LEFT OR RIGHT TIE ROD
Note. Numbers in text refer to numbers in figures.
Removal & Installation
Remove front wheel. Unfasten nut. Force tie rod end off swivel bearing with special tool (32 3 090). (Scheme 1) During installation, keep journal on tie rod end and bore hole in swivel bearing clean and free from grease. Replace self-locking nut.
Scheme 1
Determine measurement (A) to simplify adjustment of front axle. Release clamping nut. Screw off tie rod end. If necessary, grip tie rod with open-end wrench. During installation, check mount clamping ring (1). Screw in tie-rod end to distance (A). (Scheme 2) After installation, perform chassis alignment check. See SPECIFICATIONS & PROCEDURES. Carry out steering angle sensor adjustment. See STEERING ANGLE SENSOR.
Scheme 2
