Interior Trim Buick Century VI

Specifications

Fastener Tightening Specification Table

Eliminating Unwanted Odors in Vehicles

GM Vehicle Care Odor Eliminator, GM P/N 12378554, US ACDelco 88900909, Canadian P/N 88901678, may control or eliminate odors in the interior and luggage compartment areas of GM vehicles. This non-toxic, biodegradable, odorless product has been shown to greatly reduce or remove the following types of odor

1. Objectionable smells of mold and mildew resulting from vehicle water leaks
2. Customer created odors, such as smoke

You may safely use GM Vehicle Care Odor Eliminator on fabrics, vinyl, leather, carpet, and sound deadening materials. You may also induce this product into HVAC modules and instrument panel ducts for the control of non-bacterial related odors.

This product may result in the permanent elimination of an odor and may be preferable to customers whose allergies make them sensitive to perfumes.

This product may effectively remove odors when directly contacting the odor source. In cases such as water leaks, use this product with diagnostic procedures to first eliminate the primary cause of the odor. Then use further applications on the residual odor to permanently correct the vehicle condition.

How to Use this Product

1. Spray GM Vehicle Care Odor Eliminator directly or as an additive with carpet shampoo in steam cleaners.
2. Do not use on any interior surface that plain water would deteriorate, because this product will have the same effect. Also avoid letting this product come into contact with vinegar or any acidic substance. Acid-based products will hamper the effectiveness of GM Vehicle Care Odor Eliminator.
3. Instructions and cautions are printed on the bottle, but additional help is available. If you encounter a persistent or recurring odor, you may call to obtain additional information and usage suggestions.

1. In the USA, call 1-800-955-8591.
2. In Canada, call 1-800-977-4145.

Tools Require

J 38778 Door Trim Pad and Clip Remover

Removal Procedure

1. Using J 38778 loosen the door opening carpet retainer clips.
2. Remove the carpet retainer from the vehicle.

Installation Procedure

1. Install the carpet retainer to the vehicle.
2. Position the door carpet retainer clips to the carpet slots and push down to secure.

J 38778 Door Trim Pad Clip Remover

1. Use J 38778 to loosen the carpet retainer clips.
2. Remove the rear side door opening carpet retainers from the vehicle.

1. Install the rear side door opening carpet retainers to the vehicle.
2. Position the door carpet retainer clips to the carpet slots and push down to secure.

Floor Carpet Drying

If the carpet or the pad or insulator is wet, use the following criteria for drying or for replacing the components

1. For a 1-piece carpet assembly bonded to a cotton or a fiber padding, replace the entire assembly.
2. For a 2-piece carpet assembly with a cotton or a fiber padding, replace the padding only. While the carpet is out of the vehicle, dry the carpet using the method described below.
3. For a 1-piece carpet assembly bonded to a foam padding or attached to a synthetic padding, dry the carpet using the method described below.
4. For a 2-piece carpet assembly with a synthetic padding, dry the assembly using the method described below.

Drying Method

1. If you observe puddles of liquid on the carpet face, use a wet vacuum to remove the excess moisture.
2. Blot the face of the carpet with a towel in order to absorb as much moisture as possible.
3. Point a fan at the affected area and air dry the carpet.

1. Remove the front seats. Refer to SEAT REPLACEMENT - FRONT BUCKET or to SEAT REPLACEMENT - SPLIT BENCH in Seats.
2. Remove the center console, if equipped. Refer to CONSOLE REPLACEMENT - FRONT FLOOR (D06) in Instrument Panel, Gages, and Console.
3. Remove the rear seat cushion. Refer to SEAT CUSHION REPLACEMENT - REAR in Seats.
4. Remove the carpet retainers. Refer to «CARPET RETAINER REPLACEMENT - FRONT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) for the rear «CARPET RETAINER REPLACEMENT - REAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
5. Remove the both instrument panel insulators. Refer to CLOSEOUT/INSULATOR PANEL REPLACEMENT - RIGHT and CLOSEOUT/INSULATOR PANEL REPLACEMENT - LEFT in Instrument Panel, Gages, and Console.
6. Remove the trim panel from the lower center pillar. Refer to «TRIM PANEL REPLACEMENT - LOWER CENTER PILLAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
7. Remove the quarter lower trim. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER LOWER»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
8. Reposition the front and rear door weatherstrips and remove the carpet retainers (1) from the clips.
9. Remove the carpet from the vehicle.

1. Install the carpet into the vehicle. Reach under the carpet and feed the following connectors through the slits in the carpet where required: The power seat adjusters The vacuum connector The seat belt warning wire connector
2. Install the carpet retainers over the clips on top of the rocker panels. Install the door weatherstrips.
3. Install the quarter lower trim. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER LOWER»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
4. Install the trim panel to the lower center pillar. Refer to «TRIM PANEL REPLACEMENT - LOWER CENTER PILLAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
5. Install the carpet retainers. Refer to «CARPET RETAINER REPLACEMENT - FRONT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) for the rear «CARPET RETAINER REPLACEMENT - REAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
6. Install both instrument panel insulators. Refer to CLOSEOUT/INSULATOR PANEL REPLACEMENT - RIGHT and CLOSEOUT/INSULATOR PANEL REPLACEMENT - LEFT in Instrument Panel, Gages, and Console.
7. Install the rear seat cushion. Refer to SEAT CUSHION REPLACEMENT - REAR in Seats.
8. Install the center console, if equipped. Refer to CONSOLE REPLACEMENT - FRONT FLOOR (D06) in Instrument Panel, Gages, and Console.
9. Install the front seats. Refer to SEAT REPLACEMENT - FRONT BUCKET or to SEAT REPLACEMENT - SPLIT BENCH in Seats.

1. Remove the rear seat cushion. Refer to SEAT CUSHION REPLACEMENT - REAR in Seats.
2. Remove the rear seat back. Refer to SEAT BACK REPLACEMENT - REAR (NON-FOLDING) or SEAT BACK REPLACEMENT - REAR (FOLDING) in Seats.
3. On stationary seat back models, remove the child seat belt bracket. Refer to Bracket Replacement - Child Seat Belt Restraint System in Seat Belts.
4. Remove the rear window trim panel. Refer to «TRIM PANEL REPLACEMENT - REAR WINDOW SHELF»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
5. Remove the upper quarter trim panel. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER UPPER»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
6. Remove the lower quarter trim panel. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER LOWER»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
7. On the split rear seat, remove the push-in retainers holding the rear compartment trim. Move the trim into the rear compartment.
8. Remove the sound barrier.

1. Reposition the rear compartment trim and install the push in retainers.
2. Install the sound barrier.
3. Install the rear window trim panel. Refer to «TRIM PANEL REPLACEMENT - REAR WINDOW SHELF»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
4. Install the upper quarter trim panel. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER UPPER»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
5. Install the lower quarter trim panel. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER LOWER»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
6. On stationary seat back models, install the child seat belt bracket. Refer to Bracket Replacement - Child Seat Belt Restraint System in Seat Belts.
7. Install the rear seat back. Refer to SEAT BACK REPLACEMENT - REAR (NON-FOLDING) or SEAT BACK REPLACEMENT - REAR (FOLDING) in Seats.
8. Install the rear seat cushion. Refer to SEAT CUSHION REPLACEMENT - REAR in Seats.

J 38778 Door Trim Clip Remover

1. Remove the sunshades. Refer to «SUNSHADE REPLACEMENT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
2. Remove the sunshade retainers (3). Refer to «SUNSHADE ANCHOR REPLACEMENT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
3. Disconnect the electric connectors to the rear view mirror and to the front antenna.
4. Remove the power sunroof switch, if equipped. Refer to SUNROOF SWITCH REPLACEMENT in Roof.
5. Remove the dome lamp, if equipped. Refer to DOME LAMP REPLACEMENT in Lighting Systems.
6. Remove the assist handles. Refer to «ASSIST HANDLE REPLACEMENT - FRONT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) and to «ASSIST HANDLE REPLACEMENT - REAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
7. Remove the side upper garnish molding from the windshield. Refer to «GARNISH MOLDING REPLACEMENT - WINDSHIELD PILLAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
8. Remove the upper quarter trim panels. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER UPPER»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
9. Pull down on the door opening weatherstrip seal on both the front and the rear doors.
10. Remove the rear window trim panel. Refer to «TRIM PANEL REPLACEMENT - REAR WINDOW SHELF»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
11. Disconnect the headliner electrical harness connector, located behind the right rear speaker.
12. Disconnect the OnStar® electrical connector, if equipped.
13. Disconnect the headliner electrical harness and the antenna lead, located behind the left rear speaker.
14. Use J 38778 in order to remove the rear retainers (2).
15. Rotate the right front seatback to a horizontal position.
16. Remove the headliner (1) from the vehicle through the right front door.

1. Install the headliner (1) in the vehicle through the right front door.
2. Install the headliner (1): 2.1. Align the sunshade holes in the headlining with the respective hole in the body structure. 2.2. Engage the front hook and the loop fasteners
3. Connect the headliner electrical harness and the antenna lead, located behind the left rear speaker.
4. Connect the OnStar® electrical connector, if equipped.
5. Connect the headliner electrical harness connector, located behind the right rear speaker.
6. Install the rear window trim panel. Refer to «TRIM PANEL REPLACEMENT - REAR WINDOW SHELF»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
7. Install the rear retainers (2).
8. Install the door opening weatherstrip seal on both the front and the rear doors in order to hold the headliner (1) in place.
9. Install the center pillar upper trim panels. Refer to «TRIM PANEL REPLACEMENT - UPPER CENTER PILLAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
10. Install the upper quarter trim panels. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER UPPER»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
11. Install the side upper garnish molding to the windshield. Refer to «GARNISH MOLDING REPLACEMENT - WINDSHIELD PILLAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
12. Install the assist handles. Refer to «ASSIST HANDLE REPLACEMENT - FRONT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) and to «ASSIST HANDLE REPLACEMENT - REAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
13. Install the dome lamp, if equipped. Refer to DOME LAMP REPLACEMENT in Lighting Systems.
14. Install the power sunroof switch, if equipped. Refer to SUNROOF SWITCH REPLACEMENT in Roof.
15. Connect the electric connector to the rear view mirror.
16. Install the sunshade retainers (1). Refer to «SUNSHADE ANCHOR REPLACEMENT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
17. Install the sunshades. Refer to «SUNSHADE REPLACEMENT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .

1. Pull down on the assist handle in order to expose the retaining screws (1).
2. Remove the assist handle screws (1).
3. Remove the assist handle.

1. Position the assist handle in the vehicle. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
2. Install the assist handle screws (1). Tighten Tighten the screws to 3 N.m (27 lb in).

1. Pull the assist handle (3) down to expose the retaining screw covers (2).
2. Lift the covers and remove the retaining screws (1).
3. Pull the handle and the bezel away from the headliner and disconnect the lamp electrical connector (3).
4. Remove the assist handle from the vehicle.

Scheme 14

1. Position the assist handle by the headliner.
2. Connect the lamp electrical connector (3). NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
3. Install the assist handle retaining screws (1). Tighten Tighten the screws to 3 N.m (27 lb in).
4. Close the screw covers (2) and return the handle to the upright position.

1. Rotate the sunshade so that the bottom edge is pointing straight down.
2. Remove the sunshade from the anchor.
3. Move the sunshade rearward, about 50 mm (2 inches) until the ridge on the sunshade stem (2) is flush to the slot in the flange (1).
4. Pull down on the free end of the sunshade until a rectangular slot (3) appears between the flange and the retainer bezel. Maintain this pressure for the next two steps. IMPORTANT: The flat-bladed tool used to remove the sunshade must completely fill the slot on the sunshade flange. If there is any free play, the plastic flange will be distorted and the sunshade will not be released.
5. Insert a flat-bladed tool in the flange slot. Hold this tool in a vertical position and maintain an upward pressure on the tool equal to the downward pressure on the sunshade.
6. Quickly rotate the sunshade rearward approximately 100 mm (4 in). At this position you will feel a first disengagement.
7. Maintain the upward pressure on the flat-bladed tool and now press upward on the free end of the sunshade. Then continue to rotate the sunshade towards the side door glass.
8. Remove the flat-bladed tool and pull down on the front of the sunshade arm to separate it from the bezel.
9. Disconnect the electrical connector (3), if equipped.
10. Remove the sunshade from the vehicle.
11. Insert 2 thin, flat-bladed tools into two sunshade retainer bezel slots and press inward to release the locking tabs. Pull down to remove the bezel.
12. Remove the sunshade retainer bezel from the headliner.

1. Align the sunshade retainer bezel to the headliner and apply pressure until fully seated.
2. Position the sunshade in the vehicle.
3. Connect the electrical connector (3), if equipped.
4. Align the sunshade arm so that the triangular base with the arrow (4) is parallel to the sunshade (3).
5. Position the sunshade so it is parallel to the door.
6. Press up until the flange is seated in the retainer bezel. Maintain this pressure.
7. Quickly rotate the sunshade toward the windshield until it is past the sunshade anchor. A slight click will be heard once the retainer shaft seats into the bezel.
8. Return the sunshade to its stored position.

1. Unhook the sunshade from the retainer.
2. Use a flat-bladed tool in order to push upward on the service tab until the tab snaps. Ensure that the tab is recessed in the retainer.
3. Gently pull downward on the retainer. Remove the retainer from the headliner.

1. Set locking tab on bezel to pre-installation position: Locking tab installed position (1) Locking tab released position (2) Locking tab pre-installed position (3)
2. Push the retainer upward into the headliner.
3. Press upward on the service tab until the tab is flush with the retainer.
4. Return the sunshade to the original position.

Pull the door weatherstrip away from the pinchweld flange to expose the garnish molding.

1. Pull on the garnish molding to disengage the 2 clips.
2. Remove the garnish molding from the car.

Scheme 15

Position the garnish molding by the front pillar.

1. Push on the molding to engage the 2 clips.
2. Press the weatherstrip back onto the pinchweld flange.

Scheme 16

1. Remove the carpet retainer. Refer to «CARPET RETAINER REPLACEMENT - FRONT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
2. Reposition the front door weatherstrip (2) as necessary.
3. Grasp the lower end of the molding (1) and pull away from the pillar.
4. Remove the molding from the vehicle.

1. Position the molding (1) in the vehicle.
2. Press the molding down onto the retainers until seated.
3. Reset the weatherstrip (2).
4. Install the carpet retainer. Refer to «CARPET RETAINER REPLACEMENT - FRONT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .

1. Open the guide loop attachment cover to the upper seat belt.
2. Remove the guide loop attachment nut.
3. Remove the guide loop attachment from the adjuster bracket.
4. Remove the door weatherstrip from the center pillar pinch weld flange to expose the upper trim panel.
5. Grasp the trim panel firmly with both hands. Pull the panel away from the center pillar.

1. Position the upper trim panel to the center pillar.
2. Push firmly on the trim panel in order to seat the retainers.
3. Install the guide loop attachment for the upper seat belt to the adjuster bracket. NOTE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
4. Install the attachment nut for the seat belt guide loop Tighten Tighten the nut to 42 N.m (31 lb ft).
5. Install the door weatherstrip to the center pillar.

1. Remove the front carpet retainer. Refer to «CARPET RETAINER REPLACEMENT - FRONT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
2. Remove the rear carpet retainer. Refer to «CARPET RETAINER REPLACEMENT - REAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
3. Remove the door weatherstrip from the center pillar pinch weld flange to expose the lower trim panel.
4. Starting at the base, grasp the trim panel firmly with both hands. Pull the panel away from the center pillar.
5. Remove the seat belt from the slot in the lower trim panel.

1. Install the seat belt to the slot in the lower trim panel.
2. Position the lower trim panel to the center pillar.
3. Push firmly on the lower trim panel in order to seat the retainers.
4. Install the front carpet retainer. Refer to «CARPET RETAINER REPLACEMENT - FRONT»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
5. Install the rear carpet retainer. Refer to «CARPET RETAINER REPLACEMENT - REAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
6. Install the door weatherstrip to the center pillar.

Tools Required

J 38778 Door Trim Pad and Garnish Clip Remover

1. Remove the rear seat back. Refer to SEAT BACK REPLACEMENT - REAR (NON-FOLDING) or SEAT BACK REPLACEMENT - REAR (FOLDING) .
2. Remove the door weatherstrip from the pinch weld flange to expose the upper quarter trim panel.
3. Use J 38778 to disengage the push-in retainers and remove the trim panel.

1. Position the upper quarter trim panel into place.
2. Install the push-in retainers to secure the trim panel.
3. Install the door weatherstrip onto the pinch weld flange.
4. Install the rear seat back. Refer to SEAT BACK REPLACEMENT - REAR (NON-FOLDING) or SEAT BACK REPLACEMENT - REAR (FOLDING) .

J 38778 Door Trim Pad and Garnish Clip Remover

1. Remove the rear carpet retainer. Refer to «CARPET RETAINER REPLACEMENT - REAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
2. Remove the rear seat cushion. Refer to SEAT CUSHION REPLACEMENT - REAR in Seats.
3. Remove the rear seat back. Refer to SEAT BACK REPLACEMENT - REAR (NON-FOLDING) or SEAT BACK REPLACEMENT - REAR (FOLDING) in Seats.
4. Remove the door weatherstrip from the pinch weld flange to expose the trim panel
5. Use J 38778 in order to disengage the push-in retainers. Remove the quarter lower trim.

1. Engage the push-in retainers in order to install the quarter lower trim.
2. Install the door weatherstrip.
3. Install the rear seat back. Refer to SEAT BACK REPLACEMENT - REAR (NON-FOLDING) or SEAT BACK REPLACEMENT - REAR (FOLDING) in Seats.
4. Install the rear seat cushion. Refer to SEAT CUSHION REPLACEMENT - REAR in Seats.
5. Install the rear carpet retainer. Refer to «CARPET RETAINER REPLACEMENT - REAR»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .

J 38778 Door Trim Clip Remover

1. Remove the rear seat cushion. Refer to SEAT CUSHION REPLACEMENT - REAR in Seats.
2. Remove the rear seat back. Refer to SEAT BACK REPLACEMENT - REAR (NON-FOLDING) or SEAT BACK REPLACEMENT - REAR (FOLDING) in Seats.
3. Remove the rear upper quarter trim panel. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER UPPER»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
4. Use J 38778 to remove the push pins from the panel front.
5. Lift the panel and remove the seat belts through the slots in the trim panel.
6. Front inside the rear compartment, disengage the clip by the high mount stoplamp.
7. Slide the panel forward to disengage the integral hook from the retaining hole.
8. Disconnect the electrical cable connector for the high mount stoplamp, located on the passenger end of panel.
9. Remove the rear shelf from the vehicle.

1. Position the panel in the vehicle.
2. Connect the electrical cable connector for the high mount stoplamp, located on the passenger end of panel.
3. Slide the panel rearward to engage the integral hook in the retaining hole.
4. Lift the panel and route the seat belts through the slots in the trim panel.
5. Install the push pins in the panel front.
6. Install the rear quarter upper trim panel. Refer to «TRIM PANEL REPLACEMENT - REAR QUARTER UPPER»(/buick/century/vi-1997-2005/remont/exteriorinterior-trim/#interior-trim) .
7. Install the rear seat back. Refer to SEAT BACK REPLACEMENT - REAR (NON-FOLDING) or SEAT BACK REPLACEMENT - REAR (FOLDING) in Seats.
8. Install the rear seat cushion. Refer to SEAT CUSHION REPLACEMENT - REAR in Seats.
9. From inside the rear compartment, install the bulb in the high mount stoplamp.

Scheme 17

See also:
• CARPET RETAINER REPLACEMENT - FRONT
