BRAKE PAD WARNING LIGHT RESET - PROCEDURE 1

To reset light after replacing brake pads, turn ignition on with engine off. Wait 30 seconds. Brake pad warning indicator light will switch off.

BRAKE PAD WARNING LIGHT RESET - PROCEDURE 2

Start engine. Brake pad warning indicator will switch off.

OXYGEN SENSOR WARNING LIGHT RESET - PROCEDURE 1

1. Every 30,000 miles (25,000 miles on 528i) the OXYGEN light in dash will come on as a reminder to replace the oxygen sensor. NOTE: On 528e models, pull the protective metal plate off before removing oxygen sensor.
2. On 528e models, no interval reset switch is provided. After replacing sensor, remove instrument panel. Remove and discard bulb for OXYGEN sensor light.
3. On all other models, trace speedometer cable to interval switch (in-line with cable, mounted on frame rail left of transmission). Press White reset button. (Scheme 1) Ensure warning light is out.

Scheme 1

OXYGEN SENSOR WARNING LIGHT RESET - PROCEDURE 2

Note. Some late production (February 1985 and later) BMW models have a reset button on rear of the light control assembly located near pedal assembly. Press button to reset light after servicing oxygen sensor.

No reset switch is provided. When oxygen sensor light comes on, service oxygen sensor. Remove and discard bulb from indicator.

SERVICE INTERVAL REMINDER LIGHTS

Note. This is sometimes referred to as the "Oil Change Light" or "Oil Service Light".

Note. The service indicator can only be reset using the reset mode in the instrument cluster or by using BMW hardware. This procedure applies to 3-Series from production date 9/99, and 5-Series and 7-Series from production date 9/00 (except 2002-05 7-Series and 2004-05 5-Series) without an engine compartment diagnostic connector. On models that still use the round diagnostic connector in engine compartment, use SIA reset tool to reset service lights. See SERVICE INTERVAL LIGHT RESET - PROCEDURE 1 . On models without the round diagnostic connector in the engine compartment, the use of the SIA reset tool is not possible. See SERVICE INTERVAL LIGHT RESET - PROCEDURE 2 . For 2002-up models with condition based service (CBS) interval system reset procedure, see SERVICE INTERVAL LIGHT RESET - PROCEDURE 3 .

Note. To determine the appropriate reset procedure, refer to SERVICE INTERVAL REMINDER LIGHT RESET INDEX . Only vehicles listed in this index have a service interval reminder.

SERVICE INTERVAL REMINDER LIGHT RESET INDEX

SERVICE INTERVAL LIGHT RESET - PROCEDURE 1

1. To reset instrument cluster SIA OIL SERVICE indicator, turn ignition switch to ON position. Connect Service Indicator Resetter (62 1 110) to diagnosis connector in engine compartment. (Scheme 2)
2. Press Yellow OIL SERVICE button. Green LED will illuminate. Wait until Yellow LED illuminates and then goes out again. Ensure that OIL SERVICE indicator has been reset.
3. To reset SERVICE INTERVAL indicator, press Red INSPECTION service button for inspection. Green LED illuminates. Wait until Red LED illuminates and then goes out again. Turn ignition switch to OFF position, wait 20 seconds and repeat procedure in order to adapt interval of annual inspection to inspection. Ensure that SERVICE INTERVAL indicator has been reset.

Scheme 2

SERVICE INTERVAL LIGHT RESET - PROCEDURE 2

Reset service light by performing the following

1. Ignition key must be in OFF position.
2. Press and hold trip odometer reset button in the instrument cluster (left button), and turn ignition key to first position.
3. Keep the button pressed for approximately 5 seconds until one of the following words appear in the display: "OIL SERVICE", or "INSPECTION", with "RESET".
4. Release reset button and press it again until "RESET" begins to flash in the display. (Scheme 3)and (Scheme 4).
5. Service due is shown with "RESET" if coded minimum consumption limit has been reached and resetting is possible. If "RESET" is not shown, minimum limit has not been reached and resetting is not possible.
6. While "RESET" is flashing, press left button briefly to reset service interval. After display has shown new interval, following will appear: "END SIA".
7. System can only be reset again after 2.5 gallons of fuel have been consumed.

Scheme 3

Scheme 4

SERVICE INTERVAL LIGHT RESET - PROCEDURE 3

The BMW maintenance system SIA IV (service interval indicator) is used on X3 models (E83). The service interval indicator is a system subject to constant development which in its development stages has been integrated in various model series such as E85 (Z4) and E46 (3 and M3-Series).

The service indicator appears in the LC display in the instrument cluster's speedometer. The indicator is shown for 5 seconds in the LC display after terminal R is "ON". (Scheme 5)

Scheme 5

Resetting Service Interval Indicator

Resetting the service interval indicator for the oil service and inspection procedures can only be done by pressing the left button in the instrument cluster. (Scheme 6)

Scheme 6

SERVICE INTERVAL LIGHT RESET - PROCEDURE 4

Note. Use this procedure on vehicles with an instrument panel like the ones (Scheme 7), (Scheme 8), or (Scheme 9). If vehicle has an instrument panel like the one (Scheme 10), see Service Interval Light Reset - Procedure 5.

Models using a Condition Based Service (CBS) service interval system, which displays a Service Need Display (SND). When ignition is on, Service Need Display appears under the speedometer in the instrument cluster for 10 seconds in the place where the fuel tank level is normally displayed. The first line corresponds to the mileage dependent service items. It specifies the mileage when the next service is due.

If the mileage is exceeded (service overdue), it appears with a minus sign. The second line corresponds to the time dependent service items and is displayed by a clock symbol. It specifies the weeks/months/years when the next service is due. If the service is overdue, it appears with a minus sign. The actual service item (with additional information) can be viewed in the control display.

Note. On some models an appropriate scan tool may be used to reset CBS service schedules. By using suitable diagnostic equipment connected to the vehicle diagnostic connector it is possible to reset CBS service schedules at any time. By selecting the `CBS' option, the diagnostic equipment will gather information regarding the current state of CBS items from their relevant modules on the CAN network. See SERVICE INTERVAL LIGHT RESET - PROCEDURE 6 .

Service reset is accomplished using instrument cluster

1. Insert key into ignition.
2. Press ignition start/stop button without depressing the clutch or brake, and wait for the service reminder to dissapear.
3. Immediately after the service reminder indicator goes out, press and hold the odometer reset button or stalk. After 3 secs a warning triangle will appear, keep the odometer button pressed and after another 2-3 secs an oil can will appear. NOTE: If the odometer button is pressed too long (10 secs in total), German writing will appear (giving the software level/ can bus etc. of the vehicle). This indicates that you've overshot the reset procedure and you need to re-start from the beginning.
4. The service menu should now be displayed. Use the button (twist if the switch is a stalk - or if a button, tap repeatedly) to scroll up/down through the various service items. NOTE: On newer models, it may be the rocker/toggle switch on the turn indicator lever that is used to scroll up/down through the various service items. (Scheme 9)
5. When the item to be reset is showing, press the BC button on end of turn indicator lever. "Reset" should now appear in the display. Press in and hold the BC button for 2-3 secs and a whirling clock icon will be displayed. The reset procedure for the selected service item is done.
6. Scroll up/down to select another item (as in step 4), or press the ignition start/stop button to exit.

Note. Residual wear or remaining time are specified (possibly with a minus sign). The "1" symbol means that you can reset service operation (early production vehicles may show an "F"), while a "0" indicates it is not resettable (the first 20 percent of the service interval is also protected against accidental reset). For additional information about Condition Based Service (CBS), see RESETTING AND CORRECTING CONDITION BASED SERVICE under PROGRAMMING in SELF-DIAGNOSIS - 7-SERIES article.

Scheme 7

Scheme 8

Scheme 9

SERVICE INTERVAL LIGHT RESET - PROCEDURE 5

Note. Use this procedure on vehicles with an instrument panel like the one (Scheme 10) If vehicle has an instrument panel like the ones (Scheme 7), (Scheme 8), or (Scheme 9), see Service Interval Light Reset - Procedure 4

On-the-vehicle service operations can be reset at the instrument panel.

Note. A reset is only possible in the car if: There is no Check Control message Availability of the service job is under 90% On-board date must be correctly set

Note. On some models an appropriate scan tool may be used to reset CBS service schedules. By using suitable diagnostic equipment connected to the vehicle diagnostic connector it is possible to reset CBS service schedules at any time. By selecting the `CBS' option, the diagnostic equipment will gather information regarding the current state of CBS items from their relevant modules on the CAN network. See SERVICE INTERVAL LIGHT RESET - PROCEDURE 6 .

Note. Resetting of a service job must always be carried out after a maintenance measure has been completed.

1. Switch the ignition on.
2. Press the odometer reset button (1) for approx. 10 seconds, until the 1st service job appears in the display (2). (Scheme 10)
3. Bring up the next item by briefly pressing the button again.
4. Select the desired service job.
5. If a reset is possible, this is displayed in the instrument panel as "Reset executable".
6. Start the reset by pressing the button for 3 seconds.
7. Confirm text message "Execute reset?" by pressing the button for 3 seconds again.
8. The status of the reset is indicated in the display by a progress bar and in text as "Reset running".
9. The reset is confirmed after completion as "Reset successful".

Scheme 10

SERVICE INTERVAL LIGHT RESET - PROCEDURE 6

CBS Reset Using BMW Diagnosis System (Scan Tool)

The CBS jobs can be reset via the diagnosis system on the following path

1. Start diagnosis
2. Carry out vehicle identification
3. Function selection
4. Service functions
5. Maintenance
6. CBS reset

TPMS RESET - PROCEDURE 1

1. Set the tire pressure on all wheels to specification.
2. Turn ignition switch to ON position, with engine off.
3. Press reset button (for no longer than 10 seconds) until tire pressure warning light illuminates Yellow for a few seconds. (Scheme 11), (Scheme 12), see scheme 13, or see scheme 17. NOTE: On some X5 models, the reset button is marked "RDC".
4. Drive vehicle. Initialization is automatically completed during the drive, without any feedback issued.

TPMS RESET - PROCEDURE 2

Note. The initialization finishes during driving, which can be interrupted at any time. When driving resumes, the initialization is continued automatically.

1. Set the tire pressure of all wheels to specification.
2. Start engine, but do not start driving.
3. On Control Center, select "RPA" from the "SETTINGS" menu and confirm selection. The initialization menu will appear. see scheme 14
4. Select "SET" and confirm selection.
5. Drive vehicle. The message "FTM IS BEING INITIALIZED" will be displayed. see scheme 15 NOTE: It takes at least 10 minutes before the TPM system can detect and report a flat tire.
6. Select counterclockwise left arrow button and confirm to exit from menu.

TPMS RESET - PROCEDURE 3

Note. The initialization finishes during driving, which can be interrupted at any time. When driving resumes, the initialization is continued automatically.

1. Set the tire pressure of all wheels to specification.
2. Start the engine.
3. Press iDrive knob down once to enter Vehicle Info.
4. Select Settings.
5. Select Vehicle Tires.
6. Select TPM.
7. Select Reset.
8. Scroll to Yes.
9. Select "YES" and press the controller.
10. After selecting Yes, drive vehicle until tires on iDrive screen turn green.

TPMS RESET - PROCEDURE 4

Note. The initialization finishes during driving, which can be interrupted at any time. When driving resumes, the initialization is continued automatically.

1. Set the tire pressure of all wheels to specification.
2. Press "MENU" button to open start menu.
3. Open the i-menu of the Control Center.
4. Select "SETTINGS" and press the controller.
5. Select "VEHICLE" and press the controller. see scheme 16
6. Select "TIRES: TPM" and press controller.
7. Start engine, but do not start driving.
8. Select "RESET" and press the controller.
9. Select "YES" and press the controller.
10. Drive vehicle. The message "RESETTING TPM...." will be displayed. Initialization is automatically completed during the drive. When initialization is complete, "STATUS: TPM ACTIVE" message will be displayed.

TPMS RESET - PROCEDURE 5

1. Set the tire pressure of all wheels to specification.
2. Start engine, but do not start driving.
3. Press reset button (for no longer than 10 seconds) until tire pressure warning light illuminates Yellow for a few seconds. see scheme 17, see scheme 18 or see scheme 19.
4. Drive vehicle. Initialization is automatically completed during the drive, without any feedback issued.

Resetting TPM With iDrive

1. Set the tire pressure of all wheels to specification.
2. Turn ignition switch ON.
3. Press controller to call up I menu. see scheme 20
4. Select SETTINGS and press controller.
5. Select CAR/TIRES and press controller.
6. If necessary, switch to top field and select TIRES/RDC and press controller.
7. Start engine.
8. Select CONFIRM TIRE PRESSURE and press controller.
9. Drive vehicle. Initialization is automatically completed during the drive, without any feedback issued.

Scheme 11

Resetting TPM Without iDrive

1. Set the tire pressure of all wheels to specification.
2. Start engine.
3. Move turn signal lever up or down until TPM warning symbol and RESET appears. see scheme 21
4. Press BC button on end of turn signal lever to confirm selection.
5. Press and hold BC button for approximately 5 seconds until a CHECK/TICK appears after RESET.
6. Drive vehicle. Initialization is automatically completed during the drive, without any feedback issued.

Scheme 12
