Engine Mechanical - 3.6l - Repair Instructions - on Vehicle Buick Enclave I

Scheme 20

Drive Belt Replacement

Scheme 21

Drive Belt Tensioner Replacement

Scheme 22

Drive Belt Idler Pulley Replacement

Scheme 23

Engine Support Fixture

Engine Mount Inspection

1. Install the engine support fixture. Refer to «Engine Support Fixture»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Observe the engine mount while raising the engine. Raising the engine removes the weight from the engine mount and creates slight tension on the rubber.
3. Replace the engine mount if the engine mount exhibits any of the following conditions: The hard rubber is covered with heat check cracks. The rubber is separated from the metal plate of the engine mount. The rubber is split through the center of the engine mount. The engine mount itself is leaking fluid.
4. For engine mount replacement. Refer to «Engine Front Mount Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) , , «Engine Rear Mount Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) , or «Transmission Mount Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle) .

Scheme 24

Engine Front Mount Replacement

Scheme 25

Engine Rear Mount Replacement

Scheme 26

Engine Front Mount Bracket Replacement

Scheme 27

Engine Rear Mount Bracket Replacement (Front Wheel Drive)

Scheme 28

Engine Rear Mount Bracket Replacement (All Wheel Drive)

Scheme 29

Engine Mount Strut Replacement - Right Side

Scheme 30

Engine Mount Strut Bracket Replacement - Right Side

Scheme 31

Fuel Injector Sight Shield Replacement

Scheme 32

Positive Crankcase Ventilation Tube Replacement - Front

Removal Procedure

1. Remove the fuel injector sight shield. Refer to «Fuel Injector Sight Shield Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Disconnect the positive crankcase ventilation (PCV) fresh air pipe (1) from the intake manifold.
3. Disconnect the PCV air pipe from the camshaft cover.

Installation Procedure

1. Connect the PCV air pipe (1) to the camshaft cover valve.
2. Connect the PCV air pipe to the intake manifold.
3. Install the fuel injector sight shield. Refer to «Fuel Injector Sight Shield Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

1. Turn the ignition OFF.
2. Remove the fuel injector sight shield. Refer to «Fuel Injector Sight Shield Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
3. Remove the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
4. Disconnect the brake booster vacuum hose from the intake manifold.
5. Remove the rear positive crankcase ventilation hose. Refer to «Positive Crankcase Ventilation Tube Replacement - Rear»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
6. Disconnect the purge solenoid valve electrical connector (1).
7. Disconnect the purge line (2) from the purge solenoid valve.
8. Remove the electrical connector retainer (1).
9. Disconnect the throttle body electrical connector (2).
10. Remove the fuel pipe shield. Refer to «Fuel Pipe Shield Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
11. Remove the engine wiring harness retaining clip (1) from the side of the intake manifold.
12. Remove the wiring harness retaining bolt.
13. Remove the engine wiring harness retaining clips (1) from the intake manifold.
14. Position the engine wiring harness aside.
15. Remove the intake manifold insulator.
16. Remove the intake manifold bolts.
17. Remove the intake manifold with the throttle body.
18. If the intake manifold is being replaced, disassemble the intake manifold. Refer to «Intake Manifold Disassemble»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__intake-manifold-disassemble) .
19. Clean and inspect the intake manifold. Refer to «Intake Manifold Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .

1. If the intake manifold is being replaced, assemble the intake manifold. Refer to «Intake Manifold Assemble»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__intake-manifold-assemble) .
2. Install a NEW intake manifold gasket.
3. Install the intake manifold.
4. Install the intake manifold bolts and tighten to 25 N.m (18 lb ft).
5. Position the engine wiring harness in place.
6. Install the engine wiring harness retaining clips (1) to the intake manifold.
7. Install the engine wiring harness retaining clip (1) to the side of the intake manifold.
8. Install the fuel pipe shield. Refer to «Fuel Pipe Shield Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
9. Connect the electrical connector (2) to the throttle body.
10. Install the electrical connector retainer (1).
11. Connect the purge line (2) to the purge solenoid valve.
12. Connect the purge solenoid valve electrical connector (1).
13. Install the rear positive crankcase ventilation hose. Refer to «Positive Crankcase Ventilation Tube Replacement - Rear»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
14. Connect the brake booster vacuum hose to the intake manifold.
15. Install the air cleaner outlet duct. Refer to «Air Cleaner Outlet Duct Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
16. Install the fuel injector sight shield. Refer to «Fuel Injector Sight Shield Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

1. Remove the Fuel Injector Sight Shield. Refer to «Fuel Injector Sight Shield Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle)
2. Remove the oil level indicator from the oil level indicator tube.
3. Remove the oil level indicator tube bolt.
4. Remove the oil level indicator tube up through the exhaust manifold.
5. If you are replacing only the oil level indicator tube seal, remove and discard the old seal.

1. Install a new seal on the oil level indicator tube.
2. Install the oil level indicator tube.
3. Install the oil level indicator tube bolt and tighten to 10 N.m (89 lb in).
4. Install the oil level indicator in the oil level indicator tube.
5. Install the Fuel Injector Sight Shield. Refer to «Fuel Injector Sight Shield Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle)

1. Remove the generator. Refer to «Generator Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
2. Remove and properly dispose of the oil filter. Refer to «Engine Oil and Oil Filter Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
3. Disconnect the oil pressure sensor electrical connector.
4. Remove the oil filter adapter bolts from the engine block.
5. Remove the oil filter adapter.
6. Remove and discard the oil filter adapter gasket.

1. Position a NEW oil filter adapter gasket onto the oil filter adapter.
2. Place the oil filter adapter into position.
3. Install the oil filter adapter bolts. Ensure the longer bolts (1) is installed in the upper rear position and tighten to 25 N.m (18 lb ft).
4. Install a NEW oil filter. Refer to «Engine Oil and Oil Filter Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
5. Install the generator. Refer to «Generator Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .

Crankshaft Balancer Replacement

Special Tools

1. EN 46106 Flywheel Holding Tool
2. J 38416-2 Crankshaft Button
3. J 41816 Crankshaft Balancer Remover
4. J 41998-B Crankshaft Balancer Installer

1. Remove the engine mount strut bracket. Refer to «Engine Mount Strut Bracket Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Remove the drive belt. Refer to «Drive Belt Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
3. Remove the starter. Refer to «Starter Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
4. Install the EN 46106 flywheel holding tool through the starter mounting hole.
5. Support the right side of the frame with jackstands.
6. Remove the right side frame reinforcement bolts.
7. Loosen the right side frame bolts.
8. Lower the right side of the frame approximately 2 inches.
9. Remove the crankshaft balancer bolt. Discard the bolt.
10. Install the J 38416-2 crankshaft button in the nose of the crankshaft.
11. Install the J 41816 crankshaft balancer remover in order to remove the crankshaft balancer.
12. Tighten the center bolt of the J 41816 crankshaft balancer remover in order to pull the crankshaft balancer off of the crankshaft.
13. Remove the J 41816 crankshaft balancer remover from the crankshaft balancer.

1. The EN 46106 flywheel holding tool must be installed onto the flywheel.
2. Use the J 41998-B crankshaft balancer installer , nut, bearing and washer to install the crankshaft balancer.
3. Apply lubricant to the inside of the crankshaft balancer hub bore.
4. Place the crankshaft balancer in position on the crankshaft.
5. Thread the J 41998-B crankshaft balancer installer in the crankshaft. Ensure you engage at least 10 threads of the J 41998-B crankshaft balancer installer before pressing the crankshaft balancer in place.
6. Push the crankshaft balancer into position by tightening the nut on the J 41998-B crankshaft balancer installer until the large washer bottoms out on the crankshaft end.
7. Remove the J 41998-B crankshaft balancer installer.
8. Install the NEW crankshaft balancer bolt.
9. Tighten the crankshaft balancer bolt. Tighten the crankshaft balancer bolt to 100 N.m (74 lb ft). Tighten the crankshaft balancer bolt an additional 150 degrees using the J 45059 angle meter.
10. Remove the EN 46106 flywheel holding tool.
11. Install the starter. Refer to «Starter Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
12. Using engine support fixture, raise the engine into position.
13. Install the engine mount strut bracket. Refer to «Engine Mount Strut Bracket Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
14. Install the drive belt. Refer to «Drive Belt Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

Crankshaft Front Oil Seal Replacement

Special Tools

J 29184 Oil Seal Installer

1. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__crankshaft-balancer-replacement) .
2. Use a flat-bladed tool in order to remove the crankshaft oil seal. Use care not to damage the engine front cover or the crankshaft.

1. Use the J 29184 oil seal installer or equivalent to install the crankshaft front oil seal.
2. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__crankshaft-balancer-replacement) .

Camshaft Cover Replacement - Left Side

Special Tools

EN 46101 Spark Plug Tube Seal Guide

1. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Remove the left side ignition coils. Refer to «Ignition Coil Replacement - Bank 2»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Unclip and reposition the wire harness from the camshaft cover.
4. Remove the power steering reservoir bracket. Refer to «Power Steering Fluid Reservoir Bracket Replacement»(/buick/enclave/i-2007-2013/remont/manual-power-steering/#power-steering-system) .
5. Remove the left camshaft cover bolts.
6. Remove the left camshaft cover from the left cylinder head.
7. Clean the mating surfaces of the cylinder head and the camshaft cover. Refer to «Camshaft Cover Cleaning and Inspection (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
8. Install the EN 46101 spark plug tube seal guide onto the spark plug tubes of the left cylinder head.

1. Install new camshaft cover bolt grommets prior to installing the camshaft cover bolts.
2. Wipe the camshaft cover sealing surface on the left cylinder head with a clean, lint-free cloth.
3. Place a bead 8 mm (0.3150 in) in diameter by 4 mm (0.1575 in) in height of RTV sealant, GM P/N 12378521 (Canadian P/N 88901148) or equivalent, on the engine front cover split lines (1).
4. Place the left camshaft cover into position onto the left cylinder head.
5. Loosely install the left camshaft cover bolts.
6. Tighten the left camshaft cover bolts in sequence shown. Tighten Tighten the bolts to 10 N.m (89 lb in).
7. Remove the EN 46101 spark plug tube seal guide from the spark plug tubes of the left cylinder head.
8. Install the power steering reservoir bracket. Refer to «Power Steering Fluid Reservoir Bracket Replacement»(/buick/enclave/i-2007-2013/remont/manual-power-steering/#power-steering-system) .
9. Position the wire harness and clip to the camshaft cover.
10. Install the left side ignition coils. Refer to «Ignition Coil Replacement - Bank 2»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
11. Install the lower intake manifold. Refer to «Intake Manifold Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

Camshaft Cover Replacement - Right Side

Special Tools

EN 46101 Spark Plug Tube Seal Guide

1. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Remove the right bank spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Unbolt the power steering reservoir and position aside. Refer to «Power Steering Fluid Reservoir Replacement»(/buick/enclave/i-2007-2013/remont/manual-power-steering/#power-steering-system) .
4. Remove the right camshaft cover bolts.
5. Remove the right camshaft cover from the right cylinder head.
6. Clean the mating surfaces of the cylinder head and the camshaft cover. Refer to «Camshaft Cover Cleaning and Inspection (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
7. Install the EN 46101 spark plug tube seal guide onto the spark plug tubes of the right cylinder head.

1. Install new camshaft cover bolt grommets prior to installing the camshaft cover bolts.
2. Place a bead 8 mm (0.3150 in) in diameter by 4 mm (0.1575 in) in height of RTV sealant, GM P/N 12378521 (Canadian P/N 88901148) or equivalent, on the engine front cover split lines (1).
3. Place the right camshaft cover into position onto the right cylinder head.
4. Loosely install the right camshaft cover bolts.
5. Tighten the right camshaft cover bolts in sequence. Tighten Tighten the bolts to 10 N.m (89 lb in).
6. Install the power steering reservoir. Refer to «Power Steering Fluid Reservoir Replacement»(/buick/enclave/i-2007-2013/remont/manual-power-steering/#power-steering-system) .
7. Remove the EN 46101 spark plug tube seal guide from the spark plug tubes of the right cylinder head.
8. Install NEW spark plugs into the right cylinder head. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
9. Install the intake manifold. Refer to «Intake Manifold Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

Engine Front Cover Replacement

Special Tools

1. EN 46109 Guide Pin Set
2. EN-48383 Camshaft Retaining Tools
3. EN-48589 Crankshaft Rotational Socket
4. EN-46104 Water Pump Pulley Holding Tool

1. Remove the frame from the body with the engine and transmission. Refer to «Engine Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) . Follow steps 1-40 in the Engine Replacement Removal.
2. Remove the intake manifold. Refer to «Intake Manifold Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__intake-manifold-removal) .
3. Remove the power steering reservoir bracket bolts and reposition.
4. Remove the power steering pump bracket bolts and reposition.
5. Remove the left and right camshaft covers. Refer to «Camshaft Cover Removal - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-cover-removal-left-side) , and «Camshaft Cover Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-cover-removal-right-side) .
6. Remove the engine mount bracket bolts and bracket.
7. Remove the water outlet housing assembly. Refer to «Water Outlet Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__water-outlet-removal) .
8. Remove the drive belt and drive belt tensioner. Refer to «Drive Belt Tensioner Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__drive-belt-tensioner-removal) .
9. Remove the water pump pulley using EN-46104 Holding Tool and if necessary remove the water pump. Refer to «Water Pump Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__water-pump-removal) .
10. Remove the oil filter.
11. Remove the starter heat shield.
12. Remove the starter electrical connections, starter bolts and starter.
13. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__crankshaft-balancer-removal) .
14. Remove the drive belt idler bolt and idler. Refer to «Drive Belt Idler Pulley Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__drive-belt-idler-pulley-removal)
15. Remove the generator.
16. Remove camshaft position sensors (2) from the front cover.
17. Remove the camshaft position actuators from the front cover.
18. Remove the engine front cover. «Engine Front Cover Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__engine-front-cover-removal) .

1. Install front cover. Refer to «Engine Front Cover Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__engine-front-cover-installation) .
2. Install the camshaft position actuators to the front cover.
3. Install the camshaft position sensors (2) to the front cover.
4. Install the generator.
5. Install the drive belt idler bolt and idler. Refer to «Drive Belt Idler Pulley Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__drive-belt-idler-pulley-installation)
6. Install the crankshaft balancer. Refer to «Crankshaft Balancer Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__crankshaft-balancer-installation) .
7. Install the starter, starter bolts and starter electrical connections.
8. Install the starter heat shield.
9. Install the oil filter.
10. If removed, install the water pump and the water pump pulley using EN-46104 Holding Tool. Refer to «Water Pump Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__water-pump-installation) .
11. Install the drive belt tensioner and drive belt. Refer to «Drive Belt Tensioner Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__drive-belt-tensioner-installation) .
12. Install the water outlet housing assembly. Refer to «Water Outlet Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__water-outlet-installation) .
13. Install the engine mount bracket and bracket bolts.
14. Remove the left and right camshaft covers. Refer to «Camshaft Cover Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-cover-installation-left-side) , and «Camshaft Cover Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-cover-installation-right-side) .
15. Reposition the power steering pump and install the bracket bolts. Tighten the bolts to 50 N.m (37 lb ft).
16. Install the power steering reservoir and install the bracket bolts. Tighten the bolts to 9 N.m (80 lb in).
17. Remove the intake manifold. Refer to «Intake Manifold Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__intake-manifold-installation) .
18. Install the frame with the engine and transmission. Refer to «Engine Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) . Follow steps 16-49 in Engine Replacement Installation.

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .
3. Remove the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-removal) .
4. Remove the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-removal) .
5. Remove the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
6. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .
7. Remove the primary upper camshaft drive chain guide. Refer to «Primary Timing Chain Guide Removal - Upper»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-timing-chain-guide-removal) .
8. Remove the primary camshaft drive chain. Refer to «Primary Camshaft Intermediate Drive Chain Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
9. Remove the right bank camshaft intermediate drive chain idler. Refer to «Timing Chain Idler Sprocket Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__timing-chain-idler-sprocket-removal) .
10. Remove the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .
11. Remove the left bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-removal) .
12. Remove the left bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-removal) .
13. Remove the left bank camshaft intermediate drive chain idler. Refer to «Timing Chain Idler Sprocket Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__timing-chain-idler-sprocket-removal) .
14. Remove the left bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
15. Clean and inspect all of the camshaft timing drive components. Refer to «Camshaft Timing Drive Components Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) . Replace components as necessary.

1. Install the left bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Installation - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-intermediate-drive-chain-installation) .
2. Install the left bank camshaft intermediate drive chain idler. Refer to «Timing Chain Idler Sprocket Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__timing-chain-idler-sprocket-installation) .
3. Install the left bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-installation) .
4. Install the left bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-installation) .
5. Install the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
6. Install the right bank camshaft intermediate drive chain idler. Refer to «Timing Chain Idler Sprocket Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__timing-chain-idler-sprocket-installation) .
7. Install the primary camshaft drive chain. Refer to «Primary Camshaft Intermediate Drive Chain Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-installation) .
8. Install the primary upper camshaft drive chain guide. Refer to «Primary Timing Chain Guide Installation - Upper»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-timing-chain-guide-installation) .
9. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .
10. Install the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-intermediate-drive-chain-installation) .
11. Install the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-installation) .
12. Install the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-installation) .
13. Install the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
14. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .
4. Remove the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-removal) .
5. Remove the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-removal) .
6. Remove the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .

1. Ensure the stage 1 camshaft timing is correct. Refer to «Setting Camshaft Timing»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__setting-camshaft-timing) .
2. Install the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-intermediate-drive-chain-installation) .
3. Install the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-installation) .
4. Install the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-installation) .
5. Install the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
6. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
7. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .

1. Install the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
2. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .

1. Install the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
2. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .
4. Remove the left secondary camshaft drive chain shoe bolt.
5. Remove the left secondary camshaft drive chain shoe.

1. Ensure that the left secondary camshaft drive chain shoe (2) is being installed.
2. Position the left secondary camshaft drive chain shoe.
3. Install the secondary camshaft drive chain shoe bolt and tighten to 25 N.m (18 lb ft).
4. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
5. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .
4. Remove the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-removal) .

1. Install the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-installation) .
2. Install the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
3. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
4. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .
4. Remove the left bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-removal) .

1. Install the left bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-installation) .
2. Install the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
3. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
4. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .
4. Remove the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-removal) .

1. Install the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-installation) .
2. Install the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
3. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
4. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .

Primary Camshaft Drive Chain and Sprockets Replacement

Special Tools

EN 46111 Crankshaft Rotation Socket

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .
4. Remove the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-removal) .
5. Remove the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-removal) .
6. Remove the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
7. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .
8. Remove the primary camshaft drive chain upper guide. Refer to «Primary Timing Chain Guide Removal - Upper»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-timing-chain-guide-removal) .
9. Remove the primary camshaft timing chain. Refer to «Secondary Camshaft Intermediate Drive Chain Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
10. Remove the crankshaft sprocket from the nose of the crankshaft.

1. Ensure the crankshaft sprocket is installed with the timing mark (1) visible.
2. Install the crankshaft sprocket on to the nose of the crankshaft.
3. Align the notch in the crankshaft sprocket with the pin in the crankshaft.
4. Slide the crankshaft sprocket on the crankshaft nose until the crankshaft sprocket contacts the step in the crankshaft.
5. Ensure the crankshaft is in the stage one timing position with the crankshaft sprocket timing mark (1) aligned to the stage one timing mark on the oil pump cover (2) using the EN 46111 crankshaft rotation socket. Refer to «Timing Chain Alignment Diagram»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-timing-chain-alignment-routing-diagram) - Stage One.
6. Install the primary camshaft timing chain. Refer to «Primary Camshaft Intermediate Drive Chain Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-installation) .
7. Install the primary upper camshaft drive chain guide. Refer to «Primary Timing Chain Guide Installation - Upper»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-timing-chain-guide-installation) .
8. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .
9. Install the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-intermediate-drive-chain-installation) .
10. Install the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-installation) .
11. Install the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-installation) .
12. Install the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
13. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
14. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .
4. Remove the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-removal) .
5. Remove the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-removal) .
6. Remove the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
7. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .
8. Remove the primary upper camshaft drive chain guide. Refer to «Primary Timing Chain Guide Removal - Upper»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-timing-chain-guide-removal) .
9. Remove the primary camshaft drive chain. Refer to «Primary Camshaft Intermediate Drive Chain Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
10. Remove the right bank camshaft intermediate drive chain idler. Refer to «Timing Chain Idler Sprocket Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__timing-chain-idler-sprocket-removal) .
11. If you are servicing the left bank camshaft intermediate drive chain idler, perform the following steps: Remove the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) . Remove the left bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-removal) . Remove the left bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-removal) . Remove the left bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) . Remove the left bank camshaft intermediate drive chain idler. Refer to «Timing Chain Idler Sprocket Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__timing-chain-idler-sprocket-removal) .

1. If you are servicing the left bank idler sprocket, perform the following steps: Install the left bank camshaft intermediate drive chain idler. Refer to «Timing Chain Idler Sprocket Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__timing-chain-idler-sprocket-installation) . Install the left bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Installation - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-intermediate-drive-chain-installation) . Install the left bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-installation) . Install the left bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-installation) . Install the left bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
2. Install the right bank camshaft intermediate drive chain idler. Refer to «Timing Chain Idler Sprocket Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__timing-chain-idler-sprocket-installation) .
3. Install the primary camshaft drive chain. Refer to «Primary Camshaft Intermediate Drive Chain Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-installation) .
4. Install the primary upper camshaft drive chain guide. Refer to «Primary Timing Chain Guide Installation - Upper»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-timing-chain-guide-installation) .
5. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .
6. Install the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-intermediate-drive-chain-installation) .
7. Install the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-installation) .
8. Install the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-installation) .
9. Install the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
10. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
11. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-removal) .
4. Remove the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-removal) .
5. Remove the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-removal) .
6. Remove the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
7. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .
8. Remove the primary upper camshaft drive chain guide. Refer to «Primary Timing Chain Guide Removal - Upper»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-timing-chain-guide-removal) .
9. Remove the primary camshaft drive chain. Refer to «Primary Camshaft Intermediate Drive Chain Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
10. Remove the right bank camshaft intermediate drive chain idler. Refer to «Timing Chain Idler Sprocket Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__timing-chain-idler-sprocket-removal) .

1. Ensure stage 1 camshaft timing is correct. Refer to «Setting Camshaft Timing»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__setting-camshaft-timing) .
2. Install the right bank camshaft intermediate drive chain idler. Refer to «Timing Chain Idler Sprocket Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__timing-chain-idler-sprocket-installation) .
3. Install the primary camshaft drive chain. Refer to «Primary Camshaft Intermediate Drive Chain Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-installation) .
4. Install the primary upper camshaft drive chain guide. Refer to «Primary Timing Chain Guide Installation - Upper»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-timing-chain-guide-installation) .
5. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .
6. Install the right bank secondary camshaft drive chain. Refer to «Secondary Camshaft Intermediate Drive Chain Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-intermediate-drive-chain-installation) .
7. Install the right bank secondary camshaft drive chain guide. Refer to «Secondary Timing Chain Guide Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-guide-installation) .
8. Install the right bank secondary camshaft drive chain shoe. Refer to «Secondary Camshaft Drive Chain Shoe Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-camshaft-drive-chain-shoe-installation) .
9. Install the right bank secondary camshaft drive chain tensioner. Refer to «Secondary Timing Chain Tensioner Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__secondary-timing-chain-tensioner-installation) .
10. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
11. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .

1. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
2. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .

1. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .
2. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .

1. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Remove the primary camshaft drive chain lower guide bolts.
3. Remove the primary camshaft drive chain lower guide.

1. Position the primary camshaft drive chain lower guide to the oil pump.
2. Install the primary camshaft drive chain lower guide bolts and tighten to 25 N.m (18 lb ft).
3. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

1. Remove the spark plugs in order to ease crankshaft/engine rotation. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
2. Remove the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
3. Remove the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .
4. Remove the primary upper camshaft drive chain guide. Refer to «Primary Timing Chain Guide Removal - Upper»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-timing-chain-guide-removal) .

1. Install the primary upper camshaft drive chain guide. Refer to «Primary Timing Chain Guide Installation - Upper»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-timing-chain-guide-installation) .
2. Install the primary camshaft drive chain tensioner. Refer to «Primary Camshaft Intermediate Drive Chain Tensioner Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__primary-camshaft-intermediate-drive-chain-tensioner) .
3. Install the engine front cover. Refer to «Engine Front Cover Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__engine-front-cover-replacement) .
4. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .

Camshaft Position Actuator Replacement - Bank 1

Special Tools

1. EN49982-1 Timing Chain Retainer
2. EN49982-2 Timing Chain Retainer

For equivalent regional tools, refer to Special Tools .

1. Remove the camshaft cover. Refer to «Camshaft Cover Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-cover-replacement-right-side) .
2. Remove the camshaft position actuator solenoid valve solenoid - intake. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 1 (Right Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
3. Remove the intake camshaft position sensor. Refer to «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
4. Remove the exhaust camshaft position sensor. Refer to «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
5. Remove the camshaft position actuator solenoid valve solenoid - exhaust. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 1 (Right Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
6. Rotate engine clockwise using crankshaft dampener retaining bolt until the flats at the rear ends of the camshafts are pointing up. This puts the camshafts on "base circle" and will reduce their tendency to rotate from valve spring pressure when the camshaft position actuators/drive chains are removed.
7. Loosen intake and/or exhaust camshaft position actuator retaining bolts, depending on which camshaft position actuator and/or camshaft you will be servicing. If servicing both camshaft position actuators and/or camshafts, loosen both bolts.
8. Mark the position of the chain to the camshaft position actuator - intake.
9. Mark the position of the chain to the camshaft position actuator - exhaust.
10. Remove camshaft front cap bolts (1).
11. Remove the camshaft front cap (1).
12. Loosen wingnut (4) to open the clamping area of EN49982-1 retainer.
13. Install EN49982-1 retainer intake side chain holder onto front cover by screwing in the thumbscrew (2) on the EN49982-1 retainer finger-tight.
14. Tighten wingnut (4) so EN49982-1 retainer closes over and firmly grasps timing chain.
15. EN49982-2 retainer (1) will be installed in the following steps such that it wedges between an internal rib (2) that is cast into the inside of the front cover (shown in dotted line above) and the timing chain and spring-loaded tensioner shoe (3), holding the chain in position. The wedge will be left in place during the cam position actuator and/or camshaft service.
16. Insert the EN49982-2 retainer between the two camshaft position actuators with the "teeth" on the EN49982-2 retainer facing toward the front cover.
17. Once the wedge portion of EN49982-2 retainer is below the camshaft position actuators, rotate the EN49982-2 retainer until the flat in the handle faces toward the intake camshaft position actuator. This orients the "teeth" toward the chain.
18. Drop the wedge down until it begins to engage the timing chain and the belt casting (2).
19. If possible shine a strong light down from above, between the camshaft position actuators, and see the wedge in overall position as shown in the above graphic.
20. Using a 20 mm wrench on the cast hexagonal portion of the exhaust camshaft, rotate the camshaft toward the intake camshaft while pushing down on the handle of the EN49982-2 retainer.
21. This rotation of the camshaft will compress the tensioner shoe (3) against the spring force of the tensioner, opening up a gap between the chain and the internal rib in the front cover. The wedge will then drop into this gap. You will feel a distinct click as the teeth engage the chain.
22. Release the force on the wrench, allowing the spring tension to close the tensioner shoe against the wedge portion of EN49982-2 retainer. You should be able to lightly tug on the EN49982-2 retainer and it should stay in position. Repeat Steps 20 and 21 if necessary to re-insert the EN49982-2 retainer until you are certain it is in position and will stay in position.
23. With EN49982-2 retainer in position and with the 20 mm wrench removed, there should now be some slack in the timing drive chain as indicated in the graphics shown.
24. Do not pry against the face of the camshaft position actuators or the position actuator retaining bolt.
25. Position a screwdriver or small pry bar between a camshaft cap and camshaft lobe. Carefully move/pry the camshafts as far as possible toward the rear/flywheel end of the engine.
26. The EN49982-1 retainer and EN49982-2 retainer should be in position as shown, they must be left in position during the servicing of the camshaft position actuator(s) and/or camshaft(s).
27. Remove and capture the plastic thrust washers (1) in the following steps. Ensure the plastic thrust washer does not fall into the front cover area.
28. To remove the intake camshaft position actuator, remove the loosened retaining bolt. To remove only the exhaust camshaft position actuator, skip the steps for removing the intake camshaft position actuator. However, the EN49982-1 retainer MUST be installed as discussed even if the intake side will not be serviced or the timing of the camshaft chains will be lost.
29. Slide the camshaft position actuator forward and off the end of the intake camshaft. The slot in the EN49982-1 retainer will allow the tool to move forward enough to disengage the camshaft position actuator from the front of the camshaft. Remove the plastic thrust washer when removing the camshaft position actuator from the end of the camshaft.
30. Tilt the camshaft position actuator forward and out/away from the engine.
31. Allow the chain to rest on the EN49982-1 retainer and EN49982-2 retainer in position during service.

1. Install plastic camshaft position actuator thrust washer (1) between cylinder head face and camshaft position actuator on assembly.
2. It may help to carefully pry the camshaft forward and to move the EN49982-1 retainer backward via the slot to reengage the position actuator to the camshaft. The dowel pin on the camshaft position actuator must be aligned with the slot in the camshaft nose for reassembly.
3. Install the intake camshaft position actuator first by inserting the actuator between the timing chain and front cover. Tilt the actuator in and engage the chain while aligning the marks you made on the chain and position actuator.
4. Ensure the camshaft position actuator fits snugly to the end of the camshaft.
5. Install the intake camshaft position actuator retaining bolt, and lightly tighten the bolt to hold the camshaft actuator in place. DO NOT torque at this time.
6. Install the exhaust camshaft position actuator retaining bolt, and lightly tighten the bolt to hold the camshaft actuator in place. DO NOT torque at this time.
7. Double-check that the marks on both the intake and exhaust camshaft position actuators to ensure that they are aligned with their respective paint marks on the chain.
8. Using a 20 mm wrench on the cast hexagonal portion of the exhaust camshaft, rotate the camshaft clockwise while pulling up on the handle of the EN49982-2 retainer.
9. Remove EN49982-2 retainer.
10. Release the pressure on the wrench. The timing chain should now be tight and should lose the slack the wedge was providing.
11. Torque one or both camshaft position actuator retaining bolts to 58 N.m (43 lb ft).
12. Unscrew the wingnut on EN49982-1 retainer to release timing chain, and then remove EN49982-1 retainer from the front cover by unscrewing the thumbscrew (2).
13. Install camshaft front cap and bolts (1).
14. Tighten the camshaft front cap outer bolts to 10 N.m (89 lb in).
15. Tighten the camshaft front cap inner bolts to 10 N.m (89 lb in).
16. Install the camshaft position actuator solenoid valve solenoid - exhaust. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 1 (Right Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
17. Install the camshaft position actuator solenoid valve solenoid-intake. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 1 (Right Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
18. Install the intake camshaft position sensors. Refer to «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
19. Install the exhaust camshaft position sensor. Refer to «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
20. Install the camshaft cover. Refer to «Camshaft Cover Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-cover-replacement-right-side) .

Camshaft Position Actuator Replacement - Bank 2

Special Tools

EN-48313 Timing Chain Retention Tool

For equivalent regional tools, refer to Special Tools .

1. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Remove the left camshaft cover. Refer to «Camshaft Cover Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-cover-replacement-left-side) .
3. Remove the left intake and exhaust camshaft position sensors. Refer to «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) , and «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
4. Remove the left intake and exhaust camshaft position actuator solenoids. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 2 (Left Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) , and «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 2 (Left Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
5. Rotate the crankshaft balancer using the balancer bolt until the camshafts are in a neutral (low tension) position. The camshafts will be parallel with the camshaft cover rail (1).
6. Use a paint stick to create an alignment mark on one of the timing chain links (2) and the adjacent tooth on the exhaust camshaft position actuator (1).
7. Use a paint stick to create an alignment mark on one of the timing chain links (3) and the adjacent tooth on the intake camshaft position actuator (4).
8. Use an open end wrench on the hex cast into the left intake and exhaust camshafts and rotate the camshafts toward each other in order to create slack in the chain between the actuators.
9. Unscrew the EN-48313 tool so that the legs of the tool are retracted.
10. Insert the EN-48313 tool between the camshaft actuators, rearward of the timing chain until the bottom line that is scribed in the body of the tool (2) is adjacent to the top surface of the cylinder head (1). This is the approximate installed position.
11. Ensure that the feet (4) on the legs of the tool are facing the front of the engine.
12. Partially expand the legs (1, 3) of the EN-48313 tool by turning the T-shaped handle clockwise.
13. Insert the leg of the tool (1) behind the timing chain guide (2).
14. Continue expanding the EN-48313 tool until the legs (1, 3) contact the timing chain. Do not tighten at this time.
15. Hand tighten the EN-48313 tool.
16. Use an open end wrench on the hex cast into the left intake and exhaust camshafts and rotate the camshafts toward each other in order to create slack in the chain between the actuators.
17. The EN-48313 tool is now properly installed to hold the timing chain in position.
18. Use an open end wrench on the hex cast into the camshaft in order to prevent engine rotation when loosening the camshaft position actuator bolt.
19. If replacing the exhaust camshaft position actuator, then remove the bolt and the actuator.
20. If replacing the intake camshaft position actuator, then remove the bolt and the actuator.
21. If removing both the exhaust and intake camshaft actuators, the timing chain can be draped over the EN-48313 tool once the actuators have been removed.
22. Rotate the actuator in order to align the opening in the actuator reluctor wheel with the cam sensor boss in the front cover, to allow actuator removal.
23. Remove the camshaft thrust washer.

1. Align the exhaust camshaft actuator alignment mark (1) to the timing chain alignment mark (2) made during disassembly.
2. Ensure that the intake camshaft actuator alignment mark (4) and the timing chain alignment mark (3) are also aligned.
3. Position the exhaust camshaft actuator to the camshaft and install the actuator bolt hand tight.
4. Remove the EN-48313 tool.
5. If equipped, ensure the proper camshaft thrust washer is used. Use a 1.6 mm (0.063 in) thrust washer on applications that have 5 attaching screws on the back side of the camshaft position actuator (1). Use a 1.1 mm (0.043 in) thick thrust washer with yellow speckles on applications that have 4 attaching screws on the back side of the camshaft position actuator (2).
6. Install the thrust washer, if applicable.
7. If the exhaust camshaft position actuator has been replaced, then tighten the bolt to 58 N.m (43 lb ft).
8. If the intake camshaft position actuator has been replaced, then tighten the bolt to 58 N.m (43 lb ft).
9. If both the exhaust and intake has been replaced, then tighten bolt to 58 N.m (43 lb ft).
10. Install the left intake and exhaust camshaft position actuator solenoids. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 2 (Left Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) , and «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 2 (Left Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
11. Install the left intake and exhaust camshaft position sensors. Refer to «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) , and «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
12. Install the left camshaft cover. Refer to «Camshaft Cover Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-cover-replacement-left-side) .
13. Install the intake manifold. Refer to «Intake Manifold Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

Setting Camshaft Timing

Follow the left bank secondary camshaft drive chain replacement procedures to reset the camshaft timing. Refer to Secondary Camshaft Intermediate Drive Chain Replacement - Left Side .

Camshaft Replacement - Left Side

Special Tools

1. EN-48589 Crankshaft Rotation Socket
2. EN-48383 Timing Chain Retention Tool

For equivalent regional tools, refer to Special Tools .

1. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Remove the fuel pump from the cylinder head. Refer to «Fuel Pump Replacement (LLT)»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions__fuel-pump-replacement-llt) .
3. Remove the left bank camshaft cover. Refer to «Camshaft Cover Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-cover-replacement-left-side) .
4. Remove the camshaft sensors. Refer to «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) , and «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
5. Remove the camshaft position actuator solenoid. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 2 (Left Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
6. Remove the camshaft position actuator. Refer to «Camshaft Position Actuator Replacement - Bank 2»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-position-actuator-replacement-bank) .
7. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__crankshaft-balancer-replacement) .
8. Rotate the crankshaft with the EN-48589 socket until the camshafts are in a neutral (low tension) position. The camshaft flats will be parallel with the camshaft cover rail (1).
9. Loosen the camshaft position actuator bolt.
10. Install the EN-48383 tool in order to retain the timing chain. Firmly tighten the EN-48383 tool nuts.
11. Mark the timing chain and the respective locations on the camshaft position actuators (1-4).
12. Remove the camshaft position actuator bolt.
13. Remove the camshafts. Refer to «Camshaft Removal - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-removal-left-side-llt) .

1. Locate the camshafts to the cylinder head and assemble the camshaft actuators to the camshafts.
2. Install the camshafts and the camshaft bearing caps. Refer to «Camshaft Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-installation-left-side) .
3. Remove the EN-48383 tool.
4. Install and tighten the camshaft position actuators. Refer to «Camshaft Position Actuator Installation - Left Side Intake»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-position-actuator-installation-left) , and «Camshaft Position Actuator Installation - Left Side Exhaust»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-position-actuator-installation-left) .
5. Install the intake camshaft position actuator solenoid. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 2 (Left Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
6. Install the camshaft sensors. Refer to «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) , and «Camshaft Position Sensor Replacement - Bank 2 (Left Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
7. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__crankshaft-balancer-replacement) .
8. Install the camshaft cover. Refer to «Camshaft Cover Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-cover-replacement-left-side) .
9. Install the fuel pump to the cylinder head. Refer to «Fuel Pump Replacement (LLT)»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions__fuel-pump-replacement-llt) .
10. Install the intake manifold. Refer to «Intake Manifold Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

Camshaft Replacement - Right Side

Special Tools

1. EN-48313 Timing Chain Retention Tool
2. EN 46111 Crankshaft Rotation Socket

1. Remove the intake manifold. Refer to «Intake Manifold Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Remove the camshaft cover. Refer to «Camshaft Cover Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-cover-replacement-right-side) .
3. Remove the camshaft sensors. Refer to «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) , and «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
4. Remove the intake camshaft position actuator solenoid. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 1 (Right Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
5. Remove the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__crankshaft-balancer-replacement) .
6. Rotate the crankshaft with the EN 46111 crankshaft rotation socket until the camshafts are in a neutral (low tension) position. The camshaft flats will be parallel with the camshaft cover rail (1).
7. Loosen the camshaft position actuator bolt.
8. Unscrew the EN-48313 timing chain retention tool so the legs of the tool are retracted.
9. Insert the EN-48313 timing chain retention tool between the camshaft actuators, rearward of the timing chain until the top line that is scribed in the body of the tool (1) is adjacent to the top surface of the cylinder head (2). This is the approximate installed position.
10. Ensure that the feet (2) on the legs of the tool are facing the front of the engine.
11. Partially expand the legs (1) of the EN-48313 timing chain retention tool by turning the T-shaped handle clockwise.
12. Continue expanding the EN-48313 timing chain retention tool until the feet (2) contact the timing chain. Do not tighten at this time.
13. Hand tighten the EN-48313 timing chain retention tool.
14. Use an open end wrench on the hex cast into the body of the EN-48313 timing chain retention tool and hand tighten the T-handle.
15. Use an open end wrench on the hex cast into the right intake and exhaust camshafts and rotate the camshafts towards each other in order to create slack in the chain between the actuators.
16. The EN-48313 timing chain retention tool is now properly installed to hold the timing chain in position.
17. Mark the timing chain and the respective locations on camshaft position actuators (15-18).
18. Remove the camshaft position actuator bolt.
19. Remove the camshaft bearing caps and the camshaft. Refer to «Camshaft Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-removal-right-side) .

1. Locate the camshafts to the cylinder head and assemble the camshaft actuators to the camshafts.
2. Install the camshafts and the camshaft bearing caps. Refer to «Camshaft Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-installation-right-side) .
3. Remove the EN-48313 timing chain retention tool.
4. Install the crankshaft balancer. Refer to «Crankshaft Balancer Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__crankshaft-balancer-replacement) .
5. Install and tighten the camshaft position actuators. Refer to «Camshaft Position Actuator Installation - Right Side Intake»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-position-actuator-installation-right) , and «Camshaft Position Actuator Installation - Right Side Exhaust»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-position-actuator-installation-right) .
6. Install the intake camshaft position actuator solenoid. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 1 (Right Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
7. Install the camshaft sensors. Refer to «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) , and «Camshaft Position Sensor Replacement - Bank 1 (Right Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
8. Install the camshaft cover. Refer to «Camshaft Cover Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-cover-replacement-right-side) .
9. Install the intake manifold. Refer to «Intake Manifold Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

1. Remove the applicable camshaft(s). Refer to «Camshaft Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-replacement-left-side) .
2. Remove the rocker arms. Refer to «Valve Rocker Arm Removal - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
3. Clean and inspect the camshaft(s) and the rocker arm(s). Repair or replace as necessary. Refer to «Camshaft Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-cleaning-and-inspection) , and «Valve Rocker Arm Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-rocker-arm-cleaning-and-inspection) .

1. Install the rocker arms. Refer to «Valve Rocker Arm Installation - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-rocker-arm-installation-left) .
2. Install the applicable camshaft(s). Refer to «Camshaft Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-replacement-left-side) .

1. Remove the applicable camshaft(s). Refer to «Camshaft Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-replacement-right-side) .
2. Remove the rocker arms. Refer to «Valve Rocker Arm Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
3. Clean and inspect the camshaft(s) and the rocker arm(s). Repair or replace as necessary. Refer to «Camshaft Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-cleaning-and-inspection) , and «Valve Rocker Arm Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-rocker-arm-cleaning-and-inspection) .

1. Install the rocker arms.
2. Install the applicable camshaft(s). Refer to «Valve Rocker Arm Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-rocker-arm-installation-right) .

1. Remove the applicable camshaft(s). Refer to «Camshaft Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-replacement-left-side) .
2. Remove the rocker arms. Refer to «Valve Rocker Arm Removal - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
3. Remove the lifters. Refer to «Valve Lifter Removal - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
4. Clean and inspect the camshaft(s), rocker arm(s) and lifter(s). Repair or replace as necessary. Refer to «Camshaft Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-cleaning-and-inspection) , , «Valve Lifter Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-lifter-cleaning-and-inspection) , and «Valve Rocker Arm Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-rocker-arm-cleaning-and-inspection) .

1. Install the lifters. Refer to «Valve Lifter Installation - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-lifter-installation-left-side) .
2. Install the rocker arms. Refer to «Valve Rocker Arm Installation - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-rocker-arm-installation-left) .
3. Install the applicable camshaft(s). Refer to «Camshaft Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-replacement-left-side) .

1. Remove the applicable camshaft(s). Refer to «Camshaft Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-replacement-right-side) .
2. Remove the rocker arms. Refer to «Valve Rocker Arm Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
3. Remove the lifters. Refer to «Valve Lifter Removal - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) .
4. Clean and inspect the camshaft(s), rocker arm(s) and lifter(s). Repair or replace as necessary. Refer to «Camshaft Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-cleaning-and-inspection) , , «Valve Lifter Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-lifter-cleaning-and-inspection) , and «Valve Rocker Arm Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-rocker-arm-cleaning-and-inspection) .

1. Install the lifters. Refer to «Valve Lifter Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-lifter-installation-right-side) .
2. Install the rocker arms. Refer to «Valve Rocker Arm Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__valve-rocker-arm-installation-right) .
3. Install the applicable camshaft(s). Refer to «Camshaft Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-replacement-right-side) .

Valve Stem Oil Seal and Valve Spring Replacement - Left Side

Special Tools

1. EN 46106 Flywheel Holding Tool
2. EN 46110 On-Vehicle Valve Spring Compressor
3. EN 46116 Valve Stem Seal Remover/Installer
4. J 39313 Spark Plug Port Adapter

1. Remove the starter motor. Refer to «Starter Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
2. Install the EN 46106 flywheel holding tool in order to prevent crankshaft rotation.
3. Remove the camshafts and rocker arms. Refer to «Camshaft Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-replacement-left-side) .
4. Remove the spark plug from the applicable cylinder. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
5. Remove Rocker arm. refer to «Valve Rocker Arm Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle)
6. Install the J 39313 spark plug port adapter to the applicable cylinder.
7. Connect the J 39313 spark plug port adapter to a compressed air source.
8. Install the EN 46110 on-vehicle valve spring compressor above the applicable cylinder as shown.
9. Tighten the EN 46110 on-vehicle valve spring compressor valve spring compressor nut (2).
10. Remove the valve keepers.
11. Loosen the EN 46110 on-vehicle valve spring compressor valve spring compressor nut.
12. Remove the valve spring retainer.
13. Remove the valve spring.
14. Use the EN 46116 valve stem seal remover/installer (1) in order to remove the valve stem seal (2).

1. Use the EN 46116 valve stem seal remover/installer (1) in order to install the valve stem seal (2).
2. Install the valve spring.
3. Install the valve spring retainer.
4. Install the EN 46110 on-vehicle valve spring compressor above the applicable valve spring as shown. Tighten the EN 46110 on-vehicle valve spring compressor valve spring compressor nut (2).
5. Install the valve spring keepers.
6. Remove the EN 46110 on-vehicle valve spring compressor.
7. Disconnect the J 39313 spark plug port adapter from the compressed air source.
8. Remove the J 39313 spark plug port adapter.
9. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
10. Install the rocker arms and camshafts. Refer to «Camshaft Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-replacement-left-side) .
11. Remove the EN 46106 flywheel holding tool in order to prevent crankshaft rotation.
12. Install the starter motor. Refer to «Starter Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .

Valve Stem Oil Seal and Valve Spring Replacement - Right Side

Special Tools

1. EN 46106 Flywheel Holding Tool
2. EN 46110 On-Vehicle Valve Spring Compressor
3. EN 46116 Valve Stem Seal Remover/Installer
4. J 39313 Spark Plug Port Adapter

1. Remove the starter motor. Refer to «Starter Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
2. Install the EN 46106 flywheel holding tool in order to prevent crankshaft rotation.
3. Remove the camshafts and rocker arms. Refer to «Camshaft Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-replacement-right-side) , «Valve Rocker Arm Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
4. Remove the spark plug from the applicable cylinder. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
5. Install the J 39313 spark plug port adapter to the applicable cylinder.
6. Connect the J 39313 spark plug port adapter to a compressed air source.
7. Install the EN 46110 on-vehicle valve spring compressor above the applicable cylinder as shown.
8. Tighten the EN 46110 on-vehicle valve spring compressor valve spring compressor nut (2).
9. Remove the valve keepers.
10. Loosen the EN 46110 on-vehicle valve spring compressor valve spring compressor nut.
11. Remove the valve spring retainer.
12. Remove the valve springs.
13. Use the EN 46116 valve stem seal remover/installer (1) in order to remove the valve stem seal (2).

1. Use the EN 46116 valve stem seal remover/installer (1) in order to install the valve stem seals (2).
2. Install the valve spring.
3. Install the valve spring retainer.
4. Install the EN 46110 on-vehicle valve spring compressor above the applicable valve spring as shown. Tighten the EN 46110 on-vehicle valve spring compressor valve spring compressor nut (2).
5. Install the valve spring keepers.
6. Remove the EN 46110 on-vehicle valve spring compressor.
7. Disconnect the J 39313 spark plug port adapter from the compressed air source.
8. Remove the J 39313 spark plug port adapter.
9. Install the spark plugs. Refer to «Spark Plug Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
10. Install the rocker arms and camshafts. Refer to «Camshaft Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__camshaft-replacement-right-side) .
11. Remove the EN 46106 flywheel holding tool.
12. Install the starter motor. Refer to «Starter Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .

1. Remove the left bank secondary timing chain. Refer to «Secondary Camshaft Intermediate Drive Chain Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Remove the oil level indicator. Refer to «Oil Level Indicator Tube Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
3. Disconnect the coolant temperature sensor electrical connector.
4. Remove the catalytic converter from the exhaust manifold. Refer to «Catalytic Converter Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/exhaust/#engine-exhaust-system) .
5. Remove the camshaft position actuator solenoid valve. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 2 (Left Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) , and «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 2 (Left Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
6. Remove the cylinder head (1) with the exhaust manifold. Refer to «Cylinder Head Removal - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__cylinder-head-removal-left-side) .
7. Remove and discard the cylinder head gasket.
8. Clean and inspect the cylinder head and the engine block sealing surfaces. Refer to «Cylinder Head Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__cylinder-head-cleaning-and-inspection) , and «Engine Block Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__engine-block-cleaning-and-inspection) .
9. If necessary, perform the following steps: Remove the exhaust manifold from the cylinder head. Refer to «Exhaust Manifold Removal - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__exhaust-manifold-removal-left-side) . Remove the camshaft. Refer to «Camshaft Removal - Left Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-removal-left-side-llt) . Disassemble the cylinder head. Refer to «Cylinder Head Disassemble»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__cylinder-head-disassemble) . Remove the coolant sensor. Refer to «Engine Coolant Temperature Sensor Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .

1. If necessary, perform the following steps: Install the coolant sensor. Refer to «Engine Coolant Temperature Sensor Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) . Assemble the cylinder head. Refer to «Cylinder Head Assemble (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__cylinder-head-assemble-llt) . Install the camshaft. Refer to «Camshaft Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-installation-left-side) . Install the exhaust manifold to the cylinder head. Refer to «Exhaust Manifold Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__exhaust-manifold-installation-left-side) .
2. Install a NEW cylinder head gasket.
3. Carefully install the cylinder head with the exhaust manifold to the engine. Refer to «Cylinder Head Installation - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__cylinder-head-installation-left-side) .
4. Install the camshaft position actuator solenoid valve. Refer to «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 2 (Left Side) Intake»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) , and «Camshaft Position Actuator Solenoid Valve Solenoid Replacement - Bank 2 (Left Side) Exhaust»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
5. Install the catalytic converter to the exhaust manifold. Refer to «Catalytic Converter Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/exhaust/#engine-exhaust-system) .
6. Connect the wiring harness electrical connector located at the side of the cylinder head.
7. Install the coolant temperature sensor electrical connector.
8. Install the oil level indicator. Refer to «Oil Level Indicator Tube Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
9. Install the left bank secondary timing chain. Refer to «Secondary Camshaft Intermediate Drive Chain Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

1. Remove the right bank secondary timing chain. Refer to «Secondary Camshaft Intermediate Drive Chain Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Remove the right side catalytic converter from the exhaust manifold. Refer to «Catalytic Converter Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/exhaust/#engine-exhaust-system) .
3. Remove the ground wires from the cylinder head.
4. Disconnect and unclip the heated oxygen sensor (HO2) wiring harness.
5. Unbolt the power steering hose retainer.
6. Remove the cylinder head (1) with the exhaust manifold. Refer to «Cylinder Head Removal - Right Side (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__cylinder-head-removal-right-side) .
7. Remove and discard the cylinder head gasket.
8. Clean and inspect the cylinder head and the engine block sealing surfaces. Refer to «Cylinder Head Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__cylinder-head-cleaning-and-inspection) , and «Engine Block Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__engine-block-cleaning-and-inspection) .
9. If necessary, perform the following steps: Remove the exhaust manifold from the cylinder head. Refer to «Exhaust Manifold Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__exhaust-manifold-removal-right-side) . Remove the camshaft. Refer to «Camshaft Removal - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-removal-right-side) . Disassemble the cylinder head. Refer to «Cylinder Head Disassemble»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__cylinder-head-disassemble) .

1. If necessary, perform the following steps: Assemble the cylinder head. Refer to «Cylinder Head Assemble (LLT)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__cylinder-head-assemble-llt) . Install the camshaft. Refer to «Camshaft Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__camshaft-installation-right-side) . Install the exhaust manifold to the cylinder head. Refer to «Exhaust Manifold Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__exhaust-manifold-installation-right-side) .
2. Install a NEW cylinder head gasket.
3. Install the cylinder head (1) with the exhaust manifold to the engine. Refer to «Cylinder Head Installation - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__cylinder-head-installation-right-side) .
4. Install the power steering hose retainer.
5. Connect and clip the HO2 sensor wiring harness.
6. Install the ground wires to the cylinder head.
7. Install the right side catalytic converter to the exhaust manifold. Refer to «Catalytic Converter Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/exhaust/#engine-exhaust-system) .
8. Install the right bank secondary timing chain. Refer to «Secondary Camshaft Intermediate Drive Chain Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

1. Remove the transmission. Refer to «Transmission Replacement (Front Wheel Drive)»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle) , «Transmission Replacement (All Wheel Drive)»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle) .
2. Remove the engine flywheel bolts and flywheel. Refer to «Engine Flywheel Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__engine-flywheel-removal) .
3. Clean and inspect the flywheel. Refer to «Engine Flywheel Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle) , . If the flywheel teeth are damaged, inspect the starter for proper operation. Replace the starter if you find excessive wear or damage to the starter drive. Refer to «Starter Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .

1. Install the engine flywheel and bolts. Refer to «Engine Flywheel Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__engine-flywheel-installation) .
2. Install the transmission. Refer to «Transmission Replacement (Front Wheel Drive)»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle) , «Transmission Replacement (All Wheel Drive)»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle) .

1. Remove the oil pan. Refer to «Oil Pan Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__oil-pan-replacement) .
2. Remove the engine flywheel. Refer to «Engine Flywheel Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
3. Remove the crankshaft rear oil seal and housing. Refer to «Crankshaft Rear Oil Seal and Housing Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__crankshaft-rear-oil-seal-and-housing) .

1. Install the crankshaft rear oil seal and housing. Refer to «Crankshaft Rear Oil Seal and Housing Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__crankshaft-rear-oil-seal-and-housing) .
2. Install the engine flywheel. Refer to «Engine Flywheel Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
3. Install the oil pan. Refer to «Oil Pan Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__oil-pan-replacement) .

1. Remove the primary timing chain. Refer to «Primary Camshaft Drive Chain and Sprockets Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__primary-camshaft-drive-chain-and-sprockets) .
2. Remove the oil pump bolts and the oil pump. Refer to «Oil Pump Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__oil-pump-removal) .

1. Install the oil pump. Refer to «Oil Pump Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__oil-pump-installation) .
2. Install the primary timing chain. Refer to «Primary Camshaft Drive Chain and Sprockets Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__primary-camshaft-drive-chain-and-sprockets) .

Oil Pan Replacement

Special Tools

1. EN 46109 Guide Pin Set
2. J 39505 Torque Wrench Adapter

1. Drain the engine oil and remove the oil filter. Refer to «Engine Oil and Oil Filter Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Remove the exhaust flexible pipe. Refer to «Exhaust Flexible Pipe Replacement»(/buick/enclave/i-2007-2013/remont/exhaust/#engine-exhaust-system) .
3. Remove the engine. Refer to «Engine Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
4. Remove the engine front cover. Refer to «Engine Front Cover Removal»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__engine-front-cover-removal) .
5. Remove the oil pan bolts.
6. Using the pry points located at the edge of the oil pan separate the RTV sealant.
7. Remove the oil pan from the block.
8. Clean the oil pan and the engine block gasket surface. Refer to «Oil Pan Cleaning and Inspection»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__oil-pan-cleaning-and-inspection) .

1. Install the 8 mm (0.315 in) guides from the EN 46109 guide pin set into the center oil pan rail bolt hole on each side of the engine block.
2. Place a 3 mm (0.118 in) bead (1) of RTV sealant, GM P/N 12378521 (Canadian P/N 88901148) or equivalent, on the block pan rail and the crankshaft rear oil seal housing.
3. Position the oil pan onto the block.
4. Remove the EN 46109 guide pin set 8 mm (0.315 in) guides from the engine block.
5. Loosely install the oil pan bolts.
6. Tighten the oil pan bolts in sequence shown. Tighten Tighten the 8 mm bolts (1-11) to 25 N.m (18 lb ft). Tighten the 6 mm bolts (12, 13) to 10 N.m (89 lb in).
7. Install the engine front cover. Refer to «Engine Front Cover Installation»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-off-vehicle__engine-front-cover-installation) .
8. Install the engine. Refer to «Engine Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
9. Install the exhaust flexible pipe. Refer to «Exhaust Flexible Pipe Replacement»(/buick/enclave/i-2007-2013/remont/exhaust/#engine-exhaust-system) .
10. Refill the engine oil. Refer to «Engine Oil and Oil Filter Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .

Engine Oil Pressure Sensor and/or Switch Replacement

Special Tools

J 41712 Oil Pressure Switch Socket

1. Turn the ignition OFF.
2. Remove the generator. Refer to «GENERATOR REPLACEMENT»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
3. Disconnect the oil pressure sensor electrical connector.
4. Remove the oil pressure sensor (1).

1. Install the oil pressure sensor (1). Tighten Tighten the oil pressure sensor to 20 N.m (15 lb ft).
2. Connect the oil pressure sensor electrical connector.
3. Install the generator. Refer to «GENERATOR REPLACEMENT»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .

1. Remove the oil pan. Refer to «Oil Pan Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__oil-pan-replacement) .
2. Remove the oil pan scraper bolts.
3. Remove the oil pan scraper.
4. Remove the oil suction pipe bolts.
5. Remove the oil suction pipe.
6. Remove the oil suction tube seal from the oil suction tube. Discard the oil suction tube seal.

1. Install a NEW oil suction tube seal onto the oil suction tube. DO NOT reuse the old oil suction tube seal.
2. Install the oil suction pipe.
3. Install the oil suction pipe bolts. Tighten Tighten the oil suction pipe bolts to 10 N.m (89 lb in).
4. Install the oil pan scraper.
5. Install the oil pan scraper bolts. Tighten Tighten the oil pan scraper bolts to 10 N.m (89 lb in).
6. Install the oil pan. Refer to «Oil Pan Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle__oil-pan-replacement) .

1. Remove the fuel injector sight shield. Refer to «Fuel Injector Sight Shield Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
2. Disconnect the brake booster vacuum hose (2) from the intake manifold.
3. Remove the air cleaner assembly. Refer to «Air Cleaner Assembly Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
4. Discharge the fuel system. Refer to «Fuel Pressure Relief (Without CH-48027)»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions__fuel-pressure-relief-without-ch-48027) , «Fuel Pressure Relief (CH-48027)»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions__fuel-pressure-relief-ch-48027) , «Fuel Pressure Relief (High Side)»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions__fuel-pressure-relief-high-side) .
5. Disconnect the evaporative emission (EVAP) hose/pipe (3) from the EVAP canister purge solenoid valve. Refer to «Plastic Collar Quick Connect Fitting Service»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
6. Disconnect the engine fuel hose/pipe (3) from the chassis fuel hose/pipe (2). Refer to «Metal Collar Quick Connect Fitting Service»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions__metal-collar-quick-connect-fitting-service) .
7. Discharge the air conditioning (A/C) system. Refer to «Refrigerant Recovery and Recharging»(/buick/enclave/i-2007-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
8. Remove the A/C compressor suction hose assembly (2) from the compressor. Cap or plug the hoses and compressor to prevent contamination. Refer to «Suction Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__suction-hose-replacement) .
9. Remove the A/C compressor discharge hose assembly (3) from the compressor. Cap or plug the hoses and compressor to prevent contamination. Refer to «Discharge Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__discharge-hose-replacement) .
10. Drain the engine coolant from the cooling system. Refer to «Cooling System Draining and Filling (Static Fill)»(/buick/enclave/i-2007-2013/remont/cooling-system-mechanical/#engine-cooling-system) , «Cooling System Draining and Filling (Vac N Fill)»(/buick/enclave/i-2007-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
11. Remove the coolant recovery reservoir. Refer to «Coolant Recovery Reservoir Replacement»(/buick/enclave/i-2007-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
12. Disconnect the inlet coolant heater hose from the engine. Refer to «Heater Inlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
13. Disconnect the outlet coolant heater hose from the engine. Refer to «Heater Outlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning)
14. Remove the radiator inlet hose. Refer to «Radiator Inlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
15. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(/buick/enclave/i-2007-2013/remont/ignition-switchsteering-lock/#general-information__lifting-and-jacking-the-vehicle) .
16. Remove the radiator outlet hose. Refer to «Radiator Outlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
17. Remove the exhaust flexible pipe and secure the rear half of the exhaust system to the vehicle underbody. Refer to «Exhaust Flexible Pipe Replacement»(/buick/enclave/i-2007-2013/remont/exhaust/#engine-exhaust-system) .
18. Remove the front tires. Refer to «Tire and Wheel Removal and Installation»(/buick/enclave/i-2007-2013/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
19. Remove the steering intermediate shaft pinch bolt (1) in order to disconnect the steering intermediate shaft from the steering gear.
20. Disconnect the transaxle shift cable (2). Refer to «Range Selector Lever Cable Replacement»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle) .
21. Disconnect the transaxle cooler lines. Refer to «Fluid Cooler Inlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle) , and «Fluid Cooler Outlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle__fluid-cooler-outlet-hose-replacement) .
22. Disconnect the negative battery extension cable. Refer to «Battery Negative Cable Extension Cable Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
23. Disconnect all engine electrical connectors.
24. Remove the right and left steering linkage outer tie rod ends from the steering knuckles. Refer to «Steering Linkage Outer Tie Rod Replacement»(/buick/enclave/i-2007-2013/remont/manual-power-steering/#power-steering-system__steering-linkage-outer-tie-rod-replacement) .
25. Remove the right and left stabilizer shaft links from the stabilizer shaft. Refer to «Stabilizer Shaft Link Replacement»(/buick/enclave/i-2007-2013/remont/suspension-front/#front-suspension-system) .
26. Remove the right and left lower ball joints from the steering knuckles. Refer to «Lower Control Arm Replacement»(/buick/enclave/i-2007-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .
27. Place a drain pan under the transaxle then separate the right and left front wheel drive shafts from the transaxle/transfer case. Refer to «Front Wheel Drive Shaft Replacement»(/buick/enclave/i-2007-2013/remont/axle-shafts/#wheel-drive-shafts__front-wheel-drive-shaft-replacement) .
28. On all wheel drive (AWD) models, remove the propeller shaft retaining bolts (1) in order to remove the shaft. Refer to «Propeller Shaft Replacement»(/buick/enclave/i-2007-2013/remont/driveshaft-universal-joints/#propeller-shaft) .
29. Remove the engine mount strut. Refer to «Engine Mount Strut Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
30. Disconnect the power steering hoses at the power steering fluid cooler (1). Refer to «Power Steering Cooler Pipe/Hose Replacement»(/buick/enclave/i-2007-2013/remont/manual-power-steering/#power-steering-system) .
31. Place a universal frame support fixture or jackstands under the frame.
32. Lower the vehicle until the frame contacts the frame support fixture or jackstands.
33. Remove the subframe to body bracket bolts.
34. Remove the frame-to-body bolts (1).
35. Carefully raise the vehicle body up away from the powertrain.
36. Disconnect the engine electrical wiring harness from the following components: Oxygen sensor (1) EVAP purge solenoid (2) Ignition coils (3, 4, 10) Ground lead (7) Remove wire harness from retainers (5, 6, 8, 9)
37. Disconnect the left and right cylinder head engine electrical wiring harness from the following components: Camshaft position sensors (1) Camshaft position actuators (2)
38. Disconnect the engine electrical wiring harness from the following components: Generator (1) Retainer clips (2, 3, 4, 5, 6, 7, 9) A/C compressor hose (8) Oil pressure switch (10) A/C compressor (8)
39. Disconnect the engine electrical wiring harness from the following components: Battery cable Retainer clips (2) Transmission module (1)
40. If equipped with an engine coolant heater, disconnect the coolant heater cord.
41. Remove the throttle body assembly. Refer to «Throttle Body Assembly Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
42. On FWD vehicles, remove the engine-to-transaxle brace bolts and brace.
43. On AWD vehicles, perform the following: Remove the front wheel drive intermediate shaft. Refer to «Front Wheel Drive Intermediate Shaft Replacement»(/buick/enclave/i-2007-2013/remont/axle-shafts/#wheel-drive-shafts) . Remove the engine rear mount bracket. Refer to «Engine Rear Mount Bracket Replacement (Front Wheel Drive)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) , «Engine Rear Mount Bracket Replacement (All Wheel Drive)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) . Remove the transfer case. Refer to «Transfer Case Assembly Replacement»(/buick/enclave/i-2007-2013/remont/transfer-case/#transfer-case-getrag-790) .
44. Remove the starter motor (2). Refer to «Starter Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
45. Remove the torque converter bolts (1).
46. Using a engine hoist and lift chain, support the engine weight.
47. Support the bellhousing of the transmission with a block of wood.
48. Remove the automatic transaxle bolts (1, 2).
49. Remove the front and rear engine mount to mount bracket nuts.
50. Separate the automatic transaxle from the engine.
51. Lift the engine (1) away from the frame and the automatic transaxle (2).
52. Secure the engine to an engine stand.
53. Remove any additional engine components as necessary. Refer to appropriate component sections in manual if needed.

1. Using a engine hoist and lift chain, remove the engine from the engine stand.
2. Align the engine (1) to the frame and automatic transaxle (2).
3. Install the automatic transaxle bolts (1, 2) and tighten to 75 N.m (55 lb ft).
4. Remove the engine hoist and lift chain.
5. Install the front and rear engine mount to bracket nuts, and tighten to 50 N.m (37 lb ft).
6. Install the torque converter bolts (1) and tighten to 60 N.m (44 lb ft).
7. Install the starter motor (2). Refer to «Starter Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
8. On FWD vehicles, install the engine to transaxle brace and bolts and tighten to 50 N.m (37 lb ft).
9. On AWD vehicles, perform the following: Install the transfer case. Refer to «Transfer Case Assembly Replacement»(/buick/enclave/i-2007-2013/remont/transfer-case/#transfer-case-getrag-790) . Install the engine rear mount bracket. Refer to «Engine Rear Mount Bracket Replacement (Front Wheel Drive)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) , «Engine Rear Mount Bracket Replacement (All Wheel Drive)»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) . Install the front wheel drive intermediate shaft. Refer to «Front Wheel Drive Intermediate Shaft Replacement»(/buick/enclave/i-2007-2013/remont/axle-shafts/#wheel-drive-shafts) .
10. Install the throttle body assembly. Refer to «Throttle Body Assembly Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
11. If equipped with an engine coolant heater, connect the coolant heater cord.
12. Connect the engine electrical wiring harness to the following components: Transmission module (1) Retainer clips (2) Battery cable
13. Install the battery cable to the cylinder head and tighten the bolt to 25 N.m (18 lb ft).
14. Connect the engine electrical wiring harness to the following components: A/C compressor (8) Oil pressure switch (10) A/C compressor hose (8) Retainer clips (2, 3, 4, 5, 6, 7, 9)
15. Install the Generator terminal connector and nut (1) and tighten to 13 N.m (115 lb in).
16. Connect the left and right cylinder head engine electrical wiring harness to the following components: Camshaft position actuators (2) Camshaft position sensors (1)
17. Connect the engine electrical wiring harness to the following components: Install wire harness to retainers (5, 6, 8, 9) Ground lead (7) Ignition coils (3, 4, 10) EVAP purge solenoid (2) Oxygen sensor (1)
18. Install the frame-to-body bolts (1) and tighten to 100 N.m (74 lb ft) + 90 degrees.
19. Install the subframe to body bracket bolts and tighten to 60 N.m (44 lb ft).
20. Raise the vehicle and remove the support fixture or jackstands from under the vehicle.
21. Connect the power steering hoses to the power steering fluid cooler (1). Refer to «Power Steering Cooler Pipe/Hose Replacement»(/buick/enclave/i-2007-2013/remont/manual-power-steering/#power-steering-system) .
22. Install the left transaxle mount bracket. Refer to «Transmission Mount Bracket Replacement - Left Side»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle) .
23. Install the engine mount strut. Refer to «Engine Mount Strut Replacement - Right Side»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
24. Raise the vehicle.
25. On AWD models, install the propeller shaft and retainers (1). Refer to «Propeller Shaft Replacement»(/buick/enclave/i-2007-2013/remont/driveshaft-universal-joints/#propeller-shaft) .
26. On FWD models, install the right and left front wheel drive shafts into the transaxle. Refer to «Front Wheel Drive Shaft Replacement»(/buick/enclave/i-2007-2013/remont/axle-shafts/#wheel-drive-shafts__front-wheel-drive-shaft-replacement) .
27. On all models, install the right and left lower ball joints to the steering knuckles. Refer to «Lower Control Arm Replacement»(/buick/enclave/i-2007-2013/remont/suspension-front/#front-suspension-system__lower-control-arm-replacement) .
28. Install the right and left stabilizer shaft links to the stabilizer shaft. Refer to «Stabilizer Shaft Link Replacement»(/buick/enclave/i-2007-2013/remont/suspension-front/#front-suspension-system) .
29. Install the right and left steering linkage outer tie rod ends to the steering knuckles. Refer to «Steering Linkage Outer Tie Rod Replacement»(/buick/enclave/i-2007-2013/remont/manual-power-steering/#power-steering-system__steering-linkage-outer-tie-rod-replacement) .
30. Connect all engine electrical connectors.
31. Connect the negative battery extension cable. Refer to «Battery Negative Cable Extension Cable Replacement»(/buick/enclave/i-2007-2013/remont/charging-system/#battery-charging-system-and-starting-system) .
32. Connect the transaxle shift cable (2). Refer to «Range Selector Lever Cable Replacement»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle) .
33. Connect the transaxle cooler lines. Refer to «Fluid Cooler Inlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle) , and «Fluid Cooler Outlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-repair-instructions-on-vehicle__fluid-cooler-outlet-hose-replacement) .
34. Connect the steering intermediate shaft to the steering gear and install the pinch bolt (1). Refer to «Intermediate Steering Shaft Replacement»(/buick/enclave/i-2007-2013/remont/steering-column-switches/#steering-wheel-and-steering-column) .
35. Install the front tires. Refer to «Tire and Wheel Removal and Installation»(/buick/enclave/i-2007-2013/remont/wheel-tire-system/#tires-and-wheels__tire-and-wheel-removal-and-installation) .
36. Install the exhaust flexible pipe. Refer to «Exhaust Flexible Pipe Replacement»(/buick/enclave/i-2007-2013/remont/exhaust/#engine-exhaust-system) .
37. Install the radiator outlet hose. Refer to «Radiator Outlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
38. Lower the vehicle.
39. Install the radiator inlet hose. Refer to «Radiator Inlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
40. Connect the outlet coolant heater hose to the engine. Refer to «Heater Outlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning)
41. Connect the inlet coolant heater hose to the engine. Refer to «Heater Inlet Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning) .
42. Install the coolant recovery reservoir. Refer to «Coolant Recovery Reservoir Replacement»(/buick/enclave/i-2007-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
43. Install the A/C compressor discharge hose (3) assembly to the compressor. Refer to «Discharge Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__discharge-hose-replacement) .
44. Install the A/C compressor suction hose assembly (2) to the compressor. Refer to «Suction Hose Replacement»(/buick/enclave/i-2007-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__suction-hose-replacement) .
45. Connect the engine fuel hose/pipe (3) to the chassis fuel hose/pipe (2). Refer to «Metal Collar Quick Connect Fitting Service»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions__metal-collar-quick-connect-fitting-service) .
46. Connect the EVAP hose/pipe (3) to the EVAP canister purge solenoid valve. Refer to «Plastic Collar Quick Connect Fitting Service»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
47. Install the air cleaner assembly. Refer to «Air Cleaner Assembly Replacement»(/buick/enclave/i-2007-2013/remont/testing-diagnostics/#engine-controlsfuel-36l-repair-instructions) .
48. Connect the brake booster vacuum hose (2) to the intake manifold.
49. Position the clamp (1) on the brake booster vacuum hose connection.
50. Install the fuel injector sight shield. Refer to «Fuel Injector Sight Shield Replacement»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-repair-instructions-on-vehicle) .
51. Fill the engine with engine oil. Refer to «Approximate Fluid Capacities»(/buick/enclave/i-2007-2013/remont/lubrication-system/#maintenance-and-lubrication__approximate-fluid-capacities) , , «Fluid and Lubricant Recommendations»(/buick/enclave/i-2007-2013/remont/lubrication-system/#maintenance-and-lubrication__fluid-and-lubricant-recommendations) , , and «Maintenance Schedule (North American Emissions)»(/buick/enclave/i-2007-2013/remont/lubrication-system/#maintenance-and-lubrication__maintenance-schedule-north-american-emissions) .
52. Fill the engine with coolant. Refer to «Cooling System Draining and Filling (Static Fill)»(/buick/enclave/i-2007-2013/remont/cooling-system-mechanical/#engine-cooling-system) , «Cooling System Draining and Filling (Vac N Fill)»(/buick/enclave/i-2007-2013/remont/cooling-system-mechanical/#engine-cooling-system) .
53. Check the transaxle fluid level. Refer to «Adhesives, Fluids, Lubricants, and Sealers»(/buick/enclave/i-2007-2013/remont/mechanical/#engine-mechanical-36l-specifications__adhesives-fluids-lubricants-and-sealers) , , «Transmission General Specifications»(/buick/enclave/i-2007-2013/remont/automatic-trans/#automatic-transmission-6t75-specifications__transmission-general-specifications) , , and «Approximate Fluid Capacities»(/buick/enclave/i-2007-2013/remont/lubrication-system/#maintenance-and-lubrication__approximate-fluid-capacities) .
54. Charge the AC system. Refer to «Refrigerant Recovery and Recharging»(/buick/enclave/i-2007-2013/remont/automatic-hvac-system/#heating-ventilation-and-air-conditioning__refrigerant-recovery-and-recharging) .
55. Add power steering fluid and bleed air from the power steering system. Refer to «Power Steering System Bleeding»(/buick/enclave/i-2007-2013/remont/manual-power-steering/#power-steering-system) .
56. Prime the fuel system. Cycle the ignition ON for 5 seconds then OFF for 10 seconds. Repeat cycling twice. Crank the engine until it starts. The maximum starter motor cranking time is 20 seconds. If the engine does not start, repeat the steps.

1. Place the drain pan under the oil filter.
2. Loosen the oil filter. Allow the oil to drain completely.
3. Wrap the oil filter in a disposable towel or rag. Remove the oil filter, keep it upright until it is clear of the vehicle.
4. Thoroughly clean all oil spillage.
5. Lubricate the NEW oil filter gasket with clean engine oil and tighten the oil filter to 25 N.m (18 lb ft).
6. Place a drain pan under the oil pan drain plug.
7. Remove the oil pan drain plug (1). Allow the oil to drain completely.

1. Install the oil pan drain plug and tighten to 25 N.m (18 lb ft).
2. Clean the oil pan drain plug and oil filter areas from below.
3. Lower the vehicle.
4. Refill the engine oil. Refer to «Approximate Fluid Capacities»(/buick/enclave/i-2007-2013/remont/lubrication-system/#maintenance-and-lubrication__approximate-fluid-capacities) .
5. Start the engine and inspect for leaks.

See also:
• FRONT WHEELHOUSE FRONT LINER REPLACEMENT (ENCLAVE - ACADIA)
• Fastener Caution
• Generator Replacement
• Front Compartment Sight Shields Replacement (Traverse)
• Special Tools
• Transmission Mount Replacement - Left Side
• Lifting and Jacking the Vehicle
• Adhesives, Fluids, Lubricants, and Sealers
• Catalytic Converter Replacement - Left Side
• Front Wheel Drive Intermediate Shaft Replacement
• Front Wheel Drive Shaft Replacement
• Radiator Inlet Hose Replacement
• Underhood Electrical Center or Junction Block Replacement
• Plastic Collar Quick Connect Fitting Service
• Intake Manifold Disassemble
• Intake Manifold Cleaning and Inspection
• Intake Manifold Assemble
• Power Steering Fluid Reservoir Bracket Replacement
• Intake Manifold Removal
• Camshaft Cover Removal - Left Side (LLT)
• Camshaft Cover Removal - Right Side
• Water Outlet Removal
• Drive Belt Tensioner Removal
• Water Pump Removal
• Crankshaft Balancer Removal
• Drive Belt Idler Pulley Removal
• Engine Front Cover Removal
• Engine Front Cover Installation
• Drive Belt Idler Pulley Installation
• Crankshaft Balancer Installation
• Water Pump Installation
• Drive Belt Tensioner Installation
• Water Outlet Installation
• Camshaft Cover Installation - Left Side
• Camshaft Cover Installation - Right Side
• Intake Manifold Installation
• Secondary Timing Chain Tensioner Removal - Right Side
• Secondary Camshaft Drive Chain Shoe Removal - Right Side
• Secondary Timing Chain Guide Removal - Right Side
• Primary Camshaft Intermediate Drive Chain Tensioner Removal
• Primary Timing Chain Guide Removal - Upper
• Timing Chain Idler Sprocket Removal - Right Side
• Secondary Camshaft Intermediate Drive Chain Installation - Left Side (LLT)
• Timing Chain Idler Sprocket Installation - Left Side
• Secondary Timing Chain Guide Installation - Left Side
• Secondary Camshaft Drive Chain Shoe Installation - Left Side
• Secondary Timing Chain Tensioner Installation - Left Side
• Primary Camshaft Intermediate Drive Chain Installation
• Primary Timing Chain Guide Installation - Upper
• Timing Chain Alignment Diagram
• Torque Reaction Against Timing Drive Chain Caution
• Fuel Pump Replacement (LLT)
• Camshaft Removal - Left Side (LLT)
• Camshaft Installation - Left Side
• Camshaft Position Actuator Installation - Left Side Intake
• Camshaft Removal - Right Side
• Camshaft Installation - Right Side
• Camshaft Position Actuator Installation - Right Side Intake
• Camshaft Cleaning and Inspection
• Valve Rocker Arm Cleaning and Inspection
• Valve Rocker Arm Installation - Left Side (LLT)
• Valve Rocker Arm Installation - Right Side
• Valve Lifter Cleaning and Inspection
• Valve Lifter Installation - Left Side (LLT)
• Valve Lifter Installation - Right Side
• Cylinder Head Removal - Left Side (LLT)
• Cylinder Head Cleaning and Inspection
• Engine Block Cleaning and Inspection
• Exhaust Manifold Removal - Left Side
• Cylinder Head Disassemble
• Cylinder Head Assemble (LLT)
• Exhaust Manifold Installation - Left Side
• Cylinder Head Installation - Left Side
• Cylinder Head Removal - Right Side (LLT)
• Exhaust Manifold Removal - Right Side
• Exhaust Manifold Installation - Right Side
• Cylinder Head Installation - Right Side
• Engine Flywheel Removal
• Engine Flywheel Installation
• Crankshaft Rear Oil Seal and Housing Removal
• Oil Pump Removal
• Oil Pump Installation
• Oil Pan Cleaning and Inspection
• Fuel Pressure Relief (Without CH-48027)
• Fuel Pressure Relief (CH-48027)
• Fuel Pressure Relief (High Side)
• Metal Collar Quick Connect Fitting Service
• Refrigerant Recovery and Recharging
• Suction Hose Replacement
• Discharge Hose Replacement
• Heater Inlet Hose Replacement
• Tire and Wheel Removal and Installation
• Fluid Cooler Outlet Hose Replacement
• Steering Linkage Outer Tie Rod Replacement
• Stabilizer Shaft Link Replacement
• Lower Control Arm Replacement
• Propeller Shaft Replacement
• Transfer Case Assembly Replacement
• Intermediate Steering Shaft Replacement
• Approximate Fluid Capacities
• Fluid and Lubricant Recommendations
• Maintenance Schedule (North American Emissions)
• Transmission General Specifications
• Hot Exhaust System Warning
• Engine Mount Strut Replacement - Right Side
• Crankshaft Balancer Replacement
• Engine Front Cover Replacement
• Setting Camshaft Timing
• Camshaft Cover Replacement - Right Side
• Camshaft Cover Replacement - Left Side
• Camshaft Position Actuator Replacement - Bank 2
• Camshaft Replacement - Left Side
• Camshaft Replacement - Right Side
• Oil Pan Replacement
• Primary Camshaft Drive Chain and Sprockets Replacement
