Engine Mechanical - 3.6l - Description and Operation Buick Enclave I

Scheme 84

A crankcase ventilation system is used to consume crankcase vapors created during the combustion process instead of venting them to the atmosphere.

Fresh air is supplied through a filter to the crankcase, the crankcase mixes the fresh air with the blow-by gases and then passed through a positive crankcase ventilation (PCV) orificed tube into the intake manifold.

The PCV orificed tube restricts the flow rate of the blow-by gases using a 3 mm (0.118 in) (a) orifice located at the end of the tube. If abnormal operating conditions arise, the system is designed to allow excessive amounts of blow-by gases to back flow through the crankcase vent tube into the throttle body in order to be consumed by normal combustion.

Drive Belt System Description

The drive belt system consists of the following components

1. The drive belt
2. The drive belt tensioner
3. The drive belt idler pulley
4. The crankshaft balancer pulley
5. The accessory drive component mounting brackets
6. The accessory drive components The power steering pump, if belt driven The generator The A/C compressor, if equipped The engine cooling fan, if belt driven The water pump, if belt driven The vacuum pump, if equipped The air compressor, if equipped

The drive belt system may use 1 belt or 2 belts. The drive belt is thin so that it can bend backwards and has several ribs to match the grooves in the pulleys. The drive belts are made of different types of rubbers, chloroprene or EPDM, and have different layers or plys containing either fiber cloth or cords for reinforcement.

Both sides of the drive belt may be used to drive the different accessory drive components. When the back side of the drive belt is used to drive a pulley, the pulley is smooth.

The drive belt is pulled by the crankshaft balancer pulley across the accessory drive component pulleys. The spring loaded drive belt tensioner keeps constant tension on the drive belt to prevent the drive belt from slipping. The drive belt tensioner arm will move when loads are applied to the drive belt by the accessory drive components and the crankshaft.

The drive belt system may have an idler pulley, which is used to add wrap to the adjacent pulleys. Some systems use an idler pulley in place of an accessory drive component when the vehicle is not equipped with the accessory.

Engine Component Description (LLT)

The High Feature V6 (VIN Code Identifier "D" ) RPO LLT is a 3.6L VVT (Variable Valve Timing) engine with direct injection. The direct injection system places the high pressure injectors in the cylinder heads. This engine incorporates 2 intake and 2 exhaust valves per cylinder and is a dual overhead cam design with individual intake and exhaust camshafts. The LLT is now E85-fuel-compatible, this only applies to the valves and seats, engine calibrations and other areas are NOT intended for E85. The E85-compatible valves and seats are installed to be compliant with fuel blends of E15 to E20 that may be mandated. A camshaft position actuator is mounted on each camshaft. The cylinders are arranged in 2 banks of 3 with a 60 degree included angle. The right bank of cylinders are number 1-3-5 and the left bank of cylinders are 2-4-6, viewed from the flywheel end of the engine. The engine firing order is 1-2-3-4-5-6.

Crankcase

The cylinder block is constructed of aluminum alloy by precision sand-casting with cast in place iron cylinder liners. Each steel main bearing cap incorporates 6 bolts bolting the cap into the engine block. Along with 2 outer and 2 inner bolts, 2 side bolts are used in the deep skirt block. To prevent aeration, oil return from the valvetrain and cylinder heads is channeled away from the rotating and reciprocating components through oil drain back passages incorporated into the cylinder heads and engine block. Pressure-actuated piston oil cooling jets are mounted between opposing cylinders. A knock sensor is located on each side of the exterior of the engine block. The crankshaft position sensor is located on the right side of the exterior of the engine block.

Crankshaft

The crankshaft is a hardened, forged steel design with 4 main bearings. Crankshaft thrust is controlled by the upper portion of number 3 main bearing. The crankshaft position reluctor wheel is pressed onto the rear of the crankshaft in front of the rear main journal. A micro encapsulated adhesive is used on the reluctor wheel to aid retention. The crankshaft is internally balanced, and has an integral oil pump drive machined into the nose in front of the front main journal.

Connecting Rods and Pistons

The connecting rods are steel and have full floating piston pins. The piston pins are a slip fit in the bronze bushed connecting rod. Round wire retainers are used to retain the piston pin into the piston. The cast aluminum pistons incorporate a polymer-coated skirt to reduce friction. The piston uses two low tension compression rings and one multi-piece oil control ring. The top of the piston contains a shaped portion for the direct injection system to aid in fuel-air charge mixture and even combustion.

Camshaft Drive System

The camshaft drive system consists of one primary timing drive chain driven by the crankshaft sprocket. The primary timing drive chain drives two intermediate drive shaft sprockets. Each intermediate drive shaft sprocket drives separate secondary timing drive chains. Each secondary timing drive chain drives the respective cylinder head's intake and exhaust camshaft position actuators.

The primary timing drive chain uses two stationary timing drive chain guides and a hydraulically-actuated tensioner with built-in shoe. The tensioner minimizes timing drive chain noise and provides accurate valve action by keeping slack out of the timing drive chains and continuously adjusting for timing drive chain wear. The tensioner incorporates a plunger that adjusts out with wear allowing only a minimal amount of backlash. The tensioner is equipped with an oiling jet to spray oil onto the timing components during engine operation. The secondary timing drive chains use a stationary timing drive chain guide and movable timing drive chain shoe. The secondary timing drive chain shoe is under tension from a hydraulically-actuated tensioner. All tensioners are sealed to the head or block using a rubber coated steel gasket. The gasket traps an adequate oil reserve to ensure quiet start-up.

Camshaft Position Actuator System

The engine incorporates a camshaft position actuator for each intake and exhaust camshaft. Camshaft phasing changes the inlet and exhaust valve timing as engine operating conditions vary. Dual camshaft phasing allows the further optimization of performance, fuel economy and emissions without compromising overall engine response and driveability. Variable valve timing also contributes to a reduction in exhaust emissions. It optimizes exhaust and inlet valve overlap and eliminates the need for an exhaust gas recirculation (EGR) system.

The camshaft position actuator is a hydraulic vane-type actuator that changes the camshaft lobe timing relative to the camshaft drive sprocket. Engine oil is directed by a camshaft position actuator oil control valve to the appropriate passages in the camshaft position actuator. Oil acting on the vane in the camshaft position actuator rotates the camshaft relative to the sprocket. At idle, both camshafts are at the default or "home" position. At this position, the exhaust camshaft is fully advanced and the intake is fully retarded to minimize valve overlap for smooth idle. An internal lock pin locks the inner rotor to the outer camshaft position actuator housing at idle and maintains this position during start-up conditions. Under other engine operating conditions, the camshaft position actuator is controlled by the engine control module (ECM) to deliver optimal intake and exhaust valve timing for performance, driveability and fuel economy. The camshaft position actuator incorporates an integral trigger wheel, which is sensed by the camshaft position sensor mounted in the front cover to accurately determine the position of each camshaft. Each camshaft position actuator has a specific timing drive mark for right or left bank application, as the camshaft position actuators are common bank to bank. The exhaust camshaft position actuator has a different internal configuration than the intake camshaft position actuator since the exhaust camshaft position actuator phases in the opposite direction relative to the inlet camshaft position actuator.

The camshaft position actuator oil control valve (OCV) directs oil from the oil feed in the head to the appropriate camshaft position actuator oil passages. There is one OCV for each camshaft position actuator. The OCV is sealed and mounted to the front cover. The ported end of the OCV is inserted into the cylinder head with a sliding fit. A filter screen protects each OCV oil port from any contamination in the oil supply.

The camshaft front journal has several drilled oil holes to allow camshaft position actuator control oil to transfer from the cylinder head to the camshaft position actuator. The center camshaft bolt hole is counterbored to allow oil to flow around the camshaft bolt and to the camshaft position actuator. Oil in this oil passage is used to move the camshaft position actuator to the default or home position. Radially outward from the center of the journal is a set of 4 drilled camshaft position actuator oil holes. Oil in this group of oil holes is used to move the camshaft from the default position to a specific set position as determined by the ECM. Seal rings are used at the front and rear of the front camshaft journal to prevent oil leakage from the camshaft position actuator hydraulic system. The seal is made from a plastic compound that resists wear and has a diagonal end gap to enhance sealing. The camshaft position actuator is mounted to the front end of the camshaft and the timing notch in the nose of the camshaft aligns with the dowel pin in the camshaft position actuator to ensure proper cam timing and camshaft position actuator oil hole alignment.

Cylinder Heads

The cylinder heads are cast aluminum with powdered metal valve seat inserts and valve guides. Two intake valves and two exhaust valves are actuated by roller finger followers pivoting on a stationary hydraulic lash adjuster (SHLA). Separate exhaust and intake camshafts are supported by bearings machined into the cylinder head. The front camshaft bearing cap is used as a thrust control surface for each camshaft. Each spark plug is shielded by a tube that is pressed into the cylinder head. Each spark plug ignition coil is also mounted through the spark plug tube. The engine coolant temperature (ECT) sensor is threaded into the cylinder head. Longer intake ports are designed into the head for better airflow and eliminate the need for a separate lower intake manifold. With direct injection, the high pressure injectors are located in machined bores below the intake ports. A stainless steel, high pressure fuel rail is attached to the intake side of the head. The E85 fuel compatible LLT engine has valves and seats constructed with specialized materials and coatings to perform properly in the E85, or lower blends, such as E15 or E20, fuel environment.

Induction System

The intake manifold assembly is used to deliver a dry-air charge to the combustion chamber. Fuel is introduced directly to the cylinder during the intake stroke. As the piston approaches top-dead center, the air-fuel mixture is ignited by the spark plug. An electronically controlled throttle (ETC), through the ECM, coordinates the input from the driver with various control components.

Right and Left Bank Designation

Right hand (RH) and left hand (LH) designation through the engine mechanical section are viewed from the rear of the engine or from inside the vehicle. These banks are also referred to as Bank 1 (RH) and Bank 2 (LH).

New Product Information

The purpose of New Product Information is to highlight or indicate important changes from the previous model year.

Changes may include one or more of the following items

1. Torque values and/or fastener tightening strategies
2. Changed engine specifications
3. New sealants and/or adhesives
4. Disassembly and assembly procedure revisions
5. Engine mechanical diagnostic procedure revisions
6. New special tools required
7. A component comparison from the previous year

Torque Values and/or Fastener Tightening Strategies

Some torque specifications have changed for this model year. Refer to Fastener Tightening Specifications .

Changed Engine Specifications

There have been no significant revisions to engine specifications. Refer to Engine Mechanical Specifications (LLT) .

New Sealants and/or Adhesives

There are no changes to the sealants and/or adhesives used for this model year. Refer to Adhesives, Fluids, Lubricants, and Sealers .

Disassembly and Assembly Procedure Revisions

Some procedures have been revised based on design changes in the LLT engine. Particular areas of note are

Engine valve and valve seat refurbishing has changed due to the E85-compatible valves and seats.

Engine Mechanical Diagnostic Procedure Revisions

Diagnosis on a vehicle should follow a logical process. Strategy based diagnostics is a uniform approach for repairing all systems. The diagnostic flow should always be used in order to resolve a system condition. The diagnostic flow is the place to start when repairs are necessary. For a detailed explanation, refer to Diagnostic Starting Point - Vehicle .

New Special Tools Required

There are no new special tools required for this model year.

A Component Comparison from the Previous Year

Saddle-cap style front cam caps and winged intermediate caps are used in all 2012 LLT engines. Installation procedures are very similar but the saddle caps require lubrication on both the fore and aft faces of the cap on reassembly. Winged intermediate caps install same as previous.

Refer to Engine Component Description (LLT) for additional information.

Lubrication Description

A structural diecast aluminum oil pan incorporates an oil suction tube and a windage tray. The oil suction tube is bolted into the oil pan and seals to the bottom of the block with O-ring gasket. The windage tray is bolted to the upper portion of the oil pan and reduces friction losses at high speed.

A crankshaft driven gerotor oil pump with internal pressure-relief valve is mounted to the front of the engine block and pulls oil from the oil suction tube through the lower passage in the engine block. The oil pump then directs the flow of pressurized oil back through the upper passage in the block to the left side of the engine block where the oil filter adapter is mounted.

An oil filter adapter is mounted with a gasket to the left side of the engine block.

RWD Applications : The oil filter adapter incorporates a top-access, cartridge style oil filter. The filter is accessed through a screw on cap with an O-ring gasket. The oil filter adapter cap has a built-in oil bypass valve. The oil filter adapter housing incorporates a drain back control valve and a threaded oil pressure sending unit. Oil flows through the lower passage in the oil filter adapter up to and through the oil filter cartridge. Filtered oil travels back through the upper passage of the oil filter adapter and back into the engine block.

FWD Applications : An oil filter adapter is mounted with a gasket to the left side of the engine block. The oil filter adapter incorporates a bottom-access, spin-on oil filter. The oil filter adapter housing incorporates a threaded oil pressure sending unit. Oil flows through the lower passage in the oil filter adapter to and through the oil filter. Filtered oil travels back through the upper passage of the oil filter adapter and back into the engine block.

Oil is directed up and across the engine block front through several drilled passages. These front passages feed oil to each cylinder head, oil to the passage for the main bearings and piston oil jets, oil to the right and left secondary idler sprockets, and oil to the primary timing drive chain tensioner.

Each cylinder head passage directs oil into the cylinder head where it is directed to oiling circuits for the stationary hydraulic lifter assemblies (SHLAs) and the camshaft bearing journals. Oil is also directed through 2 passages each with a spring-loaded check-ball valve to the 2 chambers where the camshaft position actuator oil control solenoid valves are mounted. Each chamber contains a camshaft position actuator oil control solenoid valve with built-in oil filter screen. One camshaft position actuator oil control solenoid valve is used to control the exhaust camshaft position actuator and 1 camshaft position actuator oil control solenoid valve is used to control the intake camshaft position actuator. The engine control module (ECM) electrically controls each camshaft position actuator oil control solenoid valve. When energized by the ECM the camshaft position actuator oil control solenoid valve directs oil to pass up through the cylinder head front camshaft bearing cap. Oil passes through the camshaft bearing cap passage into oil holes drilled into the side of the front camshaft journal and onto the front of the camshaft mounting surface. Oil passes through to matching passages in the camshaft position actuator. Oil is directed by the camshaft position actuator oil control solenoid valve to the appropriate passage in the system to pressurize oil on the vanes on the inside of the of the camshaft position actuator. Oil acting on the vanes rotates the camshaft mounted to the inner camshaft position actuator rotor relative to the sprocket mounted to the outer camshaft position actuator housing. An internal lock pin locks the inner rotor to the outer camshaft position actuator housing at idle and maintains the camshaft position actuator in the home or default position during start-up conditions. Oil pressure directed by the camshaft position actuator oil control solenoid valve unlocks the pin and allows the camshaft position actuator to function. An additional passage in the cylinder head also directs oil to the secondary timing drive chain tensioner mounted to each cylinder head.

The oil passage that supplies oil to the main bearings also supplies oil to pressure-actuated piston-cooling oil jets. Each oil jet is mounted between opposing cylinder bores and directs oil to the 2 bores to provide extra cooling and control piston temperatures.

Oil is directed from the front passages to the front of the block where the right and left secondary idler sprockets and the primary timing drive chain tensioner are mounted. Each camshaft timing drive chain tensioner relies on a gasket in order to maintain an oil reserve after the engine is turned OFF. All camshaft timing drive chain tensioners incorporate a small oil jet to supply an oil spray onto the camshaft timing drive chain components.

Oil returns to the oil pan sump either through the camshaft timing drive chain area or through the cast oil drain back passages on the outboard walls of the cylinder heads and engine block.

Cleanliness and Care

An automobile engine is a combination of many of the following surfaces

1. Machined
2. Honed
3. Polished
4. Lapped

The tolerances of these surfaces are measured in the ten-thousandths of an inch. When you service any internal engine part, cleanliness and care are important. Apply a liberal coating of engine oil to the friction areas during assembly in order to protect and lubricate the surfaces on initial operation. Throughout this section, practice proper cleaning and protection procedures to the machined surfaces and to the friction areas.

Whenever you remove the valve train components, keep the components in order. Follow this procedure in order to install the components in the same locations and with the same mating surfaces as when removed.

Disconnect the negative battery cables before you perform any major work on the engine.

Separating Parts

In addition to the room temperature vulcanizing (RTV) sealant's sealing capabilities, the RTV sealants may form an adhesive bond between the components. This may make the components difficult to remove or to separate. If possible, bump the components sideways rather than using prying tools in order to remove the components. This technique prevents damage when the bonding strength of the RTV sealant is stronger than the component itself. Perform bumping at the bends or at the reinforced areas in order to prevent part distortion.

Gasket Reuse and Applying Sealant

1. Do not reuse any gasket unless specified.
2. Gaskets that can be reused will be identified in the service procedure.
3. Do not apply sealant to any gasket or sealing surface unless specified in the service procedure.

Separating Components

1. Use a rubber mallet in order to separate the components.
2. Bump the part sideways in order to loosen the components.
3. Bumping of the component should be done at bends or reinforced areas of the component to prevent distortion of the components.

Cleaning Gasket Surfaces

1. Use care to avoid gouging or scraping the sealing surfaces.
2. Use a plastic or wood scraper in order to remove all the sealant from the components. Do not use any other method or technique to remove the sealant or the gasket material from a part.
3. Do not use abrasive pads, sand paper, or power tools to clean the gasket surfaces. These methods of cleaning can cause damage to the component sealing surfaces. Abrasive pads also produce a fine grit that the oil filter cannot remove from the engine oil. This fine grit is an abrasive and can cause internal engine damage.

Assembling Components

1. Assemble components using only the sealant (or equivalent) that is specified in the service procedure.
2. Sealing surfaces must be clean and free of debris or oil.
3. Specific components such as crankshaft oil seals or valve stem oil seals may require lubrication during assembly.
4. Components requiring lubrication will be identified in the service procedure.
5. Apply only the amount of sealant specified in the service procedure to a component.
6. Do not allow the sealant to enter into any blind threaded holes, as the sealant may prevent the fastener from clamping properly or cause component damage when tightened.
7. Tighten the fasteners to the proper specifications.

Sealant Types

Note. The correct sealant and amount of sealant must be used in the proper location to prevent oil leaks, coolant leaks, or the loosening of the fasteners. DO NOT interchange the sealants. Use only the sealant, or equivalent, as specified in the service procedure.

The following 2 major types of sealant are commonly used in engines

1. Anaerobic sealant room temperature vulcanizing (RTV)
2. Anaerobic sealant, which include the following: Gasket eliminator Pipe Threadlock

Anaerobic Type Room Temperature Vulcanizing (RTV) Sealant

Anaerobic type room temperature vulcanizing (RTV) sealant cures in the absence of air. This type of sealant is used where 2 components, such as the intake manifold and the engine block, are assembled together.

Use the following information when using RTV sealant

1. Do not use RTV sealant in areas where extreme temperatures are expected. These areas include: The exhaust manifold The head gasket Any other surfaces where a different type of sealant is specified in the service procedure
2. Always follow all the safety recommendations and the directions that are on the RTV sealant container.
3. Use a plastic or wood scraper in order to remove all the RTV sealant from the components.
4. The surfaces to be sealed must be clean and dry.
5. Use a RTV sealant bead size as specified in the service procedure.
6. Apply the RTV sealant bead to the inside of any bolt holes areas.
7. Assemble the components while the RTV sealant is still wet to the touch, within 3 minutes.
8. Tighten the fasteners in sequence, if specified, and to the proper torque specifications.

Anaerobic Type Gasket Eliminator Sealant

Anaerobic type gasket eliminator sealant cures in the absence of air. This type of sealant is used where 2 rigid parts, such as castings, are assembled together. When 2 rigid parts are disassembled and no sealant or gasket is readily noticeable, then the 2 parts were probably assembled using an anaerobic type gasket eliminator sealant.

Use the following information when using gasket eliminator sealant

1. Always follow all the safety recommendations and directions that are on the gasket eliminator sealant container.
2. Apply a continuous bead of gasket eliminator sealant to one flange. The surfaces to be sealed must be clean and dry.

Note. Gasket eliminator sealed joint fasteners that are partially torqued and the gasket eliminator sealant allowed to cure more than 5 minutes, may result in incorrect shimming and sealing of the joint. Do not overtighten the fasteners. Apply the gasket eliminator sealant evenly to get a uniform thickness of the gasket eliminator sealant on the sealing surface. Tighten the fasteners in sequence, if specified, and to the proper torque specifications. After properly tightening the fasteners, remove the excess gasket eliminator sealant from the outside of the joint.

Anaerobic Type Threadlock Sealant

Anaerobic type threadlock sealant cures in the absence of air. This type of sealant is used for threadlocking and sealing of bolts, fittings, nuts, and studs. This type of sealant cures only when confined between 2 close fitting metal surfaces.

Use the following information when using threadlock sealant

1. Always follow all safety recommendations and directions that are on the threadlock sealant container.
2. The threaded surfaces to be sealed must be clean and dry.
3. Apply the threadlock sealant as specified on the threadlock sealant container.
4. Tighten the fasteners in sequence, if specified, and to the proper torque specifications.

Anaerobic Type Pipe Sealant

Anaerobic type pipe sealant cures in the absence of air and remains pliable when cured. This type of sealant is used where 2 parts are assembled together and require a leak proof joint.

Use the following information when using pipe sealant

1. Do not use pipe sealant in areas where extreme temperatures are expected. These areas include: The exhaust manifold The head gasket Surfaces where a different sealant is specified
2. Always follow all the safety recommendations and the directions that are on the pipe sealant container.
3. The surfaces to be sealed must be clean and dry.
4. Use a pipe sealant bead of the size or quantity as specified in the service procedure.
5. Apply the pipe sealant bead to the inside of any bolt hole areas.
6. Apply a continuous bead of pipe sealant to one sealing surface.
7. Tighten the fasteners in sequence, if specified, and to the proper torque specifications.

Tools and Equipment

1. Special tools are listed and illustrated throughout this section, with a complete listing at the end of the section. These tools, or their equivalents, are designed to quickly and safely accomplish the operations for which they are intended. The use of these special tools also minimize possible damage to engine components. Some precision measuring tools are required for inspection of certain critical components. Torque wrenches and a torque angle meter are necessary for the proper tightening of various fasteners.
2. To properly service the engine assembly, the following items should be readily available: Approved eye protection and safety gloves A clean, well-lit, work area A suitable component cleaning tank A compressed air supply Trays or storage containers to keep components and fasteners organized An adequate set of hand tools Approved engine repair stand An approved engine lifting device that adequately supports the weight of the components
