Instrument Panel Trim and Console Trim — Buick Enclave I (2007-2013)

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Carrier Assembly Lower Bolts	9 N.m	80 lb in
Carrier Assembly to Body Bolts	9 N.m	80 lb in
Carrier Assembly Upper Bolts	9 N.m	80 lb in
Drivers Knee Bolster Assembly Screws	2.5 N.m	22 lb in
Front Floor Console Accessory Housing Screws	2 N.m	18 lb in
Front Floor Console Armrest Assembly Bolts	9 N.m	18 lb in
Front Floor Console Armrest Bin Screws	2 N.m	18 lb in
Front Floor Console Armrest Screws	2 N.m	18 lb in
Front Floor Console Bolts	2 N.m	18 lb in
Front Floor Console Compartment Bin Screws	2 N.m	18 lb in
Front Floor Console Compartment Door Latch Opening Cover Screws	2 N.m	18 lb in
Front Floor Console Cover Screws	2 N.m	18 lb in
Front Floor Console Extension Accessory Upper Bezel Screws	2 N.m	18 lb in
Front Floor Console Filler Panel Screws	2 N.m	18 lb in
Floor Console Front Rear Trim Panel Screw	2 N.m	18 lb in
Front Floor Console Screws	2 N.m	18 lb in
Instrument Panel Center Compartment Screws	2 N.m	18 lb in
Instrument Panel Cluster Trim Plate Screws	2 N.m	18 lb in
Instrument Panel Cluster Trim Plate Applique Screws	2 N.m	18 lb in
Instrument Panel Compartment Striker Screws	2 N.m	18 lb in
Instrument Panel Inflatable Restraint Bolts	9 N.m	80 lb in
Instrument Panel Lower Trim Panel Screws/Bolts	2 N.m	18 lb in
Instrument Panel Trim Panel Screws	2 N.m	18 lb in
Instrument Panel Trim Pad Screws	2 N.m	18 lb in
Left Window Air Outlet Screw	9 N.m	80 lb in
Rear Floor Console Armrest Hinge Screw	2.5 N.m	22 lb in
Rear Floor Console Armrest Latch Screw	2.5 N.m	22 lb in
Rear Floor Console Bolts	45 N.m	33 lb ft
Rear Floor Console Front Trim Upper Panel Screw	2.5 N.m	22 lb in
Rear Floor Console Hinge Cover Closeout Screw	2.5 N.m	22 lb in
Rear Floor Console Latch Cover Screw	2.5 N.m	22 lb in
Rear Floor Console Lid Latch Screw	2.5 N.m	22 lb in
Rear Floor Console Lid Trim Cover Screw	2.5 N.m	22 lb in
Rear Floor Console Lid Trim Cover Screw	2.5 N.m	22 lb in
Rear Floor Console Rear Release Latch Screw	2.5 N.m	22 lb in
Rear Floor Console Rear Trim Cover Lower Panel Screw	2.5 N.m	22 lb in
Rear Floor Console Rear Trim Upper Panel Screw	2.5 N.m	22 lb in
Rear Floor Console Side Trim Panel Screw	2.5 N.m	22 lb in
Rear Floor Console Storage Lower Tray Screw	2.5 N.m	22 lb in
Steering Column Housing Cover Screws	2.5 N.m	22 lb in

Fastener Tightening Specifications

Scheme 105

Scheme 105: Instrument Panel Insulator Panel Replacement - Right Side (Acadia)

Callout	Component Name
1	Push-pin Fasteners (Qty: 2)
2	Insulator/Closeout Panel - Right Procedures Disconnect the electrical connectors. Ensure the tab on the right side of the insulator locks into the carrier assembly securing the insulator to the instrument panel.

Instrument Panel Insulator Panel Replacement - Right Side (Acadia)

Scheme 106

Scheme 106: Instrument Panel Insulator Panel Replacement - Right Side (Enclave)

Callout	Component Name
1	Push-pin Fasteners (Qty: 2)
2	Insulator/Closeout Panel - Right Procedures Disconnect the electrical connectors. Ensure the tab on the right side of the insulator locks into the carrier assembly securing the insulator to the instrument panel.

Instrument Panel Insulator Panel Replacement - Right Side (Enclave)

Scheme 107

Scheme 107: Instrument Panel Insulator Panel Replacement - Right Side (Traverse)

Callout	Component Name
1	Push-pin Fasteners (Qty: 2)
2	Insulator/Closeout Panel - Right Procedures Disconnect the electrical connectors, if applicable. Ensure the tab on the right side of the insulator locks into the carrier assembly securing the insulator to the instrument panel.

Instrument Panel Insulator Panel Replacement - Right Side (Traverse)

Scheme 108

Scheme 108: Instrument Panel Insulator Panel Replacement - Left Side (Acadia)

Callout	Component Name
1	Push-pin Fasteners (Qty: 3)
2	Insulator/Closeout Panel - Left Procedure Disconnect the electrical connectors.

Instrument Panel Insulator Panel Replacement - Left Side (Acadia)

Scheme 109

Scheme 109: Instrument Panel Insulator Panel Replacement - Left Side (Enclave)

Callout	Component Name
1	Push-pin Fasteners (Qty: 3)
2	Insulator/Closeout Panel - Left Procedure Disconnect the electrical connectors.

Instrument Panel Insulator Panel Replacement - Left Side (Enclave)

Scheme 110

Scheme 110: Instrument Panel Insulator Panel Replacement - Left Side (Traverse)

Callout	Component Name
1	Push-pin Fasteners (Qty: 3)
2	Insulator/Closeout Panel - Left Procedure Disconnect the electrical connectors, if applicable.

Instrument Panel Insulator Panel Replacement - Left Side (Traverse)

Scheme 111

Scheme 111: Steering Column Housing Cover Replacement (Traverse)

Callout	Component Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the steering wheel. Refer to Steering Wheel Replacement . Remove the turn signal multifunction switch assembly. Refer to Turn Signal Multifunction Switch Replacement . Remove the turn signal switch bracket. Refer to Turn Signal Switch Bracket Replacement . Remove the instrument panel (I/P) cluster trim plate assembly. Refer to Instrument Panel Cluster Trim Plate Replacement (Traverse) . Remove the instrument panel trim pad. Refer to Instrument Panel Trim Pad Replacement (Traverse) . Remove the driver knee bolster. Refer to Driver Knee Bolster Replacement (Traverse) .
1	Steering Column Housing Cover Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Steering Column Housing Cover Assembly

CAUTION
Refer to Fastener Caution .

Steering Column Housing Cover Replacement (Traverse)

Scheme 112

Scheme 112: Driver Knee Bolster Replacement (Traverse)

Callout	Component Name
1	Driver Knee Bolster Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Driver Knee Bolster Assembly Procedures Disconnect the electrical connections. When replacing the knee bolster, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Driver Knee Bolster Replacement (Traverse)

Scheme 113

Scheme 113: Driver Knee Bolster Replacement (Acadia)

Callout	Component Name
Preliminary Procedure Remove the left instrument panel insulator. Refer to Instrument Panel Insulator Panel Replacement - Left Side (Acadia) .
1	Driver Knee Bolster Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Drivers Knee Bolster Assembly Procedure Disconnect the electrical connections. When replacing the drivers knee bolster, transfer all necessary components.
3	Retainer Clip (Qty: 5)

CAUTION
Refer to Fastener Caution .

Driver Knee Bolster Replacement (Acadia)

Scheme 114

Scheme 114: Driver Knee Bolster Replacement (Enclave)

Callout	Component Name
Preliminary Procedure Remove the hood latch release handle assembly. Refer to Hood Primary Latch Release Cable Handle Replacement .
1	Driver Knee Bolster Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Driver Knee Bolster Assembly Procedures Disconnect the electrical connections. When replacing the knee bolster, transfer all necessary components.
3	Retainer Clip (Qty: 5)

CAUTION
Refer to Fastener Caution .

Driver Knee Bolster Replacement (Enclave)

Scheme 115

Scheme 115: Instrument Panel Trim Plate Replacement - Right Side (Traverse)

Callout	Component Name
Preliminary Procedure Remove the instrument panel accessory trim plate. Refer to Instrument Panel Accessory Trim Plate Replacement (Traverse) .
1	Instrument Panel Trim Plate Assembly Procedure Use a flat bladed plastic trim tool in order to release the retainer clips securing the trim plate to the instrument panel assembly.

Instrument Panel Trim Plate Replacement - Right Side (Traverse)

Scheme 116

Scheme 116: Instrument Panel Trim Plate Replacement - Left Side (Traverse)

Callout	Component Name
1	Instrument Panel Trim Plate Assembly Procedure Use a flat bladed plastic trim tool in order to release the retainer clips securing the trim plate to the instrument panel assembly.

Instrument Panel Trim Plate Replacement - Left Side (Traverse)

Scheme 117

Scheme 117: Instrument Panel Accessory Trim Plate Replacement (Acadia)

Callout	Component Name
1	Accessory Trim Plate Assembly Procedure Use a flat-bladed plastic trim tool in order to release the accessory trim plate from the instrument panel assembly. Disconnect the electrical connections. When replacing the accessory trim plate, transfer all necessary components.
2	Retainer Clip (Qty: 8)

Instrument Panel Accessory Trim Plate Replacement (Acadia)

Scheme 118

Scheme 118: Instrument Panel Accessory Trim Plate Replacement (Enclave)

Callout	Component Name
1	Accessory Trim Plate Assembly Procedures Use a flat bladed plastic trim tool in order to release the accessory trim plate from the instrument panel assembly. Disconnect the electrical connections. When replacing the accessory trim plate, transfer all necessary components.
2	Retainer Clips (Qty: 8)

Instrument Panel Accessory Trim Plate Replacement (Enclave)

Scheme 119

Scheme 119: Instrument Panel Accessory Trim Plate Replacement (Traverse)

Callout	Component Name
1	Instrument Panel Accessory Trim Plate Assembly Procedures Use a flat bladed plastic trim tool in order to release the clips securing the instrument panel accessory trim plate to the instrument panel assembly. Disconnect the electrical connections. When replacing the accessory trim plate, transfer all necessary components.

Instrument Panel Accessory Trim Plate Replacement (Traverse)

Scheme 120

Scheme 120: Instrument Panel Center Trim Panel Replacement (Enclave)

Callout	Component Name
Preliminary Procedure Remove the instrument panel cluster trim plate applique. Refer to Instrument Panel Cluster Trim Plate Applique Replacement (Enclave) .
1	Instrument Panel Trim Panel - Right Procedures Use a plastic flat bladed trim tool in order to release the trim panel from the instrument panel assembly. Disconnect the electrical connections. When replacing the trim panel, transfer all necessary components.
2	Retainer Clips (Qty 10)

Instrument Panel Center Trim Panel Replacement (Enclave)

Scheme 121

Scheme 121: Clock Bezel Replacement (Enclave)

Callout	Component Name
1	Instrumnet Panel Trim Panel - Center Refer to Instrument Panel Center Trim Panel Replacement (Enclave) .
2	Instrument Panel Center Air Outlet Refer to Instrument Panel Center Air Outlet Replacement (Enclave) .
3	Clock Assembly Refer to Clock Replacement (Enclave) .
4	Clock Bezel Procedure Release the tabs on the back of the trim panel and push the clock bezel from the trim panel.

Clock Bezel Replacement (Enclave)

Scheme 122

Scheme 122: Instrument Panel Cluster Trim Plate Cover Replacement (Enclave)

Callout	Component Name
1	Instrument Panel Cluster Trim Plate Cover Procedure Use a flat bladed plastic trim tool in order to release the cluster trim plate cover from the instrument panel assembly.
2	Retainer Clips (Qty 4)

Instrument Panel Cluster Trim Plate Cover Replacement (Enclave)

Scheme 123

Scheme 123: Instrument Panel Cluster Trim Plate Applique Replacement (Enclave)

Callout	Component Name
Preliminary Procedure Remove the instrument panel cluster trim plate cover. Refer to Instrument Panel Cluster Trim Plate Cover Replacement (Enclave) . Remove the left side instrument panel trim panel. Refer to Instrument Panel Trim Panel Replacement - Left Side (Enclave) .
1	Instrument Panel Cluster Trim Plate Applique Screw (Qty 2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Instrument Panel Cluster Trim Plate Applique Assembly
3	Retainer Clip (Qty: 6)

CAUTION
Refer to Fastener Caution .

Instrument Panel Cluster Trim Plate Applique Replacement (Enclave)

Scheme 124

Scheme 124: Instrument Panel Cluster Trim Plate Replacement (Acadia)

Callout	Component Name
Preliminary Procedure Remove the drivers knee bolster. Refer to Driver Knee Bolster Replacement (Acadia) .
1	Instrument Panel Cluster Trim Plate Screw CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Instrument Panel Cluster Trim Plate Assembly
3	Retainer Clip (Qty: 4)

CAUTION
Refer to Fastener Caution .

Instrument Panel Cluster Trim Plate Replacement (Acadia)

Scheme 125

Scheme 125: Instrument Panel Cluster Trim Plate Replacement (Traverse)

Callout	Component Name
Preliminary Procedure Remove the left instrument panel trim plate. Refer to Instrument Panel Trim Plate Replacement - Left Side (Traverse) . Disengage the instrument panel accessory trim plate from the instrument panel assembly. Do not remove completely from vehicle. Refer to Instrument Panel Accessory Trim Plate Replacement (Traverse) .
1	Instrument Panel Cluster Trim Plate Assembly Procedure Use a flat-bladed plastic trim tool in order to release the clips retaining the cluster trim plate to the instrument panel assembly.

Instrument Panel Cluster Trim Plate Replacement (Traverse)

Scheme 126

Scheme 126: Instrument Panel Trim Panel Replacement - Left Side (Enclave)

Callout	Component Name
Preliminary Procedures Remove the left windshield garnish molding. Refer to Windshield Garnish Molding Replacement - Left Side . Remove the instrument panel upper trim panel with windshield defroster nozzle. Refer to Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Enclave) . Remove the left instrument panel outer trim cover. Refer to Instrument Panel Compartment Access Hole Cover Replacement (Enclave) .
1	Instrument Panel Left Trim Panel Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Instrument Panel Left Trim Panel Procedure When replacing the trim panel , transfer all necessary components.
3	Retainer Clip (Qty: 2)

CAUTION
Refer to Fastener Caution .

Instrument Panel Trim Panel Replacement - Left Side (Enclave)

Scheme 127

Scheme 127: Instrument Panel Lower Trim Panel Replacement

Callout	Component Name
Preliminary Procedures Remove the instrument panel upper trim pad. Refer to Instrument Panel Trim Pad Replacement (Traverse) , Instrument Panel Trim Pad Replacement (Acadia w/RPO UV6) , Instrument Panel Trim Pad Replacement (Acadia w/o RPO UV6) , Instrument Panel Trim Pad Replacement (Enclave) . Remove the front floor console. Refer to Front Floor Console Replacement (Enclave) , Front Floor Console Replacement (Acadia) , Front Floor Console Replacement (Traverse) . Remove the steering column assembly. Refer to Steering Column Replacement . Remove the instrument cluster assembly. Refer to Instrument Cluster Replacement (Traverse) , Instrument Cluster Replacement (Enclave) , Instrument Cluster Replacement (Acadia) .
1	Instrument Panel Lower Trim Panel Screw/Bolt (Qty: 26) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	ALDL Screw (Qty: 2) Tighten 2 N.m (18 lb in)
3	Push Pin Fasteners (Qty: 2)
4	Instrument Panel Lower Trim Panel Procedure Prior to removing the lower trim panel from the carrier assembly, note the routing of the wiring harness to ensure proper reinstallation. Disconnect all electrical connections. With the aid of an assistant, remove the trim panel from the vehicle. When replacing the instrument panel lower trim panel, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Instrument Panel Lower Trim Panel Replacement

Scheme 128

Scheme 128: Instrument Panel Center Compartment Replacement (Traverse)

Callout	Component Name
1	Instrument Panel Center Compartment Fastener CAUTION: Refer to Fastener Caution . Procedure Remove the compartment liner in order to access the fastener. Tighten 2 N.m (18 lb in)
2	Instrument Panel Center Compartment Assembly Procedure Use a flat bladed plastic trim tool in order to release the retainer clips securing the instrument panel storage compartment to the instrument panel assembly.

CAUTION
Refer to Fastener Caution .

Instrument Panel Center Compartment Replacement (Traverse)

Scheme 129

Scheme 129: Instrument Panel Center Compartment Replacement (Acadia)

Callout	Component Name
Preliminary Procedure Remove the accessory trim plate. Refer to Instrument Panel Accessory Trim Plate Replacement (Acadia) .
1	Instrument Panel Center Compartment Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Instrument Panel Center Compartment Assembly
3	Retainer Clip (Qty: 2)

CAUTION
Refer to Fastener Caution .

Instrument Panel Center Compartment Replacement (Acadia)

Scheme 130

Scheme 130: Instrument Panel Center Compartment Replacement (Enclave)

Callout	Component Name
1	Instrument Panel Center Compartment Screws Qty: (2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Instrument Panel Center Compartment Assembly Procedure Use a flat-bladed plastic trim tool in order to release the forward edge of the instrument panel storage compartment from the instrument panel.
3	Retainer Clips (Qty: 2)

CAUTION
Refer to Fastener Caution .

Instrument Panel Center Compartment Replacement (Enclave)

Scheme 131

Scheme 131: Instrument Panel Compartment Replacement (Acadia)

Callout

Component Name

Instrument Panel Compartment Retainers (Qty: 2) Procedure Twist the compartment retainers and pull outward to remove.

Instrument Panel Compartment Assembly Procedure Squeeze the sides of the compartment, and open the compartment beyond the stops. Unsnap the instrument panel compartment assembly from the instrument panel. When replacing the instrument panel compartment, transfer all necessary components. When reinstalling the instrument panel compartment assembly ensure the instrument panel compartment dampener arm is aligned properly to the dampener gear assembly.

Instrument Panel Compartment Replacement (Acadia)

Scheme 132

Scheme 132: Instrument Panel Compartment Replacement (Enclave)

Callout	Component Name
1	Instrument Panel Compartment Retainers (Qty: 2) Procedure Twist the compartment retainers and pull outward to remove.
2	Instrument Panel Compartment Assembly Procedure Squeeze the sides of the compartment, and open the compartment beyond the stops. Unsnap the instrument panel compartment assembly from the instrument panel. When reinstalling the instrument panel compartment assembly ensure the instrument panel compartment dampener arm is aligned properly to the dampener gear assembly.

Instrument Panel Compartment Replacement (Enclave)

Scheme 133

Scheme 133: Instrument Panel Compartment Replacement (Traverse)

Callout	Component Name
1	Instrument Panel Compartment Retainers (Qty: 2) Procedure Twist the compartment retainers and pull outward to remove.
2	Instrument Panel Compartment Assembly Procedure Squeeze the sides of the compartment, and open the compartment beyond the stops. Unsnap the instrument panel compartment assembly from the instrument panel. When reinstalling the instrument panel compartment assembly ensure the instrument panel compartment dampener arm is aligned properly to the dampener gear assembly.

Instrument Panel Compartment Replacement (Traverse)

Scheme 134

Scheme 134: Instrument Panel Compartment Trim Plate Replacement (Acadia)

Callout	Component Name
Preliminary Procedure Remove the instrument panel compartment assembly. Refer to Instrument Panel Compartment Replacement (Acadia) .
1	Instrument Panel Compartment Trim Plate Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel compartment trim plate, transfer all necessary components.
2	Retainer Clip (Qty: 4)

Instrument Panel Compartment Trim Plate Replacement (Acadia)

Scheme 135

Scheme 135: Instrument Panel Compartment Trim Plate Replacement (Enclave)

Callout	Component Name
Preliminary Procedure Remove the instrument panel compartment assembly. Refer to Instrument Panel Compartment Replacement (Enclave) .
1	Instrument Panel Compartment Trim Plate Assembly Procedure Disconnect the electrical connections. When replacing the instrument panel compartment trim plate, transfer all necessary components.
2	Retainer Clip (Qty: 4)

Instrument Panel Compartment Trim Plate Replacement (Enclave)

Scheme 136

Scheme 136: Instrument Panel Compartment Trim Plate Replacement (Traverse)

Callout	Component Name
Preliminary Procedure Remove the instrument panel compartment assembly. Refer to Instrument Panel Compartment Replacement (Traverse) . Remove the instrument panel compartment access hole cover. Refer to Instrument Panel Compartment Access Hole Cover Replacement (Traverse) .
1	Instrument Panel Compartment Trim Plate Assembly Procedure Grasp the compartment trim plate and pull rearward releasing the trim plate from the instrument panel assembly. Disconnect the electrical connections, if applicable. When replacing the instrument panel compartment trim plate, transfer all necessary components.

Instrument Panel Compartment Trim Plate Replacement (Traverse)

Scheme 137

Scheme 137: Instrument Panel Compartment Access Hole Cover Replacement (Acadia)

Callout	Component Name
1	Instrument Panel Outer Trim Cover
2	Retainer Clip (Qty: 4)

Instrument Panel Compartment Access Hole Cover Replacement (Acadia)

Scheme 138

Scheme 138: Instrument Panel Compartment Access Hole Cover Replacement (Enclave)

Callout	Component Name
1	Instrument Panel Outer Trim Cover
2	Retainer Clips (Qty: 4)

Instrument Panel Compartment Access Hole Cover Replacement (Enclave)

Scheme 139

Scheme 139: Instrument Panel Compartment Access Hole Cover Replacement (Traverse)

Callout	Component Name
1	Instrument Panel Outer Trim Cover Procedure Use a flat bladed plastic trim tool in order to release the retainer clips securing the instrument panel outer trim cover to the instrument panel.

Instrument Panel Compartment Access Hole Cover Replacement (Traverse)

Removal Procedure

Open the instrument panel compartment door.
Insert the key into the instrument panel compartment door lock cylinder (1).
Lift up on the instrument panel compartment door latch.
Rotate the key clockwise to the locked position.
Use a suitable tool and depress the retaining tumbler through the access hole indicated.
With the retaining tumbler depressed, rotate the lock cylinder (1) clockwise an additional 90° and pull the instrument panel compartment door lock cylinder out of the instrument panel compartment door latch assembly.

Installation Procedure

Insert the key into the instrument panel compartment door lock cylinder (1).
Position the instrument panel compartment door lock cylinder (1) to the compartment door latch with the cylinder in the upside down position.
Insert the instrument panel door lock cylinder (1) upside down fully into the latch assembly.
Rotate the lock cylinder (1) 180° counter clockwise.
An audible click should be heard when the door lock cylinder (1) is being rotated.
Ensure proper operation of the instrument panel compartment door lock.

Scheme 140

Scheme 140: Instrument Panel Compartment Door Dampener Replacement (Acadia)

Callout	Component Name
Preliminary Procedure Remove the instrument panel compartment. Refer to Instrument Panel Compartment Replacement (Acadia) .
1	Instrument Panel Compartment Dampener Assembly Procedure Twist the dampener and pull outward to remove the dampener from the instrument panel assembly. When reinstalling the instrument panel compartment assembly ensure the instrument panel compartment dampener arm is aligned properly to the dampener gear assembly.

Instrument Panel Compartment Door Dampener Replacement (Acadia)

Scheme 141

Scheme 141: Instrument Panel Compartment Door Dampener Replacement (Enclave)

Callout	Component Name
Preliminary Procedure Remove the instrument panel compartment. Refer to Instrument Panel Compartment Replacement (Enclave) .
1	Instrument Panel Compartment Dampener Assembly Procedure Twist the dampener and pull outward to remove the dampener from the instrument panel assembly. When reinstalling the instrument panel compartment assembly ensure the instrument panel compartment dampener arm is aligned properly to the dampener gear assembly.

Instrument Panel Compartment Door Dampener Replacement (Enclave)

Scheme 142

Scheme 142: Instrument Panel Compartment Door Dampener Replacement (Traverse)

Callout	Component Name
Preliminary Procedure Remove the instrument panel compartment. Refer to Instrument Panel Compartment Replacement (Traverse) .
1	Instrument Panel Compartment Dampener Assembly Procedure Twist the dampener and pull outward to remove the dampener from the instrument panel assembly. When reinstalling the instrument panel compartment assembly ensure the instrument panel compartment dampener arm is aligned properly to the dampener gear assembly.

Instrument Panel Compartment Door Dampener Replacement (Traverse)

Scheme 143

Scheme 143: Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Acadia w/RPO

Callout	Component Name
Preliminary Procedure Remove the windshield garnish moldings. Refer to Windshield Garnish Molding Replacement - Left Side , and Windshield Garnish Molding Replacement - Right Side .
1	Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Procedure Use a flat-bladed plastic trim tool in order to release the upper trim panel from the instrument panel assembly. Disconnect the electrical connections. When replacing the upper trim plate, transfer all necessary components.
2	Retainer Clip (Qty: 10)

Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Acadia w/RPO UV6)

Scheme 144

Scheme 144: Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Acadia w/o RP

Callout	Component Name
Preliminary Procedure Remove the windshield garnish moldings. Refer to Windshield Garnish Molding Replacement - Left Side , and Windshield Garnish Molding Replacement - Right Side .
1	Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Procedure Use a flat-bladed plastic trim tool in order to release the upper trim panel from the instrument panel assembly. Disconnect the electrical connections. When replacing the upper trim plate, transfer all necessary components.
2	Retainer Clip (Qty: 10)

Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Acadia w/o RPO UV6)

Scheme 145

Scheme 145: Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Enclave)

Callout	Component Name
Preliminary Procedure Remove the windshield garnish moldings. Refer to Windshield Garnish Molding Replacement - Left Side , and Windshield Garnish Molding Replacement - Right Side .
1	Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Procedures Use a flat bladed plastic trim tool in order to release the upper trim panel from the instrument panel assembly. Disconnect the electrical connections. When replacing the upper trim plate, transfer all necessary components.
2	Retainer Clips (Qty: 11)

Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Enclave)

Scheme 146

Scheme 146: Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Traverse)

Callout	Component Name
Preliminary Procedure Remove the windshield garnish moldings. Refer to Windshield Garnish Molding Replacement - Left Side , and Windshield Garnish Molding Replacement - Right Side .
1	Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Procedures Use a flat bladed plastic trim tool in order to release the upper trim panel from the instrument panel assembly. Disconnect the electrical connections. When replacing the upper trim plate, transfer all necessary components.

Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Traverse)

Scheme 147

Scheme 147: Instrument Panel Trim Pad Replacement (Traverse)

Callout	Component Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the instrument panel upper trim panel with defroster nozzle. Refer to Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Traverse) . Remove the instrument panel outer trim covers. Refer to Instrument Panel Compartment Access Hole Cover Replacement (Traverse) . Remove the right and left instrument panel trim plates. Refer to Instrument Panel Trim Plate Replacement - Right Side (Traverse) , and Instrument Panel Trim Plate Replacement - Left Side (Traverse) . Remove the instrument panel compartment trim panel. Refer to Instrument Panel Compartment Trim Plate Replacement (Traverse) . Remove the instrument panel cluster. Refer to Instrument Cluster Replacement (Traverse) . Remove the radio. Refer to Radio Replacement . Remove the radio front speaker. Refer to Radio Front Speaker Replacement .
1	Instrument Panel Trim Pad Screw (Qty: 25) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Instrument Panel Inflatable Restraint Fasteners (Qty: 2) Tighten 10 N.m (89 lb in)
3	Instrument Panel Trim Pad Assembly Procedure Prior to removing the trim pad from the instrument panel assembly, note the routing of the wiring to ensure proper reinstallation. Disconnect all electrical connections. With the aid of an assistant, remove the trim panel from the vehicle. When replacing the instrument panel trim pad, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Instrument Panel Trim Pad Replacement (Traverse)

Scheme 148

Scheme 148: Instrument Panel Trim Pad Replacement (Acadia w/RPO UV6)

Callout	Component Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the instrument panel heads up display module. Refer to Head-Up Display Replacement . Remove the instrument panel outer trim covers. Refer to Instrument Panel Compartment Access Hole Cover Replacement (Acadia) . Remove the instrument panel cluster. Refer to Instrument Cluster Replacement (Acadia) . Remove the radio. Refer to Radio Replacement . Remove the radio front speaker. Refer to Radio Front Speaker Replacement . Remove the instrument panel compartment trim panel. Refer to Instrument Panel Compartment Trim Plate Replacement (Acadia) .
1	Instrument Panel Inflatable Restraint Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
2	Instrument Panel Trim Pad Bolt (Qty: 4) Tighten 2 N.m (18 lb in)
3	Instrument Panel Trim Pad Screw (Qty: 22) Tighten 2 N.m (18 lb in)
4	Instrument Panel Trim Pad Assembly Procedure Prior to removing the trim pad from the instrument panel assembly, note the routing of the wiring to ensure proper reinstallation. Disconnect all electrical connections. With the aid of an assistant, remove the trim panel from the vehicle. When replacing the instrument panel trim pad, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Instrument Panel Trim Pad Replacement (Acadia w/RPO UV6)

Scheme 149

Scheme 149: Instrument Panel Trim Pad Replacement (Acadia w/o RPO UV6)

Callout	Component Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the instrument panel upper trim panel with defroster nozzle. Refer to Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Acadia w/o RPO UV6) . Remove the instrument panel outer trim covers. Refer to Instrument Panel Compartment Access Hole Cover Replacement (Acadia) . Remove the instrument panel cluster trim plate . Refer to Instrument Panel Cluster Trim Plate Replacement (Acadia) . Remove the radio. Refer to Radio Replacement . Remove the radio front speaker. Refer to Radio Front Speaker Replacement . Remove the instrument panel compartment trim panel. Refer to Instrument Panel Compartment Trim Plate Replacement (Acadia) .
1	Instrument Panel Inflatable Restraint Bolt (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
2	Instrument Panel Trim Pad Screw (Qty: 22) Tighten 2 N.m (18 lb in)
3	Instrument Panel Trim Pad Assembly Procedure Prior to removing the trim pad from the instrument panel assembly, note the routing of the wiring to ensure proper reinstallation. Disconnect all electrical connections. With the aid of an assistant, remove the trim panel from the vehicle. When replacing the instrument panel trim pad, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Instrument Panel Trim Pad Replacement (Acadia w/o RPO UV6)

Instrument Panel Trim Pad Replacement (Enclave)

Callout	Component Name
Preliminary Procedures Disable the SIR system. Refer to SIR Disabling and Enabling . Remove the instrument panel upper trim panel with defroster nozzle. Refer to Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement (Enclave) . Remove the instrument panel outer trim covers. Refer to Instrument Panel Compartment Access Hole Cover Replacement (Enclave) . Remove the instrument panel compartment trim panel. Refer to Instrument Panel Compartment Trim Plate Replacement (Enclave) . Remove the instrument panel cluster trim plate applique. Refer to Instrument Panel Cluster Trim Plate Applique Replacement (Enclave) . Remove the radio. Refer to Radio Replacement . Remove the radio front speaker. Refer to Radio Front Speaker Replacement . Disconnect the instrument panel inflatable restraint module electrical connector located at or near the right A pillar.
1	Instrument Panel Trim Pad Screw (Qty: 25) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Instrument Panel Inflatable Restraint Fasteners (Qty: 2) Tighten 10 N.m (89 lb in)
3	Instrument Panel Trim Pad Assembly Procedure Prior to removing the trim pad from the instrument panel assembly, note the routing of the wiring to ensure proper reinstallation. Disconnect all electrical connections. With the aid of an assistant, remove the trim panel from the vehicle. When replacing the instrument panel trim pad, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Instrument Panel Trim Pad Replacement (Enclave)

Scheme 150

Scheme 150: Instrument Panel Carrier Replacement

Callout	Component Name
Preliminary Procedures Remove the instrument panel lower trim panel. Refer to Instrument Panel Lower Trim Panel Replacement . Remove the windshield defroster duct. Refer to Windshield Defroster Duct Replacement . Remove the right window air outlet duct. Refer to Side Window Defogger Outlet Duct Replacement - Right Side .
1	Left Window Air Outlet Screw (Qty: 1) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Carrier Assembly Upper Bolt (Qty: 4) Tighten 9 N.m (80 lb in)
3	Carrier Assembly Lower Bolt (Qty: 2) Tighten 9 N.m (80 lb in)
4	Carrier Assembly to Body Bolt (Qty: 4) Tighten 9 N.m (80 lb in)
5	Carrier Assembly Procedure Prior to removing the carrier assembly, note the routing of the wiring to ensure proper reinstallation. Disconnect all electrical connections. Remove the fasteners securing the HVAC module assembly to the carrier assembly. Refer to Air Conditioning and Heater Module Assembly Removal and Installation . Prior to removing the carrier assembly, support the HVAC module. With the aid of an assistant, remove the carrier assembly from the vehicle. When replacing the carrier assembly, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Instrument Panel Carrier Replacement

Scheme 151

Scheme 151: Front Floor Console Filler Replacement

Callout	Component Name
Preliminary Procedures Remove the right or left front floor console extension panel. Refer to Front Floor Console Extension Panel Replacement - Right Side (Enclave) , Front Floor Console Extension Panel Replacement - Right Side (Traverse) , Front Floor Console Extension Panel Replacement - Right Side (Acadia) , or Front Floor Console Extension Panel Replacement - Left Side (Enclave) , Front Floor Console Extension Panel Replacement - Left Side (Traverse) , Front Floor Console Extension Panel Replacement - Left Side (Acadia) . Remove the front floor console rear trim plate. Refer to Front Floor Console Rear Trim Panel Replacement .
1	Front Floor Console Filler Screw (Qty: 1) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Front Floor Console Filler Panel
3	Retainer Clip (Qty: 4)

CAUTION
Refer to Fastener Caution .

Front Floor Console Filler Replacement

Scheme 152

Scheme 152: Front Floor Console Rear Compartment Door Replacement

Callout	Component Name
Preliminary Procedure Remove the front floor console cover. Refer to Front Floor Console Cover Replacement .
1	Front Floor Console Compartment Door Procedure Slide the compartment door out of the compartment door track.

Front Floor Console Rear Compartment Door Replacement

Scheme 153

Scheme 153: Front Floor Console Cover Replacement

Callout	Component Name
Preliminary Procedures Remove the front floor console. Refer to Front Floor Console Replacement (Enclave) , Front Floor Console Replacement (Acadia) , Front Floor Console Replacement (Traverse) . Remove the front floor console accessory housing. Refer to Front Floor Console Accessory Housing Replacement (Acadia) , Front Floor Console Accessory Housing Replacement (Enclave) , Front Floor Console Accessory Housing Replacement (Traverse) . Remove the front floor console cover. Refer to Front Floor Rear Console Front Cover Replacement .
1	Console Trim Plate Screws (Qty: 7) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Console Trim Plate

CAUTION
Refer to Fastener Caution .

Front Floor Console Cover Replacement

Scheme 154

Scheme 154: Front Floor Console Accessory Trim Plate Applique Replacement

Callout	Component Name
1	Front Floor Console Bezel Procedure Use a flat-bladed plastic trim tool in order to release the front floor console bezel from the console assembly.
2	Retainer Clip (Qty: 2)

Front Floor Console Accessory Trim Plate Applique Replacement

Scheme 155

Scheme 155: Front Floor Console Accessory Trim Plate Replacement (Acadia)

Callout	Component Name
1	Front Floor Console Accessory Trim Plate Assembly TIP: Use a flat-bladed plastic trim tool in order to release the console accessory trim plate from the console assembly.
2	Retainer Clip (Qty: 8)

Front Floor Console Accessory Trim Plate Replacement (Acadia)

Scheme 156

Scheme 156: Front Floor Console Accessory Trim Plate Replacement (Enclave)

Callout	Component Name
1	Front Floor Console Accessory Trim Plate Assembly Procedure Use a flat bladed plastic trim tool in order to release the console accessory trim plate from the console assembly.
2	Retainer Clips (Qty: 5)

Front Floor Console Accessory Trim Plate Replacement (Enclave)

Scheme 157

Scheme 157: Front Floor Console Accessory Trim Plate Replacement (Traverse)

Callout	Component Name
1	Front Floor Console Accessory Trim Plate Assembly Procedure Starting along the rear edge of the trim plate, use a flat bladed plastic trim tool in order to release the retainer clips securing the console accessory trim plate to the console assembly.

Front Floor Console Accessory Trim Plate Replacement (Traverse)

Scheme 158

Scheme 158: Front Floor Console Accessory Housing Replacement (Traverse)

Callout	Component Name
Preliminary Procedure Remove the front floor console accessory trim plate. Refer to Front Floor Console Accessory Trim Plate Replacement (Traverse) .
1	Front Floor Console Accessory Housing Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Front Floor Console Accessory Housing Assembly Procedure Move the shiftier into low gear in order to create enough clearance to remove the housing assembly. Disconnect the electrical connectors. When replacing the front floor console accessory housing assembly, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Front Floor Console Accessory Housing Replacement (Traverse)

Scheme 159

Scheme 159: Front Floor Console Accessory Housing Replacement (Acadia)

Callout	Component Name
Preliminary Procedure Remove the front floor console accessory trim plate. Refer to Front Floor Console Accessory Trim Plate Replacement (Acadia) .
1	Front Floor Console Accessory Housing Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Front Floor Console Accessory Housing Assembly Procedure Disconnect the electrical connectors. When replacing the front floor console accessory switch housing assembly, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Front Floor Console Accessory Housing Replacement (Acadia)

Scheme 160

Scheme 160: Front Floor Console Accessory Housing Replacement (Enclave)

Callout	Component Name
Preliminary Procedure Remove the front floor console accessory trim plate. Refer to Front Floor Console Accessory Trim Plate Replacement (Enclave) .
1	Front Floor Console Accessory Housing Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Front Floor Console Accessory Housing Assembly Procedure Disconnect the electrical connectors. When replacing the front floor console accessory housing assembly, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Front Floor Console Accessory Housing Replacement (Enclave)

Scheme 161

Scheme 161: Front Floor Console Rear Trim Panel Replacement

Callout	Component Name
Preliminary Procedure Remove the floor console accessory trim plate applique. Refer to Front Floor Console Accessory Trim Plate Applique Replacement .
1	Front Floor Console Rear Trim Plate Procedure Disconnect the electrical connections. When replacing the front floor console rear trim plate, transfer all necessary components.
2	Retainer Clip (Qty: 4)

Front Floor Console Rear Trim Panel Replacement

Scheme 162

Scheme 162: Front Floor Console Extension Panel Replacement - Right Side (Acadia)

Callout	Component Name
Preliminary Procedure Remove the right front seat . Refer to Bucket Seat Replacement .
1	Front Floor Console Extension Panel CAUTION: Failure to remove the respective front seats will result in damage to the front floor console extension panel.
2	Retainer Clip (Qty: 6)

CAUTION
Failure to remove the respective front seats will result in damage to the front floor console extension panel.

Front Floor Console Extension Panel Replacement - Right Side (Acadia)

Scheme 163

Scheme 163: Front Floor Console Extension Panel Replacement - Right Side (Enclave)

Callout	Component Name
Preliminary Procedure Remove the right front seat. Refer to Bucket Seat Replacement .
1	Front Floor Console Extension Panel CAUTION: Failure to remove the respective front seats will result in damage to the front floor console extension panel.
2	Retainer Clip (Qty: 5)

CAUTION
Failure to remove the respective front seats will result in damage to the front floor console extension panel.

Front Floor Console Extension Panel Replacement - Right Side (Enclave)

Scheme 164

Scheme 164: Front Floor Console Extension Panel Replacement - Right Side (Traverse)

Callout	Component Name
Preliminary Procedure Remove the right front seat. Refer to Bucket Seat Replacement .
1	Front Floor Console Extension Panel CAUTION: Failure to remove the respective front seats will result in damage to the front floor console extension panel. Procedure Grasp the front floor console extension panel and pull outward releasing the clips securing the extension panel to the console assembly.

CAUTION
Failure to remove the respective front seats will result in damage to the front floor console extension panel.

Front Floor Console Extension Panel Replacement - Right Side (Traverse)

Scheme 165

Scheme 165: Front Floor Console Extension Panel Replacement - Left Side (Acadia)

Callout	Component Name
Preliminary Procedure Remove the left front seat . Refer to Bucket Seat Replacement .
1	Front Floor Console Extension Panel. CAUTION: Failure to remove the respective front seats will result in damage to the front floor console extension panel.
2	Retainer Clips (Qty: 6).

CAUTION
Failure to remove the respective front seats will result in damage to the front floor console extension panel.

Front Floor Console Extension Panel Replacement - Left Side (Acadia)

Scheme 166

Scheme 166: Front Floor Console Extension Panel Replacement - Left Side (Enclave)

Callout	Component Name
Preliminary Procedure Remove the left front seat . Refer to Bucket Seat Replacement .
1	Front Floor Console Extension Panel CAUTION: Failure to remove the respective front seats will result in damage to the front floor console extension panel.
2	Retainer Clip (Qty: 5)

CAUTION
Failure to remove the respective front seats will result in damage to the front floor console extension panel.

Front Floor Console Extension Panel Replacement - Left Side (Enclave)

Scheme 167

Scheme 167: Front Floor Console Extension Panel Replacement - Left Side (Traverse)

Callout	Component Name
Preliminary Procedure Remove the left front seat . Refer to Bucket Seat Replacement .
1	Front Floor Console Extension Panel CAUTION: Failure to remove the respective front seats will result in damage to the front floor console extension panel. Procedure Grasp the front floor console extension panel and pull outward releasing the clips securing the extension panel to the console assembly.

CAUTION
Failure to remove the respective front seats will result in damage to the front floor console extension panel.

Front Floor Console Extension Panel Replacement - Left Side (Traverse)

Scheme 168

Scheme 168: Front Floor Console Extension Accessory Upper Bezel Replacement

Callout	Component Name
Preliminary Procedure Remove the front floor console armrest bin assembly. Refer to Front Floor Console Armrest Compartment Replacement .
1	Front Floor Console Extension Accessory Upper Bezel Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Front Floor Console Extension Accessory Upper Bezel Procedure Disconnect the electrical connections.

CAUTION
Refer to Fastener Caution .

Front Floor Console Extension Accessory Upper Bezel Replacement

Scheme 169

Scheme 169: Front Floor Console Compartment Replacement

Callout	Component Name
1	Front Floor Console Carrier Refer to Front Floor Console Carrier Replacement .
2	Front Floor Console Compartment Fasteners (Qty: 4) CAUTION: Refer to Fastener Caution .
3	Front Floor Console Compartment Assembly

CAUTION
Refer to Fastener Caution .

Front Floor Console Compartment Replacement

Scheme 170

Scheme 170: Front Floor Console Replacement (Traverse)

Callout	Component Name
Preliminary Procedures Remove the front floor console accessory housing. Refer to Front Floor Console Accessory Housing Replacement (Traverse) . Remove the front floor console accessory trim plate. Refer to Front Floor Console Accessory Trim Plate Replacement (Traverse) . Remove the right and left front floor console extension panels. Refer to Front Floor Console Extension Panel Replacement - Right Side (Traverse) Front Floor Console Extension Panel Replacement - Left Side (Traverse) . Disconnect the automatic transmission range selector lever cable. Refer to Range Selector Lever Cable Replacement .
1	Front Floor Console Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Procedure Remove the fastener covers in order to access the fasteners. Tighten 2 N.m (18 lb in)
2	Front Floor Console Bolt (Qty: 10) TIP: Before installing the right lower forward bolt, ensure that the console wiring harness is tucked below the fastener location to avoid driving the bolt into the harness. Tighten 9 N.m (80 lb in)
3	Front Floor Console Assembly Procedure Note location and routing of the front floor console wiring harness prior to removal of the front floor console assembly to ensure proper reinstallation. Disconnect the electrical connectors. With the aid of an assistant remove the console assembly from the vehicle. When replacing the front floor console, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Front Floor Console Replacement (Traverse)

Scheme 171

Scheme 171: Front Floor Console Replacement (Acadia)

Callout	Component Name
Preliminary Procedures Remove the front floor console accessory trim plate. Refer to Front Floor Console Accessory Trim Plate Replacement (Acadia) . Remove the right and left front floor console extension panels. Refer to Front Floor Console Extension Panel Replacement - Right Side (Acadia) , and Front Floor Console Extension Panel Replacement - Left Side (Acadia) . Disconnect the automatic transmission range selector lever cable. Refer to Range Selector Lever Cable Replacement .
1	Front Floor Console Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Front Floor Console Bolt (Qty: 10) TIP: Before installing the right lower forward bolt, ensure that the console wiring harness is tucked below the fastener location to avoid driving the bolt into the harness. Tighten 9 N.m (80 lb in)
3	Front Floor Console Assembly Procedure Note location and routing of the front floor console wiring harness prior to removal of the front floor console assembly to ensure proper reinstallation. Disconnect the electrical connectors. With the aid of an assistant, remove the console assembly from the vehicle. When replacing the front floor console, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Front Floor Console Replacement (Acadia)

Scheme 172

Scheme 172: Front Floor Console Replacement (Enclave)

Callout	Component Name
Preliminary Procedures Remove the front floor console accessory trim plate. Refer to Front Floor Console Accessory Trim Plate Replacement (Enclave) . Remove the right and left front floor console extension panels. Refer to Front Floor Console Extension Panel Replacement - Right Side (Enclave) , and Front Floor Console Extension Panel Replacement - Left Side (Enclave) . Disconnect the automatic transmission range selector lever cable. Refer to Range Selector Lever Cable Replacement .
1	Front Floor Console Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Front Floor Console Bolt (Qty: 10) TIP: Before installing the right lower forward bolt, ensure that the console wiring harness is tucked below the fastener location to avoid driving the bolt into the harness. Tighten 9 N.m (80 lb in)
3	Front Floor Console Assembly Procedure Note location and routing of the front floor console wiring harness prior to removal of the front floor console assembly to ensure proper reinstallation. Disconnect the electrical connectors. With the aid of an assistant remove the console assembly from the vehicle. When replacing the front floor console, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Front Floor Console Replacement (Enclave)

Scheme 173

Scheme 173: Front Floor Console Carrier Replacement

Callout	Component Name
Preliminary Procedure Remove the front floor console assembly from the vehicle. Refer to Front Floor Console Replacement (Enclave) , Front Floor Console Replacement (Acadia) , Front Floor Console Replacement (Traverse) .
1	Front Floor Console Cover Refer to Front Floor Console Cover Replacement .
2	Transmission Control Assembly Refer to Transmission Control Replacement (Acadia) .
3	Front Floor Console Rear Compartment Door Refer to Front Floor Console Rear Compartment Door Replacement .
4	Front Floor Console Carrier Assembly

Front Floor Console Carrier Replacement

Scheme 174

Scheme 174: Rear Floor Console Replacement

Callout	Component Name
Preliminary Procedure Remove the rear seat track covers. Refer to Rear Seat Track Front Inboard Cover, Front Outboard Cover, Rear Inboard Cover, and Rear Outboard Cover Replacement .
1	Rear Floor Console Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 45 N.m (33 lb ft)
2	Rear Floor Console Assembly Procedure Disconnect the electrical connections. When replacing the rear floor console assembly, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Rear Floor Console Replacement

Scheme 175

Scheme 175: Rear Floor Console Release Latch Replacement

Callout	Component Name
Preliminary Procedure Remove the rear floor console front upper trim panel assembly . Refer to Rear Floor Console Front Trim Upper Panel Replacement .
1	Rear Floor Console Rear Release Latch Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Rear Floor Console Release Latch Assembly

CAUTION
Refer to Fastener Caution .

Rear Floor Console Release Latch Replacement

Scheme 176

Scheme 176: Rear Floor Console Cover Replacement

Callout	Component Name
1	Rear Floor Console Cover Assembly Procedure Grasp the cover assembly and pull upward and rearward disengaging the clips retaining the cover to the console assembly.

Rear Floor Console Cover Replacement

Scheme 177

Scheme 177: Rear Floor Console Rear Trim Lower Panel Replacement

Callout	Component Name
1	Rear Floor Console Rear Trim Cover Lower Panel Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Rear Floor Console Rear Trim Lower Panel Assembly Procedure Disconnect the electrical connections. When replacing the rear floor console rear trim lower panel assembly, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Rear Floor Console Rear Trim Lower Panel Replacement

Scheme 178

Scheme 178: Rear Floor Console Cup Holder Bezel Replacement

Callout	Component Name
1	Rear Floor Console Cupholder Bezel Assembly Procedure Use a flat bladed plastic trim tool in order to release the clips securing the bezel to the console assembly.

Rear Floor Console Cup Holder Bezel Replacement

Scheme 179

Scheme 179: Rear Floor Console Cup Holder Trim Upper Panel Replacement

Callout	Component Name
1	Rear Floor Console Cupholder Trim Upper Panel Assembly Procedure Use a flat bladed plastic trim tool in order to release the clips securing the trim panel to the console assembly.

Rear Floor Console Cup Holder Trim Upper Panel Replacement

Scheme 180

Scheme 180: Rear Floor Console Front Trim Panel Replacement

Callout	Component Name
1	Rear Floor Console Front Trim Panel Assembly Procedure Use a flat bladed plastic trim tool in order to release the clips securing the trim panel to the console assembly.

Rear Floor Console Front Trim Panel Replacement

Scheme 181

Scheme 181: Rear Floor Console Front Trim Upper Panel Replacement

Callout	Component Name
Preliminary Procedures Remove the rear floor console cupholder bezel assembly. Refer to Rear Floor Console Cup Holder Bezel Replacement . Remove the rear floor console cupholder trim upper panel assembly. Refer to Rear Floor Console Cup Holder Trim Upper Panel Replacement . Remove the rear floor console latch cover. Refer to Rear Floor Console Latch Cover Replacement .
1	Rear Floor Console Front Trim Upper Panel Screw (Qty: 3) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Rear Floor Console Front Trim Upper Panel Assembly Procedure Use a flat-bladed plastic trim tool in order to release the clips securing the trim panel to the console assembly.

CAUTION
Refer to Fastener Caution .

Rear Floor Console Front Trim Upper Panel Replacement

Scheme 182

Scheme 182: Rear Floor Console Latch Cover Replacement

Callout	Component Name
1	Rear Floor Console Latch Cover Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Rear Floor Console Latch Cover

CAUTION
Refer to Fastener Caution .

Rear Floor Console Latch Cover Replacement

Scheme 183

Scheme 183: Rear Floor Console Rear Release Latch Replacement

Callout	Component Name
1	Rear Floor Console Lid Trim Cover Screw (Qty: 14) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Rear Floor Console Lid Trim Cover
3	Rear Floor Console Lid Latch Screw (Qty: 2) Tighten 2.5 N.m (22 lb in)
4	Rear Floor Console Lid Latch Assembly

CAUTION
Refer to Fastener Caution .

Rear Floor Console Rear Release Latch Replacement

Scheme 184

Scheme 184: Rear Floor Console Side Trim Panel Replacement - Right Side

Callout	Component Name
Preliminary Procedures Remove the rear floor console rear trim lower panel Assembly. Refer to Rear Floor Console Rear Trim Lower Panel Replacement . Remove the rear floor console front trim panel assembly - Lower. Refer to Rear Floor Console Front Trim Panel Replacement . Remove the rear floor console front trim upper panel assembly. Refer to Rear Floor Console Front Trim Upper Panel Replacement .
1	Rear Floor Console Side Trim Panel Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Rear Floor Console Side Trim Panel Assembly Procedure Grasp the trim panel and pull outward in order to release the clips securing the side trim panel to the console assembly.

CAUTION
Refer to Fastener Caution .

Rear Floor Console Side Trim Panel Replacement - Right Side

Scheme 185

Scheme 185: Rear Floor Console Side Trim Panel Replacement - Left Side

Callout	Component Name
Preliminary Procedures Remove the rear floor console rear trim lower panel Assembly. Refer to Rear Floor Console Rear Trim Lower Panel Replacement . Remove the rear floor console front trim panel assembly - Lower. Refer to Rear Floor Console Front Trim Panel Replacement . Remove the rear floor console front trim upper panel assembly. Refer to Rear Floor Console Front Trim Upper Panel Replacement .
1	Rear Floor Console Side Trim Panel Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Rear Floor Console Side Trim Panel Assembly Procedure Grasp the trim panel and pull outward in order to release the clips securing the side trim panel to the console assembly.

CAUTION
Refer to Fastener Caution .

Rear Floor Console Side Trim Panel Replacement - Left Side

Scheme 186

Scheme 186: Rear Floor Console Armrest Replacement

Callout	Component Name
1	Rear Floor Console Hinge Cover Closeout Screw (Qty: 12) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Rear Floor Console Hinge Cover Closeout Panel
3	Rear Floor Console Armrest Hinge Screw (Qty: 4) Tighten 2.5 N.m (22 lb in)
4	Rear Floor Console Armrest Assembly Procedure When replacing the rear floor console armrest assembly, transfer all necessary components.

CAUTION
Refer to Fastener Caution .

Rear Floor Console Armrest Replacement

Scheme 187

Scheme 187: Rear Floor Console Armrest Latch Replacement

Callout	Component Name
1	Rear Floor Console Hinge Cover Closeout Screw (Qty: 12) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Rear Floor Console Hinge Cover Closeout Panel
3	Rear Floor Console Armrest Latch Screw (Qty: 4) Tighten 2.5 N.m (22 lb in)
4	Rear Floor Console Armrest Latch Assembly

CAUTION
Refer to Fastener Caution .

Rear Floor Console Armrest Latch Replacement

Scheme 188

Scheme 188: Rear Floor Console Rear Trim Upper Panel Replacement

Callout	Component Name
1	Rear Floor Console Rear Trim Upper Panel Screw (Qty: 2) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Rear Floor Console Rear Trim Upper Panel Screw (Qty: 2) Tighten 2.5 N.m (22 lb in)
3	Rear Floor Console Rear Trim Upper Panel Assembly Procedure Use a flat-bladed plastic trim tool in order to release the clips securing the trim panel to the console assembly.

CAUTION
Refer to Fastener Caution .

Rear Floor Console Rear Trim Upper Panel Replacement

Scheme 189

Scheme 189: Rear Floor Console Stowage Tray Replacement

Callout	Component Name
Preliminary Procedures Remove the rear floor console right side trim panel. Refer to Rear Floor Console Side Trim Panel Replacement - Right Side . Remove the rear floor console left side trim panel. Refer to Rear Floor Console Side Trim Panel Replacement - Left Side .
1	Rear Floor Console Lid Trim Cover Screw (Qty: 14) CAUTION: Refer to Fastener Caution . Tighten 2.5 N.m (22 lb in)
2	Rear Floor Console Lid Trim Cover
3	Rear Floor Console Storage Lower Tray Screw (Qty: 4) Tighten 2.5 N.m (22 lb in)
4	Rear Floor Console Storage Lower Tray Screw (Qty: 4) Tighten 2.5 N.m (22 lb in)
5	Rear Floor Console Storage Lower Tray Assembly

CAUTION
Refer to Fastener Caution .

Rear Floor Console Stowage Tray Replacement

Scheme 190

Scheme 190: Front Floor Console Armrest Latch Replacement

Callout	Component Name
Preliminary Procedure Remove the front floor console armrest compartment. Refer to Front Floor Console Armrest Compartment Replacement .
1	Front Floor Console Armrest Latch Screw (Qty: 1) CAUTION: Refer to Fastener Caution . Tighten 2.5Y(22 lb in)
2	Front Floor Console Armrest Latch Assembly Procedure Ensure the rubber bumper on the end of the front floor console armrest latch is fully seated into the opening in the armrest assembly.

CAUTION
Refer to Fastener Caution .

Front Floor Console Armrest Latch Replacement

Scheme 191

Scheme 191: Front Floor Console Outer Armrest Replacement

Callout	Component Name
1	Front Floor Console Armrest Screw Cover
2	Front Floor Console Armrest Screw (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
3	Front Floor Console Armrest Assembly

CAUTION
Refer to Fastener Caution .

Front Floor Console Outer Armrest Replacement

Scheme 192

Scheme 192: Front Floor Console Armrest with Support Replacement

Callout	Component Name
Preliminary Procedures Remove the front floor console filler. Refer to Front Floor Console Filler Replacement . Remove the front floor console extension accessory upper bezel. Refer to Front Floor Console Extension Accessory Upper Bezel Replacement .
1	Front Floor Console Armrest Assembly with Supports Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
2	Front Floor Console Armrest Assembly with Supports

CAUTION
Refer to Fastener Caution .

Front Floor Console Armrest with Support Replacement

Scheme 193

Scheme 193: Front Floor Console Armrest Compartment Replacement

Callout	Component Name
Preliminary Procedure Remove the front floor console armrest assembly. Refer to Front Floor Console Outer Armrest Replacement .
1	Front Floor Console Armrest Bin Screw (Qty: 6) CAUTION: Refer to Fastener Caution . Tighten 2 N.m (18 lb in)
2	Front Floor Console Armrest Bin Assembly

CAUTION
Refer to Fastener Caution .

Front Floor Console Armrest Compartment Replacement

Scheme 194

Scheme 194: Front Floor Rear Console Front Cover Replacement

Callout	Component Name
Preliminary Procedures Remove the front floor console accessory trim plate. Refer to Front Floor Console Accessory Trim Plate Replacement (Enclave) , Front Floor Console Accessory Trim Plate Replacement (Acadia) , Front Floor Console Accessory Trim Plate Replacement (Traverse) . Remove the right and left front floor console fillers. Refer to Front Floor Console Filler Replacement .
1	Front Floor Console Armrest Assembly Bolt (Qty: 4) CAUTION: Refer to Fastener Caution . Tighten 9 N.m (80 lb in)
2	Front Floor Console Armrest Assembly Procedure Position the armrest assembly out of the way leaving the electrical harness attached.
3	Front Floor Upper Console Trim Plate Procedure Lift the rear of the trim plate first, releasing the retainers securing the trip plate to the console assembly.
4	Retainer Clips (Qty: 4)

CAUTION
Refer to Fastener Caution .

Front Floor Rear Console Front Cover Replacement

Scheme 195

Scheme 195: Roof Console Replacement

Callout	Component Name
1	Roof Console Assembly Procedure Use a flat-bladed tool on the bezel to release the tabs and gently pull down to remove the roof console. Disconnect the electrical connectors. If replacing the roof console assembly, transfer all necessary components. Uplevel console shown, all others similar and are removed in the same manner.
2	Roof Console Retainer (Qty: 6)

Roof Console Replacement

Scheme 196

Scheme 196: Roof Rear Console Replacement

Callout	Component Name
Preliminary Procedure Remove the video display assembly. Refer to Video Display Replacement (U42/C3U) , Video Display Replacement (U42) .
1	Roof Console Assembly Procedure Pull down to disengage the retainer clips. Disconnect the electrical connectors. If replacing the rear roof console, transfer all necessary components.
2	Roof Console Retainer (Qty: 4)

Roof Rear Console Replacement

Instrument Panel Trim and Console Trim Buick Enclave I

Fastener Tightening Specifications

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Removal Procedure

Installation Procedure

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Instrument Panel Trim Pad Replacement (Enclave)

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179
