Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Center Applique Nuts | 6 N.m | 53 lb in |
| Grille Screws | 9 N.m | 80 lb in |
| High Mount Stop Lamp | 2 N.m | 18 lb in |
| Liftgate Applique Bolts | 2.3 N.m | 20 lb in |
| Rear License Plate Wiring Harness Bolt | 2.3 N.m | 20 lb in |
| Rocker Panel Finish Panel Screws | 1.5 N.m | 13 lb in |
| Rear Spoiler Nuts | 6 N.m | 53 lb in |
Fastener Tightening Specifications
Emblem/Nameplate Repair
- Wash the panel using soap and water.
- Wipe the panel dry.
- Use a clean rag and 3M General Purpose Adhesive Cleaner 08984 or the equivalent in order to wipe the panel and the adhesive side of the emblem/nameplate.
- Use a clean rag and an alcohol/water mixture in order to remove residue from the following components: The molding The emblem The nameplate
- Apply a length of masking tape or a magnetic strip as a guide, if needed.
- Apply a thin film of adhesive to the back of the emblem/nameplate. The molding The emblem The nameplate
- Press the piece into place. If you use the LOCTITE™ 414 adhesive GM P/N 1052621 (Canadian P/N 993365) or the equivalent, apply constant pressure to the molding for 30 seconds or until a firm bond has been made.
Body Panel Paint Protector Replacement (VGC)
- The paint protective film and vehicle surface temperature should be 13-32°C (55-90°F) for best results.
- Automatic car washes should be avoided for at least 24 hours after the paint protective film application.
- Wipe the vehicle surface with isopropyl alcohol or flash naptha at the application area.
- Dry the surface with a clean lint-free cloth.
- Create a mixture of 25 percent isopropyl alcohol and 75 percent water and two drops of baby shampoo per 16 oz of fluid mixture.
- Remove the backing liner from the protective film patch.
- Use the solution to liberally spray the adhesive side of the protective patch, the mounting location along with your hands.
- Position the paint protective film patch to the desired location on the vehicle.
- Spray the surface of the film with the alcohol, water and soap solution.
- Using a dampened squeegee, start at the center of the protective patch, working outward in order to remove the air and solution from under the protective patch.
- Release any air bubbles with a pin.
- Dry the surface with a clean, lint-free cotton cloth.
Stripes or Decals
The stripes and decals adhere to a painted surface using pressure sensitive adhesive.
The use of a wetting solution aids the technician in lifting and positioning the stripe or decal during the installation. The wetting solution ensures a better bond between the stripe or decal and the panel assembly. Use a wetting solution when applying large stripe and decal packages.
Complete the following procedures before you apply a stripe or a decal
- Place the front door window in the full down position.
- Remove the front door outer belt sealing strip. Refer to «Front Side Door Window Belt Outer Sealing Strip Replacement (Enclave)»(/buick/enclave/i-2007-2013/remont/heated-glassdefoggers/#fixed-and-moveable-windows) .
- Remove the front door window inner sealing strip. Refer to «Front Side Door Window Belt Inner Sealing Strip Replacement»(/buick/enclave/i-2007-2013/remont/heated-glassdefoggers/#fixed-and-moveable-windows) .
- Metal repair or refinishing after a collision
- Painting the underlying surface
Maintain a temperature 21-38°C (70-100°F) on the body surfaces and the decals prior to installation. The decal requires auxiliary heat sources in order to warm the body surfaces and decals. If the temperature is below 21°C (70°F) the decal may not adhere to the body surface properly.
| IMPORTANT | You may apply stripes or decals using the dry method. Use the wet method if the dry method does not result in a bubble free application. This may be the case in large graphics packages. Use the wet method in order to apply the stripes or decals that are applied on flexible surfaces (fascias, etc.). This will reduce the formation of bubbles under the decal due to the outgassing potential of the flexible materials. |
Use the following equipment and materials in order to apply a stripe or a decal
- A wetting solution A foaming type of window cleaner that does not contain ammonia.
- A silicone, wax and grease remover
- Varnish Makers and Painters (VM&P) Naptha
- Isopropyl alcohol
- A squeegee 75-100 mm (3-4 in) wide Made of plastic or hard rubber Deburr any sharp or rough edges in order to prevent scratching of the stripe or decal.
- A water bucket and sponge or spray bottle
- Sandpaper 800 grit or finer Wet or dry type
- A J 25070 heat gun
- A clean, lint-free wiping cloth
- A sharp knife or razor blade
- A pair of scissors
- A fine pin or needle
- A marking pencil
Stripe or Decal Removal
- Remove the following components: Necessary moldings or trim panel Molding attaching clips Handles Sidemarker lamps Other stripe or decal overlapping parts
- Clean the following areas as needed: The repair surfaces The adjacent panels The openings
- Use 3M™ ScotchBrite molding adhesive remover disk 3M™ P/N 07502 or equivalent in order to remove the stripe or decal from the body panel.
- Use Varnish Makers and Painters (VM&P) Naptha to remove all traces of adhesive residue from the painted surfaces.
Stripe or Decal Installation - Wet Method
- Place the front door window in the full down position.
- Remove the front door window inner sealing strip. Refer to «Front Side Door Window Belt Inner Sealing Strip Replacement»(/buick/enclave/i-2007-2013/remont/heated-glassdefoggers/#fixed-and-moveable-windows) .
- Remove the front door outer belt sealing strip. Refer to «Front Side Door Window Belt Outer Sealing Strip Replacement (Enclave)»(/buick/enclave/i-2007-2013/remont/heated-glassdefoggers/#fixed-and-moveable-windows) .
- Prepare the surface. IMPORTANT: Remove any imperfections that would appear through the stripe or decal if the area has been refinished. Clean the painted surface using the following types of removers: Silicone Wax Grease
- Clean the area where the stripe or decal will be applied using a 50-50 mixture of isopropyl alcohol and water.
- Wipe the panel surface using a clean cloth while the solvent is still wet. Allow the panel surface to dry.
- Apply the wetting solution to the area where you are installing the stripe or decal. Application of a soapy wetting solution on the top side of the stripe or decal will ease the pull of the squeegee on the stripe or decal. IMPORTANT: Do not touch the adhesive backing of the stripes. Apply the wetting solution on the adhesive side of the stripe or decal. Remove the backing material of the stripe or the decal as needed.
- Apply the strip or decal to the panel. The wetting solution will allow movement for proper positioning on the panel surface.
- Working from the center where possible, squeegee the stripe or decal into position. Apply additional wetting solution as needed to ease installation.
- Apply heat to the stripe or decal at the recessed areas. Press the stripe or decal into the recess to obtain a firm bond.
- Use adequate light reflection to inspect the stripe or decal from a critical angle. This technique detects any irregularities that may have developed during the installation. IMPORTANT: Do not use a razor blade or a knife edge to pierce the air bubbles. Remove all air bubbles by piercing the bubble with one of the following items: A safety pin A needle A tool with the same size piercing tip
- Pierce the bubble on the outer edge. Force the air out through the opposite edge using the blade of the squeegee.
- Install any previously removed components. Clean the components as needed.
Scheme 8
Scheme 8: Front Door Frame Applique Replacement (Acadia)
Front Door Frame Applique Replacement (Acadia)
Scheme 9
Scheme 9: Liftgate Applique Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the liftgate trim panel. Refer to Liftgate Trim Panel Replacement (Acadia) . |
| 1 | Center Applique Nuts (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 6 N.m (53 lb in) |
| 2 | Center Applique Integral Clips Procedure Install the applique to the liftgate panel first by securing the integral clips. |
| 3 | License Plate Lamp Electrical Connector Procedure Transfer the license plate lamp sockets and electrical harness to the new applique panel. |
| 4 | Liftgate Center Applique |
Liftgate Applique Replacement (Acadia)
Scheme 10
Scheme 10: Liftgate Applique Replacement (Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedures Remove the liftgate interior trim panel. Refer to Liftgate Trim Panel Replacement (Enclave) . Disconnect the rear liftgate applique electrical connector from the rear body harness. |
| 1 | Liftgate Applique Nut (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 6 N.m (53 lb in) |
| 2 | Liftgate Applique Electrical Harness and Grommet |
| 3 | Liftgate Applique Assembly Procedure Disconnect and release the electrical harness grommet from the liftgate outer panel. Release the center retention clip securing the applique to the liftgate outer panel. Remove the liftgate applique. Transfer parts as necessary. |
Liftgate Applique Replacement (Enclave)
The stripes and decals adhere to a painted surface using pressure sensitive adhesive.
The use of a wetting solution aids the technician in lifting and positioning the stripe or decal during the installation. The wetting solution ensures a better bond between the stripe or decal and the panel assembly. Use a wetting solution when applying large stripe and decal packages.
Complete the following procedures before you apply a stripe or a decal
- Remove the rear side door stationary window. Refer to «Rear Side Door Stationary Window Replacement»(/buick/enclave/i-2007-2013/remont/heated-glassdefoggers/#fixed-and-moveable-windows) .
- Metal repair or refinishing after a collision
- Painting the underlying surface
Maintain a temperature 21-38°C (70-100°F) on the body surfaces and the decals prior to installation. The decal requires auxiliary heat sources in order to warm the body surfaces and decals. If the temperature is below 21°C (70°F) the decal may not adhere to the body surface properly.
| IMPORTANT | You may apply stripes or decals using the dry method. Use the wet method if the dry method does not result in a bubble free application. This may be the case in large graphics packages. Use the wet method in order to apply the stripes or decals that are applied on flexible surfaces (fascias, etc.). This will reduce the formation of bubbles under the decal due to the outgassing potential of the flexible materials. |
Use the following equipment and materials in order to apply a stripe or a decal
- A wetting solution A foaming type of window cleaner that does not contain ammonia.
- A silicone, wax and grease remover
- Varnish Makers and Painters (VM&P) Naptha
- Isopropyl alcohol
- A squeegee 75-100 mm (3-4 in) wide Made of plastic or hard rubber Deburr any sharp or rough edges in order to prevent scratching of the stripe or decal.
- A water bucket and sponge or spray bottle
- Sandpaper 800 grit or finer Wet or dry type
- A J 25070 heat gun
- A clean, lint-free wiping cloth
- A sharp knife or razor blade
- A pair of scissors
- A fine pin or needle
- A marking pencil
- Remove the following components: Necessary moldings or trim panel Molding attaching clips Handles Sidemarker lamps Other stripe or decal overlapping parts
- Clean the following areas as needed: The repair surfaces The adjacent panels The openings
- Use 3M™ ScotchBrite molding adhesive remover disk 3M™ P/N 07502 or equivalent in order to remove the stripe or decal from the body panel.
- Use Varnish Makers and Painters (VM&P) Naptha to remove all traces of adhesive residue from the painted surfaces.
- Prepare the surface. IMPORTANT: Remove any imperfections that would appear through the stripe or decal if the area has been refinished. Clean the painted surface using the following types of removers: Silicone Wax Grease
- Clean the area where the stripe or decal will be applied using a 50-50 mixture of isopropyl alcohol and water.
- Wipe the panel surface using a clean cloth while the solvent is still wet. Allow the panel surface to dry.
- Apply the wetting solution to the area where you are installing the stripe or decal. Application of a soapy wetting solution on the top side of the stripe or decal will ease the pull of the squeegee on the stripe or decal. IMPORTANT: Do not touch the adhesive backing of the stripes. Apply the wetting solution on the adhesive side of the stripe or decal. Remove the backing material of the stripe or the decal as needed.
- Apply the strip or decal to the panel. The wetting solution will allow movement for proper positioning on the panel surface.
- Working from the center where possible, squeegee the stripe or decal into position. Apply additional wetting solution as needed to ease installation.
- Apply heat to the stripe or decal at the recessed areas. Press the stripe or decal into the recess to obtain a firm bond.
- Use adequate light reflection to inspect the stripe or decal from a critical angle. This technique detects any irregularities that may have developed during the installation. IMPORTANT: Do not use a razor blade or a knife edge to pierce the air bubbles. Remove all air bubbles by piercing the bubble with one of the following items: A safety pin A needle A tool with the same size piercing tip
- Pierce the bubble on the outer edge. Force the air out through the opposite edge using the blade of the squeegee.
- Install the rear side door stationary window. Refer to «Rear Side Door Stationary Window Replacement»(/buick/enclave/i-2007-2013/remont/heated-glassdefoggers/#fixed-and-moveable-windows) .
Scheme 11
Scheme 11: Rear Door Frame Applique Replacement (Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedures Place the rear door window in the full down position. Remove the rear door outer belt sealing strip. Refer to Rear Side Door Window Inner Sealing Strip Replacement . Remove the rear door window inner sealing strip. Refer to Rear Side Door Window Outer Sealing Strip Replacement (Enclave) . |
| 1 | Rear Side Door Applique Rivet (Qty: 2) Apply masking tape to the door frame and applique. Pull the window channel weatherstrip from the applique to expose the rivets. Drill out the rivets to remove the applique. |
| 2 | Rear Door Applique TIP: Pull the applique up and out of the door. |
Rear Door Frame Applique Replacement (Enclave)
Scheme 12
Scheme 12: Front Fog Lamp Bezel Replacement (Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the parking and front fog lamp bracket. Refer to Parking and Front Fog Lamp Bracket Replacement (Enclave) . |
| 1 | Front Fog Lamp Bezel Procedure Disengage the front fog lamp bezel tabs from the parking and front fog lamp bracket. |
| 2 | Parking and Front Fog Lamp Bracket |
Front Fog Lamp Bezel Replacement (Enclave)
Scheme 13
Scheme 13: Front Fog Lamp Bezel Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the wheelhouse liner in order to access the rear of the front fog lamp. Refer to Front Wheelhouse Front Liner Replacement (Enclave - Acadia) . |
| 1 | Front Fog Lamp Bezel Procedure Release the tabs securing the bezel to the front upper bumper fascia fog lamp opening. Push the bezel outward from inside the fascia in order to remove. |
Front Fog Lamp Bezel Replacement (Acadia)
Scheme 14
Scheme 14: Rocker Panel Front Molding Replacement (Enclave)
| Callout | Component Name |
|---|
| WARNING: Use the proper eye protection when drilling to prevent metal chips from causing physical injury. Preliminary Procedures Open both side doors in order to assist in the removal process of the lower front rocker panel molding. Remove the tire and wheel assembly. Refer to Tire and Wheel Removal and Installation . Remove the three rivets from the front lower wheelhouse panel. Remove the front and rear side door lower weatherstrip. |
| 1 | Wheelhouse Liner Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in) |
| 2 | Rivet (Qty: 3) WARNING: Use the proper eye protection when drilling to prevent metal chips from causing physical injury. Procedure Use a suitable sharp twist drill and remove the three rivets. |
| 3 | Retainer Lower (Qty: 7) Procedure Use a suitable type trim tool in order to disengage the retainers from the quarter outer lower panel. |
| 4 | Retainer Upper (Qty: 12) Procedure Use a suitable type trim tool in order to disengage the retainers from the quarter outer upper panel. |
| 5 | Rocker Panel Front Molding Procedure Detach and remove the rocker panel front molding from the rocker panel rear molding. |
| WARNING |
|---|
| Use the proper eye protection when drilling to prevent metal chips from causing physical injury. |
| WARNING |
|---|
| Use the proper eye protection when drilling to prevent metal chips from causing physical injury. |
Rocker Panel Front Molding Replacement (Enclave)
Scheme 15
Scheme 15: Rocker Panel Front Molding Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure Open both side doors in order to remove the rocker panel front molding assembly. |
| 1 | Rocker Panel Finish Panel Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Procedure Remove the rocker panel rear molding assembly. Remove the 3 front finish panel screws. Release the 6 lower rocker molding retainers. Release the 12 upper rocker molding retainers. Tighten 1.5 N.m (13 lb in) |
| 2 | Rocker Panel Rear Molding Retainer (Qty: 18) |
| 3 | Rocker Panel Front Molding Assembly TIP: Replace the retainer clips as needed. |
Rocker Panel Front Molding Replacement (Acadia)
Scheme 16
Scheme 16: Rocker Panel Front Molding Replacement (Traverse)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front wheelhouse rear liner in order to access the upper front rocker panel molding screw. Refer to Front Wheelhouse Rear Liner Replacement (Traverse) . Open both side doors in order to remove the rocker panel front molding assembly. Disengage the last rear front and rear side door weatherstrip clip from the rear rocker molding. |
| 1 | Rocker Panel Finish Panel Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in) |
| 2 | Lower W-clip (Qty: 7) TIP: Use a suitable retainer release tool to disengage the w-clips from the lower rocker panel |
| 3 | Upper W-clip (Qty: 12) |
| 4 | Fender W-clip (Qty2) |
| 5 | Rocker Panel Front Molding Procedure Release the auxiliary weatherstrip from the rear rocker molding. Release the front rocker panel molding from the forward edge of the rear rocker molding. |
Rocker Panel Front Molding Replacement (Traverse)
Scheme 17
Scheme 17: Rocker Panel Rear Molding Replacement (Traverse)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the rear tire and wheel assembly. Refer to Tire and Wheel Removal and Installation . Open the rear door in order to remove the rocker panel rear molding. Release the front and rear side door weatherstrip retainer from the rear rocker panel molding. |
| 1 | Rear Rocker Panel Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in) |
| 2 | Rocker Panel Molding W-clip (Qty: 4) |
| 3 | Rocker Panel Rear Molding Assembly Procedure Release the three retainers from the back side of the molding and remove. Slide the rear rocker panel molding from the rear edge of the front rocker panel molding. |
Rocker Panel Rear Molding Replacement (Traverse)
Scheme 18
Scheme 18: Rocker Panel Rear Molding Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure Open the rear door in order to remove the rocker panel rear molding. |
| 1 | Rear Rocker Panel Finish Panel Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in) |
| 2 | Rocker Panel Molding Retainers (Qty: 2) |
| 3 | Rocker Panel Rear Molding Assembly Procedure Release the 2 retainers from the back side of the molding and remove. |
Rocker Panel Rear Molding Replacement (Acadia)
Scheme 19
Scheme 19: Rocker Panel Rear Molding Replacement (Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedures Open the rear side door on the side the molding is to be replaced. Remove the outer lower screw from the rocker panel molding extension. Refer to Rocker Panel Extension Molding Replacement . Disengage the rear most retainer clip from the front and rear side door lower weatherstrip that attaches to the rocker panel rear molding. |
| 1 | Rear Wheelhouse Liner Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in) |
| 2 | Retainer (Qty: 3) |
| 3 | Rocker Panel Rear Molding Procedure Detach the rear rocker panel molding from the front rocker panel molding. |
Rocker Panel Rear Molding Replacement (Enclave)
Scheme 20
Scheme 20: Rear Side Door Window Frame Rear Cover Replacement (Traverse)
| Callout | Component Name |
|---|
| 1 | Rear Side Door Window Frame Rear Cover |
| 2 | Rear Side Door Window Frame Rear Cover Retainer (Qty: 2) |
Rear Side Door Window Frame Rear Cover Replacement (Traverse)
Scheme 21
Scheme 21: Front Bumper Fascia Emblem/Nameplate Replacement (Traverse)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front bumper fascia in order to access and remove the heat stakes from the emblem assembly. Refer to Front Bumper Fascia Replacement (Traverse) . |
| 1 | Front Bumper Fascia Emblem Assembly Procedure Place the front bumper fascia face down on a clean protected surface. Cut the heat stakes from the rear side of the emblem assembly. Remove the emblem from the bumper fascia. Place the new emblem locator pins to the holes in the front bumper fascia. Hold the emblem firmly against the front bumper fascia. |
| 2 | Front Bumper Fascia Emblem Nut (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten Hand Tighten the nuts. |
Front Bumper Fascia Emblem/Nameplate Replacement (Traverse)
Scheme 22
Scheme 22: Radiator Grille Emblem/Nameplate Replacement (Enclave)
| Callout | Component Name |
|---|
| 1 | Radiator Grille Emblem (Tri-Shield) Procedure Open the hood. Squeeze the 4 tabs on the emblem in order to unlock the emblem from the radiator grille. Rotate the emblem in a counter-clockwise direction and push outward. Remove the emblem from the radiator grille. |
Radiator Grille Emblem/Nameplate Replacement (Enclave)
Scheme 23
Scheme 23: Radiator Grille Emblem/Nameplate Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front radiator grille. Refer to Radiator Grille Replacement (Acadia) . |
| 1 | Emblem Assembly (GMC) CAUTION: Refer to Exterior Trim Emblem Removal Caution . Release the 4 retaining clips as heating the front radiator grille emblem. The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 heat gun or equivalent to remove the old nameplate. Clean all adhesive from grille and wipe the surface dry with a clean lint-free towel prior to installing the new name plate. When removing protective liners from the adhesive tape, be careful not to touch tape with hands and do not allow tape to come in contact with dirt or any foreign matter prior to adhesion. Align the two pins and 4 retaining clips into the grille opening. Using the palm of the hand, wet out the emblem to the grille and ensure full adhesion of the emblem is made. |
Radiator Grille Emblem/Nameplate Replacement (Acadia)
Scheme 24
Scheme 24: Body Side Emblem/Nameplate Replacement (Acadia)
| Callout | Component Name |
|---|
| 1 | C Pillar Emblem / Nameplate CAUTION: Refer to Exterior Trim Emblem Removal Caution . Procedure Use a J 25070 heat gun or equivalent to remove the old emblem/nameplate. Clean all adhesive from the bodyside, wipe surface dry with a clean lint-free towel prior to installing new emblem/nameplate. When removing protective liners from adhesive tape, be careful not to touch tape with hands and do not allow tape to come in contact with dirt or any foreign matter prior to adhesion. Ensure full adhesion of the nameplate to the bodyside is made. |
Body Side Emblem/Nameplate Replacement (Acadia)
Scheme 25
Scheme 25: Front Side Door Emblem/Nameplate Replacement (Acadia)
| Callout | Component Name |
|---|
| 1 | Front Door Nameplate (GM) Procedure When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Use a J 25070 heat gun or equivalent to remove the old nameplate. Clean all the adhesive residue from the door, wipe the surface dry with a clean lint-free towel prior to installing the new GM nameplate. Press the nameplate firmly to the front door molding to ensure full adhesion to the molding is made. |
Front Side Door Emblem/Nameplate Replacement (Acadia)
Scheme 26
Scheme 26: Front Side Door Emblem/Nameplate Replacement (Traverse)
| Callout | Component Name |
|---|
| 1 | Front Side Door Nameplate Assembly (TRAVERSE) Procedure When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Use a J 25070 heat gun or equivalent and a small flat-bladed tool in order to remove the old letter nameplate. Clean all the adhesive residue from the door bodyside molding, wipe the surface dry with a clean lint-free towel prior to installing the new TRAVERSE letter nameplate. Close the front door. Press the nameplate firmly to the front door molding to ensure full adhesion to the body side molding is made. |
Front Side Door Emblem/Nameplate Replacement (Traverse)
Scheme 27
Scheme 27: Front Side Door Emblem/Nameplate Replacement (Enclave GM)
| Callout | Component Name |
|---|
| 1 | Front Side Door Nameplate/Emblem CAUTION: Refer to Exterior Trim Emblem Removal Caution . Procedure The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 heat gun or equivalent to remove the old nameplate. Clean all the adhesive residue from the door and wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the door prior to installing the new nameplate/emblem to the lower front rocker molding. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the front rocker molding and press to ensure full adhesion is made. |
Front Side Door Emblem/Nameplate Replacement (Enclave GM)
Scheme 28
Scheme 28: Liftgate Emblem/Nameplate Replacement (TRAVERSE AWD)
| Callout | Component Name |
|---|
| 1 | Liftgate Nameplate Assembly CAUTION: Refer to Exterior Trim Emblem Removal Caution . Procedure The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 heat gun or equivalent to remove the old emblem. Clean all adhesive from rear liftgate and wipe the surface dry with a clean lint-free towel prior to installing the new emblem / nameplate. Close the liftgate. When removing protective liners from the adhesive tape, be careful not to touch tape with hands and do not allow tape to come in contact with dirt or any foreign matter prior to adhesion. Apply the liftgate nameplate to the desired location on the liftgate. Wet out the emblem and ensure full adhesion of the emblem to the liftgate is made. |
Liftgate Emblem/Nameplate Replacement (TRAVERSE AWD)
Scheme 29
Scheme 29: Liftgate Emblem/Nameplate Replacement (TRAVERSE LS LT LTZ)
| Callout | Component Name |
|---|
| 1 | Liftgate Trim Nameplate Assembly (LS LT LTZ) CAUTION: Refer to Exterior Trim Emblem Removal Caution . Procedure Use a J 25070 heat gun or equivalent to remove the old nameplate. Clean all the adhesive residue from the liftgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the liftgate prior to installing the new nameplate/emblem to the liftgate. Remove the protective liner from the back side of the adhesive tape. Position the nameplate/emblem to the liftgate and press to ensure full adhesion is made. |
Liftgate Emblem/Nameplate Replacement (TRAVERSE LS LT LTZ)
Scheme 30
Scheme 30: Liftgate Emblem/Nameplate Replacement (Chevrolet)
| Callout | Component Name |
|---|
| 1 | Liftgate Nameplate Assembly CAUTION: Refer to Exterior Trim Emblem Removal Caution . Procedure The part and surface should be 21°C (70°F) prior to installation. The vehicle should remain 21°C (70°F) for one hour after assembly to allow adhesive to develop sufficient bond strength. Use a J 25070 heat gun or equivalent to remove the old emblem. Clean all adhesive from rear liftgate and wipe the surface dry with a clean lint-free towel prior to installing the new emblem / nameplate. Close the liftgate. When removing protective liners from the adhesive tape, be careful not to touch tape with hands and do not allow tape to come in contact with dirt or any foreign matter prior to adhesion. Apply the liftgate nameplate to the desired location on the liftgate. Wet out the emblem and ensure full adhesion of the emblem to the liftgate is made. |
Liftgate Emblem/Nameplate Replacement (Chevrolet)
Scheme 31
Scheme 31: Liftgate Emblem/Nameplate Replacement (Acadia)
| Callout | Component Name |
|---|
| 1 | Liftgate Nameplate/Emblem CAUTION: Refer to Exterior Trim Emblem Removal Caution . Procedure Use a J 25070 heat gun or equivalent to remove the old nameplate. Clean all the adhesive residue from the liftgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the liftgate prior to installing the new nameplate/emblem to the liftgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the liftgate and press to ensure full adhesion is made. |
Liftgate Emblem/Nameplate Replacement (Acadia)
Scheme 32
Scheme 32: Liftgate Emblem/Nameplate Replacement (AWD Acadia)
| Callout | Component Name |
|---|
| 1 | Liftgate Nameplate/Emblem CAUTION: Refer to Exterior Trim Emblem Removal Caution . Procedure Use a J 25070 heat gun or equivalent to remove the old nameplate. Clean all the adhesive residue from the liftgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the liftgate prior to installing the new nameplate/emblem to the liftgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate/emblem to the liftgate and press to ensure full adhesion is made. |
Liftgate Emblem/Nameplate Replacement (AWD Acadia)
Scheme 33
Scheme 33: Liftgate Emblem/Nameplate Replacement (Enclave Nameplate)
| Callout | Component Name |
|---|
| 1 | Liftgate Emblem (ENCLAVE) CAUTION: Refer to Exterior Trim Emblem Removal Caution . Procedure Use a J 25070 heat gun or equivalent to remove the old emblem. Clean all the adhesive residue from the liftgate, wipe the surface dry with a clean lint-free towel prior to installing new emblem. When removing protective liners from adhesive backed emblems, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the liftgate prior to installing the new emblem to the liftgate. Remove the protective liner from the back side of the adhesive tape. Align the emblem to the liftgate and press to ensure full adhesion is made. |
| 2 | Liftgate Emblem (CX, CXL) Procedure Use a J 25070 heat gun or equivalent to remove the old emblem. Clean all the adhesive residue from the endgate, wipe the surface dry with a clean lint-free towel prior to installing new emblem. When removing protective liners from adhesive backed emblems, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the liftgate prior to installing the new emblem to the liftgate. Remove the protective liner from the back side of the adhesive tape. Align the emblem to the liftgate and press to ensure full adhesion is made. |
| 3 | Liftgate Nameplate (BUICK) Procedure Use a J 25070 heat gun or equivalent to remove the old nameplate. Clean all the adhesive residue from the liftgate, wipe the surface dry with a clean lint-free towel prior to installing new nameplate. When removing protective liners from adhesive backed nameplates, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the liftgate prior to installing the new nameplate to the liftgate. Remove the protective liner from the back side of the adhesive tape. Align the nameplate to the liftgate and press to ensure full adhesion is made. |
Liftgate Emblem/Nameplate Replacement (Enclave Nameplate)
Scheme 34
Scheme 34: Liftgate Emblem/Nameplate Replacement (Enclave Tri Shield)
| Callout | Component Name |
|---|
| 1 | Liftgate Emblem (Tri-Shield) CAUTION: Refer to Exterior Trim Emblem Removal Caution . Procedure Using masking tape mark two sides of the placement where the old emblem/nameplate was placed. Use a J 25070 heat gun or equivalent to remove the old emblem. Clean all the adhesive residue from the liftgate, wipe the surface dry with a clean lint-free towel prior to installing new emblem. When removing protective liners from adhesive backed emblems, be careful not to touch the tape with hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Close the liftgate prior to installing the new emblem to the liftgate. Remove the protective liner from the back side of the adhesive tape. Align the emblem to the two guide holes or with the non-pin design align to the masking tape on the liftgate outer panel and press to ensure full adhesion is made. |
Liftgate Emblem/Nameplate Replacement (Enclave Tri Shield)
Scheme 35
Scheme 35: Radiator Grille Replacement (Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedure Open the hood in order to access the fasteners for the radiator grille. |
| 1 | Radiator Grille Support Bracket Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in) |
| 2 | Radiator Grille Support Bracket (Qty: 2) |
| 3 | Radiator Grille Outer Bracket Bolt (Qty: 2) Tighten 2.5 N.m (22 lb in) |
| 4 | Radiator Grille Upper Nut (Qty: 4) Tighten 9 N.m (80 lb in) |
| 5 | Radiator Grille Assembly TIP: Transfer the radiator grille emblem. Refer to Radiator Grille Emblem/Nameplate Replacement (Enclave) . |
Radiator Grille Replacement (Enclave)
Scheme 36
Scheme 36: Radiator Grille Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement (Acadia) . |
| 1 | Radiator Grille Screw (Qty: 6) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in) |
| 2 | Radiator Grille Assembly Procedure Release the 12 integral tabs using a small flat-bladed tool securing the radiator grille to the front bumper fascia. Pull the grille assembly outward from the front bumper fascia and remove. Place the grille assembly on a clean protected surface. Transfer the radiator grille emblem/nameplate. Refer to Radiator Grille Emblem/Nameplate Replacement (Acadia) . |
Radiator Grille Replacement (Acadia)
Scheme 37
Scheme 37: Radiator Upper Grille Replacement (Traverse)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement (Traverse) . |
| 1 | Upper Radiator Grille Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten Hand tighten the screws. |
| 2 | Upper Radiator Grille TIP: Release the retainer tabs securing the upper radiator grille to the front bumper fascia. |
Radiator Upper Grille Replacement (Traverse)
Scheme 38
Scheme 38: Radiator Lower Grille Replacement (Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedures Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . Remove the lower radiator retainers from the air baffle. |
| 1 | Radiator Lower Grille Edge Type Clip (Qty: 15) TIP: Release the clips from inside the lower radiator grille. |
| 2 | Radiator Lower Grille Procedure Remove the lower grille from inside the lower bumper fascia. |
Radiator Lower Grille Replacement (Enclave)
Scheme 39
Scheme 39: Radiator Lower Grille Replacement (Traverse)
| Callout | Component Name |
|---|
| Preliminary Procedure Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement (Traverse) . |
| 1 | Radiator Lower Grille TIP: Release the retainer tabs securing the lower radiator grille to the front bumper fascia opening. |
Radiator Lower Grille Replacement (Traverse)
Scheme 40
Scheme 40: Front Side Door Molding Replacement (Acadia, Traverse)
| Callout | Component Name |
|---|
| 1 | Front Side Door Center Molding Assembly CAUTION: Refer to Exterior Trim Emblem Removal Caution . Procedure Using a J 25070 heat gun in a circular motion in order to warm and help to remove the front side door molding. Peel the adhesive tape liner from the molding. Align the 3 plastic retainers to the holes in the door. Secure the retainers to the door. Using a clean towel and hand pressure, wet out the entire length of the molding starting at the front edge of the rear door and working rearward. |
| 2 | Front Side Door Center Molding Retainer (Qty: 3) |
Front Side Door Molding Replacement (Acadia, Traverse)
Scheme 41
Scheme 41: Front Side Door Lower Molding Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure Using a J 25070 heat gun in a circular motion, warm the lower edge of the front side door molding prior to removal. Carefully clean the body panel thoroughly prior to bonding the new lower body side molding to the door. |
| 1 | Front Side Door Lower Molding and Retainers (Qty: 12) Procedure Using a J 38778 door trim pad clip remover or equivalent, release the retainers securing the door lower molding to the door. Close the door upon assembly of the new molding. Begin with the center retainer, secure, and work outward from the center securing the remainder of the molding to the door. Release the adhesive tape backing and wet out completely. |
Front Side Door Lower Molding Replacement (Acadia)
Scheme 42
Scheme 42: Front Side Door Lower Molding Replacement (Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedure Using a J 25070 heat gun in a circular motion, warm the lower edge of the front side door molding prior to removal. Carefully clean the body panel thoroughly prior to bonding the new lower body side molding to the door. |
| 1 | Front Side Door Lower Locating Hole Procedure Align the pin on the backside of the molding to the hole prior to securing the retainers. |
| 2 | Front Side Door Molding Integral Retainers (Qty: 11) |
| 3 | Front Side Door Lower Molding Procedure Close the door upon assembly of the new lower front door molding. Align the locator pin and secure the retainers. Release the adhesive tape backing and using a clean shop towel and the palm of the hand, completely wet out the entire periphery of the molding in order to assure complete adhesion of the lower front door bodyside molding. |
Front Side Door Lower Molding Replacement (Enclave)
Scheme 43
Scheme 43: Front Side Door Lower Molding Replacement (Traverse)
| Callout | Component Name |
|---|
| Preliminary Procedure Using a J 25070 heat gun in a circular motion, warm the front side of the lower front door molding prior to removal. Carefully clean the body panel thoroughly prior to bonding the new lower body side molding to the door. |
| 1 | Lower Molding Base Clip Retainers (Qty: 11) Procedure Use a suitable trim removal tool to disengage the base clip retainers from the door panel. |
| 2 | Rear Side Lower Door Molding Assembly Procedure Close the door prior to engaging the base clip retainers. Peel the adhesive tape backing from the molding. Align the center retainer to the center hole in the front door panel. Align the remaining retainers to the adjacent holes. Firmly press the molding into the door beginning at the center base clip retainer and working outward in both directions. |
Front Side Door Lower Molding Replacement (Traverse)
Scheme 44
Scheme 44: Front and Rear Side Door Opening Frame Reveal Molding Replacement
| Callout | Component Name |
|---|
| Preliminary Procedure Open the front and rear door on the side the door opening frame reveal molding will be replaced. |
| 1 | Front and Rear Side Door Opening Frame Reveal Molding Integral Clip (Qty: 12) |
| 2 | Front and Rear Side Door Opening Frame Reveal Molding Procedure Remove the front fender upper rear molding. Refer to Front Fender Upper Rear Molding Replacement (Enclave) . Carefully release the front frame reveal molding from the butt joint located at the quarter panel bezel joint tie plate. Upon installation, secure the butt joint ends firmly together prior aligning the molding retainer clips to the body panel. Secure the front fender upper rear molding. Refer to Front Fender Upper Rear Molding Replacement (Enclave) . |
Front and Rear Side Door Opening Frame Reveal Molding Replacement
Scheme 45
Scheme 45: Front Fender Wheel Opening Molding Replacement (Acadia)
| Callout | Component Name |
|---|
| CAUTION: Refer to Exterior Trim Emblem Removal Caution . Preliminary Procedures Using a 50/50 mixture of isopropyl alcohol and clean drinkable water and a clean towel, remove the left over adhesive residue from the flare. Wipe the fender with a clean dry towel. Peel the adhesive tape backing from the fender wheel molding. Secure the fender wheel molding starting at the center and working outward. Completely wet out the fender wheel molding. |
| 1 | Integral Tabs (Qty: 9) |
| 2 | Integral Clips (Qty: 2) |
| 3 | Front Wheelhouse Molding |
Front Fender Wheel Opening Molding Replacement (Acadia)
Scheme 46
Scheme 46: Front Fender Wheel Opening Molding Replacement (Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedures Release the five forward and six rearward wheelhouse liner screws to allow for the repositioning of the liner. Remove the five screws from the front portion of the wheelhouse liner to fender flange. Remove the three upper fender molding to fender flange push pin retainers. Remove the six rearward flare to fender flange screws. Release the retainer clips, three forward and two rearward from the fender flange. |
| 1 | Front Wheel Opening Molding Screw (Qty: 5) CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb ) |
| 2 | Retainer Clips (Qty: 5) TIP: Release the clips from inside the fender flange. |
| 3 | Front Wheel Opening Molding Assembly |
Front Fender Wheel Opening Molding Replacement (Enclave)
Scheme 47
Scheme 47: Hood Front Molding Replacement (Acadia Denali)
| Callout | Component Name |
|---|
| CAUTION: Refer to Exterior Trim Emblem Removal Caution . Preliminary Procedure Open and support the hood assembly. |
| 1 | Hood Front Molding Procedure Ensure the hood outer panel paint is protected at the edge of the hood molding with the use of masking tape. Gently pry upward on one corner of the hood front molding releasing the two outer retainer clips first, followed by the remaining seven retainer clips across the molding. Remove the masking tape from the outer hood panel. |
Hood Front Molding Replacement (Acadia Denali)
Scheme 48
Scheme 48: Hood Side Molding Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Use a J 25070 heat gun , or equivalent to remove the old hood molding. Clean all adhesive from the hood side molding, then wipe the surface dry with a clean lint-free towel, prior to installing the new hood molding. When removing the protective liners from the adhesive tape, be careful not to touch the tape with your hands and do not allow the tape to come in contact with dirt or any foreign matter prior to adhesion. Never allow the body temperature to be below 19°C (66°F) prior to installation. Ensure the hood is free from dirt and foreign matter prior to the molding installation. |
| 1 | Hood Molding TIP: Remove the protective adhesive tape liner and carefully insert the molding into the 3 openings in the upper hood. |
Hood Side Molding Replacement
Scheme 49
Scheme 49: Liftgate Upper Molding Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure Open the liftgate in order to access the applique integral tabs and retainers. |
| 1 | Integral Tabs (Qty: 6) |
| 2 | Liftgate Applique Procedure Release the retainers and roll the applique outward off from the hem flange. |
Liftgate Upper Molding Replacement (Acadia)
Scheme 50
Scheme 50: Front Fender Upper Rear Molding Replacement (Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedure Open the front driver or passenger door in order to access the retainers. |
| 1 | Front Fender Upper Rear Molding Screw CAUTION: Refer to Fastener Caution . Tighten 1.5 N.m (13 lb in) |
| 2 | Integral Retainer Clip (Qty: 3) |
| 3 | Front Fender Upper Rear Molding Assembly Procedure Remove the screw. Carefully release the three retainers from the front fender upper rear molding and release four retainers from the forward edge of the front and rear upper reveal molding. Hold onto the front and rear side door upper reveal molding and pull the front fender upper rear molding butt joint apart. |
Front Fender Upper Rear Molding Replacement (Enclave)
Scheme 51
Scheme 51: Rear Side Door Molding Replacement (Acadia, Traverse)
| Callout | Component Name |
|---|
| 1 | Rear Side Door Center Molding Assembly CAUTION: Refer to Exterior Trim Emblem Removal Caution . Procedure Use a J 25070 heat gun in a circular motion in order to warm and help to remove the rear side door molding. Peel the adhesive tape liner from the molding. Align the 3 plastic clips to the holes in the door. Align the B pillar clip first followed by the other two clips. Secure the clips using the mandatory sequence as noted. Push up slightly on the molding when aligning the other 2 holes. Using a clean towel and hand pressure, wet out the entire length of the molding starting at the front edge of the rear door and working rearward. |
Rear Side Door Molding Replacement (Acadia, Traverse)
Scheme 52
Scheme 52: Rear Side Door Lower Molding Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure Using a J 25070 heat gun in a circular motion, warm the front side door molding prior to removal. Carefully clean the body panel thoroughly prior to bonding the new lower body side molding to the door. Special Tools J 25070 Heat Gun |
| 1 | Rear Side Door Lower Molding Locating Pin Procedure Align the pin to the center of the door prior to securing the retainers. |
| 2 | Rear Side Lower Door Molding Procedure Secure the molding to the door and remove the protective liner on the backside of the molding after all of the retainers are secure. |
| 3 | Lower Molding Integral Retainer (Qty: 10) |
Rear Side Door Lower Molding Replacement (Acadia)
Scheme 53
Scheme 53: Rear Side Door Lower Molding Replacement (Enclave)
| Callout | Component Name |
|---|
| Preliminary Procedure Using a J 25070 heat gun in a circular motion, warm the rear side door molding prior to removal. Carefully clean the body panel thoroughly prior to bonding the new lower body side molding to the door. |
| 1 | Rear Side Door Lower Molding Locating Hole Procedure Align the pin to the center of the door prior to securing the retainers. |
| 2 | Lower Molding Integral Retainers (Qty: 11) |
| 3 | Rear Side Lower Door Molding Procedure Secure the molding retainers to the door and remove the protective liner on the backside of the molding after all of the retainers are secure. Using a clean shop towel and the palm of the hand, wet out the entire periphery of the molding in order to assure complete adhesion of the lower door bodyside molding. |
Rear Side Door Lower Molding Replacement (Enclave)
Scheme 54
Scheme 54: Rear Side Door Lower Molding Replacement (Traverse)
| Callout | Component Name |
|---|
| Preliminary Procedure Using a J 25070 heat gun in a circular motion, warm the front side of the lower rear door molding prior to removal. Carefully clean the body panel thoroughly prior to bonding the new lower body side molding to the door. |
| 1 | Lower Molding Base Clip Retainers (Qty: 10) Procedure Use a suitable trim removal tool to disengage the base clip retainers from the door panel. |
| 2 | Rear Side Lower Door Molding Assembly Procedure Close the door prior to engaging the base clip retainers. Peel the adhesive tape backing from the molding. Align the center retainer to the center hole in the door panel. Align the remaining retainers to the adjacent holes. Firmly press the molding into the door beginning at the center base clip retainer and working outward in both directions. |
Rear Side Door Lower Molding Replacement (Traverse)
Scheme 55
Scheme 55: Rear Wheel Opening Molding Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedure Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle . |
| 1 | Rear Wheel Opening Flare Integral Retainers (Qty: 7) Procedure Secure the center retainer to the center upper wheelhouse opening followed by the remainder of the retainers. |
| 2 | Rear Wheel Opening Flare Tabs (Qty: 2) |
| 3 | Rear Wheel Opening Flare |
Rear Wheel Opening Molding Replacement (Acadia)
Scheme 56
Scheme 56: Rocker Panel Extension Molding Replacement
| Callout | Component Name |
|---|
| 1 | Rocker Panel Extension Molding Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in) |
| 2 | Rocker Panel Extension Molding Bolt Tighten 5.0 N.m (44 lb in) |
| 3 | Rocker Panel Extension Molding Assembly TIP: Position the top edge of the molding under the front bottom edge of the rear wheelhouse panel prior to installing the screws. |
Rocker Panel Extension Molding Replacement
Scheme 57
Scheme 57: Roof Panel Molding Retainer Replacement
| Callout | Component Name |
|---|
| CAUTION: Refer to Tape Corners of Panel Caution . CAUTION: Refer to Exterior Trim Emblem Removal Caution . Preliminary Procedure Remove roof panel joint finish molding. Refer to Roof Panel Joint Finish Molding Replacement (Traverse) , Roof Panel Joint Finish Molding Replacement (Acadia) Mark the front and rear edge of the current roof panel molding retainer location Carefully cut the epoxy bond at both edges of the roof panel molding retainer using a sharp tool. Cut far enough into the epoxy in order to help release the roof panel molding retainer and not damage the painted surface of the ditch. Protect the painted surface of the ditch using a clean towel when releasing the roof panel molding retainer from the ditch. Clean the remaining epoxy using a 50/50 mixture by volume of isopropyl alcohol and clean drinkable water. Use fine grit sand paper to scuff the bonding surface where the new roof panel molding retainer will be installed. |
| 1 | Roof Panel Molding Retainer (Front) Procedure Ensure that a new pre-cured roof panel molding retainer is being used and discard old retainer. Apply 3M DURAMIX Super-Fast Adhesive 4747 or equivalent to the cured structural bonding on the new roof panel molding retainer. The front roof panel molding retainer is placed 25 mm from the front edge of the window frame, centered side to side in the ditch channel and secured with masking tape. Apply an overlapping drop of adhesive on the front and rear edge of the roof panel molding retainer to the ditch channel. Allow time for sufficient bonding strength. Minimum 15 minutes at 23°C (73°F) Minimum 30 minutes at 10-23°C (50-73°F) Minimum 60 minutes at 5-10°C (41-50°F) Remove the masking tape after the bonding time has elapsed. Please allow adhesive to fully cure prior to installing roof panel joint finish molding. |
| 2 | Roof Panel Molding Retainer (Rear) Procedure Ensure that a new pre-cured roof panel molding retainer is being used and discard old retainer. Apply 3M DURAMIX Super-Fast Adhesive 4747 or equivalent to the cured structural bonding on the new roof panel molding retainer. The rear roof panel molding retainer is placed 25 mm from the rear edge of the roof panel, centered side to side in the ditch channel and secured with masking tape. Apply an overlapping drop of adhesive on the front and rear edge of the roof panel molding retainer to the ditch channel. Allow time for sufficient bonding strength. Minimum 15 minutes at 23°C (73°F) Minimum 30 minutes at 10-23°C (50-73°F) Minimum 60 minutes at 5-10°C (41-50°F) Remove the masking tape after the bonding time has elapsed. Please allow adhesive to fully cure prior to installing roof panel joint finish molding. |
Roof Panel Molding Retainer Replacement
Scheme 58
Scheme 58: Roof Panel Joint Finish Molding Replacement (Traverse)
| Callout | Component Name |
|---|
| 1 | Roof Panel Joint Finish Molding Procedure Remove the luggage carrier (if equipped). Refer to Luggage Carrier Replacement (Traverse) . Locate the finish molding fore/aft to be within 15-20 mm from the front edge of the windshield opening and also the rear edge of the roof panel. Insert molding into the front roof ditch clip securing one clip finger at a time from front to rear. Press small portions of the roof ditch molding front to rear. Secure the reminder of the molding into the rear ditch one clip finger at a time. If loose or damaged molding retainer clips are present, refer to Roof Panel Molding Retainer Replacement for the repair procedure. |
Roof Panel Joint Finish Molding Replacement (Traverse)
Roof Panel Joint Finish Molding Replacement (Acadia)
| Callout | Component Name |
|---|
| 1 | Roof Panel Joint Finish Molding Procedure Locate the finish molding fore/aft to be within 15-20 mm from the front edge of the windshield opening and also the rear edge of the roof panel. Insert molding into the front roof ditch clip securing one clip finger at a time from front to rear. Press small portions of the roof ditch molding front to rear. Secure the reminder of the molding into the rear ditch one clip finger at a time. If loose or damaged molding retainer clips are present, refer to Roof Panel Molding Retainer Replacement for the repair procedure. |
Roof Panel Joint Finish Molding Replacement (Acadia)
Scheme 59
Scheme 59: Rear Spoiler Replacement (Enclave, Traverse)
| Callout | Component Name |
|---|
| Preliminary Procedures Open the rear liftgate. Remove the interior liftgate garnish molding. Refer to Liftgate Garnish Molding Replacement (TB4) , Liftgate Garnish Molding Replacement (TB5) . Disconnect the center high mounted stop lamp electrical connector. Disconnect the rear window washer nozzle hose from the bottom side of the rear spoiler and washer nozzle spout. |
| 1 | Rear End Spoiler Assembly Nut (Qty: 5) CAUTION: Refer to Fastener Caution . Tighten 6 N.m (53 lb in) |
| 2 | Rear End Spoiler Assembly Integral Retainer (Qty: 4) Procedure Insert a flat-bladed tool into the access holes in the inner liftgate panel in order to release the clips while lifting up on the outside edges of the rear spoiler. Release the integral clips from across the upper liftgate flange working from the outboard edge inward. Transfer the rear window washer nozzle. |
| 3 | Rear End Spoiler Assembly TIP: Remove and transfer the high mounted stop lamp. Refer to High Mount Stop Lamp Replacement (Traverse) , High Mount Stop Lamp Replacement (Enclave) . |
Rear Spoiler Replacement (Enclave, Traverse)
Rear Spoiler Replacement (Acadia)
| Callout | Component Name |
|---|
| Preliminary Procedures Open the rear liftgate. Remove the interior liftgate garnish molding. Refer to Liftgate Garnish Molding Replacement (TB4) , Liftgate Garnish Molding Replacement (TB5) . Disconnect the center high mounted stop lamp electrical connector. |
| 1 | Rear Spoiler Assembly Nut (Qty: 5) CAUTION: Refer to Fastener Caution . Tighten 6 N.m (53 lb in) |
| 2 | Rear Spoiler Assembly Clip (Qty: 4) Procedure Insert a flat-bladed tool into the access holes in the inner liftgate panel in order to release the clips while lifting up on the outside edges of the rear spoiler. Release the integral clips from across the upper liftgate flange working from the outboard edge inward. |
| 3 | Rear End Spoiler Assembly TIP: Remove and transfer the high mounted stop lamp. Refer to High Mount Stop Lamp Replacement (Acadia) . |
Rear Spoiler Replacement (Acadia)
