Engine Mechanical - 3.6l - Timing Chain Alignment Routing Diagram Buick Enclave I

Mechanical 3 illustrations

Scheme 33

Scheme 33: Camshaft Position Actuator Timing Marks
Scheme 33: Camshaft Position Actuator Timing Marks
CalloutComponent Name
1Right Intake Camshaft Position Actuator Identifier
2Right Intake Camshaft Position Actuator Right Side Timing Mark- Triangle
3Left Intake Camshaft Position Actuator Left Side Timing Mark- Circle
4Left Intake Camshaft Position Actuator Identifier
5Exhaust Camshaft Position Actuator Identifier
6Exhaust Camshaft Position Actuator Right Side Timing Mark- Triangle
7Exhaust Camshaft Position Actuator Left Side Timing Mark- Circle

Scheme 34

Scheme 34: Stage One
Scheme 34: Stage One
CalloutComponent Name
1Left Intake Camshaft Position (CMP) Actuator Timing Mark- Circle
2Left Intake Secondary Camshaft Timing Drive Chain Timing Link
3Left Exhaust Secondary Camshaft Timing Drive Chain Timing Link
4Left Exhaust Camshaft Position (CMP) Actuator Timing Mark- Circle
5Left Secondary Camshaft Timing Drive Chain
6Primary Camshaft Drive Chain Timing Link for the Left Primary Camshaft Intermediate Drive Chain Sprocket
7Left Primary Camshaft Intermediate Drive Chain Sprocket Timing Mark for the Primary Camshaft Drive Chain
8Left Primary Camshaft Intermediate Drive Chain Sprocket
9Left Secondary Camshaft Timing Drive Chain Timing Link for the Left Primary Camshaft Intermediate Drive Chain Sprocket, behind hole in sprocket
10Left Primary Camshaft Intermediate Drive Chain Sprocket Timing Window for the Left Secondary Camshaft Timing Drive Chain Timing Link
11Primary Camshaft Drive Chain
12Primary Camshaft Drive Chain Timing Link for the Crankshaft Sprocket
13Crankshaft Sprocket Timing Mark
14Crankshaft Sprocket
15Right Primary Camshaft Intermediate Drive Chain Sprocket
16Primary Camshaft Drive Chain Timing Link for the Right Primary Camshaft Intermediate Drive Chain Sprocket
17Right Primary Camshaft Intermediate Drive Chain Sprocket Timing Mark

Scheme 35

Scheme 35: Stage Two
Scheme 35: Stage Two
CalloutComponent Name
1Left Intake Camshaft Position (CMP) Actuator Timing Mark- Circle
2Left Intake Secondary Camshaft Timing Drive Chain Timing Link
3Left Exhaust Secondary Camshaft Timing Drive Chain Timing Link
4Left Exhaust Camshaft Position (CMP) Actuator Timing Mark- Circle
5Left Secondary Camshaft Timing Drive Chain
6Primary Camshaft Drive Chain Timing Link for the Left Primary Camshaft Intermediate Drive Chain Sprocket
7Left Primary Camshaft Intermediate Drive Chain Sprocket Timing Mark for the Primary Camshaft Drive Chain
8Left Primary Camshaft Intermediate Drive Chain Sprocket
9Left Secondary Camshaft Timing Drive Chain Timing Link for the Left Primary Camshaft Intermediate Drive Chain Sprocket, behind hole in sprocket
10Left Primary Camshaft Intermediate Drive Chain Sprocket Timing Window
11Primary Camshaft Drive Chain
12Primary Camshaft Drive Chain Timing Link for the Crankshaft Sprocket
13Crankshaft Sprocket Timing Mark
14Crankshaft Sprocket
15Right Primary Camshaft Intermediate Drive Chain Sprocket
16Primary Camshaft Drive Chain Timing Link for the Right Primary Camshaft Intermediate Drive Chain Sprocket
17Right Primary Camshaft Intermediate Drive Chain Sprocket Timing Mark for the Primary Camshaft Drive Chain
18Right Primary Camshaft Intermediate Drive Chain Sprocket Timing Mark/Window for the Right Secondary Camshaft Timing Drive Chain
19Right Secondary Camshaft Timing Drive Chain Timing Link for the Right Primary Camshaft Intermediate Drive Chain Sprocket
20Right Secondary Camshaft Timing Drive Chain
21Right Exhaust Camshaft Position (CMP) Actuator Timing Mark- Triangle
22Right Exhaust Secondary Camshaft Timing Drive Chain Timing Link
23Right Intake Secondary Camshaft Timing Drive Chain Timing Link
24Right Intake Camshaft Position (CMP) Actuator Timing Mark- Triangle
