Interior Trim and Interior Paneling Buick Enclave I

Exterior/interior Trim 40 illustrations ~930 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Center Pillar Assit Handle Screw1.2 N.m10 lb in
Coat Hook Screw9 N.m80 lb in
Front Side Door Trim Panel Bolts2 N.m18 lb in
Liftgate Trim Finish Panel Screws2 N.m18 lb in
Rear Quarter Upper Trim Panel Screws3 N.m27 lb in
Rear Quarter Lower Trim Panel Screws3 N.m27 lb in
Rear Side Door Trim Panel Screws2 N.m18 lb in
Sunshade Anchor Screws3 N.m25 lb in
Sunshade Screws3 N.m25 lb in
Windshield Pillar Garnish Molding Bolts2 N.m18 lb in

Fastener Tightening Specifications

Scheme 60

Scheme 60: Front Side Door Armrest Switch Mount Plate Replacement (Driver Side Traverse without A45)
Scheme 60: Front Side Door Armrest Switch Mount Plate Replacement (Driver Side Traverse without A45)
CalloutComponent Name
1Front Side Door Armrest Switch Mount Plate Driver Side Assembly Procedure Use a flat-bladed plastic trim tool in order to release the front side door armrest switch mount plate from the door trim assembly. Disconnect the electrical connector from the switch assembly. Transfer parts as necessary.

Front Side Door Armrest Switch Mount Plate Replacement (Driver Side Traverse without A45)

Scheme 61

Scheme 61: Front Side Door Armrest Switch Mount Plate Replacement (Passenger Side Traverse without A45)
Scheme 61: Front Side Door Armrest Switch Mount Plate Replacement (Passenger Side Traverse without A45)
CalloutComponent Name
1Front Side Door Armrest Switch Mount Plate Passenger Side Assembly Procedure Use a flat-bladed plastic trim tool in order to release the front side door armrest switch mount plate from the door trim assembly. Disconnect the electrical connector from the switch assembly. Transfer parts as necessary.

Front Side Door Armrest Switch Mount Plate Replacement (Passenger Side Traverse without A45)

Scheme 62

Scheme 62: Front Side Door Window Frame Front Cover Replacement (Traverse)
Scheme 62: Front Side Door Window Frame Front Cover Replacement (Traverse)
CalloutComponent Name
Preliminary Procedure Remove the front side door trim panel. Refer to Front Side Door Trim Panel Replacement - Left Side (Traverse) , and Front Side Door Trim Panel Replacement - Right Side (Traverse) .
1Front Side Door Trim Fastener CAUTION: Refer to Fastener Caution . Tighten 1 N.m (9 lb in)
2Front Side Door Window Frame Front Cover Assembly
CAUTION
Refer to Fastener Caution .

Front Side Door Window Frame Front Cover Replacement (Traverse)

Scheme 63

Scheme 63: Front Side Door Trim Panel Replacement - Left Side (Traverse)
Scheme 63: Front Side Door Trim Panel Replacement - Left Side (Traverse)
CalloutComponent Name
1Front Side Door Pull Handle Cover
2Front Side Door Inside Handle Bezel Finish Cover
3Front Side Door Trim Panel Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 6 (53 lb in)
4Front Side Door Locking Rod Knob Assembly Procedure Ensure the locking rod is in the unlocked position. Use a flat-bladed tool to disengage the detent tab and then remove the knob by pulling upward. When re-installing, push the knob down until the detent tab touches the locking rod opening cover. Push the detent tab into the lock knob to locking rod.
5Front Side Door Trim Panel Assembly Procedure Use a door trim pad removal tool, or equivalent, at each of the nine retainer locations to aid in the removal of the trim panel. Disengage the door lock cable. Disconnect the electrical connector. For programming and setup information for a new door lock switch, refer to Control Module References .
6Front Side Door Trim Panel Retainer (Qty: 9)
CAUTION
Refer to Fastener Caution .

Front Side Door Trim Panel Replacement - Left Side (Traverse)

Front Side Door Trim Panel Replacement - Left Side (Acadia)

CalloutComponent Name
1Front Side Door Pull Handle Cover
2Front Side Door Inside Handle Bezel Finish Cover
3Front Side Door Trim Panel Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 6 (53 lb in)
4Front Side Door Locking Rod Knob Assembly Procedure Ensure the locking rod is in the unlocked position. Use a flat-bladed tool to disengage the detent tab and then remove the knob by pulling upward. When re-installing, push the knob down until the detent tab touches the locking rod opening cover. Push the detent tab into the lock knob to locking rod.
5Front Side Door Trim Panel Assembly Procedure Use a door trim pad removal tool, or equivalent, at each of the 9 retainer locations to aid in the removal of the trim panel. Disengage the door lock cable. Disconnect the electrical connector. For programming and setup information for a new door lock switch, refer to Control Module References .
6Front Side Door Trim Panel Retainer (Qty: 9)
CAUTION
Refer to Fastener Caution .

Front Side Door Trim Panel Replacement - Left Side (Acadia)

Scheme 64

Scheme 64: Front Side Door Trim Panel Replacement - Left Side (Enclave)
Scheme 64: Front Side Door Trim Panel Replacement - Left Side (Enclave)
CalloutComponent Name
1Front Side Door Pull Handle Cover
2Front Side Door Inside Handle Bezel Finish Cover
3Front Side Door Trim Panel Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 6 (53 lb in)
4Front Side Door Locking Rod Knob Assembly Procedure Ensure the locking rod is in the unlocked position. Use a flat-bladed tool to disengage the detent tab and then remove the knob by pulling upward. When re-installing, push the knob down until the detent tab touches the locking rod opening cover. Push the detent tab into the lock knob to locking rod.
5Front Side Door Trim Panel Assembly Procedure Use a door trim pad removal tool, or equivalent, at each of the 9 retainer locations to aid in the removal of the trim panel. Disengage the door lock cable. Disconnect the electrical connector. For programming and setup information for a new door lock switch, refer to Control Module References .
6Front Side Door Trim Panel Retainer (Qty: 9)
CAUTION
Refer to Fastener Caution .

Front Side Door Trim Panel Replacement - Left Side (Enclave)

Scheme 65

Scheme 65: Front Side Door Trim Panel Replacement - Right Side (Traverse)
Scheme 65: Front Side Door Trim Panel Replacement - Right Side (Traverse)
CalloutComponent Name
1Front Side Door Pull Handle Cover
2Front Side Door Inside Handle Bezel Finish Cover
3Front Side Door Trim Panel Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 6 (53 lb in)
4Front Side Door Locking Rod Knob Assembly Procedure Ensure the locking rod is in the unlocked position. Use a flat-bladed tool to disengage the detent tab and then remove the knob by pulling upward. When re-installing, push the knob down until the detent tab touches the locking rod opening cover. Push the detent tab into the lock knob to locking rod.
5Front Side Door Trim Panel Assembly Procedure Use a door trim pad removal tool, or equivalent, at each of the 9 retainer locations to aid in the removal of the trim panel. Disengage the door lock cable. Disconnect the electrical connector. Transfer parts as necessary. For programming and setup information for a new door lock switch, refer to Control Module References .
6Front Side Door Trim Panel Retainer (Qty: 9)
CAUTION
Refer to Fastener Caution .

Front Side Door Trim Panel Replacement - Right Side (Traverse)

Front Side Door Trim Panel Replacement - Right Side (Acadia)

CalloutComponent Name
1Front Side Door Pull Handle Cover NOTE: Install the top portion of the pull handle cover first to ensure tabs are lined up and push the cover in firmly.
2Front Side Door Inside Handle Bezel Finish Cover
3Front Side Door Trim Panel Fastener (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 6 (53 lb in)
4Front Side Door Locking Rod Knob Assembly Procedure Ensure the locking rod is in the unlocked position. Use a flat-bladed tool to disengage the detent tab and then remove the knob by pulling upward. When re-installing, push the knob down until the detent tab touches the locking rod opening cover. Push the detent tab into the lock knob to locking rod.
5Front Side Door Trim Panel Assembly Procedure Use a door trim pad removal tool, or equivalent, at each of the 9 retainer locations to aid in the removal of the trim panel. Disengage the door lock cable. Disconnect the electrical connector. For programming and setup information for a new door lock switch, refer to Control Module References .
6Front Side Door Trim Panel Retainer (Qty: 9)
NOTE
Install the top portion of the pull handle cover first to ensure tabs are lined up and push the cover in firmly.
CAUTION
Refer to Fastener Caution .

Front Side Door Trim Panel Replacement - Right Side (Acadia)

Scheme 66

Scheme 66: Front Side Door Trim Panel Replacement - Right Side (Enclave)
Scheme 66: Front Side Door Trim Panel Replacement - Right Side (Enclave)
CalloutComponent Name
1Front Side Door Pull Handle Cover
2Front Side Door Inside Handle Bezel Finish Cover NOTE: Install the top portion of the pull handle cover first to ensure tabs are lined up and push the cover in firmly.
3Front Side Door Trim Panel Bolt (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 6 (53 lb in)
4Front Side Door Locking Rod Knob Assembly Procedure Ensure the locking rod is in the unlocked position. Use a flat-bladed tool to disengage the detent tab and then remove the knob by pulling upward. When re-installing, push the knob down until the detent tab touches the locking rod opening cover. Push the detent tab into the lock knob to locking rod.
5Front Side Door Trim Panel Assembly Procedure Use a door trim pad removal tool, or equivalent, at each of the 9 retainer locations to aid in the removal of the trim panel. Disengage the door lock cable. Disconnect the electrical connector. For programming and setup information for a new door lock switch, refer to Control Module References .
6Front Side Door Trim Panel Retainer (Qty: 9)
NOTE
Install the top portion of the pull handle cover first to ensure tabs are lined up and push the cover in firmly.
CAUTION
Refer to Fastener Caution .

Front Side Door Trim Panel Replacement - Right Side (Enclave)

Scheme 67

Scheme 67: Front Side Door Garnish Molding Replacement (Enclave)
Scheme 67: Front Side Door Garnish Molding Replacement (Enclave)
CalloutComponent Name
Preliminary Procedure Remove the front side door trim panel. Refer to Front Side Door Trim Panel Replacement - Left Side (Enclave) or Front Side Door Trim Panel Replacement - Right Side (Enclave) .
1Front Side Door Garnish Molding Retainer TIP: Use a door trim panel removal tool or equivalent to aid in the removal of the retainer.
2Front Side Door Garnish Molding TIP: Pull outward starting at the front and moving slowly rearward to remove the molding.
3Front Side Door Garnish Molding Retainer Clip

Front Side Door Garnish Molding Replacement (Enclave)

Scheme 68

Scheme 68: Rear Side Door Trim Panel Replacement (Enclave)
Scheme 68: Rear Side Door Trim Panel Replacement (Enclave)
CalloutComponent Name
1Rear Side Door Pull Handle Cover
2Rear Side Door Inside Handle Bezel Finish Cover
3Rear Side Door Trim Panel Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 6 N.m (18 lb in)
4Rear Side Door Trim Panel Assembly Procedure Use a door trim pad removal tool, or equivalent, at each of the 9 retainer locations to aid in the removal of the trim panel. Disengage the door lock cable. Disconnect the electrical connector. For programming and setup information, refer to Control Module References .
5Rear Side Door Trim Panel Retainer (Qty: 9)
CAUTION
Refer to Fastener Caution .

Rear Side Door Trim Panel Replacement (Enclave)

Scheme 69

Scheme 69: Rear Side Door Trim Panel Replacement (Acadia)
Scheme 69: Rear Side Door Trim Panel Replacement (Acadia)
CalloutComponent Name
Preliminary Procedure Remove the rear side door upper molding. Refer to Rear Side Door Upper Molding Replacement (Acadia) .
1Rear Side Door Pull Handle Cover NOTE: Install the top portion of the pull handle cover first to ensure tabs are lined up and push the cover in firmly.
2Rear Side Door Inside Handle Bezel Finish Cover
3Rear Side Door Trim Panel Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 6 N.m (18 lb in)
4Rear Side Door Locking Rod Knob Assembly Procedure Ensure the locking rod is in the unlocked position. Use a flat-bladed tool to disengage the detent tab and then remove the knob by pulling upward. When re-installing, push the knob down until the detent tab touches the locking rod opening cover. Push the detent tab into the lock knob to locking rod.
5Rear Side Door Trim Panel Retainer (Qty: 9)
6Rear Side Door Trim Panel Assembly Procedure Use a door trim pad removal tool, or equivalent, at each of the 9 retainer locations to aid in the removal of the trim panel. Disengage the door lock cable. Disconnect the electrical connector. For programming and setup information, refer to Control Module References .
NOTE
Install the top portion of the pull handle cover first to ensure tabs are lined up and push the cover in firmly.
CAUTION
Refer to Fastener Caution .

Rear Side Door Trim Panel Replacement (Acadia)

Rear Side Door Trim Panel Replacement (Traverse)

CalloutComponent Name
Preliminary Procedure Remove the rear side door window frame rear cover. Refer to Rear Side Door Window Frame Rear Cover Replacement (Traverse) .
1Rear Side Door Pull Handle Cover Procedure The rear side door pull handle cover MUST be replaced every time the pull handle cover is removed for service. Install the top portion of the pull handle cover first to ensure tabs are lined up and push the cover in firmly.
2Rear Side Door Inside Handle Bezel Finish Cover
3Rear Side Door Trim Panel Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 6 N.m (18 lb in)
4Rear Side Door Locking Rod Knob Assembly Procedure Ensure the locking rod is in the unlocked position. Use a flat-bladed tool to disengage the detent tab and then remove the knob by pulling upward. When re-installing, push the knob down until the detent tab touches the locking rod opening cover. Push the detent tab into the lock knob to locking rod.
5Rear Side Door Trim Panel Retainer (Qty: 9)
6Rear Side Door Trim Panel Assembly Procedure Use a door trim pad removal tool, or equivalent, at each of the 9 retainer locations to aid in the removal of the trim panel. Disengage the door lock cable. Disconnect the electrical connector. For programming and setup information, refer to Control Module References .
CAUTION
Refer to Fastener Caution .

Rear Side Door Trim Panel Replacement (Traverse)

Scheme 70

Scheme 70: Rear Side Door Upper Molding Replacement (Acadia)
Scheme 70: Rear Side Door Upper Molding Replacement (Acadia)
CalloutComponent Name
Preliminary Procedure Remove the rear side door trim panel. Refer to Rear Side Door Trim Panel Replacement (Acadia) .
1Rear Side Door Upper Molding Screw (Qty: 5) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2Rear Side Door Trim Bracket
3Rear Side Door Upper Molding Procedure Pull away from door to disengage the retainer clips.
CAUTION
Refer to Fastener Caution .

Rear Side Door Upper Molding Replacement (Acadia)

Scheme 71

Scheme 71: Rear Side Door Upper Garnish Molding Replacement (Enclave)
Scheme 71: Rear Side Door Upper Garnish Molding Replacement (Enclave)
CalloutComponent Name
Preliminary Procedure Remove the rear side door trim panel. Refer to Rear Side Door Trim Panel Replacement (Enclave) .
1Rear Side Door Upper Garnish Molding Retainer (Qty: 2) TIP: Use a door trim panel removal tool or equivalent to aid in the removal of the retainer.
2Rear Side Door Upper Garnish Molding TIP: Pull outward starting at the front and moving slowly rearward to remove the molding.

Rear Side Door Upper Garnish Molding Replacement (Enclave)

Scheme 72

Scheme 72: Rear Door Energy Absorber Pad Replacement
Scheme 72: Rear Door Energy Absorber Pad Replacement
CalloutComponent Name
Preliminary Procedure Remove the water deflector. Refer to Rear Side Door Water Deflector Replacement .
1Rear Side Door Energy Absorber Retainer (Qty: 2)
2Rear Side Door Energy Absorber TIP: Use care when removing retainers, if damaged must be replaced.

Rear Door Energy Absorber Pad Replacement

Removal Procedure

  1. Remove the door trim panel. Refer to «Front Side Door Trim Panel Replacement - Left Side (Traverse)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) , «Front Side Door Trim Panel Replacement - Left Side (Acadia)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling__front-side-door-trim-panel-replacement) , «Front Side Door Trim Panel Replacement - Left Side (Enclave)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) , or «Front Side Door Trim Panel Replacement - Right Side (Acadia)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling__front-side-door-trim-panel-replacement) , «Front Side Door Trim Panel Replacement - Right Side (Enclave)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) , «Front Side Door Trim Panel Replacement - Right Side (Traverse)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  2. Remove the outside rear view mirror (ORVM) wire harness from the water deflector.
  3. Carefully remove the water deflector from the door by releasing the adhesive backing.

Installation Procedure

  1. Install the ORVM wire harness to the water deflector.
  2. Position the water deflector to the door.
  3. Press the water deflector to the door. Ensure that the water deflector forms a proper seal around the surface of the door panel.
  4. Install the door trim panel. Refer to «Front Side Door Trim Panel Replacement - Left Side (Traverse)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) , «Front Side Door Trim Panel Replacement - Left Side (Acadia)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling__front-side-door-trim-panel-replacement) , «Front Side Door Trim Panel Replacement - Left Side (Enclave)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) , or «Front Side Door Trim Panel Replacement - Right Side (Acadia)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling__front-side-door-trim-panel-replacement) , «Front Side Door Trim Panel Replacement - Right Side (Enclave)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) , «Front Side Door Trim Panel Replacement - Right Side (Traverse)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  1. Open the door.
  2. Remove the door trim panel. Refer to «Rear Side Door Trim Panel Replacement (Traverse)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling__rear-side-door-trim-panel-replacement) , «Rear Side Door Trim Panel Replacement (Enclave)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) , «Rear Side Door Trim Panel Replacement (Acadia)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .
  3. Remove the retainer (1).
  4. Carefully remove the water deflector from the door by releasing the adhesive backing.
  1. Position the water deflector to the door.
  2. Install the retainers (1).
  3. Press the water deflector to the door. Ensure that the water deflector forms a proper seal around the surface of the door panel.
  4. Install the door trim panel. Refer to «Rear Side Door Trim Panel Replacement (Traverse)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling__rear-side-door-trim-panel-replacement) , «Rear Side Door Trim Panel Replacement (Enclave)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) , «Rear Side Door Trim Panel Replacement (Acadia)»(/buick/enclave/i-2007-2013/remont/exteriorinterior-trim/#interior-trim-and-interior-paneling) .

Scheme 73

Scheme 73: Front Side Door Sill Trim Plate Replacement
Scheme 73: Front Side Door Sill Trim Plate Replacement
CalloutComponent Name
1Front Side Door Sill Plate Assembly
2Front Side Door Sill Plate Assembly Clip (Qty: 4) Procedure Use a flat-bladed plastic trim tool in order to release the clips and remove the sill plate. Disconnect lighting, if equipped.

Front Side Door Sill Trim Plate Replacement

Scheme 74

Scheme 74: Rear Side Door Sill Trim Plate Replacement
Scheme 74: Rear Side Door Sill Trim Plate Replacement
CalloutComponent Name
1Rear Side Door Sill Plate Assembly
2Rear Side Door Sill Plate Assembly Clip (Qty: 3) TIP: Use a flat-bladed plastic trim tool in order to release the clips and remove the sill plate.

Rear Side Door Sill Trim Plate Replacement

Scheme 75

Scheme 75: Liftgate Door Sill Plate Replacement (Enclave)
Scheme 75: Liftgate Door Sill Plate Replacement (Enclave)
CalloutComponent Name
1Liftgate Door Sill Plate Assembly TIP: Use a flat-bladed plastic trim tool in order to release the clips and remove the sill plate.
2Liftgate Door Sill Plate Retainer Clip

Liftgate Door Sill Plate Replacement (Enclave)

Liftgate Door Sill Plate Replacement (Traverse)

CalloutComponent Name
1Liftgate Door Sill Plate Assembly TIP: Use a flat-bladed plastic trim tool in order to release the clips and remove the sill plate.
2Liftgate Door Sill Plate Retainer Clip

Liftgate Door Sill Plate Replacement (Traverse)

Scheme 76

Scheme 76: Liftgate Door Sill Plate Replacement (Acadia)
Scheme 76: Liftgate Door Sill Plate Replacement (Acadia)
CalloutComponent Name
1Liftgate Door Sill Plate Assembly TIP: Use a flat-bladed plastic trim tool in order to release the clips and remove the sill plate.
2Liftgate Door Sill Plate Clip (Qty: 8)

Liftgate Door Sill Plate Replacement (Acadia)

Scheme 77

Scheme 77: Center Pillar Assist Handle Replacement
Scheme 77: Center Pillar Assist Handle Replacement
CalloutComponent Name
Preliminary Procedure Remove the center pillar upper garnish molding. Refer to Center Pillar Upper Garnish Molding Replacement .
1Center Pillar Assist Handle Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 1.2 N.m (10 lb in)
2Center Pillar Assist Handle Assembly
CAUTION
Refer to Fastener Caution .

Center Pillar Assist Handle Replacement

Scheme 78

Scheme 78: Coat Hook Replacement (Enclave or Traverse)
Scheme 78: Coat Hook Replacement (Enclave or Traverse)
CalloutComponent Name
1Coat Hook Fastener CAUTION: Refer to Fastener Caution . Tighten 6 N.m (53 lb in)
2Coat Hook Assembly Procedure Flip the integral hook downward to access the fastener.
CAUTION
Refer to Fastener Caution .

Coat Hook Replacement (Enclave or Traverse)

Scheme 79

Scheme 79: Coat Hook Replacement (Acadia)
Scheme 79: Coat Hook Replacement (Acadia)
CalloutComponent Name
1Coat Hook Screw CAUTION: Refer to Fastener Caution . Tighten 6 N.m (53 lb in)
2Coat Hook Assembly TIP: Flip the cover downward to access the fastener.
CAUTION
Refer to Fastener Caution .

Coat Hook Replacement (Acadia)

Scheme 80

Scheme 80: Sunshade Replacement
Scheme 80: Sunshade Replacement
CalloutComponent Name
Preliminary Procedures Remove the windshield garnish moldings. Refer to Windshield Garnish Molding Replacement - Left Side , and Windshield Garnish Molding Replacement - Right Side . Remove the sunshade anchor. Refer to Sunshade Anchor Replacement .
1Sunshade Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 3 N.m (25 lb in)
2Sunshade Assembly Procedure Lower the front of the headliner enough to gain access to the sunshade electrical connector which is glued to the headliner. Disconnect the sunshade electrical connector.
CAUTION
Refer to Fastener Caution .

Sunshade Replacement

Scheme 81

Scheme 81: Sunshade Anchor Replacement
Scheme 81: Sunshade Anchor Replacement
CalloutComponent Name
1Sunshade Anchor Screw CAUTION: Refer to Fastener Caution . Tighten 3 N.m (25 lb in)
2Sunshade Anchor Assembly TIP: Pull the cover downward to access the fastener.
CAUTION
Refer to Fastener Caution .

Sunshade Anchor Replacement

Scheme 82

Scheme 82: Windshield Garnish Molding Replacement - Left Side
Scheme 82: Windshield Garnish Molding Replacement - Left Side
CalloutComponent Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling .
1Windshield Side Garnish Molding Screw CAUTION: Refer to Fastener Caution . TIP: Open the access door to remove the screw. Tighten 2 N.m (18 lb in)
2Windshield Side Garnish Molding Assembly Procedure Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Windshield Garnish Molding Replacement - Left Side

Scheme 83

Scheme 83: Windshield Garnish Molding Replacement - Right Side
Scheme 83: Windshield Garnish Molding Replacement - Right Side
CalloutComponent Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling .
1Windshield Side Garnish Molding Bolt Hole Finish Plug (Qty: 2)
2Windshield Side Garnish Molding Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
3Windshield Side Garnish Molding Assembly TIP: Disconnect the electrical connector.
CAUTION
Refer to Fastener Caution .

Windshield Garnish Molding Replacement - Right Side

Scheme 84

Scheme 84: Center Pillar Upper Garnish Molding Replacement
Scheme 84: Center Pillar Upper Garnish Molding Replacement
CalloutComponent Name
Preliminary Procedure Remove the center pillar lower garnish molding. Refer to Center Pillar Lower Garnish Molding Replacement (Traverse) , Center Pillar Lower Garnish Molding Replacement (Acadia or Enclave) .
1Center Pillar Upper Garnish Molding Screw CAUTION: Refer to Fastener Caution . TIP: Open the access door to remove the screw. Tighten 2 N.m (18 lb in)
2Center Pillar Upper Garnish Molding Assembly Procedure Route the seat belt through the molding prior to installing.
CAUTION
Refer to Fastener Caution .

Center Pillar Upper Garnish Molding Replacement

Scheme 85

Scheme 85: Center Pillar Lower Garnish Molding Replacement (Traverse)
Scheme 85: Center Pillar Lower Garnish Molding Replacement (Traverse)
CalloutComponent Name
WARNING: When replacing the center pillar lower garnish molding, ensure the seatbelt webbing does not become mis-routed or trapped underneath the retaining clips. If the seatbelt webbing is trapped, it could result in the seatbelt being inoperable, which may cause personal injury. Preliminary Procedures Remove the front carpet retainer. Refer to Front Side Door Opening Floor Carpet Retainer Replacement . Remove the rear carpet retainer. Refer to Rear Side Door Opening Floor Carpet Retainer Replacement . Remove the seat belt anchor bolt from the front seat. Refer to Seat Belt Retractor Pretensioner Replacement - Front .
1Center Pillar Lower Garnish Molding Clip (Qty: 4)
2Center Pillar Lower Garnish Molding Assembly
WARNING
When replacing the center pillar lower garnish molding, ensure the seatbelt webbing does not become mis-routed or trapped underneath the retaining clips. If the seatbelt webbing is trapped, it could result in the seatbelt being inoperable, which may cause personal injury.

Center Pillar Lower Garnish Molding Replacement (Traverse)

Scheme 86

Scheme 86: Center Pillar Lower Garnish Molding Replacement (Acadia or Enclave)
Scheme 86: Center Pillar Lower Garnish Molding Replacement (Acadia or Enclave)
CalloutComponent Name
WARNING: When replacing the center pillar lower garnish molding, ensure the seatbelt webbing does not become mis-routed or trapped underneath the retaining clips. If the seatbelt webbing is trapped, it could result in the seatbelt being inoperable, which may cause personal injury. Preliminary Procedures Remove the front carpet retainer. Refer to Front Side Door Opening Floor Carpet Retainer Replacement . Remove the rear carpet retainer. Refer to Rear Side Door Opening Floor Carpet Retainer Replacement . Remove the seat belt anchor bolt from the seat belt anchor tensioner. Refer to Front Seat Belt Anchor Plate Tensioner Replacement .
1Center Pillar Lower Garnish Molding Clip (Qty: 6)
2Center Pillar Lower Garnish Molding Assembly
WARNING
When replacing the center pillar lower garnish molding, ensure the seatbelt webbing does not become mis-routed or trapped underneath the retaining clips. If the seatbelt webbing is trapped, it could result in the seatbelt being inoperable, which may cause personal injury.

Center Pillar Lower Garnish Molding Replacement (Acadia or Enclave)

Scheme 87

Scheme 87: Body Lock Pillar Upper Trim Panel Replacement
Scheme 87: Body Lock Pillar Upper Trim Panel Replacement
CalloutComponent Name
Preliminary Procedures Remove the seat belt anchor bolt. Refer to Seat Belt Retractor Replacement - No. 1 Rear . Remove the rear quarter lower trim panel. Refer to Quarter Lower Rear Trim Panel Replacement (Acadia with TB5) , Quarter Lower Rear Trim Panel Replacement (Traverse with TB5) , Quarter Lower Rear Trim Panel Replacement (Traverse with TB4) , Quarter Lower Rear Trim Panel Replacement (Enclave with TB5) , Quarter Lower Rear Trim Panel Replacement (Acadia with TB4) , Quarter Lower Rear Trim Panel Replacement (Enclave with TB4) .
1Body Lock Upper Trim Panel Retainer (Qty: 3)
2Body Lock Upper Trim Panel Clip
3Body Lock Upper Trim Panel Assembly TIP: Route the seat belt through the trim panel.

Body Lock Pillar Upper Trim Panel Replacement

Scheme 88

Scheme 88: Quarter Upper Trim Panel Replacement (TB5)
Scheme 88: Quarter Upper Trim Panel Replacement (TB5)
CalloutComponent Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the seat belt anchor bolt. Refer to Rear Seat Number 2 Retractor Side Belt Replacement .
1Rear Quarter Upper Trim Panel Screw CAUTION: Refer to Fastener Caution . TIP: Open the access door to remove screw. Tighten 3 N.m (27 lb in)
2Rear Quarter Upper Trim Panel Assembly TIP: Route the seat belt through the trim panel.
CAUTION
Refer to Fastener Caution .

Quarter Upper Trim Panel Replacement (TB5)

Scheme 89

Scheme 89: Quarter Upper Trim Panel Replacement (TB4)
Scheme 89: Quarter Upper Trim Panel Replacement (TB4)
CalloutComponent Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the seat belt anchor bolt. Refer to Rear Seat Number 2 Retractor Side Belt Replacement .
1Rear Quarter Upper Trim Panel Screw CAUTION: Refer to Fastener Caution . TIP: Open the access door to remove screw. Tighten 3 N.m (27 lb in)
2Rear Quarter Upper Trim Panel Assembly TIP: Route the seat belt through trim panel.
3Rear Quarter Upper Trim Panel Clip (Qty: 3)
4Rear Quarter Upper Trim Panel Retainer
CAUTION
Refer to Fastener Caution .

Quarter Upper Trim Panel Replacement (TB4)

Scheme 90

Scheme 90: Quarter Lower Rear Trim Panel Replacement (Traverse with TB5)
Scheme 90: Quarter Lower Rear Trim Panel Replacement (Traverse with TB5)
CalloutComponent Name
Preliminary Procedures Move the rear seat to the full forward position. Remove the rear number 2 seat . Refer to 3rd Row Seat Replacement . Remove the rear quarter upper trim panel. Refer to Quarter Upper Trim Panel Replacement (TB5) . Disconnect the liftgate actuator rod from the liftgate. Refer to Liftgate Actuator Rod Replacement . Disconnect the rear seat number 2 shoulder belt anchor bolt. Refer to Rear Seat Number 2 Retractor Side Belt Replacement . Remove the liftgate door sill plate. Refer to Liftgate Door Sill Plate Replacement (Traverse) .
1Cargo Tie Down Loop Bolt Cap (Qty: 2)
2Cargo Tie Down Loop Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 3 N.m (27 lb in)
3Cargo Tie Down Loop (Qty: 2)
4Body Side Trim Panel Armrest Procedure Pull upward on the armrest to disengage the retainer clips.
5Cargo Screen Retainer Assembly (Qty: 2) Procedure Turn the left front and right rear cargo screen retainer counterclockwise one quarter turn to disengage the 2 integral tabs. Turn the left rear and right front cargo screen retainer clockwise one quarter turn to disengage the 2 integral tabs.
6Rear Quarter Lower Trim Panel Bolt Tighten 3 N.m (27 lb in)
7Rear Quarter Lower Trim Panel Assembly Procedure Pull outward to disengage the trim panel retainers. Disconnect the electrical connectors.
CAUTION
Refer to Fastener Caution .

Quarter Lower Rear Trim Panel Replacement (Traverse with TB5)

Scheme 91

Scheme 91: Quarter Lower Rear Trim Panel Replacement (Traverse with TB4)
Scheme 91: Quarter Lower Rear Trim Panel Replacement (Traverse with TB4)
CalloutComponent Name
Preliminary Procedures Move the rear seat to the full forward position. Remove the rear number 2 seat . Refer to 3rd Row Seat Replacement . Remove the rear quarter upper trim panel. Refer to Quarter Upper Trim Panel Replacement (TB4) . Disconnect the liftgate actuator rod from the liftgate. Refer to Liftgate Actuator Rod Replacement . Disconnect the rear seat number 2 shoulder belt anchor bolt. Refer to Rear Seat Number 2 Retractor Side Belt Replacement . Remove the liftgate door sill plate. Refer to Liftgate Door Sill Plate Replacement (Traverse) .
1Cargo Tie Down Loop Bolt Cap (Qty: 2)
2Cargo Tie Down Loop Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 3 N.m (27 lb in)
3Cargo Tie Down Loop (Qty: 2)
4Body Side Trim Panel Armrest Procedure Pull upward on the armrest to disengage the retainer clips.
5Cargo Screen Retainer Assembly (Qty: 2) Procedure Turn the left front and right rear cargo screen retainer counterclockwise one quarter turn to disengage the 2 integral tabs. Turn the left rear and right front cargo screen retainer clockwise one quarter turn to disengage the 2 integral tabs.
6Rear Quarter Lower Trim Push Nut (Qty: 2)
7Rear Quarter Lower Trim Panel Assembly Procedure Pull outward to disengage the trim panel retainers. Disconnect the electrical connectors.
CAUTION
Refer to Fastener Caution .

Quarter Lower Rear Trim Panel Replacement (Traverse with TB4)

Scheme 92

Scheme 92: Quarter Lower Rear Trim Panel Replacement (Enclave with TB5)
Scheme 92: Quarter Lower Rear Trim Panel Replacement (Enclave with TB5)
CalloutComponent Name
Preliminary Procedures Move the rear seat to the full forward position. Remove the rear number 2 seat . Refer to 3rd Row Seat Replacement . Remove the rear quarter upper trim panel. Refer to Quarter Upper Trim Panel Replacement (TB5) . If removing the left side trim panel, disconnect the liftgate actuator rod from the liftgate. Refer to Liftgate Actuator Rod Replacement . Disconnect the rear seat number 2 shoulder belt anchor bolt. Refer to Rear Seat Number 2 Retractor Side Belt Replacement . Remove the liftgate door sill plate. Refer to Liftgate Door Sill Plate Replacement (Enclave) .
1Cargo Tie Down Loop Bolt Cap (Qty: 2)
2Cargo Tie Down Loop Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 3 N.m (27 lb in)
3Cargo Tie Down Loop (Qty: 2)
4Body Side Trim Panel Armrest Procedure Pull upward on the armrest to disengage the retainer clips.
5Cargo Screen Retainer Assembly (Qty: 2) Procedure Turn the left front and right rear cargo screen retainer counterclockwise one quarter turn to disengage the 2 integral tabs. Turn the left rear and right front cargo screen retainer clockwise one quarter turn to disengage the 2 integral tabs.
6Rear Quarter Lower Trim Panel Bolt (Qty: 2) Tighten 3 N.m (27 lb in)
7Rear Quarter Lower Trim Panel Assembly Procedure Pull outward to disengage the trim panel retainers. Disconnect the electrical connectors. Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Quarter Lower Rear Trim Panel Replacement (Enclave with TB5)

Scheme 93

Scheme 93: Quarter Lower Rear Trim Panel Replacement (Enclave with TB4)
Scheme 93: Quarter Lower Rear Trim Panel Replacement (Enclave with TB4)
CalloutComponent Name
Preliminary Procedures Move the rear seat to the full forward position. Remove the rear number 2 seat . Refer to 3rd Row Seat Replacement . Remove the rear quarter upper trim panel. Refer to Quarter Upper Trim Panel Replacement (TB4) . Disconnect the liftgate actuator rod from the liftgate. Refer to Liftgate Actuator Rod Replacement . Disconnect the rear seat number 2 shoulder belt anchor bolt. Refer to Rear Seat Number 2 Retractor Side Belt Replacement . Remove the liftgate door sill plate. Refer to Liftgate Door Sill Plate Replacement (Enclave) .
1Cargo Tie Down Loop Bolt Cap (Qty: 2)
2Cargo Tie Down Loop Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 3 N.m (27 lb in)
3Cargo Tie Down Loop (Qty: 2)
4Body Side Trim Panel Armrest Procedure Pull upward on the armrest to disengage the retainer clips.
5Cargo Screen Retainer Assembly (Qty: 2) Procedure Turn the left front and right rear cargo screen retainer counterclockwise one quarter turn to disengage the 2 integral tabs. Turn the left rear and right front cargo screen retainer clockwise one quarter turn to disengage the 2 integral tabs.
6Rear Quarter Lower Trim Panel Bolt (Qty: 2) Tighten 3 N.m (27 lb in)
7Rear Quarter Lower Trim Panel Assembly Procedure Pull outward to disengage the trim panel retainers. Disconnect the electrical connectors. Transfer components as necessary.
CAUTION
Refer to Fastener Caution .

Quarter Lower Rear Trim Panel Replacement (Enclave with TB4)

Quarter Lower Rear Trim Panel Replacement (Acadia with TB5)

CalloutComponent Name
Preliminary Procedures Move the rear seat to the full forward position. Remove the rear number 2 seat . Refer to 3rd Row Seat Replacement . Remove the rear quarter upper trim panel. Refer to Quarter Upper Trim Panel Replacement (TB5) . Disconnect the liftgate actuator rod from the liftgate. Refer to Liftgate Actuator Rod Replacement . Disconnect the rear seat number 2 shoulder belt anchor bolt. Refer to Rear Seat Number 2 Retractor Side Belt Replacement . Remove the liftgate door sill plate. Refer to Liftgate Door Sill Plate Replacement (Acadia) .
1Cargo Tie Down Loop Bolt Cap (Qty: 2)
2Cargo Tie Down Loop Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 3 N.m (27 lb in)
3Cargo Tie Down Loop (Qty: 2)
4Body Side Trim Panel Armrest Procedure Pull upward on the armrest to disengage the retainer clips.
5Cargo Screen Retainer Assembly (Qty: 2) Procedure Turn the left front and right rear cargo screen retainer counterclockwise one quarter turn to disengage the 2 integral tabs. Turn the left rear and right front cargo screen retainer clockwise one quarter turn to disengage the 2 integral tabs.
6Rear Quarter Lower Trim Panel Bolt (Qty: 2) Tighten 3 N.m (27 lb in)
7Rear Quarter Lower Trim Panel Assembly Procedure Pull outward to disengage the trim panel retainers. Disconnect the electrical connectors.
CAUTION
Refer to Fastener Caution .

Quarter Lower Rear Trim Panel Replacement (Acadia with TB5)

Quarter Lower Rear Trim Panel Replacement (Acadia with TB4)

CalloutComponent Name
Preliminary Procedures Move the rear seat to the full forward position. Remove the rear number 2 seat . Refer to 3rd Row Seat Replacement . Remove the rear quarter upper trim panel. Refer to Quarter Upper Trim Panel Replacement (TB4) . Disconnect the liftgate actuator rod from the liftgate. Refer to Liftgate Actuator Rod Replacement . Disconnect the rear seat number 2 shoulder belt anchor bolt. Refer to Rear Seat Number 2 Retractor Side Belt Replacement . Remove the liftgate door sill plate. Refer to Liftgate Door Sill Plate Replacement (Acadia) .
1Cargo Tie Down Loop Bolt Cap (Qty: 2)
2Cargo Tie Down Loop Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 3 N.m (27 lb in)
3Cargo Tie Down Loop (Qty: 2)
4Body Side Trim Panel Armrest Procedure Pull upward on the armrest to disengage the retainer clips.
5Cargo Screen Retainer Assembly (Qty: 2) Procedure Turn the left front and right rear cargo screen retainer counterclockwise one quarter turn to disengage the 2 integral tabs. Turn the left rear and right front cargo screen retainer clockwise one quarter turn to disengage the 2 integral tabs.
6Rear Quarter Lower Trim Panel Bolt (Qty: 2) Tighten 3 N.m (27 lb in)
7Rear Quarter Lower Trim Panel Assembly Procedure Pull outward to disengage the trim panel retainers. Disconnect the electrical connectors.
CAUTION
Refer to Fastener Caution .

Quarter Lower Rear Trim Panel Replacement (Acadia with TB4)

Scheme 94

Scheme 94: Rear Storage Compartment Replacement
Scheme 94: Rear Storage Compartment Replacement
CalloutComponent Name
1Cargo Box Stowage Box Lid Assembly
2Rear Compartment Floor Stowage Compartment Fasteners
3Rear Compartment Floor Stowage Compartment Assembly

Rear Storage Compartment Replacement

Scheme 95

Scheme 95: Liftgate Garnish Molding Replacement (TB5)
Scheme 95: Liftgate Garnish Molding Replacement (TB5)
CalloutComponent Name
1Liftgate Actuator Rod
2Liftgate Actuator Rod Stud CAUTION: Refer to Fastener Caution . Procedure Unclip the rod from the stud. Tighten 20 N.m (15 lb ft)
3Liftgate Upper Trim Finish Panel Assembly
CAUTION
Refer to Fastener Caution .

Liftgate Garnish Molding Replacement (TB5)

Scheme 96

Scheme 96: Liftgate Garnish Molding Replacement (TB4)
Scheme 96: Liftgate Garnish Molding Replacement (TB4)
CalloutComponent Name
1Liftgate Upper Trim Finish Panel Retainer (Qty: 6)
2Liftgate Upper Trim Finish Panel Assembly

Liftgate Garnish Molding Replacement (TB4)

Scheme 97

Scheme 97: Liftgate Trim Panel Replacement (Traverse)
Scheme 97: Liftgate Trim Panel Replacement (Traverse)
CalloutComponent Name
Preliminary Procedure Remove the liftgate window garnish molding. Refer to Liftgate Garnish Molding Replacement (TB4) , Liftgate Garnish Molding Replacement (TB5) .
1Liftgate Inside Pull Handle Cover
2Liftgate Trim Finish Panel Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
3Liftgate Trim Finish Panel Push Pin Retainer (Qty: 2)
4Liftgate Trim Finish Panel Retainer (Qty: 6)
5Liftgate Trim Finish Panel Assembly Procedure Use a trim panel removal tool to aid in the removal of the trim panel from the liftgate assembly. Disconnect the electrical connector, if equipped.
CAUTION
Refer to Fastener Caution .

Liftgate Trim Panel Replacement (Traverse)

Scheme 98

Scheme 98: Liftgate Trim Panel Replacement (Enclave)
Scheme 98: Liftgate Trim Panel Replacement (Enclave)
CalloutComponent Name
Preliminary Procedure Remove the liftgate window garnish molding. Refer to Liftgate Garnish Molding Replacement (TB4) , Liftgate Garnish Molding Replacement (TB5) .
1Liftgate Inside Pull Handle Cover
2Liftgate Trim Finish Panel Fastener (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
3Liftgate Trim Finish Panel Push Pin Retainer (Qty: 2)
4Liftgate Trim Finish Panel Retainer (Qty: 6)
5Liftgate Trim Finish Panel Assembly Procedure Use a trim panel removal tool to aid in the removal of the trim panel from the liftgate assembly. Disconnect the electrical connector, if equipped.
CAUTION
Refer to Fastener Caution .

Liftgate Trim Panel Replacement (Enclave)

Liftgate Trim Panel Replacement (Acadia)

CalloutComponent Name
Preliminary Procedure Remove the liftgate window garnish molding. Refer to Liftgate Garnish Molding Replacement (TB4) , Liftgate Garnish Molding Replacement (TB5) .
1Liftgate Inside Pull Handle Cover
2Liftgate Trim Finish Panel Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
3Liftgate Trim Finish Panel Push Pin Retainer (Qty: 2)
4Liftgate Trim Finish Panel Retainer (Qty: 6)
5Liftgate Trim Finish Panel Assembly Procedure Use a trim panel removal tool to aid in the removal of the trim panel from the liftgate assembly. Disconnect the electrical connector, if equipped.
CAUTION
Refer to Fastener Caution .

Liftgate Trim Panel Replacement (Acadia)

Scheme 99

Scheme 99: Pressure Relief Valve Replacement
Scheme 99: Pressure Relief Valve Replacement
CalloutComponent Name
Preliminary Procedure Remove the rear fascia. Refer to Rear Bumper Fascia Replacement .
1Pressure Relief Valve Assembly TIP: Release the tabs attaching the valve (1) to the inner rear quarter panel to remove

Pressure Relief Valve Replacement

More articles — Body & Frame
