panel Lower Trim Panel Insulator Replacement»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  3. Remove the passenger side inflatable restraint instrument panel lower module, if equipped. Refer to «Instrument Panel Lower Airbag Replacement - Passenger Side (AYF)»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system)
  4. Unsnap the instrument panel fuse block (1) and disconnect harness from the instrument panel tie bar assembly and position out of the way.
  5. Remove the air inlet grill panel. Refer to «Air Inlet Grille Panel Replacement (Trax)»(/buick/encore/i-2012-2016/remont/wiperwasher-systems/#wiper-system-and-washer-system) , «Air Inlet Grille Panel Replacement (Encore)»(/buick/encore/i-2012-2016/remont/wiperwasher-systems/#wiper-system-and-washer-system) .
  6. Remove the nut (1) securing the instrument panel tie bar assembly to the cowl panel.
  7. Remove the bolts (1) securing the instrument panel tie bar assembly to the brake pedal bracket.
  8. Remove bolt (1) securing the instrument panel tie bar to the brake pedal mounting bracket.
  9. Remove the bolts (1) securing the right and left instrument panel tie bar lower support brackets (2) to the front floor tunnel panel.
  10. Remove the fasteners (1) securing the instrument panel tie bar assembly to the HVAC module.
  11. Remove the bolts (1) securing the instrument panel tie bar assembly to the vehicle body.
  12. Note the location and routing of the instrument panel wiring harness in order to ensure proper installation.
  13. Support the HVAC module in order to prevent damage.
  14. With the aid of an assistant remove the instrument panel tie bar assembly from the vehicle.
  1. With the aid of an assistant position the instrument panel tie bar assembly into the vehicle.
  2. Install the instrument panel wiring harness assembly to its in vehicle position as it was noted in the removal procedure.
  3. Loosely install the bolts (1) securing the instrument panel tie bar assembly to the vehicle body.
  4. Loosely install the fasteners (1) securing the instrument panel tie bar assembly to the HVAC module.
  5. Loosely install the bolts (1) securing the right and left instrument panel tie bar lower support brackets (2) to the front floor tunnel panel.
  6. Loosely install the bolt (1) securing the instrument panel tie bar to the brake pedal mounting bracket.
  7. Loosely install the bolts (1) securing the instrument panel tie bar assembly to the brake pedal bracket.
  8. Loosely install the nut (1) securing the instrument panel tie bar assembly to the cowl panel.
  9. Tighten the instrument panel tie bar to vehicle body bolts to 22Y (16 lb ft).
  10. Tighten the instrument panel tie bar to HVAC module fasteners to 9Y (80 lb in).
  11. Tighten the instrument panel tie bar lower support bracket to front floor tunnel panel bolts to 22Y (16 lb ft).
  12. Tighten the instrument panel tie bar to brake pedal mounting bracket bolt to 22Y (16 lb ft).
  13. Tighten the instrument panel tie bar assembly to the brake pedal bracket bolts to 9Y (80 lb in).
  14. Tighten the instrument panel tie bar assembly to the cowl panel nut to 22Y (16 lb ft).
  15. Install the instrument panel fuse block (1) onto the instrument panel tie bar assembly.
  16. Install the air inlet grill panel. Refer to «Air Inlet Grille Panel Replacement (Trax)»(/buick/encore/i-2012-2016/remont/wiperwasher-systems/#wiper-system-and-washer-system) , «Air Inlet Grille Panel Replacement (Encore)»(/buick/encore/i-2012-2016/remont/wiperwasher-systems/#wiper-system-and-washer-system) .
  17. Install the passenger side inflatable restraint instrument panel lower module, if equipped. Refer to «Instrument Panel Lower Airbag Replacement - Passenger Side (AYF)»(/buick/encore/i-2012-2016/remont/airbag/#supplemental-inflatable-restraint-system)
  18. Install the instrument panel lower trim panel insulator. Refer to «Instrument Panel Lower Trim Panel Insulator Replacement»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .
  19. Install the Instrument panel assembly. Refer to «Instrument Panel Assembly Replacement (Trax)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) , «Instrument Panel Assembly Replacement (Encore)»(/buick/encore/i-2012-2016/remont/exteriorinterior-trim/#instrument-panel-trim-and-console-trim) .

Scheme 116

Scheme 116: Front Floor Console Wiring Harness Replacement (Encore)
Scheme 116: Front Floor Console Wiring Harness Replacement (Encore)
CalloutComponent Name
1Front Floor Console Refer to Front Floor Console Replacement (Encore)
2Front Floor Console Wiring Harness

Front Floor Console Wiring Harness Replacement (Encore)

Scheme 117

Scheme 117: Front Floor Console Wiring Harness Replacement (Trax)
Scheme 117: Front Floor Console Wiring Harness Replacement (Trax)
CalloutComponent Name
1Front Floor Console Refer to Front Floor Console Replacement (Trax) .
2Front Floor Console Wiring Harness

Front Floor Console Wiring Harness Replacement (Trax)

Scheme 118

Scheme 118: Front Floor Console Stowage Tray Replacement (Encore)
Scheme 118: Front Floor Console Stowage Tray Replacement (Encore)
CalloutComponent Name
Preliminary Procedure Remove the front floor console. Refer to Front Floor Console Replacement (Encore) .
1Front Floor Console Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
2Front Floor Console Stowage Tray Procedure Disconnect electrical connections and transfer all necessary components, if equipped.
CAUTION
Refer to Fastener Caution .

Front Floor Console Stowage Tray Replacement (Encore)

Scheme 119

Scheme 119: Front Floor Console Stowage Tray Replacement (Trax)
Scheme 119: Front Floor Console Stowage Tray Replacement (Trax)
CalloutComponent Name
Preliminary Procedure Remove the front floor console. Refer to Front Floor Console Replacement (Trax) .
1Front Floor Console Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2.5 (22 lb in)
2Front Floor Console Stowage Tray Procedure Disconnect electrical connections and transfer all necessary components, if equipped.
CAUTION
Refer to Fastener Caution .

Front Floor Console Stowage Tray Replacement (Trax)

Scheme 120

Scheme 120: Front Floor Console Cup Holder Replacement (Encore)
Scheme 120: Front Floor Console Cup Holder Replacement (Encore)
CalloutComponent Name
1Front Floor Console Refer to Front Floor Console Replacement (Encore) .
2Front Floor Console Cup Holder Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution .
3Front Floor Console Cup Holder
CAUTION
Refer to Fastener Caution .

Front Floor Console Cup Holder Replacement (Encore)

Scheme 121

Scheme 121: Front Floor Console Cup Holder Replacement (Trax)
Scheme 121: Front Floor Console Cup Holder Replacement (Trax)
CalloutComponent Name
1Front Floor Console Bracket Refer to Front Floor Console Bracket Replacement (Trax) .
2Front Floor Console Cup Holder Fasteners (Qty: 10) CAUTION: Refer to Fastener Caution .
3Front Floor Console Cup Holder Procedure Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Front Floor Console Cup Holder Replacement (Trax)

Scheme 122

Scheme 122: Front Floor Console Compartment Liner Replacement (Encore)
Scheme 122: Front Floor Console Compartment Liner Replacement (Encore)
CalloutComponent Name
Preliminary Procedure Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement (Encore) .
1Front Floor Console Compartment Liner

Front Floor Console Compartment Liner Replacement (Encore)

Scheme 123

Scheme 123: Front Floor Console Compartment Liner Replacement (Trax)
Scheme 123: Front Floor Console Compartment Liner Replacement (Trax)
CalloutComponent Name
Preliminary Procedure Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement (Trax) .
1Front Floor Console Compartment Liner

Front Floor Console Compartment Liner Replacement (Trax)

Scheme 124

Scheme 124: Front Floor Console Center Compartment Replacement (Encore)
Scheme 124: Front Floor Console Center Compartment Replacement (Encore)
CalloutComponent Name
Preliminary Procedures Remove the front floor console wiring harness. Refer to Front Floor Console Wiring Harness Replacement (Encore) . Remove the accessory power receptacle. Refer to Accessory Power Receptacle Replacement .
1Front Floor Console Refer to Front Floor Console Replacement (Encore) .
2Front Floor Console Center Compartment Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution .
3Front Floor Console Bracket
4Front Floor Console Center Compartment
CAUTION
Refer to Fastener Caution .

Front Floor Console Center Compartment Replacement (Encore)

Scheme 125

Scheme 125: Front Floor Console Extension Replacement - Right Side
Scheme 125: Front Floor Console Extension Replacement - Right Side
CalloutComponent Name
1Front Floor Console Extension Panel Procedure Use a flat bladed plastic trim tool in order to release the retainers securing the extension panel to the front floor console assembly.

Front Floor Console Extension Replacement - Right Side

Scheme 126

Scheme 126: Front Floor Console Extension Replacement - Left Side
Scheme 126: Front Floor Console Extension Replacement - Left Side
CalloutComponent Name
1Front Floor Console Clip
2Front Floor Console Extension Panel Procedure Use a flat bladed plastic trim tool in order to release the retainers securing the extension panel to the front floor console assembly.

Front Floor Console Extension Replacement - Left Side

Scheme 127

Scheme 127: Front Floor Console Parking Brake Lever Opening Cover Replacement (Encore)
Scheme 127: Front Floor Console Parking Brake Lever Opening Cover Replacement (Encore)
CalloutComponent Name
1Front Floor Console Parking Brake Lever Opening Cover Procedure Use a flat bladed plastic trim tool on the outside edge of the cover and lift the cover up and out from the floor console.

Front Floor Console Parking Brake Lever Opening Cover Replacement (Encore)

Scheme 128

Scheme 128: Front Floor Console Replacement (Encore)
Scheme 128: Front Floor Console Replacement (Encore)
CalloutComponent Name
Preliminary Procedures Remove both front floor console extension panels. Refer to Front Floor Console Extension Replacement - Left Side , and Front Floor Console Extension Replacement - Right Side . Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement (Encore) . Remove the front floor console parking brake lever opening cover. Refer to Front Floor Console Parking Brake Lever Opening Cover Replacement (Encore) .
1Front Floor Console Cup Holder Procedure Lift up the cup holder liner and trim plate to access the fastener from the floor console.
2Front Floor Console Fasteners (Qty: 9) CAUTION: Refer to Fastener Caution . Procedures Position the front seats as necessary to access the console bolt access hole covers and fasteners. Use a flat bladed plastic trim tool to open the front floor console bolt access hole cover to access the fasteners from the rear of the floor console.
3Front Floor Console Procedures Set the park brake lever. Place the shift control rearward. Disconnect electrical connections. With the aid of an assistant lift the floor console forward and over the park brake handle, then away from the instrument panel assembly.
CAUTION
Refer to Fastener Caution .

Front Floor Console Replacement (Encore)

Scheme 129

Scheme 129: Front Floor Console Replacement (Trax)
Scheme 129: Front Floor Console Replacement (Trax)
CalloutComponent Name
Preliminary Procedures Remove both front floor console extension panels. Refer to Front Floor Console Extension Replacement - Left Side , and Front Floor Console Extension Replacement - Right Side . Remove the front floor console trim plate. Refer to Front Floor Console Trim Plate Replacement (Trax) .
1Front Floor Console Fasteners (Qty: 8) CAUTION: Refer to Fastener Caution . Tighten 2.5 (22 lb in) Procedures Position seats as necessary to access hole covers and fasteners. Use a flat bladed plastic trim tool to open the front floor console bolt access hole cover to access the fasteners from the rear of the floor console.
2Front Floor Console Procedures Disconnect electrical connections. Apply the parking brake. Place the transmission shift control rearward. With the aid of an assistant lift the floor console forward and over the park brake handle and away from the instrument panel assembly.
CAUTION
Refer to Fastener Caution .

Front Floor Console Replacement (Trax)

Scheme 130

Scheme 130: Front Floor Console Bracket Replacement (Encore)
Scheme 130: Front Floor Console Bracket Replacement (Encore)
CalloutComponent Name
Preliminary Procedures Remove the front floor console wiring harness. Refer to Front Floor Console Wiring Harness Replacement (Encore) . Remove the accessory power receptacle. Refer to Accessory Power Receptacle Replacement .
1Front Floor Console Refer to Front Floor Console Replacement (Encore) .
2Front Floor Console Bracket Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
3Front Floor Console Bracket
CAUTION
Refer to Fastener Caution .

Front Floor Console Bracket Replacement (Encore)

Scheme 131

Scheme 131: Front Floor Console Bracket Replacement (Trax)
Scheme 131: Front Floor Console Bracket Replacement (Trax)
CalloutComponent Name
1Front Floor Console Refer to Front Floor Console Replacement (Trax) .
2Front Floor Console Bracket Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution .
3Front Floor Console Bracket Procedure Disconnect the electrical connection.
CAUTION
Refer to Fastener Caution .

Front Floor Console Bracket Replacement (Trax)

Scheme 132

Scheme 132: Front Floor Console Trim Plate Replacement (Encore)
Scheme 132: Front Floor Console Trim Plate Replacement (Encore)
CalloutComponent Name
1Automatic Transmission Control Indicator Bezel Procedure Use a flat bladed plastic trim tool to aid in the release of the indicator bezel from the transmission control assembly.
2Front Floor Console Trim Plate Procedure Use a flat bladed plastic trim tool to aid in the removal of the trim plate from the front floor console assembly.

Front Floor Console Trim Plate Replacement (Encore)

Scheme 133

Scheme 133: Front Floor Console Trim Plate Replacement (Trax)
Scheme 133: Front Floor Console Trim Plate Replacement (Trax)
CalloutComponent Name
1Automatic Transmission Control Indicator Bezel Procedures Use a flat bladed plastic trim tool to aid in the release of the indicator bezel from the transmission control assembly. If equipped with a manual transmission refer to Transmission Control Lever Boot Replacement procedure.
2Front Floor Console Trim Plate Procedure Use a flat bladed plastic trim tool to aid in the removal of the trim plate from the front floor console assembly.

Front Floor Console Trim Plate Replacement (Trax)

Scheme 134

Scheme 134: Roof Console Replacement
Scheme 134: Roof Console Replacement
CalloutComponent Name
Preliminary Procedure Remove the center reading lamp. Refer to Center Reading Lamp Replacement .
1Roof Console Fasteners (Qty: 2) CAUTION: Refer to Fastener Caution .
2Roof Console Assembly Procedure Grasp the roof console assembly and pull downward releasing the retainer clips securing the roof console assembly to the headlining assembly. Disconnect the electrical connections. When replacing the roof console assembly, transfer all necessary components.
CAUTION
Refer to Fastener Caution .

Roof Console Replacement

More articles — Body & Frame
